Smart Key System (For Start Function) (Diagnostics - Introduction): Other Toyota Corolla XI

PRECAUTION [08/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following system after the cable is reconnected. System Name See Procedure Air Conditioning System (for Automatic Air Conditioning System) Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)
2. PRECAUTIONS WHEN USING TECHSTREAM When using the Techstream with the engine switch off, connect the Techstream to the DLC3 and turn a courtesy light switch on and off at intervals of 1.5 seconds or less until communication between the Techstream and the vehicle begins. Then select the vehicle type under manual mode and enter the following menus: Body Electrical / Smart Key. While using the Techstream, periodically turn a courtesy light switch on and off at intervals of 1.5 seconds or less to maintain communication between the Techstream and the vehicle.
3. PRECAUTION FOR REGISTRATION If replacing any of the following parts, refer to the registration procedures. Certification ECU (smart key ECU assembly) Steering lock ECU (steering lock actuator assembly) Electrical key transmitter sub-assembly ID code box (immobilizer code ECU) ECM

Scheme 86

Scheme 87

Scheme 88

Scheme 89

Scheme 90

1. *1: except Manual Transaxle
2. *2: for Manual Transaxle
3. *3: w/ Multi-information Display (Dot LCD Type)
4. *4: w/ Multi-information Display (Segment LCD Type)

