Windshield/window Glass (Except Hybrid): Other Toyota Highlander II

PRECAUTION

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. EXPRESSIONS OF IGNITION SWITCH Switch Type Ignition Switch (Position) Engine Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch on (IG) ON On (IG) Ignition switch on (ACC) ACC On (ACC) Engine start START Start

Scheme 154

Scheme 155

CUSTOMIZE PARAMETERS

1. CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Be sure to make a note of the current settings before customizing. When troubleshooting a function, first make sure that the function is set to the default setting. Connect Techstream to the DLC3. Turn the engine switch on (IG). Turn the tester on. Enter the following menus: Customize Setting / Power Window Select the setting by referring to the table below. Power Window (Main Body ECU): CUSTOMIZE PARAMETERS TABLE Tester Display Default Contents Setting Door Key PAW Up ON Function that raises all power windows when, with engine switch off, key is used to hold driver door key cylinder to lock position for more than 2.3 seconds ON/OFF Door Key PA/V Down ON Function that lowers all power windows when, with engine switch off, key is used to hold driver door key cylinder to unlock position for more than 2.3 seconds ON/OFF P/W Down W/ Transmit ON Function that lowers all power windows when, with engine switch off, unlock switch on transmitter is pressed and held for more than 3.0 seconds ON/OFF

Scheme 156

Scheme 157

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ON DRIVER SIDE)) NOTE: DTC B2313 will be set if the driver side power window regulator motor assembly is replaced with a new assembly. Clear the DTC after initializing the power window motor. Initialization should be made when the vehicle is stationary. Be sure to initialize the door glass position memory (pulse sensor) after replacing the driver side power window regulator motor assembly. Without the initialization, the driver door auto up-and-down function, jam protection function and key-off operation will not work. Be sure not to tap or give any shock or force to the door glasses during the initialization procedure as the vehicle is learning the door glasses' sliding resistance during initialization. After replacing the driver side power window regulator, door glass, or glass adhesive dams, be sure to initialize the door glass position memory (pulse sensor). Otherwise, the jam protection function may work when unnecessary. If the initialization procedure cannot be completed normally, there may be a malfunction in the Local Interconnect Network (LIN) communication. Check the body multiplex (LIN, Local Interconnect Network) communication system. Inspection procedure HINT: *1: Even if the door glass has been fully opened before procedure No. 3, it is necessary to press the power window switch down for at least 1 second. *2: As soon as the switch is pulled completely up (Automatic Closing), the master switch indicator starts to blink. *3: If the master switch indicator does not come on after procedure No. 4, restart from procedure No. 3. *4: Allow the automatic operation to continue without stopping until the door glass is fully closed. Check the body multiplex (LIN, Local Interconnect Network) system (See «SYSTEM DESCRIPTION»(ref-290710-S21375411672008071700000) ).
2. TO RETURN THE SYSTEM TO THE PRE-INITIALIZED CONDITION NOTE: After replacing or reinstalling the driver side power window regulator, door glass, or door glass adhesive dams, be sure to initialize the door glass position memory (pulse sensor). Otherwise, the jam protection function may work when unnecessary. Procedure HINT: *1: Even if the door glass has been fully closed before procedure No. 3, it is necessary to pull the power window switch up for at least 6 seconds while the door glass is fully closed. *2: After completing procedure No. 4, return the door glass switch to its neutral position, then perform automatic opening operation. *3: After completing the whole initialization process, make sure that the door glass fully closes with the automatic closing operation. If the initialization procedure cannot be completed normally, there may be a malfunction in the Local Interconnect Network (LIN) communication. Check the body multiplex (LIN, Local Interconnect Network) communication system (See «SYSTEM DESCRIPTION»(ref-290710-S21375411672008071700000) ).

