PRECAUTION [08/2013 - ]

1. PRECAUTION FOR DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL NOTE: When disconnecting the cable from the negative (-) battery terminal, initialize the following system after the cable is reconnected. System Name See Procedure Air Conditioning System (for Automatic Air Conditioning System) Refer to «INITIALIZATION [08/2013 - ]»(ref-635429-S20696467122014070300000)
2. DOOR CONTROL RECEIVER EXPRESSIONS The type of door control receiver used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this article. Vehicle Specification Part Name in Manual Actual Part Name w/ Tire Pressure Warning System Door control receiver Electrical key and tire pressure monitoring system receiver assembly w/o Tire Pressure Warning System Door control receiver Smart door control receiver assembly
3. PRECAUTION WHEN USING TECHSTREAM When using the Techstream with the engine switch off, connect the Techstream to the DLC3 and turn a courtesy light switch on and off at intervals of 1.5 seconds or less until communication between the Techstream and the vehicle begins. Then select the vehicle type under manual mode and enter the following menus: Body Electrical / Smart Key. While using the Techstream, periodically turn a courtesy light switch on and off at intervals of 1.5 seconds or less to maintain communication between the Techstream and the vehicle.
4. PRECAUTION FOR REGISTRATION If replacing any of the following parts, refer to the registration procedures. Refer to «REGISTRATION [08/2013 - ]»(ref-635449-S41259747962014070300000) Certification ECU (smart key ECU assembly) Steering lock ECU (steering lock actuator assembly) ID code box (immobilizer code ECU) Electrical key transmitter sub-assembly ECM
5. PRECAUTIONS WHEN DISCONNECTING CABLE FROM NEGATIVE BATTERY TERMINAL After disconnecting and reconnecting the battery cable, the entry unlock function may not operate. If this occurs, the entry unlock function can be restored by performing a wireless door lock and unlock operation.
6. PRECAUTIONS FOR VEHICLE BATTERY AND TRANSMITTER BATTERY BUILT INTO ELECTRICAL KEY TRANSMITTER SUB-ASSEMBLY When the doors are locked, power from the vehicle battery is used to transmit radio waves. The battery may be discharged if the vehicle remains parked for a long time. If the vehicle is not to be used for a long time, disconnect the vehicle battery or cancel the smart key system (for Entry Function). HINT: Refer to the following procedures to cancel the smart key system (for Entry Function). Refer to «CUSTOMIZE PARAMETERS [08/2013 - ]»(ref-635436-S35765981882014070300000) When the doors are locked and an electrical key transmitter sub-assembly is in the detection area of an electrical key antenna, the transmitter battery may be depleted due to periodic communication between the electrical key transmitter sub-assembly and the vehicle. If the vehicle is not to be used for a long time, keep the key away from the vehicle (more than 2 m (6.56 ft.)).
7. PRECAUTIONS FOR ELECTRICAL KEY TRANSMITTER SUB-ASSEMBLY The electrical key transmitter sub-assembly is a precision instrument. Be sure to observe the following: Do not subject the electrical key transmitter sub-assembly to strong physical shocks. Do not keep the electrical key transmitter sub-assembly in a high temperature area for a long time. Do not use an ultrasonic washing machine to clean the electrical key transmitter sub-assembly. Do not use the electrical key transmitter sub-assembly near any magnets or magnetized items. Do not place the electrical key transmitter sub-assembly near magnetic equipment, such as digital audio players, induction cookers, medical devices that generate low-frequency electromagnetic waves, etc. Do not attach any stickers to the electrical key transmitter sub-assembly. Do not disassemble the electrical key transmitter sub-assemblies. The mechanical key should only be used in an emergency, such as when the transmitter battery is depleted.
8. PRECAUTIONS WHEN INSPECTING SMART KEY SYSTEM (for Entry Function) General precaution for the smart key system (for Entry Function): Always carry the electrical key transmitter sub-assembly. The smart key system (for Entry Function) may not operate normally or the key detection area may decrease in the following situations: The transmitter battery is depleted. There are TV towers, electric power plants, broadcasting stations, gas stations or other facilities that generate strong radio waves or electrical noise nearby. Wireless communication devices, such as walkie-talkies, cell phones, cordless telephones, digital audio players, portable game systems, etc., are carried together with the electrical key transmitter sub-assembly. The electrical key transmitter sub-assembly is covered by or in contact with objects made of metal, such as coins, certain types of cards, etc. Metallic film is applied to the rear window glass. A radio wave type keyless entry system or wireless remote is operated nearby. An electrical key transmitter sub-assembly from another vehicle is nearby. The electrical key transmitter sub-assembly is placed near equipment that generates high-voltage or electrical noise. The electrical key transmitter sub-assembly is placed near an electronic device such as a battery charger. Operating range of the smart key system (for Entry Function): Due to the body design, there are some areas in which proper system operation is difficult. Even if the electrical key transmitter sub-assembly is in the vehicle exterior detection area, the electrical key transmitter sub-assembly may not be properly detected if the electrical key transmitter sub-assembly is near a window, a door handle or the center of the bumper. Even if an electrical key transmitter sub-assembly is in a vehicle interior detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, in the glove box or on the floor. Depending on the way the electrical key transmitter sub-assembly is held, the electrical key transmitter sub-assembly may not operate properly. As weak radio waves are emitted from the electrical key transmitter sub-assembly, if a pacemaker is being used, be sure to read the pacemaker instruction manual. The smart key system (for Entry Function) will not operate under the following conditions, The procedures to cancel the smart key system (for Entry Function) have been performed. There is no transmitter battery or the battery is depleted (the LED of the electrical key transmitter sub-assembly does not blink when an electrical key transmitter sub-assembly switch is pressed).
9. PRECAUTIONS FOR ENTRY UNLOCK FUNCTION When unlocking the doors, make sure to grasp a front door outside handle assembly, ensuring contact with the sensor on the inner part of the handle. Pull the handle after confirming that the door has unlocked. If a front door outside handle assembly is grasped with gloved hands, unlocking may be delayed or may not occur. When performing an entry unlock operation, make sure to check that the doors are unlocked before pulling a door outside handle assembly to open a door. When attempting to open a door suddenly or immediately after entering a vehicle exterior detection area, the door may not unlock. In this case the system automatically performs the door unlock operation 4 times. However, if a front door outside handle assembly is being pulled at this time, the door may not unlock due to mechanical reasons. If the door is not unlocked, return the door outside handle to its original position and pull the handle after confirming that the door has unlocked. If the electrical key transmitter sub-assembly is brought too close to a front door outside handle assembly, it may not be possible to unlock the door with the entry unlock function. If an electrical key transmitter sub-assembly is within a vehicle exterior detection area, the door can be unlocked even when a person other than the person carrying the electrical key transmitter sub-assembly grasps the front door outside handle assembly. However, doors other than the door for which the matching code is detected cannot be unlocked. (If the electrical key transmitter sub-assembly is in the vehicle exterior detection area of the driver door and the front door outside handle assembly (for driver door) is held, the doors can be unlocked. However, if the front door outside handle assembly (for front passenger door) is held, the doors cannot be unlocked.) After a wireless door lock, manual door lock or key-linked door lock operation is performed with the electrical key transmitter sub-assembly in an interior detection area, an entry unlock operation cannot be performed. Therefore, when a wireless door lock operation is performed near a window or door handle, the entry unlock may not be able to be operated. To unlock the doors, perform a wireless door unlock operation. If a door is not opened after a door unlock operation, the doors automatically lock after approximately 60 seconds. HINT: When the auto lock function operates after an entry unlock operation, if an electrical key transmitter sub-assembly is detected in the cabin, the doors will be unlocked by the door ajar warning function. If an electrical key transmitter sub-assembly is within a vehicle exterior detection area and a large amount of water is applied to a front door outside handle assembly, such as by a car wash or heavy rain, the sensor may react and the entry unlock operation may be performed. However, the doors will automatically lock after approximately 60 seconds if a door is not opened. If the electrical key transmitter sub-assembly is being carried together with an electrical key transmitter sub-assembly from another vehicle with a smart key system (for Entry Function) and the front door outside handle assembly is held, the time before the door is unlocked by the entry unlock operation may be more than normal. HINT: *: When the auto lock function operates after an entry unlock operation, if an electrical key transmitter sub-assembly is detected in the cabin, the doors will be unlocked by the door ajar warning function.
10. PRECAUTIONS FOR ENTRY LOCK FUNCTION When performing an entry lock operation, if the lock sensor on a front door outside handle assembly is touched too quickly, the door may not lock. If the electrical key transmitter sub-assembly is brought near the vehicle interior (window, front door outside handle assembly), the entry lock function may not operate. Also, the key reminder warning buzzer may sound and the entry unlock operation may stop functioning. In this case, move the electrical key transmitter sub-assembly away from the vehicle interior (window, front door outside handle assembly), perform an entry lock operation, and then perform an entry unlock operation. If the electrical key transmitter sub-assembly is being carried and a lock operation is performed from the driver door while the driver door is open (the door is ajar), the door ajar warning does not operate. If the electrical key transmitter sub-assembly is left on the instrument panel, in the glove box or on the floor, the key reminder warning function may not operate and the electrical key transmitter sub-assembly may be locked in the vehicle when a door lock operation is performed. Always carry the electrical key transmitter sub-assembly. The entry unlock operation cannot be performed for approximately 3 seconds after an operation that locks the doors, such as an entry lock or wireless lock operation, is performed. When checking the entry lock operation several times, it can only be performed up to 2 times consecutively depending on the setting. To perform the operation 3 times or more consecutively, the doors need to be unlocked once (any unlock operation is acceptable). However, this is only for an entry lock operation, other door lock operations, such as a wireless door lock operation, can be performed consecutively.

