DEFINITION OF TERMS

Scheme 56

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

CHECK FOR INTERMITTENT PROBLEMS

HINT

Inspect the vehicle's ECM using check mode. Intermittent problems are easier to detect with the Techstream when the ECM is in check mode. In check mode, the ECM uses 1 trip detection logic, which is more sensitive to malfunctions than normal mode (default), which uses 2 trip detection logic.

1. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-427311-S31989667402011101200000) .
2. Switch the ECM from normal mode to check mode using the Techstream. Refer to «CHECK MODE PROCEDURE»(ref-427311-S18345068272011101200000) .
3. Perform a simulation test. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-427305-S34248619712011101200000) .
4. Check and wiggle the harness(es), connector(s) and terminal(s). Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-427305-S30340386252011101200000) .

REGISTRATION

Note. The Vehicle Identification Number (VIN) must be input into a replacement ECM.

HINT

The VIN is a 17-digit alphanumeric vehicle identification number. The Techstream is required to register the VIN.

1. DESCRIPTION HINT: This registration information consists of two parts: Read VIN and Write VIN. Read VIN: This process allows the VIN stored in the ECM to be read in order to confirm that the two VINs, provided with the vehicle and stored in the vehicle's ECM, are the same. Write VIN: This process allows the VIN to be input into the ECM. If the ECM is changed, or the ECM VIN and vehicle VIN do not match, the VIN can be registered, or overwritten in the ECM by following this procedure.
2. READ VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Read.
3. WRITE VIN Confirm the vehicle VIN. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / VIN / VIN Write.

CHECKING MONITOR STATUS

The purpose of the monitor result (mode 06) is to allow access to the results for on-board diagnostic monitoring tests of specific components/systems that are not continuously monitored. Examples are catalysts and evaporative emissions (EVAP) systems.

The monitor result allows the OBD II scan tool to display the monitor status, test value, minimum test limit and maximum test limit. These data are displayed after the vehicle has been driven to run the monitor.

When the test value is not between the minimum and maximum test limits, the ECM (PCM) interprets this as a malfunction. If the test value is on the borderline of the test limits, the component is likely to malfunction in the near future.

Perform the following procedures to view the monitor status. Although these procedures refer to the Toyota Techstream, the monitor status can be checked using a generic OBD II scan tool. Refer to your scan tool operator's manual for specific procedural information.

1. PERFORM MONITOR DRIVE PATTERN Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-427311-S31989667402011101200000) . Operate the vehicle in accordance with the applicable drive pattern described in Readiness Monitor Drive Pattern. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-427311-S30997881282011101200000) . Do not turn the ignition switch off. HINT: The test results will be lost if the ignition switch is turned off.
2. ACCESS MONITOR RESULT Enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Result. Confirm the monitor status for each component. HINT: The monitor status for each component is displayed in the Result column. Pass: The component is functioning normally. Fail: The component is malfunctioning. Display the test results and test value for a monitor by selecting the icon in the Details column for that monitor.
3. CHECK COMPONENT STATUS Compare the Test Value with the minimum test limit (Min Limit) and maximum test limit (Max Limit). If the test value is between the minimum and maximum test limits, the component is functioning normally. If not, the component is malfunctioning. The test value is usually not near the test limits. If the test value is on the borderline of the test limits, the component is likely to malfunction in the near future. HINT: The monitor result might on rare occasions be Pass even if the Malfunction Indicator Lamp (MIL) is illuminated. This indicates the system malfunctioned on a previous driving cycle. This might be caused by an intermittent problem.
4. MONITOR RESULT INFORMATION If you use a generic scan tool, multiply the test value by the scaling value listed below. ADVANCE / RETARDED INTAKE SIDE Monitor ID Test ID Scaling Unit Description $35 $81 Multiply by 0.01 Second Forced movement of oil control valve time ADVANCE / RETARDED EXHAUST SIDE Monitor ID Test ID Scaling Unit Description $35 $85 Multiply by 0.01 Second Forced movement of oil control valve time AIR FUEL RATIO SENSOR (SENSOR 1) Monitor ID Test ID Scaling Unit Description $01 $8E Multiply by 0.001 V Air fuel ratio sensor deterioration level $01 $91 Multiply by 0.004 mA Air fuel ratio sensor current HEATED OXYGEN SENSOR (SENSOR 2) Monitor ID Test ID Scaling Unit Description $02 $08 Multiply by 0.001 V Maximum sensor voltage $02 $8B Multiply by 0.001 Seconds 0.35 - 0.2 V sensor switch time $02 $8D Multiply by 0.001 Seconds Duration that sensor voltage drops to 0.2 V during fuel-cut $02 $8F Multiply by 0.0003 g Maximum oxygen storage capacity FUEL SYSTEM Monitor ID Test ID Scaling Unit Description $81 $81 Multiply by 0.00003 No dimension Monitoring method using air fuel ratio sensor $81 $82 Multiply by 0.001 No dimension Monitoring method using crank angle sensor CATALYST Monitor ID Test ID Scaling Unit Description $21 $A9 Multiply by 0.0003 No dimension Oxygen storage capacity of catalyst EVAP Monitor ID Test ID Scaling Unit Description $3D $C9 Multiply by 0.001 kPa Test value for small leak (P0456) $3D $CA Multiply by 0.001 kPa Test value for gross leak (P0455) $3D $CB Multiply by 0.001 kPa Test value for leak detection pump off stuck (P2401) $3D $CD Multiply by 0.001 kPa Test value for leak detection pump on stuck (P2402) $3D $CE Multiply by 0.001 kPa Test value for vent valve off stuck (P2420) $3D $CF Multiply by 0.001 kPa Test value for vent valve on stuck (P2419) $3D $D0 Multiply by 0.001 kPa Test value for reference orifice low flow (P043E) $3D $D1 Multiply by 0.001 kPa Test value for reference orifice high flow (P043F) $3D $D4 Multiply by 0.001 kPa Test value for purge VSV close stuck (P0441) $3D $D5 Multiply by 0.001 kPa Test value for purge VSV open stuck (P0441) $3D $D7 Multiply by 0.001 kPa Test value for purge flow insufficient (P0441) MISFIRE Monitor ID Test ID Scaling Unit Description $A1 $0B Multiply by 1 Time Total EWMA* misfire count of all cylinders in last ten driving cycles $A1 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of all cylinders in last driving cycle is displayed. While engine is running, total misfire count of all cylinders in current driving cycle is displayed. $A2 $0B Multiply by 1 Time Total EWMA* misfire count for cylinder 1 in last ten driving cycles $A2 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 1 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 1 in current driving cycle is displayed. $A3 $0B Multiply by 1 Time Total EWMA* misfire count for cylinder 2 in last ten driving cycles $A3 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 2 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 2 in current driving cycle is displayed. $A4 $0B Multiply by 1 Time Total EWMA* misfire count for cylinder 3 in last ten driving cycles $A4 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 3 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 3 in current driving cycle is displayed. $A5 $0B Multiply by 1 Time Total EWMA* misfire count for cylinder 4 in last ten driving cycles $A5 $0C Multiply by 1 Time When ignition switch is ON, total misfire count of cylinder 4 in last driving cycle is displayed. While engine is running, total misfire count of cylinder 4 in current driving cycle is displayed. HINT: *: EWMA (Exponential Weighted Moving Average) misfire counts for last 10 driving cycles (calculated) Calculation: 0.1 x (current counts) + 0.9 x (previous average) Initial value for (previous average) = 0

