REMOVAL
HINT
However, only installation procedures requiring additional information are included.
Scheme 38
Scheme 39
Scheme 40
Scheme 41
Scheme 42
Scheme 43
- REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH (See «REMOVAL»(ref-291123-S34069576942008072400000) )
- REMOVE WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH (See «REMOVAL»(ref-291123-S34069576942008072400000) )
- REMOVE COWL TOP VENTILATOR LOUVER RH (See «REMOVAL»(ref-291123-S34069576942008072400000) )
- REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP LH
- REMOVE FRONT DOOR OPENING TRIM WEATHERSTRIP RH
- REMOVE FRONT PILLAR GARNISH LH (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE FRONT PILLAR GARNISH RH (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ASSIST GRIP SUB-ASSEMBLY FRONT (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ASSIST GRIP SUB-ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE VISOR BRACKET COVER (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE LH VISOR ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE RH VISOR ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ROOF CONSOLE BOX ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE VISOR HOLDER (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE INNER REAR VIEW MIRROR STAY HOLDER COVER (See «REMOVAL»(ref-291147-S11019510942008072400000) )
- REMOVE RAIN SENSOR COVER (See «REMOVAL»(ref-291123-S26244841922008072400000) )
- REMOVE RAIN SENSOR (See «REMOVAL»(ref-291123-S26244841922008072400000) )
- REMOVE SUN ROOF OPENING TRIM MOULDING (w/ Sliding Roof) (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ROOF HEADLINING ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE WINDSHIELD MOULDING OUTER UPPER Using a knife, cut off the moulding as shown in the illustration. NOTE: Be careful not to damage the vehicle body with the knife. Remove the remaining moulding. HINT: Partially cut the moulding. Then pull and remove it by hand.
- REMOVE WINDSHIELD GLASS From the interior, insert piano wires between the vehicle body and glass as shown in the illustration. Tie objects that can serve as handles to all wire ends. HINT: Apply protective tape to the outer surface of the vehicle body to prevent its surface from being scratched. NOTE: w/ Curtain shield airbag: When working around the curtain shield airbag, be careful not to damage the airbag. When separating the glass from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. To prevent the safety pad from being scratched when removing the glass, place a plastic sheet between the piano wire and safety pad. Cut through the adhesive by pulling the piano wire around the glass. Disengage the stoppers. HINT: In some cases, both 1-piece type and 2-piece type stoppers are installed in the same vehicle. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
- CLEAN WINDSHIELD GLASS Using a scraper, remove the damaged stoppers, the damaged any adhesive remaining the glass. Clean the outer circumference on of the glass with white gasoline. NOTE: Do not tough the glass after cleaning it. Even if using new glass, clean the glass with white gasoline.
- CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure a proper fit. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a shop rag or piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.
Scheme 44
Scheme 45
Scheme 46
Scheme 47
Scheme 48
Scheme 49
Scheme 50
Scheme 51
Scheme 52
- INSTALL WINDSHIELD GLASS STOPPER NO. 2 Coat the installation part of the stopper with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G. Install 2 new stoppers onto the glass as shown in the illustration. Specification SPECIFICATION CHART Area Measurement A 7.7 mm (0.303 in.) B 40.0 mm (1.575 in.)
- INSTALL WINDSHIELD GLASS STOPPER NO. 1 Install 2 new stoppers to the vehicle body as shown in the illustration.
- INSTALL WINDSHIELD GLASS RETAINER Install 2 new retainers onto the glass as shown in the illustration.
- INSTALL WINDOW GLASS ADHESIVE DAM Coat the installation part of the windshield glass adhesive dam with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much primer. Install a new dam as shown in the illustration. Specification SPECIFICATION CHART Area Measurement a 7.0 mm (0.276 in.) b 48.4 mm (1.905 in.)
