PRECAUTION

Note. When disconnecting the negative (-) battery cable, initialize the following systems after the cable is reconnected.

SYSTEM REFERENCE

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this information. EXPRESSIONS OF IGNITION SWITCH Switch Type Ignition Switch (position) Engine Switch (condition) Expression Ignition Switch off LOCK Off Ignition Switch on (IG) ON On (IG) Ignition Switch on (ACC) ACC On (ACC) Engine Start START Start

Scheme 67

Scheme 68

INITIALIZATION

1. INITIALIZE POWER WINDOW REGULATOR MOTOR NOTE: Resetting the power window motor (initializing the pulse sensor) is necessary when the battery terminal is disconnected; when the power window regulator master switch, power window regulator switch, wire harness, power window regulator and power window motor are replaced or removed/installed; or when the FR DOOR fuse, ECU-B fuse and ECU-IG No. 1 fuse are replaced. AUTO operation function, jam protection function and remote operation function via the power window regulator master switch do not operate without resetting. Ignition switch on (IG). (Power window can be partially or fully open.) Close the power window by holding the Auto UP knob ON. Continue to hold the Auto UP knob ON a minimum of 1 second after the power window completely closes. Release the Auto UP knob. HINT: Front passenger must be initialized from actual multiplex network switch assembly. After initialization operation (from the multiplex network master switch assembly to the multiplex network switch assembly) will be allowed.

POWER WINDOW CONTROL SYSTEM

POWER WINDOW CONTROL SYSTEM - PROBLEM SYMPTOMS CHART

Scheme 69

Scheme 70

1. MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY ECU TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition E (H6-1) - Body ground W-B - Body ground Ground Always Below 1 ohms SGND (H6-2) - Body ground W-B - Body ground Ground Always Below 1 ohms VC (H6-3) - E (H6-1) L - W-B Power window motor position sensor power source Always 10 to 14 V U (H6-4) - Body ground P - Body ground Power window motor UP output signal (Driver side) Ignition switch on (IG), power window OFF --> UP 0 V --> 10 to 14 V L (H6-5) - E (H6-1) G - W-B Door lock signal Door lock switch position is OFF --> LOCK 10 to 14 V --> 0 V B (H6-6) - E (H6-1) R - W-B Power window switch power source Always 10 to 14 V BW (H6-7) - E (H6-1) W - W-B Power window switch power source Always 10 to 14 V UL (H6-8) - E (H6-1) L - W-B Door lock signal Door lock switch position is OFF --> UNLOCK 10 to 14 V --> 0 V D (H6-9) - Body ground BR - Body ground Power window motor DOWN output signal (Driver side) Ignition switch on (IG), power window OFF --> DOWN 0 V --> 10 to 14 V D (H6-10) - Body ground R - Body ground Power window motor DOWN output signal (Rear LH) Ignition switch on (IG), power window OFF --> DOWN 0 V --> 10 to 14 V IG (H6-11) - E (H6-1) GR - W-B Power window switch power source Ignition switch OFF --> ON 0 V --> 10 to 14 V U (H6-12) - Body ground BR - Body ground Power window motor UP output signal (Rear LH) Ignition switch on (IG), power window OFF --> UP 0 V --> 10 to 14 V TX (H6-13) - E (H6-1) B - W-B Communication circuit - - PLS1 (H6-14) - E (H6-1) O - W-B Power window motor position sensor input signal (Driver side) Power window operating Pulse generation PCT (H6-15) - E (H6-1) Y - W-B Power window lock switch' output signal Ignition switch on (IG), power window lock switch NORMAL --> LOCK 10 to 14 V --> 0 V D (H6-16) - Body ground V - Body ground Power window motor DOWN output signal (Rear RH) Ignition switch on (IG), power window OFF --> DOWN 0 V --> 10 to 14 V PLS2 (H6-17) - E (H6-1) LG - W-B Power window motor position sensor input signal (Driver side) Power window operating Pulse generation U (H6-18) - Body ground L - Body ground Power window motor UP output signal (Rear RH) Ignition switch on (IG), power window OFF --> UP 0 V --> 10 to 14 V
2. MULTIPLEX NETWORK SWITCH ASSEMBLY ECU CONNECTOR G6 TERMINALS REFERENCE Symbols (Terminal No.) Wiring Color Terminal Description Condition Specified Condition D (G6-1) - Body ground R - Body ground Power window motor DOWN output signal (Front passenger side) Ignition switch on (IG), power window OFF --> DOWN 0 V --> 10 to 14 V RX (G6-2) - E (G6-7) GR - W-B Communication circuit - - PLS1 (G6-3) - E (G6-7) B - W-B Power window motor position sensor input signal (Driver side) Power window operating Pulse generation PLS2 (G6-4) - E (G6-7) LG - W-B Power window motor position sensor input signal (Driver side) Power window operating Pulse generation VCC (G6-5) - E (G6-7) W - W-B Power window motor position sensor power source Always 10 to 14 V U (G6-6) - Body ground G - Body ground Power window motor UP output signal (Front passenger side) Ignition switch on (IG), power window OFF --> UP 0 V --> 10 to 14 V E (G6-7) - Body ground W-B - Body ground Ground Always Below 1 ohms SGND (G6-8) - Body ground W-B - Body ground Ground Always Below 1 ohms PCT (G6-11) - E (G6-7) BR - W-B Power window lock switch output signal Ignition switch on (IG), power window lock switch NORMAL --> LOCK 10 to 14 V --> 0 V BW (G6-12) - E (G6-7) V - W-B Power window switch power source Always 10 to 14 V