CAUTION / NOTICE / HINT

HINT

1. Use these procedures to troubleshoot the smart key system (for Start Function).
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What Vehicle model, system name When Date, time, occurrence frequency, whether the problem occurred recently or has been occurring for a long time Where Whether the problem occurs at a specific location Under what conditions? Whether the doors were locked or unlocked, whether the engine switch was on, whether the engine has started How did it happen? Problem symptoms* *: Be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem, and then check for DTCs. If the entry lock/unlock function does not operate for all doors. If the entry lock function does not operate. If the entry unlock function does not operate. If both the entry lock and unlock functions do not operate. If the wireless lock and unlock functions do not operate If there is no power even when the engine switch is pressed (does not turn on (ACC)). If the engine does not start with the push-button start function. If the outside warning buzzers do not sound. If the customer attempted to start the engine by near the electrical key transmitter sub-assembly to the engine switch and pressing the engine switch. If the interior warning buzzers do not sound. If the steering does not unlock. Any other details concerning the problem. If it is thought that wave interference is likely, be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem. Specific locations where the system does not operate (such as near TV towers, large video displays, wireless garage door opener systems, wireless security cameras, home security systems, etc.). Specific times when the system does not operate: Whether or not symptoms occurred immediately after purchase or only recently. Whether or not the symptoms occurred even when the electrical key transmitter sub-assembly was near the vehicle (electrical key antenna). If the system does not operate only when near specific vehicles (there may be an effect from electric waves from the wireless systems of other vehicles). If the system operates intermittently. If the electrical key transmitter sub-assembly is bundled together with other items. If the electrical key transmitter sub-assembly is carried together with other electronic devices, such as cell phones, personal computers, portable music players, other electrical keys, etc. (keep the electrical key transmitter sub-assembly at least 0.1 m (0.328 ft.) away from such items). Where the electrical key transmitter sub-assembly is being kept when not in use: Whether or not the electrical key transmitter sub-assembly is being placed within 1 m (3.28 ft.) of items such as TVs, DVD recorders, induction cookers, rice cookers, dishwashers, modems, cell phones, personal computers, microwave ovens, desk or floor lamps, cordless telephones, etc. If there are electronic devices that transmit electric waves placed in the vehicle. When the key battery was last replaced (when the battery is low): The key battery can be checked using the "Key Low Battery" item in the Data List. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635437-S28739948622014070300000) If the customer installed any optional components (theft deterrent devices, wireless fog lights, etc.) to the vehicle. Result Proceed to NEXT Result: 1 NEXT See step 3
3. INSPECT BASIC OPERATION Inspect battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the battery before proceeding to the next step. Check the fuses and relays. Check the connector connections and terminals to make sure that there are no abnormalities such as loose connections, deformation, etc. Result Proceed to NEXT Result: 1 NEXT See step 4
4. INSPECT COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Using the Techstream, check for CAN communication system DTCs. Refer to «DIAGNOSIS SYSTEM [08/2013 - 04/2014]»(ref-635647-S40458511452014070300000) Refer to «DIAGNOSIS SYSTEM [04/2014 - ]»(ref-635652-S02842089492014070300000) Result Result Proceed to CAN DTCs are not output A CAN DTCs are output B Result: 2 B GO TO CAN COMMUNICATION SYSTEM (HOW TO PROCEED WITH TROUBLESHOOTING). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635647-S27781195552014070300000) Result: 1 A See step 5
5. INSPECT COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Using the Techstream, check for LIN communication system DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635671-S21721299832014070300000) Result Result Proceed to LIN DTCs are not output A LIN DTCs are output B Result: 2 B GO TO LIN COMMUNICATION SYSTEM (HOW TO PROCEED WITH TROUBLESHOOTING). Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635671-S22380098072014070300000) Result: 1 A See step 6
6. CHECK FOR DTC* Check for DTCs and note any codes that are output. Powertrain > Engine and ECT > Trouble Codes Body Electrical > Smart Key > Trouble Codes Body Electrical > Power Source Control > Trouble Codes Body Electrical > Starting Control > Trouble Codes Result Result Proceed to DTCs are not output A Steering lock system DTCs are output B Immobilizer system DTCs are output C Smart key system (for Entry Function) DTCs are output D Smart key system (for Start Function) DTCs are output E Result: 5 B GO TO STEERING LOCK SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635670-S11584690042014070300000) Result: 2 C GO TO IMMOBILIZER SYSTEM. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635449-S12069620382014070300000) Result: 3 D GO TO SMART KEY SYSTEM (for Entry Function). Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635436-S23611357552014070300000) Result: 4 E GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635437-S15246327292014070300000) Result: 1 A See step 7
7. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-635437-S07871495942014070300000) Result Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B Result: 2 B See step 9 Result: 1 A See step 8
8. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check Refer to «OPERATION CHECK [08/2013 - ]»(ref-635437-S42728907772014070300000) Terminals of ECU Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635437-S25494866982014070300000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635437-S28739948622014070300000) Result Proceed to NEXT Result: 1 NEXT See step 9
9. REPAIR OR REPLACE Result Proceed to NEXT Result: 1 NEXT See step 10
10. CHECK FOR DTC* Clear the DTCs. Powertrain > Engine and ECT > Clear DTCs Body Electrical > Smart Key > Clear DTCs Body Electrical > Power Source Control > Clear DTCs Body Electrical > Starting Control > Clear DTCs Recheck for DTCs. Powertrain > Engine and ECT > Trouble Codes Body Electrical > Smart Key > Trouble Codes Body Electrical > Power Source Control > Trouble Codes Body Electrical > Starting Control > Trouble Codes HINT: Before checking for DTCs, perform the "DTC Output Confirmation Operation" procedure. Result Result Proceed to DTCs are not output A DTCs are output B Result: 1 A END Result: 2 B GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635437-S15246327292014070300000)

