Engine Control System Sfi System (Diagnostic Codes (P0136 - P0441)): Other Toyota Avalon XX30 рестайлинг 2

MONITOR STRATEGY

TYPICAL ENABLING CONDITIONS

ALL

HO2S VOLTAGE (P0136, P0156), HO2S LOW VOLTAGE (P0137, P0157), HO2S HIGH VOLTAGE (P0138, P0158)

HO2S LOW IMPEDANCE (P0136, P0156)

HO2S HIGH IMPEDANCE (P0137, P0157)

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

HO2S VOLTAGE (DURING FUEL CUT) (P0139, P0159)

TYPICAL MALFUNCTION THRESHOLDS

HO2S VOLTAGE (P0136, P0156)

HO2S LOW IMPEDANCE (P0136, P0156)

HO2S HIGH IMPEDANCE (P0137, P0157)

HO2S LOW VOLTAGE (P0137, P0157)

HO2S HIGH VOLTAGE (P0138, P0158)

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

HO2S VOLTAGE (DURING FUEL CUT) (P0139, P0159)

COMPONENT OPERATING RANGE

MONITOR RESULT

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 167

CONFIRMATION DRIVING PATTERN

P0136, P0137, P0138, P0156, P0157 and P0158

Scheme 168

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the transmission in 4th gear or more, drive the vehicle at 37 to 75 mph (60 to 120 km/h) for 10 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTCs [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [C] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P0159

Scheme 169

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at 37 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTCs [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0139 or P0159.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2nd and then perform step [C] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

HO2S VOLTAGE (P0136, P0156), HO2S LOW VOLTAGE (P0137, P0157), HO2S HIGH VOLTAGE (P0138, P0158)

HO2S LOW IMPEDANCE (P0136, P0156)

HO2S HIGH IMPEDANCE (P0137, P0157)

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

HO2S VOLTAGE (DURING FUEL CUT) (P0139, P0159)

HO2S VOLTAGE (P0136, P0156)

HO2S LOW IMPEDANCE (P0136, P0156)

HO2S HIGH IMPEDANCE (P0137, P0157)

HO2S LOW VOLTAGE (P0137, P0157)

HO2S HIGH VOLTAGE (P0138, P0158)

HO2S HIGH VOLTAGE (EXTREMELY HIGH) (P0138, P0158)

HO2S VOLTAGE (DURING FUEL CUT) (P0139, P0159)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

P0136, P0137, P0138, P0156, P0157 and P0158

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. With the transmission in 4th gear or more, drive the vehicle at 37 to 75 mph (60 to 120 km/h) for 10 minutes or more [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTCs [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0136, P0137, P0138, P0156, P0157 or P0158.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [C] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

P0139 and P0159

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
7. Drive the vehicle at 37 mph (60 km/h), and then decelerate the vehicle by releasing the accelerator pedal for 5 seconds or more to perform the fuel-cut [C].
8. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
9. Read the pending DTCs [D].
10. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0139 or P0159.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, move the shift lever to 2nd and then perform step [C] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

PROCEDURE

1. READ OTHER DTC OUTPUT Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0138 or P0158 is output A DTC P0137 or P0157 is output B DTC P0136 or P0156 is output C DTC P0139 or P0159 is output D DTC P0136, P0137, P0138, P0156, P0157 or P0158 and other DTCs are output E B --> See step 9 C --> See step 7 D --> See step 18 E --> See step 28 A: Go to next step
2. READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF HEATED OXYGEN SENSOR) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / O2S B1S2 or O2S B2S2. Allow the engine to idle. Read the Heated Oxygen (HO2) sensor output voltage while idling. Result Result Proceed to 1.0 V or more A Less than 1.0 V B B --> See step 5 A: Go to next step
3. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 2) Tester Connection Condition Specified Condition 2 (+B) - 4 (E) Always 10 kohms or higher 2 (+B) - 3 (OX1B) Always 10 kohms or higher Standard resistance (Bank 2 sensor 2) Tester Connection Condition Specified Condition 2 (+B) - 4 (E) Always 10 kohms or higher 2 (+B) - 3 (OX2B) Always 10 kohms or higher Reconnect the heated oxygen sensor connector. NG --> See step 22 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the ignition switch off and wait for 5 minutes. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition B50-48 (HT1B) - B50-88 (OX1B) Always 10 kohms or higher B50-47 (HT2B) - B50-87 (OX2B) Always 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK --> See step 23
5. PERFORM ACTIVE TEST USING TECHSTREAM (INJECTION VOLUME) Connect the Techstream to the DLC3. Start the engine. Turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume. Change the fuel injection volume using the Techstream, and monitoring the voltage output of air fuel ratio and heated oxygen sensors displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% and +12%. The injection volume can be changed in 0.1 or 0.2% graduations within the range. The air fuel ratio sensor is displayed as AFS Voltage B1S1 or AFS Voltage B2S1, and the heated oxygen sensor is displayed as O2S B1S2 or O2S B2S2, on the Techstream. Result Result Voltage Variation Proceed to AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Alternates between more and less than 3.3 V OK AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Remains at more than 3.3 V NG AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Remains at less than 3.3 V NG HINT: A normal heated oxygen sensor voltage (O2S B1S2 or O2S B2S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage remains at either less or more than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. NG --> See step 15 OK: Go to next step
6. CHECK AIR FUEL RATIO SENSOR CURRENT HINT: This air fuel ratio sensor test is to check the air fuel ratio sensor current during the fuel-cut. When the sensor is normal, the sensor current will indicate below 3.0 mA in this test. Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Perform the drive pattern as listed below. Warm-up the engine until the engine coolant temperature is 75°C (167°F) or more. Drive the vehicle at 37 mph (60 km/h) or more and decelerate the vehicle for 5 seconds or more. Repeat the deceleration above at 3 times. Enter the following menu items: Powertrain / Engine / Monitor / O2 Sensor / Details. Confirm that RANGE B1S1 and RANGE B2S1 are either PASS or FAIL. If the Techstream shows Incomplete, re-check RANGE B1S1 and RANGE B2S1 after performing the drive pattern. Select the RANGE B1S1 and RANGE B2S1. Read the test value. Standard current Less than 3.0 mA HINT: If the Techstream shown Incomplete again, add the vehicle speed and use the second gear to decelerate the vehicle. OK --> See step 12 NG --> See step 15
7. READ VALUE USING TECHSTREAM (O2S B1S2 OR O2S B2S2) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Enter the following menus: Powertrain / Engine / Data List / All Data / O2S B1S2 or O2S B2S2. After warming up the engine, run the engine at an engine speed of 2500 rpm for 3 minutes. Read the output voltage of the HO2 sensor when the engine rpm is suddenly increased. HINT: Quickly accelerate the engine to 4000 rpm 3 times using the accelerator pedal. Standard voltage Fluctuates between 0.4 V or less and 0.55 V or more. NG --> See step 9 OK: Go to next step
8. PERFORM ACTIVE TEST USING TECHSTREAM (INJECTION VOLUME) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine. Enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume. Change the fuel injection volume using the Techstream, and monitoring the voltage output of air fuel ratio and heated oxygen sensor displayed on the Techstream. HINT: Change the fuel injection volume within the range of -12% and +12%. The injection volume can be changed in 0.1 or 0.2% graduations within the range. The air fuel ratio sensor is displayed as AFS Voltage B1S1 or AFS Voltage B2S1, and the heated oxygen sensor is displayed as O2S B1S2 or O2S B2S2, on the Techstream. Result Result Voltage Variation Proceed to AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Alternates between more and less than 3.3 V OK AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Remains more than 3.3 V NG AFS Voltage B1S1 (Air fuel ratio) AFS Voltage B2S1 (Air fuel ratio) Remains less than 3.3 V NG HINT: A normal heated oxygen sensor voltage (O2S B1S2 or O2S B2S2) reacts in accordance with increases and decreases in fuel injection volumes. When the air fuel ratio sensor voltage remains either less or more than 3.3 V despite the heated oxygen sensor indicating a normal reaction, the air fuel ratio sensor is malfunctioning. NG --> See step 15 OK --> See step 24
9. INSPECT FOR EXHAUST GAS LEAK Check for exhaust gas leakage from the exhaust manifold and pipe. OK No exhaust gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK: Go to next step
10. INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 2) Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT1B) - 4 (E) Always 10 kohms or higher Standard resistance (Bank 2 sensor 2) Tester Connection Condition Specified Condition 1 (HT2B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT2B) - 4 (E) Always 10 kohms or higher Reconnect the heated oxygen sensor connector. NG --> See step 25 OK: Go to next step
11. CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B3-1 (HT1B) - B50-48 (HT1B) Always Below 1 ohms B3-3 (OX1B) - B50-88 (OX1B) Always Below 1 ohms B3-4 (E) - B50-65 (EX1B) Always Below 1 ohms B2-1 (HT2B) - B50-47 (HT2B) Always Below 1 ohms B2-3 (OX2B) - B50-87 (OX2B) Always Below 1 ohms B2-4 (E) - B50-64 (EX2B) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B3-1 (HT1B) or B50-48 (HT1B) - Body ground Always 10 kohms or higher B3-3 (OX1B) or B50-88 (OX1B) - Body ground Always 10 kohms or higher B3-4 (E) or B50-65 (EX1B) - Body ground Always 10 kohms or higher B2-1 (HT2B) or B50-47 (HT2B) - Body ground Always 10 kohms or higher B2-3 (OX2B) or B50-87 (OX2B) - Body ground Always 10 kohms or higher B2-4 (E) or B50-64 (EX2B) - Body ground Always 10 kohms or higher Reconnect the heated oxygen sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK: Go to next step
12. REPLACE HEATED OXYGEN SENSOR Replace the heated oxygen sensor. Refer to «REMOVAL»(ref-428893-S20676909622011101200000) . NEXT: Go to next step
13. PERFORM CONFIRMATION DRIVING PATTERN Refer to the «CONFIRMATION DRIVING PATTERN»(ref-428884-S35666484862011101200000) for P0136, P0137, P0138, P0156, P0157 and P0158. NEXT: Go to next step
14. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0137, P0138, P0156, P0157 OR P0158) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input DTC: P0136, P0137, P0138, P0156, P0157 or P0158. Check the DTC Monitor is NORMAL. If DTC Monitor is INCOMPLETE, perform the drive pattern adding the vehicle speed and using the second gear to decelerate the vehicle. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0136, P0137, P0138, P0156, P0157 or P0158 is output) B B --> See step 26 A --> END
15. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-428893-S38119987512011101200000) . NEXT: Go to next step
16. PERFORM CONFIRMATION DRIVING PATTERN Refer to the «CONFIRMATION DRIVING PATTERN»(ref-428884-S35666484862011101200000) for P0136, P0138, P0156 and P0158. NEXT: Go to next step
17. CHECK WHETHER DTC OUTPUT RECURS (DTC P0136, P0138, P0156 OR P0158) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input DTC: P0136, P0138, P0156 or P0158. Check the DTC Monitor is NORMAL. If DTC Monitor is INCOMPLETE, perform the drive pattern adding the vehicle speed and using the second gear to decelerate the vehicle. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0136, P0138, P0156 or P0158 is output) B B --> See step 25 A --> END
18. READ VALUE USING TECHSTREAM (OUTPUT VOLTAGE OF HEATED OXYGEN SENSOR) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / O2S B1S2 or O2S B2S2. Allow the engine to idle. Read the Heated Oxygen (HO2) sensor output voltage while idling. Result Result Proceed to 1.0 V or more A Less than 1.0 V B B --> See step 21 A: Go to next step
19. INSPECT HEATED OXYGEN SENSOR (CHECK FOR SHORT) Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 2) Tester Connection Condition Specified Condition 2 (+B) - 4 (E) Always 10 kohms or higher 2 (+B) - 3 (OX1B) Always 10 kohms or higher Standard resistance (Bank 2 sensor 2) Tester Connection Condition Specified Condition 2 (+B) - 4 (E) Always 10 kohms or higher 2 (+B) - 3 (OX2B) Always 10 kohms or higher Reconnect the heated oxygen sensor connectors. NG --> See step 25 OK: Go to next step
20. CHECK HARNESS AND CONNECTOR (CHECK FOR SHORT) Turn the ignition switch off and wait for 5 minutes. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition B50-48 (HT1B) - B50-88 (OX1B) Always 10 kohms or higher B50-47 (HT2B) - B50-87 (OX2B) Always 10 kohms or higher Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (HEATED OXYGEN SENSOR - ECM) OK --> See step 23
21. READ VALUE USING DTC OUTPUT (DTC P0139 OR P0159 IS OUTPUT AGAIN) Connect the Techstream to the DLC3. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off and wait for 30 seconds [A]. Start the engine. Warm-up the engine until the engine coolant temperature is 75°(167°F) or more [B]. Drive the vehicle 37 mph (60 km/h) and decelerate the vehicle for 5 seconds or more [C]. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Utility / All Readiness [D]. Input DTCs: P0139 and P0159. Check that DTC Monitor is NORMAL. If DTC Monitor is Incomplete, perform the driving pattern increasing the vehicle speed and using the second gear to decelerate the vehicle. Result Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0139 or P0159 is output) B B --> See step 25 A --> See step 27
22. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-428893-S20676909622011101200000)
23. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
24. CHECK AND REPAIR EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO (INJECTOR, FUEL PRESSURE, GAS LEAKAGE FROM EXHAUST SYSTEM). Refer to «INSPECTION PROCEDURE»(ref-428884-S32647372322011101200000)
25. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-428893-S20676909622011101200000)
26. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
27. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
28. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (RICH TO LEAN)

