INSPECTION PROCEDURE

Note. DTC B2311 can be stored in each power window regulator motor assembly (power window ECU). If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION . If a power window regulator motor assembly and door window regulator sub-assembly have been removed and installed, or if a power window regulator motor assembly was reused when a door glass or door glass run was replaced, initialize the power window control system. Refer to INITIALIZATION .

HINT

If DTC B2312 is not output again after the DTC has been cleared, the DTC was output due to the switch being held.

Note. DTC B2312 can be stored in the multiplex network master switch assembly and in each power window regulator motor assembly (power window ECU). If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Scheme 317

1. CHECK FOR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553303-S08086982122013051700000) . Check for DTCs. Refer to «DTC CHECK / CLEAR»(ref-553303-S08086982122013051700000) . OK DTC B2312 is not output. NG --> See step 2 OK --> END (DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
2. CHECK DTC OUTPUT Check the parts which the DTCs have been output from. Result Result Proceed to DTC output from multiplex network master switch assembly A DTC output from power window regulator motor assembly (for driver door) B DTC output from power window regulator motor assembly (for front passenger door) C DTC output from power window regulator motor assembly (for rear LH door) D DTC output from power window regulator motor assembly (for rear RH door) E B --> See step 3 C --> See step 7 D --> See step 10 E --> See step 13 A --> See step 16
3. READ VALUE USING TECHSTREAM (D-Door Motor) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / D-Door Motor / Data List. Read the Data List according to the display on the Techstream. D-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR DRIVER DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Up SW Driver door power window manual up switch signal / OFF or ON OFF: Driver door power window manual up switch not operated ON: Driver door power window manual up switch operated - D Door P/W Down SW Driver door power window manual down switch signal / OFF or ON OFF: Driver door power window manual down switch not operated ON: Driver door power window manual down switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 4 OK --> See step 20
4. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - DRIVER DOOR MOTOR) Disconnect the multiplex network master switch assembly connector. Disconnect the power window regulator motor assembly (for driver door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition O6-20 (UP) - Body ground Always 10 kohms or higher O6-15 (DOWN) - Body ground Always 10 kohms or higher O2-10 (UP) - Body ground Always 10 kohms or higher O2-7 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
5. REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Replace the multiplex network master switch assembly. Refer to «REMOVAL»(ref-553502-S14307835562013051700000) . NEXT: Go to next step
6. CHECK FOR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-553303-S08086982122013051700000) . Check for DTCs. Refer to «DTC CHECK / CLEAR»(ref-553303-S08086982122013051700000) . OK DTC B2312 is not output. NG --> See step 20 OK --> END (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY WAS DEFECTIVE)
7. READ VALUE USING TECHSTREAM (P-Door Motor) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger door power window auto switch signal / OFF or ON OFF: Front passenger door power window auto switch not operated ON: Front passenger door power window auto switch operated - P Door P/W Up SW Front passenger door power window manual up switch signal / OFF or ON OFF: Front passenger door power window manual up switch not operated ON: Front passenger door power window manual up switch operated - P Door P/W Down SW Front passenger door power window manual down switch signal / OFF or ON OFF: Front passenger door power window manual down switch not operated ON: Front passenger door power window manual down switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 8 OK --> See step 21
8. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch assembly. Refer to «REMOVAL»(ref-553502-S19479898442013051700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Auto up or up position Below 1 ohms 7 (DOWN) - 1 (GND) Auto down or down position Below 1 ohms 8 (AUTO) - 1 (GND) Auto up or auto down position Below 1 ohms 6 (UP) - 1 (GND) Free 10 kohms or higher 7 (DOWN) - 1 (GND) Free 10 kohms or higher 8 (AUTO) - 1 (GND) Free 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Power Window Regulator Switch Assembly) NG --> See step 17 OK: Go to next step
9. CHECK HARNESS AND CONNECTOR (FRONT PASSENGER DOOR SWITCH - FRONT PASSENGER DOOR MOTOR) Disconnect the power window regulator motor assembly (for front passenger door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N7-6 (UP) - Body ground Always 10 kohms or higher N7-7 (DOWN) - Body ground Always 10 kohms or higher N7-8 (AUTO) - Body ground Always 10 kohms or higher N2-10 (UP) - Body ground Always 10 kohms or higher N2-7 (DOWN) - Body ground Always 10 kohms or higher N2-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 21
