MONITOR STRATEGY
| Related DTCs | P0010: Camshaft oil control valve assembly (bank 1) range check P0020: Camshaft oil control valve assembly (bank 2) range check |
| Required Sensors/Components (Main) | Camshaft oil control valve assembly |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Ignition switch | ON |
| Starter | OFF |
| Time after ignition switch off to ON | 0.5 seconds or more |
| Either of the following conditions is met | Conditions A or B |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty cycle | Less than 70% |
| B. All of the following conditions are met | |
| Battery voltage | 13 V more |
| Target duty cycle | Less than 80% |
| Current cut status | Not cut |
TYPICAL MALFUNCTION THRESHOLDS
| Output duty cycle | 100% or more |
| Output duty cycle | 3% or less |
COMPONENT OPERATING RANGE
| VVT oil control valve duty ratio | More than 3%, and Less than 100% |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 97
Scheme 97: WIRING DIAGRAM
PROCEDURE
- READ OUTPUT DTC (DTC P0010 OR P0020) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTC after recording the freeze frame data and DTC. Turn the ignition switch off. Start the engine and allow the engine to idle. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0010 or P0020 is output A DTC is not output B B --> See step 4 A: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect the camshaft timing oil control valve assembly. Refer to «INSPECTION»(ref-554463-S38971762932013052000000) . NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY - ECM) Disconnect the camshaft timing oil control valve assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition C4-1 - E10-19 (OC1+) Always Below 1 ohms C4-2 - E10-20 (OC1-) Always Below 1 ohms C3-1 - E9-19 (OC2+) Always Below 1 ohms C3-2 - E9-20 (OC2-) Always Below 1 ohms C4-1 or E10-19 (OC1+) - Body ground Always 10 kohms or higher C4-2 or E10-20 (OC1-) - Body ground Always 10 kohms or higher C3-1 or E9-19 (OC2+) - Body ground Always 10 kohms or higher C3-2 or E9-20 (OC2-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-554459-S38977550292013052000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-554463-S15449106332013052000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-554463-S20232329082013052000000)
| Related DTCs | P0011: Advanced camshaft timing (bank 1) P0012: Retard camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retard camshaft timing (bank 2) |
| Required Sensors/Components (Main) | Camshaft timing oil control valve assembly Camshaft timing gear assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor VVT sensor Engine coolant temperature sensor |
| Frequency of Operation | Continuous |
| Duration | Less than 10 seconds |
| MIL Operation | P0011 and P0021: Immediate P0012 and P0022: 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve) P0016, P0018 (VVT system - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop Fuel Control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0346, P0347, P0348 (VVT Sensor) |
| Battery voltage | 11 V or more |
| Engine speed | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at advanced valve timing |
P0011 AND P0021: ADVANCED CAMSHAFT TIMING
| Both of following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit. |
| Valve timing | No change at retarded valve timing |
P0012 AND P0022: RETARDED CAMSHAFT TIMING
- If the difference between the target and actual camshaft timing is greater than the specified value, the ECM operates the VVT controller for 10 seconds by applying and releasing oil pressure. Then, the ECM monitors the camshaft timing change for 10 seconds.
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 98
Scheme 98: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 3 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [F] through [H].
- Repeat the pattern of accelerating the vehicle from rest to approximately 60 km/h (37 mph) and then decelerating the vehicle 10 to 15 times [F]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Depress the accelerator pedal by a large amount.
- Idle the engine for 3 minutes or more [G].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result again. HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform the following procedure.
- Perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0016: Camshaft Timing Misalignment at idling |
| Required Sensors/Components (Main) | Camshaft timing gear assembly |
| Required Sensors/Components (Related) | VVT sensor Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve) P0016, P0018 (VVT system - misalignment) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0346, P0347, P0348 (VVT Sensor) |
| Engine speed | 500 to 1000 RPM |
| One of following conditions is met | |
| VVT learning value at maximum retarded valve timing (Bank 1) | Less than 22.5°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | Less than 22.5°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 1) | More than 45.2°CA (crankshaft angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | More than 45.2°CA (crankshaft angle) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 99
Scheme 99: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0016 or P0018.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Idle the engine for 5 minutes or more [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [G].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Check the DTC judgment result.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0016 or P0018 is output A DTC P0016 or P0018 and other DTCs are output B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT LINEAR) HINT: If the VVT system can be operated through the Active Test, it can be assumed that the VVT system is operating normally. Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the VVT Linear (Bank 1) or Control the VVT Linear (Bank 2) / VVT Change Angle #1 or VVT Change Angle #2. Perform the Active Test. Check that the displacement angle varies. OK Displacement angle varies. NG --> See step 4 OK: Go to next step
- ADJUST VALVE TIMING Adjust the valve timing. Refer to «INSTALLATION»(ref-554377-S03950371072013052000000) . NEXT --> See step 7
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY Inspect camshaft timing oil control valve assembly. Refer to «INSPECTION»(ref-554463-S38971762932013052000000) . NG --> See step 9 OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER See step 6 NG --> CLEAN OR REPLACE OIL CONTROL VALVE FILTER OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY See step 7 NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P0016 or P0018 is output B B --> See step 10 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY. Refer to «REMOVAL»(ref-554463-S15449106332013052000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-554463-S20232329082013052000000)
| Related DTCs | P0031: Air fuel ratio sensor (bank 1 sensor 1) heater Range check (Low electrical current) P0032: Air fuel ratio sensor (bank 1 sensor 1) heater Range check (High electrical current) P0051: Air fuel ratio sensor (bank 2 sensor 1) heater Range check (Low electrical current) P0052: Air fuel ratio sensor (bank 2 sensor 1) heater Range check (High electrical current) P101D: Air fuel ratio sensor (bank 1 sensor 1) heater performance P103D: Air fuel ratio sensor (bank 2 sensor 1) heater performance |
| Required Sensors/Components (Main) | Air fuel ratio sensor (bank 1, 2 sensor 1) heater |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second: P101D and P103D 10 seconds: P0031 and P0051 10.24 seconds: P0032 and P0052 |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Air fuel ratio sensor heater performance fail (P101D, P103D) | Not detected |
| Heater output duty cycle | 30% or higher |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Heater output duty cycle | Higher than 0% |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Time after heater on | 5 seconds or more |
| Air fuel ratio sensor heater low current fail (P0031, P0051) | Not detected |
| Heater output duty cycle | 10% or higher, and less than 60% |
| Heater on current | 0.8 A or higher |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Air fuel ratio sensor heater ON current | Less than 0.8 A |
| Both of the following conditions are met | |
| Air fuel ratio sensor heater output | ON |
| Hybrid IC high current limiter monitor input | Fail |
| Both of the following conditions are met | |
| Air fuel ratio sensor heater OFF current | Higher than 11 A |
| Hybrid IC high current limiter monitor input | Fail |
| Air fuel ratio sensor heater current | 0.8 A or more |
| Both of the following conditions are met | |
| Air fuel ratio sensor heater output | ON |
| Hybrid IC high current limiter monitor input | Pass |
| Air fuel ratio sensor heater ON current | 11 A or less |
Scheme 100
Scheme 100: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051, P0052, P101D or P103D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 101
Scheme 101: WIRING DIAGRAM
| Related DTCs | P0037: Heated oxygen sensor (bank 1 sensor 2) heater range check (Low electrical current) P0038: Heated oxygen sensor (bank 1 sensor 2) heater range check (High electrical current) P0057: Heated oxygen sensor (bank 2 sensor 2) heater range check (Low electrical current) P0058: Heated oxygen sensor (bank 2 sensor 2) heater range check (High electrical current) P0141: Heated oxygen sensor (bank 1 sensor 2) heater performance P0161: Heated oxygen sensor (bank 2 sensor 2) heater performance P102D: Heated oxygen sensor (bank 1 Sensor 2) heater Performance P105D: Heated oxygen sensor (bank 2 Sensor 2) heater Performance |
| Required Sensors/ Components (Main) | Heated oxygen sensor (bank 1, 2 sensor 2) heater |
| Required Sensors/ Components (Related) | |
| Frequency of Operation | Continuous: P0037, P0038, P0057, P0058, P102D, P105D Once per driving cycle: P0141, P0161 |
| Duration | 2.064 seconds: P0038, P0058 0.5 seconds: P0037, P0057, P102D, P105D 10 seconds: P0141 and P0161 |
| MIL Operation | Immediate: P0037, P0038, P0057, P0058, P102D, P105D 2 driving cycles: P0141, P0161 |
| Sequence of Operation | None |
| Monitor runs whenever the following DTCs are not stored | None |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Learned heater off current operation | Succeeded |