Scheme 63

Scheme 64

Scheme 65

1. PURPOSE OF READINESS TESTS The On-Board Diagnostic (OBD II) system is designed to monitor the performance of emission related components, and indicate any detected abnormalities using DTCs (Diagnostic Trouble Codes). Since various components need to be monitored during different driving conditions, the OBD II system is designed to run separate monitoring programs called Readiness Monitors. To view the monitor status, enter the following menus: Powertrain / Engine and ECT / Monitor / Current Monitor / Current. When the status of a Readiness Monitor reads Complete, the necessary conditions have been met for running the performance tests for that Readiness Monitor. A generic OBD II scan tool can also be used to view the Readiness Monitor status. HINT: Many state Inspection and Maintenance (I/M) programs require the status of vehicle Readiness Monitors to show Complete before beginning emission tests. The Readiness Monitors will be reset to Incomplete if: The ECM has lost battery power or blown a fuse. DTCs have been cleared. The conditions for running the Readiness Monitor have not been met. If a Readiness Monitor status shows Incomplete, follow the appropriate Readiness Monitor Drive Pattern to change the status to Complete. WARNING: Strictly observe posted speed limits, traffic laws, and road conditions when performing these drive patterns. NOTE: These drive patterns represent the fastest method of satisfying all conditions necessary to achieve complete status for each specific Readiness Monitor. In the event of a drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed. In most cases, the Readiness Monitor will still achieve complete status upon completion of the drive pattern. To ensure completion of the Readiness Monitors, avoid sudden changes in vehicle load and speed (driving up and down hills and/or sudden acceleration).
2. CATALYST MONITOR (ACTIVE AIR FUEL RATIO CONTROL TYPE) Preconditions The monitor will not run unless: The MIL is OFF. Drive Pattern (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs (if set). Refer to «DTC CHECK / CLEAR»(ref-427311-S31989667402011101200000) . (5) Start the engine and warm it up. (6) Drive the vehicle at between 40 mph and 70 mph (64 km/h and 113 km/h) for at least 10 minutes. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, extend the driving time.
3. EVAP SYSTEM MONITOR (KEY OFF TYPE) Preconditions The monitor will not run unless: The fuel tank is less than 90% full. The altitude is less than 8000 ft. (2438 m). The vehicle is stationary. The engine coolant temperature is between 4.4°C and 35°C (40°F and 95°F). The intake air temperature is between 4.4°C and 35°C (40°F and 95°F). The vehicle was driven in a city area (or on a free-way) for 10 minutes or more. Monitor Conditions Turn the ignition switch off and wait for 5 to 10 hours. HINT: Do not start the engine until checking Readiness Monitor status. If the engine is started, the step described above must be repeated. Monitor Status Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, restart the engine, make sure that the preconditions have been met, and then perform the Monitor Conditions again.
4. AIR FUEL RATIO AND HEATED OXYGEN SENSOR MONITORS (ACTIVE AIR FUEL RATIO CONTROL TYPE) Preconditions The monitor will not run unless: 2 minutes or more have elapsed since the engine was started. The engine coolant temperature is 75°C (167°F) or more. Cumulative driving time at a vehicle speed of 30 mph (48 km/h) or more exceeds 6 minutes. Air fuel ratio feedback control is performed. Drive Pattern for front air fuel ratio sensor and heated oxygen sensor (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs. Refer to «DTC CHECK / CLEAR»(ref-427311-S31989667402011101200000) . (5) Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F). (6) Drive the vehicle at between 37 mph (60 km/h) and 75 mph (120 km/h) for at least 10 minutes. (7) Change the transaxle to 2nd gear. (8) Accelerate the vehicle to 40 mph (64 km/h) or more by depressing the accelerator pedal for at least 10 seconds. (9) Soon after performing step (8) above, release the accelerator pedal for at least 8 seconds without depressing the brake pedal, in order to execute fuel-cut control. (10) Allow the vehicle to decelerate until the vehicle speed declines to less than 6 mph (10 km/h). (11) Repeat steps from (8) through (10) above at least 3 times in one driving cycle. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, make sure that the preconditions have been met, and then perform steps from (5) through (11) in Drive Pattern above.
5. AIR FUEL RATIO AND HEATED OXYGEN SENSOR HEATER MONITORS (FRONT AIR FUEL RATIO AND REAR HEATED OXYGEN SENSOR TYPE) Preconditions The monitor will not run unless: The MIL is OFF. Drive Pattern (1) Connect the Techstream to the DLC3. (2) Turn the ignition switch to ON. (3) Turn the Techstream on. (4) Clear DTCs (if set). Refer to «DTC CHECK / CLEAR»(ref-427311-S31989667402011101200000) . (5) Start the engine. (6) Allow the engine to idle for 10 minutes or more. (7) Drive the vehicle at 25 mph (40 km/h) or more for at least 2 minutes. Monitor Status Check the Readiness Monitor status displayed on the Techstream. If the status does not switch to Complete, make sure that the preconditions have been met, and repeat steps (5) to (7) described in the Drive Pattern above.

CHECK MODE PROCEDURE

Compared to normal mode, check mode is more sensitive to malfunctions. Therefore, check mode can detect malfunctions that cannot be detected in normal mode.

Note. All the stored DTCs and freeze frame data are cleared if: 1) the ECM is changed from normal mode to check mode or vice versa; or 2) the ignition switch is turned from ON to ACC or OFF while in check mode. Before changing modes, always check and note any DTCs and freeze frame data.