Scheme 53

Scheme 54

Scheme 55

SYSTEM DIAGRAM [08/2013 - ]

1. This is a detailed diagram related to the certification ECU (smart key ECU assembly).

Scheme 56

Scheme 57

Scheme 58

1. This is a detailed diagram related to the main body ECU (multiplex network body ECU).

Scheme 59

Scheme 60

Scheme 61

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

1. MULTI CHANNEL FUNCTION The electrical key transmitter sub-assembly and door control receiver can operate on two different RF channels. When an electrical key transmitter sub-assembly is brought within an exterior detection area, key verification begins. If key verification fails due to wave interference, the channel will be switched and key verification will be performed again. The multi channel system begins verification using the channel on which the last verification was successfully performed. When verification fails, the system switches to the other channel. *a Exterior detection areas are created using LF waves (emitted from the vehicle at intervals of 0.25 seconds) to receive a response from the electrical key transmitter sub-assembly. *b When the electrical key transmitter sub-assembly is brought into an exterior detection area, it receives LF waves from the vehicle. Using RF waves, the electrical key transmitter sub-assembly responds to the vehicle. *c Upon receiving the response from the electrical key transmitter sub-assembly, the certification ECU (smart key ECU assembly) activates the electrical key antennas (outside) one by one. Using LF waves, the certification ECU (smart key ECU assembly) determines which exterior detection area the electrical key transmitter sub-assembly is in. *d The electrical key transmitter sub-assembly receives the LF waves from the vehicle and responds using RF waves. (The certification ECU (smart key ECU assembly) recognizes which exterior detection area the electrical key transmitter sub-assembly is in.) *e The certification ECU (smart key ECU assembly) sends registered key ID information to the electrical key transmitter sub-assembly using LF waves. (Up to 7 key IDs can be registered.) *f The electrical key transmitter sub-assembly sends the key ID information using RF waves. When the certification ECU (smart key ECU assembly) receives it, verification completes. *g Wave interference (Channel switching) - - The multi channel system changes the channels when the RF band (*b, *d and *f) is interrupted by wave interference. Refer to the table below to confirm when the system changes the channels. *b or *d is NG *f is NG Condition RF waves cannot be received RF waves cannot be received properly RF waves cannot be received RF waves cannot be received properly Channel switching The channels will not be switched. The channels will be switched. The channels will not be switched. The channels will be switched.* *: The channels are not switched during vehicle interior verification after an entry lock operation is performed.
2. SMART KEY SYSTEM SPECIFICATIONS Some customers may inquire about the frequency used by the smart key system on various models. This repair manual contains the applicable specifications of the smart key system. *a Transmitter Detection Area *b Outside Detection Area *c Inside Detection Area - - SPECIFICATIONS FOR SMART KEY SYSTEM ANTENNA LF OUTPUT POWER Specification Frequency Output Power/Electric Field Intensity Modulation Method Mounting Point in Vehicle Inside Passenger Compartment 134.2 kHz 94.4 dBuV/m at 3 m AM Inside front floor Inside Luggage Compartment 134.2 kHz 94.4 dBuV/m at 3 m AM Inside Luggage Compartment Outside Vehicle 134.2 kHz 95 dBuV/m at 3 m AM Inside door handle 95 dBuV/m at 3 m AM Inside rear bumper SPECIFICATIONS FOR SMART KEY SYSTEM ANTENNA LF TRANSMISSION TIMING Transmission Timing Vehicle Remains Parked Entering or Exiting the Vehicle Vehicle is being Driven Inside Passenger Compartment Does not transmit Operating door locks Operating engine switch/depressing brake pedal*1 or clutch pedal*2 Opening or closing doors With engine switch on (IG) or on (ACC), and shift lever in P*1, closing a door when the electrical key transmitter sub-assembly cannot be detected inside the vehicle (continues for 3 seconds until the electrical key transmitter sub-assembly is detected or the engine switch is turned off) Engine switch is off after driving for more than 20 minutes With shift lever not in P*1, closing a door when the electrical key transmitter sub-assembly cannot be detected inside the vehicle (continues for 3 seconds until the electrical key transmitter sub-assembly is detected)*1 When electrical key transmitter sub-assembly is not detected inside passenger compartment while car is being driven (transmits for 4 seconds) Inside Luggage Compartment Does not transmit Operating door locks/pressing the luggage electrical key switch Closing the luggage compartment door Opening or closing doors Does not transmit Outside Vehicle (1) When door is locked, transmits at 250 ms intervals (stops when door is unlocked) (2) Does not transmit (1) Touch the lock sensor (2) Luggage electrical key switch is pressed (3) Touch the unlock sensor in power saving mode Does not transmit *1: except Manual Transaxle *2: for Manual Transaxle
3. BASIC PRECAUTIONS DTC numbers and ECU Data Lists of the smart key system can be checked using the Techstream. Check for DTCs using the following procedure. If any DTCs are output, diagnose those DTCs first. Connect the Techstream to the DLC3. Turn the engine switch on (IG). Enter the following menus: Body Electrical / Smart Key, Power Source Control or Starting Control / Trouble Codes. When using the Techstream with the engine switch off, connect the Techstream to the DLC3 and turn a courtesy light switch on and off at intervals of 1.5 seconds or less until communication between the Techstream and the vehicle begins. Then select the vehicle type under manual mode and enter the following menus: Body Electrical / Smart Key. While using the Techstream, periodically turn a courtesy light switch on and off at intervals of 1.5 seconds or less to maintain communication between the Techstream and the vehicle. If cancel is selected for the smart key system customize setting, cancel the smart key cancel setting. Refer to «CUSTOMIZE PARAMETERS [08/2013 - ]»(ref-635436-S35765981882014070300000)
4. DIAGRAM OF SMART KEY SYSTEM
5. SYSTEM DESCRIPTION The following pattern will be used: "Operation" indicates user operation using the smart key system. "Expected operation of the vehicle" indicates how a known good vehicle will react in accordance with each operation. "Suspected Area/Diagnosis" indicates suspected malfunctioning areas and tips for each diagnosis if the vehicle did not react as expected. Example: Operation No. Operation - Expected operation of the vehicle - Waveform or Output Value - Suspected Area Diagnosis
6. DIAGNOSIS IN ACCORDANCE WITH USER OPERATION Operation 1 Operation Turn the engine switch off and lock all the doors, then take the electrical key transmitter sub-assembly approximately 3 m (9.84 ft.) or more away from the vehicle. HINT: The detection area of each electrical key antenna (outside) is formed by emitting a periodic LF band request signal every 0.25 seconds. The detection area formed by each front door outside handle assembly (electrical key antenna) has a detection range of approximately 0.7 m (2.30 ft.). Waveform or Output Value Pulse generation (E59-12 (CLG1) - E57-11 (E)*) *: Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635436-S01053747492014070300000) Operation 2 Operation Bring the electrical key transmitter sub-assembly within 0.7 m (2.30 ft.) of the driver door. HINT: The system is in unlock standby mode when the electrical key transmitter sub-assembly is in the detection area and the key ID code sent by the electrical key transmitter sub-assembly matches the key ID code stored by the certification ECU (smart key ECU assembly). The door unlocks if the unlock sensor is touched by hand with the system in unlock standby mode. Signal transmission: Certification ECU (smart key ECU assembly) --> Front door outside handle assembly (electrical key antenna) --> Electrical key transmitter sub-assembly --> Door control receiver --> Certification ECU (smart key ECU assembly) --> Main body ECU (multiplex network body ECU) Expected operation of the vehicle The electrical key transmitter sub-assembly LED starts blinking. If it does not, check the suspected areas in the following table. Waveform or Output Value Pulse generation (E59-12 (CLG1) - E57-11 (E)*) Pulse generation (E58-5 (RCO) - E57-11 (E)*) Pulse generation (E58-17 (RDAM) - E57-11 (E)*) Pulse generation (E58-6 (CSEL) - E57-11 (E)*) *: Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635436-S01053747492014070300000) Suspected Area Diagnosis Electrical key transmitter sub-assembly The key ID code sent by the electrical key transmitter sub-assembly does not match the key ID code stored in the certification ECU (smart key ECU assembly). Use another electrical key transmitter sub-assembly to check the operation. If the LED of the electrical key transmitter sub-assembly does not blink when it is brought within 0.7 m (2.30 ft.) of the driver door, perform the following procedure. Press the lock and unlock switches of the electrical key transmitter sub-assembly to check the operation. If the doors can be locked and unlocked, that means the detection area has not been formed. Parts other than the electrical key transmitter sub-assemblies and front door outside handle assemblies may be malfunctioning. If the electrical key transmitter sub-assembly malfunctions, the engine cannot be started and the engine switch cannot be turned on (ACC or IG). Under normal operation, the key warning light in the combination meter assembly blinks in green slowly*1 or "POWER ON" is displayed on the multi-information display in the combination meter assembly*2 when the engine switch is pressed with the electrical key transmitter sub-assembly in the driver seat area, the shift lever in P*3 and the brake pedal*3 or clutch pedal*4 released. If the door cannot be opened, use the mechanical key installed in the electrical key transmitter sub-assembly to open the door. HINT: Before replacing the electrical key transmitter sub-assembly, check if the transmitter battery is depleted. If the door cannot be opened, use the mechanical key installed in the electrical key transmitter sub-assembly to open the door. Transmitter battery is depleted Press and hold the lock switch of the electrical key transmitter sub-assembly for 5 seconds and check the number of times that the electrical key transmitter sub-assembly LED blinks. If the electrical key transmitter sub-assembly LED does not blink or blinks only once or twice, the transmitter battery may be depleted. If the electrical key transmitter sub-assembly LED does not blink at all, the electrical key transmitter sub-assembly may be malfunctioning. If the transmitter battery voltage at the time the electrical key transmitter sub-assembly sends a signal drops to 2.2 V or less, "Yes" is displayed for "Key Low Battery" in the Data List. If the transmitter battery voltage drops to 2.0 V or lower, operation cannot be assured. HINT: The output of the electrical key transmitter sub-assembly will decrease if it is in low temperatures. When the transmitter battery is depleted, the engine cannot be started and the engine switch cannot be turned on (ACC or IG). If the electrical key transmitter sub-assembly is held near the engine switch, the engine can be started. Make sure that the transmitter battery type and installation direction are correct. Wave Interference If the problem occurs in certain locations or times of day, the possibility of wave interference is high. When the electrical key transmitter sub-assembly is malfunctioning, the transmitter battery is depleted, an electrical key transmitter sub-assembly from another vehicle has been used or wave interference is suspected. "Yes" may be displayed for any of the following Data List items: "Unmatch Code or Form", "No Response", "ID Code Difference" or "Unmatched Vehicle-ID" Certification ECU (smart key ECU assembly) - Front door outside handle assembly Vehicle exterior detection area is not formed properly. If the electrical key transmitter sub-assembly LED does not blink within 0.7 m (2.30 ft.) of the front door outside handle assembly (for driver door), but blinks within 0.7 m (2.30 ft.) of the front door outside handle assembly (for front passenger door), the front door