Scheme 91

Scheme 92

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. OPERATION DESCRIPTION NOTE: Make sure that the smart key system (for Start Function) has not been canceled before performing this inspection. Refer to «CUSTOMIZE PARAMETERS [08/2013 - ]»(ref-635437-S27074256892014070300000) Push-button start function: (except Manual Transaxle) When the electrical key transmitter sub-assembly is in a detection area inside the vehicle and the brake pedal is depressed, the engine is started by pressing the engine switch. When the electrical key transmitter sub-assembly is in a detection area inside the vehicle and the brake pedal is not depressed, the power source mode is changed by pressing the engine switch. The power source mode changes in the following order every time the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed while not depressing the brake pedal, the power source mode changes to on (ACC) and "POWER ON" is displayed*1 or the key warning light blinks in green*2 in the combination meter assembly. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed 2 times without depressing the brake pedal, the power source mode changes to on (IG) and "POWER ON" is displayed*1 or the key warning light blinks in green*2 in the combination meter assembly. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the brake pedal is depressed while the shift lever is in P or N, the key warning light is displayed*1 or the key warning light illuminates in green*2. *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Illuminates in Green (w/ Multi-information Display (Segment LCD Type)) *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) The engine starts if the engine switch is pressed when the key warning light is displayed*1 or the key warning light is illuminated in green*2. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Push-button start function: (for Manual Transaxle) When the electrical key transmitter sub-assembly is in a detection area inside the vehicle and the clutch pedal is depressed, the engine is started by pressing the engine switch. When the electrical key transmitter sub-assembly is in a detection area inside the vehicle and the clutch pedal is not depressed, the power source mode is changed by pressing the engine switch. The power source mode changes in the following order every time the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed while not depressing the clutch pedal, the power source mode changes to on (ACC) and "POWER ON"*1 is displayed or the key warning light blinks in green*2 in the combination meter assembly. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the engine switch is pressed 2 times without depressing the clutch pedal, the power source mode changes to on (IG) and "POWER ON" is displayed*1 or the key warning light blinks in green*2 in the combination meter assembly. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) After getting into the vehicle while carrying the electrical key transmitter sub-assembly when the engine switch is off, if the clutch pedal is depressed, the key warning light is displayed*1 or the key warning light is illuminated in green*2. *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Illuminates in Green (w/ Multi-information Display (Segment LCD Type)) *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) The engine starts if the engine switch is pressed when the key warning light is displayed*1 or the key warning light is illuminated in green*2. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Changing the power source mode when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or transmitter battery depletion: (except Manual Transaxle) Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the brake pedal and facing the logo side of the electrical key transmitter sub-assembly towards the engine switch, hold the electrical key transmitter sub-assembly near the engine switch. A buzzer in the combination meter assembly sounds and the power source mode changes to on (IG). *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) Pressing the engine switch without depressing the brake pedal turns the power source mode from on (IG) to off. Changing the power source mode when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or transmitter battery depletion: (for Manual Transaxle) Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the clutch pedal and facing the logo side of the electrical key transmitter sub-assembly towards the engine switch, hold the electrical key transmitter sub-assembly near the engine switch. A buzzer in the combination meter assembly sounds and the power source mode changes to on (IG). *a Key Warning Light Displayed (w/ Multi-information Display (Dot LCD Type)) *b Key Warning Light Blinks in Green (w/ Multi-information Display (Segment LCD Type)) Pressing the engine switch without depressing the clutch pedal turns the power source mode from on (IG) to off. Starting the engine when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or transmitter battery depletion: (except Manual Transaxle) Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the brake pedal with the shift lever in P or N* and facing the logo side of the electrical key transmitter sub-assembly towards the engine switch, hold the electrical key transmitter sub-assembly near the engine switch. HINT: *: This is only applicable when the steering is unlocked. A buzzer in the combination meter assembly sounds, the power source mode changes to on (IG). Press the engine switch with the brake pedal depressed to start the engine. Starting the engine when the electrical key transmitter sub-assembly does not operate correctly due to wave interference or transmitter battery depletion: (for Manual Transaxle) Unlock the door using the built-in mechanical key and get into the vehicle while carrying the electrical key transmitter sub-assembly. While depressing the clutch pedal and facing the logo side of the electrical key transmitter sub-assembly towards the engine switch, hold the electrical key transmitter sub-assembly near the engine switch. A buzzer in the combination meter assembly sounds, the power source mode changes to on (IG). Press the engine switch with the clutch pedal depressed to start the engine.