Scheme 66

1. CHECK MODE PROCEDURE Check and ensure the following conditions: Battery voltage 11 V or more. Throttle valve fully closed. Transaxle in P or N (neutral). A/C switch OFF. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility / Check Mode. Switch the ECM from normal mode to check mode. Make sure that the MIL flashes as shown in the illustration. Start the engine. Make sure that the MIL turns off. Simulate that the conditions of the malfunction described by the customer. Check DTCs and freeze frame data using the Techstream.

FAIL-SAFE CHART

If any of the following DTCs are set, the ECM enters fail-safe mode to allow the vehicle to be driven temporarily or stops fuel injection.

HINT

1. *1: The vehicle can be driven slowly when the accelerator pedal is depressed firmly and slowly. If the accelerator pedal is depressed quickly, the vehicle may speed up and slow down erratically.
2. *2: Misfire related fail-safe operations occur when catalyst overheat malfunctions occur.

Scheme 67

1. DATA LIST HINT: Using the Techstream to read the Data List allows the values or states of switches, sensors, actuators and other items to be read without removing any parts. This non-intrusive inspection can be very useful because intermittent conditions or signals may be discovered before parts or wiring is disturbed. Reading the Data List information early in troubleshooting is one way to save diagnostic time. NOTE: In the table below, the values listed under Normal Condition are reference only. Do not depend solely on these values when determining whether or not a part is faulty. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Data List. According to the display on the Techstream, read the Data List. Tester Display Measurement Item/Range Normal Condition*1 Diagnostic Note Vehicle Speed Vehicle speed: Min.: 0 mph (0 km/h), Max.: 158 mph (255 km/h) Actual vehicle speed Speed indicated on speedometer Engine Speed Engine speed: Min.: 0 RPM, Max.: 16383 RPM 650 to 750 RPM: Idling (Automatic transaxle) 600 to 700 RPM: Idling (Manual transaxle) - Calculate Load Calculated load by ECM: Min.: 0%, Max.: 100% 20 to 40%: Idling 15 to 35%: Running without load (2500 RPM) - Vehicle Load Vehicle load: Min.: 0%, Max.: 25700% Actual vehicle load Load percentage in terms of maximum intake air flow amount MAF Air flow rate from mass air flow meter: Min.: 0 gm/sec, Max.: 655.35 gm/sec 1 to 3 gm/sec: Idling 4.5 to 8.5 gm/sec: Running without load (2500 RPM) If value approximately 0.0 gm/sec: Mass air flow meter power source circuit open VG circuit open or short If value 271.0 gm/sec or more: E2G circuit open Atmosphere Pressure Atmospheric pressure: Min.: 0 kPa (0 mmHg) , Max.: 255 kPa (1912 mmHg) Equivalent to atmospheric pressure - Coolant Temp Engine coolant temperature: Min.: -40°C (-40°F), Max.: 140°C (284°F) 75 to 100°C (167 to 212°F): After warming up If value -40°C (-40°F): sensor circuit open If value higher than 135°C (275°F): sensor circuit shorted Intake Air Intake air temperature: Min.: -40°C (-40°F), Max.: 140°C (284°F) Equivalent to ambient air temperature If value -40°C (-40°F): sensor circuit open If value higher than 128°C (262°F): sensor circuit shorted Engine Run Time Engine run time: Min.: 0 s, Max.: 65535 s Time since engine started - Initial Engine Coolant Temp Initial engine coolant temperature: Min.: -40°C (-40°F), Max.: 119.3°C (246.8°F) Coolant temperature when engine started Service data Initial Intake Air Temp Initial intake air temperature: Min.: -40°C (-40°F), Max.: 119.3°C (246.8°F) Intake air temperature when engine started Service data Battery Voltage Battery voltage: Min.: 0 V, Max.: 65.535 V 11 to 14 V: Idling - Accel Sens. No. 1 Volt % Accelerator pedal position No. 1: Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 52 to 90%: Accelerator pedal fully depressed - Accel Sens. No. 2 Volt % Accelerator pedal position No. 2: Min.: 0%, Max.: 100% 24 to 40%: Accelerator pedal released 68 to 100%: Accelerator pedal fully depressed - Accel Sensor Out No. 1 Accelerator pedal position sensor No. 1 voltage: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 2.6 to 4.5 V: Accelerator pedal fully depressed - Accel Sensor Out No. 2 Accelerator pedal position sensor No. 2 voltage: Min.: 0 V, Max.: 4.98 V 1.2 to 2.0 V: Accelerator pedal released 3.4 to 4.7 V: Accelerator pedal fully depressed - Accelerator Idle Position Whether or not accelerator pedal position sensor detecting idle: ON or OFF ON: Idling - Accel Fully Close Learn #1 Accelerator fully closed learning value No. 1: Min.: 0 deg, Max.: 124.5 deg - Electronic throttle control system service data Accel Fully Close Learn #2 Accelerator fully closed learning value No. 2: Min.: 0 deg., Max.: 124.5 deg. - Electronic throttle control system service data Throttle Sensor Volt % Throttle valve opening percentage according to throttle position sensor: Min.: 0%, Max.: 100% 10 to 22%: Accelerator pedal released 64 to 96%: Accelerator pedal fully depressed Value calculated based on the voltage at terminal VTA1 Throttl Sensor #2 Volt % Throttle valve opening percentage according to throttle position sensor No. 2: Min.: 0%, Max.: 100% 42 to 62%: Accelerator pedal released 92 to 100%: Accelerator pedal fully depressed Value calculated based on the voltage at terminal VTA2 ST1 Brake pedal signal: ON or OFF ON: Brake pedal released - System Guard System guard: ON or OFF - Electronic throttle control system service data Open Side Malfunction Open side malfunction: ON or OFF - Electronic throttle control system service data Throttle Idle Position Whether or not throttle position sensor detecting idle: ON or OFF ON: Accelerator pedal released OFF: Accelerator pedal fully depressed - Throttle Require Position Required position: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Idling - Throttle Sensor Position*3 Throttle sensor positioning: Min.: 0%, Max.: 100% 0%: Accelerator pedal released 50 to 80%: Accelerator pedal fully depressed Recognition value for throttle opening angle on ECM Throttle Position No. 1 Throttle position No. 1: Min.: 0 V, Max.: 4.98 V 0.5 to 1.1 V: Accelerator pedal released 3.2 to 4.8 V: Accelerator pedal fully depressed 0.6 to 1.4 V: Fail-safe operating - Throttle Position No. 2 Throttle position No. 2: Min.: 0 V, Max.: 4.98 V 2.1 to 3.1 V: Accelerator pedal released 4.6 to 4.98 V: Accelerator pedal