MONITOR STRATEGY
| Related DTCs | P0010: VVT OCV (bank 1) range check P0020: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (Variable Valve Timing Oil Control Valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
TYPICAL ENABLING CONDITIONS
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after turning ignition switch from off to ON | 0.5 seconds or more |
TYPICAL MALFUNCTION THRESHOLDS
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% or more |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
COMPONENT OPERATING RANGE
| Output signal duty ratio | More than 3% and less than 100% |
Scheme 210
Scheme 210: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 211
Scheme 211: WIRING DIAGRAM
| Related DTCs | P0010: VVT OCV (bank 1) range check P0020: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (Variable Valve Timing Oil Control Valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after turning ignition switch from off to ON | 0.5 seconds or more |
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output signal duty ratio | 100% or more |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Output signal duty ratio | More than 3% and less than 100% |
CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0010 or P0020.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
PROCEDURE
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. On the Techstream, enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank1) or Control the VVT System (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) OK --> See step 5 NG: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Remove the OCV for intake camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the OCV for intake camshaft connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-58 (OC1+) - B44-1 Always Below 1 ohms B50-57 (OC1-) - B44-2 Always Below 1 ohms B50-52 (OC2+) - B19-1 Always Below 1 ohms B50-51 (OC2-) - B19-2 Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-58 (OC1+) or B44-1 - Body ground Always 10 kohms or higher B50-57 (OC1-) or B44-2 - Body ground Always 10 kohms or higher B50-52 (OC2+) or B19-1 - Body ground Always 10 kohms or higher B50-51 (OC2-) or B19-2 - Body ground Always 10 kohms or higher Reconnect the OCV connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OCV - ECM) OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0011: Advanced camshaft timing (bank 1) P0012: Retard camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retard camshaft timing (bank 2) |
| Required sensors / components (Main) | VVT OCV and VVT actuator |
| Required sensors / components (Sub) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of operation | Once per drive cycle |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing (bank 1): Immediately Advanced camshaft timing (bank 2): Immediately Retard camshaft timing (bank 1): 2 driving cycles Retard camshaft timing (bank 2): 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| ECT | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at advanced valve timing |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at retarded valve timing |
MONITOR RESULT
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 212
Scheme 212: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the ignition and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle for 5 minutes or more [C].
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Drive the vehicle for 5 minutes or more [F].
- Idle the engine for 30 seconds or more [G].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
- Then, the ECM monitors the camshaft timing change for 5 seconds.
| Related DTCs | P0011: Advanced camshaft timing (bank 1) P0012: Retard camshaft timing (bank 1) P0021: Advanced camshaft timing (bank 2) P0022: Retard camshaft timing (bank 2) |
| Required sensors / components (Main) | VVT OCV and VVT actuator |
| Required sensors / components (Sub) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of operation | Once per drive cycle |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing (bank 1): Immediately Advanced camshaft timing (bank 2): Immediately Retard camshaft timing (bank 1): 2 driving cycles Retard camshaft timing (bank 2): 2 driving cycles |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| ECT | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at advanced valve timing |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the ignition and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle for 5 minutes or more [C].
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Drive the vehicle for 5 minutes or more [F].
- Idle the engine for 30 seconds or more [G].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0011, P0012, P0021 or P0022.
- Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- If the difference between the target and actual camshaft timings is greater than the specified value, the ECM operates the VVT actuator.
- Then, the ECM monitors the camshaft timing change for 5 seconds.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0011, P0012, P0021 OR P0022) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0011, P0012, P0021 or P0022 is output A DTC P0011, P0012, P0021 or P0022 and other DTCs are output B HINT: If any DTCs other than P0011, P0012, P0021 or P0022 are output, troubleshoot those DTCs first. B --> See step 8 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT System (Bank1) or Control the VVT System (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine speed ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0011, P0012, P0021 OR P0022) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0011, P0012, P0021 or P0022 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 4 OK --> See step 11
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Remove the OCV for intake camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT --> See step 9
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. OK --> END NG --> See step 10
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0013: VVT OCV (bank 1) range check P0023: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (Variable Valve Timing Oil Control Valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output duty ratio | 100% or more |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Output signal duty ratio | More than 3% and less than 100% |
Scheme 213
Scheme 213: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 214
Scheme 214: WIRING DIAGRAM
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition -128% (OCV OFF) Normal engine speed 127% (OCV ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the OCV for exhaust camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the OCV for exhaust camshaft connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-16 (OE1+) - B43-1 Always Below 1 ohms B50-17 (OE1-) - B43-2 Always Below 1 ohms B50-14 (OE2+) - B20-1 Always Below 1 ohms B50-15 (OE2-) - B20-2 Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-16 (OE1+) or B43-1 - Body ground Always 10 kohms or higher B50-17 (OE1-) or B43-2 - Body ground Always 10 kohms or higher B50-14 (OE2+) or B20-1 - Body ground Always 10 kohms or higher B50-15 (OE2-) or B20-2 - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the OCV connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OCV - ECM) OK --> See step 5
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
| Related DTCs | P0013: VVT OCV (bank 1) range check P0023: VVT OCV (bank 2) range check |
| Required sensors / components (Main) | VVT OCV (Variable Valve Timing Oil Control Valve) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 1 second |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of the following conditions are met | |
| Starter | OFF |
| Ignition switch | ON |
| Time after ignition switch off to ON | 0.5 seconds or more |
| One of the following conditions is met | Condition A, B or C |
| A. All of the following conditions are met | |
| Battery voltage | 11 V or more, and less than 13 V |
| Target duty ratio | Less than 70% |
| Output signal duty ratio | 100% or more |
| B. All of the following conditions are met | |
| Battery voltage | 13 V or more |
| Target duty ratio | Less than 80% |
| Output duty ratio | 100% or more |
| C. All of the following conditions are met | |
| Current cut status | Not cut |
| Output signal duty ratio | 3% or less |
| Output signal duty ratio | More than 3% and less than 100% |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 5 seconds [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0013 or P0023.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition -128% (OCV OFF) Normal engine speed 127% (OCV ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 3 OK --> See step 2
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the OCV for exhaust camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- CHECK HARNESS AND CONNECTOR (OCV - ECM) Disconnect the OCV for exhaust camshaft connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-16 (OE1+) - B43-1 Always Below 1 ohms B50-17 (OE1-) - B43-2 Always Below 1 ohms B50-14 (OE2+) - B20-1 Always Below 1 ohms B50-15 (OE2-) - B20-2 Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-16 (OE1+) or B43-1 - Body ground Always 10 kohms or higher B50-17 (OE1-) or B43-2 - Body ground Always 10 kohms or higher B50-14 (OE2+) or B20-1 - Body ground Always 10 kohms or higher B50-15 (OE2-) or B20-2 - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the OCV connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (OCV - ECM) OK --> See step 5
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
| Related DTCs | P0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2) |
| Required sensors / components (Main) | VVT OCV and VVT actuator |
| Required sensors / components (Related) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing (bank 1): 2 driving cycles Advanced camshaft timing (bank 2): 2 driving cycles Retarded camshaft timing (bank 1): Immediately Retarded camshaft timing (bank 2): Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at advanced valve timing |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 215
Scheme 215: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle for 5 minutes or more [C].
