Windshield/window Glass (Except Hybrid): Overview Toyota Highlander II

SYSTEM DESCRIPTION

1. POWER WINDOW CONTROL SYSTEM DESCRIPTION The power window control system controls the power window operation using the power window regulator motors. The main controls of this system are the power window regulator master switch, which is mounted on the driver side door, and the power window regulator switches, which are mounted on the passenger side door and rear doors. Operating a window switch results in electrical power being transmitted to the corresponding power window regulator motor. The power window control system has the following functions: FUNCTION OUTLINE Function Outline Manual up-and-down function Function that causes window to go up while power window switch is being pulled halfway up and to go down while pushed halfway down Window stops as soon as the switch is released Driver's door auto up-and-down function Function that enables window of driver's door to be fully opened or closed by one press of power window switch Jam protection function Function that automatically stops power window and moves it downward if a foreign object gets jammed in door window during auto-up operation (driver door). Remote control function Function that allows power window master switch to control MANUAL up-and-down operations of front passenger door window and rear door windows Key-off operation function Function that makes it possible to operate power window for approximately 45 seconds after the ignition switch is turned on (IG) or off, if either front door is not opened Diagnosis Function that allows power window switch to make a diagnosis for failed section when power window switch detects a malfunction in power window system Power window switch light comes on or blinks to inform driver Fail-safe A fail-safe function to disable a part of power window functions if pulse sensor in power window motor has a malfunction Driver's door auto up-and-down function and remote control function are disabled

DESCRIPTION

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

DTC B2311 is set when the ECU for the driver door power window regulator motor assembly malfunctions.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

HINT

1. Initialization is required only when the power window regulator motor is replaced. However, replacing the motor may cause the motor gear to be engaged in a different position. This can cause a difference to exist between the current door glass position and the position memorized in the ECU. In this case, the jam protection function may work improperly. Return the system to the pre-initialized condition and reinitialize the system.
2. To return the system to the pre-initialized condition: Disconnect the power window regulator motor connector during power window operation. This will return the motor to the pre-initialized condition.

DTC DETECTION CONDITION AND TROUBLE AREA

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

When the ECU determines that the power window master switch is stuck, DTC B2312 is set.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

DTC DETECTION CONDITION AND TROUBLE AREA TABLE

Scheme 1

Scheme 2

Scheme 3

1. CHECK DTC OUTPUT Turn the ignition switch off. Wait for at least 10 seconds, and then turn the ignition switch on (IG). Check whether the DTC output recurs. Result RESULT REFERENCE Result Proceed to B2312 A No output B B: END (DUE TO KEEPING SWITCH OPERATED FOR 20 SECONDS OR MORE) A: Go to next step.
2. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 8 (U) - 1 (E) Manual UP Below 1 ohms 5 (D) - 1 (E) Manual DOWN Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto DOWN Below 1 ohms NG: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) ) OK: Go to next step.
3. CHECK HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - WINDOW REGULATOR MOTOR) Disconnect the M1 and H1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-8 (U) - H1-10 (UP1) Always Below 1 ohms M1-3 (LED) - H1-5 (LED) Always Below 1 ohms M1-4 (A) - H1-4 (AUTO) Always Below 1 ohms M1-5 (D) - H1-7 (DWN1) Always Below 1 ohms M1-8 (U) - Body ground Always 10 kohms or higher M1-3 (LED) - Body ground Always 10 kohms or higher M1-4 (A) - Body ground Always 10 kohms or higher M1-5 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) (See «REMOVAL»(ref-290721-S08640092362008071700000) )

The portion of the power window control system that is located in the driver door consists of a power window master switch, regulator, and a motor with an integrated ECU. The driver door power window regulator motor is controlled by the ECU when the power window master switch is operated (models with jam protection).

When the ECU determines that the driver's door power window regulator motor assembly has not been initialized, DTC B2313 is set.

Note. The power window control system uses a serial communication protocol (LIN) to communicate with the main body ECU. Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly.

HINT

1. Replacing the door glass or door glass run may cause a difference to exist between the current door glass position and the position memorized in the ECU. In this case, the jam protection function may work improperly. Return the system to the pre-initialized condition and reinitialize the system.
2. To return the system to the pre-initialized condition. (See «CUSTOMIZE PARAMETERS»(ref-290721-S42902201842008071700000) )

DTC DETECTION CONDITION AND TROUBLE AREA TABLE

Refer to DTC B2321 (LIN communication system) (See DESCRIPTION ).

DTC DETECTION CONDITION AND TROUBLE AREA

With the ignition switch on (IG), the power window regulator master switch transmits remote switch signals to the regulator switch of the passenger door power window. Then, the regulator switch drives the passenger power window regulator motor.

Scheme 4

Scheme 5

Scheme 6

Scheme 7

Scheme 8

Scheme 9

1. CHECK POWER WINDOW MASTER SWITCH Turn the window lock switch OFF and operate the switches on the master switch. Check that the remote UP / DOWN function operates normally. OK: Remote UP / DOWN function operates normally. NG: Go to step 2 OK: END
2. CHECK MANUAL UP / DOWN FUNCTION Check that the passenger door power window manual UP / DOWN function operates normally. OK: Manual UP / DOWN function operates normally. NG: Go to step 3 OK: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) )
3. HARNESS AND CONNECTOR (POWER WINDOW MASTER SWITCH - BATTERY AND BODY GROUND) Disconnect the M1 connector. Measure the voltage and resistance according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-6 (B) - Body ground Ignition switch on (IG) 11 to 14 V Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-1 (E) - Body ground Always Below 1 ohms NG: REPLACE POWER WINDOW REGULATOR SWITCH ASSY OK: Go to next step.
4. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 6 (B) - 16 (U) 15 (D) - 1 (E) UP (Passenger side) Below 1 ohms 6 (B) - 15 (D) 16 (U) - 1 (E) DOWN (Passenger side) Below 1 ohms 6 (B) - 12 (U) 13 (D) - 1 (E) UP (Rear LH) Below 1 ohms 6 (B) - 13 (D) 12 (U) - 1 (E) DOWN (Rear LH) Below 1 ohms 6 (B) - 10 (U) 18 (D) - 1 (E) UP (Rear RH) Below 1 ohms 6 (B) - 18 (D) 10 (U) - 1 (E) DOWN (Rear RH) Below 1 ohms NG: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) ) OK: Go to next step.
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - FRONT PASSENGER, REAR LH/RH SWITCH) Front passenger side: Disconnect the M1 and G7 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-16 (U) - G7-5 (SU) Always Below 1 ohms M1-15 (D) - G7-2 (SD) Always Below 1 ohms M1-16 (U) - Body ground Always 10 kohms or higher M1-15 (D) - Body ground Always 10 kohms or higher for Rear LH side: Disconnect the M1 and K2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-12 (U) - K2-5 (SU) Always Below 1 ohms M1-13 (D) - K2-2 (SD) Always Below 1 ohms M1-12 (U) - Body ground Always 10 kohms or higher M1-13 (D) - Body ground Always 10 kohms or higher for Rear RH side: Disconnect the M1 and J2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-10 (U) - J2-5 (SU) Always Below 1 ohms M1-18 (D) - J2-2 (SD) Always Below 1 ohms M1-10 (U) - Body ground Always 10 kohms or higher M1-18 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW SWITCH (APPLICABLE LOCATION)

If the manual UP/DOWN and AUTO DOWN functions do not operate, a malfunction may exist in the power window master switch, power window regulator motor or wire harness.