fully depressed 2.1 to 3.1 V: Fail-safe operating - Throttle Position Command Throttle position command value: Min.: 0 V, Max.: 4.98 V 0.5 to 4.8 V - Throttle Sens Open Pos #1 Throttle sensor opener position No. 1: Min.: 0 V, Max.: 4.98 V 0.6 to 1.4 V Electronic throttle control system service data Throttle Sens Open Pos #2 Throttle sensor opener position No. 2: Min.: 0 V, Max.: 4.98 V 1.7 to 2.5 V Electronic throttle control system service data Throttle Motor Current Throttle actuator current: Min.: 0 A, Max.: 19.9 A 0 to 3.0 A: Idling Electronic throttle control system service data Throttle Motor DUTY Throttle actuator: Min.: 0%, Max.: 100% 10 to 22%: Idling after engine warmed up Electronic throttle control system service data Throttle Motor Duty (Open) Throttle actuator duty ratio (open): Min.: 0%, Max.: 255% 0 to 40%: Idling Electronic throttle control system service data Throttle Motor Duty (Close) Throttle actuator duty ratio (close): Min.: 0%, Max.: 255% 0 to 40%: Idling Electronic throttle control system service data Throttle Fully Close Learn Throttle valve fully closed (learned value): Min.: 0 V, Max.: 4.98 V 0.4 to 1.0 V: Accelerator pedal released - +BM Voltage +BM voltage: Min.: 0, Max.: 79.998 V 11 to 14 V: Ignition switch ON and system normal Electronic throttle control system service data Actuator Power Supply Actuator power supply: ON or OFF ON: Idling - Throttle Position Throttle valve opening angle: Min.: 0 deg, Max.: 499.99 deg - When the engine stalls, is difficult to start, or idles roughly ISC Flow Flow rate calculated from information from each sensor: Min.: 0 L/s, Max.: 79.99 L/s - When the engine stalls, is difficult to start, or idles roughly ISC Position Target valve opening angle calculated from ISC: Min.: 0 deg, Max.: 499.99 deg - When the engine stalls, is difficult to start, or idles roughly ISC Feedback Value ISC feedback value: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly ISC Learning Value ISC learning value: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Electric Load Feedback Val Electrical load feedback value: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Air Conditioner FB Val Air conditioner load feedback value: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Low Revolution Control Status of low engine speed control: ON or OFF - When the engine stalls, is difficult to start, or idles roughly N Range Status*3 Judgment shift lever N position: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Eng Stall Control FB Flow Feedback value of intake air flow: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Deposit Loss Flow Deposit loss air flow rate: Min.: -40 L/s, Max.: 39.99 L/s - When the engine stalls, is difficult to start, or idles roughly Injector (Port) Injection duration for cylinder 1: Min.: 0 μs, Max.: 65535 μs 1000 to 3000 μs: Idling - Injection Volum (Cylinder1) Injection volume (Cylinder 1): Min.: 0 ml, Max.: 2.047 ml 0.05 to 0.15 ml: Idling Quantity of fuel injection volume for 10 times Fuel Pump/Speed Status Fuel pump/status: ON or OFF - - Vacuum Pump Key-off EVAP system leak detection pump status: ON or OFF - - EVAP (Purge) VSV EVAP (Purge) VSV control duty: Min.: 0%, Max.: 100% 10 to 50%: Idling, under purge control Order signal from ECM Evap Purge Flow Ratio of evaporative purge flow to intake air volume: Min.: 0%, Max.: 399.9% 0 to 10%: Idling Service data Purge Density Learn Value Learning value of purge density: Min.: -200, Max.: 199.993 -40 to 10: Idling Service data Vapor Pressure Pump Vapor pressure: Min.: 0 kPa (mmHg), Max.: 1441.77 kPa (10813.275 mmHg) Approximately 100 kPa (760 mmHg) (absolute): Ignition switch ON EVAP system pressure monitored by canister pressure sensor Vapor Pressure (Calculated) Vapor pressure (calculated): Min.: -720.896 kPa (-5406.72 mmHg), Max.: 720.874 kPa (5406.555 mmHg) Approximately 100 kPa (760 mmHg) (absolute): Ignition switch ON EVAP system pressure monitored by canister pressure sensor EVAP System Vent Valve Key-off EVAP system vent valve status: ON or OFF - - EVAP Purge VSV VSV status for EVAP control: ON or OFF - - Purge Cut VSV Duty Purge cut VSV duty: Min.: 0%, Max.: 399.9% - - Target Air-Fuel Ratio Ratio compared to stoichiometric level: Min.: 0, Max.: 1.99 0.8 to 1.2: Idling - AF Lambda B1S1 Short-term fuel trim associated with bank 1 sensor 1: Min.: 0, Max.: 1.99 Value less than 1 (0.000 to 0.999) = Rich Stoichiometric air fuel ratio = 1 Value greater than 1 (1.001 to 1.999) = Lean - AFS Voltage B1S1 Air fuel ratio sensor output voltage for bank 1 sensor 1: Min.: 0 V, Max.: 7.99 V 2.6 to 3.8 V: Idling, engine warmed up Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensors AFS Current B1S1 Air fuel ratio sensor output current for bank 1 sensor 1: Min.: -128 mA, Max.: 127.99 mA -0.5 to 0.5 mA: Idling, engine warmed up Value becomes higher when fuel-cut executed under high engine speed A/F Heater Duty #1 Air fuel ratio heater duty for bank 1: Min.: 0%, Max.: 399.9% 0 to 100% - O2S B1S2 Heated oxygen sensor output voltage for bank 1 sensor 2: Min.: 0 V, Max.: 1.275 V 0.0 to 0.9 V: Driving at 44 mph (70 km/h) Performing Control the Injection Volume or Control the Injection Volume for A/F Sensor function of Active Test enables technician to check output voltage of sensors O2S Impedance B1S2 Sub heated oxygen sensor impedance (bank 1 sensor 2): Min.: 0 ohm, Max.: 21247.67 ohm 5 to 15000 ohm: After driving for 10 minutes or more in urban area - O2 Heater B1S2 Heated oxygen sensor heater for bank 1 sensor 2: Not Act or Active - - O2 Heater Curr Val B1S2 Heated oxygen sensor current for bank 1 sensor 2: Min.: 0 A, Max.: 4.9 A - - Short FT #1 Short-term fuel trim of bank 1: Min.: -100%, Max.: 99.2% -20 to 20% Short-term fuel compensation used to maintain air fuel ratio at stoichiometric air fuel ratio Long FT #1 Long-term fuel trim of bank 1: Min.: -100%, Max.: 99.2% -20 to 20% Overall fuel compensation carried out long-term to compensate continual deviation of short-term fuel trim from central value Total FT #1 Total fuel trim of bank 1 Average value for fuel trim system of bank 1: Min.: -0.5, Max.: 0.496 -0.28 to 0.2: Idling - Fuel System Status #1 Fuel system status (bank 1): OL or CL or OLDrive or OLFault or CLFault CL: Idling after warming up OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning Fuel System Status #2 Fuel system status (bank 