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (LEAN TO RICH)

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (RICH TO LEAN)

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (LEAN TO RICH)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

Scheme 170

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
5. Turn the ignition switch off and wait for 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details.
8. Check that the RES RATE B1S1 and RES RATE B2S1 are Incomplete.
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
11. Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RES RATE B1S1 and RES RATE B2S1.
12. If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-428881-S42545175372011101200000) .
13. Note the value of the Monitor Result.
14. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
15. Read the pending DTCs [C].
16. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
20. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
21. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
22. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-428885-S19238502512011101200000) NG --> See step 11 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 14»(ref-428883-S05023102132011101200000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 12 OK: Go to next step
5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output A DTC is not output B B --> See step 13 A: Go to next step
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-428893-S38119987512011101200000) . NEXT: Go to next step
8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output B B --> See step 14 A --> END
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
11. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
12. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
13. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
14. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-428884-S42252314502011101200000)

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (RICH TO LEAN)

AIR FUEL RATIO SENSOR (BANK 1, 2) SLOW RESPONSE (LEAN TO RICH)

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (RICH TO LEAN)

AIR FUEL RATIO SENSOR (BANK 1, 2) DELAYED RESPONSE (LEAN TO RICH)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

Performing this confirmation pattern will activate the air fuel ratio sensor response monitor.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
5. Turn the ignition switch off and wait for 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details.
8. Check that the RES RATE B1S1 and RES RATE B2S1 are Incomplete.
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at a constant speed of between 47 and 62 mph (75 and 100 km/h) for 10 minutes [B].
11. Check the monitor result values on the Techstream by entering the following menus: Powertrain / Engine / Monitor / O2 Sensor / Details / RES RATE B1S1 and RES RATE B2S1.
12. If the values indicated on the Techstream do not change, perform Readiness Monitor Drive Pattern for the air fuel ratio sensor and heated oxygen sensor. Refer to «READINESS MONITOR DRIVE PATTERN»(ref-428881-S04270597662011101200000) .
13. Note the value of the Monitor Result.
14. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
15. Read the pending DTCs [C].
16. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
17. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
18. Input the DTC: P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D.
19. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
20. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
21. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
22. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK ANY OTHER DTCS OUTPUT (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D is output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D and other DTCs are output B HINT: If any DTCs other than P014C, P014D, P014E, P014F, P015A, P015B, P015C or P015D are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
2. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE). Refer to «PROCEDURE - Step 1»(ref-428885-S22429056232011101200000) NG --> See step 11 OK: Go to next step
3. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ECM). Refer to «PROCEDURE - Step 14»(ref-428883-S16767128962011101200000) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
4. INSPECT AIR FUEL RATIO SENSOR Check that the proper air fuel ratio sensors are installed to the vehicle. NG --> See step 12 OK: Go to next step
5. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output A DTC is not output B B --> See step 13 A: Go to next step
7. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-428893-S38119987512011101200000) . NEXT: Go to next step
8. PERFORM CONFIRMATION DRIVING PATTERN Drive the vehicle according to the Confirmation Driving Pattern. NEXT: Go to next step
9. CHECK WHETHER DTC OUTPUT RECURS (DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C OR P015D) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P014C, P014D, P014E, P014F, P015A, P015B, P015C and/or P015D are output B B --> See step 14 A --> END
10. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
11. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
12. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
13. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
14. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEAN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-428884-S32647372322011101200000)

FUEL-TRIM

FUEL TRIM

Scheme 171

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
7. With the engine warmed up, idle the engine for 2 minutes or more [C].
8. Drive the vehicle at between 37 and 75 mph (60 and 120 km/h) and at an engine speed of between 1400 and 3200 rpm for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTCs [E]. HINT: If a pending DTC is output, the system is malfunctioning