Scheme 10

Scheme 11

Scheme 12

1. INSPECT POWER WINDOW MASTER SWITCH (DRIVER SWITCH) Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 8 (U) - 1 (E) Manual UP Below 1 ohms 5 (D) - 1 (E) Manual DOWN Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto DOWN Below 1 ohms NG: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) ) OK: Go to next step.
2. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - MOTOR (DRIVER SIDE)) Disconnect the M1 and H1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-8 (U) - H1-10 (UP1) Always Below 1 ohms M1-4 (A) - H1-4 (AUTO) Always Below 1 ohms M1-5 (D) - H1-7 (DWN1) Always Below 1 ohms M1-8 (U) - Body ground Always 10 kohms or higher M1-4 (A) - Body ground Always 10 kohms or higher M1-5 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) Remove the power window regulator motor (See «REMOVAL»(ref-290721-S08640092362008071700000) ). Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1, 2, 4, 7, 9 and 10. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION TABLE Switch Condition Measurement Condition Specified Condition Manual Operation Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 10 (UP1) Motor gear rotates clockwise Auto Operation Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 7 (DWN1) Motor gear rotates counterclockwise Battery positive (+) --> Terminal 2 (B), 9 (LIN) Battery negative (-) --> Terminal 1 (E), 4 (AUTO), 10 (UP1) Motor gear rotates clockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) (See «REMOVAL»(ref-290721-S08640092362008071700000) ) OK: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) )

If the passenger side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

1. CHECK POWER WINDOW SWITCH (FRONT PASSENGER SIDE) (POWER SOURCE) Disconnect the G7 connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition G7-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. INSPECT POWER WINDOW SWITCH (FRONT PASSENGER SIDE) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG: REPLACE POWER WINDOW SWITCH (FRONT PASSENGER SIDE) (See «REMOVAL»(ref-290721-S08359507972008071700000) ) OK: Go to next step.
3. CHECK HARNESS AND CONNECTOR (SWITCH (FRONT PASSENGER SIDE) - MOTOR (FRONT PASSENGER SIDE)) Disconnect the G7 and G1 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition G7-4 (U) - G1-2 (U) Always Below 1 ohms G7-1 (D) - G1-1 (D) Always Below 1 ohms G7-4 (U) - Body ground Always 10 kohms or higher G7-1 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE) Check power window regulator motor operation. Remove the power window regulator motor. (See «REMOVAL»(ref-290721-S08640092362008071700000) ) Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates clockwise Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor. (See «INSTALLATION»(ref-290721-S31552969182008071700000) ) Connect an electrical tester DC 400 A probe to the wire harness of terminal 2. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard: 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (passenger side). OK: The passenger side window goes down. NG: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (FRONT PASSENGER SIDE) (See «REMOVAL»(ref-290721-S08640092362008071700000) ) OK: Go to next step.
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (FRONT PASSENGER SIDE)) Disconnect the M1 and G7 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-16 (U) - G7-5 (SU) Always Below 1 ohms M1-15 (D) - G7-2 (SD) Always Below 1 ohms M1-16 (U) - Body ground Always 10 kohms or higher M1-15 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) )

If the rear LH side manual UP/DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 19

Scheme 20

Scheme 21

Scheme 22

Scheme 23

Scheme 24

1. CHECK POWER WINDOW REGULATOR SWITCH (REAR LH) (POWER SOURCE) Disconnect the K2 connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition K2-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. INSPECT POWER WINDOW SWITCH (REAR LH) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG: REPLACE POWER WINDOW SWITCH (REAR LH) (See «REMOVAL»(ref-290721-S09762701022008071700000) ) OK: Go to next step.
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR LH) - MOTOR (REAR LH)) Disconnect the K2 and K3 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition K2-4 (U) - K3-1 (U) Always Below 1 ohms K2-1 (D) - K3-2 (D) Always Below 1 ohms K2-4 (U) - Body ground Always 10 kohms or higher K2-1 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH) Check power window regulator motor operation. Remove the power window regulator motor (See «REMOVAL»(ref-290721-S08640092362008071700000) ). Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates clockwise Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor (See «INSTALLATION»(ref-290721-S31552969182008071700000) ). Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard: 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (rear LH side). OK: The rear LH side window goes down. NG: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR LH) (See «REMOVAL»(ref-290721-S08640092362008071700000) ) OK: Go to next step.
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR LH)) Disconnect the M1 and K2 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-12 (U) - K2-5 (SU) Always Below 1 ohms M1-13 (D) - K2-2 (SD) Always Below 1 ohms M1-12 (U) - Body ground Always 10 kohms or higher M1-13 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) )

If the rear RH side manual UP / DOWN function does not operate, a malfunction may exist in the power window regulator motor, power window regulator switch, power window regulator master switch or wire harness.

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

1. CHECK POWER WINDOW SWITCH (REAR RH) (POWER SOURCE) Disconnect the J2 connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition J2-3 (B) - Body ground Ignition switch on (IG) 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
2. INSPECT POWER WINDOW SWITCH (REAR RH) Measure the resistance when the switch is operated according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Switch Condition Specified Condition 1 (D) - 2 (SD) UP Below 1 ohms 3 (B) - 4 (U) Below 1 ohms 1 (D) - 2 (SD) OFF Below 1 ohms 4 (U) - 5 (SU) Below 1 ohms 4 (U) - 5 (SU) DOWN Below 1 ohms 1 (D) - 3 (B) Below 1 ohms NG: REPLACE POWER WINDOW SWITCH (REAR RH) (See «REMOVAL»(ref-290721-S09762701022008071700000) ) OK: Go to next step.
3. CHECK HARNESS AND CONNECTOR (SWITCH (REAR RH) - MOTOR (REAR RH)) Disconnect the J2 and J3 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition J2-4 (U) - J3-1 (U) Always Below 1 ohms J2-1 (D) - J3-2 (D) Always Below 1 ohms J2-4 (U) - Body ground Always 10 kohms or higher J2-1 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH) Check power window regulator motor operation. Remove the power window regulator motor (See «REMOVAL»(ref-290721-S08640092362008071700000) ). Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. OK MEASUREMENT CONDITION AND SPECIFIED CONDITION TABLE Measurement Condition Specified Condition Battery negative (-) --> Terminal 1 Battery positive (+) --> Terminal 2 Motor gear rotates clockwise Battery negative (-) --> Terminal 2 Battery positive (+) --> Terminal 1 Motor gear rotates counterclockwise Check PTC operation: NOTE: The work must be performed with the power window regulator and door glass installed on the vehicle. Install the power window regulator motor (See «INSTALLATION»(ref-290721-S31552969182008071700000) ). Connect an electrical tester DC 400 A probe to the wire harness of terminal 1. NOTE: Match the arrow mark of the probe with the direction of the current flow. Fully close the door glass by pressing the power window UP switch. Wait for approximately 60 seconds. Continue to press the power window UP switch and measure how long it takes for the electrical current to change from a range of 16 to 28 A to approximately 1 A (Inspection of current shut-off). Standard: 4 to 90 seconds 60 seconds after the previous step, press the power window DOWN switch (rear RH side). OK: The rear RH side window goes down. NG: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (REAR RH) (See «REMOVAL»(ref-290721-S08640092362008071700000) ) OK: Go to next step.
5. CHECK HARNESS AND CONNECTOR (MASTER SWITCH - SWITCH (REAR RH)) Disconnect the M1 and J2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-10 (U) - J2-5 (SU) Always Below 1 ohms M1-18 (D) - J2-2 (SD) Always Below 1 ohms M1-10 (U) - Body ground Always 10 kohms or higher M1-18 (D) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) )

When the AUTO UP/DOWN does not function, the power window control system may be in fail-safe mode. If the system has not been initialized after replacement of the driver door power window regulator motor, it also results in the same problem.