Scheme 71

Scheme 72

1. CHECK DIAGNOSIS Turn the ignition switch ON. Operate the driver side switch of the master switch. Check the blinking pattern of the AUTO light as shown in the illustration. If pattern (A) is displayed, reset power window regulator motor. If pattern (B) or (C) displayed, check the wire harness. If the normal pattern is displayed, replace the multiplex network master switch.

Note. When disconnecting the negative (-) battery terminal, initialize the following system(s) after the terminal is reconnected.

SYSTEM REFERENCE

1. EXPRESSIONS OF IGNITION SWITCH The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this information. EXPRESSIONS OF IGNITION SWITCH Switch Type Ignition Switch (position) Engine Switch (condition) Expression Ignition Switch off LOCK Off Ignition Switch on (IG) ON On (IG) Ignition Switch on (ACC) ACC On (ACC) Engine Start START Start

Scheme 73

Scheme 74

WINDOW DEFOGGER SYSTEM

PROBLEM SYMPTOMS CHART - WINDOW DEFOGGER SYSTEM

Scheme 75

1. INSPECT RELAY Remove the RR DEF relay from the engine room R/ B. Measure the resistance according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester connection Condition Specified condition 3 - 5 Always 10 kohms or higher 3 - 5 Voltage is applied between terminals 1 and 2 Below 1 ohms If the result is not as specified, replace the relay.

Scheme 76

Scheme 77

Scheme 78

1. INSPECT BACK WINDOW Prepare a piece of tin foil to wrap the tip of the negative tester probe. NOTE: When cleaning the glass, wipe the glass along the wire using a soft and dry cloth. Take care not to damage the wires. Do not use detergents or glass cleaners that have abrasive ingredients. When measuring voltage, wrap a piece of tin foil around the tip of the negative tester probe and press the foil against the wire with your finger, as shown in the illustration. Turn the ignition switch on (IG). Turn the defogger switch on. Check the voltage at the center of each defogger wire, as shown in the illustration. Voltage VOLTAGE SPECIFICATION Voltage Criteria Appox. 5 V Wire is not broken Appox. 10 or 0 V Wire is broken If there is approximately 10 V, the wire may be faulty between the center of the wire and the wire end on the battery side. If there is no voltage, the wire may be faulty between the center of the wire and the wire end on the ground side. Place the voltmeter's positive (+) lead against the defogger wire on the battery side. Place the voltmeter's negative (-) lead with the foil strip against the wire on the ground side. Slide the positive (+) lead from the battery side to the ground side. The point where the voltage jumps from approximately 10 V to 0 V is where the defogger wire is broken. HINT: If the defogger wire is not broken, the voltmeter should indicate 0 V at the positive (+) end of the defogger wire but gradually increases to approximately 12 V as the meter probe moves to the other end.

Scheme 79

Scheme 80

1. REPAIR REAR WINDOW DEFOGGER WIRE HINT: If necessary, repair the defogger wire. Clean the broken wire tips with grease, wax and silicone remover. Place 2 pieces of masking tape along both sides of the wire. Thoroughly mix the repair agent (Dupont paste No. 4817 of equivalent). Using a fine tip brush, apply a small amount of the agent to the wire. After a few minutes, remove the masking tape. NOTE: Do not touch the repaired part on the wire for at least 24 hours, until the repair agent is completely fixed.