FUEL-TRIM

FUEL TRIM

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) with all the accessories switched off [B].
7. With the engine warmed up, idle the engine for 2 minutes or more [C].
8. Drive the vehicle at between 37 and 75 mph (60 and 120 km/h) and at an engine speed of between 1400 and 3200 rpm for 5 minutes or more [D].
9. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
10. Read the pending DTCs [E]. HINT: If a pending DTC is output, the system is malfunctioning

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0171, P0172, P0174 OR P0175) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0171, P0172, P0174 or P0175 are output A DTC P0171, P0172, P0174 or P0175 and other DTCs are output B HINT: If any DTCs other than P0171, P0172, P0174 or P0175 are output, troubleshoot those DTCs first. B --> See step 23 A: Go to next step
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
3. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from the air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
4. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine at an engine speed of 2500 rpm for approximately 90 seconds. Select the following menu items on the Techstream: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the voltage outputs of the A/F and HO2 sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Standard Voltage Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) +25% Rich Less than 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) -12.5% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (HO2) +25% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (HO2) -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 A/F Condition and A/F Sensor Condition Misfire Suspected Trouble Area Proceed to Lean/Rich Lean/Rich Normal - - A Lean Lean Actual air-fuel ratio lean May occur PCV valve and hose PCV hose connections Injector blockage Gas leakage from exhaust system Air induction system Fuel pressure Mass Air Flow (MAF) meter Engine Coolant Temperature (ECT) sensor A Rich Rich Actual air-fuel ratio rich - Injector leakage or blockage Gas leakage from exhaust system Ignition system Fuel pressure MAF meter ECT sensor A Lean Lean/Rich A/F sensor malfunction - A/F sensor B Rich Lean/Rich A/F sensor malfunction - A/F sensor B Lean: During the Control the Injection Volume for A/F Sensor, the A/F sensor output voltage (AFS) is consistently more than 3.4 V, and the HO2 sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the heated oxygen sensor alternates correctly. B --> See step 11 A: Go to next step
5. READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Select the following menu items: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the Coolant Temp twice, when the engine is both cold and warmed up. Standard With cold engine Same as ambient air temperature. With warm engine Between 75°C and 95°C (167°F and 203°F) NG --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR OK: Go to next step
6. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Start the engine and warm it up. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 12 g/sec. and 17 g/sec. (shift lever: N; A/C: Off). NG --> See step 16 OK: Go to next step
7. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-428895-S35867406742011101200000) . NG --> REPAIR OR REPLACE FUEL SYSTEM OK: Go to next step
8. INSPECT FOR EXHAUST GAS LEAKS Check for exhaust gas leaks. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST SYSTEM OK: Go to next step
9. CHECK FOR SPARKS AND IGNITION Check for sparks and ignition. Refer to «ON-VEHICLE INSPECTION»(ref-428874-S08175027342011101200000) . HINT: If the spark plugs or ignition system malfunction, engine misfire may occur. The misfire count can be read using Techstream. Select the following menu items: Powertrain / Engine / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #6 Misfire Count). NG --> REPAIR OR REPLACE IGNITION SYSTEM OK: Go to next step
10. INSPECT FUEL INJECTOR ASSEMBLY (INJECTION AND VOLUME) Inspect the fuel injector assembly. Refer to «INSPECTION»(ref-428891-S35895714442011101200000) . HINT: If the injectors malfunction, engine misfire may occur. The misfire count can be read using Techstream. Select the following menu items: Powertrain / Engine / Data List / All Data / Cylinder #1 Misfire Count (to Cylinder #6 Misfire Count). OK --> See step 15 NG --> See step 24
11. INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Disconnect the A/F sensor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Bank 1 Sensor 1) Standard Resistance (Bank 2 Sensor 1) Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA1A) - 4 (A1A-) Always 10 kohms or higher Tester Connection Condition Specified Condition 1 (HA2A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA2A) - 4 (A2A-) Always 10 kohms or higher Reconnect the A/F sensor connector. NG --> See step 25 OK: Go to next step
12. CHECK TERMINAL VOLTAGE (+B OF A/F SENSOR). Refer to «PROCEDURE - Step 2»(ref-428885-S22429056232011101200000) NG --> See step 21 OK: Go to next step
13. CHECK HARNESS AND CONNECTOR (A/F SENSOR - ECM) Disconnect the A/F sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B32-1 (HA1A) - B50-86 (HA1A) Always Below 1 ohms B32-3 (A1A+) - B50-93 (A1A+) Always Below 1 ohms B32-4 (A1A-) - B50-116 (A1A-) Always Below 1 ohms B26-1 (HA2A) - B50-109 (HA2A) Always Below 1 ohms B26-3 (A2A+) - B50-120 (A2A+) Always Below 1 ohms B26-4 (A2A-) - B50-119 (A2A-) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B32-1 (HA1A) or B50-86 (HA1A) - Body ground Always 10 kohms or higher B32-3 (A1A+) or B50-93 (A1A+) - Body ground Always 10 kohms or higher B32-4 (A1A-) or B50-116 (A1A-) - Body ground Always 10 kohms or higher B26-1 (HA2A) or B50-109 (HA2A) - Body ground Always 10 kohms or higher B26-3 (A2A+) or B50-120 (A2A+) - Body ground Always 10 kohms or higher B26-4 (A2A-) or B50-119 (A2A-) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the A/F sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
14. REPLACE AIR FUEL RATIO SENSOR Replace the air fuel ratio sensor. Refer to «REMOVAL»(ref-428893-S38119987512011101200000) . NEXT: Go to next step
15. PERFORM CONFIRMATION DRIVING PATTERN Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Select the following menu items: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0171, P0172, P0174 or P0175 is output B B --> See step 16 A --> END
16. CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-428782-S21492416292011101200000) . HINT: Repair any problems. NEXT: Go to next step
17. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC P0171, P0172, P0174 or P0175 is output A DTC is not output B B --> END A: Go to next step
18. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B50-72 (VG) - B10-5 (VG) Always Below 1 ohms B50-73 (E2G) - B10-4 (E2G) Always Below 1 ohms B50-72 (VG) or B10-5 (VG) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
19. REPLACE MASS AIR FLOW METER Replace the mass air flow meter. HINT: If the result of the inspection performed in step 6 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
20. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off and wait for 30 seconds. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. RESULT Result Proceed to DTC is not output A DTC P0171, P0172, P0174 or P0175 is output B B --> See step 26 A --> END
21. CHECK HARNESS AND CONNECTOR (AIR FUEL RATIO SENSOR - ENGINE ROOM JUNCTION BLOCK) Disconnect the air fuel ratio sensor connector. Remove the engine room junction block from the engine room R/B. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B32-2 (+B) - 1C-6 Always Below 1 ohms B26-2 (+B) - 1C-6 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B32-2 (+B) or 1C-6 - Body ground Always 10 kohms or higher B26-2 (+B) or 1C-6 - Body ground Always 10 kohms or higher Reinstall the engine room junction block. Reconnect the air fuel ratio sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (AIR FUEL RATIO SENSOR - ENGINE ROOM JUNCTION BLOCK) OK: Go to next step
22. INSPECT ENGINE ROOM JUNCTION BLOCK (A/F RELAY). Refer to «PROCEDURE - Step 4»(ref-428885-S22429056232011101200000) NG --> REPLACE ENGINE ROOM JUNCTION BLOCK OK --> See step 27
23. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
24. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-428891-S03480314972011101200000)
25. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
26. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
27. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-428883-S06863030212011101200000)

MISFIRE

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

1. Connect Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Record the DTC(s) and freeze frame data.
5. Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-428881-S31273558512011101200000) .
6. Read the misfire counts of each cylinder (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count) with the engine in an idling condition. If any misfire count is displayed, skip the following confirmation driving pattern.
7. Drive the vehicle several times with the conditions, such as engine rpm and engine load, shown in, Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine RPM Duration Idling 3.5 minutes or more 1000 3 minutes or more 2000 1.5 minutes or more 3000 1 minute or more
8. Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be erased.
9. Record the DTC(s), freeze frame data and misfire counts.
10. Turn the ignition switch off and wait for at least 5 seconds.