| Oxygen sensor heater high current fail (P0038, P0058) | Not detected |
| Heater on current - Learned heater off current | 0.3 A or less |
| Heater output | On |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Heater off current | Higher than 3.5 A |
| Hybrid IC high current limiter monitor input | Fail |
| Oxygen sensor heater high current fail (P0038 P0058) | Not detected |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| All of the following conditions are met | |
| Oxygen sensor heater circuit fail (P0037, P0038, P0057, P0058, P102D and P105D) | Not detected |
| Battery voltage | 10.5 V or higher |
| Fuel cut | Off |
| Time after fuel cut on to off | 30 seconds or more |
| Accumulated heater on time | 100 seconds or more |
| Learned heater off current operation | Completed |
| Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or higher |
| Engine | Running |
| Starter | Off |
| Catalyst active air fuel ratio control | Not operating |
| Time after heater on | 10 seconds or more |
| Learned heater off current operation | Completed |
| Oxygen sensor heater low current fail (P0037, P0057) | Not detected |
| Oxygen sensor heater high current fail (P0038, P0058) | Not detected |
| Heater current - Learned heater off current | 0.3 A or less |
| Heater on current | 1 A or less |
| Both of the following conditions are met | |
| Hybrid IC high current limiter monitor input | Fail |
| Heater output | On |
| Heater resistance | Varies with sensor element temperature (Example: Higher than 23 ohms) |
| Heater on current | Higher than 1 A |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 102
Scheme 102: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141, P0161, P102D or P105D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Throttle position (throttle position sensor voltage) | 0.2 V or more, and less than 2 V |
| Time after engine starts | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature | 70°C (158°F) or more |
| Estimated Load | 30% or more and less than 70% |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Crankshaft position sensor circuit fail (P0335) | Not detected |
| Throttle position sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| Canister pressure sensor circuit fail (P0452, P0453) | Not detected |
| EVAP leak detection pump fail (P2401, P2402) | Not detected |
| EVAP vent valve fail (P2419, P2420) | Not detected |
| Both of following conditions 1 and 2 met | |
| 1. Averaged engine load value ratio | Less than 0.85, more than 1.15 (varies with estimated engine load) |
| 2. Averaged air fuel ratio | Less than -20%, or more than 20% |
Scheme 103
Scheme 103: CONFIRMATION DRIVING PATTERN
- Connect Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 80 km/h (50 mph) to 112 km/h (70 mph) for 5 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [C] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0101 is output A P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 6 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. Refer to «COMPONENTS»(ref-554377-S09307904132013052000000) . OK PCV valve and hose are connected correctly and are not damaged. NG --> See step 7 OK: Go to next step
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY Replace the mass air flow meter sub-assembly. Refer to «REMOVAL»(ref-554463-S20636246822013052000000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . Turn the ignition switch off and wait for at least 30 seconds. Turn the ignition switch to ON. Turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness. Input the DTC: P0101. Check the DTC judgment. RESULT Result Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit NEXT --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPAIR OR REPLACE PCV HOSE. Refer to «COMPONENTS»(ref-554377-S09307904132013052000000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | Mass air flow meter sub-assembly |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate: Engine speed less than 4000 RPM 2 driving cycles: Engine speed 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | 0.2 V or more, and 4.9 V or less |
Scheme 104
Scheme 104: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] through [E] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 105
Scheme 105: WIRING DIAGRAM
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine coolant temperature at ECM started by internal engine off timer | 40°C (-40°F) or more |
| Engine coolant temperature before engine stop | 70°C (158°F) or more |
| Time that mass air flow is low before engine stop | 35 minutes or more |
| Accumulated mass air flow amount in previous driving cycle | 1815 g or more (Automatic Transmission) 3359 g or more (Manual Transmission) |
| Key-off duration | 30 minutes |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| All of the following conditions are met | |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| Engine coolant temperature before engine stop | 70°C (158°F) or more |
| Accumulated mass air flow amount | 1815 g or more (Automatic Transmission) 3359 g or more (Manual Transmission) |
| Either of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| Intake air temperature circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0102, P0103) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Intake air temperature change | Less than 1°C (2°F) |
| Intake air temperature change | Less than 1°C (2°F) |
Scheme 106
Scheme 106: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is less than 1°C (1.8°F), the intake air temperature sensor (mass air flow meter sub-assembly) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check the DTC judgment result again [F]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [E] and [F] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> See step 3 A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-554463-S20636246822013052000000)
Scheme 107
- The intake air temperature sensor, mounted on the mass air flow meter sub-assembly, monitors the intake air temperature. The intake air temperature sensor has a built in thermistor with a resistance that varies according to the temperature of the intake air. When the intake air temperature sensor is low, the resistance of the thermistor increases. When the temperature is high, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes ( see scheme 1above). The intake air temperature sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R. Resistor R and the intake air temperature sensor are connected in series. When the resistance value of the intake air temperature sensor changes, according to changes in the intake air temperature, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve drivability.
When any of DTCs P0112 and P0113 are stored, the ECM enters fail-safe mode. During fail-safe mode, the intake air temperature is estimated to be 20°C (68°F) by the ECM. Fail-safe mode continues until a pass condition is detected.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0112 | Short in intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic) | Short in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter sub-assembly) ECM |
| P0113 | Open in intake air temperature sensor circuit for 0.5 seconds (1 trip detection logic) | Open in intake air temperature sensor circuit Intake air temperature sensor (built into mass air flow meter sub-assembly) ECM |
When any of these DTCs are output, check the intake air temperature sensor by entering the following menus: Powertrain / Engine and ECT / Data List / Intake Air.
| Temperature Displayed | Malfunction |
| 40°C (-40°F) | Open circuit |
| Higher than 128°C (262°F) | Short circuit |
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake air temperature sensor |
| Required sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Intake air temperature sensor voltage | Less than 0.18 V [Higher than 128°C (262°F)] |
| Intake air temperature sensor voltage | More than 4.91 V [Less than -55°C (-67°F)] |
| Intake air temperature sensor voltage | 0.18 V or more, and 4.91 V or less [-55°C (-67°F) or more and 128°C (262°F) or less] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 108
Scheme 108: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check P0117: Engine coolant temperature sensor range check P0118: Engine coolant temperature sensor range check |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or more than 4.91 V [Higher than 135°C (275°F), or less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage | Less than 0.14 V [Higher than 135°C (275°F)] |
| Engine coolant temperature sensor voltage | More than 4.91 V [Less than -60°C (-76°F)] |
| Engine coolant temperature sensor voltage | 0.14 V or more, and 4.91 V or less [-60°C (-76°F) or more, and 135°C (275°F) or less] |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 109
Scheme 109: WIRING DIAGRAM
| Related DTCs | P0116: Engine coolant temperature sensor rationality (cold start monitor) P0116: Engine coolant temperature sensor rationality (soak monitor) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Mass air flow meter sub-assembly |
| Frequency of Operation | Once per driving cycle |
| Duration | Cold start monitor 10 seconds: Soak monitor |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| Engine coolant temperature at engine start | Less than 60°C (140°F) |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Soak time | 0 seconds or more |
| Accumulated mass air flow | 9700 g or more |
| Fuel cut | OFF |
| Difference between ECT at engine start and IAT | Less than 40°C (72°F) |
| All of the following conditions are met | |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Soak time | 5 hours or more |
| Either (a) or (b) condition met | |
| (a) Engine coolant temperature | 60°C (140°F) or more |
| (b) Accumulated mass air flow | 19400 g or more |
| Engine coolant temperature sensor value change | Less than 5°C (9°F) |
| Difference between current engine coolant temperature sensor value and previous engine coolant temperature sensor value when engine stopped | Less than 5°C (9°F) (varies with engine coolant temperature at engine stop) |
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 110
Scheme 110: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menu items: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or more, the ECT sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E].