outside handle assembly (for driver door) may be malfunctioning. Even if the vehicle exterior detection area is not formed properly, the engine switch can be turned on (ACC) and the engine can be started. Formation of the vehicle exterior detection area can be confirmed by using the Techstream. Refer to «OPERATION CHECK [08/2013 - ]»(ref-635436-S12811079872014070300000) Even if the vehicle exterior detection area is not formed properly, the doors can be unlocked by pressing the unlock switch of the electrical key transmitter sub-assembly. Door Control Receiver If the door control receiver is malfunctioning, it is not possible to unlock the front passenger door. If the door control receiver is malfunctioning, it is not possible to unlock the doors by a wireless unlock operation. If the door control receiver is malfunctioning, the engine cannot be started and the engine switch cannot be turned on (ACC or IG) unless in an emergency. Formation of the vehicle exterior detection area can be confirmed by using the Techstream. Refer to «OPERATION CHECK [08/2013 - ]»(ref-635436-S12811079872014070300000) Vehicle Battery is discharged It may be possible to tell whether the vehicle battery is discharged by operating the horn. Others If the smart key system function has been canceled through the customize function, the detection area cannot be formed, therefore the electrical key transmitter sub-assembly LED will not blink even if the electrical key transmitter sub-assembly is brought near a front door outside handle assembly. In the smart key system, if the electrical key transmitter sub-assembly is constantly in the exterior detection area of one of the doors, the transmitter battery could be drained. For this reason, if this state continues longer than 10 minutes, the smart key system automatically deactivates the exterior detection area that the electrical key transmitter sub-assembly is in. If the electrical key transmitter sub-assembly is in battery saving mode, even if it receives LF waves from the vehicle, it does not respond using RF waves, therefore the electrical key transmitter sub-assembly LED does not blink. If the electrical key transmitter sub-assembly is left in the vehicle and the doors are locked using another electrical key transmitter sub-assembly, the electrical key transmitter sub-assembly LED will not blink even if it is brought near a front door outside handle assembly. *1: w/ Multi-information Display (Segment LCD Type) *2: w/ Multi-information Display (Dot LCD Type) *3: except Manual Transaxle *4: for Manual Transaxle Operation 3 Operation Touch the unlock sensor of the driver door with the electrical key transmitter sub-assembly in the exterior detection area. Expected operation of the vehicle While the doors are unlocked, the answer-back is performed at the same time. If it is not performed, check the suspected areas in the following table. Waveform or Output Value Pulse generation (E59-22 (SEN1) - E57-11 (E)*) Tester Connection "main body ECU (multiplex network body ECU), driver side junction block assembly (ACT-)* *: Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635436-S01053747492014070300000) Suspected Area Diagnosis The suspected parts below overlap with the parts covered in operation 2 for when the electrical key transmitter sub-assembly LED does not blink. - Front door outside handle assembly (for driver door) (unlock sensor) If the doors can be unlocked by touching the unlock sensor of the front passenger door while carrying the electrical key transmitter sub-assembly, the unlock sensor of the driver door may be malfunctioning. Under normal operation, "ON" is displayed for the Data List item "D-Door Touch Sensor" when the unlock sensor is touched. Door lock/unlock mechanism If a door cannot be locked/unlocked by operating the door control switch on the door in the cabin, the door lock mechanism is malfunctioning. Operation 4 Operation After getting into the vehicle while carrying the electrical key transmitter sub-assembly, close the door and press the engine switch once with the shift lever in P*1 while not depressing the brake pedal*1 or clutch pedal*2. Expected operation of the vehicle The key warning light in the combination meter assembly blinks in green slowly*3 or "POWER ON" is displayed*4, and the engine switch is turned on (ACC). The blinking security indicator light goes off, and then the set immobilizer function cancels, allowing the vehicle to be driven. The steering is unlocked. If any of the preceding did not happen, check the suspected areas in the following table. HINT: When the engine switch is pressed, the indoor electrical key antenna forms a key detection area inside the vehicle and detects the electrical key transmitter sub-assembly in the cabin. The electrical key transmitter sub-assembly sends a key ID code upon receiving a request signal and the electrical key transmitter sub-assembly LED illuminates for a short time. After pressing the engine switch, if the key ID code sent by the electrical key transmitter sub-assembly matches the key ID code stored by the certification ECU (smart key ECU assembly), the ACC relay turns on and the key warning light in the combination meter assembly blinks in green slowly*3 or "POWER ON" is displayed on the multi-information display in the combination meter assembly*4. After the power source mode has changed, and L code and S code verification has been completed, the steering will be unlocked and the immobilizer will be inactive. The Data List status of "Immobilizer" will then be changed from "Set" to "Unset".Signal transmission: Certification ECU (smart key ECU assembly) --> Indoor electrical key antenna --> Electrical key transmitter sub-assembly --> Certification ECU (smart key ECU assembly) HINT: The interior detection area is formed when any of the following conditions are met: Door is opened. Within approximately 30 seconds after any of the doors have been opened and closed. The brake pedal*1 or clutch pedal*2 is depressed. Within approximately 30 seconds after the brake pedal*1 or clutch pedal*2 has been depressed. Right after the engine switch is pressed. Waveform or Output Value Pulse generation (E58-17 (RDAM) - E57-11 (E)*5) Pulse generation (E59-3 (CLG5) - E57-11 (E)*5) *1: except Manual Transaxle *2: for Manual Transaxle *3: w/ Multi-information Display (Segment LCD Type) *4: w/ Multi-information Display (Dot LCD Type) *5: Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635436-S01053747492014070300000) Suspected Area Diagnosis Certification ECU (smart key ECU assembly) - Wave Interference If malfunctions occur at a specific location/time, wave interference may be the cause. If wave interference is suspected in the cabin, disconnect all the connectors of electronic devices besides standard equipment, or remove the electronic devices and check for noise. Indoor electrical key antenna assemblies that form the interior detection areas If the interior detection areas are not formed properly, the engine cannot be started and the engine switch cannot be turned on (ACC or IG). If the electrical key transmitter sub-assembly is held near the engine switch in an emergency, the engine can be started. Using the Techstream, enter key diagnostic mode to forcibly form the interior detection area. If the electrical key transmitter sub-assembly is brought near the area, short beeps sound. Refer to «OPERATION CHECK [08/2013 - ]»(ref-635436-S12811079872014070300000) Engine switch Under normal operation, after the engine switch is pressed, "ON" is displayed for the Data List items "Start Switch1" and "Start Switch2". ID code box (immobilizer code ECU) In order to unlock the steering, it is necessary for "S Code Check" in the Date List to display "OK". If "S Code Check" displays "OK", the certification ECU (smart key ECU assembly) code and ID code box (immobilizer code ECU) code match. Park/neutral position switch assembly* Under normal conditions, "Neutral SW/ Clutch SW" in the Data List displays "ON" when the shift lever is moved to P. Steering lock ECU (steering lock actuator assembly) If "OK" is displayed for the Data List item "L Code Check" and "S Code Check" when the engine switch is turned on (ACC), power will be supplied to the steering motor for approximately 10 seconds. Then the ECU sends an unlock signal to the steering motor and the Data List item "Unlock Request Receive" temporarily changes from "NG" to "OK". After the steering unlocks, the ECU receives the unlocked signal from the steering motor and the Data List item "Steering Unlock" changes from "Unset" to "Set". In order to unlock the steering, it is necessary that "OK" is displayed for the Data List item "L Code Check" (the ID code stored in the steering lock ECU (steering lock actuator assembly) matches that of the ID code box (immobilizer code ECU)) *: except Manual Transaxle HINT: The electrical key transmitter sub-assembly, the transmitter battery and the vehicle battery should have already been inspected in the previous operation steps. However, if they have not been inspected, inspect them. Operation 5 Operation Depress the brake pedal*1 or clutch pedal*2 with the shift lever in P while carrying an electrical key transmitter sub-assembly. Expected operation of the vehicle The key warning light in the combination meter assembly blinks in green*3 or is displayed on the multi-information display*4. If it does not, check the suspected areas in the following table. *1: except Manual Transaxle *2: for Manual Transaxle *3: w/ Multi-information Display (Segment LCD Type) *4: w/ Multi-information Display (Dot LCD Type) Suspected Area Diagnosis Stop light switch assembly*1 If the brake pedal is depressed, "ON" is displayed for the Data List item "Stop Light Switch1". Clutch start switch assembly*2 If the clutch pedal is depressed, "ON" is displayed for the Data List item "Neutral SW/ Clutch SW". Certification ECU (smart key ECU assembly) Start function-Terminals of ECU Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635437-S25494866982014070300000) *1: except Manual Transaxle *2: for Manual Transaxle Operation 6 Operation After getting into the vehicle while carrying the electrical key transmitter sub-assembly, press the engine switch with the shift lever in P*1 while depressing the brake pedal*1 or clutch pedal*2. Expected operation of the vehicle The engine starts. If it does not, check the suspected areas in the following table. *1: except Manual Transaxle *2: for Manual Transaxle Suspected Area Diagnosis Steering lock system Under normal operation, the steering will be unlocked and "ON" is displayed for the Data List item "Steering Unlock Switch". Vehicle Battery is discharged Whether the vehicle battery is discharged or not can be checked easily by operating the horn. Operation 7 Operation Press the engine switch. Expected operation of the vehicle The engine stops, the key warning light illuminates and then goes off and the security indicator light changes from off to blinking. Operation 8 Operation Open any of the doors with the engine switch off. Expected operation of the vehicle The steering locks. If it does not, check the suspected areas in the following table. Suspected Area Diagnosis Steering lock system - Door courtesy light switch assembly When any of the doors are opened, "ON" is displayed for the Data List item "FL Door Courtesy SW". Operation 9 Operation Touch the lock sensor of the driver door outside handle while carrying the electrical key transmitter sub-assembly. Expected operation of the vehicle Answer-back is performed at the same time as the doors are locked.
7. VEHICLE BATTERY SAVING FUNCTION When the smart key system is operating, the vehicle performs key detection operations every 0.25 seconds. Therefore, if the vehicle is left as is for a long period of time, the vehicle battery may become fully discharged. The following controls help reduce the rate at which the vehicle battery is discharged. If the smart key system is not operated for 5 days or more, periodic signal transmission from the electrical key antennas stops. However, the doors can still be unlocked by touching the unlock sensor of a front door outside handle assembly. If the smart key system is not operated for 14 days or more, the lock and unlock sensors of the outside handle assembly (for front passenger door) are disabled. Therefore, only the unlock sensor of the front door outside handle assembly (for driver door) can be used to unlock the doors. If 10 minutes or more elapse while the electrical key transmitter sub-assembly is in an exterior detection area, the front door outside handle assembly (electrical key antenna) detecting the electrical key transmitter sub-assembly will stop operating. To restore operation of the smart key system, perform any of the following operations. While carrying the electrical key transmitter sub-assembly, touch the lock or unlock sensor of the front door outside handle assembly (for driver door) and perform a door lock or unlock operation. Lock or unlock the doors with the wireless operation. Insert the mechanical key into the door key cylinder of the driver door and lock or unlock the doors.
