Windshield/window Glass: Overview Toyota Avalon XX30 рестайлинг

SYSTEM DESCRIPTION

1. POWER WINDOW CONTROL SYSTEM DESCRIPTION The power window control system controls the power windows' UP/DOWN function using regulator motors. The main controls of this system are: the multiplex network master switch assembly, which is built into the driver side door, and the power window regulator switches, which are built into the passenger side door and rear doors. Pressing each regulator switch on the multiplex network master switch assembly transmits a remote UP/DOWN signal to each power window regulator switch.
2. FUNCTION OF MAIN COMPONENT FUNCTION OF MAIN COMPONENT Component Outline Multiplex Network Master Switch Assembly Control window operations for all windows. Also, when window lock switch is set to lock position, window operation will only be possible for driver side power window. Multiplex Network Switch Assembly Located on passenger side door. Regulator switch assembly controls window operations for its respective window. Power Window Regulator Switch (Rear LH, RH) Located on rear door. Regulator switch assembly controls window operations for its respective window. Power Window Regulator Motor Assembly Receives switch signals and changes signals into motor activation. As a result, window position changes. Also, regulator motor assembly uses pulse sensor(s) to detect window position.
3. SYSTEM FUNCTION The power window control system has the following functions: POWER WINDOW CONTROL SYSTEM FUNCTION Function Outline Manual UP/DOWN function Function that raises window while power window switch is pulled halfway up and lowers window while switch is pushed halfway down. Window stops as soon as the switch is released. Auto UP/DOWN function Function that enables window to be fully opened or fully closed by one full push or pull of power window switch. Jam protection function Function that automatically stops power window and moves it downward if object is jammed in all power windows during AUTO UP operation. During key-off operation function, jam protection function works for manual UP and AUTO UP operation. Jam protection is available for front doors. Remote control function Function that allows multiplex network master switch assembly to control manual and AUTO UP/DOWN operations of passenger door power window and rear door power window. Key-off operation function Function that makes it possible to operate power window for approximately 43 seconds after ignition switch is turned to ACC or LOCK position and both front doors are closed. Window lock function Function where passenger door power window and rear door power windows' operations are disabled when window lock switch of the multiplex network master switch assembly is pressed. Passenger door power window and rear door power window can be operated when window lock switch is pressed again. Diagnosis Function where power window switch can detect malfunctions in power window system and make diagnoses. Power window switch light starts blinking to inform driver. Fail-safe Function that disables power window AUTO UP/DOWN function if pulse sensor (Hall IC) or limit sensor in power window regulator motor malfunction. Manual operation is possible through power window switches.

DESCRIPTION

This circuit supplies power to operate the multiplex network master switch.

Scheme 1

Scheme 2

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK MASTER SWITCH - BATTERY AND BODY GROUND) Disconnect the H6 connector. Measure the resistance and voltage according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition H6-1 (E) - Body ground Always Below 1 ohms Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition H6-7 (BW) - Body ground Always 10 to 14 V H6-6 (B) - Body ground Always 10 to 14 V H6-11 (IG) - Body ground Ignition switch OFF --> ON 0 V --> 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit supplies power to operate the multiplex network switch.

Scheme 3

Scheme 4

1. CHECK WIRE HARNESS (MULTIPLEX NETWORK SWITCH - BATTERY AND BODY GROUND) Disconnect the G6 connector. Measure the resistance and voltage according to the value(s) in the table below. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition G6-7 (E) - Body ground Always Below 1 ohms Voltage VOLTAGE SPECIFICATION Tester Connection Condition Specified Condition G6-12 (BW) - Body ground Always 10 to 14 V NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network master switch assembly to multiplex network switch assembly.

Scheme 5

Scheme 6

1. INSPECT MULTIPLEX NETWORK SWITCH ASSEMBLY Remove the switch. Measure the resistance of the switch when the switch is operated. Resistance RESISTANCE SPECIFICATION Switch Condition Tester Connection Specified Condition AUTO UP 1 (D) - 7 (E) 6 (U) - 12 (BW) Below 1ohms UP 1 (D) - 7 (E) 6 (U) - 12 (BW) Below 1ohms OFF 1 (D) - 7 (E) 6 (U) - 7 (E) Below 1ohms DOWN 6 (U) - 7 (E) 1 (D) - 12 (BW) Below 1 ohms AUTO DOWN 6 (U) -7 (E) 1 (D) - 12 (BW) Below 1ohms NG: REPLACE MULTIPLEX NETWORK SWITCH ASSEMBLY OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network master switch assembly to power window regulator switch assembly (Rear LH).