- Drive the vehicle at 40 km/h (25 mph) or more for a total of 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows INCOMPLETE or N/A, perform steps [D] and [E] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0116) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTC. RESULT Result Proceed To DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs and other than P0116 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT Remove the water inlet with thermostat. Refer to «REMOVAL»(ref-554444-S40633882972013052000000) . Check the valve opening temperature of the thermostat. Standard opening temperature 80°C to 84°C (176°F to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. NG --> See step 5 OK --> See step 3
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-554463-S24336685552013052000000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE WATER INLET WITH THERMOSTAT. Refer to «REMOVAL»(ref-554444-S40633882972013052000000)
| Related DTCs | P011B: Engine Coolant Temperature / Intake Air Temperature sensor correlation |
| Required Sensors / Components (Main) | Engine Coolant Temperature Intake Air Temperature sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Time engine not running after ignition switch ON | 20 seconds or less |
| Soak Time | 7 hours or more |
| Battery voltage | 10.5 V or more |
| Time after engine start | 700 seconds or more |
| Either of the following conditions are met | Condition (a) and (b) |
| (a) Minimum intake air temperature after engine start | 10°C (14°F) or more |
| (b) Engine coolant temperature sensor before engine start | 10°C (14°F) or more |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Deviated engine coolant temperature and intake air temperature | Less than -20°C (-36°F) or more than 20°C (36°F) |
Scheme 111
Scheme 111: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation) [A].
- Turn the ignition switch off.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Start the engine and wait 20 minutes or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] through [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menu: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE) Leave the vehicle for 7 hours or more. HINT: It is necessary leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menu: Powertrain / Engine and ECT / Intake Air. Read the value displayed on the Techstream. Standard The difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent swings in the temperature display. Use an accurate thermometer to determine the outside air temperature. NG --> See step 5 OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMPERATURE) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menu: Powertrain / Engine and ECT /Coolant Temp. Read the value displayed on the Techstream. Standard The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there no heat sources such as a block heater in the engine compartment. NG --> See step 7 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE MASS AIR FLOW METER SUB-ASSEMBLY. Refer to «REMOVAL»(ref-554463-S20636246822013052000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-554463-S20232329082013052000000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-554463-S24336685552013052000000)
| Related DTCs | P0120: Throttle position sensor 1 range check (chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 2 seconds or less: P0121 0.5 seconds: P2135 (Case 1) 0.4 seconds: P2135 (Case 2) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Either of following conditions A or B met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223 AND P2135
| Either of following conditions A or B met | |
| A. Ignition switch | ON |
| B. Electronic throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.54 V or more |
| Either of following conditions is met | |
| Difference of learned throttle position sensor opener position voltage between VTA1 and VTA2 x 0.8 | More than 1.6 V |
| Difference of learned throttle position sensor opener position voltage between VTA1 and VTA2 x 0.8 | Less than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.54 V or more |
| When either condition below is met | Condition A or B |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 V or more, and 2.02 V or less | 4.8 V or more |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or more, and 2.02 V or less | 4.8 V or more |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | Higher than 0.2 V, and less than 4.54 V |
| VTA2 voltage | Higher than 1.75 V, and less than 4.8 V |
Scheme 112
Scheme 112: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [B] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs or other DTCs relating to ETCS (Electronic Throttle Control System) malfunctions are stored, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 113
Scheme 113: WIRING DIAGRAM
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Engine coolant temperature sensor Thermostat Cooling system |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 56 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or more 98 seconds: Engine coolant temperature at engine start -19.44°C (-3°F) or more, and less than -8.33°C (17°F) 1200 seconds: Engine coolant temperature at engine start -19.44°C (-3°F) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Thermostat fail (P0128) | Not detected |
| Intake air temperature sensor circuit fail (P0112, P0113) | Not detected |
| Engine coolant temperature sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Mass air flow meter circuit fail (P0101, P0102, P0103) | Not detected |
| Time until actual engine coolant temperature reaches closed loop fuel control enabling temperature | 56 seconds: Engine coolant temperature at engine start -8.33°C (17°F) or more 98 seconds: Engine coolant temperature at engine start -19.44°C (-3°F) or more, and less than -8.33°C (17°F) 1200 seconds: Engine coolant temperature at engine start -19.44°C (-3°F) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menu items: Powertrain / Engine and ECT / Data List / Coolant Temp.
- Check that the engine coolant temperature is less than 0°C (32°F).
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Wait 20 minutes or more.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT Remove the water inlet with thermostat. Refer to «REMOVAL»(ref-554444-S40633882972013052000000) . Check the valve opening temperature of the thermostat. Standard opening temperature 80° to 84°C (176° to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE WATER INLET WITH THERMOSTAT. Refer to «REMOVAL»(ref-554444-S40633882972013052000000)
- REPLACE ENGINE COOLANT TEMPERATURE SENSOR. Refer to «REMOVAL»(ref-554463-S24336685552013052000000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Engine coolant temperature Thermostat |
| Required Sensors/Components (Related) | Intake air temperature sensor Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 800 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve) P0011, P0021 (VVT system - advance) P0012, P0022 (VVT System - retard) P0016, P0018 (VVT system - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle speed sensor) P219A, P219B (Air-fuel ratio imbalance) |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 met | |
| 1. All of following conditions (a), (b) and (c) met | |
| (a) Engine coolant temperature at engine start - Intake air temperature at engine start | 15°C (5°F) or more, and 7°C (45°F) or less |
| (b) Engine coolant temperature at engine start | 10°C (14°F) or more, and 56°C (133°F) or less |
| (c) Intake air temperature at engine start | 10°C (14°F) or more, and 56°C (133°F) or less |
| 2. All of following conditions (d), (e) and (f) met | |
| (d) Engine coolant temperature at engine start - Intake air temperature at engine start | More than 7°C (45°F) |
| (e) Engine coolant temperature at engine start | 56°C (133°F) or less |
| (f) Intake air temperature at engine start | 10°C (14°F) or more |
| Accumulated time with 128 km/h (80 mph) or more of vehicle speed | Less than 20 seconds |
| Duration that following conditions A and B met | 5 seconds or more |
| A. Estimated engine coolant temperature | 75°C (167°F) or more |
| B. Engine coolant temperature sensor output | Less than 75°C (167°F) |
Scheme 114
Scheme 114: CONFIRMATION DRIVING PATTERN
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine and ECT / Data List / Coolant Temp and Intake Air.
- Check that "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F).
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle at 80 km/h (50 mph) for 15 minutes [B]. NOTE: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snapshot configuration / Record time / 5 min. Data capture can be started by using the target point function. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher [C]. HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 80 km/h (50 mph), inspect the cooling system and thermostat.