10. READ VALUE USING TECHSTREAM (RL-Door Motor) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RL-Door Motor / Data List. Read the Data List according to the display on the Techstream. RL-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR LH DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear LH door power window auto switch signal / OFF or ON OFF: Rear LH door power window auto switch not operated ON: Rear LH door power window auto switch operated - RL Door P/W Up SW Rear LH door power window manual up switch signal / OFF or ON OFF: Rear LH door power window manual up switch not operated ON: Rear LH door power window manual up switch operated - RL Door P/W Down SW Rear LH door power window manual down switch signal / OFF or ON OFF: Rear LH door power window manual down switch not operated ON: Rear LH door power window manual down switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 11 OK --> See step 22
11. INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for LH Door) Remove the rear power window regulator switch assembly (for LH door). Refer to «REMOVAL»(ref-553502-S19549883622013051700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Auto up or up position Below 1 ohms 7 (DOWN) - 1 (GND) Auto down or down position Below 1 ohms 8 (AUTO) - 1 (GND) Auto up or auto down position Below 1 ohms 6 (UP) - 1 (GND) Free 10 kohms or higher 7 (DOWN) - 1 (GND) Free 10 kohms or higher 8 (AUTO) - 1 (GND) Free 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for LH Door)) NG --> See step 18 OK: Go to next step
12. CHECK HARNESS AND CONNECTOR (REAR LH SWITCH - REAR LH MOTOR) Disconnect the power window regulator motor assembly (for rear LH door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition Q2-6 (UP) - Body ground Always 10 kohms or higher Q2-7 (DOWN) - Body ground Always 10 kohms or higher Q2-8 (AUTO) - Body ground Always 10 kohms or higher Q4-10 (UP) - Body ground Always 10 kohms or higher Q4-7 (DOWN) - Body ground Always 10 kohms or higher Q4-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 22
13. READ VALUE USING TECHSTREAM (RR-Door Motor) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / RR-Door Motor / Data List. Read the Data List according to the display on the Techstream. RR-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR REAR RH DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear RH door power window auto switch signal / OFF or ON OFF: Rear RH door power window auto switch not operated ON: Rear RH door power window auto switch operated - RR Door P/W Up SW Rear RH door power window manual up switch signal / OFF or ON OFF: Rear RH door power window manual up switch not operated ON: Rear RH door power window manual up switch operated - RR Door P/W Down SW Rear RH door power window manual down switch signal / OFF or ON OFF: Rear RH door power window manual down switch not operated ON: Rear RH door power window manual down switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 14 OK --> See step 23
14. INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for RH Door) Remove the rear power window regulator switch assembly (for RH door). Refer to «REMOVAL»(ref-553502-S19549883622013051700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Auto up or up position Below 1 ohms 7 (DOWN) - 1 (GND) Auto down or down position Below 1 ohms 8 (AUTO) - 1 (GND) Auto up or auto down position Below 1 ohms 6 (UP) - 1 (GND) Free 10 kohms or higher 7 (DOWN) - 1 (GND) Free 10 kohms or higher 8 (AUTO) - 1 (GND) Free 10 kohms or higher TEXT IN ILLUSTRATION *a Component without harness connected (Rear Power Window Regulator Switch Assembly (for RH Door)) NG --> See step 19 OK: Go to next step
15. CHECK HARNESS AND CONNECTOR (REAR RH SWITCH - REAR RH MOTOR) Disconnect the power window regulator motor assembly (for rear RH door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition P2-6 (UP) - Body ground Always 10 kohms or higher P2-7 (DOWN) - Body ground Always 10 kohms or higher P2-8 (AUTO) - Body ground Always 10 kohms or higher P4-10 (UP) - Body ground Always 10 kohms or higher P4-7 (DOWN) - Body ground Always 10 kohms or higher P4-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 23
16. REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-553502-S14307835562013051700000)
17. REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-553502-S19479898442013051700000)
18. REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for LH Door). Refer to «REMOVAL»(ref-553502-S19549883622013051700000)
19. REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY (for RH Door). Refer to «REMOVAL»(ref-553502-S19549883622013051700000)
20. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Door). Refer to «REMOVAL»(ref-553502-S26977415982013051700000)
21. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Door). Refer to «REMOVAL»(ref-553502-S26977415982013051700000)
22. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH Door). Refer to «REMOVAL»(ref-553502-S17305121422013051700000)
23. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH Door). Refer to «REMOVAL»(ref-553502-S17305121422013051700000)