Scheme 7

Scheme 8

1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (REAR LH) Remove the switch. Measure the resistance of the switch when the switch is operated. Resistance RESISTANCE SPECIFICATION Switch Condition Tester Connection Specified Condition UP 1 (D) - 2 (SD) 3 (U) - 4 (B) Below 1 ohms OFF 1 (D) - 2 (SD) 3 (U) - 5 (SU) Below 1 ohms DOWN 1 (D) - 4 (B) 3 (U) - 5 (SU) Below 1 ohms NG: REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (REAR LH) OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signals from the multiplex network master switch assembly to power window regulator switch assembly (Rear RH).

Scheme 9

Scheme 10

1. INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY (REAR RH) Remove the switch. Measure the resistance of the switch when the switch is operated. Resistance RESISTANCE SPECIFICATION Switch Condition Tester Connection Specified Condition UP 1 (D) - 2 (SD) 3 (U) - 4 (B) Below 1 ohms OFF 1 (D) - 2 (SD) 3 (U) - 5 (SU) Below 1 ohms AUTO DOWN 1 (D) - 4 (B) 3 (U) - 5 (SU) Below 1 ohms NG: REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY (REAR RH) OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signal from the multiplex network master switch assembly to power window regulator motor assembly (Driver side).

Scheme 11

Scheme 12

Scheme 13

1. INSPECT POWER WINDOW REGULATOR MOTOR (DRIVER SIDE) Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminal 1 and 2. Standard POWER WINDOW REGULATOR MOTOR SPECIFIED CONDITION Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR (DRIVER SIDE) OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK MASTER SWITCH) Disconnect the H4 and H6 connectors. Measure the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition H4-1 - H6-9 Always Below 1 ohms H4-2 - H6-4 Always Below 1 ohms H4-1 - Body ground Always 10 kohms or higher H4-2 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signal from the multiplex network switch to power window regulator motor.

Scheme 14

Scheme 15

Scheme 16

1. INSPECT POWER WINDOW REGULATOR MOTOR (FRONT PASSENGER SIDE) Remove the power window motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Standard POWER WINDOW REGULATOR MOTOR SPECIFIED CONDITION Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR (FRONT PASSENGER SIDE) OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - MULTIPLEX NETWORK SWITCH) Disconnect the G4 and G6 connectors. Measure the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition G4-2 - G6-6 Always Below 1 ohms G4-1 - G6-1 Always Below 1 ohms G4-2 - Body ground Always 10 kohms or higher G4-1 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signal from the power window regulator switch assembly (Rear LH) to power window regulator motor assembly (Rear LH).

Scheme 17

Scheme 18

Scheme 19

1. INSPECT POWER WINDOW REGULATOR MOTOR (REAR LH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery to any terminals except terminals 1 and 2. Standard POWER WINDOW REGULATOR MOTOR SPECIFIED CONDITION Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (U) Battery negative (-) --> Terminal 2 (D) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR (REAR LH) OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - POWER WINDOW REGULATOR SWITCH) Disconnect the J2 and J4 connectors. Measure the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition J4-1 - J2-3 Always Below 1 ohms J4-2 - J2-1 Always Below 1 ohms J4-1 - Body ground Always 10 kohms or higher J4-2 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

This circuit transmits signal from the power window regulator switch assembly (Rear RH) to power window regulator motor assembly (Rear RH).