- CHECK ANY OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menu: Powertrain / Engine and ECT / Trouble Codes. Read DTC. RESULT Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTCs other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT WATER INLET WITH THERMOSTAT Check the valve opening temperature of the water inlet with thermostat. Refer to «INSPECTION»(ref-554444-S22270291412013052000000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE WATER INLET WITH THERMOSTAT. Refer to «REMOVAL»(ref-554444-S40633882972013052000000)
- REPLACE ECM. Refer to «REMOVAL»(ref-554463-S20232329082013052000000)
| Related DTCs | P0136: Heated oxygen sensor (bank 1 sensor 2) output voltage (Abnormal voltage output) P0136: Heated oxygen sensor (bank 1 sensor 2) impedance (Low) P0137: Heated oxygen sensor (bank 1 sensor 2) output voltage (Low voltage) P0137: Heated oxygen sensor (bank 1 sensor 2) impedance (High) P0138: Heated oxygen sensor (bank 1 sensor 2) output voltage (Extremely high) P0139: Heated oxygen sensor (bank 1 sensor 2) output voltage during fuel cut P0156: Heated oxygen sensor (bank 2 sensor 2) output voltage (Abnormal voltage output) P0156: Heated oxygen sensor (bank 2 sensor 2) impedance (Low) P0157: Heated oxygen sensor (bank 2 sensor 2) output voltage (Low voltage) P0157: Heated oxygen sensor (bank 2 sensor 2) impedance (High) P0158: Heated oxygen sensor (bank 2 sensor 2) output voltage (Extremely high) P0159: Heated oxygen sensor (bank 2 sensor 2) output voltage during fuel cut |
| Required Sensors/Components (Main) | Heated oxygen sensor (bank 1, 2 sensor 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor Engine coolant temperature sensor Mass air flow meter sub-assembly Throttle position sensor |
| Frequency of Operation | Once per driving cycle: Active air fuel ratio control detection Continuous: Other |
| Duration | 20 seconds: Heated oxygen sensor output voltage (Abnormal voltage, Low voltage) 90 seconds: Heated oxygen sensor impedance (High) 30 seconds: Heated oxygen sensor impedance (Low) 10 seconds: Heated oxygen sensor output voltage (Extremely high) 7 seconds: Heated oxygen sensor voltage (during fuel cut) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016, P0018 (VVT system - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Rear oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0128 (Thermostat) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0412, P0418, P1613 (Secondary air injection system control) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445 (Secondary air injection system) P0451, P0452, P0453 (EVAP system) P0500, P0722 (Vehicle speed sensor) P219A, P219B (Air-fuel ratio imbalance) |
| Battery voltage | 11 V or more |
| Engine coolant temperature | 75°C (167°F) or more |
| Intake air temperature | 10°C (14°F) or more |
| Atmospheric pressure | 76 kPa(abs) [570 mmHg(abs)] or more |
| Idling | OFF |
| Engine speed | Less than 3200 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10% or more, and less than 70% |
| Shift position | 4th or higher |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT AND LOW VOLTAGE)
| Battery voltage | 11 V or more |
| Estimated rear Heated Oxygen sensor temperature | Less than 700°C (1292°F) |
| DTC P0607 | Not set |
| ECM monitor | Not detected |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Battery voltage | 11 V or more |
| Estimated rear Heated Oxygen sensor temperature | 520°C (968°F) or more, and less than 750°C(1382°F) |
| DTC P0607 | Not set |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Battery voltage | 11 V or more |
| Time after engine start | 2 seconds or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Engine coolant temperature | 75°C (167°F) or higher |
| Estimated catalyst temperature | 400°C (752°F) or higher |
| Fuel cut | ON |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| 1. All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Heated oxygen sensor voltage | 0.21 or more, and less than 0.66 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (ABNORMAL VOLTAGE OUTPUT)
| All of following conditions (a), (b) and (c) met | |
| (a) Commanded air fuel ratio | 14.3 or less |
| (b) Heated oxygen sensor voltage | Less than 0.21 V |
| (c) OSC (Oxygen Storage Capacity of Catalyst) | 2 g or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (LOW)
| Duration of following condition met | 30 seconds or more |
| Heated oxygen sensor impedance | Less than 5 ohms |
HEATED OXYGEN SENSOR IMPEDANCE (LOW)
| Duration of following condition met | 90 seconds or more |
| Heated oxygen sensor impedance | 15 kohms or more |
HEATED OXYGEN SENSOR IMPEDANCE (HIGH)
| Duration of following condition met | 10 seconds or more |
| Heated oxygen sensor voltage | 1.2 V or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE (EXTREMELY HIGH)
| Total airflow volume reached after start of fuel-cut while heated oxygen sensor voltage remains at 0.2 V or higher | More than 14 g |
| Duration that rear oxygen sensor voltage drops from 0.35 V to 0.2 V during fuel cut | 1 second or more |
HEATED OXYGEN SENSOR OUTPUT VOLTAGE DURING FUEL CUT
| Duration of following condition met | 30 seconds or more |
| Heated oxygen sensor voltage | Varies between 0.1 and 0.9 V |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- This confirmation driving pattern is used in the "Perform Confirmation Driving Pattern" procedure of the following diagnostic troubleshooting procedure.
- Performing this confirmation driving pattern will activate the heated oxygen sensor monitor (The catalyst monitor is performed simultaneously). This is very useful for verifying the completion of a repair.
P0136, P0137, P0138, P0156, P0157 and P0158
Scheme 115
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- With the transmission in 4th gear or higher, drive the vehicle at 60 to 120 km/h (37 to 75 mph) for 10 minutes or more [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 116
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Drive the vehicle at 60 km/h (37 mph), and then decelerate the vehicle by releasing the accelerator pedal for 8 seconds or more to perform the fuel-cut [C]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [D].
- Read pending DTCs. HINT: If a pending DTC or current DTC is output, the system is malfunctioning. If a pending DTC or current DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0139 or P0159.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, shift the transmission to 2nd gear, and then perform steps [C] and [D] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 117
Scheme 117: WIRING DIAGRAM
| Related DTCs | P014C: Air fuel ratio sensor (bank 1 sensor 1) slow response (rich to lean) P014D: Air fuel ratio sensor (bank 1 sensor 1) slow response (lean to rich) P014E: Air fuel ratio sensor (bank 2 sensor 1) slow response (rich to lean) P014F: Air fuel ratio sensor (bank 2 sensor 1) slow response (lean to rich) P015A: Air fuel ratio sensor (bank 1 sensor 1) delayed response (rich to lean) P015B: Air fuel ratio sensor (bank 1 sensor 1) delayed response (lean to rich) P015C: Air fuel ratio sensor (bank 2 sensor 1) delayed response (rich to lean) P015D: Air fuel ratio sensor (bank 2 sensor 1) delayed response (lean to rich) |
| Required Sensors/Components (Main) | Air fuel ratio sensor (bank 1, 2 sensor 1) |
| Required Sensors/Components (Related) | Vehicle speed sensor Crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 to 15 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Active air fuel ratio control | Performing |
| Active air fuel ratio control is performed when the following conditions are met | |
| Battery voltage | 11 V or more |
| Engine coolant temperature | 75°C (167°F) or higher |
| Idle | OFF |
| Engine speed | 1000 RPM or higher, and less than 4000 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel-cut | OFF |
| Engine load | 10% or higher, and less than 70% |
| Shift position | 2nd or higher |
| Catalyst monitor | Not yet |
| Mass air flow | 6 gm/sec or more, and less than to 15 gm/sec. |
| Rich to Lean response rate deterioration level | 0.04 V or less (Automatic Transmission) 0.036 V or less (Manual Transmission) |
P014C AND P014E: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN RESPONSE RATE)
| Lean to Rich response rate deterioration level | 0.04 V or higher (Automatic Transmission) -0.036 V or higher (Manual Transmission) |
P014D AND P014F: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH RESPONSE RATE)
| Rich to Lean delay level | 327.68 ms or more |
P015A AND P015C: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (RICH TO LEAN DELAY)
| Lean to Rich delay level | 327.68 ms or more |
P015B AND P015D: AIR FUEL RATIO SENSOR (BANK 1, 2) RESPONSE RATE (LEAN TO RICH DELAY)
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the air fuel ratio sensor response monitor.