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Drive the vehicle for 5 minutes or more [F].
- Idle the engine for 30 seconds or more [G].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0014, P0015, P0024 or P0025 is output A DTC P0014, P0015, P0024 or P0025 and other DTCs are output B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition -128% (OCV OFF) Normal engine speed 127% (OCV ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 5 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0014, P0015, P0024 or P0025 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil, thus eliminating the source of the problem. NG --> See step 5 OK --> See step 11
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the OCV for exhaust camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY Replace the exhaust camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 10 OK --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0014: Advanced camshaft timing (bank 1) P0015: Retarded camshaft timing (bank 1) P0024: Advanced camshaft timing (bank 2) P0025: Retarded camshaft timing (bank 2) |
| Required sensors / components (Main) | VVT OCV and VVT actuator |
| Required sensors / components (Related) | Crankshaft position sensor, VVT sensor and engine coolant temperature sensor |
| Frequency of operation | Once per driving cycle |
| Duration | Within 10 seconds |
| MIL operation | Advanced camshaft timing (bank 1): 2 driving cycles Advanced camshaft timing (bank 2): 2 driving cycles Retarded camshaft timing (bank 1): Immediately Retarded camshaft timing (bank 2): Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Battery voltage | 11 V or more |
| Engine RPM | 500 to 4000 RPM |
| Engine coolant temperature | 75 to 100°C (167 to 212°F) |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at advanced valve timing |
| All of the following conditions are met | |
| Deviation of between actual valve timing and target valve timing | More than 5°CA (Crankshaft Angle) for 5 seconds or more after the VVT hold duty ratio learned value reaches the upper or lower limit |
| Valve timing | No change at retarded valve timing |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or more [B].
- Drive the vehicle for 5 minutes or more [C].
- Idle the engine for 30 seconds or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [F] through [H].
- Drive the vehicle for 5 minutes or more [F].
- Idle the engine for 30 seconds or more [G].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0014, P0015, P0024 or P0025.
- Check the DTC judgment result again [H]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0014, P0015, P0024 OR P0025) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0014, P0015, P0024 or P0025 is output A DTC P0014, P0015, P0024 or P0025 and other DTCs are output B HINT: If any DTCs other than P0014, P0015, P0024 or P0025 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Enter the following menus: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank1) or Control the VVT Exhaust Linear (Bank2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition -128% (OCV OFF) Normal engine speed 127% (OCV ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 5 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0014, P0015, P0024 OR P0025) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0014, P0015, P0024 or P0025 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil, thus eliminating the source of the problem. NG --> See step 5 OK --> See step 11
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the OCV for exhaust camshaft. Measure the resistance between the terminals of the OCV. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the OCV. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- INSPECT OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY Replace the exhaust camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect the Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 10 OK --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0016: Crankshaft position - Camshaft position misaligned at idling (bank 1) P0018: Crankshaft position - Camshaft position misaligned at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | |
| VVT learning value at maximum retarded valve timing (Bank 1) | Less than 18.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | Less than 18.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 1) | More than 43.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | More than 43.5°CA (Crankshaft Angle) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
Scheme 216
Scheme 216: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0016 or P0018.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0016 or P0018 is output A DTC P0016 or P0018 and other DTCs are output B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM BANK 1 OR BANK 2) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Select the following menu items: Powertrain / Engine / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine idle speed ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0016 or P0018 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 4 OK --> See step 11
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Remove the camshaft timing oil control valve for intake camshaft. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 9 OK --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0016: Crankshaft position - Camshaft position misaligned at idling (bank 1) P0018: Crankshaft position - Camshaft position misaligned at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | |
| VVT learning value at maximum retarded valve timing (Bank 1) | Less than 18.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | Less than 18.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 1) | More than 43.5°CA (Crankshaft Angle) |
| VVT learning value at maximum retarded valve timing (Bank 2) | More than 43.5°CA (Crankshaft Angle) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0016 or P0018.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0016 OR P0018) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0016 or P0018 is output A DTC P0016 or P0018 and other DTCs are output B HINT: If any DTCs other than P0016 or P0018 are output, troubleshoot those DTCs first. B --> See step 10 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT SYSTEM BANK 1 OR BANK 2) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Select the following menu items: Powertrain / Engine / Active Test / Control the VVT System (Bank 1) or Control the VVT System (Bank 2). Check the engine speed while operating the Oil Control Valve (OCV) using the Techstream. OK Techstream Operation Specified Condition OFF Normal engine idle speed ON Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0016 OR P0018) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0016 or P0018 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay output even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 4 OK --> See step 11
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMPED TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) Remove the camshaft timing oil control valve for intake camshaft. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Connect the positive (+) battery terminal to terminal 1 and connect the negative (-) battery terminal to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR INTAKE CAMSHAFT) OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE CAMSHAFT TIMING GEAR ASSEMBLY Replace the camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 9 OK --> END
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0017: Exhaust valve timing misalignment at idling (bank 1) P0019: Exhaust valve timing misalignment at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | |
| VVT learning value at maximum advanced valve timing (bank 1) | Less than 77°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 2) | Less than 77°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 1) | More than 102°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 2) | More than 102°CA (Crankshaft angle) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0017 or P0019.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0017 or P0019 is output A DTC P0017 or P0019 and other DTCs are output B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Select the following menu items: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Techstream Operation Specified Condition -128% (Oil control valve OFF) Normal engine idle speed 127% (Oil control valve ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0017 or P0019 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay registered even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 4 OK --> See step 11
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the camshaft timing oil control valve for exhaust camshaft. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Apply positive (+) battery voltage to terminal 1 and negative (-) battery voltage to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY Replace the exhaust camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 10 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0017: Exhaust valve timing misalignment at idling (bank 1) P0019: Exhaust valve timing misalignment at idling (bank 2) |
| Required Sensors / Components (Main) | VVT actuator |
| Required Sensors / Components (Related) | VVT sensor, crankshaft position sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | Less than 60 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0013, P0023 (Exhaust OCV bank 1, 2) P0102, P0103 (MAF meter) P0115, P0117, P0118 (ECT sensor) P0125 (Insufficient ECT for closed loop) P0335 (CKP sensor) P0340 (Camshaft position sensor) |
| Engine RPM | 500 to 1000 RPM |
| One of the following conditions is met | |
| VVT learning value at maximum advanced valve timing (bank 1) | Less than 77°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 2) | Less than 77°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 1) | More than 102°CA (Crankshaft angle) |
| VVT learning value at maximum advanced valve timing (bank 2) | More than 102°CA (Crankshaft angle) |
Refer to Checking Monitor Status. Refer to CHECKING MONITOR STATUS .