2. CHECK PUSH-BUTTON START FUNCTION Check the push-button start function: (except Manual Transaxle) w/ Multi-information Display (Segment LCD Type): Get into the vehicle while carrying the electrical key transmitter sub-assembly. With the engine switch off and the shift lever in P, check that the key warning light illuminates in green when the brake pedal is depressed. Check that the engine starts when the engine switch is pressed with the key warning light illuminated in green. w/ Multi-information Display (Dot LCD Type): Get into the vehicle while carrying the electrical key transmitter sub-assembly with the engine switch off. With the shift lever in P, check that the key warning light is displayed when the brake pedal is depressed. Then check that the engine starts when the engine switch is pressed with the key warning light displayed. While the brake pedal is released and the electrical key transmitter sub-assembly is being carried, check that the power source mode changes in the following order when the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. HINT: When the engine switch is pressed with the engine switch on (IG) and the shift lever not in P, the power source mode does not change to off, but changes to on (ACC). With the shift lever in P, check that the steering lock operates when a door is opened. HINT: When the engine switch is pressed after the vehicle is stopped, the engine stops and all the power turns off. However, if the shift lever is not in P when the engine switch is pressed with the vehicle stopped, the power source mode does not change to off, but changes to on (ACC). Check the push-button start function operation range for the front side. Place the electrical key transmitter sub-assembly at either inspection point making sure that the electrical key transmitter sub-assembly is oriented as shown in the illustration, and then check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in a vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if the electrical key transmitter sub-assembly is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform this inspection for both inspection points. Check the push-button start function operation range for the rear side. Place the electrical key transmitter sub-assembly at either inspection point making sure that the electrical key transmitter sub-assembly is oriented as shown in the illustration, and then check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in a vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if the electrical key transmitter sub-assembly is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform this inspection for both inspection points. Check the push-button start function: (for Manual Transaxle) w/ Multi-information Display (Segment LCD Type): Get into the vehicle while carrying the electrical key transmitter sub-assembly. With the engine switch off, check that the key warning light illuminates in green when the clutch pedal is depressed. Check that the engine starts when the engine switch is pressed with the key warning light illuminated in green. w/ Multi-information Display (Dot LCD Type): Get into the vehicle while carrying the electrical key transmitter sub-assembly with the engine switch off. Check that the key warning light is displayed when the clutch pedal is depressed. Then check that the engine starts when the engine switch is pressed with the key warning light displayed. While the clutch pedal is released and the electrical key transmitter sub-assembly is being carried, check that the power source mode changes in the following order when the engine switch is pressed: off --> on (ACC) --> on (IG) --> off. Check that the steering lock operates when a door is opened. Check the push-button start function operation range for the front side. Place the electrical key transmitter sub-assembly at either inspection point making sure that the electrical key transmitter sub-assembly is oriented as shown in the illustration, and then check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in a vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if the electrical key transmitter sub-assembly is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform this inspection for both inspection points. Check the push-button start function operation range for the rear side. Place the electrical key transmitter sub-assembly at either inspection point making sure that the electrical key transmitter sub-assembly is oriented as shown in the illustration, and then check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is in a vehicle interior key detection area, the electrical key transmitter sub-assembly may not be properly detected if the electrical key transmitter sub-assembly is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform this inspection for both inspection points.
3. CHECK TRANSMITTER BATTERY SAVING MODE FUNCTION Check the transmitter battery saving mode function: Press the unlock button of the electrical key transmitter sub-assembly twice while pressing the lock button and check that the electrical key transmitter sub-assembly LED blinks 4 times and enters transmitter battery saving mode. Check that the smart key system does not operate while in transmitter battery saving mode. HINT: To cancel transmitter battery saving mode, press a button of the electrical key transmitter sub-assembly.