Scheme 20

Scheme 21

Scheme 22

1. INSPECT POWER WINDOW REGULATOR MOTOR (REAR RH) Remove the power window regulator motor. Apply battery voltage to the motor connector according to the table below. NOTE: Do not apply battery voltage to any terminals except terminals 1 and 2. Standard POWER WINDOW REGULATOR MOTOR SPECIFIED CONDITION Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (U) Battery negative (-) --> Terminal 2 (D) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates counterclockwise NG: REPLACE POWER WINDOW REGULATOR MOTOR (REAR RH) OK: Go to next step
2. CHECK WIRE HARNESS (WINDOW REGULATOR MOTOR - POWER WINDOW REGULATOR SWITCH) Disconnect the 12 and 14 connectors. Measure the resistance of the wire harness side connectors. Resistance RESISTANCE SPECIFICATION Tester Connection Condition Specified Condition 14-1 - I2 - 3 Always Below 1 ohms I4-2 - 12 - 1 Always Below 1 ohms 14-1 - Body ground Always 10 kohms or higher I4-2 - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS OR CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

When the window lock switch on the multiplex network master switch is in the LOCK position, the front passenger door power window regulator and rear LH and RH power window switches cannot operate their respective power windows.

Scheme 23

Scheme 24

Scheme 25

1. CHECK MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY Remove the multiplex network master switch with connector still connected. Measure the voltage of the wire harness side connector. Standard voltage VOLTAGE SPECIFICATION Switch Condition Tester Connection Specified Condition H6-15 (PCT) - Body ground Window lock switch is OFF --> ON 0 V --> 2 V or less H6-13 (TX) - Body ground Ignition switch ON 10 to 14 V NG: REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY OK: Go to next step
2. CHECK WIRE HARNESS (MULTIPLEX NETWORK MASTER SWITCH - MULTIPLEX NETWORK SWITCH) Disconnect the H6 and G6 connectors. Measure the resistance of the wire harness side connector. Standard resistance RESISTANCE SPECIFICATION Switch Condition Tester Connection Specified Condition H6-15 (PCT) - G6-11 (PCT) Always Below 1 ohms H6-15 (PCT) - Body ground Always 10 kohms or higher H6-13 (TX) - G6-2 (RX) Always Below 1 ohms H6-13 (TX) - Body ground Always 10 kohms or higher NG: REPAIR OR REPLACE HARNESS AND CONNECTOR OK : PROCEED TO NEXT INSPECTION PROCEDURE SHOWN IN PROBLEM SYMPTOMS TABLE

Scheme 26

1. INSPECT FRONT PASSENGER POWER WINDOW SWITCH ASSEMBLY Remove the multiplex network switch assembly. Measure the resistance of the switch when the switch is operated. Resistance RESISTANCE SPECIFICATION Switch Condition Tester Connection Specified Condition AUTO UP 1 (D) - 7 (E) 6 (U) - 12 (BW) Below 1 ohms UP 1 (D) - 7 (E) 6 (U) -12 (BW) Below 1 ohms OFF 1 (D) - 7 (E) 6 (U) - 7 (E) Below 1 ohms DOWN 6 (U) - 7 (E) 1 (D) - 12 (BW) Below 1 ohms AUTO DOWN 6(U) - 7 (E) 1 (D) - 12 (BW) Below 1 ohms If the result is not as specified, replace the multiplex network switch assembly.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