Note. The power window control system uses a multiplex communication system (LIN). Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly. When the power window regulator motor assembly (on the driver side) is reinstalled or replaced, the power window control system must be initialized. After a door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the AUTO UP function is used. In such cases, the AUTO UP function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it in the AUTO UP position. Open the power window by fully pushing down the switch.

HINT

If the pulse sensor built into the power window regulator motor assembly (on the driver side) malfunctions, the power window control system enters fail-safe mode. The remote UP/DOWN and AUTO UP/DOWN functions cannot be operated during fail-safe mode. (However, the power window can be closed by holding the power window switch at the AUTO UP position, and opened manually by pushing down the switch.)

Scheme 31

Scheme 32

1. CHECK DTC Check for DTCs. Connect Techstream to the DLC3. By following the tester screen display, check whether any DTCs are output. Result RESULT REFERENCE Result Proceed to No output A DTC output B B: PROCEED TO INSPECTION PROCEDURE RELEVANT TO OUTPUT DTC A: Go to next step.
2. READ VALUE ON TECHSTREAM (D-DOOR MOTOR) Use the Data List to check the function of the power window master switch. D-Door Motor DATA LIST - D-DOOR MOTOR Item Measurement Item / Display (Range) Normal Condition Diagnostic Note D P/W Auto Switch Driver side power window AUTO switch signal / ON or OFF ON: Driver side power window AUTO switch operates OFF: Driver side power window AUTO switch does not operate - D P/W Up Switch Driver side power window UP switch signal / ON or OFF ON: Driver side power window UP switch operates OFF: Driver side power window UP switch does not operate - D P/W Down Switch Driver side power window DOWN switch signal / ON or OFF ON: Driver side power window DOWN switch operates OFF: Driver side power window DOWN switch does not operate - OK: ON (switch operates) appears on screen. NG: Go to step 3 OK: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) (See «REMOVAL»(ref-290721-S08640092362008071700000) )
3. INSPECT POWER WINDOW MASTER SWITCH Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 8 (U) - 1 (E) - 4 (A) Auto UP Below 1 ohms 4 (A) - 5 (D) - 1 (E) Auto Down Below 1 ohms NG: REPLACE POWER WINDOW MASTER SWITCH (See «REMOVAL»(ref-290721-S38395604332008071700000) ) OK: Go to next step.
4. INSPECT FUSE (DOOR NO. 2) Remove the DOOR NO. 2 fuse from the instrument panel junction block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition DOOR NO. 2 Always Below 1 ohms NG: REPLACE FUSE (DOOR NO. 2) OK: Go to next step.
5. CHECK WIRE HARNESS (MASTER SWITCH - REGULATOR MOTOR) Disconnect the M1 and H1 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition M1-4 (A) - H1-4 (AUTO) Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) (See «REMOVAL»(ref-290721-S08640092362008071700000) )

When the driver door has not been opened and fully closed, each door power window regulator motor can control its power window operation for approximately 45 seconds after the ignition switch is turned from on (IG) to off (the key is removed) by receiving operation permission signals from the main body ECU. However, when approximately 45 seconds have elapsed, or the driver door or front passenger side door is opened within approximately 45 seconds of the ignition switch being turned off (the key is removed), the power window regulator motor stops operating.

During AUTO function operation, the window operation will continue until complete even if 45 seconds have passed or a door is opened.

Note. The power window control system uses a multiplex communication system (LIN). Inspect the communication function by following HOW TO PROCEED WITH TROUBLESHOOTING. Troubleshoot the power window control system after confirming that the communication system is functioning properly. The power window control system prohibits the AUTO UP / DOWN function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no diagnostic codes are displayed.

Scheme 33

The driver door power window regulator motor is activated by operating the power window regulator master switch. The driver door power window regulator motor has motor, regulator and ECU functions. DTC B2311 is set when the main body ECU determines that the driver door power window regulator motor malfunctions.

HINT

If the pulse sensor in the power window regulator motor assembly (on the driver side) malfunctions, the power window control system enters fail-safe mode. The remote UP / DOWN and AUTO UP / DOWN functions cannot be operated during fail-safe mode. (However, the power window can be closed by holding the power window switch at the AUTO UP position, and opened manually by pushing down the switch.)

1. GENERAL The defogger system's thin heater wires are attached to the inside of the rear window and defog the window surface quickly. The indicator light illuminates while the system is operating. The system automatically turns off after approximately 15 minutes. HINT: The rear window defogger is linked with the mirror defogger (w/ mirror defogger).
2. FUNCTION OF MAIN COMPONENT COMPONENTS OUTLINE Component Outline RR DEF Relay Receives rear defogger activation request signals from the air conditioning amplifier assembly and supplies power to the rear window defogger. Rear Window Defogger Receives power from the RR DEF relay and heats the defogger wire.
3. DESCRIPTION FUNCTION OUTLINE Function Outline Defogs the rear window surface Receives rear defogger activation request signals from the air conditioning amplifier assembly and supplies power to the rear window defogger. Receives power from the RR DEF relay and heats the defogger wire.

When the rear window defogger switch, which is built into the air conditioning control assembly, is operated, the operation signals are transmitted to the air conditioning amplifier assembly through LIN. When the air conditioning amplifier assembly receives the signals, it turns on the DEFOGGER relay (Marking: RR DEF) to operate the rear window defogger.

