DESCRIPTION
The power window regulator motor assembly is operated by the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.
This DTC is output when the power window regulator motor assembly has a malfunction, or the ECU built into the power window regulator motor assembly determines that the fully closed window position has deviated approximately 20 mm (0.787 in.) or more from the normal position.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Power window regulator motor assembly (for driver door) Incorrect installation of power window components Overheated power window regulator motor assembly |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Power window regulator motor assembly (for front passenger door) Incorrect installation of power window components Overheated power window regulator motor assembly |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Power window regulator motor assembly (for rear LH door) Incorrect installation of power window components Overheated power window regulator motor assembly |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2311 | Either condition is met: Power window regulator motor assembly malfunctions When ECU in power window regulator motor assembly determines that fully closed window position has deviated approx. 20 mm (0.787 in.) or more from normal position | Power window regulator motor assembly (for rear RH door) Incorrect installation of power window components Overheated power window regulator motor assembly |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH DOOR))
The power window regulator motor assemblies are operated by the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assemblies. The power window regulator motor assemblies have motor, regulator and ECU functions.
This DTC is output when the ECU built into a power window regulator motor assembly and multiplex network master switch assembly determine that the multiplex network master switch assembly, power window regulator switch assembly or rear power window regulator switch assembly is stuck.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 seconds Door control switch (multiplex network master switch assembly) operated for 20 seconds or more | Multiplex network master switch assembly |
MASTER SWITCH (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY)
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Multiplex network master switch assembly stuck Multiplex network master switch assembly held in same position for more than 20 seconds | Multiplex network master switch assembly Power window regulator motor assembly (for driver door) Wire harness or connector |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Power window regulator switch assembly stuck Power window regulator switch assembly held in same position for more than 20 seconds | Power window regulator switch assembly Power window regulator motor assembly (for front passenger door) Wire harness or connector |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Rear power window regulator switch assembly (for LH door) stuck Power window regulator switch assembly held in same position for more than 20 seconds | Rear power window regulator switch assembly (for LH door) Power window regulator motor assembly (for rear LH door) Wire harness or connector |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2312 | Rear power window regulator switch assembly (for RH door) stuck Power window regulator switch assembly held in same position for more than 20 seconds | Rear power window regulator switch assembly (for RH door) Power window regulator motor assembly (for rear RH door) Wire harness or connector |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH DOOR))
Scheme 304
Scheme 305
Scheme 306
Scheme 307
- for Driver Door
- for Front Passenger Door
- for Rear LH Door
- for Rear RH Door
The power window regulator motor assembly is operated by the multiplex network master switch or power window regulator switch assembly. The power window regulator motor assembly has motor, regulator and ECU functions.
When the ECU determines that the power window regulator motor assembly has not been initialized, DTC B2313 is stored.
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions Auxiliary battery disconnected when power switch on (IG) | Power window regulator motor assembly (for driver door) not initialized Power window regulator motor assembly (for driver door) |
D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions Auxiliary battery disconnected when power switch on (IG) | Power window regulator motor assembly (for front passenger door) not initialized Power window regulator motor assembly (for front passenger door) |
P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions Auxiliary battery disconnected when power switch on (IG) | Power window regulator motor assembly (for rear LH door) not initialized Power window regulator motor assembly (for rear LH door) |
RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH DOOR))
| DTC No. | DTC Detection Condition | Trouble Area |
|---|---|---|
| B2313 | Power window regulator motor assembly not initialized Power window regulator motor assembly malfunctions Auxiliary battery disconnected when power switch on (IG) | Power window regulator motor assembly (for rear RH door) not initialized Power window regulator motor assembly (for rear RH door) |
RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH DOOR))
When the power switch is on (IG), the multiplex network master switch assembly sends remote up and down signals to each power window regulator motor assembly via LIN communication.
Scheme 308
When the hybrid control system is running or the power switch is on (IG), the power window regulator motor assembly (for driver door) is operated by the multiplex network master switch assembly. The power window regulator motor assembly (for driver door) has motor, regulator and ECU functions.
Scheme 309
When the hybrid control system is running or the power switch is on (IG), the power window regulator motor assembly (for front passenger door) is operated by the power window regulator switch assembly. The power window regulator motor assembly (for front passenger door) has motor, regulator, and ECU functions.
Scheme 310
When the hybrid control system is running or the power switch is on (IG), the power window regulator motor assembly (for rear LH door) is operated by the rear power window regulator switch assembly (for LH door). The power window regulator motor has motor, regulator, and ECU functions.
Scheme 311
When the hybrid control system is running or the power switch is on (IG), the power window regulator motor assembly (for rear RH door) is operated by the rear power window regulator switch assembly (for RH door). The power window regulator motor assembly (for rear RH door) has motor, regulator, and ECU functions.
Scheme 312
If the manual up and down functions operate normally but the auto up and down functions do not, then fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
HINT
If the pulse sensor built into the power window regulator motor assembly (for driver door) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the multiplex network master switch assembly at the auto up position, and opened manually by pushing down the multiplex network master switch assembly.
Scheme 313
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
HINT
If the pulse sensor built into the power window regulator motor assembly (for front passenger door) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the power window regulator switch assembly at the auto up position, and opened manually by pushing down the power window regulator switch assembly.
Scheme 314
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
HINT
If the pulse sensor built into the power window regulator motor assembly (for rear LH door) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the rear power window regulator switch assembly (for LH door) at the auto up position, and opened manually by pushing down the rear power window regulator switch assembly (for LH door).
Scheme 315
If the manual up and down functions operate normally but the auto up and down functions do not, the fail-safe mode may be functioning.
If power window initialization. Refer to INITIALIZATION has not been performed, the auto up and down functions will not operate.
HINT
If the pulse sensor built into the power window regulator motor assembly (for rear RH door) malfunctions, the power window control system enters fail-safe mode. The remote up and down and auto up and down functions cannot be operated during fail-safe mode. However, the power window can be closed by holding the rear power window regulator switch assembly (for RH door) at the auto up position, and opened manually by pushing down the rear power window regulator switch assembly (for RH door).
Scheme 316
- When the front doors are closed, each power window regulator motor assembly can control its power window operation for approximately 43 seconds after the power switch is turned from on (IG) to off by receiving operation permission signals from the main body ECU (multiplex network body ECU).
- However, when approximately 43 seconds have elapsed, or the driver door or front passenger door is opened within approximately 43 seconds of the power switch being turned off, the power window regulator motor assembly stops operating.
- During an auto operation, when 43 seconds have passed and key-off operation is prohibited, the window operation stops immediately.
If a door glass or a power window regulator motor assembly does not operate smoothly, the jam protection function may be triggered automatically, resulting in the auto up function being unable to fully close the window.
HINT
This symptom may occur for any of the windows.
This symptom may occur for any of the windows.
The jam protection function operates within a specified range during the manual up or auto up operation.