8. WIRELESS DOOR LOCK BUZZER VOLUME ADJUSTMENT FUNCTION The volume of the wireless door lock buzzer can be changed through the customize function. HINT: The volume of the following wireless door lock buzzer operations cannot be adjusted. Warning function buzzer operations Customize function buzzer operations Buzzer operations for key diagnostic mode using the Techstream Key registration buzzer operations
9. WARNING FUNCTION Warning When any of the situations below occur, the smart key system causes the certification ECU (smart key ECU assembly) to sound the wireless door lock buzzer and a buzzer in the combination meter assembly, and display a message on the multi-information display*1 or illuminate the key warning light in the combination meter assembly*2 in order to alert the driver. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The engine is left running and the shift lever is in a position other than P when the driver gets out of the vehicle. (except Manual Transaxle) There are 2 patterns for this situation. Pattern 1: When the engine is left running and the shift lever is in a position other than P, the driver opens the door and attempts to get out of the vehicle. In this situation, the following control is performed: Possible effects without warning Sudden vehicle start, vehicle theft, vehicle roll-away Warning Start Condition (All conditions are met) The engine switch is on (ACC) or on (IG). The shift lever is in a position other than P. The driver door is opened. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds continuously. "SHIFT TO P POSITION" is displayed on the multi-information display in the combination meter assembly.* Warning Stop Condition (One condition is met) The engine switch is turned off. The shift lever is in P. The driver door is closed. The vehicle speed is 5 km/h (3.11 mph) or more. *: w/ Multi-information Display (Dot LCD Type) Pattern 2: Under the situation of pattern 1, the driver closes the door and attempts to leave the vehicle while holding the electrical key transmitter sub-assembly. In this situation, the following control is performed: Possible effects without warning Sudden vehicle start, vehicle theft, vehicle roll-away Warning Start Condition (All conditions are met) The engine switch is on (ACC) or on (IG). The shift lever is in a position other than P. The driver door is opened --> closed. The electrical key transmitter sub-assembly is not in the vehicle. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds continuously. The wireless buzzer sounds continuously. "SHIFT TO P POSITION" is displayed on the multi-information display in the combination meter assembly for 60 seconds. [A]*1 "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly. [B]*1 The key warning light in the combination meter assembly flashes in orange. [C]*2 Warning Stop Condition (One condition is met) The engine switch is turned off ([A] continues to be displayed).*1 The electrical key transmitter sub-assembly is returned to the vehicle ([A] continues to be displayed).*1 The vehicle speed is 5 km/h (3.11 mph) or more ([B]*1 or [C]*2 continues to be displayed). The shift lever is in P ([B]*1 or [C]*2 continues to be displayed). *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The key reminder sounds. When the driver door is open, the driver turns the engine switch on (ACC) and attempts to leave the vehicle. Possible effects without warning Vehicle theft Warning Start Condition (Either Condition 1 or 2 is met) Condition 1 The shift lever is in P.* The engine switch is on (ACC). The driver door is opened. Condition 2 (Approval for 1 second or more) The shift lever is in P.* The engine switch is off. The steering is unlocked. The driver door is opened. Warning description The buzzer in the combination meter assembly sounds continuously at short and even intervals. Warning Stop Condition (One condition is met) The warning is stopped when any of the following conditions is met: The engine switch is turned on (IG). The driver door is closed. The engine switch is turned off and the steering is locked. *: except Manual Transaxle Situation: The engine is left running with the shift lever in P*1 when the driver gets out of the vehicle. There are 2 patterns for this situation. Pattern 1: When the engine is left running with the shift lever in P*1, the driver closes the driver door and attempts to leave the vehicle while carrying the electrical key transmitter sub-assembly. In this situation, the following control is performed: Possible effects without warning Vehicle theft, engine cannot be restarted, discharged vehicle battery Warning Start Condition (All conditions are met) The engine switch is on (ACC) or on (IG). The shift lever is in P.*1 The driver door is opened --> closed. The electrical key transmitter sub-assembly is not in the vehicle. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds once. The wireless buzzer sounds 3 times. "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly.*2 The key warning light in the combination meter assembly flashes in orange.*3 Warning Stop Condition (Either condition is met) The engine switch is turned off. The electrical key transmitter sub-assembly is returned to the vehicle. Pattern 2: Under the situation of pattern 1, the driver touches the lock sensor on a front door outside handle assembly. In this situation, the following control is performed: Possible effects without warning Vehicle theft, engine cannot be restarted, discharged vehicle battery Warning Start Condition (All conditions are met) The engine switch is on (ACC) or on (IG). The shift lever is in P.*1 The electrical key transmitter sub-assembly is not in the interior detection areas. The electrical key transmitter sub-assembly is in the exterior detection areas. The lock sensor is on. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds once. The wireless buzzer sounds continuously. "TURN POWER OFF" is displayed on the multi-information display in the combination meter assembly for 60 seconds. [A]*2 "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly. [B]*2 The key warning light in the combination meter assembly flashes in orange.*3 Warning Stop Condition (One condition is met) The engine switch is turned off. With the shift lever in P, the shift lever is moved to a position other than P ([B] continues to be displayed).*1,*2 The vehicle speed is 5 km/h (3.11 mph) or more ([B] continues to be displayed).*2 5 seconds have elapsed after the wireless door lock buzzer is activated (only wireless buzzer stops). Any door is opened or closed (only wireless buzzer stops). The electrical key transmitter sub-assembly is returned to the vehicle ([A] continues to be displayed).*2 *1: except Manual Transaxle *2: w/ Multi-information Display (Dot LCD Type) *3: w/ Multi-information Display (Segment LCD Type) Situation: The engine is left running when a passenger gets out of the vehicle while carrying the electrical key transmitter sub-assembly. When the engine is left running, a passenger leaves the vehicle while carrying the electrical key transmitter sub-assembly. In this situation, the following control is performed: Possible effects without warning Engine cannot be restarted Warning Start Condition (All conditions are met) The engine switch is on (ACC) or on (IG). A door other than the driver door is opened --> closed. The electrical key transmitter sub-assembly is not in the vehicle. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds once. The wireless buzzer sounds 3 times. "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly.*1 The key warning light in the combination meter assembly flashes in orange.*2 Warning Stop Condition (Either condition is met) The engine switch is turned off. The electrical key transmitter sub-assembly is returned to the vehicle. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The electrical key transmitter sub-assembly is not in the interior or exterior detection areas. When the electrical key transmitter sub-assembly is not in the vehicle or the transmitter battery is depleted, the driver attempts to start the engine or turn the engine switch on (IG). In this situation, the following control is performed: Possible effects without warning Confuses the user Warning Start Condition (All conditions are met) A door is not unlocked using the mechanical key and the engine switch is pressed. The electrical key transmitter sub-assembly is not in the vehicle or the transmitter battery is depleted. The immobilizer system is set. Warning description The buzzer in the combination meter assembly sounds once. "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly for 15 seconds.*1 The key warning light in the combination meter assembly flashes in orange.*2 Warning Stop Condition (Either condition is met) The electrical key transmitter sub-assembly is returned to the vehicle. 30 seconds have elapsed after the door is opened *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The vehicle is driven without a registered electrical key transmitter sub-assembly. In this situation, the following control is performed: Possible effects without warning Engine cannot be restarted Warning Start Condition (All conditions are met) The engine switch is on (IG). Warning indicating that the electrical key transmitter sub-assembly is being brought out of vehicle is output. The vehicle speed is 5 km/h (3.11 mph) or more. The electrical key transmitter sub-assembly is not in the vehicle. Warning description The buzzer in the combination meter assembly sounds nine times. "KEY NOT DETECTED" is displayed on the multi-information display in the combination meter assembly.*1 The key warning light in the combination meter assembly flashes in orange.*2 Warning Stop Condition (Either condition is met) The engine switch is turned off. The electrical key transmitter sub-assembly is returned to the vehicle. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The electrical key transmitter sub-assembly is left in the vehicle. The lock sensor on a door outside handle assembly is touched to perform entry lock with the electrical key transmitter sub-assembly left in the vehicle. In this situation, the following control is performed: Possible effects without warning Vehicle theft Warning Start Condition (All conditions are met) The engine switch is off. All doors are closed. The electrical key transmitter sub-assembly is in the vehicle. The lock sensor on a front door outside handle assembly is on (touched). Any door is unlocked. No vehicle speed is detected. Warning description The wireless buzzer sounds continuously for 5 seconds. "KEY DETECTED IN VEHICLE" is displayed on the multi-information display in the combination meter assembly for 60 seconds.