Scheme 118
Scheme 118: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that the monitor item O2 Sensor is Incomplete. HINT: The test values for the test items RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1 do not exist in Details of the O2 Sensor monitor at this time (the initial value of "0.0000" or "0.000" is indicated for each test item).
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at a constant speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Check that the monitor item O2 Sensor becomes Complete. HINT: Check the test values on the Techstream by entering the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / O2 Sensor / Details / RL RES RATE B1S1, LR RES RATE B1S1, RL DELAY B1S1, LR DELAY B1S1, RL RES RATE B2S1, LR RES RATE B2S1, RL DELAY B2S1 and LR DELAY B2S1.
- If the monitor item O2 Sensor does not become Complete (if the test values indicated on the Techstream do not change), perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-554459-S03258109602013052000000) .
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [C].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK FOR ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Inspect the air fuel ratio sensor. Refer to «INSPECTION»(ref-554446-S20791915132013052000000) . NG --> See step 11 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM) Disconnect the air fuel ratio sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A4-1 (HA1A) - E12-17 (HA1A) Always Below 1 ohms A4-3 (A1A+) - E11-1 (A1A+) Always Below 1 ohms A4-4 (A1A-) - E11-2 (A1A-) Always Below 1 ohms A5-1 (HA2A) - E12-19 (HA2A) Always Below 1 ohms A5-3 (A2A+) - E11-7 (A2A+) Always Below 1 ohms A5-4 (A2A-) - E11-8 (A2A-) Always Below 1 ohms A4-1 (HA1A) or E12-17 (HA1A) - Body ground Always 10 kohms or higher A4-3 (A1A+) or E11-1 (A1A+) - Body ground Always 10 kohms or higher A4-4 (A1A-) or E11-2 (A1A-) - Body ground Always 10 kohms or higher A5-1 (HA2A) or E12-19 (HA2A) - Body ground Always 10 kohms or higher A5-3 (A2A+) or E11-7 (A2A+) - Body ground Always 10 kohms or higher A5-4 (A2A-) or E11-8 (A2A-) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK AIR FUEL RATIO SENSOR Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NG --> See step 14 OK: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC is not output B B --> See step 12 A: Go to next step
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-554446-S22142429722013052000000) . NEXT: Go to next step
- PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output B B --> See step 13 A --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-554446-S22142429722013052000000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-554459-S38977550292013052000000)
- CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-554467-S37107976722013052000000)
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-554446-S22142429722013052000000)
| Related DTCs | P0171: Fuel trim Lean (bank 1) P0172: Fuel trim Rich (bank 1) P0174: Fuel trim Lean (bank 2) P0175: Fuel trim Rich (bank 2) |
| Required Sensors/Components (Main) | Fuel system |
| Required Sensors/Components (Related) | Air fuel ratio sensor Mass air flow meter sub-assembly Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | Less than 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve) P0011, P0021 (VVT system - advance) P0012, P0022 (VVT System - retard) P0016, P0018 (VVT system - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0412, P0418, P1613 (Secondary air injection system control) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445 (Secondary air injection system) P0500 (Vehicle speed sensor) P219A, P219B (Air-fuel ratio imbalance) |
| Fuel system status | Closed-loop |
| Battery voltage | 11 V or more |
| Either of following conditions 1 or 2 set | |
| 1. Engine speed | Less than 1100 RPM |
| 2. Intake air amount per revolution | 0.22 g/rev or more |
| Catalyst monitor | Not executed |
| Purge-cut | Executing |
| Either of following conditions 1 or 2 met | |
| 1. Average between short-term fuel trim and long-term fuel trim | 35% or more (varies with engine coolant temperature) |
| 2. Average between short-term fuel trim and long-term fuel trim | 35% or less (varies with engine coolant temperature) |
Scheme 119
Scheme 119: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher with all the accessories switched off [B].
- With the engine warmed up, idle the engine for 2 minutes or more [C].
- Drive the vehicle at a speed between 60 and 135 km/h (38 and 84 mph) for 5 minutes or more [D]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [E].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0300: Multiple cylinder misfire P0301: Cylinder 1 misfire P0302: Cylinder 2 misfire P0303: Cylinder 3 misfire P0304: Cylinder 4 misfire P0305: Cylinder 5 misfire P0306: Cylinder 6 misfire |
| Required Sensors/Components (Main) | Crankshaft position sensor Camshaft position sensor |
| Required Sensors/Components (Related) | Engine coolant temperature Intake air temperature sensor Mass air flow meter sub-assembly |
| Frequency of Operation | Continuous |
| Duration | 1000 crankshaft revolutions (soon after engine is started: 1 time, other 4 times) (Emissions-related misfire) 200 crankshaft revolutions (1 or 3 times) (Catalyst-damaging misfire) |
| MIL Operation | 2 driving cycles: (MIL illuminates when misfire detected) MIL flashes immediately: When catalyst damaged misfire occur |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0016, P0018 (VVT system - misalignment) P0102, P0103 (Mass air flow meter) P0112, P0113 (Intake air temperature sensor) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0327, P0328, P0332, P0333 (Knock control sensor) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0500 (Vehicle Speed Sensor) P0705 (Shift lever position switch) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5400 RPM (Automatic transmission) 450 to 5400 RPM (Manual transmission) |
| Either of following conditions (a) or (b) met | |
| (a) Engine coolant temperature at engine start | More than -7°C (19°F) |
| (b) Engine coolant temperature | More than 20°C (68°F) |
| Fuel cut | OFF |
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| All of the following conditions 1, 2, 3 and 4 are met | Crankshaft 200 revolutions x 3 |
| Except above (MIL blinks immediately) | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| 3. Engine speed | Less than 2800 RPM |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| Monitor runs whenever following DTCs not stored | P0102 - P0103 (Mass Air Flow Meter) P0110 - P0113 (Intake Air Temperature Sensor) P0115 - P0118 (Engine Coolant Temperature Sensor) P0120 - P0223, P2135 (Throttle Position Sensor) P0125 (Insufficient Engine Coolant Temperature for Closed Loop) P0327, P0328 (Knock Sensor) P0335 (Crankshaft Position Sensor) P0340 (VVT sensor) P0500 (Vehicle Speed Sensor) |
| Battery voltage | 8 V or more |
| VVT system | Not operated by scan tool |
| Engine speed | 400 to 5400 RPM |
| Engine coolant temperature | More than 65°C (149°F) |
| Fuel cut | OFF |
MISFIRE: FOR MEXICO MODELS
| First 1000 revolutions after engine start, or Check Mode | Crankshaft 1000 revolutions |
| Except above | Crankshaft 1000 revolutions x 4 |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| All of following conditions 1 and 2 met | Crankshaft 200 revolutions |
| 1. Driving cycles | 1st |
| 2. Check mode | OFF |
| Except above | Crankshaft 200 revolutions x 3 |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE
| Number of misfire per 200 revolutions | 77 or more (varies with intake air amount and RPM) |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)
| Misfire rate | 33.2% or more: for 1st 1000 revolutions 16.6% or more: after 1st 1000 revolutions |
MONITOR PERIOD OF EMISSION-RELATED-MISFIRE: FOR MEXICO MODELS
| Number of misfire per 200 revolutions | 77 or more (varies with intake air amount and RPM) |
| Paired cylinder misfire (MIL blinks immediately) | Detected |
MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS): FOR MEXICO MODELS
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Record the DTC(s) and freeze frame data.