MISFIRE

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

MONITOR PERIOD OF EMISSION-RELATED-MISFIRE

MONITOR PERIOD OF CATALYST-DAMAGED-MISFIRE (MIL BLINKS)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

1. Connect Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Record the DTC(s) and freeze frame data.
5. Using the Techstream, switch the ECM from normal mode to check mode. Refer to «CHECK MODE PROCEDURE»(ref-428881-S31273558512011101200000) .
6. Read the misfire counts of each cylinder (Cylinder #1 Misfire Count to Cylinder #6 Misfire Count) with the engine in an idling condition. If any misfire count is displayed, skip the following confirmation driving pattern.
7. Drive the vehicle several times with the conditions, such as engine rpm and engine load, shown in, Misfire RPM and Misfire Load in the Data List. HINT: In order to store misfire DTCs, it is necessary to operate the vehicle for the period of time shown in the table below, using the Misfire RPM and Misfire Load in the Data List. Engine RPM Duration Idling 3.5 minutes or more 1000 3 minutes or more 2000 1.5 minutes or more 3000 1 minute or more
8. Check whether misfires have occurred by checking DTCs and freeze frame data. HINT: Do not turn the ignition switch off until the stored DTC(s) and freeze frame data have been recorded. When the ECM returns to normal mode (default), the stored DTC(s), freeze frame data and other data will be erased.
9. Record the DTC(s), freeze frame data and misfire counts.
10. Turn the ignition switch off and wait for at least 5 seconds.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO MISFIRE CODES) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. HINT: Write down the DTCs. Result Result Proceed to DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 is output A DTC P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 and other DTCs are output B HINT: If any DTCs other than P0300, P0301, P0302, P0303, P0304, P0305 and/or P0306 are output, troubleshoot those DTCs first. B --> See step 38 A: Go to next step
2. CHECK PCV HOSE CONNECTIONS Check the PCV hose connections. OK PCV hose is correctly connected and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK: Go to next step
3. READ VALUE USING TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Misfire RPM and Misfire Load. Read and note the Misfire RPM and Misfire Load values. HINT: The Misfire RPM and Misfire Load values indicate the vehicle conditions under which the misfire occurred. NEXT: Go to next step
4. READ VALUE USING TECHSTREAM (CATALYST OT MF F/C) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Catalyst OT MF F/C. Read the value displayed on the Techstream. Result Data List Techstream Display Proceed to Catalyst OT MF F/C Avail A Not Avl B B --> See step 6 A: Go to next step
5. PERFORM ACTIVE TEST USING TECHSTREAM Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Prohibit the Catalyst OT Misfire prevent F/C. Perform the Active Test. NOTE: When performing the Active Test, make sure the vehicle is stopped and the engine is either idling or being revved within 3000 rpm or less. NEXT: Go to next step
6. READ VALUE USING TECHSTREAM (CYLINDER #1 (TO #6) MISFIRE COUNT) Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Cylinder #1 Misfire Count, #2, #3, #4, #5 and #6 Read each value for Cylinder #1 Misfire Count to #6 displayed on the Techstream. If no misfire counts occur in any cylinders, perform the following procedures: Start the engine and let it idle. Move the shift lever to the D. Check the Cylinder #1 Misfire Count to #6. If misfire counts are still not displayed, perform steps [A] and [B]. Drive the vehicle with the Misfire RPM and Misfire Load noted in the "READ VALUE OF TECHSTREAM (MISFIRE RPM AND MISFIRE LOAD)" procedures above [A]. Read the Cylinder #1 Misfire Count to #6 or DTCs displayed on the Techstream [B]. Result Result Proceed to Most misfires occur in only 1 or 2 cylinders A 3 cylinders or more have equal misfire counts B HINT: If it is difficult to reproduce misfires for each cylinder, check the Data List item called Misfire Margin. Try to find vehicle driving conditions that lower the Misfire Margin value. Values above 30% are considered normal. If the freeze frame data's record of the engine coolant temperature is below 75°C (167°F), the misfire may be detected only when the engine is cold. If the freeze frame data's record of the Engine Run Time is below 120 seconds, the misfire may be detected immediately after the engine is started. B --> See step 18 A: Go to next step
7. CHECK SPARK PLUG Remove the ignition coil and the spark plug of the misfiring cylinder. Measure the spark plug electrode gap. Electrode Gap for New Spark Plug 1.0 to 1.1 mm (0.0394 to 0.0433 in.) Maximum Electrode Gap for Used Spark Plug 1.4 mm (0.0551 in.) NOTE: If the electrode gap is more than the maximum, replace the spark plug. Do not adjust the electrode gap. Check the electrode for carbon deposits. RECOMMENDED SPARK PLUG: Manufacturer Product DENSO FK20HR11 Reinstall the ignition coil and spark plug. NG --> REPLACE SPARK PLUG OK: Go to next step
8. CHECK FOR SPARKS AND IGNITION Disconnect the fuel injector assembly connectors to prevent the engine from starting. WARNING: Always disconnect all fuel injector assembly connectors. NOTE: Do not crank the engine for more than 2 seconds. Remove the ignition coil from the cylinder head. Install the spark plug onto the ignition coil. Attach the spark plug assembly to the cylinder head. Crank the engine for less than 2 seconds and check the spark. OK Sparks jump across electrode gap. Install the ignition coil. Reconnect the fuel injector assembly connectors. NG --> See step 34 OK: Go to next step
9. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-428873-S28060745922011101200000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
10. CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE) Disconnect the fuel injector assembly connector (of the misfiring cylinder). Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B39-2 - Body ground Ignition switch ON 11 to 14 V B27-2 - Body ground Ignition switch ON 11 to 14 V B40-2 - Body ground Ignition switch ON 11 to 14 V B28-2 - Body ground Ignition switch ON 11 to 14 V B41-2 - Body ground Ignition switch ON 11 to 14 V B29-2 - Body ground Ignition switch ON 11 to 14 V Reconnect the fuel injector assembly connector. NG --> See step 37 OK: Go to next step
11. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B50-45 (#10) - B39-1 Always Below 1 ohms B50-85 (#20) - B27-1 Always Below 1 ohms B50-44 (#30) - B40-1 Always Below 1 ohms B50-84 (#40) - B28-1 Always Below 1 ohms B50-43 (#50) - B41-1 Always Below 1 ohms B50-83 (#60) - B29-1 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B50-45 (#10) or B39-1 - Body ground Always 10 kohms or higher B50-85 (#20) or B27-1 - Body ground Always 10 kohms or higher B50-44 (#30) or B40-1 - Body ground Always 10 kohms or higher B50-84 (#40) or B28-1 - Body ground Always 10 kohms or higher B50-43 (#50) or B41-1 - Body ground Always 10 kohms or higher B50-83 (#60) or B29-1 - Body ground Always 10 kohms or higher Reconnect the fuel injector assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) OK: Go to next step
12. CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(ref-428891-S35895714442011101200000) . NG --> See step 39 OK: Go to next step
13. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
14. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-428895-S35867406742011101200000) . NG --> See step 36 OK: Go to next step
15. READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR OK: Go to next step
16. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Start the engine and warm it up. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 12 g/sec. and 17 g/sec. (shift lever: N; A/C: Off). NG --> See step 29 OK: Go to next step
17. CHECK VALVE TIMING. Refer to «PROCEDURE - Step 4»(ref-428885-S03803170222011101200000) OK --> See step 29 NG --> ADJUST VALVE TIMING
18. CHECK AIR INDUCTION SYSTEM Check the air induction system for vacuum leakage. OK No leakage from air induction system. NG --> REPAIR OR REPLACE AIR INDUCTION SYSTEM OK: Go to next step