2): OL or CL or OLDrive or OLFault or CLFault Unused OL (Open Loop): Has not yet satisfied conditions to go closed loop CL (Closed Loop): Using air fuel ratio sensor as feedback for fuel control OLDrive: Open loop due to driving conditions (fuel enrichment) OLFault: Open loop due to detected system fault CLFault: Closed loop but air fuel ratio sensor, which used for fuel control malfunctioning IGN Advance Ignition timing advance for No. 1 cylinder: Min.: -64 deg., Max.: 63.5 deg. BTDC 0 to 15 deg.: Idling - Knock Feedback Value Feedback value of knocking: Min.: -1024°CA, Max.: 1023°CA -20 to 0°CA: Driving at 44 mph (70 km/h) Service data Knock Correct Learn Value Correction learning value of knocking: Min.: -1024°CA, Max.: 1023°CA 0 to 20°CA: Driving at 44 mph (70 km/h) Service data Idle Spark Advn Ctrl #1 Ignition timing advance value (for No. 1 cylinder): Min.: 0°CA, Max.: 15.93°CA - When the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #2 Ignition timing advance value (for No. 2 cylinder): Min.: 0°CA, Max.: 15.93°CA - When the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #3 Ignition timing advance value (for No. 3 cylinder): Min.: 0°CA, Max.: 15.93°CA - When the engine stalls, is difficult to start, or idles roughly Idle Spark Advn Ctrl #4 Ignition timing advance value (for No. 4 cylinder): Min.: 0°CA, Max.: 15.93°CA - When the engine stalls, is difficult to start, or idles roughly VVT Control Status #1 VVT control (bank 1) status: ON or OFF - - VVT Advance Fail Status of VVT advance fail: ON or OFF ON: VVT control failure - VVT Aim Angle #1*2 VVT aim angle (bank 1): Min.: 0%, Max.: 399.9% 0 to 100% VVT duty signal value during intrusive operation VVT Change Angle #1*2 VVT change angle (bank 1): Min.: 0 DegFR, Max.: 639.9 DegFR 0 to 56 DegFR: Idling Displacement angle during intrusive operation VVT OCV Duty #1*2 VVT camshaft timing oil control valve operation duty: Min.: 0%, Max.: 399.9% 0 to 100% Requested duty value for intrusive operation VVT Ex Hold Lrn Val #1*2 VVT exhaust hold duty ratio learning value (bank 1): Min.: 0%, Max.: 399.9% 0 to 100%: Idling - VVT Ex Chg Angle #1*2 VVT exhaust change angle (bank 1): Min.: 0 DegFR, Max.: 639.9 DegFR 0 DegFR: Idling Displacement angle during intrusive operation (Active Test) VVT Ex OCV Duty #1*2 VVT exhaust camshaft timing oil control valve duty (bank 1): Min.: 0%, Max.: 399.9% 0 to 100%: Idling Requested duty value for intrusive operation (Active Test) VN Turbo Type Variable nozzle turbo type: Not Avl or Commo or Vacuum or CAN Com Not Avl (Unused) - Catalyst Temp B1S1 Catalyst temperature (associated with sensor 1): Min.: -40°C (-40°F), Max.: 6513.5°C (11756.3°F) Close to catalyst inlet temperature - Catalyst Temp B1S2 Catalyst temperature (associated with sensor 2): Min.: -40°C (-40°F), Max.: 6513.5°C (11756.3°F) Close to catalyst outlet temperature - Starter Signal Starter signal (STA terminal input status): Open or Close Open: Cranking - Starter Control Ignition switch signal (STSW terminal input status): ON or OFF ON: Cranking (during ignition switch operation) - Starter Relay Starter relay (STAR terminal output status): ON or OFF ON: Cranking - ACC Relay ACC (cut) relay (ACCR terminal output status): ON or OFF ON: Cranking - Neutral Position SW Signal*3 Park/Neutral position switch status: ON or OFF ON: P or N position - Clutch Switch*4 Clutch switch status: ON or OFF ON: Clutch pedal depressed - Clutch Start SW*4 Clutch start switch status: ON or OFF ON: Clutch pedal depressed - Stop Light Switch Stop light switch status: ON or OFF ON: Brake pedal depressed - A/C Signal Air conditioning signal: ON or OFF ON: Air conditioning ON - Closed Throttle Position SW Closed throttle position switch: ON or OFF ON: Throttle fully closed OFF: Throttle open - Fuel Cut Condition Fuel cut determination flag: ON or OFF - - Immobilizer Communication Immobilizer communication: ON or OFF ON: Normal - Electrical Load Signal Electrical load signal: ON or OFF ON: Headlights or defogger turned ON - Check Mode Check mode: ON or OFF ON: Check mode ON Refer to «CHECK MODE PROCEDURE»(ref-427311-S18345068272011101200000) SPD Test Result Check mode result for vehicle speed sensor: Compl or Incmpl - - Misfire Test Result Check mode result for misfire monitor: Compl or Incmpl - - OXS1 Test Result Check mode result for heated oxygen sensor (bank 1): Compl or Incmpl - - A/F Test Results #1 Check mode result for air fuel ratio sensor (bank 1) Compl or Incmpl - - Complete Parts Monitor Comprehensive component monitor: Not Avl or Avail - - Fuel System Monitor Fuel system monitor: Not Avl or Avail - - Misfire Monitor Misfire monitor: Not Avl or Avail - - EGR/VVT Monitor EGR monitor: Not Avl or Avail - - EGR/VVT Monitor EGR monitor: Compl or Incmpl - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Not Avl or Avail - - O2S(A/FS) Heater Monitor O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor O2S (A/FS) monitor: Not Avl or Avail - - O2S(A/FS) Monitor O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor A/C monitor: Not Avl or Avail - - A/C Monitor A/C monitor: Compl or Incmpl - - 2nd Air Monitor 2nd air monitor: Not Avl or Avail - - 2nd Air Monitor 2nd air monitor: Compl or Incmpl - - EVAP Monitor EVAP monitor: Not Avl or Avail - - EVAP Monitor EVAP monitor: Compl or Incmpl - - Heated Catalyst Monitor Heated catalyst monitor: Not Avl or Avail - - Heated Catalyst Monitor Heated catalyst monitor: Compl or Incmpl - - Catalyst Monitor Catalyst monitor: Not Avl or Avail - - Catalyst Monitor Catalyst monitor: Compl or Incmpl - - Component Monitor ENA Comprehensive component monitor: Unable or Enable - - Component Monitor CMPL Comprehensive component monitor: Compl or Incmpl - - Fuel System Monitor ENA Fuel system monitor: Unable or Enable - - Fuel System Monitor CMPL Fuel system monitor: Compl or Incmpl - - Misfire Monitor ENA Misfire monitor: Unable or Enable - - Misfire Monitor CMPL Misfire monitor: Compl or Incmpl - - EGR/VVT Monitor ENA EGR monitor: Unable or Enable - - EGR/VVT Monitor CMPL EGR monitor: Compl or Incmpl - - Heater Monitor ENA O2S (A/FS) heater monitor: Unable or Enable - - Heater Monitor CMPL O2S (A/FS) heater monitor: Compl or Incmpl - - O2S(A/FS) Monitor ENA O2S (A/FS) monitor: Unable or Enable - - O2S(A/FS) Monitor CMPL O2S (A/FS) monitor: Compl or Incmpl - - A/C Monitor ENA A/C monitor: Unable or Enable - - A/C Monitor CMPL A/C monitor: Compl or Incmpl - - 2nd Air Monitor ENA 2nd air monitor: Unable or Enable - - 2nd Air Monitor CMPL 2nd air monitor: Compl or Incmpl - - EVAP Monitor ENA EVAP monitor: Unable or Enable - - EVAP Monitor CMPL EVAP monitor: Compl or Incmpl - - Heated Cat Monitor ENA Heated catalyst monitor: Unable or Enable - - Heated Cat Monitor CMPL Heated catalyst monitor: Compl or Incmpl - - Catalyst Monitor ENA Catalyst monitor: Unable or Enable - - Catalyst Monitor CMPL Catalyst monitor: Compl or Incmpl - - TC Terminal TC terminal status: ON or OFF - - # Codes (Include History) Number of emission related DTCs 0: No emission related DTC detected - MIL MIL status: ON or OFF ON: MIL ON - MIL ON Run Distance Distance traveled since MIL turned ON: Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) Distance since DTC detected - Running Time from MIL ON Running time since MIL turned ON: Min.: 0 min, Max.: 65535 min Equivalent to running time since MIL turned ON - Time after DTC Cleared Time since DTCs cleared: Min.: 0 min, Max.: 65535 min Equivalent to time since DTCs cleared - Distance from DTC Cleared Distance traveled since DTCs cleared: Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) Equivalent to distance driven since DTCs cleared - Warmup Cycle Cleared DTC Warm-up cycles since DTCs cleared: Min.: 0, Max.: 255 - Number of warm-up cycles since DTCs cleared Dist Batt Cable Disconnect Accumulated distance from battery cable disconnected: Min.: 0 km (0 mile), Max.: 65535 km (40723 mile) - - IG OFF Elapsed Time*4 Cumulative time after ignition switch off: Min.: 0 min, Max.: 655350 min - - OBD Requirements OBD requirement OBD II (California ARB) - Number of Emission DTC Emission related DTCs - Number of emission related DTCs TC and TE1 TC and CG (TE1) terminals of DLC3: ON or OFF - - Ignition Trig. Count Ignition counter for calculated misfire rate: Min.: 0, Max.: 65535 0 to 400 - Cylinder #1 Misfire Count Misfire count of cylinder 1: Min.: 0, Max.: 255 0 - Cylinder #2 Misfire Count Misfire count of cylinder 2: Min.: 0, Max.: 255 0 - Cylinder #3 Misfire Count Misfire count of cylinder 3: Min.: 0, Max.: 255 0 - Cylinder #4 Misfire Count Misfire count of cylinder 4: Min.: 0, Max.: 255 0 - All Cylinders Misfire Count All cylinders misfire count: Min.: 0, Max.: 255 0 - Misfire RPM Average of engine speed when misfire occurs: Min.: 0 RPM, Max.: 6375 RPM 0 RPM: Misfire 0 - Misfire Load Average of engine load when misfire occurred: Min.: 0 g/rev, Max.: 3.98 g/rev 0 g/rev: Misfire 0 - Misfire Margin Margin to detect engine misfire: Min.: -128%, Max.: 127% -100 to 99.22% Misfire detection margin Catalyst OT MF F/C Catalyst overheat misfire prevention fuel cut function availability: Not Avl or Avail Avail: Catalyst overheat misfire prevention fuel cut function available Not Avl: Catalyst overheat misfire prevention fuel cut function not available Service data Cat OT MF F/C History Catalyst overheat misfire prevention fuel cut function history: ON or OFF ON: Fuel cut operation history exists Service data Cat OT MF F/C Cylinder#1 Display of fuel cut operation for No. 1 cylinder (if certain level of misfire is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder#2 Display of fuel cut operation for No. 2 cylinder (if certain level of misfire is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder#3 Display of fuel cut operation for No. 3 cylinder (if certain level of misfire is detected): ON or OFF ON: Fuel cut is operating - Cat OT MF F/C Cylinder#4 Display of fuel cut operation for No. 4 cylinder (if certain level of misfire is detected): ON or OFF ON: Fuel cut is operating - Engine Speed (Starter Off) Engine speed when starter off: Min,: 0 RPM, Max.: 51199 RPM - When the engine stalls, is difficult to start, or idles roughly Starter Count Number of times starter turned on after ignition switch turned from off to ON: Min.: 0, Max.: 255 - When the engine stalls, is difficult to start, or idles roughly Run Dist of Previous Trip Distance traveled during previous trip: Min.: 0 km (0 mile), Max.: 655.35 km (407.23 mile) - Run Dist of Previous Trip continues to display the distance traveled in the previous trip during the detection period of DTC P1604, which ends 5 seconds after the engine starts. Then the previous trip distance will be cleared and the distance traveled during this trip, which is calculated based on the vehicle speed, will be displayed. When the engine is difficult to start and DTC P1604 is stored, Run Dist of Previous Trip will continue to be displayed. When inspecting for DTCs other than P1604, or when taking a snapshot, the distance traveled during this trip will be displayed. Engine Starting Time Engine run time (elapsed time from ignition switch ON to off): Min.: 0 ms, Max.: 655350 ms - When the engine stalls, is difficult to start, or idles roughly Previous Trip Coolant Temp Coolant temperature of previous trip: Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Previous Trip Intake Temp Intake temperature of previous trip: Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Engine Oil Temperature Engine oil temperature (estimated): Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Previous Trip Eng Oil Temp Engine oil temperature of previous trip: Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Ambient Temp for A/C Ambient temperature: Min.: Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Previous Trip Ambient Temp Ambient temperature of previous trip: Min.: -40°C (-40°F), Max.: 215°C (419°F) - When the engine stalls, is difficult to start, or idles roughly Engine Start Hesitation History of instances of slow engine starts: ON or OFF - - Low Rev for Eng Start History of low engine speed after engine starts: ON or OFF - - Minimum Engine Speed Minimum engine speed: Min.: 0 RPM, Max.: 51199 RPM - When the engine stalls, is difficult to start, or idles roughly Fuel Cut Elps Time Elapsed time since fuel cut due to high engine speed: Min.: 0 sec, Max.: 68746 sec - The time elapsed after a fuel cut after high engine rotation speed has occurred (More than the engine speed at which fuel cut occurs +500 RPM). A/F Learn Value Idle #1 Air fuel ratio learn value of idle area (bank 1): Min.: -50%, Max.: 49.6% -15 to 15% - A/F Learn Value Low #1 Air fuel ratio learn value of low load area (bank 1): Min.: -50%, Max.: 49.6% -15 to 15% - A/F Learn Value