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0017 or P0019.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] through [G].
- Drive the vehicle for 2 to 3 minutes [E].
- Idle the engine for 5 minutes or more [F].
- Check the DTC judgment result [G]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0017 AND P0019) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0017 or P0019 is output A DTC P0017 or P0019 and other DTCs are output B HINT: If any DTCs other than P0017 or P0019 are output, troubleshoot those DTCs first. B --> See step 9 A: Go to next step
- PERFORM ACTIVE TEST USING TECHSTREAM (CONTROL THE VVT EXHAUST LINEAR (BANK 1 OR BANK 2)) Connect Techstream to the DLC3. Start the engine and turn the Techstream on. Select the following menu items: Powertrain / Engine / Active Test / Control the VVT Exhaust Linear (Bank 1) or Control the VVT Exhaust Linear (Bank 2). Check the engine speed while operating the oil control valve using the Techstream. OK Techstream Operation Specified Condition -128% (Oil control valve OFF) Normal engine idle speed 127% (Oil control valve ON) Engine idles roughly or stalls (soon after OCV switched from OFF to ON) NG --> See step 4 OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (DTC P0017 OR P0019) Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. HINT: DTC P0017 or P0019 is output when foreign objects in engine oil are caught in some parts of the system. These codes will stay registered even if the system returns to normal after a short time. These foreign objects are then captured by the oil filter, thus eliminating the source of the problem. NG --> See step 4 OK --> See step 11
- CHECK VALVE TIMING (CHECK FOR LOOSE AND JUMP TEETH ON TIMING CHAIN) Remove the cylinder head cover sub-assemblies RH and LH. Turn the crankshaft to align the timing marks of the crankshaft. Align the notch of the crankshaft pulley to the "0" position. Check if the timing marks of the camshaft pulley and camshaft bearing cap align. Turn the crankshaft clockwise by 360° if the timing marks do not align. Check if they align once again. OK The timing marks of the camshaft pulley and the camshaft bearing cap align when the notch of the crankshaft pulley is in the "0" position. Reinstall the cylinder head cover sub-assemblies RH and LH. NG --> ADJUST VALVE TIMING OK: Go to next step
- INSPECT CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) Remove the camshaft timing oil control valve for exhaust camshaft. Measure the resistance according to the value(s) in the table below. Standard resistance Tester Connection Condition Specified Condition 1 - 2 20°C (68°F) 6.9 to 7.9 ohms Apply positive (+) battery voltage to terminal 1 and negative (-) battery voltage to terminal 2. Check the valve operation. OK Valve moves quickly. Reinstall the camshaft timing oil control valve. NG --> REPLACE CAMSHAFT TIMING OIL CONTROL VALVE ASSEMBLY (FOR EXHAUST CAMSHAFT) OK: Go to next step
- CHECK OIL CONTROL VALVE FILTER AND OIL PIPE Remove the No. 1 oil pipe or No. 2 oil pipe. Remove the oil control valve filter RH or oil control valve filter LH. Check that the oil control valve filter and oil pipe are not clogged. OK The oil control valve filter and oil pipe are not clogged. Reinstall the oil control valve filter RH or oil control valve filter LH. Reinstall the No. 1 oil pipe or No. 2 oil pipe. NG --> REPLACE OIL CONTROL VALVE FILTER OR OIL PIPE OK: Go to next step
- REPLACE EXHAUST CAMSHAFT TIMING GEAR ASSEMBLY Replace the exhaust camshaft timing gear assembly (bank 1 or bank 2). Refer to «DISASSEMBLY»(ref-428873-S09779335952011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON and turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Enter the following menus: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs using the Techstream. OK No pending DTC output. NG --> See step 10 OK --> END
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0031: A/F sensor heater (bank 1) open/shorted (Low electrical current) P0032: A/F sensor heater (bank 1) open/shorted (High electrical current) P0051: A/F sensor heater (bank 2) open/shorted (Low electrical current) P0052: A/F sensor heater (bank 2) open/shorted (High electrical current) |
| Required sensors / components (Main) | A/F sensor heater (bank 1 and 2) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 10 seconds: P0031 and P0051 10.24 seconds: P0032 and P0052 |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Heater output duty | 50% or more |
| Time after engine start | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Battery voltage | 10.5 V or more |
| Heater output duty | More than 0% |
| Time after engine start | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Heater on current | Less than 0.8 A |
| Both of the following conditions are met | Conditions A and B |
| A. Hybrid IC high current limiter monitor input | Fail |
| B. Heater output | ON |
| Heater on current | 0.8 A or more |
| All of the following conditions are met | |
| Heater output | ON |
| Hybrid IC high current limiter monitor input | Pass |
Scheme 217
Scheme 217: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [E].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051 or P0052.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0031: A/F sensor heater (bank 1) open/shorted (Low electrical current) P0032: A/F sensor heater (bank 1) open/shorted (High electrical current) P0051: A/F sensor heater (bank 2) open/shorted (Low electrical current) P0052: A/F sensor heater (bank 2) open/shorted (High electrical current) |
| Required sensors / components (Main) | A/F sensor heater (bank 1 and 2) |
| Required sensors / components (Sub) | |
| Frequency of operation | Continuous |
| Duration | 10 seconds: P0031 and P0051 10.24 seconds: P0032 and P0052 |
| MIL operation | Immediately |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Heater output duty | 50% or more |
| Time after engine start | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Battery voltage | 10.5 V or more |
| Heater output duty | More than 0% |
| Time after engine start | 10 seconds or more |
| Active heater off control | Not operating |
| Active heater on control | Not operating |
| Heater on current | Less than 0.8 A |
| Both of the following conditions are met | Conditions A and B |
| A. Hybrid IC high current limiter monitor input | Fail |
| B. Heater output | ON |
| Heater on current | 0.8 A or more |
| All of the following conditions are met | |
| Heater output | ON |