Scheme 34

Scheme 35

Scheme 36

Scheme 37

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

1. CHECK FUSES (RR DEF) Remove the fusible link block assembly (RR DEF) from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition A - B (RR DEF) Always Below 1 ohms NG: REPLACE FUSIBLE LINK BLOCK ASSEMBLY (RR DEF FUSE) OK: Go to next step.
2. INSPECT DEFOGGER RELAY (Marking: RR DEF) Remove the defogger relay (Marking: RR DEF) from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 4 Voltage is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Apply battery voltage between terminals 1 and 2 10 kohms or higher 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms NG: REPLACE DEFOGGER RELAY (Marking: RR DEF) OK: Go to next step.
3. PERFORM ACTIVE TEST BY TECHSTREAM Select the ACTIVE TEST, use Techstream to issue a control command, and then check the window defogger operation. Air Conditioner: ACTIVE TEST DETAIL - AIR CONDITIONER Tester Display Test Part Control Range Diagnostic Note Defogger Relay (Rear) Rear window defogger OFF/ON - Result RESULT REFERENCE Result Proceed to The window defogger system does not operate normally when operating it through Techstream. A The window defogger system operates normally when operating it through Techstream. B A: Go to step 7 B: Go to next step.
4. CHECK HARNESS AND CONNECTOR (LIN COMMUNICATION LINE) Disconnect the D37 air conditioning amplifier connector. Disconnect the E10 air conditioning control connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition D37-37 (LIN1) - E10-5 (LIN1) Always Below 1 ohms D37-37 (LIN1) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
5. REPLACE AIR CONDITIONING CONTROL ASSEMBLY for Automatic Air Conditioning System Replace the air conditioning control assembly (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) ). for Manual Air Conditioning System Replace the air conditioning control assembly (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) ).
6. CONFIRM REAR WINDOW DEFOGGER OPERATION Turn the ignition switch on (IG), press the defogger switch, and check that the window defogger operates. OK: Window defogger system operates normally NG: REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) ) OK: END
7. PERFORM ACTIVE TEST BY TECHSTREAM Select the ACTIVE TEST, use Techstream to issue a control command, and then check the window defogger operation. Air Conditioner: ACTIVE TEST DETAIL - AIR CONDITIONER Tester Display Test Part Control Range Diagnostic Note Defogger Relay (Rear) Rear window defogger OFF/ON - Check that operation sound of the DEFOGGER relay (Marking: RR DEF) is heard. Result RESULT REFERENCE TABLE Result Proceed to Relay operating sound is heard A Relay operating sound is not heard B A: Go to step 10 B: Go to next step.
8. CHECK HARNESS AND CONNECTOR (A/C AMPLIFIER ASSEMBLY - ENGINE ROOM RELAY BLOCK) Disconnect the D37 air conditioning amplifier connector. Disconnect the defogger relay (Marking: RR DEF) engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition D37-38 (RDFG) - 2 Always Below 1 ohms D37-38 (RDFG) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
9. CHECK HARNESS AND CONNECTOR (RDFG TERMINAL BATTERY VOLTAGE) Reconnect the defogger relay (Marking: RR DEF) engine room relay block. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition D37-38 (RDFG) - Body ground Ignition switch on (IG) 11 to 14 V NG: PROCEED TO NEXT CIRCUIT INSPECTION SHOWN IN PROBLEM SYMPTOMS TABLE (See «TERMINALS OF ECU»(ref-290721-S20223970602008071700000) ) OK: REPLACE AIR CONDITIONING AMPLIFIER ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) )
10. CHECK HARNESS AND CONNECTOR (REAR WINDOW DEFOGGER WIRE - ENGINE ROOM RELAY BLOCK) w/ Glass Hatch Opener Disconnect the Y2 connector. Remove the defogger relay (Marking: RR DEF) from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition Y2-1 - 2F-5 Always Below 1 ohms Y2-1 - Body ground Always 10 kohms or higher w/o Glass Hatch Opener Disconnect the T12 connector. Remove the defogger relay (Marking: RR DEF) from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition T12-1 - 2F-5 Always Below 1 ohms T12-1 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
11. CHECK HARNESS AND CONNECTOR (REAR WINDOW DEFOGGER WIRE BATTERY POSITIVE) w/ Glass Hatch Opener Reconnect the defogger relay (Marking: RR DEF) from the engine room relay block. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition Y2-1 - Body ground Ignition switch on (IG) Rear window defogger switch on 11 to 14 V w/o Glass Hatch Opener Reconnect the defogger relay (Marking: RR DEF) from the engine room relay block. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition T12-1 - Body ground Ignition switch on (IG) Rear window defogger switch on 11 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
12. CHECK HARNESS AND CONNECTOR (REAR WINDOW DEFOGGER WIRE CONNECTOR BODY GROUND) w/ Glass Hatch Opener Disconnect the Y2 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition Y2-1 - Body ground Always Below 1 ohms w/o Glass Hatch Opener Disconnect the T11 connector. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition T11-1 - Body ground Always Below 1 ohms NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPAIR OR REPLACE REAR WINDOW DEFOGGER WIRE

Scheme 45

Scheme 46

Scheme 47

Scheme 48

1. CHECK WINDSHIELD DEICER SWITCH Disconnect the windshield deicer switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition 8 (ILL+) - 7 (ILL-) Headlight dimmer switch OFF --> ON Below 1 V --> 11 to 14 V 10 (D) - 9 (E) Ignition switch on (IG) 11 to 14 V 6 (IG) - 9 (E) Ignition switch on (IG) 11 to 14 V Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 7 (ILL-) - Body ground Always Below 1 ohms 9 (E) - Body ground Always Below 1 ohms Reconnect the windshield deicer connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Condition Specified Condition 10 (D) - 9 (E) Ignition switch on (IG), windshield deicer switch OFF --> ON 11 to 14 V --> Below 1 V (after 15 + / - 3 minutes: 11 to 14 V) 6 (IG) - 9 (E) Ignition switch on (IG), windshield deicer switch OFF --> ON Below 1 V --> 11 to 14 V Check the ON/OFF indicator of the switch. Push the switch several times. Check that the ON/OFF indicator illuminates or turns off according to the switch operation. Check the illumination area of the switch. Check that the ON/OFF indicator illuminates or turns off according to the switch operation.

Scheme 49

1. INSPECT POWER WINDOW RELAY Remove the power window relay from the instrument panel junction block. Measure the resistance of the relay. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.

Scheme 50

1. INSPECT WINDSHIELD DEICER RELAY (Marking: DEICER) Measure the resistance of the relay. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.

Scheme 51

1. INSPECT DEFOGGER RELAY Remove the defogger relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 4 Voltage is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Apply battery voltage between terminals 1 and 2 10 kohms or higher 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the defogger relay.

Scheme 52

Scheme 53

Scheme 54

1. INSPECT BACK DOOR GLASS (DEFOGGER WIRE) NOTE: When cleaning the glass, wipe the glass along the wire using a soft, dry cloth. Take care not to damage the defogger wires. Do not use detergents or glass cleaners that have abrasive ingredients. When measuring voltage, wrap a piece of tin foil around the tip of the negative (-) tester probe and press the foil against the wire with your finger as shown below. Turn the ignition switch on (IG). Turn the defogger switch ON. Measure the voltage at the center of each defogger wire as shown below. Standard voltage VOLTAGE SPECIFICATION TABLE Voltage Criteria Approx. 5 V Wire is not broken Approx. 10 or 0 V Wire is broken HINT: If there is approximately 10 V, the wire may be faulty between the center of the wire and the wire end on the battery side. If there is no voltage, the wire may be faulty between the center of the wire end and the wire end on the ground side. Place the voltmeter's positive (+) lead against the defogger wire on the battery side. Place the voltmeter's negative (-) lead with the foil strip against the wire on the ground side. Slide the positive (+) lead from the battery side to the ground side. The point where the voltage drops from approximately 10 V to 0 V is where the defogger wire is broken. HINT: If the defogger wire is not broken, the voltmeter indicates 0 V at the positive (+) end of the defogger wire and gradually increases to approximately 12 V as the meter probe moves to the other end.

Scheme 55

Scheme 56

1. REPAIR DEFOGGER WIRE Clean the broken wire tips with grease, wax and silicone remover. Place masking tape along both sides of the wire. Thoroughly mix the repair agent. Dupont paste: No. 4817 or equivalent Using a fine tip brush, apply a small amount of the agent to the wire. After a few minutes, remove the masking tape. NOTE: Do not repair the defogger wire again for at least 24 hours.