Scheme 32

Scheme 33

Scheme 34

1. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Driver Side) Check operation of the regulator motor. Remove the power window regulator motor assembly. Apply battery voltage to the motor terminals. NOTE: Do not apply voltage to the terminals except 1 and 2. Check that the motor operates smoothly. OK DRIVER SIDE POWER WINDOW OPERATION CONDITIONS Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates counterclockwise Check the PTC operation inside the regulator motor. NOTE: The work must be performed with the power window regulator and door glass installed in the vehicle. Disconnect the driver side power window regulator motor connector. Connect the ammeter's positive (+) lead to terminal 1 (D) of the wire harness side connector and the negative (-) lead to the battery's negative terminal. Connect the battery's positive (+) lead to terminal 2 (U) of the wire harness side connector, and raise the window to the fully closed position. Continue to apply voltage, and check that the current changes to less than 1 A within 4 to 90 seconds. Disconnect the leads from the terminals. Approximately 60 seconds later, connect the battery's positive (+) lead to terminal 1 (D) and the negative (-) lead to terminal 2 (U). Check that the window begins to descend. If the result is not as specified, replace the motor assembly.
2. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY Check operation of the regulator motor. Remove the power window regulator motor assembly. Apply battery voltage to the motor terminals. NOTE: Do not apply voltage to the terminals except 1 and 2. Check that the motor operates smoothly. OK DRIVER SIDE POWER WINDOW OPERATION CONDITIONS Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (D) Battery negative (-) --> Terminal 2 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (U) Battery negative (-) --> Terminal 1 (D) Motor gear rotates counterclockwise Check the PTC operation inside the regulator motor. NOTE: The work must be performed with the power window regulator and door glass installed in the vehicle. Disconnect the driver side power window regulator motor connector. Connect the ammeter's positive (+) lead to terminal 2 (U) of the wire harness side connector and the negative (-) lead to the battery's negative terminal. Connect the battery's positive (+) lead to terminal 1 (D) of the wire harness side connector, and raise the window to the fully closed position. Continue to apply voltage, and check that the current changes to less than 1 A within 4 to 90 seconds. Disconnect the leads from the terminals. Approximately 60 seconds later, connect the battery's positive (+) lead to terminal 2 (U) and the negative (-) lead to terminal 1 (D). Check that the window begins to descend. If the result is not as specified, replace the motor assembly.
3. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear LH) Check operation of the regulator motor. Remove the power window regulator motor assembly. Apply battery voltage to the motor terminals. NOTE: Do not apply voltage to the terminals except 1 and 2. Check that the motor operates smoothly. OK DRIVER SIDE POWER WINDOW OPERATION CONDITIONS Measurement Condition Specified Condition Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates clockwise Battery positive (+) --> Terminal 1 (U) Battery negative (-) --> Terminal 2 (D) Motor gear rotates counterclockwise Check the PTC operation inside the regulator motor. NOTE: The work must be performed with the power window regulator and door glass installed in the vehicle. Disconnect the driver side power window regulator motor connector. Connect the ammeter's positive (+) lead to terminal 1 (U) of the wire harness side connector and the negative (-) lead to the battery's negative terminal. Connect the battery's positive (+) lead to terminal 2 (D) of the wire harness side connector, and raise the window to the fully closed position. Continue to apply voltage, and check that the current changes to less than 1 A within 4 to 90 seconds. Disconnect the leads from the terminals. Approximately 60 seconds later, connect the battery's positive (+) lead to terminal 1 (U) and the negative (-) lead to terminal 2 (D). Check that the window begins to descend. If the result is not as specified, replace the motor assembly.
4. INSPECT POWER WINDOW REGULATOR MOTOR ASSEMBLY (for Rear RH) Check operation of the regulator motor. Remove the power window regulator motor assembly. Apply battery voltage to the motor terminals. NOTE: Do not apply voltage to the terminals except land 2. Check that the motor operates smoothly. OK DRIVER SIDE POWER WINDOW OPERATION CONDITIONS Measurement Condition Specified Condition Battery positive (+) --> Terminal 1 (U) Battery negative (-) --> Terminal 2 (D) Motor gear rotates clockwise Battery positive (+) --> Terminal 2 (D) Battery negative (-) --> Terminal 1 (U) Motor gear rotates counterclockwise Check the PTC operation inside the regulator motor. NOTE: The work must be performed with the power window regulator and door glass installed in the vehicle. Disconnect the driver side power window regulator motor connector. Connect the ammeter's positive (+) lead to terminal 2 (D) of the wire harness side connector and the negative (-) lead to the battery's negative terminal. Connect the battery's positive (+) lead to terminal 1 (U) of the wire harness side connector, and raise the window to the fully closed position. Continue to apply voltage, and check that the current changes to less than 1 A within 4 to 90 seconds. Disconnect the leads from the terminals. Approximately 60 seconds later, connect the battery's positive (+) lead to terminal 2 (D) and the negative (-) lead to terminal 1 (U). Check that the window begins to descend. If the result is not as specified, replace the motor assembly.

Scheme 35

1. The defogger system and rear view mirror system use heater wires to defog the rear windshield and rear view mirror, respectively. The defogger switch is installed on the vehicles equipped with the rear window defogger system and rear view mirror system. The defogger switch operates both the defogger system and the rear view heater system. Both systems are part of the same circuit.
2. This system is activated when the ignition switch is turned on (IG) and the rear window defogger switch is pushed. This switch is provided with a timer function to keep the defogger and mirror heater on for approximately. 15 minutes.