| Hybrid IC high current limiter monitor input | Pass |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [E].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0031, P0032, P0051 or P0052.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- INSPECT AIR FUEL RATIO SENSOR (HEATER RESISTANCE) Disconnect the A/F sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 1) Tester Connection Condition Specified Condition 1 (HA1A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA1A) - 4 (A1A-) Always 10 kohms or higher Standard resistance (Bank 2 sensor 1) Tester Connection Condition Specified Condition 1 (HA2A) - 2 (+B) 20°C (68°F) 1.8 to 3.4 ohms 1 (HA2A) - 4 (A2A-) Always 10 kohms or higher Reconnect the A/F sensor connector. NG --> See step 7 OK: Go to next step
- CHECK TERMINAL VOLTAGE (+B OF A/F SENSOR) Disconnect the A/F sensor connector. Turn the ignition switch to ON. Measure the voltage between the terminal of the A/F sensor connector and body ground. Standard voltage Tester Connection Switch Condition Specified Condition B32-2 (+B) - Body ground Ignition switch ON 11 to 14 V B26-2 (+B) - Body ground Ignition switch ON 11 to 14 V Reconnect the A/F sensor connector. OK --> See step 5 NG: Go to next step
- INSPECT FUSE (A/F FUSE) Remove the A/F fuse from the engine room R/B. Measure the A/F fuse resistance. Standard resistance Below 1 ohms Reinstall the A/F fuse. NG --> REPLACE A/F FUSE OK: Go to next step
- INSPECT ENGINE ROOM JUNCTION BLOCK (A/F RELAY) Remove the engine room junction block from the engine room R/B. Measure the A/F relay resistance. Standard resistance Tester Connection Condition Specified Condition 1F-1 - 1C-6 Always 10 kohms or higher 1F-1 - 1C-6 Always Below 1 ohms (Apply battery voltage between terminals 1D-5 and 1H-2) Reinstall the engine room junction block. NG --> REPLACE ENGINE ROOM JUNCTION BLOCK OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (A/F RELAY - A/F SENSOR)
- CHECK HARNESS AND CONNECTOR (A/F SENSOR - ECM) Disconnect the A/F sensor connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-86 (HA1A) - B32-1 (HA1A) Always Below 1 ohms B50-109 (HA2A) - B26-1 (HA2A) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-86 (HA1A) or B32-1 (HA1A) - Body ground Always 10 kohms or higher B50-109 (HA2A) or B26-1 (HA2A) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the A/F sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (A/F SENSOR - ECM) OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC is not output A DTC P0031, P0032, P0051 and/or P0052 is output B B --> See step 8 A --> See step 9
- REPLACE AIR FUEL RATIO SENSOR. Refer to «REMOVAL»(ref-428893-S38119987512011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0037: Heated oxygen sensor heater (bank 1 sensor 2) open/short (Low electrical current) P0038: Heated oxygen sensor heater (bank 1 sensor 2) open/short (High electrical current) P0057: Heated oxygen sensor heater (bank 2 sensor 2) open/short (Low electrical current) P0058: Heated oxygen sensor heater (bank 2 sensor 2) open/short (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2) |
| Required sensors / components (Main) | Heated oxygen sensor heater (bank 1 sensor 2) Heated oxygen sensor heater (bank 2 sensor 2) |
| Required sensors / components (Sub) | Vehicle speed sensor |
| Frequency of operation | Continuous: P0037, P0038, P0057 and P0058 Once per driving cycle: P0141 and P0161 |
| Duration | 0.5 seconds: P0037 and P0057 2.064 seconds: P0038 and P0058 10 seconds: P0141 and P0161 |
| MIL operation | Immediately: P0037, P0038, P0057 and P0058 2 driving cycles: P0141 and P0161 |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 10 seconds or more |
| One of the following conditions is met | Condition A or B |
| A. All of the following conditions are met | 1, 2, 3, 4, 5 and 6 |
| 1. Battery voltage | 10.5 V or more |
| 2. Fuel cut | OFF |
| 3. Time after fuel cut ON to OFF | 30 seconds or more |
| 4. Accumulated heater ON time | 100 seconds or more |
| 5. Learned heater OFF current operation completed flag | ON |
| 6. Heated oxygen sensor heater circuit fail (P0037, P0038, P0057, P0058) | Not detected |
| B. Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Heater current - Learned heater OFF current | 0.3 A or less |
| Both of the following conditions are met | Condition A and B |
| A. Hybrid IC high current limiter port | Fail |
| B. Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: More than 23 ohms) |
| Heated Oxygen (HO2) sensor heater current | 0.4 to 1 A (when engine idles, HO2 sensor warmed up and battery voltage 11 to 14 V) |
Scheme 218
Scheme 218: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141 or P0161.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
| Related DTCs | P0037: Heated oxygen sensor heater (bank 1 sensor 2) open/short (Low electrical current) P0038: Heated oxygen sensor heater (bank 1 sensor 2) open/short (High electrical current) P0057: Heated oxygen sensor heater (bank 2 sensor 2) open/short (Low electrical current) P0058: Heated oxygen sensor heater (bank 2 sensor 2) open/short (High electrical current) P0141: Heated oxygen sensor heater performance (bank 1 sensor 2) P0161: Heated oxygen sensor heater performance (bank 2 sensor 2) |
| Required sensors / components (Main) | Heated oxygen sensor heater (bank 1 sensor 2) Heated oxygen sensor heater (bank 2 sensor 2) |
| Required sensors / components (Sub) | Vehicle speed sensor |
| Frequency of operation | Continuous: P0037, P0038, P0057 and P0058 Once per driving cycle: P0141 and P0161 |
| Duration | 0.5 seconds: P0037 and P0057 2.064 seconds: P0038 and P0058 10 seconds: P0141 and P0161 |
| MIL operation | Immediately: P0037, P0038, P0057 and P0058 2 driving cycles: P0141 and P0161 |
| Sequence of operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| Engine | Running |
| Starter | OFF |
| Battery voltage | 10.5 V or more |
| Time after heater ON | 10 seconds or more |
| One of the following conditions is met | Condition A or B |
| A. All of the following conditions are met | 1, 2, 3, 4, 5 and 6 |
| 1. Battery voltage | 10.5 V or more |
| 2. Fuel cut | OFF |
| 3. Time after fuel cut ON to OFF | 30 seconds or more |
| 4. Accumulated heater ON time | 100 seconds or more |
| 5. Learned heater OFF current operation completed flag | ON |
| 6. Heated oxygen sensor heater circuit fail (P0037, P0038, P0057, P0058) | Not detected |
| B. Duration that rear heated oxygen sensor impedance is less than 15 kohms | 2 seconds or more |
| Heater current - Learned heater OFF current | 0.3 A or less |
| Both of the following conditions are met | Condition A and B |
| A. Hybrid IC high current limiter port | Fail |
| B. Heated oxygen sensor heater output | ON |
| Accumulated heater resistance | Varies with sensor element temperature (Example: More than 23 ohms) |
| Heated Oxygen (HO2) sensor heater current | 0.4 to 1 A (when engine idles, HO2 sensor warmed up and battery voltage 11 to 14 V) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B].
- With the vehicle stationary, depress the accelerator pedal and maintain an engine speed of 3000 RPM for 1 minute [C].