- INSTALL WINDSHIELD GLASS Position the glass. Using the suction cup, place the glass in the correct position. Check that the whole contact surface of the glass rim is perfectly even. Place reference marks on the glass and vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. HINT: When reusing the glass, check and correct the reference mark positions. Using a suction cup, remove the glass. Using a brush, coat the exposed areas of the vehicle body, where all adhesive has been removed with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer M. Do not apply too much Primer M. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer M. HINT: If a non-specified area is coated by accident, wipe off the primer with a clean piece of cloth before it dries. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of away any excess Primer M. Do not apply too much Primer M. Apply adhesive. Adhesive: Part No. 00850-00801 or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration. HINT: After cutting off the tip, use adhesive within the time described in the table below. Usage time frame TIME AND TEMPERATURE SPECIFICATION Temperature Usage time frame 35°C(95°F) 15 minutes 20°C(68°F) 1 hour 40 minutes 5°C(41°F) 8 hour Load a sealer gun with the cartridge. Coat the glass with adhesive as shown in the illustration. Specification SPECIFICATION CHART Area Measurement a 8.0 mm (0.315 in.) b 12.0 mm (0.472 in.) Install the glass. Using a suction cup, position the glass so that the reference marks are aligned. Press it in gently along the rim. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the stoppers are attached to the vehicle body correctly. Check that there is a small gap between the vehicle body and glass. Lightly press the front surface of the glass to ensure that the glass is securely fit to the vehicle body. Using a scraper, remove any excess or protruding adhesive (Procedure A). HINT: Make sure that adhesive is applied up to the glass rim. NOTE: The vehicle should not be driven until the time indicated in the table below has elapsed after procedure A. Minimum time TIME AND TEMPERATURE SPECIFICATION Temperature Minimum time prior to driving vehicle 35°C(95°F) 1 hour 30 minutes 20°C(68°F) 5 hours 5°C(41°F) 24 hours
- INSTALL WINDSHIELD MOULDING OUTER UPPER Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of away any excess Primer G. Do not apply too much Primer G. Install the moulding.
- INSPECT FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with out glass sealer.
- INSTALL ROOF HEADLINING ASSEMBLY
- INSTALL SUN ROOF OPENING TRIM MOULDING
- INSTALL RAIN SENSOR
- INSTALL RAIN SENSOR COVER
- INSTALL INNER REAR VIEW MIRROR STAY HOLDER COVER
- INSTALL VISOR HOLDER
- INSTALL ROOF CONSOLE BOX ASSEMBLY
- INSTALL RH VISOR ASSEMBLY
- INSTALL LH VISOR ASSEMBLY
- INSTALL VISOR BRACKET COVER
- INSTALL ASSIST GRIP SUB-ASSEMBLY
- INSTALL ASSIST GRIP SUB-ASSEMBLY FRONT
- INSTALL FRONT PILLAR GARNISH RH (See «INSTALLATION»(ref-291105-S18093485082008072400000) )
- INSTALL FRONT PILLAR GARNISH LH (See «INSTALLATION»(ref-291105-S18093485082008072400000) )
- INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP RH
- INSTALL FRONT DOOR OPENING TRIM WEATHERSTRIP LH
- INSTALL COWL TOP VENTILATOR LOUVER RH
- INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY RH
- INSTALL WINDSHIELD WIPER ARM AND BLADE ASSEMBLY LH
Scheme 53
HINT
However, only installation procedures requiring additional information are included.
Scheme 54
Scheme 55
Scheme 56
Scheme 57
Scheme 58
Scheme 59
- REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP LH
- REMOVE REAR DOOR OPENING TRIM WEATHERSTRIP RH
- REMOVE ROOF SIDE GARNISH ASSEMBLY INNER LH (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ROOF SIDE GARNISH ASSEMBLY INNER RH (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE PACKAGE TRAY TRIM PANEL ASSEMBLY (See «REMOVAL»(ref-291137-S31364617752008072400000) )
- REMOVE ASSIST GRIP SUB-ASSEMBLY
- REMOVE REAR ROOM LIGHT ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE ROOF HEADLINING ASSEMBLY (See «REMOVAL»(ref-291105-S16624044192008072400000) )
- REMOVE BACK WINDOW MOULDING OUTSIDE UPPER Using a knife, cut off the moulding, as shown in the illustration. NOTE: Be careful not to damage the vehicle body with the knife. Remove the remaining moulding. HINT: Partially cut the moulding. Then pull and remove it by hand.
- REMOVE BACK WINDOW GLASS From the interior, insert piano wires between the vehicle body and glass as shown in the illustration. Tie wooden blocks or other objects that can serve as handles to all wire ends. HINT: Apply protective tape to the outer surface of the vehicle body to prevent its surface from being scratched. NOTE: When separating the grass from the vehicle, be careful not to damage the vehicle's paint or interior/exterior ornaments. Cut through the adhesive by pulling the piano wire around the glass. Disengage the stoppers. HINT: In some cases, both 1-piece type and 2-piece type stoppers are installed in the same vehicle. Using a suction cup, remove the glass. NOTE: Leave as much adhesive on the vehicle body as possible when removing the glass.
- CLEAN BACK WINDOW GLASS Using a scraper, remove the damaged stoppers the damand any adhesive remaining on the glass. Clean the outer circumference of the glass with white gasoline. NOTE: Do not tough the glass after cleaning it. Even if using new glass, clean the glass with white gasoline.