Mid1 #1 Air fuel ratio learn value of middle1 load area (bank 1): Min.: -50%, Max.: 49.6% -15 to 15% - A/F Learn Value Mid2 #1 Air fuel ratio learn value of middle2 load area (bank 1): Min.: -50%, Max.: 49.6% -15 to 15% - A/F Learn Value High #1 Air fuel ratio learn value of high load area (bank 1): Min.: -50%, Max.: 49.6% -15 to 15% - Electric Fan Motor Electric cooling fan motor: ON or OFF ON: Electric cooling fan motor operating - Idle Fuel Cut Fuel cut idle: ON or OFF ON: Fuel cut operating Idle Fuel Cut = "ON" when throttle valve fully closed and engine speed over 2500 RPM FC TAU Fuel cut TAU (Fuel cut with very light load): ON or OFF ON: Fuel cut operating Fuel cut being performed during very light load to prevent incomplete engine combustion Immobilizer Fuel Cut Status of the immobilizer fuel cut: ON or OFF - - Immobilizer Fuel Cut History Status of the immobilizer fuel cut history: ON or OFF - - Electrical Load Signal 1 Electrical load signal: ON or OFF - - Electrical Load Signal 2 Electrical load signal: ON or OFF - - Model Code Model code - Identifies model code: ZRE14# Engine Type Engine type - Identifies engine type: 2ZRFE Cylinder Number Cylinder number: Min.: 0, Max.: 255 - Identifies number of cylinders: 4 Transmission Type Transmission type - Identifies transmission (transaxle) type: ECT 4th or MT Destination Destination - Identifies destination: A (America) Model Year Model year: Min.: 1900, Max.: 2155 - Identifies model year: 2011 System Identification System identification - Identifies engine system: Gasoline (gasoline engine) Engine Speed of Cyl #1 Engine speed for cylinder 1: Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression performed using Active Test 51199 RPM: Active Test not performed Engine Speed of Cyl #2 Engine speed for cylinder 2: Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression performed using Active Test 51199 RPM: Active Test not performed Engine Speed of Cyl #3 Engine speed for cylinder 3: Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression performed using Active Test 51199 RPM: Active Test not performed Engine Speed of Cyl #4 Engine speed for cylinder 4: Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression performed using Active Test 51199 RPM: Active Test not performed Av Engine Speed of All Cyl Engine speed for all cylinders: Min.: 0 RPM, Max.: 51199 RPM - Output only when Check the Cylinder Compression performed using Active Test 51199 RPM: Active Test not performed A/F Sensor Determination (worst value) #1 Worst judgment value of air fuel ratio sensor output (bank 1): Min.: -1, Max.: 0.99 0.00 The worst value detected during monitoring is displayed. The value is reset when DTCs are cleared. Engine Speed Fluctuation Avg (worst value) #1 Worst value of average engine speed fluctuation (cylinder 1): Min.: 0, Max.: 2.55 0.00 The worst value detected during monitoring is displayed. The value is reset when DTCs are cleared. Engine Speed Fluctuation Avg (worst value) #2 Worst value of average engine speed fluctuation (cylinder 2): Min.: 0, Max.: 2.55 0.00 The worst value detected during monitoring is displayed. The value is reset when DTCs are cleared. Engine Speed Fluctuation Avg (worst value) #3 Worst value of average engine speed fluctuation (cylinder 3): Min.: 0, Max.: 2.55 0.00 The worst value detected during monitoring is displayed. The value is reset when DTCs are cleared. Engine Speed Fluctuation Avg (worst value) #4 Worst value of average engine speed fluctuation (cylinder 4): Min.: 0, Max.: 2.55 0.00 The worst value detected during monitoring is displayed. The value is reset when DTCs are cleared. HINT: *1: If no idling conditions are specified, the shift lever should be in N (neutral) or P, and the A/C switch and all accessory switches should be off. *2: Values are only displayed when performing the Active Tests: Control the VVT System (Bank 1), Control the VVT Linear (Bank1) and Control the Exhaust Liner (Bank 1). For other Active Tests, the value will be 0. *3: Automatic transaxle models only *4: Manual transaxle models only
2. ACTIVE TEST HINT: Using the Techstream to perform the Active Tests allows relays, VSVs, actuators and other items to be operated without removing any parts. This non-intrusive functional inspection can be very useful because intermittent operation may be discovered before parts or wiring is disturbed. Performing Active Tests early in troubleshooting is one way to save diagnostic time. Data List information can be displayed while performing Active Tests. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test. According to the display on the Techstream, perform the Active Test. Tester Display Test Part Control Range Diagnostic Note Control the Injection Volume Change injection volume -12.5 to 24.8% All injectors tested at the same time Perform test at less than 3000 RPM Injection volume can be changed in fine graduations within control range Control the Injection Volume for A/F Sensor Change injection volume Lower by 12.5% or increase by 25% Perform test at less than 3000 RPM Control the Injection Volume for A/F Sensor enables checking and graphing of air fuel ratio sensor and heated oxygen sensor voltage outputs When conducting the test, select the following items: Active Test / Control the Injection Volume for A/F Sensor / Data List / AFS Voltage B1S1 and O2S B1S2 Activate the VSV for EVAP Control Activate purge VSV control ON/OFF - Control the Fuel Pump / Speed Activate fuel pump (C/OPN Relay) ON/OFF Test possible when following conditions met: Ignition switch ON Engine is stopped Connect the TC and TE1 Turn on and off TC and CG (TE1) connection ON/OFF ON: TC and TE1 connected OFF: TC and TE1 disconnected Control the Idle Fuel Cut Prohibit Prohibit idling fuel cut control ON/OFF Idling fuel-cut turned ON when throttle valve fully closed and engine speed over 2500 RPM Prohibit the Catalyst OT Misfire prevent F/C Prohibit catalyst overheat malfunction prevention fuel cut operation during misfire ON/OFF ON: Fuel cut prohibited Confirm that vehicle is stopped and engine speed is 3000 RPM or less Control the Electric Cooling Fan Control electric cooling fan motor ON/OFF - Activate the Starter Relay Starter ON/OFF - Activate the ACC Cut Relay Activate ACC cut relay ON/OFF Test is possible when following conditions are met: Ignition switch ON Engine is stopped Control the