- Idle the engine for 5 minutes or more [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [E].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0037, P0038, P0057, P0058, P0141 or P0161.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] through [D] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- INSPECT HEATED OXYGEN SENSOR (HEATER RESISTANCE) Disconnect the heated oxygen sensor connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Bank 1 sensor 2) Tester Connection Condition Specified Condition 1 (HT1B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT1B) - 4 (E) Always 10 kohms or higher Standard resistance (Bank 2 sensor 2) Tester Connection Condition Specified Condition 1 (HT2B) - 2 (+B) 20°C (68°F) 11 to 16 ohms 1 (HT2B) - 4 (E) Always 10 kohms or higher Reconnect the heated oxygen sensor connector. NG --> See step 6 OK: Go to next step
- CHECK TERMINAL VOLTAGE (+B OF HO2 SENSOR) Disconnect the heated oxygen sensor connector. Turn the ignition switch to ON. Measure the voltage between the terminals. Standard voltage Tester Connection Switch Condition Specified Condition B3-2 (+B) - Body ground Ignition switch ON 11 to 14 V B2-2 (+B) - Body ground Ignition switch ON 11 to 14 V Reconnect the heated oxygen sensor connector. OK --> See step 4 NG: Go to next step
- INSPECT FUSE (EFI NO. 2) Remove the EFI No. 2 fuse from the engine room R/B. Measure the EFI No. 2 fuse resistance. Standard resistance Below 1 ohms Reinstall the EFI No. 2 fuse. NG --> REPLACE FUSE (EFI NO. 2) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI RELAY - HO2 SENSOR)
- CHECK HARNESS AND CONNECTOR (HEATED OXYGEN SENSOR - ECM) Disconnect the heated oxygen sensor connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard resistance (Check for open) Tester Connection Condition Specified Condition B3-1 (HT1B) - B50-48 (HT1B) Always Below 1 ohms B3-3 (OX1B) - B50-88 (OX1B) Always Below 1 ohms B3-4 (E) - B50-65 (EX1B) Always Below 1 ohms B2-1 (HT2B) - B50-47 (HT2B) Always Below 1 ohms B2-3 (OX2B) - B50-87 (OX2B) Always Below 1 ohms B2-4 (E) - B50-64 (EX2B) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B3-1 (HT1B) or B50-48 (HT1B) - Body ground Always 10 kohms or higher B3-3 (OX1B) or B50-88 (OX1B) - Body ground Always 10 kohms or higher B3-4 (E) or B50-65 (EX1B) - Body ground Always 10 kohms or higher B2-1 (HT2B) or B50-47 (HT2B) - Body ground Always 10 kohms or higher B2-3 (OX2B) or B50-87 (OX2B) - Body ground Always 10 kohms or higher B2-4 (E) or B50-64 (EX2B) - Body ground Always 10 kohms or higher Reconnect the heated oxygen sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Drive the vehicle in accordance with the driving pattern described in the Confirmation Driving Pattern. Select the following menu items: Powertrain / Engine / Trouble Codes / Pending. Read the pending DTCs. Result Result Proceed to DTC is not output A DTC P0037, P0038, P0057, P0058, P0141 and/or P0161 is output B B --> See step 7 A --> See step 8
- REPLACE HEATED OXYGEN SENSOR. Refer to «REMOVAL»(ref-428893-S20676909622011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Sub) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| TP (Throttle position) sensor voltage | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| ECT | 70°C (158°F) or more |
| Estimated load | 30 to 70% |
| MAF sensor circuit fail (P0102, P0103) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| CKP sensor circuit fail (P0335) | Not detected |
| TP sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| EVAP system pressure sensor circuit fail (P0452, P0453) | Not detected |
| EVAP leak detection pump fail (P2401, P2402) | Not detected |
| EVAP system vent valve fail (P2419, P2420) | Not detected |
| Both of following conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.85% or more than 1.26% (varies with estimated engine load) |
| 2. Average air fuel ratio | Less than -20% or more than 20% |
Scheme 219
Scheme 219: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-428894-S11533945902011101200000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose conditions. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> REPLACE MASS AIR FLOW METER
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
| Related DTCs | P0101: Mass air flow meter rationality |
| Required Sensors/Components (Main) | Mass air flow meter |
| Required Sensors/Components (Sub) | Crankshaft position sensor, engine coolant temperature sensor and throttle position sensor |
| Frequency of Operation | Continuous |
| Duration | 10 times |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| TP (Throttle position) sensor voltage | 0.2 to 2 V |
| Time after engine start | 5 seconds or more |
| Battery voltage | 10.5 V or more |
| ECT | 70°C (158°F) or more |
| Estimated load | 30 to 70% |
| MAF sensor circuit fail (P0102, P0103) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| CKP sensor circuit fail (P0335) | Not detected |
| TP sensor circuit fail (P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| EVAP system pressure sensor circuit fail (P0452, P0453) | Not detected |
| EVAP leak detection pump fail (P2401, P2402) | Not detected |
| EVAP system vent valve fail (P2419, P2420) | Not detected |
| Both of following conditions 1 and 2 met | |
| 1. Average engine load value ratio | Less than 0.85% or more than 1.26% (varies with estimated engine load) |
| 2. Average air fuel ratio | Less than -20% or more than 20% |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON.
- Turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and warm it up until the engine coolant temperature reaches 70°C (158°F) or higher [A].
- Drive the vehicle at approximately 50 mph (80 km/h) to 70 mph (112 km/h) for 5 minutes or more [B]. HINT: Drive while keeping the engine load as stable as possible.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0101.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0101) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0101 is output A DTC P0101 and other DTCs are output B HINT: If any DTCs other than P0101 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK INTAKE SYSTEM Check the intake system for vacuum leaks. Refer to «ON-VEHICLE INSPECTION»(ref-428894-S11533945902011101200000) . OK No leaks from intake system. NG --> REPAIR OR REPLACE INTAKE SYSTEM OK: Go to next step
- CHECK PCV HOSE CONNECTIONS Check the PCV hose conditions. OK PCV hose is connected correctly and is not damaged. NG --> REPAIR OR REPLACE PCV HOSE OK --> REPLACE MASS AIR FLOW METER
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | MAF meter |
| Required Sensors/Components (Sub) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately: Engine RPM less than 4000 RPM 2 driving cycles: Engine RPM 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | 0.2 V or more, and 4.9 V or less |
Scheme 220
Scheme 220: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [C].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [E].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 221
Scheme 221: WIRING DIAGRAM
| Related DTCs | P0102: Mass air flow meter range check (Low voltage) P0103: Mass air flow meter range check (High voltage) |
| Required Sensors/Components (Main) | MAF meter |
| Required Sensors/Components (Sub) | Crankshaft position sensor |
| Frequency of Operation | Continuous |
| Duration | 3 seconds |
| MIL Operation | Immediately: Engine RPM less than 4000 RPM 2 driving cycles: Engine RPM 4000 RPM or more |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Mass air flow meter voltage | Less than 0.2 V |
| Mass air flow meter voltage | More than 4.9 V |
| Mass air flow meter voltage | 0.2 V or more, and 4.9 V or less |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- Idle the engine for 5 seconds [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [C].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Run the engine at an engine speed of 4000 RPM or more for 5 seconds [D].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending [E].