4. CHECK POWER SOURCE MODE CHANGING FUNCTION Check the engine switch. except Manual Transaxle: Check that the power source mode changes according to the chart below. Shift Position Brake Pedal Power Source Mode when Engine Switch Pressed P Released Off --> on (ACC) --> on (IG) --> off P Released Engine running --> off P Released On (ACC)*1 --> off P Depressed Off --> engine starts P Depressed On (ACC) --> engine starts P Depressed On (IG) --> engine starts P Depressed Engine running --> off P Depressed On (ACC)*1 --> off N Released Off --> on (ACC) --> on (IG) (after power source mode changes to on (IG), power source mode changes between on (IG) and on (ACC) every time engine switch is pressed)*2 N Released Engine running --> on (ACC)*2 N Depressed Off --> engine starts*2 N Depressed On (ACC) --> engine starts*2 N Depressed On (IG) --> engine starts*2 N Depressed Engine running --> on (ACC)*2 Not P or N*3 Released Off --> on (ACC) --> on (IG) (after power source mode changes to on (IG), power source mode changes between on (IG) and on (ACC) every time engine switch is pressed) Not P or N*4 Released Engine running --> on (ACC) Not P or N*3 Depressed Off --> on (IG) Not P or N*3 Depressed On (ACC) --> on (IG) Not P or N*4 Depressed Engine running --> on (ACC) HINT: *1: This situation is only applicable when the power source mode has changed from on (IG) to on (ACC). (Excluding an emergency stop by pressing the engine switch 3 times quickly or pressing and holding the engine switch for 2 seconds or more.) *2: This situation is only applicable when the steering is unlocked. *3: This situation is only applicable when the steering is locked. *4: This situation is only applicable when the shift lever is not in N (steering is locked). for Manual Transaxle: Check that the power source mode changes according to the chart below. Clutch Pedal Power Source Mode when Engine Switch Pressed Released Off --> on (ACC) --> on (IG) --> off Released Engine running --> off Depressed Off --> engine starts Depressed On (ACC) --> engine starts Depressed On (IG) --> engine starts Depressed Engine running --> off
5. CHECK POWER SOURCE MODE INDICATION Check the smart warning (w/ Multi-information Display (Segment LCD Type)). *a Key Warning Light INDICATOR INSPECTION Power Source Mode Indicator Off (Excluding condition in which the engine can be started) Off On (ACC) (Excluding condition in which the engine can be started) Blinks in green On (IG) (Excluding condition in which the engine can be started) Blinks in green Condition in which engine can be started*1,*2 Illuminates in green Engine started Off HINT: *1: except Manual Transaxle Indicates the condition in which the engine can be started by pressing the engine switch while either of the following conditions is met. Condition 1 All of the following conditions are met: The power source mode was turned from on (IG) to on (ACC). Key verification is OK*3 or immobilizer is unset (engine switch is on (ACC) or on (IG)). The shift lever is in N and the steering is unlocked. The stop light switch is on. Condition 2 All of the following conditions are met: The power source mode was not turned from on (IG) to on (ACC). Key verification is OK*3 or immobilizer is unset (engine switch is on (ACC) or on (IG)). The stop light switch is on. The shift lever is in P, or the shift lever is in N with the steering unlocked. *2: for Manual Transaxle Indicates the condition in which the engine can be started by pressing the engine switch while the following condition is met. Condition Both of the following conditions are met: Key verificatioln is OK*3 or the engine switch is on (ACC) or on (IG). The clutch start switch is on. *3: When the electrical key transmitter sub-assembly is in the cabin, the ID code sent as a result of communication between the electrical key transmitter sub-assembly and certification ECU (smart key ECU assembly) and the ID code calculated by the certification ECU (smart key ECU assembly) are compared. If the ID codes match each other, the vehicle recognizes that the electrical key transmitter sub-assembly is in the cabin. Check the smart warning (w/ Multi-information Display (Dot LCD Type)). *a POWER ON display *b Key Warning Light display MULTI-INFORMATION DISPLAY INSPECTION Power Source Mode Multi-information Display Off (Excluding condition in which the engine can be started) Off On (ACC) (Excluding condition in which the engine can be started) "POWER ON" displayed On (IG) (Excluding condition in which the engine can be started) "POWER ON" displayed Condition in which engine can be started*1,*2 Key Warning Light displayed Engine started Off HINT: *1: except Manual Transaxle Indicates the condition in which the engine can be started by pressing the engine switch while either of the following conditions is met. Condition 1 All of the following conditions are met: The power source mode was turned from on (IG) to on (ACC). Key verification is OK*3 or immobilizer is unset (engine switch is on (ACC) or on (IG)). The shift lever is in N and the steering is unlocked. The stop light switch is on. Condition 2 All of the following conditions are met: The power source mode was not turned from on (IG) to on (ACC). Key verification is OK*3 or immobilizer is unset (engine switch is on (ACC) or on (IG)). The stop light switch is on. The shift lever is in P, or the shift lever is in N with the steering unlocked. *2: for Manual Transaxle Indicates the condition in which the engine can be started by pressing the engine switch while the following condition is met. Condition Both of the following conditions are met: Key verificatioln is OK*3 or the engine switch is on (ACC) or on (IG). The clutch start switch is on. *3: When the electrical key transmitter sub-assembly is in the cabin, the ID code sent as a result of communication between the electrical key transmitter sub-assembly and certification ECU (smart key ECU assembly) and the ID code calculated by the certification ECU (smart key ECU assembly) are compared. If the ID codes match each other, the vehicle recognizes that the electrical key transmitter sub-assembly is in the cabin.