Scheme 57

Scheme 58

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. REMOVE REAR CENTER SEAT ASSEMBLY
2. REMOVE REAR SEAT HEADREST ASSEMBLY (for LH Side) (See «REMOVAL»(ref-290711-S12914516422008071700000) )
3. REMOVE REAR SEAT TRACK BRACKET COVER LH (See «REMOVAL»(ref-290711-S12914516422008071700000) )
4. REMOVE REAR OUTER TRACK BRACKET COVER LH (See «REMOVAL»(ref-290711-S12914516422008071700000) )
5. REMOVE REAR INNER TRACK BRACKET COVER LH (See «REMOVAL»(ref-290711-S12914516422008071700000) )
6. REMOVE REAR SEAT LEG SIDE COVER LH (See «REMOVAL»(ref-290711-S12914516422008071700000) )
7. DISCONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY LH (w/ Remote Folding Function) (See «REMOVAL»(ref-290711-S12914516422008071700000) )
8. REMOVE REAR NO. 1 SEAT ASSEMBLY LH (See «REMOVAL»(ref-290711-S12914516422008071700000) )
9. REMOVE REAR SEAT HEADREST ASSEMBLY (for RH Side)
10. REMOVE REAR SEAT TRACK BRACKET COVER RH (See «REMOVAL»(ref-290711-S11659695882008071700000) )
11. REMOVE REAR OUTER TRACK BRACKET COVER RH (See «REMOVAL»(ref-290711-S11659695882008071700000) )
12. REMOVE REAR INNER TRACK BRACKET COVER RH (See «REMOVAL»(ref-290711-S11659695882008071700000) )
13. REMOVE REAR SEAT LEG SIDE COVER RH (See «REMOVAL»(ref-290711-S11659695882008071700000) )
14. DISCONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY RH (w/ Remote Folding Function) HINT: Use the same procedure for the RH side and the LH side.
15. REMOVE REAR NO. 1 SEAT ASSEMBLY RH (See «DISASSEMBLY»(ref-290711-S34789268692008071700000) )
16. REMOVE FRONT DOOR SCUFF PLATE LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
17. REMOVE COWL SIDE TRIM SUB-ASSEMBLY LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
18. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
19. REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
20. REMOVE REAR DOOR SCUFF PLATE LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
21. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
22. REMOVE LOWER CENTER PILLAR GARNISH LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
23. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY LH (See «REMOVAL»(ref-290708-S13103148562008071700000) )
24. REMOVE CENTER PILLAR GARNISH LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
25. REMOVE FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
26. REMOVE COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
27. REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure for the RH side and the LH side.
28. REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
29. REMOVE REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
30. REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH HINT: Use the same procedure for the RH side and the LH side.
31. REMOVE LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
32. DISCONNECT FRONT SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
33. REMOVE CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
34. REMOVE DECK BOARD ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
35. REMOVE NO. 3 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
36. REMOVE NO. 2 DECK BOARD SUB-ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
37. REMOVE TONNEAU COVER ASSEMBLY (w/ Tonneau Cover)
38. REMOVE REAR NO. 1 FLOOR BOARD (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
39. REMOVE REAR SEAT SIDE COVER LH (w/ Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
40. REMOVE DECK SIDE TRIM BOX LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
41. REMOVE REAR SEAT SIDE COVER RH (w/ Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
42. REMOVE JACK CARRIER SUPPORT
43. REMOVE JACK CARRIER CUSHION (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
44. REMOVE JACK ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
45. REMOVE JACK CARRIER ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
46. REMOVE DECK SIDE TRIM BOX RH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
47. REMOVE DECK FLOOR BOARD ASSEMBLY (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
48. REMOVE REAR MAT (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
49. REMOVE DECK FLOOR BOARD ASSEMBLY (w/ Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
50. REMOVE REAR DECK FLOOR BOX (w/o Rear No. 2 Seat) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
51. REMOVE REAR NO. 2 SEAT INNER BELT ASSEMBLY (w/ Rear No. 2 Seat) (See «REMOVAL»(ref-290708-S31850938332008071700000) )
52. DISCONNECT REAR SEAT LAP TYPE BELT ASSEMBLY LH (w/ Rear No. 2 Seat) (See «REMOVAL»(ref-290708-S31492748012008071700000) )
53. DISCONNECT REAR SEAT LAP TYPE BELT ASSEMBLY RH (w/ Rear No. 2 Seat) (See «REMOVAL»(ref-290708-S31492748012008071700000) )
54. REMOVE REAR NO. 2 SEAT ASSEMBLY (w/ Rear No. 2 Seat) (See «REMOVAL»(ref-290711-S12654544142008071700000) )
55. REMOVE REAR FLOOR FINISH PLATE (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
56. REMOVE DECK SIDE TRIM COVER LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
57. REMOVE DECK SIDE TRIM LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
58. REMOVE SIDE TRIM COVER LH (w/o Rear Seat Entertainment System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
59. REMOVE POWER OUTLET SOCKET BEZEL (w/ Rear Seat Entertainment System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
60. REMOVE REAR COMBINATION LIGHT SERVICE COVER LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
61. REMOVE REAR POWER POINT SOCKET ASSEMBLY (See «REMOVAL»(ref-290713-S01915385702008071700000) )
62. REMOVE REAR POWER OUTLET SOCKET COVER (See «REMOVAL»(ref-290713-S01915385702008071700000) )
63. REMOVE REAR DECK TRIM COVER (w/o Remote Folding Function) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
64. REMOVE RECLINING REMOTE CONTROL LEVER BEZEL LH (w/ Remote Folding Function) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
65. REMOVE ROPE HOOK ASSEMBLY (for LH Side) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
66. REMOVE NO. 2 DECK SIDE TRIM HOOK (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
67. REMOVE FRONT DECK SIDE TRIM COVER LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
68. DISCONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY LH (See «REMOVAL»(ref-290708-S31656062712008071700000) )
69. REMOVE DECK TRIM SIDE PANEL ASSEMBLY LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
70. REMOVE QUARTER PILLAR GARNISH LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
71. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY LH (w/o Power Back Door) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
72. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY LH (w/ Power Back Door) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
73. REMOVE REAR SEAT SIDE GARNISH CAP (w/o Rear Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
74. REMOVE REAR SEAT SIDE GARNISH CAP (w/ Rear Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
75. REMOVE DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
76. REMOVE DECK SIDE TRIM RH HINT: Use the same procedure for the RH side and the LH side.
77. REMOVE SIDE TRIM COVER RH (w/o Rear Automatic Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
78. REMOVE REAR ROOM TEMPERATURE SENSOR (w/ Rear Automatic Air Conditioning System) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) )
79. REMOVE REAR COMBINATION LIGHT SERVICE COVER RH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
80. REMOVE ROPE HOOK ASSEMBLY (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
81. REMOVE NO. 1 LUGGAGE COMPARTMENT TRIM HOOK HINT: Use the same procedure for the No. 1 luggage compartment trim hook and the No. 2 deck side trim hook.
82. REMOVE FRONT DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
83. DISCONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
84. REMOVE DECK TRIM SIDE PANEL ASSEMBLY RH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
85. REMOVE QUARTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
86. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY RH (w/o Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
87. REMOVE ROOF SIDE INNER GARNISH ASSEMBLY RH (w/ Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
88. REMOVE ROOF CONSOLE BOX ASSEMBLY (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
89. REMOVE VISOR BRACKET COVER (for LH Side) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
90. REMOVE VISOR ASSEMBLY LH (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
91. REMOVE VISOR BRACKET COVER (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
92. REMOVE VISOR ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
93. REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ EC Mirror) (See «REMOVAL»(ref-290719-S24623994212008071700000) )
94. REMOVE NO. 1 ROOM LIGHT ASSEMBLY (for Standard) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
95. REMOVE NO. 1 ROOM LIGHT ASSEMBLY (for Independent Type) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
96. REMOVE NO. 2 ROOM LIGHT ASSEMBLY
97. REMOVE TELEVISION BASE (w/ Rear Seat Entertainment System) (See «REMOVAL»(ref-290716-S36350522292008071700000) )
98. REMOVE TELEVISION DISPLAY ASSEMBLY (w/ Rear Seat Entertainment System) (See «REMOVAL»(ref-290716-S36350522292008071700000) )
99. REMOVE FRONT ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
100. REMOVE REAR ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
101. REMOVE ASSIST GRIP ASSEMBLY (w/ Sliding Roof) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
102. REMOVE ROOF HEADLINING TRIM CLIP STOPPER (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
103. REMOVE SUN ROOF OPENING TRIM MOLDING (w/ Sliding Roof)
104. REMOVE VISOR HOLDER (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
105. REMOVE ROOF HEADLINING ASSEMBLY (w/o Sliding Roof) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
106. REMOVE ROOF HEADLINING ASSEMBLY (w/ Sliding Roof) (See «REMOVAL»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid) )
107. REMOVE QUARTER WINDOW ASSEMBLY Apply protective tape to the outer surface of the vehicle body to prevent scratches. From the interior, insert a piano wire between the vehicle body and glass as shown below. Tie objects that can serve as handles (for example, wooden blocks) to both wire ends. NOTE: When separating the quarter window assembly from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. Cut through the adhesive by pulling the piano wire around the quarter window assembly. NOTE: Leave as much adhesive on the vehicle body as possible when cutting through the adhesive. Disengage the 3 clips. NOTE: Please be careful not to break it because there is not the supplying of a clip. Disengage the retainer. NOTE: Please be careful not to break it because there is not the supplying of a retainer. Using suction cups, remove the glass. NOTE: Be careful not to drop the glass.
108. CLEAN QUARTER WINDOW ASSEMBLY Clean the outer edges of the glass with a non-residue solvent. NOTE: Do not touch the glass surface after cleaning it. Be careful not to damage the glass, retainer, and spacers. Ever if using a new glass, clean the glass with a non-residue solvent.
109. CLEAN VEHICLE BODY Clean and shape the contact surfaces of the vehicle body. On the contact surfaces of the vehicle body, use a knife to cut away excess adhesive as shown below. HINT: Leave as much adhesive on the vehicle body as possible. NOTE: Be careful not to damage the vehicle body. Clean the contact surfaces of the vehicle body with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.