19. CHECK FUEL PRESSURE Check the fuel pressure. Refer to «ON-VEHICLE INSPECTION - Step 2»(ref-428895-S35867406742011101200000) . NG --> See step 36 OK: Go to next step
20. READ VALUE USING TECHSTREAM (COOLANT TEMP) See step 5 NG --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR OK: Go to next step
21. READ VALUE USING TECHSTREAM (MAF) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF and Coolant Temp. Start the engine and warm it up. Allow the engine to idle until Coolant Temp reaches 75°C (167°F) or higher. Read MAF with the engine speed at 3000 rpm. Standard Between 12 g/sec. and 17 g/sec. (shift lever: N; A/C: Off). NG --> See step 29 OK: Go to next step
22. CHECK VALVE TIMING. Refer to «PROCEDURE - Step 4»(ref-428885-S03803170222011101200000) NG --> ADJUST VALVE TIMING OK: Go to next step
23. CHECK SPARK PLUG Remove the ignition coil and the spark plug of the misfiring cylinder. Measure the spark plug electrode gap. Electrode Gap for New Spark Plug 1.0 to 1.1 mm (0.0394 to 0.0433 in.) Maximum Electrode Gap for Used Spark Plug 1.4 mm (0.0551 in.) NOTE: If the electrode gap is more than the maximum, replace the spark plug. Do not adjust the electrode gap. Check the electrode for carbon deposits. RECOMMENDED SPARK PLUG: Manufacturer Product DENSO FK20HR11 Reinstall the ignition coil and spark plug. NG --> REPLACE SPARK PLUG OK: Go to next step
24. CHECK FOR SPARKS AND IGNITION Disconnect the fuel injector assembly connectors to prevent the engine from starting. WARNING: Always disconnect all fuel injector assembly connectors. NOTE: Do not crank the engine for more than 2 seconds. Remove the ignition coil from the cylinder head. Install the spark plug onto the ignition coil. Attach the spark plug assembly to the cylinder head. Crank the engine for less than 2 seconds and check the spark. OK Sparks jump across electrode gap. Install the ignition coil. Reconnect the fuel injector assembly connectors. NG --> See step 34 OK: Go to next step
25. CHECK CYLINDER COMPRESSION PRESSURE Measure the cylinder compression pressure of the misfiring cylinder. Refer to «ON-VEHICLE INSPECTION - Step 4»(ref-428873-S28060745922011101200000) . NG --> CHECK ENGINE TO DETERMINE CAUSE OF LOW COMPRESSION OK: Go to next step
26. CHECK FUEL INJECTOR ASSEMBLY (POWER SOURCE) Disconnect the fuel injector assembly connector (of the misfiring cylinder). Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B39-2 - Body ground Ignition switch ON 11 to 14 V B27-2 - Body ground Ignition switch ON 11 to 14 V B40-2 - Body ground Ignition switch ON 11 to 14 V B28-2 - Body ground Ignition switch ON 11 to 14 V B41-2 - Body ground Ignition switch ON 11 to 14 V B29-2 - Body ground Ignition switch ON 11 to 14 V Reconnect the fuel injector assembly connector. NG --> See step 37 OK: Go to next step
27. CHECK HARNESS AND CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) Disconnect the fuel injector assembly connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B50-45 (#10) - B39-1 Always Below 1 ohms B50-85 (#20) - B27-1 Always Below 1 ohms B50-44 (#30) - B40-1 Always Below 1 ohms B50-84 (#40) - B28-1 Always Below 1 ohms B50-43 (#50) - B41-1 Always Below 1 ohms B50-83 (#60) - B29-1 Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B50-45 (#10) or B39-1 - Body ground Always 10 kohms or higher B50-85 (#20) or B27-1 - Body ground Always 10 kohms or higher B50-44 (#30) or B40-1 - Body ground Always 10 kohms or higher B50-84 (#40) or B28-1 - Body ground Always 10 kohms or higher B50-43 (#50) or B41-1 - Body ground Always 10 kohms or higher B50-83 (#60) or B29-1 - Body ground Always 10 kohms or higher Reconnect the fuel injector assembly connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (FUEL INJECTOR ASSEMBLY - ECM) OK: Go to next step
28. CHECK FUEL INJECTOR ASSEMBLY OF MISFIRING CYLINDER Check the fuel injector assembly injection (whether fuel volume is high or low, and whether injection pattern is poor). Refer to «INSPECTION»(ref-428891-S35895714442011101200000) . NG --> See step 39 OK: Go to next step
29. CHECK HARNESS AND CONNECTOR Check the connection and terminal contact pressure of connectors and wire harnesses between the mass air flow meter and ECM. Refer to «ELECTRONIC CIRCUIT INSPECTION PROCEDURE»(ref-428782-S21492416292011101200000) . HINT: Repair any problems. NEXT: Go to next step
30. CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305 or P0306. Check the DTC judgment result. RESULT Result Proceed to ABNORMAL (DTC P0300, P0301, P0302, P0303, P0304, P0305 or P0306 is output) A NORMAL (DTC is not output) B B --> END A: Go to next step
31. CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the mass air flow meter connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B50-72 (VG) - B10-5 (VG) Always Below 1 ohms B50-73 (E2G) - B10-4 (E2G) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B50-72 (VG) or B10-5 (VG) - Body ground Always 10 kohms or higher Reconnect the mass air flow meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
32. REPLACE MASS AIR FLOW METER Replace the mass air flow meter. HINT: If the results of the inspections performed in steps 16 and 21 indicated no problem, proceed to the next step without replacing the mass air flow meter. NEXT: Go to next step
33. CONFIRM WHETHER MALFUNCTION HAS BEEN SUCCESSFULLY REPAIRED Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine and warm it up. Drive the vehicle in accordance with the driving pattern described in Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Utility / All Readiness. Input the DTC: P0300, P0301, P0302, P0303, P0304, P0305 or P0306. Check the DTC judgment result. RESULT Result Proceed to NORMAL (DTC is not output) A ABNORMAL (DTC P0300, P0301, P0302, P0303, P0304, P0305 or P0306 is output) B B --> See step 40 A --> END
34. CHANGE TO NORMAL SPARK PLUG AND CHECK SPARK OF MISFIRING CYLINDER Change the installed spark plug to a spark plug that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug to the ignition coil and connect the ignition coil connector. Disconnect the injector connector. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 35 OK --> REPLACE SPARK PLUG
35. CHANGE TO NORMAL IGNITION COIL AND CHECK SPARK OF MISFIRING CYLINDER Change the ignition coil to a ignition coil that functions normally. Perform a spark test. WARNING: Always disconnect all injector connectors. NOTE: Do not crank the engine for more than 2 seconds. Install the spark plug into the ignition coil and connect the ignition coil connector. Disconnect the injector connector. Ground the spark plug. Check if sparks occur while the engine is being cranked. OK Sparks jump across electrode gap. NG --> See step 40 OK --> REPLACE IGNITION COIL
36. CHECK FUEL LINE Check the fuel lines for leaks or blockage. NG --> REPAIR OR REPLACE FUEL LINE OK --> See step 41
37. CHECK HARNESS AND CONNECTOR (IG2 RELAY - FUEL INJECTOR ASSEMBLY) Disconnect the fuel injector assembly connector. Remove the IG2 relay from the engine room relay block. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B39-2 - 2 (IG2 relay terminal) Always Below 1 ohms B27-2 - 2 (IG2 relay terminal) Always Below 1 ohms B40-2 - 2 (IG2 relay terminal) Always Below 1 ohms B28-2 - 2 (IG2 relay terminal) Always Below 1 ohms B41-2 - 2 (IG2 relay terminal) Always Below 1 ohms B29-2 - 2 (IG2 relay terminal) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B39-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher B27-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher B40-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher B28-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher B41-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher B29-2 or 2 (IG2 relay terminal) - Body ground Always 10 kohms or higher Reinstall the IG2 relay. Reconnect the fuel injector assembly connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IG2 RELAY - FUEL INJECTOR ASSEMBLY) OK --> See step 42
38. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
39. REPLACE FUEL INJECTOR ASSEMBLY. Refer to «REMOVAL»(ref-428891-S03480314972011101200000)
40. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
41. REPLACE FUEL PUMP. Refer to «REMOVAL»(ref-428891-S16069029372011101200000)
42. CHECK ECM POWER SOURCE CIRCUIT. Refer to «ECM Power Source Circuit»(ref-428883-S06863030212011101200000)

KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332

KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333

Scheme 172

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and wait 10 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTCs [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0327, P0328, P0332 or P0333.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 173

KNOCK SENSOR RANGE CHECK (LOW VOLTAGE) P0327 AND P0332

KNOCK SENSOR RANGE CHECK (HIGH VOLTAGE) P0328 AND P0333

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and wait 10 seconds.
7. Enter the following menus: Powertrain / Engine / Trouble Codes.
8. Read the DTCs [B].
9. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
11. Input the DTC: P0327, P0328, P0332 or P0333.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, idle the engine for 5 minutes.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result [C]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC (CHECK KNOCK SENSOR CIRCUIT) Disconnect the BR1 connector. Using lead wires, connect the connectors as follows: Male Connector - Female Connector Terminal 2 - Terminal 4 Terminal 1 - Terminal 3 Terminal 4 - Terminal 2 Terminal 3 - Terminal 1 Warm up the engine. Run the engine at 3000 rpm for 10 seconds or more. Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Display Proceed to DTCs same as when vehicle brought in P0327, P0328 --> P0327, P0328 or P0332, P0333 --> P0332, P0333 A DTCs different from when vehicle brought in P0327, P0328 --> P0332, P0333 or P0332, P0333 --> P0327, P0328 B Reconnect the BR1 connector. B --> See step 6 A: Go to next step
2. CHECK WIRE HARNESS AND CONNECTOR (BR1 CONNECTOR - ECM) Disconnect the BR1 connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition BR1 female connector 2 - B50-95 (KNK1) Always Below 1 ohms BR1 female connector 1 - B50-94 (EKNK) Always Below 1 ohms BR1 female connector 4 - B50-118 (KNK2) Always Below 1 ohms BR1 female connector 3 - B50-117 (EKN2) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition BR1 female connector 2 or B50-95 (KNK1) - Body ground Always 10 kohms or higher BR1 female connector 1 or B50-94 (EKNK) - Body ground Always 10 kohms or higher BR1 female connector 4 or B50-118 (KNK2) - Body ground Always 10 kohms or higher BR1 female connector 3 or B50-117 (EKN2) - Body ground Always 10 kohms or higher Reconnect the BR1 connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. INSPECT ECM Disconnect the BR1 connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition BR1 female connector 2 - 1 Ignition switch ON 4.5 to 5.5 V BR1 female connector 4 - 3 Ignition switch ON 4.5 to 5.5 V Reconnect the BR1 connector. NG --> See step 4 OK --> See step 5
4. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
5. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
6. INSPECT KNOCK SENSOR Disconnect the BR1 connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Specified Condition BR1 male connector 1 - 2 120 to 280 kohms BR1 male connector 3 - 4 120 to 280 kohms Result Result Proceed to NG A OK B Reconnect the BR1 connector. B --> See step 8 A: Go to next step
7. CHECK HARNESS AND CONNECTOR (BR1 CONNECTOR - KNOCK SENSOR) HINT: If DTC P0327 or P0328 has changed to P0332 or P0333, check the knock sensor circuit on the right bank side. If DTC P0332 or P0333 has changed to P0327 or P0328, check the knock sensor circuit on the left bank side. Disconnect the BR1 connector. Disconnect the knock sensor connectors. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition BR1 male connector 2 - R2-2 Always Below 1 ohms BR1 male connector 1 - R2-1 Always Below 1 ohms BR1 male connector 4 - R1-2 Always Below 1 ohms BR1 male connector 3 - R1-1 Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition BR1 male connector 2 or R2-2 - Body ground Always 10 kohms or higher BR1 male connector 1 or R2-1 - Body ground Always 10 kohms or higher BR1 male connector 4 or R1-2 - Body ground Always 10 kohms or higher BR1 male connector 3 or R1-1 - Body ground Always 10 kohms or higher Reconnect the BR1 connector. Reconnect the knock sensor connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9
8. CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
9. REPLACE KNOCK SENSOR. Refer to «REMOVAL»(ref-428889-S38962461382011101200000)

ALL

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 1)

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 2)

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

P0335: CKP SENSOR VERIFY PULSE INPUT

Scheme 174

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 20 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0335 or P0339.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 175

ALL

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 1)

P0335: CKP SENSOR VERIFY PULSE INPUT (CASE 2)

P0335: CKP SENSOR RANGE CHECK/RATIONALITY

P0335: CKP SENSOR VERIFY PULSE INPUT

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 20 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0335 or P0339.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. INSPECT CRANKSHAFT POSITION SENSOR Disconnect the crankshaft position (CKP) sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 Cold 1630 to 2740 ohms 1 - 2 Hot 2065 to 3225 ohms HINT: Terms "cold" and "hot" refer to the temperature of the coils. "Cold" means approximately -10 to 50°C (14 to 122°F). "Hot" means approximately 50 to 100°C (122 to 212°F). Reconnect the CKP sensor connector. NG --> See step 5 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (CRANKSHAFT POSITION SENSOR - ECM) Disconnect the CKP sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B7-1 - B50-110 (NE+) Always Below 1 ohms B7-2 - B50-111 (NE-) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B7-1 or B50-110 (NE+) - Body ground Always 10 kohms or higher B7-2 or B50-111 (NE-) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the CKP sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK SENSOR INSTALLATION (CRANKSHAFT POSITION SENSOR) Check the CKP sensor installation condition. OK Sensor is installed correctly. NG --> See step 6 OK: Go to next step
4. CHECK CRANKSHAFT POSITION SENSOR PLATE (TEETH OF SENSOR PLATE) Check the teeth of the sensor plate. OK Sensor plate does not have any cracks or deformation. NG --> See step 7 OK --> See step 8
5. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-428889-S09552291782011101200000)
6. REPLACE CRANKSHAFT POSITION SENSOR. Refer to «REMOVAL»(ref-428889-S09552291782011101200000)
7. REPLACE CRANKSHAFT. Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000)
8. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)

ALL

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)

P0342, P0343: VVT SENSOR (BANK 1) RANGE CHECK

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

P0347, P0348: VVT SENSOR (BANK 1) RANGE CHECK

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)

P0342, P0347: VVT SENSOR (BANK1, 2) RANGE CHECK (LOW VOLTAGE)

P0343, P0348: VVT SENSOR (BANK1, 2) RANGE CHECK (HIGH VOLTAGE)

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

Scheme 176

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and turn the Techstream off.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
9. Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
10. Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
11. If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
13. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)

P0342, P0343: VVT SENSOR (BANK 1) RANGE CHECK

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

P0347, P0348: VVT SENSOR (BANK 1) RANGE CHECK

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 1)

P0340: VVT SENSOR (BANK 1) VERIFY PULSE INPUT (CASE 2)

P0342, P0347: VVT SENSOR (BANK1, 2) RANGE CHECK (LOW VOLTAGE)

P0343, P0348: VVT SENSOR (BANK1, 2) RANGE CHECK (HIGH VOLTAGE)

P0345: VVT SENSOR (BANK 2) VERIFY PULSE INPUT

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and turn the Techstream off.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
9. Input the DTC: P0340, P0342, P0343, P0345, P0347 or P0348.
10. Check the DTC judgment result [C]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [C] again.
11. If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
12. Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
13. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK HARNESS AND CONNECTOR (SENSOR POWER SOURCE) Disconnect the VVT sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch condition Specified Condition B42-3 (VC) - Body ground Ignition switch ON 4.5 to 5.0 V B17-3 (VC) - Body ground Ignition switch ON 4.5 to 5.0 V Reconnect the VVT sensor connector. NG --> See step 10 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR INTAKE CAMSHAFT - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B42-1 (VVR+) - B50-69 (VV1+) Always Below 1 ohms B42-2 (VVR-) - B50-92 (VV1-) Always Below 1 ohms B17-1 (VVL+) - B50-67 (VV2+) Always Below 1 ohms B17-2 (VVL-) - B50-90 (VV2-) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B42-1 (VVR+) or B50-69 (VV1+) - Body ground Always 10 kohms or higher B42-2 (VVR-) or B50-92 (VV1-) - Body ground Always 10 kohms or higher B17-1 (VVL+) or B50-67 (VV2+) - Body ground Always 10 kohms or higher B17-2 (VVL-) or B50-90 (VV2-) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK VVT SENSOR FOR INTAKE CAMSHAFT (SENSOR INSTALLATION) Check the VVT sensor installation condition. OK Sensor is installed correctly. NG --> See step 7 OK: Go to next step
4. CHECK CAMSHAFT TIMING GEAR ASSEMBLY FOR INTAKE CAMSHAFT (TEETH OF PLATE) Check the teeth of the signal plate. OK Sensor plate teeth do not have any cracks or deformation. NG --> See step 8 OK: Go to next step
5. REPLACE VVT SENSOR Replace VVT sensor. Refer to «REMOVAL»(ref-428889-S15894472572011101200000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Idle the engine for 10 seconds or more. Select the following menu items: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0340, P0342, P0343, P0345, P0347 or P0348 is output B HINT: If the engine does not start, replace the ECM. B --> See step 9 A --> END
7. SECURELY REINSTALL VVT SENSOR. Refer to «INSTALLATION»(ref-428889-S11299529122011101200000)
8. REPLACE CAMSHAFT TIMING GEAR ASSEMBLY. Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000)
9. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
10. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR INTAKE CAMSHAFT - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B42-3 (VC) - B50-115 (VCV1) Always Below 1 ohms B17-3 (VC) - B50-113 (VCV2) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B42-3 (VC) or B50-115 (VCV1) - Body ground Always 10 kohms or higher B17-3 (VC) or B50-113 (VCV2) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 9

Scheme 177

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0351, P0352, P0353, P0354, P0355 or P0356.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Scheme 178