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning. If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0102 or P0103.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ DTC OUTPUT Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0102 is output A DTC P0103 is output B B --> See step 6 A: Go to next step
- INSPECT MASS AIR FLOW METER (POWER SOURCE VOLTAGE) Disconnect the mass air flow (MAF) meter connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard voltage Tester Connection Switch Condition Specified Condition B10-3 (+B) - Body ground Ignition switch ON 11 to 14 V Reconnect the MAF meter connector. NG --> See step 5 OK: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the MAF meter connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-72 (VG) - B10-5 (VG) Always Below 1 ohms B50-73 (E2G) - B10-4 (E2G) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-72 (VG) or B10-5 (VG) - Body ground Always 10 kohms or higher Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK: Go to next step
- INSPECT MASS AIR FLOW METER Perform On-vehicle Inspection. Refer to «ON-VEHICLE INSPECTION»(ref-428889-S18252336832011101200000) . Inspect the function of the mass air flow meter. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / MAF. Start the engine. Check that the reading of the mass air flow meter changes when the engine is raced. OK The reading changes. NG --> REPLACE MASS AIR FLOW METER OK --> See step 8
- INSPECT FUSE (EFI NO. 2) Remove the EFI No. 2 fuse from the engine room R/B. Measure the EFI No. 2 fuse resistance. Standard resistance Below 1 ohms Reinstall the EFI No. 2 fuse. NG --> REPLACE FUSE (EFI NO. 2 FUSE) OK --> REPAIR OR REPLACE HARNESS OR CONNECTOR (EFI RELAY - MASS AIR FLOW METER)
- CHECK HARNESS AND CONNECTOR (SENSOR GROUND) Disconnect the MAF meter connector. Measure the resistance between the terminals. Standard resistance Tester Connection Condition Specified Condition B10-4 (E2G) - Body ground Always Below 1 ohms Reconnect the MAF meter connector. OK --> REPLACE MASS AIR FLOW METER NG: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the MAF meter connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-73 (E2G) - B10-4 (E2G) Always Below 1 ohms Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (MASS AIR FLOW METER - ECM) OK --> See step 8
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
Scheme 222
- The Intake Air Temperature (IAT) sensor, mounted on the Mass Air Flow (MAF) meter, monitors the IAT. The IAT sensor has a built-in thermistor with a resistance that varies according to the temperature of the intake air. When the IAT drops, the resistance of the thermistor increases. When the temperature rises, the resistance drops. These variations in resistance are transmitted to the ECM as voltage changes.
- The IAT sensor is powered by a 5 V supply from the THA terminal of the ECM, via resistor R.
- Resistor R and the IAT sensor are connected in series. When the resistance value of the IAT sensor changes, according to changes in the IAT, the voltage at terminal THA also varies. Based on this signal, the ECM increases the fuel injection volume when the engine is cold to improve driveability.
| DTC No. | DTC Detection Condition | Trouble Area |
| P0111 | When either of following conditions are met (2 trip detection logic): In the time period between the warm engine being stopped and the next engine start, change in intake air temperature sensor output below threshold. During engine warm up after a cold engine starts, change in intake air temperature sensor output below threshold. | Mass air flow meter |
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake Air Temperature (IAT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| MAF meter circuit fail (P0102, P0103) | Not detected |
| ECT change since engine stop | 40°C (-40°F) or more |
| ECT before engine stop | 70°C (158°F) or more |
| Time that MAF is low before engine stop | 35 times |
| Accumulated MAF amount before engine stop | 2033 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| MAF meter circuit fail (P0102, P0103) | Not detected |
| ECT | 70°C (158°F) or more |
| Accumulated MAF amount | 2033 g or more |
| One of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| IAT change | Less than 1°C (2°F) |
| IAT change | Less than 1°C (2°F) |
Scheme 223
Scheme 223: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (2°F), the intake air temperature sensor (mass air flow meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
- Check the DTC judgment result again [F].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> REPLACE MASS AIR FLOW METER A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
| Related DTCs | P0111: Intake air temperature sensor rationality (After engine stop) P0111: Intake air temperature sensor rationality (After cold engine start) |
| Required Sensors/Components (Main) | Intake Air Temperature (IAT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Time after engine start | 10 seconds or more |
| Battery voltage | 10.5 V or more |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| MAF meter circuit fail (P0102, P0103) | Not detected |
| ECT change since engine stop | 40°C (-40°F) or more |
| ECT before engine stop | 70°C (158°F) or more |
| Time that MAF is low before engine stop | 35 times |
| Accumulated MAF amount before engine stop | 2033 g or more |
| Key-off duration | 30 minutes |
| Key-off duration | 5 hours |
| Time after engine start | 10 seconds or more |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| MAF meter circuit fail (P0102, P0103) | Not detected |
| ECT | 70°C (158°F) or more |
| Accumulated MAF amount | 2033 g or more |
| One of the following conditions 1 or 2 is met | |
| 1. Duration while engine load is low | 120 seconds or more |
| 2. Duration while engine load is high | 10 seconds or more |
| IAT change | Less than 1°C (2°F) |
| IAT change | Less than 1°C (2°F) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and warm it up until the engine coolant temperature reaches 75°C (167°F) or higher [B].
- Idle the engine for 5 minutes or more [C]. HINT: During steps [A] through [C], if the change in the intake air temperature is below 1°C (2°F), the intake air temperature sensor (mass air flow meter) is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0111.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [E] and [F].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [E].
- Check the DTC judgment result again [F].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0111) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0111 and other DTCs are output A DTC P0111 is output B HINT: If any DTCs other than P0111 are output, troubleshoot those DTCs first. B --> REPLACE MASS AIR FLOW METER A --> See step 2
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake Air Temperature (IAT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Intake air temperature sensor voltage | Less than 0.18 V |
| Intake air temperature sensor voltage | More than 4.91 V |
| Intake air temperature sensor voltage | 0.18 to 4.91 V |
Scheme 224
Scheme 224: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 225
Scheme 225: WIRING DIAGRAM
| Related DTCs | P0112: Intake air temperature sensor range check (Low voltage) P0113: Intake air temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Intake Air Temperature (IAT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 8 V or more |
| Ignition switch | ON |
| Starter | OFF |
| Intake air temperature sensor voltage | Less than 0.18 V |
| Intake air temperature sensor voltage | More than 4.91 V |
| Intake air temperature sensor voltage | 0.18 to 4.91 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Trouble Codes.