- CLEAN VEHICLE BODY Clean and shape the contact surface of the vehicle body. Using a knife, cut away any rough adhesive on the contact surface of the vehicle body to ensure a proper fit. NOTE: Be careful not to damage the vehicle body. HINT: Leave as much adhesive on the vehicle body as possible. Clean the contact surface of the vehicle body with a piece of a shop rag or piece of cloth saturated with cleaner. HINT: Even if all the adhesive has been removed, clean the vehicle body.
Scheme 60
Scheme 61
Scheme 62
Scheme 63
Scheme 64
Scheme 65
Scheme 66
- INSTALL BACK WINDOW GLASS STOPPER NO. 2 Coat the installation part of the stopper with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G, Install 2 new stoppers to the glass as shown in the illustration. Specification SPECIFICATION CHART Area Measurement A 12.5 mm (0.492 in.) B 50.0 mm (1.968 in.)
- INSTALL BACK WINDOW GLASS STOPPER NO. 1 Install 2 new stoppers to the vehicle body as shown in the illustration.
- INSTALL BACK WINDOW MOULDING OUTSIDE UPPER Using a brush or sponge, coat the edge of the glass and the contact surface with Primer G. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer G. Do not apply too much Primer G, Install the moulding.
- INSTALL BACK WINDOW GLASS Position the glass. Using a suction cup, place the glass in the correct position. Check that the whole contact surface of the glass rim perfectly even. Place reference marks on the glass and vehicle body. NOTE: Check that the stoppers are attached to the vehicle body correctly. HINT: When reusing the glass, check and correct the reference mark positions. Using a suction cup, remove the glass. Using a brush, coat the exposed areas of the vehicle body, where all adhesive has been removed with Primer M. NOTE: Allow the primer coating to dry for 3 minutes or more. Do not coat the area adhesive is still remaining with Primer M. Dispose of any excess Primer M. Do not apply too much Primer M. Using a brush or sponge, coat the edge of the glass and the contact surface with Primer M. HINT: If a non-specified area is coated by accident, wipe off the primer with a clean a piece of cloth before it dries out. NOTE: Allow the primer coating to dry for 3 minutes or more. Dispose of any excess Primer M. Do not apply too much Primer M. Apply adhesive. Adhesive: Part No. 08850-00801 or equivalent Cut off the tip of the cartridge nozzle as shown in the illustration. HINT: After cutting off the tip, use adhesive within the time described in the table below. Usage time frame TIME AND TEMPERATURE SPECIFICATION Temperature Usage time frame 35°C(95°F) 15 minutes 20°C(68°F) 1 hour 40 minutes 5°C(41°F) 8 hours Load a sealer gun with the cartridge. Coat the glass with adhesive as shown in the illustration. Specification SPECIFICATION CHART Area Measurement a 8.0 mm (0.315 in.) b 12.0 mm (0.472 in.) c 7.0 mm (0.275 in.) Install the glass. Using a suction cup, position the glass so that the reference marks are aligned. Press it in gently along the rim. NOTE: Allow the primer coating to dry for 3 minutes or more. Check that the stoppers are attached to the vehicle body correctly. Check that there is a small gap between the vehicle body and glass. Lightly press the front surface of the glass to ensure that the glass is securely fit to the vehicle body. Using a scraper, remove any excess adhesive. HINT: Make sure that adhesive is applied up to the glass rim. NOTE: The vehicle should not be driven until the time indicated in the table below has elapsed after applying adhesive. Minimum time TIME AND TEMPERATURE SPECIFICATION Temperature Minimum time prior to driving vehicle 35°C(95°F) 1 hour 30 minutes 20°C(68°F) 5 hours 5°C(41°F) 24 hours
- INSPECT FOR LEAKS AND REPAIR Conduct a leak test after the adhesive has completely hardened. Seal any leaks with auto glass sealer.
- INSTALL ROOF HEADLINING ASSY
- INSTALL REAR ROOM LIGHT ASSEMBLY
- INSTALL ASSIST GRIP SUB-ASSEMBLY
- INSTALL PACKAGE TRAY TRIM PANEL ASSEMBLY
- INSTALL ROOF SIDE GARNISH ASSEMBLY INNER RH (See «INSTALLATION»(ref-291105-S18093485082008072400000) )
- INSTALL ROOF SIDE GARNISH ASSEMBLY INNER LH (See «INSTALLATION»(ref-291105-S18093485082008072400000) )
- INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP RH
- INSTALL REAR DOOR OPENING TRIM WEATHERSTRIP LH