Note. DTC B2313 can be stored in each power window regulator motor assembly (power window ECU). When disconnecting the auxiliary battery while the power switch on (IG), DTC B2313 is stored. If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for driver door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for front passenger door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Scheme 318

1. READ VALUE USING TECHSTREAM (Main Body) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / Main Body / Data List. Read the Data List according to the display on the Techstream. MAIN BODY (MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note Communication P-Door Motor Connection status between power window regulator motor (for front passenger door) and main body ECU (multiplex network body ECU) / STOP or OK STOP: Communication stopped OK: Normal communication - OK On the Techstream screen, OK is displayed. NG --> See step 8 OK: Go to next step
2. READ VALUE USING TECHSTREAM (P-Door Motor) Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Up SW Front passenger door power window manual up switch signal / OFF or ON OFF: Front passenger power window manual up switch not operated ON: Front passenger door power window manual up switch operated - P Door P/W Down SW Front passenger door power window manual down switch signal / OFF or ON OFF: Front passenger power window manual down switch not operated ON: Front passenger door power window manual down switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 4 OK: Go to next step
3. PERFORM ACTIVE TEST USING TECHSTREAM (P-Door Motor) Enter the following menus: Body Electrical / P-Door Motor / Active Test. Perform the Active Test according to the display on the Techstream. WARNING: Be careful to avoid injuries as this test causes vehicle parts to move. During the Active Test, the jam protection function will not operate. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR)) Tester Display Test Part Control Range Diagnostic Note Power Window Power window OFF / UP / DOWN - OK Front passenger door power window operates normally. NG --> See step 7 OK --> See step 9
4. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch assembly. Refer to «REMOVAL»(ref-553502-S19479898442013051700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Auto up or up position Below 1 ohms 7 (DOWN) - 1 (GND) Auto down or down position Below 1 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Power Window Regulator Switch Assembly) NG --> See step 6 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (FRONT PASSENGER DOOR SWITCH - MOTOR AND BODY GROUND) Disconnect the power window regulator motor assembly (for front passenger door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N7-6 (UP) - N2-10 (UP) Always Below 1 ohms N7-7 (DOWN) - N2-7 (DOWN) Always Below 1 ohms N7-1 (GND) - Body ground Always Below 1 ohms N7-6 (UP) - Body ground Always 10 kohms or higher N7-7 (DOWN) - Body ground Always 10 kohms or higher N2-10 (UP) - Body ground Always 10 kohms or higher N2-7 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
6. REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-553502-S19479898442013051700000)
7. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Door). Refer to «REMOVAL»(ref-553502-S26977415982013051700000)
8. GO TO LIN COMMUNICATION SYSTEM (Proceed to How to Proceed with Troubleshooting). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-553510-S26218353412013051700000)
9. REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-553451-S27066155482013051700000)

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for rear LH door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for rear RH door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for driver door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for front passenger door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Scheme 319

1. READ VALUE USING TECHSTREAM (P-Door Motor) Connect the Techstream to the DLC3. Turn the power switch on (IG). Turn the Techstream on. Enter the following menus: Body Electrical / P-Door Motor / Data List. Read the Data List according to the display on the Techstream. P-DOOR MOTOR (POWER WINDOW REGULATOR MOTOR ASSEMBLY (FOR FRONT PASSENGER DOOR)) Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger door power window auto switch signal / OFF or ON OFF: Front passenger door power window auto switch not operated ON: Front passenger door power window auto switch operated - OK On the Techstream screen, ON or OFF is displayed accordingly. NG --> See step 4 OK: Go to next step
2. PERFORM INITIALIZATION (for Front Passenger Door) Initialize the power window regulator motor assembly (for front passenger door). Refer to «INITIALIZATION»(ref-553303-S29938663572013051700000) . NEXT: Go to next step
3. CHECK POWER WINDOW CONTROL SYSTEM (AUTO UP/DOWN FUNCTION) Check that the front passenger door power window moves when the auto up and down functions of the power window regulator switch assembly are operated. Refer to «OPERATION CHECK»(ref-553303-S40391138482013051700000) . OK Front passenger door auto up and down functions are normal. NG --> See step 6 OK --> END (PROBLEM DUE TO INITIALIZATION FAILURE)
4. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch assembly. Refer to «REMOVAL»(ref-553502-S19479898442013051700000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 8 (AUTO) - 1 (GND) Auto up or auto down position Below 1 ohms TEXT IN ILLUSTRATION *a Component without harness connected (Power Window Regulator Switch Assembly) NG --> See step 7 OK: Go to next step
5. CHECK HARNESS AND CONNECTOR (POWER WINDOW SWITCH - REGULATOR MOTOR) Disconnect the power window regulator motor assembly (for front passenger door) connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition N7-8 (AUTO) - N2-4 (AUTO) Always Below 1 ohms N7-8 (AUTO) - Body ground Always 10 kohms or higher N2-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
6. REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Front Passenger Door). Refer to «REMOVAL»(ref-553502-S26977415982013051700000)
7. REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-553502-S19479898442013051700000)

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for rear LH door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly. If the power window regulator motor assembly (for rear RH door) has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .

Note. The power window control system uses a LIN communication system. Inspect the communication function by following How to Proceed with Troubleshooting. Refer to HOW TO PROCEED WITH TROUBLESHOOTING . Troubleshoot the power window control system after confirming that the communication system is functioning properly.

Note. If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION . If a power window regulator motor assembly and door window regulator sub-assembly have been removed and installed, or if a power window regulator motor assembly was reused when a door glass or door glass run was replaced, initialize the power window control system. Refer to INITIALIZATION .

Note. If a power window regulator motor assembly has been replaced with a new one, initialize the power window control system. Refer to INITIALIZATION .