- Read the DTCs [B].
- If a DTC is output, the system is malfunctioning. HINT: If a DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0112 or P0113.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [A] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (INTAKE AIR TEMPERATURE SENSOR) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard Same as actual Intake Air Temperature (IAT). Result Result Proceed to -40°C (-40°F) A 140°C (284°F) B Same as actual IAT C HINT: If there is an open circuit, Techstream indicates -40°C (-40°F). If there is a short circuit, Techstream indicates 140°C (284°F). B --> See step 5 C --> See step 7 A: Go to next step
- CHECK MASS AIR FLOW METER (CHECK FOR OPEN IN WIRE HARNESS) Confirm good connection of the Mass Air Flow (MAF) meter. Disconnect the MAF meter connector. Connect terminals THA and E2 of the MAF meter wire harness side connector. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard 140°C (284°F). Reconnect the MAF meter connector. OK --> REPLACE MASS AIR FLOW METER NG: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER - ECM) Disconnect the MAF meter connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance (Check for open) Tester Connection Condition Specified Condition B50-71 (THA) - B10-1 (THA) Always Below 1 ohms B50-74 (ETHA) - B10-2 (E2) Always Below 1 ohms Standard resistance (Check for short) Tester Connection Condition Specified Condition B50-71 (THA) or B10-1 (THA) - Body ground Always 10 kohms or higher B50-74 (ETHA) or B10-2 (E2) - Body ground Always 10 kohms or higher Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK MASS AIR FLOW METER (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the MAF meter connector. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Intake Air. Read the value displayed on the Techstream. Standard -40°C (-40°F). Reconnect the MAF meter connector. OK --> REPLACE MASS AIR FLOW METER NG: Go to next step
- CHECK HARNESS AND CONNECTOR (MASS AIR FLOW METER- ECM) Disconnect the MAF meter connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance Tester Connection Condition Specified Condition B50-71 (THA) or B10-1 (THA) - Body ground Always 10 kohms or higher Reconnect the MAF meter connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or more than 4.91 V |
| Engine coolant temperature sensor voltage | Less than 0.14 V |
| Engine coolant temperature sensor voltage | More than 4.91 V |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V |
Scheme 226
Scheme 226: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
Scheme 227
Scheme 227: WIRING DIAGRAM
| Related DTCs | P0115: Engine coolant temperature sensor range check (Chattering) P0117: Engine coolant temperature sensor range check (Low voltage) P0118: Engine coolant temperature sensor range check (High voltage) |
| Required Sensors/Components (Main) | Engine coolant temperature sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Continuous |
| Duration | 0.5 seconds |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Engine coolant temperature sensor voltage | Less than 0.14 V, or more than 4.91 V |
| Engine coolant temperature sensor voltage | Less than 0.14 V |
| Engine coolant temperature sensor voltage | More than 4.91 V |
| Engine coolant temperature sensor voltage | 0.14 to 4.91 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on.
- Wait 0.5 seconds or more [A].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0115, P0117 or P0118.
- Check the DTC judgment result [B]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard Between 80°C and 97°C (176°F and 207°F) with warm engine. Result Result Proceed to -40°C (-40°F) A 140°C (284°F) B Between 80°C and 97°C (176°F and 207°F) C HINT: If there is an open circuit, Techstream indicates -40°C (-40°F). If there is a short circuit, Techstream indicates 140°C (284°F). B --> See step 5 C --> See step 8 A: Go to next step
- CHECK ENGINE COOLANT TEMPERATURE SENSOR (CHECK FOR OPEN IN WIRE HARNESS) Confirm good connection of the sensor. Disconnect the engine coolant temperature (ECT) sensor connector. Connect terminals 1 and 2 of the ECT sensor connector on the wire harness side. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard 140°C (284°F). Reconnect the ECT sensor connector. OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR NG: Go to next step
- CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the ECT sensor connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance Tester Connection Condition Specified Condition B50-79 (THW) - B9-2 Always Below 1 ohms B50-78 (ETHW) - B9-1 Always Below 1 ohms Reconnect the ECM connector. Reconnect the ECT sensor connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 4
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK ENGINE COOLANT TEMPERATURE SENSOR (CHECK FOR SHORT IN WIRE HARNESS) Disconnect the ECT sensor connector. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. Standard -40°C (-40°F) Reconnect the ECT sensor connector. OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR NG: Go to next step
- CHECK HARNESS AND CONNECTOR (ENGINE COOLANT TEMPERATURE SENSOR - ECM) Disconnect the ECT sensor connector. Disconnect the ECM connector. Measure the resistance between the terminals. Standard resistance Tester Connection Condition Specified Condition B50-79 (THW) or B9-2 - Body ground Always 10 kohms or higher Reconnect the ECT sensor connector. Reconnect the ECM connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 7
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
- CHECK FOR INTERMITTENT PROBLEMS. Refer to «CHECK FOR INTERMITTENT PROBLEMS»(ref-428881-S18607069502011101200000)
| Related DTCs | P0116: Engine coolant temperature sensor rationality (ECT sensor cold start monitor) P0116: Engine coolant temperature sensor rationality (ECT sensor soak monitor) |
| Required Sensors/Components (Main) | Engine Coolant Temperature (ECT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| ECT at engine start | Less than 60°C (140°F) |
| ECT sensor circuit (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit (P0112, P0113) | Not detected |
| Soak time | 0 second or more |
| Accumulated MAF | 1241.06 g or more |
| Fuel cut | OFF |
| Difference between ECT at engine start and IAT | Less than 40°C (72°F) |
ECT SENSOR COLD START MONITOR
| Battery voltage | 10.5 V or more |
| Engine | Running |
| ECT sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| Soak time | 5 hours or more |
| Either of the following conditions is met | A or B |
| A. ECT at engine start | 60°C (140°F) or more |
| B. Accumulated MAF | 2333.98 g or more |
| ECT sensor value change | Less than 5°C (9°F) |
ECT SENSOR COLD START MONITOR
| Difference between current ECT sensor value and previous ECT sensor value when engine stopped | Less than 5°C (9°F) |
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
Scheme 228
Scheme 228: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 4 OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
| Related DTCs | P0116: Engine coolant temperature sensor rationality (ECT sensor cold start monitor) P0116: Engine coolant temperature sensor rationality (ECT sensor soak monitor) |
| Required Sensors/Components (Main) | Engine Coolant Temperature (ECT) sensor |
| Required Sensors/Components (Sub) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 10 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Battery voltage | 10.5 V or more |
| Time after engine start | 1 second or more |
| ECT at engine start | Less than 60°C (140°F) |
| ECT sensor circuit (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit (P0112, P0113) | Not detected |
| Soak time | 0 second or more |
| Accumulated MAF | 1241.06 g or more |
| Fuel cut | OFF |
| Difference between ECT at engine start and IAT | Less than 40°C (72°F) |
ECT SENSOR COLD START MONITOR
| Battery voltage | 10.5 V or more |
| Engine | Running |
| ECT sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| Soak time | 5 hours or more |
| Either of the following conditions is met | A or B |
| A. ECT at engine start | 60°C (140°F) or more |
| B. Accumulated MAF | 2333.98 g or more |
| ECT sensor value change | Less than 5°C (9°F) |
ECT SENSOR COLD START MONITOR
| Difference between current ECT sensor value and previous ECT sensor value when engine stopped | Less than 5°C (9°F) |
| Engine coolant temperature | Engine coolant temperature sensor value changes in accordance with actual engine coolant temperature |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 60°C (140°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine and idle it for 5 minutes or more [B]. HINT: If the engine coolant temperature does not change by 5°C (9°F) or higher, the engine coolant temperature sensor is malfunctioning. It is not necessary to continue this procedure.