Scheme 76

Scheme 77

Scheme 78

Scheme 79

1. INSTALL QUARTER WINDOW ASSEMBLY Using a brush or sponge, apply Primer M to the exposed part of the vehicle body. Standard measurement PRIMER APPLYING AREA DIMENSION SPECIFICATION Area Specified Condition a 20.0 mm (0.787 in.) b 15.0 mm (0.590 in.) NOTE: Apply Primer M in front of the bead as shown below. Allow the primer to dry for 3 minutes or more. Throw away any leftover Primer M. Do not apply too much primer. Using a brush or sponge, apply Primer G to the contact surface of the glass. Standard measurement PRIMER APPLYING AREA DIMENSION SPECIFICATION Area Specified Condition a 4.0 mm (0.157 in.) b 12.0 mm (0.472 in.) c 5.5 mm (0.216 in.) d 10.3 mm (0.405 in.) e 9.5 mm (0.374 in.) f 6.0 mm (0.236 in.) HINT: If the primer is applied to an area that is specified, wipe off the primer with a non-residue solvent before it dries. NOTE: To prevent the glass from breaking at low temperatures, ensure that no primer adheres to the contact surface between the molding and glass during application. Allow the primer to dry for 3 minutes or more. Throw away any leftover Primer G. Do not apply too much primer. Apply adhesive to the quarter window assembly. Adhesive: Toyota Genuine Windshield Glass Adhesive or equivalent Cut off the tip of the cartridge nozzle as shown below. Standard measurement ADHESIVE APPLYING AREA DIMENSION SPECIFICATION Area Specified Condition a 6.0 mm (0.236 in.) b 8.0 mm (0.315 in.) c 12.0 mm (0.472 in.) d 5.5 mm (0.216 in.) e 9.5 mm (0.374 in.) HINT: After cutting off the tip, use all the adhesive within the time written in the table below. Usage time frame TEMPERATURE AND TIME SPECIFICATION TABLE Temperature Usage Time Frame 35°C (95°F) 15 minutes 20°C (68°F) 1 hour and 40 minutes 5°C (41°F) 8 hours Load the sealer gun with the cartridge. Apply adhesive to the quarter window glass. Install the quarter window glass to the vehicle body. Hold the quarter window assembly in place securely with protective tape or equivalent until the adhesive hardens. NOTE: Allow the primer to dry for 3 minutes or more. Check that the clips are attached to the body correctly. Check the clearance between the body and glass. Lightly press the outer surface of the glass to ensure a close fit. Using a scraper, remove any excess or protruding adhesive. HINT: Apply adhesive onto the glass rim. NOTE: Do not drive the vehicle within the time written in the table below. Minimum time TEMPERATURE SPECIFICATION TABLE Temperature Minimum time prior to driving vehicle 35°C (95°F) 1 hour and 30 minutes 20°C (68°F) 5 hours 5°C (41°F) 24 hours
2. INSPECT FOR LEAK AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
3. INSTALL ROOF HEADLINING ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
4. INSTALL ROOF HEADLINING ASSEMBLY (w/ Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
5. INSTALL VISOR HOLDER (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
6. INSTALL SUN ROOF OPENING TRIM MOLDING (w/ Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
7. INSTALL ROOF HEADLINING TRIM CLIP STOPPER (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
8. INSTALL ASSIST GRIP ASSEMBLY (w/ Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
9. INSTALL REAR ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
10. INSTALL FRONT ASSIST GRIP SUB-ASSEMBLY (w/o Sliding Roof) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
11. INSTALL TELEVISION DISPLAY ASSEMBLY (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-290716-S05666858072008071700000) )
12. INSTALL TELEVISION BASE (w/ Rear Seat Entertainment System) (See «INSTALLATION»(ref-290716-S05666858072008071700000) )
13. INSTALL NO. 2 ROOM LIGHT ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
14. INSTALL NO. 1 ROOM LIGHT ASSEMBLY (for Standard) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
15. INSTALL NO. 1 ROOM LIGHT ASSEMBLY (for Independent Type) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
16. INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER (w/ EC Mirror) (See «INSTALLATION»(ref-290719-S25471414662008071700000) )
17. INSTALL VISOR ASSEMBLY LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
18. INSTALL VISOR BRACKET COVER (for LH Side) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
19. INSTALL VISOR ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
20. INSTALL VISOR BRACKET COVER (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
21. INSTALL ROOF CONSOLE BOX ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
22. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH (w/o Power Back Door) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
23. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY LH (w/ Power Back Door) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
24. INSTALL QUARTER PILLAR GARNISH LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
25. INSTALL DECK TRIM SIDE PANEL ASSEMBLY LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
26. CONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-290708-S28585609242008071700000) )
27. INSTALL FRONT DECK SIDE TRIM COVER LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
28. INSTALL NO. 2 DECK SIDE TRIM HOOK (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
29. INSTALL ROPE HOOK ASSEMBLY (for LH Side) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
30. INSTALL REAR DECK TRIM COVER (w/o Remote Folding Function) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
31. INSTALL RECLINING REMOTE CONTROL LEVER BEZEL LH (w/ Remote Folding Function) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
32. INSTALL REAR POWER OUTLET SOCKET COVER (See «INSTALLATION»(ref-290713-S03656380682008071700000) )
33. INSTALL REAR POWER POINT SOCKET ASSEMBLY (See «INSTALLATION»(ref-290713-S03656380682008071700000) )
34. INSTALL REAR COMBINATION LIGHT SERVICE COVER LH (See «INSTALLATION»(ref-290713-S03656380682008071700000) )
35. INSTALL SIDE TRIM COVER LH (w/o Rear Seat Entertainment System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
36. INSTALL POWER OUTLET SOCKET BEZEL (w/ Rear Seat Entertainment System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
37. INSTALL DECK SIDE TRIM LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
38. INSTALL DECK SIDE TRIM COVER LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
39. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH (w/o Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
40. INSTALL ROOF SIDE INNER GARNISH ASSEMBLY RH (w/ Rear No. 2 Seat) HINT: Use the same procedure for the RH side and the LH side.
41. INSTALL QUARTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