- Clear DTCs (even if no DTCs are stored, perform the Clear DTC procedure).
- Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-554459-S18800274202013052000000) .
- Read the misfire counts of each cylinder, Cylinder #1 Misfire Count to Cylinder #6 Misfire Count, with the engine idling. If any misfire count is displayed, skip the following confirmation driving pattern.
- Drive the vehicle so that the vehicle conditions displayed in Misfire RPM and Misfire Load of the Data List are the same as the freeze frame data. Perform this step several times. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, confirm the Misfire RPM and Misfire Load in the Data List. Engine speed Duration Idling 8.0 minutes or more 1000 4.5 minutes or more 2000 2.5 minutes or more 3000 1.5 minutes or more
- Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the output DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data are cleared.
- Record the DTC(s), freeze frame data and misfire counts.
- Turn the ignition switch off and wait for at least 30 seconds.
- Clear DTCs (even if no DTCs are stored, perform the Clear DTC procedure).
Scheme 120
Scheme 120: WIRING DIAGRAM
Scheme 121
Scheme 122
| Related DTCs | P0327: Knock sensor (Bank 1) Range check (Low voltage) P0328: Knock sensor (Bank 1) Range check (High voltage) P0332: Knock sensor (Bank 2) Range check (Low voltage) P0333: Knock sensor (Bank 2) Range check (High voltage) |
| Required Sensors/Components (Main) | Knock sensor (Bank 1, 2) |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 1 second |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 5 seconds or more |
| Ignition switch | ON |
| Starter | Off |
| Knock sensor voltage | Less than 0.5 V |
KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332
| Knock sensor voltage | More than 4.5 V |
KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 5 minutes.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes.
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0327, P0328, P0332, P0333.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, idle the engine for 5 minutes and check the DTC judgment result again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 123
Scheme 123: WIRING DIAGRAM
Scheme 124
| Related DTCs | P0335: Crankshaft position sensor range check/rationality P0335: Crankshaft position sensor verify pulse input |
| Required Sensors/Components (Main) | Crankshaft position sensor |
| Required Sensors/Components (Related) | VVT sensor |
| Frequency of Operation | Continuous |
| Duration | Verify pulse input (case 1) 0.016 seconds: Range check/rationality 4.7 seconds: Verify pulse input (case 2) |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Engine speed signal | Signal input |
| Ignition switch | ON |
| Time after starter OFF to ON | 3 seconds or more |
| VVT sensor circuit fail (P0340, P0342, P0343) | Not detected |
| Number of VVT sensor signal pulse | 6 times |
| Battery voltage | 7 V or more |
| Minimum battery voltage while starter ON | Less than 11 V |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| All of the following conditions are met | |
| Starter | OFF |
| Engine speed (Top dead center) | 600 RPM or higher |
| Engine speed (30°CA) | 600 RPM or higher |
| Time after starter from ON to OFF | 3 seconds or more |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 1)
| All of the following conditions are met | |
| Starter | ON |
| Minimum battery voltage while starter ON | Less than 11 V |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT (CASE 2)
| Number of crankshaft position sensor signal pulse | 132 or less, or 174 or more |
P0335: CRANKSHAFT POSITION SENSOR RANGE CHECK/RATIONALITY
| Engine speed signal | No signal |
P0335: CRANKSHAFT POSITION SENSOR VERIFY PULSE INPUT
| Crankshaft position sensor | Crankshaft position sensor output voltage fluctuates while crankshaft revolving 34 crankshaft position sensor signals per crankshaft revolution |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 20 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0335 or P0339.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 125
Scheme 125: WIRING DIAGRAM
| Related DTCs | P0340: VVT sensor (bank 1) verify pulse input P0342: VVT sensor (bank 1) range check (low voltage) P0343: VVT sensor (bank 1) range check (high voltage) P0345: VVT sensor (bank 2) verify pulse input P0347: VVT sensor (bank 2) range check (low voltage) P0348: VVT sensor (bank 2) range check (high voltage) |
| Required Sensors/Components (Main) | VVT sensors (bank 1, 2) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 4 seconds: P0340 (VVT sensor (bank 1) verify pulse input (case 2)) P0342 and P0347 (VVT sensor (bank 1, 2) range check (low voltage)) P0343 and P0348 (VVT sensor (bank 1, 2) range check (high voltage)) 5 seconds: P0340 (VVT sensor (bank 1) verify pulse input (case 1)) P0345 (VVT sensor (bank 2) verify pulse input) |
| MIL Operation | 2 driving cycles: P0340 (VVT sensor (bank 1) verify pulse input (case 2) Immediate: Others |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Engine speed | 600 RPM or more |
| Starter | OFF |
| VVT system misalignment | Not detected |
| VVT sensor range check fail (P0342, P0343) | Not detected |
| VVT sensor voltage | 0.3 V or higher and 4.7 V or less |
P0340 VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)
| Both of the following conditions are met | |
| Starter | ON |
| Minimal battery voltage while starter ON | Less than 11 V |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch OFF to ON | 2 seconds or more |
| VVT sensor pulse input fail (P0340) | Not detected |
| Battery voltage | 8 V or higher |
P0342 AND P0343: VVT SENSOR (BANK 1) RANGE CHECK
| All of the following conditions are met | |
| Engine speed | 600 RPM or more |
| Starter | OFF |
| VVT sensor range check fail (P0342, P0343, P0347, P0348) | Not detected |
| VVT sensor voltage | 0.3 V or higher and 4.7 V or less |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch OFF to ON | 2 seconds or more |
| VVT sensor verify pulse input fail (P0340, P0345) | Not detected |
| Battery voltage | 8 V or higher |
P0347 AND P0348: VVT SENSOR (BANK 2) RANGE CHECK
| Either of the following conditions is met | 1 or 2 |
| 1. VVT and crankshaft position alignment | Misalignment |
| 2. VVT sensor signal | No signal |
P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)
| VVT sensor signal | No signal |
P0340 AND P0345: VVT SENSOR (BANK 1, 2) VERIFY PULSE INPUT (CASE 2)
| VVT sensor voltage | Less than 0.3 V |
P0342 AND P0347: VVT SENSOR (BANK1, 2) RANGE CHECK (LOW VOLTAGE)
| VVT sensor voltage | More than 4.7 V |
P0343 AND P0348: VVT SENSOR (BANK1, 2) RANGE CHECK (HIGH VOLTAGE)
| VVT sensor voltage | 0.3 V or higher and 4.7 V or less |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0351: Igniter (Cylinder 1) circuit / Open P0352: Igniter (Cylinder 2) circuit / Open P0353: Igniter (Cylinder 3) circuit / Open P0354: Igniter (Cylinder 4) circuit / Open P0355: Igniter (Cylinder 5) circuit / Open P0356: Igniter (Cylinder 6) circuit / Open |
| Required Sensors/Components (Main) | Igniter (Cylinder 1 to 6) |
| Required Sensors/Components (Related) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Spark cut | Not operating |
| Either of the following conditions is met | A or B |
| A. Starter | OFF |
| B. Engine speed | 1500 RPM or less |
| Either of the following conditions is met | C or D |
| C. All of the following conditions are met | |
| Engine speed | 500 RPM or less |
| Battery voltage | 6 V or more |
| D. All of the following conditions are met | |
| Engine speed | More than 500 RPM |
| Battery voltage | 10 V or more |
| Number of sparks after CPU is reset | 5 sparks or more |
| All of the following conditions are met | A, B, C and D |
| A. Ignition signal fail counter | More than 2 times |
| B. Time after condition A is met | 0.256 seconds or more |
| C. Ignition signal fail counter after condition B is met | 2 times or more |
| D. Ignition switch | ON |
| IGF signal | Igniter transmits IGF signal when it receives IGT signal from ECM |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine.