* Warning Stop Condition (One condition is met) The engine switch is turned to a mode other than off. The vehicle speed is 5 km/h (3.11 mph) or more. Lock operation is detected. Any door is opened (only wireless buzzer stops). *: w/ Multi-information Display (Dot LCD Type) Situation: Door is ajar. The lock sensor on the front door outside handle assembly is touched to perform entry lock with a door open. In this situation, the following control is performed: Possible effects without warning Vehicle theft Warning Start Condition (All conditions are met) The engine switch is off. The engine switch is on (ACC) or on (IG). Any door other than the door that performed the entry lock operation is open. The lock sensor is on or lock switch is pressed on the electrical key transmitter sub-assembly. The electrical key transmitter sub-assembly is in an exterior detection area. Warning description The wireless buzzer sounds continuously for 5 seconds. Warning Stop Condition (One condition is met) The engine switch is turned to a mode other than off. All doors are closed. An unlock operation is performed using the wireless door lock remote function. The touch sensor on the inner side of a door outside handle assembly is used to perform entry unlock. Situation: The electrical key transmitter sub-assembly is left in the luggage compartment. The luggage compartment door is closed with the electrical key transmitter sub-assembly left in the luggage compartment. In this situation, the following control is performed: Possible effects without warning Vehicle theft Warning Start Condition (All conditions are met) No vehicle speed is detected. Entry luggage door open function is available. All doors are closed and all doors are locked or in the state where the doors are waiting to be opened after an unlock operation. The luggage compartment door is opened --> closed. The electrical key transmitter sub-assembly is in the luggage compartment. Warning description Wireless buzzer sounds continuously for 5 seconds. Warning Stop Condition (Either condition is met) The vehicle speed is 5 km/h (3.11 mph) or more. The luggage compartment door is opened. Situation: The electrical key transmitter sub-assembly is locked inside the vehicle. With a door open and the electrical key transmitter sub-assembly in the vehicle, the lock knob is locked and then the door is closed with the door handle being pulled. In this situation, the following control is performed: Possible effects without warning Vehicle theft Warning Start Condition (All conditions are met) With a door open, the lock knob is locked and then the door is closed with the front door outside handle assembly being pulled. The electrical key transmitter sub-assembly is in the vehicle. No vehicle speed is detected. Warning description The buzzer in the combination meter assembly sounds once. The wireless buzzer sounds continuously for 5 seconds. "KEY DETECTED IN VEHICLE" is displayed on the multi-information display in the combination meter assembly for 60 seconds.* Warning Stop Condition (One condition is met) The engine switch is turned to a mode other than off. Any door is opened (only wireless buzzer stops). Lock operation is detected. The vehicle speed is 5 km/h (3.11 mph) or more. *: w/ Multi-information Display (Dot LCD Type) Situation: The transmitter battery is weak. The vehicle is driven using an electrical key transmitter sub-assembly that has a low transmitter battery. In this situation, the following control is performed: Possible effects without warning Depleted transmitter battery, engine cannot be restarted Warning Start Condition (Either Condition 1 or 2 is met) Condition 1 The engine switch is turned off after being left on (IG) for more than 20 minutes. The transmitter battery voltage is low. The electrical key transmitter sub-assembly is in the vehicle. No vehicle speed is detected. Condition 2 The engine is off --> the engine is started. The transmitter battery voltage is low. The electrical key transmitter sub-assembly is in the vehicle. No vehicle speed is detected. Condition 1 has been met (past). Warning description The buzzer in the combination meter assembly sounds once. "KEY BATTERY LOW" is displayed on the multi-information display in the combination meter assembly for 15 seconds.*1 The key warning light in the combination meter assembly flashes in orange for 15 seconds.*2 Warning Stop Condition (Either condition is met) The vehicle speed is 5 km/h (3.11 mph) or more. The transmitter battery is replaced with a new one. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The steering cannot be unlocked. The steering cannot be unlocked, thus the engine is prevented from starting. The shift lever is moved to a position other than P*1 before the steering is unlocked. In this situation, the following control is performed: Possible effects without warning User does not notice that the steering is locked Warning Start Condition Steering cannot be unlocked. Warning description The buzzer in the combination meter assembly sounds once. "STEERING LOCK ACTIVE" is displayed on the multi-information display in the combination meter assembly for 15 seconds.*2 The key warning light in the combination meter assembly blinks in green.*3 Warning Stop Condition The steering is unlocked. *1: except Manual Transaxle *2: w/ Multi-information Display (Dot LCD Type) *3: w/ Multi-information Display (Segment LCD Type) Situation: The smart key system is malfunctioning. An IG circuit malfunction, vehicle speed signal malfunction or a malfunction that interferes with the steering lock ECU (steering lock actuator assembly) operation has been detected. In this situation, the following control is performed: Possible effects without warning Malfunction cannot be detected Warning Start Condition (One condition is met) The steering lock ECU (steering lock actuator assembly), driver of the certification ECU (smart key ECU assembly) or unlock detection switch is malfunctioning. An IG relay output circuit malfunction occurs 3 times or more consecutively. The vehicle speed is judged as abnormal or vehicle speed signal communication is malfunctioning. Warning description The buzzer in the combination meter assembly sounds once. "CHECK SMART KEY SYSTEM" is displayed on the multi-information display in the combination meter assembly for 15 seconds.*1 The key warning light in the combination meter assembly flashes in orange for 15 seconds.*2 Warning Stop Condition The system returns to normal. *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) Situation: The engine does not start. (Situation A) When the engine switch is pressed, the electrical key transmitter sub-assembly cannot be detected in the vehicle two times in a row. In this situation, the following control is performed: Possible effects without warning Engine cannot be restarted Warning Start Condition (One condition is met) The immobilizer system is set. The electrical key transmitter sub-assembly is not in the vehicle. Key code verification error occurs when the engine switch is pressed twice or the driver door key linked unlock operation is performed. Warning description The buzzer in the combination meter assembly sounds once. "DEPRESS BRAKE PEDAL, TOUCH ENGINE SWITCH WITH KEY" is displayed on the multi-information display in the combination meter assembly for 60 seconds.*1,*3 "DEPRESS CLUTCH PEDAL, TOUCH ENGINE SWITCH WITH KEY" is displayed on multi-information display in the combination meter assembly for 60 seconds.*1,*4 The key warning light in the combination meter assembly flashes in orange for 60 seconds.*2 Warning Stop Condition (Either condition is met) The electrical key transmitter sub-assembly is returned to the vehicle. 30 seconds have elapsed after a door is opened *1: w/ Multi-information Display (Dot LCD Type) *2: w/ Multi-information Display (Segment LCD Type) *3: except Manual Transaxle *4: for Manual Transaxle Situation: The engine does not start. (Situation B) (w/ Multi-information Display (Dot LCD Type)) There are 2 patterns for this situation. Pattern 1: A warning message appears on the multi-information display when the driver does not follow the proper procedure to start the vehicle. In this situation, the following control is performed: Possible effects without warning Engine cannot be restarted Warning Start Condition (All conditions are met) The engine switch is off. Driver door is closed --> opened. The engine switch is turned from off to on (ACC) more than twice with the engine off and the brake pedal*1 or clutch pedal*2 released. Warning description The buzzer in the combination meter assembly sounds once. "DEPRESS BRAKE PEDAL AND PUSH ENGINE SWITCH TO START" is displayed on the multi-information display in the combination meter assembly for 5 seconds.*1 "DEPRESS CLUTCH PEDAL AND PUSH ENGINE SWITCH TO START" is displayed on the multi-information display in the combination meter assembly for 5 seconds.*2 Warning Stop Condition (Either condition is met) The engine switch is turned off. The engine switch is turned on (IG). *1: except Manual Transaxle *2: for Manual Transaxle Pattern 2: A message indicating how to start the engine appears on the multi-information display when the shift lever is in a position in which the engine cannot be started. (except Manual Transaxle) In this situation, the following control is performed: Possible effects without warning Engine cannot be restarted Warning Start Condition (All conditions are met) The engine is stopped. No vehicle speed is detected. More than 0.5 seconds have elapsed after the engine switch is turned on (IG). The shift lever is in a position other than P or N. The starter is not operating. Warning description The buzzer in the combination meter assembly sounds once. "SHIFT TO P POSITION TO START" is displayed on the multi-information display in the combination meter assembly. Warning Stop Condition (One condition is met) The shift lever is in P or N. The vehicle speed is 5 km/h (3.11 mph) or more. The power source mode is changed to any mode other than on (IG). The engine is started. Situation: The engine switch cannot be turned off. (except Manual Transaxle and w/ Multi-information Display (Dot LCD Type)) There are 2 patterns for this situation. Pattern 1: A warning message appears on the multi-information display when the driver attempts to turn the engine switch off with the shift lever in any position other than P or N In this situation, the following control is performed: Possible effects without warning Discharged vehicle battery, vehicle roll-away Warning Start Condition (Both conditions are met) The shift lever is in any position other than P or N. Even though the engine switch is pressed, the power source mode does not change to off (excluding emergency stop operation). Warning description The buzzer in the combination meter assembly sounds once. "SHIFT TO P POSITION" is displayed on the multi-information display in the combination meter assembly. Warning Stop Condition (Either condition is met) The engine switch is turned to a mode other than on (ACC). The shift lever is moved to P. Pattern 2: Under the situation of pattern 1, the shift lever is moved to P. In this situation, the following control is performed: Possible effects without warning Discharged vehicle battery, vehicle roll-away Warning Start Condition The shift lever is moved to P. Warning description The buzzer in the combination meter assembly sounds once. "TURN POWER OFF" is displayed on the multi-information display in the combination meter assembly. Warning Stop Condition (Either condition is met) The power source mode is changed to a mode other than on (ACC). The shift lever is in any position other than P. Situation: Auto power off operation occurs. (except Manual Transaxle) A warning message appears on the multi-information display when automatic power off operation occurs. In this situation, the following control is performed: Possible effects without warning Discharged vehicle battery Warning Start Condition (All conditions are met) The shift lever is in P. The engine switch is on (ACC) or on (IG). No vehicle speed is detected. The engine is stopped. The power source control system is turned off by automatic power off function. Warning description "AUTO POWER OFF TO CONSERVE BATTERY" is displayed on the multi-information display in the combination meter assembly for 10 seconds.* Warning Stop Condition The engine switch is turned on (ACC) or on (IG). *: w/ Multi-information Display (Dot LCD Type) Situation: Immobilizer system certification completion occurs. (w/ Multi-information Display (Dot LCD Type)) When an electrical key transmitter sub-assembly with a depleted transmitter battery is held near the engine switch while depressing the brake*1 or clutch pedal*2. In this situation, the following control is performed: Possible effects without warning Malfunction cannot be detected Warning Start Condition Electrical key transmitter sub-assembly certification result is OK. Warning description The buzzer in the combination meter assembly sounds once. "DEPRESS BRAKE PEDAL AND PUSH ENGINE SWITCH TO START" is displayed on the multi-information display in the combination meter assembly for 10 seconds.*1 "DEPRESS CLUTCH PEDAL AND PUSH ENGINE SWITCH TO START" is displayed on the multi-information display in the combination meter assembly for 10 seconds.*2 Warning Stop Condition (One of conditions is met) The electrical key transmitter sub-assembly is detected by the vehicle. The engine speed is at 500 rpm or more. The engine is started. The immobilizer system is set and key recognition is stopped or the key cannot be recognized. *1: except Manual Transaxle *2: for Manual Transaxle