42. INSTALL DECK TRIM SIDE PANEL ASSEMBLY RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
43. CONNECT REAR NO. 1 SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
44. INSTALL FRONT DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
45. INSTALL NO. 1 LUGGAGE COMPARTMENT TRIM HOOK HINT: Use the same procedure for the No. 1 luggage compartment trim hook and the No. 2 deck side trim hook.
46. INSTALL ROPE HOOK ASSEMBLY (for RH Side) HINT: Use the same procedure for the RH side and the LH side.
47. INSTALL REAR COMBINATION LIGHT SERVICE COVER RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
48. INSTALL REAR ROOM TEMPERATURE SENSOR (w/ Rear Automatic Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/automatic-hvac-system/#air-conditioning-except-hybrid) )
49. INSTALL SIDE TRIM COVER RH (w/o Rear Automatic Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
50. INSTALL DECK SIDE TRIM RH HINT: Use the same procedure for the RH side and the LH side.
51. INSTALL DECK SIDE TRIM COVER RH HINT: Use the same procedure for the RH side and the LH side.
52. INSTALL REAR SEAT SIDE GARNISH CAP (w/o Rear Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
53. INSTALL REAR SEAT SIDE GARNISH CAP (w/ Rear Air Conditioning System) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
54. INSTALL REAR FLOOR FINISH PLATE (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
55. INSTALL REAR NO. 2 SEAT ASSEMBLY (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290711-S33905894112008071700000) )
56. CONNECT REAR SEAT LAP TYPE BELT ASSEMBLY LH (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S31525434142008071700000) )
57. CONNECT REAR SEAT LAP TYPE BELT ASSEMBLY RH (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S31525434142008071700000) )
58. INSTALL REAR NO. 2 SEAT INNER BELT ASSEMBLY (w/ Rear No. 2 Seat) (See «INSTALLATION»(ref-290708-S05631940072008071700000) )
59. INSTALL DECK FLOOR BOARD ASSEMBLY (w/o Rear No. 2 Seat) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
60. INSTALL REAR MAT (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
61. INSTALL DECK FLOOR BOARD ASSEMBLY (w/ Rear No. 2 Seat) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
62. INSTALL DECK SIDE TRIM BOX LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
63. INSTALL REAR SEAT SIDE COVER LH (w/ Rear No. 2 Seat) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
64. INSTALL DECK SIDE TRIM BOX RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
65. INSTALL JACK CARRIER ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
66. INSTALL JACK ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
67. INSTALL JACK CARRIER CUSHION (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
68. INSTALL JACK CARRIER SUPPORT
69. INSTALL REAR SEAT SIDE COVER RH (w/ Rear No. 2 Seat) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
70. INSTALL REAR NO. 1 FLOOR BOARD (w/o Rear No. 2 Seat) (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
71. INSTALL TONNEAU COVER ASSEMBLY (w/ Tonneau Cover)
72. INSTALL NO. 2 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
73. INSTALL NO. 3 DECK BOARD SUB-ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
74. INSTALL DECK BOARD ASSEMBLY (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
75. INSTALL CENTER PILLAR GARNISH LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
76. CONNECT FRONT SEAT OUTER BELT ASSEMBLY LH (See «INSTALLATION»(ref-290708-S04899816822008071700000) )
77. INSTALL LOWER CENTER PILLAR GARNISH LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
78. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
79. INSTALL REAR DOOR SCUFF PLATE LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
80. INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
81. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
82. INSTALL COWL SIDE TRIM SUB-ASSEMBLY LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
83. INSTALL FRONT DOOR SCUFF PLATE LH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
84. INSTALL CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
85. CONNECT FRONT SEAT OUTER BELT ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
86. INSTALL LOWER CENTER PILLAR GARNISH RH HINT: Use the same procedure for the RH side and the LH side.
87. INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
88. INSTALL REAR DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
89. INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
90. INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH (See «INSTALLATION»(/toyota/highlander/ii-2007-2010/remont/exteriorinterior-trim/#interior-except-hybrid__installation) )
91. INSTALL COWL SIDE TRIM SUB-ASSEMBLY RH HINT: Use the same procedure for the RH side and the LH side.
92. INSTALL FRONT DOOR SCUFF PLATE RH HINT: Use the same procedure for the RH side and the LH side.
93. INSTALL REAR NO. 1 SEAT ASSEMBLY LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
94. CONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY LH (w/ Remote Folding Function) (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
95. INSPECT REAR SEAT SLIDE ADJUSTER LOCK (for LH Side) (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
96. INSTALL REAR SEAT LEG SIDE COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
97. INSTALL REAR INNER TRACK BRACKET COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
98. INSTALL REAR OUTER TRACK BRACKET COVER LH (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
99. INSTALL REAR SEAT TRACK BRACKET COVER (See «INSTALLATION»(ref-290711-S35153560122008071700000) )
100. INSTALL REAR SEAT HEADREST ASSEMBLY (for LH Side)
101. INSTALL REAR CENTER SEAT ASSEMBLY
102. INSTALL REAR NO. 1 SEAT ASSEMBLY RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
103. CONNECT REAR NO. 1 SEAT LOCK CABLE ASSEMBLY RH (w/ Remote Folding Function) HINT: Use the same procedure for the RH side and the LH side.
104. INSPECT REAR SEAT SLIDE ADJUSTER LOCK (for RH Side) (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
105. INSTALL REAR SEAT LEG SIDE COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
106. INSTALL REAR INNER TRACK BRACKET COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
107. INSTALL REAR OUTER TRACK BRACKET COVER RH (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
108. INSTALL REAR SEAT TRACK BRACKET COVER (See «INSTALLATION»(ref-290711-S19126382862008071700000) )
109. INSTALL REAR SEAT HEADREST ASSEMBLY (for RH Side)

The glass hatch opener system enables the back door glass to be opened when the glass hatch opener switch is pressed.