- Idle the engine for 10 seconds or more [A].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [B].
- Read pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0351, P0352, P0353, P0354, P0355 or P0356.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or N/A, perform steps [A] and [B] again.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0412: Secondary air injection system air switching valve circuit range check (bank 1) |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air switching valve assembly |
| Frequency of Operation | Once per drive cycle |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| Air pump | Operating |
| Air switching valve | Operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Air pump | Not operating |
| Air switching valve | Not operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Diagnostic signal duty ratio from air injection control driver | 31% or more, and 48% or less |
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
Note. This Secondary Air Injection Check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Secondary Air Injection Check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Secondary Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch to ON or the engine running. Turn the ignition switch off when the Secondary Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the ignition switch off.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air Injection Check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing Next.
- Perform the following to confirm the secondary air injection system pending DTCs: Press the Exit.
- Read pending DTCs. OK No pending DTC is output. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- After Secondary Air Injection Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0412.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the ignition switch off.
Scheme 126
Scheme 126: WIRING DIAGRAM
- INSPECT AIR SWITCHING VALVE ASSEMBLY (AIR SWITCHING VALVE (BANK 1)) Inspect the air switching valve assembly. Refer to «INSPECTION»(ref-554477-S17548109972013052000000) . NG --> See step 4 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR SWITCHING VALVE (BANK 1) - BODY GROUND) Disconnect the air switching valve (bank 1) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A32-1 (GND) - Body ground Always Below 1 ohms NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK HARNESS AND CONNECTOR (AIR SWITCHING VALVE (BANK 1) - AIR INJECTION CONTROL DRIVER) Disconnect the air switching valve (bank 1) connector. Disconnect the air injection control driver connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A32-5 (+B) - A7-6 (VV) Always Below 1 ohms A32-5 (+B) or A7-6 (VV) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 5
- REPLACE AIR SWITCHING VALVE ASSEMBLY. Refer to «REMOVAL»(ref-554477-S35051235372013052000000)
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-554478-S01016798112013052000000)
| Related DTCs | P0416: Secondary air injection system air switching valve circuit range check low voltage (bank 2) P0417: Secondary air injection system air switching valve circuit range check high voltage (bank 2) |
| Required Sensors/Components (Main) | AI VALVE relay |
| Required Sensors/Components (Related) | ECM |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediate |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Current air switching valve relay | ON |
| Last air switching valve relay | ON |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| All of the following conditions are met | |
| Current air switching valve relay | OFF |
| Last air switching valve relay | OFF |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Air switching valve relay output terminal voltage | Low |
| Air switching valve relay output terminal voltage | High |
Note. This Secondary Air Injection Check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Secondary Air Injection Check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Secondary Air Injection Check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch to ON or the engine running. Turn the ignition switch off when the Secondary Air Injection Check operation finishes.
- Start the engine and warm it up.
- Turn the ignition switch off.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air Injection Check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing Next.
- Perform the following to confirm the secondary air injection system pending DTCs: Press the Exit.
- Read pending DTCs. OK No pending DTC is output. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- After Secondary Air Injection Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0416 or P0417.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the ignition switch off.
Scheme 127
Scheme 127: WIRING DIAGRAM
| Related DTCs | P0418: Secondary air injection system air pump circuit range check (Bank 1) |
| Required Sensors/Components (Main) | Air injection control driver |
| Required Sensors/Components (Related) | Air pump assembly |
| Frequency of Operation | Once per drive cycle |
| Duration | 3 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | None |
| All of the following conditions are met | |
| Air pump | Operating |
| Air switching valve | Operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| All of the following conditions are met | |
| Air pump | Not operating |
| Air switching valve | Not operating |
| Battery voltage | 8 V or higher |
| Ignition switch | ON |
| Starter | OFF |
| Diagnostic signal duty ratio from air injection control driver | 11% or more, and 29% or less |
| Diagnostic signal duty ratio from air injection control driver | 70% or more, and 90% or less when secondary air injection system operating. 0% when secondary air injection system not operating. |
Note. This Secondary Air injection check only allows technicians to operate the secondary air injection system for a maximum of 5 seconds. Furthermore, the check can only be performed up to 4 times per trip. If the test is repeated, intervals of at least 30 seconds are required between checks. While secondary air injection system operation using the Techstream is prohibited, the Techstream display indicates the prohibition (WAIT or ERROR). If ERROR is displayed on the Techstream during the test, stop the engine for 10 minutes, and then try again. Performing Secondary Air injection check repeatedly may cause damage to the secondary air injection system. If it is necessary to repeat the check, leave an interval of several minutes between System Check operations to prevent the system from overheating. When performing the Secondary Air injection check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch to ON or the engine running. Turn the ignition switch off when the Secondary Air injection check operation finishes.
- Start the engine and warm it up.
- Turn the ignition switch off.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear DTCs (even if no DTCs are stored, perform the clear DTC operation). Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air injection check / Automatic Mode.
- Start the engine after the Techstream initialization is finished.
- Perform the System Check operation by pressing Next.
- Perform the following to confirm the secondary air injection system pending DTCs: Press the Exit.
- Read pending DTCs. OK No pending DTC is output. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- After Secondary Air injection check is completed, check for All Readiness by entering the following menus: Powertrain / Engine and ECT / Utility / All Readiness.
- Input the DTC: P0418.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions N/A Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows NORMAL, the system is normal. If the judgment result shows ABNORMAL, the system has a malfunction.
- If the judgment result is INCOMPLETE or N/A and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If no permanent DTC is output, the system is normal. If a permanent DTC is output, the system is malfunctioning.
- Turn the ignition switch off.
- CHECK HARNESS AND CONNECTOR (AIR PUMP ASSEMBLY - AIR INJECTION CONTROL DRIVER, BODY GROUND) Disconnect the cable from the negative (-) battery terminal. Disconnect the cable from the positive (+) battery terminal. Disconnect the air pump assembly connector. Disconnect the air injection control driver connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition A30-2 (+B) - A6-2 (VP) Always Below 1 ohms A30-4 - Body ground Always Below 1 ohms A6-1 (BATT) - Positive (+) battery cable Always Below 1 ohms A30-2 (+B) or A6-2 (VP) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- INSPECT AIR PUMP ASSEMBLY Inspect the air pump assembly. Refer to «ON-VEHICLE INSPECTION»(ref-554479-S10002891762013052000000) . NG --> See step 3 OK --> See step 6
- REPLACE AIR PUMP ASSEMBLY Replace the air pump assembly. Refer to «REMOVAL»(ref-554479-S39465365192013052000000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0418) Start the engine and warm it up. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear DTCs (if stored). Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . Enter the following menus: Powertrain / Engine and ECT / Utility / Secondary Air injection check / Automatic Mode. Start the engine after the Techstream initialization is finished. Perform the System Check operation by pressing Next. After operating the secondary air injection system, perform the following to confirm the secondary air injection system pending DTCs: Press the Exit. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. OK No pending DTC is output. Turn the ignition switch off. NOTE: When performing the Secondary Air injection check operation after the battery cable has been reconnected, wait for 7 minutes with the ignition switch to ON or the engine running. Turn the ignition switch off when the Secondary Air injection check operation finishes. NG --> See step 5 OK --> END
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-554478-S01016798112013052000000)
- REPLACE AIR INJECTION CONTROL DRIVER. Refer to «REMOVAL»(ref-554478-S01016798112013052000000)
| Related DTCs | P0420: Catalyst Deterioration P0430: Catalyst Deterioration |
| Required Sensors/Components (Main) | Air fuel ratio sensor Heated oxygen sensor |
| Required Sensors/Components (Related) | Intake air temperature sensor Mass air flow meter sub-assembly Crankshaft position sensor engine coolant temperature sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Approximately 30 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs not stored | P0010, P0020 (Camshaft timing oil control valve) P0011, P0021 (VVT system - advance) P0012, P0022 (VVT System - retard) P0016, P0018 (VVT system - misalignment) P0031, P0032, P0051, P0052, P101D, P103D (Air fuel ratio sensor heater) P0037, P0038, P0057, P0058, P102D, P105D (Rear oxygen sensor heater) P0102, P0103 (Mass air flow meter) P0115, P0117, P0118 (Engine coolant temperature sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (Throttle position sensor) P0125 (Insufficient coolant temperature for closed loop fuel control) P0136, P0137, P0138, P0139, P0156, P0157, P0158, P0159, P0607 (Heated oxygen sensor) P014C, P014D, P014E, P014F, P015A, P015B, P015C, P015D, P2195, P2196, P2197, P2198, P2237, P2238, P2239, P2240, P2241, P2242, P2252, P2253, P2255, P2256 (Air fuel ratio sensor) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (Crankshaft position sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0412, P0418, P1613 (Secondary air injection system control) P0416, P0417, P2440, P2441, P2442, P2443, P2444, P2445 (Secondary air injection system) P0500 (Vehicle speed sensor) P219A, P219B (Air-fuel ratio imbalance) |
| Battery voltage | 11 V or more |
| Intake air temperature | 10°C (14°F) or more |
| Engine coolant temperature | 75°C or more |
| Atmospheric pressure | 76 kPa(abs) {570 mmHg(abs)} or more |
| Idling | OFF |
| Engine speed | Less than 3200 RPM |
| Air fuel ratio sensor status | Activated |
| Fuel system status | Closed loop |
| Engine load | 10% or more, and less than 70% |
| All of the following conditions are met | 1, 2 and 3 |
| 1. Mass air flow rate | 5 to 70 g/sec |
| 2. Front catalyst temperature (estimated) | 650°C (1202°F) or more, and less than 840°C (1544°F) |
| 3. Rear catalyst temperature (estimated) | 100°C (212°F) or more, and less than 900°C (1652°F) |
| Shift position | 4th or higher |
| Oxygen storage capacity of catalyst | Less than 0.086 g |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Performing this confirmation driving pattern will activate the catalyst efficiency monitor. This is very useful for verifying the completion of a repair.