CAUTION / NOTICE / HINT

HINT

1. Use these procedures to troubleshoot the smart key system (for Entry Function).
2. *: Use the Techstream.

PROCEDURE

1. VEHICLE BROUGHT TO WORKSHOP Result Proceed to NEXT Result: 1 NEXT See step 2
2. CUSTOMER PROBLEM ANALYSIS HINT: In troubleshooting, confirm that the problem symptoms have been accurately identified. Preconceptions should be discarded in order to make an accurate judgment. To clearly understand what the problem symptoms are, it is extremely important to ask the customer about the problem and the conditions at the time the malfunction occurred. Gather as much information as possible for reference. Past problems that seem unrelated may also help in some cases. The following 5 items are important points for problem analysis: What? Vehicle model, system name When? Date, time, occurrence frequency, whether the problem occurred recently or has been occurring for a long time Where? Whether the problem occurs at a specific location Under what conditions? Whether the doors were locked or unlocked, whether the engine switch was on, whether the engine was running How did it happen? Problem symptoms* *: Be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem, and then check for DTCs. If the entry lock/unlock function does not operate for all doors. If the entry lock function does not operate. If the entry unlock function does not operate. If both the entry lock and unlock functions do not operate. If the wireless lock and unlock functions do not operate. If there is no power even when the engine switch is pressed (does not turn on (ACC)). If the engine does not start with the push-button start function. If the outside warning buzzers do not sound. If an engine start was attempted by holding the electrical key transmitter sub-assembly near the engine switch and then pressing the engine switch. If the interior warning buzzers do not sound. If the steering does not unlock. Any other details concerning the problem. If it is suspected that wave interference is likely, be sure to ask the customer in detail about the following points concerning the vehicle operating conditions, environment and problem. Specific locations where the system does not operate (such as near TV towers, large video displays, wireless garage door opener systems, wireless security cameras, home security systems, etc.). Specific times when the system does not operate: If the symptoms occurred immediately after purchase or only recently. If the symptoms occurred when the electrical key transmitter sub-assembly was near the vehicle (electrical key antenna). If the system does not operate only when near specific vehicles (there may be wave interference from the wireless systems of other vehicles). If the system operates intermittently. If the electrical key transmitter sub-assembly is bundled together with other items. If the electrical key transmitter sub-assembly is carried together with other electronic devices, such as cell phones, personal computers, portable music players, other electrical key transmitter sub-assemblies, etc. (keep the electrical key transmitter sub-assembly at least 0.1 m (0.328 ft.) away from such items). Where the electrical key transmitter sub-assembly is being kept when not in use: If the electrical key transmitter sub-assembly is being placed within 1 m (3.28 ft.) of items such as TVs, DVD recorders, induction cookers, rice cookers, dishwashers, modems, cell phones, personal computers, microwave ovens, desk or floor lamps, cordless telephones, etc. If there are electronic devices that transmit radio waves placed in the vehicle. When the transmitter battery was last replaced. The transmitter battery can be checked roughly using the "Key Low Battery" item in the Data List. Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635436-S13844987652014070300000) If the steering does not unlock. If the customer installed any optional components (theft deterrent devices, wireless fog lights, etc.) to the vehicle. Result Proceed to NEXT Result: 1 NEXT See step 3
3. INSPECT BATTERY VOLTAGE Measure the vehicle battery voltage. Standard Voltage 11 to 14 V If the voltage is below 11 V, recharge or replace the vehicle battery before proceeding to the next step. Result Proceed to NEXT Result: 1 NEXT See step 4
4. CHECK COMMUNICATION FUNCTION OF CAN COMMUNICATION SYSTEM* Using the Techstream, check for CAN communication system DTCs. Refer to «DIAGNOSIS SYSTEM [08/2013 - 04/2014]»(ref-635647-S40458511452014070300000) Refer to «DIAGNOSIS SYSTEM [04/2014 - ]»(ref-635652-S02842089492014070300000) Result Result Proceed to CAN DTCs are not output A CAN DTCs are output B Result: 2 B GO TO CAN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635647-S27781195552014070300000) Result: 1 A See step 5
5. CHECK METER / GAUGE SYSTEM* Use the Techstream to check if the meter/gauge system is functioning normally. HINT: If the certification ECU (smart key ECU assembly) mistakenly receives a vehicle speed signal, communication between the vehicle and the Techstream fails. Be sure to check "Vehicle Speed Meter" displayed on the Data List to make sure that the vehicle speed is not abnormal. Result Result Proceed to No vehicle speed signal is mistakenly received A A vehicle speed signal is mistakenly received B Result: 2 B GO TO METER / GAUGE SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635440-S29828934222014070300000) Result: 1 A See step 6
6. CHECK COMMUNICATION FUNCTION OF LIN COMMUNICATION SYSTEM* Using the Techstream, check for LIN communication system DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635671-S21721299832014070300000) Result Result Proceed to LIN DTCs are not output A LIN DTCs are output B Result: 2 B GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635671-S22380098072014070300000) Result: 1 A See step 7
7. CHECK FUNCTION OF WIRELESS DOOR LOCK CONTROL SYSTEM* Using the Techstream, check for wireless door lock control system DTCs. Refer to «DTC CHECK / CLEAR [08/2013 - ]»(ref-635434-S12614025772014070300000) Result Result Proceed to Wireless door lock control system DTCs are not output A Wireless door lock control system DTCs are output B Result: 2 B GO TO WIRELESS DOOR LOCK CONTROL SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635434-S39025295262014070300000) Result: 1 A See step 8
8. CHECK FOR DTC* Check for DTCs. Body Electrical > Smart Key > Trouble Codes Result Result Proceed to DTCs are not output A Steering lock system DTCs are output B Immobilizer system DTCs are output C Smart key system (for Entry Function) DTCs are output D Result: 2 B GO TO STEERING LOCK SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635670-S06260758792014070300000) Result: 3 C GO TO IMMOBILISER SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING [08/2013 - ]»(ref-635449-S12285965332014070300000) Result: 4 D GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635436-S23611357552014070300000) Result: 1 A See step 9
9. PROBLEM SYMPTOMS TABLE Refer to Problem Symptoms Table. Refer to «PROBLEM SYMPTOMS TABLE [08/2013 - ]»(ref-635436-S32400603432014070300000) Result Result Proceed to Fault is not listed in Problem Symptoms Table A Fault is listed in Problem Symptoms Table B Result: 2 B See step 11 Result: 1 A See step 10
10. OVERALL ANALYSIS AND TROUBLESHOOTING* Operation Check Refer to «OPERATION CHECK [08/2013 - ]»(ref-635436-S12811079872014070300000) Data List / Active Test Refer to «DATA LIST / ACTIVE TEST [08/2013 - ]»(ref-635436-S13844987652014070300000) Terminals of ECU Refer to «TERMINALS OF ECU [08/2013 - ]»(ref-635436-S01053747492014070300000) Result Proceed to NEXT Result: 1 NEXT See step 11
11. REPAIR OR REPLACEMENT Result Proceed to NEXT Result: 1 NEXT See step 12
12. CHECK FOR DTC* Clear the DTCs. Body Electrical > Smart Key > Clear DTCs Check for DTCs. Body Electrical > Smart Key > Clear DTCs Result Result Proceed to DTCs are not output A Smart key system (for Entry Function) DTCs are output B Result: 1 A END Result: 2 B GO TO DIAGNOSTIC TROUBLE CODE CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART [08/2013 - ]»(ref-635436-S23611357552014070300000)

