Automatic Transmission Diagnosis - U-340-E & U-341-E: Specifications Toyota Echo I

Automatic Trans 12 illustrations

SHIFT SPEED SPECIFICATIONS

ApplicationMPH
"D" Position
1st-2nd35-39
2nd-3rd69-75
3rd-4th103-110
3rd-4th (2)28-31
4th-3rd (2)20-23
4th-3rd81-86
3rd-2nd65-70
2nd-1st28-31
"2" Position
1st-2nd35-39
3rd-2nd65-70
2nd-1st26-31
"L" Position
3rd-2nd65-70
2nd-1st32-35
(1) Wide open throttle. (2) Fully closed throttle.
(1)Wide open throttle.
(2)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (CELICA) (1)

ApplicationMPH
"D" Position
1st-2nd32-36
2nd-3rd60-67
3rd-4th105-113
3rd-4th (2)25-29
4th-3rd (2)19-22
4th-3rd93-101
3rd-2nd57-63
2nd-1st27-30
"2" Position
1st-2nd32-36
3rd-2nd57-63
2nd-1st27-30
"L" Position
3rd-2nd57-63
2nd-1st28-32
(1) Wide open throttle. (2) Fully closed throttle.
(1)Wide open throttle.
(2)Fully closed throttle.

SHIFT SPEED SPECIFICATIONS (ECHO) (1)

LOCK-UP SPEED SPECIFICATIONS

ApplicationMPH
"D" Position (2)
Lock-Up On In 3rd (3)51-55
Lock-Up Off In 3rd (3)48-51
Lock-Up On In OD34-37
Lock-Up Off In OD32-36
(1) Throttle valve opening 5 percent. (2) There is no lock-up in "L" or "2" position. (3) With OD switch off.
(1)Throttle valve opening 5 percent.
(2)There is no lock-up in "L" or "2" position.
(3)With OD switch off.

LOCK-UP SPEEDS (CELICA) (1)

ApplicationMPH
"D" Position (2)
Lock-Up On In 3rd (3)60-67
Lock-Up Off In 3rd (3)57-63
Lock-Up On In OD35-39
Lock-Up Off In OD34-37
(1) Throttle valve opening 5 percent. (2) There is no lock-up in "L" or "2" position. (3) With OD switch off.
(1)Throttle valve opening 5 percent.
(2)There is no lock-up in "L" or "2" position.
(3)With OD switch off.

LOCK-UP SPEEDS (ECHO) (1)

TORQUE SPECIFICATIONS

ApplicationFt. Lbs. (N.m)
Vehicle Speed Sensor Bolt12 (16)
INCH Lbs. (N.m)
Input Turbine Speed Sensor Bolt48 (5.4)
PNP Switch Bolt48 (5.4)
PNP Switch Nut61 (6.9)
Solenoid Bolt97 (11.0)

TORQUE SPECIFICATIONS

ELECTRICAL SPECIFICATIONS

ApplicationOhms
Input Turbine & Vehicle Speed Sensor560-680
Shift Solenoids SL, ST, No. 1 & No. 211-15
Shift Solenoid SLT5.0-5.6

COMPONENT RESISTANCE SPECIFICATIONS

Scheme 1

Scheme 1: CONNECTOR IDENTIFICATION
Scheme 1: CONNECTOR IDENTIFICATION

Scheme 2

Scheme 2
Scheme 2

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5
Scheme 5

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12