CUSTOMIZE PARAMETERS [08/2013 - ]

1. CUSTOMIZE SMART KEY SYSTEM (for Start Function) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Smart Key / Access or Warning. Select the setting by referring to the table below. Smart Key / Access Tester Display Description Default Setting ECU Ignition Available Area Function that sets the area that the key must be in before the engine switch can be operated. All 00:Front, 01:All Certification ECU (smart key ECU assembly) Engine Start Indicator Function that turns the key warning light on the combination meter assembly on or off. ON 0:OFF, 1:ON Certification ECU (smart key ECU assembly) Warning Tester Display Description Default Setting ECU Key Low Battery Warning Enables or disables the sounding of the buzzer when the transmitter battery is low and the engine switch is turned off after being on (IG) for 20 minutes or more. ON 0:OFF, 1:ON Certification ECU (smart key ECU assembly) Entry cancel function (manual operation) HINT: While the smart key system is canceled, it is possible to lock and unlock the doors with the wireless operation, and the start system can be operated by holding the electrical key transmitter sub-assembly near the engine switch. The following functions are disabled when the smart key system is canceled. Entry unlock/lock functions Push-button start function Key lock-in prevention function Entry warning functions When canceling the smart key system through manual operation: Make sure the following conditions are met: The engine switch is off. The driver door is closed. The driver door is unlocked. Press the unlock switch of the electrical key transmitter sub-assembly. Open the driver door within 5 seconds of completing the step above (driver door: closed --> opened). With the driver door open, press the unlock switch of the electrical key transmitter sub-assembly 2 times within 5 seconds of completing the step above. NOTE: If the driver door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Perform the following procedure within 30 seconds of completing the step above. Close and open the driver door twice (driver door: open --> closed --> opened --> closed --> opened). With the driver door open, press the unlock switch of the electrical key transmitter sub-assembly 2 times. NOTE: If the driver door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Close and open the driver door (driver door: open --> closed --> opened). Close the driver door within 5 seconds (driver door: open --> closed). Check that the wireless buzzer sounds twice (short beeps) to confirm that the smart key system has been canceled. Perform the following procedure to restore the smart key system to the active state from the canceled state. Perform the procedure to cancel the smart key system again. Check that the wireless buzzer sounds once (short beep) to confirm that the smart key system has been restored to the active state. HINT: The system changes between the canceled state and the active state each time the procedure to cancel the system through manual operation is performed. The buzzer sounds twice when the system changes from the active state to the canceled state, and sounds once when the system changes from the canceled state to the active state.