POWER WINDOW CONTROL SYSTEM

PROBLEM SYMPTOMS TABLE

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. CHECK POWER WINDOW ECU (DRIVER SIDE) Disconnect the H1 switch connector. Measure the voltage and resistance according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition H1-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition H1-2 (B) - Body ground SB - Body ground Power Supply Always 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness.
2. CHECK POWER WINDOW MASTER SWITCH Disconnect the M1 switch connector. Measure the voltage and resistance of each terminal according to the value(s) in the table below. Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition M1-1 (E) - Body ground W-B - Body ground Ground Always Below 1 ohms Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition M1-6 (B) - M1-1 (E) B - W-B Power supply Ignition switch on (IG) 11 to 14 V Ignition switch off Below 1 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the M1 switch connectors. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition M1-16 (U) - M1-1 (E) W - W-B Power window motor UP output Ignition switch on (IG), front passenger side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V M1-15 (D) - M1-1 (E) SB - W-B Power window motor DOWN output Ignition switch on (IG), front passenger side power window switch OFF Below 1 V Power window switch DOWN (Manual operation) 11 to 14 V M1-12 (U) - M1-1 (E) L - W-B Power window motor UP output Ignition switch on (IG), rear LH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V M1-13 (D) - M1-1 (E) O - W-B Power window motor DOWN output Ignition switch on (IG), rear LH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V M1-10 (U) - M1-1 (E) Y - W-B Power window motor UP output Ignition switch on (IG), rear RH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V M1-18 (D) - M1-1 (E) LG - W-B Power window motor DOWN output Ignition switch on (IG), rear RH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V If the result is not as specified, there may be a malfunction in the wire harness.
3. CHECK POWER WINDOW SWITCH (FRONT PASSENGER) Disconnect the G7 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition G7-3 (B) - Body ground O - Body ground Power supply Ignition switch on (IG) 11 to 14 V Ignition switch off Below 1 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the G7 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition G7-4 (U) - Body ground G - Body ground Power window motor UP output Ignition switch on (IG), front passenger side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V G7-1 (D) - Body ground Y - Body ground Power window motor DOWN output Ignition switch on (IG), front passenger side power window switch OFF Below 1 V Power window switch DOWN (Manual operation) 11 to 14 V If the result is not as specified, the power window switch may have a malfunction.
4. CHECK POWER WINDOW SWITCH (REAR LH) Disconnect the K2 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition K2-3 (B) - Body ground G - Body ground Power supply Ignition switch on (IG) 11 to 14 V Ignition switch off Below 1 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the K2 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition K2-4 (U) - Body ground V - Body ground Power window motor UP output Ignition switch on (IG), rear LH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V K2-1 (D) - Body ground SB - Body ground Power window motor DOWN output Ignition switch on (IG), rear LH side power window switch OFF Below 1 V Power window switch DOWN (Manual operation) 11 to 14 V If the result is not as specified, the power window switch may have a malfunction.
5. CHECK POWER WINDOW SWITCH (REAR RH) Disconnect the J2 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition J2-3 (B) - Body ground SB - Body ground Power supply Ignition switch on (IG) 11 to 14 V Ignition switch off Below 1 V If the result is not as specified, there may be a malfunction in the wire harness. Reconnect the J2 switch connector. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition J2-4 (U) - Body ground V - Body ground Power window motor UP output Ignition switch on (IG), rear RH side power window switch OFF Below 1 V Power window switch UP (Manual operation) 11 to 14 V J2-1 (D) - Body ground R - Body ground Power window motor DOWN output Ignition switch on (IG), rear RH side power window switch OFF Below 1 V Power window switch DOWN (Manual operation) 11 to 14 V If the result is not as specified, the power window switch may have a malfunction.

Scheme 162

Scheme 163

1. DESCRIPTION The power window control system data can be read from the Data Link Connector 3 (DLC3) of the vehicle. When the system seems to be malfunctioning, use Techstream to check for malfunctions and perform repairs.
2. CHECK DLC3 Check the DLC3 (See «HOW TO TROUBLESHOOT ECU CONTROLLED SYSTEMS»(ref-290683-S36107070032008071700000) ).
3. INSPECT BATTERY VOLTAGE Measure the battery voltage. Standard voltage: 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step.
4. CHECK DIAGNOSIS HINT: If there is a malfunction in the pulse sensor, manually operating the power window switch will cause the power window switch light to blink. Turn the ignition switch on (IG). Manually operate the power window master switch or power window switch on each door. Check the blinking pattern of the AUTO light as shown below. If pattern (A) is displayed, check the wire harness or power window ECU. If pattern (B) is displayed, check the power window regulator motor or power window ECU. If the normal pattern is displayed, replace the power window regulator master switch.