Scheme 128
Scheme 128: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure).
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor.
- Check that Catalyst Efficiency / Current is Incomplete.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [A].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [B]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible.
- Turn the ignition switch off and wait for at least 30 seconds [C].
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature is 75°C (167°F) or higher [D].
- Drive the vehicle at approximately 60 km/h (37 mph) for 10 minutes or more [E]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates [F].
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [F].
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, perform the following procedure.
- Drive the vehicle at a speed between 75 and 100 km/h (47 and 62 mph) for 10 minutes or more [G]. WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Drive the vehicle while keeping the engine load as constant as possible. The monitor item will change to Complete as the Catalyst Efficiency monitor operates.
- Enter the following menus: Powertrain / Engine and ECT / Trouble Codes [H].
- Check if any DTCs (pending DTCs) are stored. HINT: If the monitor item does not change to Complete, and no pending DTCs are stored, extend the driving time.
- If no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read DTCs. RESULT Result Proceed to DTC P0420 and/or P0430 is output A DTC P0420 or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 13 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine at an engine speed of 2500 RPM for approximately 90 seconds. Enter the following menus: Powertrain / Engine and ECT / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume operation with the engine in an idling condition (press the 12.5% or -12.5% button to change the fuel injection volume). Monitor the voltage outputs of the air fuel ratio and heated oxygen sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The fuel injection volume can be changed to -12.5% or 12.5% Each sensor reacts in accordance with increases and decreases in the fuel injection volume. The air fuel ratio sensor has an output delay of a few seconds and the heated oxygen sensor has a maximum output delay of approximately 20 seconds. If the sensor output voltage does not change (almost no reaction) while performing the Active Test, the sensor may be malfunctioning. Standard Voltage Techstream Display (Sensor) Injection Volume Status Voltages AFS Voltage B1S1 or AFS Voltage B2S1 (Air fuel ratio sensor) 12.5% Rich Less than 3.1 V -12.5% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (Heated oxygen sensor) 12.5% Rich More than 0.55 V -12.5% Lean Less than 0.4 V RESULT Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 Actual Air Fuel Ratio, Air Fuel Ratio Sensor and Heated Oxygen Sensor condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - Three-way catalytic converter Gas leak from exhaust system A Lean Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor B Rich Lean/Rich Air fuel ratio sensor malfunction - Air fuel ratio sensor Lean/Rich Lean Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system C Lean/Rich Rich Heated oxygen sensor malfunction - Heated oxygen sensor Gas leak from exhaust system Lean Lean Actual air-fuel ratio lean May occur Extremely rich or lean actual air fuel ratio Gas leak from exhaust system D Rich Rich Actual air-fuel ratio rich - Extremely rich or lean actual air fuel ratio Gas leak from exhaust system Lean: During Control the Injection Volume for, the air fuel ratio sensor output voltage (AFS Voltage B1S1 or AFS Voltage B2S1) is consistently more than 3.4 V, and the heated oxygen sensor output voltage (O2S B1S2 or O2S B2S2) is consistently less than 0.4 V. Rich: During Control the Injection Volume, the AFS Voltage B1S1 or AFS Voltage B2S1 is consistently less than 3.1 V, and the O2S B1S2 or O2S B2S2 is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume of the Active Test, the output voltage of the air fuel ratio sensor and heated oxygen sensor alternates correctly. B --> See step 7 C --> See step 5 D --> See step 6 A: Go to next step
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. NG --> See step 8 OK: Go to next step
- CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the front exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the No. 2 front exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A, B DTC P0430 is output C, D DTC P0420 and P0430 are output A, B, C, D A --> See step 15 B --> See step 14 C --> See step 16 D --> See step 17
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. OK --> See step 9 NG --> See step 8
- CHECK FOR EXHAUST GAS LEAK Check for exhaust gas leaks. OK No gas leaks. OK --> See step 10 NG --> See step 8
- REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-554446-S22142429722013052000000) . NEXT --> See step 11
- REPAIR OR REPLACE EXHAUST GAS LEAK POINT Repair or replace exhaust gas leak point. NEXT --> See step 11
- REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL»(ref-554446-S25614432402013052000000) . NEXT --> See step 11
- CHECK OF CAUSE EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO Check the cause of extremely rich or lean actual air fuel ratio, referring to the DTC P0171 Inspection Procedure. Refer to «INSPECTION PROCEDURE»(ref-554467-S37107976722013052000000) . NEXT: Go to next step
- CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-554459-S40410068552013052000000) . Turn the ignition switch off and wait for at least 30 seconds. Start the engine. Turn the tester on. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the pending DTCs. RESULT Result Proceed to DTC P0420 and/or P0430 is output A DTC is not output B B --> END A: Go to next step
- CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) NOTE: When outputting DTC P0420 replace the exhaust manifold sub-assembly RH (TWC: Front catalyst) and the front exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. When outputting DTC P0430 replace the exhaust manifold sub-assembly LH (TWC: Front catalyst) and the No. 2 front exhaust pipe assembly (TWC: Rear catalyst) together when catalyst replacement is necessary. HINT: Confirm the replacement parts, referring to the illustration in the Catalyst Location. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P0420 is output A, B DTC P0430 is output C, D DTC P0420 and P0430 are output A, B, C, D A --> See step 15 B --> See step 14 C --> See step 16 D --> See step 17
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-554459-S06730665172013052000000)
- REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-554480-S41900956052013052000000)
- REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-554377-S00600519162013052000000)
- REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-554377-S00600519162013052000000)
- REPLACE NO. 2 FRONT EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-554480-S41900956052013052000000)