Scheme 179

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0351, P0352, P0353, P0354, P0355 or P0356.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. READ OUTPUT DTC Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to One of DTCs P0351, P0352, P0353, P0354, P0355, P0356 is output. A Some of DTCs P0351, P0352, P0353, P0354, P0355, P0356 are output. B B --> See step 5 A: Go to next step
2. PERFORM SIMULATION TEST Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Change the arrangement of the ignition coils (with igniters). NOTE: Do not change the location of the connectors. Perform a simulation test. Result Result Proceed to Same DTCs are output (same as DTCs that were cleared) A Other DTCs are output B B --> REPLACE IGNITION COIL ASSEMBLY A: Go to next step
3. INSPECT IGNITION COIL ASSEMBLY (POWER SOURCE) Disconnect the ignition coil connectors. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B36-1 - Body ground ignition switch ON 11 to 14 V B21-1 - Body ground ignition switch ON 11 to 14 V B35-1 - Body ground ignition switch ON 11 to 14 V B22-1 - Body ground ignition switch ON 11 to 14 V B34-1 - Body ground ignition switch ON 11 to 14 V B23-1 - Body ground ignition switch ON 11 to 14 V Reconnect the ignition coil connectors. NG --> See step 5 OK: Go to next step
4. CHECK HARNESS AND CONNECTOR (IGNITION COIL ASSEMBLY - ECM (IGT SIGNAL TERMINAL)) Disconnect the ignition coil connectors. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B36-3 (IGT1) - B50-40 (IGT1) Always Below 1 ohms B21-3 (IGT2) - B50-39 (IGT2) Always Below 1 ohms B35-3 (IGT3) - B50-38 (IGT3) Always Below 1 ohms B22-3 (IGT4) - B50-37 (IGT4) Always Below 1 ohms B34-3 (IGT5) - B50-36 (IGT5) Always Below 1 ohms B23-3 (IGT6) - B50-35 (IGT6) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B36-3 (IGT1) or B50-40 (IGT1) - Body ground Always 10 kohms or higher B21-3 (IGT2) or B50-39 (IGT2) - Body ground Always 10 kohms or higher B35-3 (IGT3) or B50-38 (IGT3) - Body ground Always 10 kohms or higher B22-3 (IGT4) or B50-37 (IGT4) - Body ground Always 10 kohms or higher B34-3 (IGT5) or B50-36 (IGT5) - Body ground Always 10 kohms or higher B23-3 (IGT6) or B50-3 (IGT6) - Body ground Always 10 kohms or higher Standard resistance (Check for open) Tester Connection Condition Specified Condition B36-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms B21-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms B35-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms B22-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms B34-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms B23-2 (IGF) - B50-106 (IGF1) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B36-2 (IGF) or B50-106 (IGF1) - Body ground Always 10 kohms or higher B21-2 (IGF) or B50-106 (IGF1) - Body ground Always 10 kohms or higher B35-2 (IGF) or B50-106 (IGF1)- Body ground Always 10 kohms or higher B22-2 (IGF) or B50-106 (IGF1) - Body ground Always 10 kohms or higher B34-2 (IGF) or B50-106 (IGF1) - Body ground Always 10 kohms or higher B23-2 (IGF) or B50-106 (IGF1) - Body ground Always 10 kohms or higher Reconnect the ignition coil connectors. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 6
5. INSPECT IGNITION COIL ASSEMBLY (GROUND CIRCUIT) Disconnect the ignition coil connectors. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition B36-4 (GND) - Body ground Always Below 1 ohms B21-4 (GND) - Body ground Always Below 1 ohms B35-4 (GND) - Body ground Always Below 1 ohms B22-4 (GND) - Body ground Always Below 1 ohms B34-4 (GND) - Body ground Always Below 1 ohms B23-4 (GND) - Body ground Always Below 1 ohms Reconnect the ignition coil connectors. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION COIL - BODY GROUND) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (IGNITION COIL - IG2 RELAY)
6. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)

ALL

P0365 AND P0390: VVT SENSOR VERIFY PULSE INPUT

P0367, P0392, P0368, P0393: VVT SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)

P0365 AND P0390: VVT SENSOR VERIFY PULSE INPUT

P0367 AND P0392: VVT SENSOR RANGE CHECK (LOW VOLTAGE)

P0368 AND P0393: VVT SENSOR RANGE CHECK (HIGH VOLTAGE)

Scheme 180

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0365, P0367, P0368, P0390, P0392 or P0393.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

P0365 AND P0390: VVT SENSOR VERIFY PULSE INPUT

P0367, P0392, P0368, P0393: VVT SENSOR RANGE CHECK (LOW VOLTAGE, HIGH VOLTAGE)

P0365 AND P0390: VVT SENSOR VERIFY PULSE INPUT

P0367 AND P0392: VVT SENSOR RANGE CHECK (LOW VOLTAGE)

P0368 AND P0393: VVT SENSOR RANGE CHECK (HIGH VOLTAGE)

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine.
7. Idle the engine for 10 seconds or more [B].
8. Enter the following menus: Powertrain / Engine / Trouble Codes.
9. Read the DTCs [C].
10. If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
11. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
12. Input the DTC: P0365, P0367, P0368, P0390, P0392 or P0393.
13. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
14. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
15. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
16. If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

1. CHECK HARNESS AND CONNECTOR (SENSOR POWER SOURCE) Disconnect the VVT sensor connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B37-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.0 V B24-3 (VC2) - Body ground Ignition switch ON 4.5 to 5.0 V Reconnect the VVT sensor connector. NG --> See step 10 OK: Go to next step
2. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR EXHAUST CAMSHAFT - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B37-1 (EX+) - B50-68 (EV1+) Always Below 1 ohms B37-2 (EX-) - B50-91 (EV1-) Always Below 1 ohms B24-1 (EX+) - B50-66 (EV2+) Always Below 1 ohms B24-2 (EX-) - B50-89 (EV2-) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B37-1 (EX+) or B50-68 (EV1+) - Body ground Always 10 kohms or higher B37-2 (EX-) or B50-91 (EV1-) - Body ground Always 10 kohms or higher B24-1 (EX+) or B50-66 (EV2+) - Body ground Always 10 kohms or higher B24-2 (EX-) or B50-89 (EV2-) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
3. CHECK VVT SENSOR FOR EXHAUST CAMSHAFT (SENSOR INSTALLATION) Check the VVT sensor installation condition. OK Sensor is installed correctly. NG --> See step 8 OK: Go to next step
4. CHECK EXHAUST CAMSHAFT Check the timing rotor of the exhaust camshaft. OK Timing rotor does not have any cranks or deformation. NG --> See step 9 OK: Go to next step
5. REPLACE VVT SENSOR Replace the VVT sensor. Refer to «REMOVAL»(ref-428889-S15894472572011101200000) . NEXT: Go to next step
6. CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Turn the ignition switch off. Turn the ignition switch to ON and turn the Techstream on. Start the engine. Idle the engine for 10 seconds or more. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0365, P0367, P0368, P0390, P0392 or P0393 is output B HINT: If the engine does not start, replace the ECM. B --> See step 7 A --> END
7. REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
8. SECURELY REINSTALL VVT SENSOR. Refer to «INSTALLATION»(ref-428889-S11299529122011101200000)
9. REPLACE EXHAUST CAMSHAFT. Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000)
10. CHECK HARNESS AND CONNECTOR (VVT SENSOR FOR EXHAUST CAMSHAFT - ECM) Disconnect the VVT sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B37-3 (VC2) - B50-114 (VCE1) Always Below 1 ohms B24-3 (VC2) - B50-112 (VCE2) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B37-3 (VC2) or B50-114 (VCE1) - Body ground Always 10 kohms or higher B24-3 (VC2) or B50-112 (VCE2) - Body ground Always 10 kohms or higher Reconnect the VVT sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.

Scheme 181

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
5. Turn the ignition switch off and wait for 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor.
8. Check that Catalyst / Status2 is Incomplete.
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at between 40 and 70 mph (64 and 113 km/h) for at least 10 minutes or more [B].
11. Those items will change to Complete after completing the driving pattern.
12. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
13. Check if any DTCs (pending DTCs) are set.

HINT

If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 and/or P0430 is output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine at an engine speed of 2500 rpm for approximately 90 seconds. On the Techstream, enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the output voltages of the A/F and HO2 sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) +25% Rich Less than 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) -12.5% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (HO2) +25% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (HO2) -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 A/F Condition and A/F and HO2 Sensor Conditions Misfire Main Suspected Trouble Areas Proceed to Lean/Rich Lean/Rich Normal - Three-Way Catalytic Converter (TWC) Gas leakage from exhaust system A Lean Lean/Rich A/F sensor malfunction - A/F sensor B Rich Lean/Rich A/F sensor malfunction - A/F sensor B Lean/Rich Lean HO2 sensor malfunction - HO2 sensor Gas leakage from exhaust system C Lean/Rich Rich HO2 sensor malfunction - HO2 sensor Gas leakage from exhaust system C Lean Lean Actual air-fuel ratio lean May occur Extremely rich or lean actual air-fuel ratio Gas leakage from exhaust system D Rich Rich Actual air-fuel ratio rich - Extremely rich or lean actual air-fuel ratio Gas leakage from exhaust system D Lean: During Control the Injection Volume for A/F Sensor, the A/F sensor (AFS) output voltage is consistently more than 3.4 V, and the HO2 sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the HO2 sensor alternates correctly. B --> See step 8 C --> See step 5 D --> See step 6 A: Go to next step
3. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK: Go to next step
4. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) According to the DTCs output in the Check Any Other DTCs Output step, proceed to the next step according to the table below. Result Display (DTC output) Proceed to P0420 A, C P0430 B, C P0420 and P0430 A, B, C A --> See step 9 B --> See step 10 C --> See step 11
5. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK --> See step 12
6. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK --> See step 13
7. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
8. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
9. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-428873-S40837555092011101200000)
10. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-428873-S40837555092011101200000)
11. REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-428896-S04291148572011101200000)
12. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-428893-S20676909622011101200000)
13. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEARN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-428884-S42252314502011101200000)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

HINT

Performing this confirmation pattern will activate the catalyst monitor. This is very useful for verifying the completion of a repair.