FAIL-SAFE

1. POWER WINDOW OPERATION IN FAIL-SAFE MODE HINT: If the pulse sensor built into the power window regulator motor (on the driver side) malfunctions, the power window control system enters fail-safe mode. FAIL-SAFE TABLE Fail mode Fail Detection Condition Pulse direction error With the door glass going up or down, the pulse that indicates door glass operation in the opposite direction is detected for 4 seconds Pulse stop error With the door glass going up or down, no pulse is detected for 3.5 to 4.5 seconds The power window control system prohibits the following power window operation when the pulse sensor for the jam protection function has problems and the window position or the learned value is abnormal. Power window control system POWER WINDOW CONTROL SYSTEM OPERATION REFERENCE Power window operation Ignition switch on (IG) Key-off (Within approx. 45 seconds after ignition switch turned off) Key-off (After approx. 45 seconds elapsed after ignition switch turned off) Manual UP Operation prohibited Operation prohibited Operation prohibited Manual DOWN Operative (Jam protection not operative) Operation prohibited Operation prohibited AUTO UP (hold switch at AUTO UP position) Operative (in MANUAL mode) (Jam protection not operative) Operation prohibited Operation prohibited AUTO UP Operation prohibited Operation prohibited Operation prohibited AUTO DOWN Operation prohibited Operation prohibited Operation prohibited HINT: When the pulse sensor is normal, the AUTO UP/ DOWN function can be resumed by deactivating fail-safe mode. To deactivate fail-safe mode, pull up the driver door power window switch to the AUTO UP position and hold it for at least 1 second to fully close the window from the fully open position. If the LIN communication system malfunctions (communication blackout), the power window control system prohibits the following operations. LIN communication system LIN COMMUNICATION SYSTEM OPERATION REFERENCE Power window operation Ignition switch on (IG) MANUAL UP Operative (Jam protection operative) MANUAL DOWN Operative (Jam protection not operative) AUTO UP (hold switch at AUTO UP position) Operation prohibited AUTO UP Operation prohibited AUTO DOWN Operation prohibited

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. EXPRESSIONS OF IGNITION SWITCH TABLE Switch Type Ignition Switch (Position) Ignition Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch on (IG) ON On (IG) Ignition switch on (ACC) ACC On (ACC) Engine start START Start

Scheme 164

Scheme 165

Window deicer system

PROBLEM SYMPTOMS TABLE

Scheme 166

1. CHECK AIR CONDITIONING AMPLIFIER ASSEMBLY Measure the voltage and resistance according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition D38-10 (FDF1) - D37-14 (GND) R - W-B Front deicer signal Ignition switch on (IG), Front window deicer switch OFF 11 to 14 V Ignition switch on (IG), Front window deicer switch ON Below 1 V D37-1 (IG+) - D37-14 (GND) GR - W-B Power source (IG) Ignition switch on (IG) 11 to 14 V Ignition switch off Below 1 V D37-21 (B) - D37-14 (GND) B - W-B Power source (Back-up) Always 11 to 14 V Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition D37-14 (GND) - Body ground W-B - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction in the wire harness or amplifier.

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. EXPRESSIONS OF IGNITION SWITCH TABLE Switch Type Ignition Switch (Position) Engine Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch on (IG) ON On (IG) Ignition switch on (ACC) ACC On (ACC) Engine start START Start

Scheme 167

Scheme 168

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this section. EXPRESSIONS OF IGNITION SWITCH Switch Type Ignition Switch (Position) Engine Switch (Condition) Expression Ignition switch off LOCK Off Ignition switch on (IG) ON On (IG) Ignition switch on (ACC) ACC On (ACC) Engine start START Start

Scheme 169

Scheme 170

GLASS HATCH OPENER SYSTEM

PROBLEM SYMPTOMS TABLE

Scheme 171

1. CHECK MAIN BODY ECU Disconnect the 1A, 1D and 1F Junction block connectors. Measure the voltage and resistance between the specified terminals of the wire harness side connectors and body ground. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition 1A-1 - Body ground B - Body ground Battery power supply Always 11 to 14 V 1D-16 (ALTB) - Body ground W - Body ground Generator power supply Always 11 to 14 V Standard resistance RESISTANCE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition 1F-10 (GND1) - Body ground W-B - Body ground Ground Always Below 1 ohms 1D-16 (ALTB) - Body ground W - Body ground Ground Always Below 1 ohms If the result is not as specified, there may be a malfunction on the wire harness side. Reconnect the 1A, 1D and 1F Junction block connectors. Measure the voltage according to the value(s) in the table below. Standard voltage VOLTAGE SPECIFICATION TABLE Tester Connection Wiring Color Terminal Description Condition Specified Condition D8-20 (GCTY) - Body ground P - Body ground Glass hatch courtesy switch input Glass hatch is open Below 1 V Glass hatch is closed 11 to 14 V D10-8 (GHSW) - Body ground O - Body ground Glass hatch open signal input Glass hatch is open Below 1 V Glass hatch is closed 11 to 14 V D7-26 (GRY2) - Body ground Y - Body ground NO.1 glass hatch relay signal Ignition switch: on (IG) Glass hatch open switch: on Below 1 V Ignition switch: on (IG) Glass hatch open switch: off 11 to 14 V D7-15 (GRY1) - Body ground V - Body ground NO.2 glass hatch relay signal Ignition switch: on (IG) Glass hatch open switch: on Below 1 V Ignition switch: on (IG) Glass hatch open switch: off 11 to 14 V
