REMOVAL & INSTALLATION
| WARNING | Vehicles are equipped with Supplemental Inflatable Restraint (SIR) system. When servicing vehicles, use care to avoid accidental air bag deployment. SIR system-related components are located in various locations throughout interior and exterior of vehicles, depending on application. Do not use electrical test equipment on or near these circuits. If necessary, deactivate SIR system before servicing components. See appropriate AIR BAG DEACTIVATION PROCEDURES article in GENERAL INFORMATION. |
| CAUTION | When battery is disconnected, vehicle computer and memory systems may lose memory data. Driveability problems may exist until computer systems have completed a relearn cycle. See appropriate COMPUTER RELEARN PROCEDURES article in GENERAL INFORMATION before disconnecting battery. |
Disconnect electrical connector. Remove lock nut and unscrew brakelight switch. To install, screw brakelight switch inward until brakelight plunger contacts brake pedal. Install and tighten lock nut.
Ensure ignition is off. Disconnect negative battery cable. Remove protective covers and glove compartment (if applicable) to access ECM. see scheme 2and see scheme 3. Disconnect connectors and remove ECM. To install, reverse removal procedure.
Disconnect electrical connector. Remove speed sensor bolt and sensor from transaxle case. see scheme 2and see scheme 3. To install, reverse removal procedure.
Removal
PNP switch is located on side of transaxle. Remove lock nut, washer and manual lever from control shaft. (Scheme 16) Bend up tabs on lock washer. Remove lock nut, lock washer and seal from control shaft. Remove retaining bolts and switch.
Installation
- Install switch on control shaft. Loosely install switch retaining bolts. Install seal and lock washer. Install lock nut and tighten to specification. See «TORQUE SPECIFICATIONS»(ref-140773-S16400007772002053100000). Bend tabs on lock washer over against lock nut.
- Ensure parking brake is applied. Temporarily install manual lever on control shaft. Place selector lever in "N" position. Remove manual lever. Rotate PNP switch and align reference mark on PNP switch with groove. (Scheme 16)
- Hold PNP switch in this position. Tighten retaining bolts to specification. To install remaining components, reverse removal procedure.
Scheme 16
Raise and support vehicle. Remove transaxle oil pan. See LUBRICATION in appropriate SERVICING article. Remove filler tube, gasket, oil strainer and magnets from oil pan. Disconnect connectors from each solenoid and A/T fluid temperature sensor. see scheme 4 Remove solenoid wiring harness and stopper plate. Solenoids are located on transaxle valve body. see scheme 5 Remove bolt, solenoid and "O" ring from valve body. To install, reverse removal procedure using NEW "O" ring and pan gasket.
