Windows / Glass (Service Information) (Base): Overview Toyota Prius Plug-in

Windows 3 illustrations ~155 words

Scheme 28

Scheme 28: ILLUSTRATION
Scheme 28: ILLUSTRATION

Scheme 29

Scheme 29: REMOVAL
Scheme 29: REMOVAL
  1. REMOVE ASSIST GRIP COVER. Refer to «DISASSEMBLY - Step 5»(ref-551602-S12863643622013051500000)
  2. REMOVE POWER WINDOW REGULATOR MASTER SWITCH ASSEMBLY WITH FRONT DOOR ARMREST BASE PANEL. Refer to «DISASSEMBLY - Step 6»(ref-551602-S12863643622013051500000)
  3. REMOVE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Remove the 3 screws and the multiplex network master switch assembly.

Scheme 30

Scheme 30: INSPECTION
Scheme 30: INSPECTION
  1. INSPECT MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Check that the LED illuminates. Apply battery voltage to the multiplex network master switch assembly and check that the LED illuminates. OK Measurement Condition Specified Condition Battery positive (+) --> 18 (LED) Battery negative (-) --> 12 (GND) LED illuminates TEXT IN ILLUSTRATION *1 Component without harness connected (to Multiplex Network Master Switch Assembly) If the result is not as specified, replace the multiplex network master switch assembly.