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. CHECK SMART KEY SYSTEM (for Entry Function) OPERATION NOTE: Make sure that the smart key system (for Entry Function) has not been canceled before performing this inspection. Check the entry unlock function (driver door, front passenger door). Perform a wireless lock operation to lock the door, touch the unlock sensor built into the backside of the front door outside handle assembly (for driver door) while carrying the electrical key transmitter sub-assembly and check that the door unlocks. HINT: To perform a wireless lock operation, press the lock button of the electrical key transmitter sub-assembly while standing near the front door outside handle assembly (for driver door). Inspect the entry unlock detection area. Hold the electrical key transmitter sub-assembly at the same height as the front door outside handle assembly (for driver door) and approximately 0.7 to 1 m (2.30 to 3.28 ft.) from the vehicle as shown in the illustration and check that the LED (red) of the electrical key transmitter sub-assembly blinks. *a 0.7 to 1 m (2.30 to 3.28 ft.) With the system in unlock standby mode, grasp the front door outside handle assembly (for driver door) and check that the door unlocks. HINT: The system is in unlock standby mode when the electrical key transmitter sub-assembly is in the detection area and the key ID code sent by the electrical key transmitter sub-assembly matches the key ID code stored by the certification ECU (smart key ECU assembly). Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the front door outside handle assembly (for driver door). Inspect the front passenger door using the same procedure. Check the unlock response sensitivity. With the system in unlock standby mode, touch the area shown in the illustration and check that the door unlocks. NOTE: If the sensor is touched too quickly or released too slowly, the sensor may not react and the door will not unlock. *a Unlock Sensor (Backside) Check the entry lock function (driver door, front passenger door). NOTE: If the electrical key transmitter sub-assembly is in the vehicle but outside the detection area (on the instrument panel, in the glove box or on the floor) and a door lock operation is performed, the key lock-in prevention function will not operate and the electrical key transmitter sub-assembly will be locked inside the vehicle. *a Lock Sensor With the door closed and unlocked, touch the lock sensor of the front door outside handle assembly (for driver door) while carrying the electrical key transmitter sub-assembly and check that the door locks. HINT: If the door does not lock even when touching the lock sensor, touch it with your palm. Inspect the entry lock operating range. Hold the electrical key transmitter sub-assembly approximately 0.1 m (0.328 ft.) below the bottom edge of the door glass and approximately 0.7 to 1 m (2.30 to 3.28 ft.) from the vehicle as shown in the illustration, touch the lock sensor and check that the door locks. *a 0.7 to 1 m (2.30 to 3.28 ft.) HINT: If the door does not lock even when touching the lock sensor, touch it with your palm. As communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the front door outside handle assembly, the door may not lock if the lock sensor is touched with the same hand that is carrying the electrical key transmitter sub-assembly, etc. If the key lock-in prevention function buzzer sounds, radio waves from the indoor electrical key antenna may be leaking from the vehicle. Inspect the front passenger door using the same procedure. The door lock operation cannot be performed more than 3 times consecutively. Check the entry luggage door open function. Perform a wireless lock operation to lock the doors, operate of the luggage electrical key switch while carrying the electrical key transmitter sub-assembly and check that the luggage compartment door opens. *1 Luggage Electrical Key Switch *a 0.7 to 1 m (2.30 to 3.28 ft.) Inspect the entry luggage door open operating range. While standing at the rear of the vehicle, hold the electrical key transmitter sub-assembly so that it is facing the direction shown in the illustration at the same height as the luggage electrical key switch and approximately 0.7 to 1 m (2.30 to 3.28 ft.) from the vehicle, press the luggage electrical key switch and check that the luggage compartment door opens. Check the key lock-in prevention function (vehicle interior). NOTE: In order to prevent the electrical key transmitter sub-assembly from being locked inside the vehicle, perform this inspection with the window of a door open. Turn the engine switch off. Place the electrical key transmitter sub-assembly on a front or rear seat. Close the door, making sure the doors are unlocked. Touch a door lock sensor and check that the doors do not lock and the key lock-in prevention function buzzer (external) sounds for approximately 5 seconds. Check the key lock-in prevention function (in luggage compartment). Place the electrical key transmitter sub-assembly in the luggage compartment with all doors locked. Check that: 1) closing the luggage compartment door sounds the wireless buzzer (for approximately 2 seconds), and 2) pressing the luggage electrical key switch opens the luggage compartment door. Inspect the key lock-in prevention detection area. Pay attention to the direction of the electrical key transmitter sub-assembly shown in the illustration. When the electrical key transmitter sub-assembly is in either of the 2 locations in the illustration, check that: 1) closing the luggage compartment door sounds the wireless buzzer, and 2) pressing the luggage electrical key switch opens the luggage compartment door. *a Inspection Point NOTE: In order to prevent the electrical key transmitter sub-assembly from being locked inside the vehicle, perform this inspection with the window of a door open. If the electrical key transmitter sub-assembly is in any of the following locations, the key lock-in prevention function may not operate: Near the spare tire or at the edge of the luggage compartment. In a metal bag or near a metal object. HINT: Perform the inspection for both inspection points. Inspect the key lock-in prevention detection area and the door control receiver for wave leaks. Hold the electrical key transmitter sub-assembly at the same height as the lower edge of the luggage compartment door aligning it with the center of the rear of the vehicle. Pay attention to the direction and position of the electrical key transmitter sub-assembly shown in the illustration. *a 0.1 m or more (0.328 ft. or more) HINT: When the electrical key transmitter sub-assembly is over 0.1 m (0.328 ft.) from the rear bumper, the wireless buzzer does not sound. If the wireless buzzer sounds, the No. 3 indoor electrical key antenna assembly (inside luggage compartment) may have a wave leak. Check the push-button start function. (except Manual Transaxle) With the engine switch off, move the shift lever to P, depress the brake pedal while carrying the electrical key transmitter sub-assembly. Then, press the engine switch and check that the engine starts. With the brake pedal released and the engine switch off, press the engine switch while carrying the electrical key transmitter sub-assembly and check that the power source mode changes as follows: off --> on (ACC) --> on (IG) --> off. When the engine switch is pressed with the engine switch on (IG) and the shift lever not in P, the power source mode does not change to off, but changes to on (ACC). Stop the vehicle, press the engine switch and check that the power source mode changes to off (the engine stops and all electrical systems turn off). With the shift lever in P, check that the steering lock operates when a door is opened. When the engine switch is pressed after the vehicle is stopped, the engine stops and all the power turns off. However, if the shift lever is not in P when the engine switch is pressed with the vehicle stopped, the power source mode does not change to off, but changes to on (ACC). Inspect the push-button start operating range (front floor). Place the electrical key transmitter sub-assembly on the front seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is within the vehicle interior detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform the inspection for both inspection points. Inspect the push-button start operating range (rear floor). Place the key on the rear seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is within the vehicle interior detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform the inspection for both inspection points. Check the push-button start function. (for Manual Transaxle) With the engine switch off, depress the clutch pedal while carrying the electrical key transmitter sub-assembly. Then, press the engine switch and check that the engine starts. With the clutch pedal released and the engine switch off, press the engine switch while carrying the electrical key transmitter sub-assembly and check that the power source mode changes as follows: off --> on (ACC) --> on (IG) --> off. Stop the vehicle, press the engine switch and check that the power source mode changes to off (the engine stops and all electrical systems turn off). Inspect the push-button start operating range (front floor). Place the electrical key transmitter sub-assembly on the front seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is within the vehicle interior detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform the inspection for both inspection points. Inspect the push-button start operating range (rear floor). Place the key on the rear seat at either inspection point so that it is facing in the direction shown in the illustration and check that the engine can be started. *a Inspection Point NOTE: Even if the electrical key transmitter sub-assembly is within the vehicle interior detection area, the electrical key transmitter sub-assembly may not be properly detected if it is on the instrument panel, in the glove box or on the floor. HINT: Communication may not be possible if the electrical key transmitter sub-assembly is within 0.2 m (0.656 ft.) of the shift lever. Perform the inspection for both inspection points. Check the transmitter battery saving function Press the unlock switch of the electrical key transmitter sub-assembly twice while pressing the lock button and check that the electrical key transmitter sub-assembly LED blinks 4 times and enters transmitter battery saving mode. Check that the smart key system (for Entry Function) does not operate while in transmitter battery saving mode. HINT: To cancel transmitter battery saving mode, press a button of the electrical key transmitter sub-assembly. Check the entry cancel function. Cancel the smart key system and check that all the functions of the smart key system (for Entry Function) no longer operate. HINT: Refer to the following procedure to cancel the smart key system (for Entry Function). Refer to «CUSTOMIZE PARAMETERS [08/2013 - ]»(ref-635436-S35765981882014070300000) While the smart key system is canceled, it is possible to lock and unlock the doors with the wireless operation, and the start system can be operated by holding the electrical key transmitter sub-assembly near the engine switch. While the key cancel function (entry cancel function) is on, check that all functions of the smart key system cannot be operated. Check the answer-back function (hazard warning light flashing and buzzer sounding). Entry Operation Hazard Warning Light Wireless Buzzer Entry Lock Flashes once Sounds once Entry Unlock Flashes twice Sounds twice
2. KEY DIAGNOSTIC MODE (Using Techstream) HINT: With key diagnostic mode, it is possible to check if the electrical key transmitter sub-assembly is operating properly with the selected electrical key antenna and within the selected detection area by the sounding of the wireless buzzer. If the buzzer sounds with [CH1] displayed but not with [CH2], the electrical key transmitter sub-assembly cannot be detected by channel 2 due to a malfunction, such as wave interference. Enter the following menus: Body Electrical / Smart Key / Utility / Communication Check (Key Diag Mode). Inspect the appropriate item according to the following table. Tester Display Inspection Item [CH1/CH2] Overhead + Driver Side*1 Front door outside handle assembly (electrical key antenna) (for driver door) [CH1] Overhead + Driver Side*1 [CH2] Overhead + Driver Side*1 [CH1/CH2] Overhead + Passenger Side*2 Front door outside handle assembly (electrical key antenna) (for front passenger door) [CH1] Overhead + Passenger Side*2 [CH2] Overhead + Passenger Side*2 [CH1/CH2] Overhead + Front Room*3 No. 1 indoor electrical key antenna assembly (front floor) [CH1] Overhead + Front Room*3 [CH2] Overhead + Front Room*3 [CH1/CH2] Overhead + Rear Room*4 No. 2 indoor electrical key antenna assembly (rear floor) [CH1] Overhead + Rear Room*4 [CH2] Overhead + Rear Room*4 [CH1/CH2] Overhead + Luggage*5 Electrical key antenna (outside luggage compartment) [CH1] Overhead + Luggage*5 [CH2] Overhead + Luggage*5 [CH1/CH2] Luggage + Luggage (inside)*6 No. 3 indoor electrical key antenna assembly (inside luggage compartment) [CH1] Luggage + Luggage (inside)*6 [CH2] Luggage + Luggage (inside)*6 [CH1/CH2] Immobilizer Amp*7 Amplifier (engine switch) [CH1] Immobilizer Amp*7 [CH2] Immobilizer Amp*7 [CH1/CH2] Luggage + Luggage*5 Electrical key antenna (outside luggage compartment) [CH1] Luggage + Luggage*5 [CH2] Luggage + Luggage*5 Bring the electrical key transmitter sub-assembly near the selected electrical key antenna and check that the wireless door lock buzzer sounds. HINT: The buzzer sounds in short, repeated beeps for all items except "Overhead + Rear Room"*4. For "Overhead + Rear Room"*4, the buzzer sounds in one long, continuous beep. *1: Front door outside handle assembly (for driver door) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *a 0.7 to 1 m (2.30 to 3.28 ft.) HINT: Hold the electrical key transmitter sub-assembly at the same height as the front door outside handle assembly in the position shown in the illustration. *2: Perform the same inspection for the front passenger door. *3: No. 1 indoor electrical key antenna assembly (front floor) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *a Inspection Point HINT: Place the electrical key transmitter sub-assembly on the front seat cushion of the driver seat or front passenger seat. *4: No. 2 indoor electrical key antenna assembly (rear floor) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *a Inspection Point HINT: Place the electrical key transmitter sub-assembly on the rear seat cushion. *5: Electrical key antenna (outside luggage compartment) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *a 0.7 to 1 m (2.30 to 3.28 ft.) HINT: Hold the electrical key transmitter sub-assembly at the same height as the rear bumper upper surface and align it with the center of the rear of the vehicle, as shown in the illustration. *6: No. 3 indoor electrical key antenna assembly (inside luggage compartment) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *a Inspection Point HINT: Place the electrical key transmitter sub-assembly in the luggage compartment. Even if the electrical key transmitter sub-assembly is in the luggage compartment, the buzzer may not sound. *7: Amplifier (engine switch) Body Electrical > Smart Key > Utility Tester Display Communication Check(Key Diag Mode) *1 Engine Switch *2 Electrical Key Transmitter Sub-assembly HINT: While facing the logo side of the electrical key transmitter sub-assembly towards the engine switch, hold the transmitter near the engine switch.