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

Scheme 86

Scheme 87

Scheme 88

Scheme 89

1. SYSTEM CHECK Confirm that the vehicle is equipped with the smart key system. Result: RESULT REFERENCE Result Proceed to w/ Smart Key System A w/o Smart Key System B B: Go to step 3 A: Go to next step.
2. CHECK SMART KEY SYSTEM When the back door entry lock switch is operated, check that the back door locks. OK: Back door entry lock function operates normally. NG: Go to OK: Go to next step.
3. PERFORM ACTIVE TEST BY TECHSTREAM Connect Techstream to the DLC3. Turn the ignition switch on (IG) and Turn on Techstream. Select the item below in the ACTIVE TEST and then check that the relay operates. Main Body (Main Body ECU): ACTIVE TEST DETAIL - MAIN BODY (MAIN BODY ECU) Tester Display Test Part Control Range Diagnostic Note Glass Hatch Open Operate Glass Hatch ON or OFF - OK: Glass hatch operates. NG: Go to step 6 OK: Go to next step.
4. READ VALUE ON TECHSTREAM (GLASS HATCH COURTESY SWITCH) Connect Techstream to the DLC3. Turn the ignition switch on (IG) and Turn on Techstream. Select the items below in the DATA LIST, and read the displays on Techstream. Main Body (Main Body ECU): DATA LIST - MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note Glass Hatch Courtesy Switch Glass hatch courtesy switch signal/ON or OFF ON: Glass hatch is open OFF: Glass hatch is closed - OK: Normal conditions listed above are displayed. NG: Go to step 6 OK: Go to next step.
5. READ VALUE ON TECHSTREAM (GLASS HATCH OPENER SWITCH) Connect Techstream to the DLC3. Turn the ignition switch on (IG) and Turn on Techstream. Select the items below in the DATA LIST, and read the displays on Techstream. Main Body (Main Body ECU): DATA LIST - MAIN BODY (MAIN BODY ECU) Tester Display Measurement Item/Range Normal Condition Diagnostic Note Glass Hatch Opener Switch Glass hatch opener switch signal / ON or OFF ON: Glass hatch opener switch Operates OFF: Glass hatch opener switch does not Operate - OK: Normal conditions listed above are displayed. NG: Go to step 7 OK: REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)
6. INSPECT BACK WINDOW LOCK ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 1 - 2 Voltage is not applied between terminals 3 and 4 10 kohms or higher 1 - 2 Apply battery voltage between terminals 3 and 4 Below 1 ohms If the result is not as specified, replace the back window lock assembly NG: REPLACE BACK WINDOW LOCK ASSEMBLY (See «REMOVAL»(ref-290721-S33456043742008071700000) ) OK: Go to next step.
7. INSPECT GLASS HATCH OPENER SWITCH ASSEMBLY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 1 - 2 Switch free 10 kohms or higher 1 - 2 Switch pushed Below 1 ohms If the result is not as specified, replace the glass hatch opener switch assembly. NG: REPLACE GLASS HATCH OPENER SWITCH ASSEMBLY (See «REMOVAL»(ref-290721-S07703465092008071700000) ) OK: Go to next step.
8. CHECK NO. 2 GLASS HATCH JUNCTION RELAY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 4 Voltage is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Apply battery voltage between terminals 1 and 2 10 kohms or higher 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the No. 2 glass hatch junction relay NG: REPLACE NO. 2 GLASS HATCH JUNCTION RELAY OK: Go to next step.
9. CHECK NO. 1 GLASS HATCH JUNCTION RELAY Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition 3 - 4 Voltage is not applied between terminals 1 and 2 Below 1 ohms 3 - 4 Apply battery voltage between terminals 1 and 2 10 kohms or higher 3 - 5 Voltage is not applied between terminals 1 and 2 10 kohms or higher 3 - 5 Apply battery voltage between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the No. 1 glass hatch junction relay NG: REPLACE NO. 1 GLASS HATCH JUNCTION RELAY OK: Go to next step.
10. CHECK HARNESS AND CONNECTOR (MAIN BODY ECU - Glass Hatch Opener Switch) Disconnect the D10 and T13 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition D10-8 (GHSW) - T13-2 (OPSW) Always Below 1 ohms D10-8 (GHSW) or T13-2 (OPSW) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
11. CHECK HARNESS AND CONNECTOR (MAIN BODY ECU - NO. 2 JUNCTION RELAY) Disconnect the D7 and O34 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition D7-15 (GRY1) - O34-1 Always Below 1 ohms O7-15 (GRY1) or O34-1 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
12. CHECK HARNESS AND CONNECTOR (NO.2 JUNCTION RELAY - NO. 1 JUNCTION RELAY) Disconnect the O34 and O33 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition O34-3 - O33-2 Always Below 1 ohms O34-3 or O33-2 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
13. CHECK HARNESS AND CONNECTOR (NO. 1 JUNCTION RELAY - MAIN BODY ECU) Disconnect the O33 and D7 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition O33-1 - D7-26 (GRY2) Always Below 1 ohms O33-1 or D7-26 (GRY2) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
14. CHECK HARNESS AND CONNECTOR (NO. 1 JUNCTION RELAY - BACK WINDOW LOCK ASSEMBLY)) Disconnect the O33 and T5 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition O33-3 - T5-3 Always Below 1 ohms O33-3 or T5-3 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step.
15. CHECK HARNESS AND CONNECTOR (MAIN BODY ECU - BACK WINDOW LOCK ASSEMBLY)) Disconnect the D8 and T5 connectors. Measure the resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Condition Specified Condition D8-20 (GCTY) - T5-2 Always Below 1 ohms D8-20 (GCTY) or T5-2 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK: REPLACE MAIN BODY ECU (INSTRUMENT PANEL JUNCTION BLOCK)

Scheme 90

Scheme 91

Scheme 92

Scheme 93

1. PRECAUTION (See «REMOVAL»(ref-290684-S37356623692008071700000) )
2. REMOVE BACK WINDOW UPPER TRIM PANEL ASSEMBLY (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
3. REMOVE BACK DOOR TRIM COVER LH (w/o Power Back Door) (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
4. REMOVE BACK DOOR SERVICE HOLE COVER LH (w/ Power Back Door) (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
5. DISCONNECT POWER BACK DOOR ROD (w/ Power Back Door) (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
6. REMOVE BACK DOOR TRIM COVER LH (w/ Power Back Door) (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
7. REMOVE BACK DOOR TRIM COVER RH (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
8. REMOVE BACK DOOR LOCK COVER (for Glass Hatch Type) (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
9. REMOVE ASSIST STRAP HOLE COVER (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
10. REMOVE ASSIST STRAP ASSEMBLY (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
11. REMOVE BACK DOOR TRIM PANEL ASSEMBLY (See «DISASSEMBLY»(ref-290704-S36064020132008071700000) )
12. REMOVE REAR WIPER SHAFT COVER (See «REMOVAL»(ref-290684-S37356623692008071700000) )
13. REMOVE REAR WIPER ARM HEAD CAP (See «REMOVAL»(ref-290684-S37356623692008071700000) )
14. REMOVE REAR WIPER ARM AND BLADE ASSEMBLY (See «REMOVAL»(ref-290684-S37356623692008071700000) )
15. REMOVE REAR WIPER LINK CAP (See «REMOVAL»(ref-290684-S37356623692008071700000) )
16. REMOVE REAR WIPER LINK PIVOT (See «REMOVAL»(ref-290684-S37356623692008071700000) )
17. REMOVE REAR WIPER MOTOR ASSEMBLY (See «REMOVAL»(ref-290684-S37356623692008071700000) )
18. REMOVE BACK WINDOW LOCK ASSEMBLY Disconnect the connector. Disengage the clamp. Remove the 3 bolts. Disengage the clip and remove the back window lock assembly.

See also:
• PRECAUTION
• REMOVAL
• INSTALLATION
• IG POWER SOURCE CIRCUIT