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON.
3. Turn the Techstream on.
4. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
5. Turn the ignition switch off and wait for 30 seconds.
6. Turn the ignition switch to ON and turn the Techstream on.
7. Enter the following menus: Powertrain / Engine / Monitor.
8. Check that Catalyst / Status2 is Incomplete.
9. Start the engine and warm it up (until the engine coolant temperature is 75°C (167°F) or higher) [A].
10. Drive the vehicle at between 40 and 70 mph (64 and 113 km/h) for at least 10 minutes or more [B].
11. Those items will change to Complete after completing the driving pattern.
12. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
13. Check if any DTCs (pending DTCs) are set.

HINT

If Catalyst does not change to Complete, and no pending DTCs are stored, extend the driving time.

1. CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0420 AND/OR P0430) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0420 and/or P0430 is output A DTC P0420 and/or P0430 and other DTCs are output B HINT: If any DTCs other than P0420 or P0430 are output, troubleshoot those DTCs first. B --> See step 7 A: Go to next step
2. PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE INJECTION VOLUME FOR A/F SENSOR) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Warm up the engine at an engine speed of 2500 rpm for approximately 90 seconds. On the Techstream, enter the following menus: Powertrain / Engine / Active Test / Control the Injection Volume for A/F Sensor. Perform the Control the Injection Volume for A/F Sensor operation with the engine in an idling condition (press the RIGHT or LEFT button to change the fuel injection volume). Monitor the output voltages of the A/F and HO2 sensors (AFS Voltage B1S1 and O2S B1S2 or AFS Voltage B2S1 and O2S B2S2) displayed on the Techstream. HINT: The Control the Injection Volume for A/F Sensor operation lowers the fuel injection volume by 12.5% or increases the injection volume by 25%. Each sensor reacts in accordance with increases and decreases in the fuel injection volume. Techstream Display (Sensor) Injection Volume Status Voltage AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) +25% Rich Less than 3.1 V AFS Voltage B1S1 or AFS Voltage B2S1 (A/F) -12.5% Lean More than 3.4 V O2S B1S2 or O2S B2S2 (HO2) +25% Rich More than 0.55 V O2S B1S2 or O2S B2S2 (HO2) -12.5% Lean Less than 0.4 V Result Status AFS Voltage B1S1 or AFS Voltage B2S1 Status O2S B1S2 or O2S B2S2 A/F Condition and A/F and HO2 Sensor Conditions Misfire Main Suspected Trouble Areas Proceed to Lean/Rich Lean/Rich Normal - Three-Way Catalytic Converter (TWC) Gas leakage from exhaust system A Lean Lean/Rich A/F sensor malfunction - A/F sensor B Rich Lean/Rich A/F sensor malfunction - A/F sensor B Lean/Rich Lean HO2 sensor malfunction - HO2 sensor Gas leakage from exhaust system C Lean/Rich Rich HO2 sensor malfunction - HO2 sensor Gas leakage from exhaust system C Lean Lean Actual air-fuel ratio lean May occur Extremely rich or lean actual air-fuel ratio Gas leakage from exhaust system D Rich Rich Actual air-fuel ratio rich - Extremely rich or lean actual air-fuel ratio Gas leakage from exhaust system D Lean: During Control the Injection Volume for A/F Sensor, the A/F sensor (AFS) output voltage is consistently more than 3.4 V, and the HO2 sensor output voltage (O2S) is consistently less than 0.4 V. Rich: During Control the Injection Volume for A/F Sensor, the AFS is consistently less than 3.1 V, and the O2S is consistently more than 0.55 V. Lean/Rich: During Control the Injection Volume for A/F Sensor of the Active Test, the output voltage of the HO2 sensor alternates correctly. B --> See step 8 C --> See step 5 D --> See step 6 A: Go to next step
3. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK: Go to next step
4. CHECK DTC OUTPUT (DTC P0420 AND/OR P0430) According to the DTCs output in the Check Any Other DTCs Output step, proceed to the next step according to the table below. Result Display (DTC output) Proceed to P0420 A, C P0430 B, C P0420 and P0430 A, B, C A --> See step 9 B --> See step 10 C --> See step 11
5. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK --> See step 12
6. INSPECT FOR EXHAUST GAS LEAK Inspect for exhaust gas leaks from the exhaust manifold sub-assembly and exhaust pipes. OK No gas leakage. NG --> REPAIR OR REPLACE EXHAUST GAS LEAKAGE POINT OK --> See step 13
7. GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
8. REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
9. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY RH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-428873-S40837555092011101200000)
10. REPLACE EXHAUST MANIFOLD SUB-ASSEMBLY LH (TWC: FRONT CATALYST). Refer to «COMPONENTS»(ref-428873-S40837555092011101200000)
11. REPLACE FRONT EXHAUST PIPE ASSEMBLY (TWC: REAR CATALYST). Refer to «COMPONENTS»(ref-428896-S04291148572011101200000)
12. REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-428893-S20676909622011101200000)
13. CHECK ENGINE TO DETERMINE CAUSE OF EXTREMELY RICH OR LEARN ACTUAL AIR FUEL RATIO. Refer to «INSPECTION PROCEDURE»(ref-428884-S32647372322011101200000)

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 182

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode [A].
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Trouble Codes / Pending.
8. Read the Pending DTCs [B].
9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All readiness.
11. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Note. The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on.
6. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode [A].
7. After the Evaporative System Check is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Trouble Codes / Pending.
8. Read the Pending DTCs [B].
9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All readiness.
11. Input the DTC: P043E, P043F, P2401, P2402 or P2419.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
13. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
14. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
15. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

KEY-OFF MONITOR

PURGE FLOW MONITOR

PURGE VSV STUCK OPEN

PURGE VSV STUCK CLOSED

PURGE FLOW

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

Scheme 183

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and wait 15 minutes or more [B].
7. Enter the following menus: Powertrain / Engine / Trouble Codes/ Pending.
8. Read the pending DTCs [C].
9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All readiness.
11. Input the DTC: P0441.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
13. Turn the ignition switch to ON and turn the Techstream on.
14. Clear the DTCs (even if no DTCs are stored, perform the clear the DTC operation). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
15. Turn the ignition switch off.
16. Turn the ignition switch to ON and turn the Techstream on.
17. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode [D].
18. After the Evaporative System is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Trouble Codes / pending.
19. Read the pending DTCs [E].
20. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
21. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
22. Input the DTC: P0441.
23. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D].
24. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
25. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
26. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.

ALL

KEY-OFF MONITOR

PURGE FLOW MONITOR

PURGE VSV STUCK OPEN

PURGE VSV STUCK CLOSED

PURGE FLOW

Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .

1. Connect the Techstream to the DLC3.
2. Turn the ignition switch to ON and turn the Techstream on.
3. Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
4. Turn the ignition switch off and wait for 30 seconds.
5. Turn the ignition switch to ON and turn the Techstream on [A].
6. Start the engine and wait 15 minutes or more [B].
7. Enter the following menus: Powertrain / Engine / Trouble Codes/ Pending.
8. Read the pending DTCs [C].
9. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
10. Enter the following menus: Powertrain / Engine / Utility / All readiness.
11. Input the DTC: P0441.
12. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit NOTE: The Evaporative System Check (Automatic Mode) consists of 5 steps performed automatically by the Techstream. It takes a maximum of approximately 18 minutes. Do not perform the Evaporative System Check when the fuel tank is more than 90% full because the cut-off valve may be closed, making the fuel tank leak check unavailable. Do not run the engine during this operation. When the temperature of the fuel is 35°C (95°F) or more, a large amount of vapor forms and any check results become inaccurate. When performing the Evaporative System Check, keep the fuel temperature below 35°C (95°F).
13. Turn the ignition switch to ON and turn the Techstream on.
14. Clear the DTCs (even if no DTCs are stored, perform the clear the DTC operation). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
15. Turn the ignition switch off.
16. Turn the ignition switch to ON and turn the Techstream on.
17. Enter the following menus: Powertrain / Engine / Utility / Evaporative System Check / Automatic Mode [D].
18. After the Evaporative System is completed, check for All Readiness by entering the following menus: Powertrain / Engine / Trouble Codes / pending.
19. Read the pending DTCs [E].
20. If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
21. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
22. Input the DTC: P0441.
23. Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D].
24. Enter the following menus: Powertrain / Engine / Utility / All Readiness.
25. Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
26. If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