Scheme 77

1. CUSTOMIZE SMART KEY SYSTEM (for Entry Function) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Customizing with the Techstream Connect the Techstream to the DLC3. Turn the engine switch on (IG). Turn the Techstream on. Enter the following menus: Customize Setting / Wireless Door Lock, Smart Key / Access or Warning. Select the setting by referring to the table below. Wireless Door Lock Tester Display Description Default Setting ECU Wireless Control Function that turns the wireless door lock control system on or off ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Hazard Answer Back Function that flashes the hazard warning lights once when the doors are locked by the entry lock function. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Open Door Warning Function that sounds a buzzer when the lock sensor on the door outside handle assembly is touched to perform entry lock with a door open. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Auto Lock Time Function that regulates the interval between unlocking and automatic relocking of doors. 60 s 00:30 s, 01:60 s, 10:120 s Main body ECU (Multiplex network body ECU) Wireless Auto Lock Function that turns the auto lock function on or off. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Wireless Buzzer Resp Wireless buzzer response. ON 0:OFF, 1:ON Main body ECU (Multiplex network body ECU) Wireless Buzzer Vol Buzzer answer-back volume. Level 5*1 or Level7*2 0000:Level7, 0001:Level6, 0010:Level5, 0011:Level4, 0100:Level3, 0101:Level2, 0110:Level1, 0111:Level0 Main body ECU (Multiplex network body ECU) *1: w/ Theft Deterrent System *2: w/o Theft Deterrent System Smart Key / Access Tester Display Description Default Setting ECU Park Wait Time Function that sets the period of time (lock confirmation time) that the door is prevented from being unlocked by operating the front door outside handle assembly after an entry lock operation is performed. 2.5s 00:0.5s, 01:1.5s, 10:2.5s, 11:5s Certification ECU (Smart key ECU assembly) Ignition Available Area Function that sets the area that the electrical key transmitter sub-assembly must be in before the engine switch can be operated. All 00:Front, 01:All Certification ECU (Smart key ECU assembly) Trunk Open Mode Function that opens the luggage compartment door when the user is carrying the electrical key transmitter sub-assembly and presses the luggage electrical key switch. ON 0:OFF, 1:ON Certification ECU (Smart key ECU assembly) Door Unlock Mode2 Function that sets which doors are unlocked by the entry unlock function. Driver 0:All, 1:Driver Certification ECU (Smart key ECU assembly) Touch Activation Over Threshold Function that limits the consecutive entry lock operations to only 2 times. This function can be changed between Active and Not Active. When in Not Active mode, there is no limit for the number of times that the consecutive entry lock operation can be performed. Active 0:Active, 1:Not Active Certification ECU (Smart key ECU assembly) Engine Start Indicator Function that turns the key warning light on the combination meter assembly on or off. ON 0:OFF, 1:ON Certification ECU (Smart key ECU assembly) Warning Tester Display Description Default Setting ECU Key Low Battery Warning Function that enables or disables the sounding of the buzzer when the transmitter battery is low and the engine switch is turned off after being on (IG) for 20 minutes or more. ON 0:OFF, 1:ON Certification ECU (Smart key ECU assembly) Customizing with the multi-display Turn the engine switch on (IG). Enter the following menus: SETUP / Vehicle / Vehicle Customization / Door Lock Settings. (for Radio and Display Type) Enter the following menus: APPS / Setup / Vehicle / Vehicle Customization / Door Lock Settings. (for Navigation Receiver Type) Select the setting by referring to the table below. Display Default Content Setting Relevant ECU Select Doors to Unlock Driver's Door Function that sets which doors are unlocked by the entry unlock function. All Doors or Driver's Door Certification ECU (Smart key ECU assembly) Auto Relock Timer 60 sec. Function that regulates the interval between unlocking and automatic relocking of doors. Off, 30 sec., 60 sec. or 120 sec. Main body ECU (Multiplex network body ECU) Lock/Unlock Feedback-Lights On Function that flashes the hazard warning lights once when the doors are locked by the entry lock function. On or Off Main body ECU (Multiplex network body ECU) Lock/Unlock Feedback-Tone 5*1 or 7*2 Buzzer answer-back volume. Off, 1, 2, 3, 4, 5, 6 or 7 Main body ECU (Multiplex network body ECU) *1: w/ Theft Deterrent System *2: w/o Theft Deterrent System Entry unlock mode switching function (manual operation) The following entry unlock modes can be selected when using the entry unlock mode switching function. All door unlock mode: When the sensor of a front door outside handle assembly is touched, an entry unlock operation is performed simultaneously for all doors. Driver door unlock mode: When the sensor of the front door outside handle assembly (for driver door) is touched, an entry unlock operation is performed for the driver door only. If any other door handle is touched, an entry unlock operation is performed simultaneously for all doors. When customizing through manual operation: Turn the engine switch off. Check that the LED of the electrical key transmitter sub-assembly is not illuminated, and then press and hold the lock and unlock switches of the electrical key transmitter sub-assembly for 5 seconds or more while the electrical key transmitter sub-assembly is in the actuation area. Check the current setting. HINT: The mode changes from all door unlock mode to driver door unlock mode and then back to all door unlock mode. The answer-back (wireless buzzer, buzzer in the combination meter assembly) operation for each mode is indicated in the table below. Currently Selected Mode Answer-back (Wireless Buzzer) Answer-back (Buzzer in Combination Meter Assembly) All door unlock mode Buzzer sounds twice (short beeps) Buzzer sounds once Driver door unlock mode Buzzer sounds 3 times (short beeps) Buzzer sounds once Release the lock and unlock switches of the electrical key transmitter sub-assembly. Check that the LED of the electrical key transmitter sub-assembly is not illuminated, and then press and hold the lock and unlock switches of the electrical key transmitter sub-assembly for 5 seconds or more to change the mode. HINT: Repeat the procedure as necessary to select the desired mode. Unlock the doors with the wireless operation, and then open any door. Entry cancel function (manual operation) HINT: While the smart key system is canceled, it is possible to lock and unlock the doors with the wireless operation, and the start system can be operated by holding the electrical key transmitter sub-assembly near the engine switch. The following functions are disabled when the smart key system is canceled. Entry unlock/lock functions Push-button start function Key lock-in prevention function Entry warning functions When canceling the smart key system through manual operation: Make sure the following conditions are met: The engine switch is off. The driver door is closed. The driver door is unlocked. Press the unlock switch of the electrical key transmitter sub-assembly. Open the driver door within 5 seconds of completing the step above (driver door: closed --> opened). With the driver door open, press the unlock switch of the electrical key transmitter sub-assembly 2 times within 5 seconds of completing the step above. NOTE: If the driver door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Perform the following procedure within 30 seconds of completing the step above. Close and open the driver door twice (driver door: open --> closed --> opened --> closed --> opened). With the driver door open, press the unlock switch of the electrical key transmitter sub-assembly 2 times. NOTE: If the driver door is closed before or while pressing the unlock switch, the entry cancel setting mode will end. Close and open the driver door (driver door: open --> closed --> opened). Close the driver door within 5 seconds (driver door: open --> closed). Check that the wireless buzzer sounds twice (short beeps) to confirm that the smart key system has been canceled. Perform the following procedure to restore the smart key system to the active state from the canceled state. Perform the procedure to cancel the smart key system again. Check that the wireless buzzer sounds once (short beep) to confirm that the smart key system has been restored to the active state. HINT: The system changes between the canceled state and the active state each time the procedure to cancel the system through manual operation is performed. The buzzer sounds twice when the system changes from the active state to the canceled state, and sounds once when the system changes from the canceled state to the active state.