ETCS Open/Close Slow Speed Throttle actuator Close/Open Test possible when following conditions met: Ignition switch ON Engine is stopped Accelerator pedal fully depressed (Accelerator pedal position: 58 degrees or more) Control the ETCS Open/Close Fast Speed Throttle actuator Close/Open Control the VVT Linear (Bank1) Control VVT (bank 1) Between -128 and 127% This value added to present camshaft timing oil control valve control duty 100%: Maximum advance -100%: Maximum retard Engine stall or rough idle when VVT actuator operated by 100%. Test possible during idle. Control the VVT System (Bank1) Turn on and off intake camshaft timing oil control valve ON/OFF Engine stalls or idles roughly when camshaft timing oil control valve turned ON Normal engine running or idling when camshaft timing oil control valve OFF Test possible during idle. Control the VVT Exhaust Linear (Bank 1) Control VVT (Bank 1) Between -128 and 127% This value added to present camshaft timing oil control valve control duty (Exhaust camshaft) 100%: Maximum retard -100%: Maximum advance - Activate the Vacuum Pump Leak detection pump ON/OFF - Activate the VSV for Vent Valve Vent valve ON/OFF - Control the Select Cylinder Fuel Cut Selected cylinder (cylinder #1 to #4) fuel cut ON/OFF Test possible while vehicle stopped and engine idling*1 Control the All Cylinder Fuel Cut All cylinder fuel cut ON/OFF Test possible while vehicle stopped and engine idling*1 Check the Cylinder Compression*2 Check the cylinder compression pressure (measuring engine speed for each cylinder) ON/OFF Fuel injection and ignition stop in all cylinders Check the Imbalance Cylinder Selected cylinder (cylinder #1 to #4) fuel injection volume change Between 50 and 200% Perform the test with the engine warmed up and idling and the shift lever in P (AT) or neutral (MT). At the time this Active Test item is entered = 100% Below 100% = Fuel injection volume is decreased Higher than 100% = Fuel injection volume is increased To conduct the test, enter the following menus: Powertrain / Engine and ECT / Active Test / Check the Imbalance Cylinder / Data List / A/F Sensor Determination (worst value) and Engine Speed Fluctuation Avg (worst value). Refer to «DTC P219A: Bank 1 Air-Fuel Ratio Imbalance»(ref-427472-S15033385442011101200000) . NOTE: *1: If the display of the Data List Catalyst OT MF F/C item is Not Avl, perform this Active Test with the vehicle stopped and the engine idling. If the display of the Data List Catalyst OT MF F/C item is Avail, perform this Active Test as described below. Stop the engine and turn the ignition switch to ON to turn Control the Cylinder #1 Fuel Cut (to #4 Fuel Cut) ON. Start the engine. HINT: *2: When cranking the engine, each cylinder measures the engine speed. In this Active Test, the fuel and ignition of all cylinders is cut. The engine must then be cranked for approximately 10 seconds. At this time, the speed of each cylinder is measured. If the speed of one cylinder is more than the other cylinders, it can be determined that the compression pressure of that cylinder is lower than the other cylinders. Warm up the engine. Turn the ignition switch off. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Active Test / Check the Cylinder Compression. HINT: To display the entire Data List, press the pull down menu button next to Primary. Then select Compression. Push the snapshot button to turn the snapshot function on. HINT: Using the snapshot function, data can be recorded during the Active Test. While the engine is not running, press the RIGHT or LEFT button to change Check the Cylinder Compression to ON. HINT: After performing the above procedure, Check the Cylinder Compression will start. Fuel injection for all cylinders is prohibited and each cylinder engine speed measurement enters standby mode. Crank the engine for about 10 seconds. HINT: Continue to crank the engine until the values change from the default value (51199 RPM). Monitor the engine speed (Engine Speed of Cyl #1 to #4) displayed on the Techstream. HINT: At first, the Techstream displays extremely high cylinder engine speed values. After approximately 10 seconds of engine cranking, each cylinder engine speed measurement will change to the actual engine speed. NOTE: Do not crank the engine continuously for 20 seconds or more. If it is necessary to crank the engine again after Check the Cylinder Compression has been changed to ON and the engine has been cranked once, press Exit to return to the Active Test menu screen. Then change Check the Cylinder Compression to ON and crank the engine. Use a fully-charged battery. Stop cranking the engine, and then change "Check the Cylinder Compression" to OFF after the engine stops. NOTE: If the Active Test is changed to OFF while the engine is being cranked, the engine will start. Push the snapshot button to turn the snapshot function off. Select "Stored Data" on the Techstream screen, select the recorded data and display the data as a graph. HINT: If the data is not displayed as a graph, the change of the values cannot be observed. Check the change in engine speed values. HINT: As the data values of the Active Test return to their default values when cranking is stopped, the engine speed value of each cylinder cannot be observed. Therefore, it is necessary to use the data recorded with the snapshot function to check the engine speed values recorded during cranking.
3. SYSTEM CHECK HINT: Performing a System Check in the Utility menu enables the system, which consists of multiple actuators, to be operated without removing any parts. In addition, it can show whether or not any DTCs are set, and can detect potential malfunctions in the system. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine and ECT / Utility. Perform the System Check by referring to the table below. Tester Display Test Part Control Range Diagnostic Note Evaporative System Check (Automatic Mode) Perform 5 steps in order to operate EVAP key-off monitor automatically 35°C (95°F) or less If no DTCs in Pending after performing this test, system functioning normally Refer to «EVAP System»(ref-427472-S06790572952011101200000) Evaporative System Check (Manual Mode) Perform 5 steps in order to operate EVAP key-off monitor manually 35°C (95°F) or less Used to detect malfunctioning parts Refer to «EVAP System»(ref-427472-S06790572952011101200000)