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0116.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [D] and [E].
- Drive the vehicle at 25 mph (40 km/h) or more for a total of 5 minutes or more [D]. HINT: In the event of the drive pattern being interrupted (possibly due to factors such as traffic conditions), the drive pattern can be resumed.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the DTC judgment result again [E]. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0116) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0116 is output A DTC P0116 and other DTCs are output B HINT: If any DTCs other than P0116 are output, troubleshoot those DTCs first. B --> See step 3 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 4 OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
| Related DTCs | P011B: Engine Coolant Temperature (ECT) / Intake Air Temperature (IAT) sensor correlation |
| Required Sensors / Components (Main) | ECT / IAT sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of following conditions met | Conditions 1 and 2 |
| 1. All of the following conditions are met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or more |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions are met | Condition (a) and (b) |
| (a) Minimum IAT after engine start | 10°C (14°F) or more |
| (b) ECT before engine start | 10°C (14°F) or more |
| ECT sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Deviated ECT and IAT | Less than -20°C (-36°F), or more than 20°C (36°F) |
Scheme 229
Scheme 229: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) [A].
- Turn the ignition switch off and wait for 30 seconds.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [C] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> REPLACE MASS AIR FLOW METER OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are heat sources such as a block heater in the engine compartment. NG --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
| Related DTCs | P011B: Engine Coolant Temperature (ECT) / Intake Air Temperature (IAT) sensor correlation |
| Required Sensors / Components (Main) | ECT / IAT sensor |
| Required Sensors / Components (Related) | |
| Frequency of Operation | Once per driving cycle |
| Duration | 7 hours or more |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| All of following conditions met | Conditions 1 and 2 |
| 1. All of the following conditions are met | Conditions (a), (b), (c) and (d) |
| (a) After ignition switch ON and engine not running time | Less than 20 seconds |
| (b) Soak Time | 7 hours or more |
| (c) Battery voltage | 10.5 V or more |
| (d) Time after engine start | 15 seconds or more |
| 2. Either of the following conditions are met | Condition (a) and (b) |
| (a) Minimum IAT after engine start | 10°C (14°F) or more |
| (b) ECT before engine start | 10°C (14°F) or more |
| ECT sensor circuit fail (P0115, P0117, P0118, P0125) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| Soak timer circuit fail (P2610) | Not detected |
| Deviated ECT and IAT | Less than -20°C (-36°F), or more than 20°C (36°F) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) [A].
- Turn the ignition switch off and wait for 30 seconds.
- With the engine stopped, leave the vehicle as is for 7.5 hours or more [B].
- Turn the ignition switch to ON and turn the Techstream on.
- Start the engine and wait 60 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [D].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P011B.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [A] through [C] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO P011B) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P011B is output A DTC P011B and other DTCs are output B HINT: If any DTCs other than P011B are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- READ VALUE USING TECHSTREAM (INTAKE AIR) Leave the vehicle for 7 hours or more. HINT: It is necessary to leave the vehicle for 7 hours or more to allow conditions similar to the DTC detection conditions. Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / All Data / Intake Air. Read the value displayed on the Techstream. OK Difference between the intake air temperature and the actual outside air temperature is within 10°C (18°F). HINT: Temperature readings on the vehicle's outside temperature gauge (if equipped) are not suitable for comparing to the intake air temperature reading. The outside temperature gauge has a significant delay built in to prevent temperature swings from being displayed on its display. Use an accurate thermometer to determine the outside air temperature. NG --> REPLACE MASS AIR FLOW METER OK: Go to next step
- READ VALUE USING TECHSTREAM (COOLANT TEMP) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Select the following menu items: Powertrain / Engine / Data List / All Data / Coolant Temp. Read the value displayed on the Techstream. OK The difference between the coolant temperature and the actual outside air temperature is within 10°C (18°F). HINT: If the result is not as specified, check that there are heat sources such as a block heater in the engine compartment. NG --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR OK --> See step 5
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
| Related DTCs | P0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 (Case 1) 0.4 seconds: P2135 (Case 2) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P02135
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch | ON |
| B. Electric throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.535 V or higher |
| Either of the following conditions is met | |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Higher than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Lower than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.535 V or higher |
| Either of the following conditions A or B is met | |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | More than 0.2 V, and less than 4.535 V |
| VTA2 voltage | More than 1.75 V, and less than 4.8 V |
Scheme 230
Scheme 230: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
FAIL-SAFE
When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
Scheme 231
Scheme 231: WIRING DIAGRAM
| Related DTCs | P0120: Throttle position sensor 1 range check (Chattering) P0121: Throttle position sensor rationality P0122: Throttle position sensor 1 range check (Low voltage) P0123: Throttle position sensor 1 range check (High voltage) P0220: Throttle position sensor 2 range check (Chattering) P0222: Throttle position sensor 2 range check (Low voltage) P0223: Throttle position sensor 2 range check (High voltage) P2135: Throttle position sensor range check (Correlation) |
| Required Sensors/Components (Main) | Throttle position sensor |
| Required Sensors/Components (Related) | |
| Frequency of Operation | Continuous |
| Duration | 2 seconds: P0120, P0122, P0123, P0220, P0222 and P0223 Within 2 seconds: P0121 0.5 seconds: P2135 (Case 1) 0.4 seconds: P2135 (Case 2) |
| MIL Operation | Immediately |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch ON | 0.012 seconds or more |
| B. Electronic throttle actuator power | ON |
P0120, P0122, P0123, P0220, P0222, P0223, P02135
| Monitor runs whenever following DTCs are not present | None |
| Either of the following conditions A or B is met | |
| A. Ignition switch | ON |
| B. Electric throttle motor power | ON |
| Throttle position sensor malfunction (P0120, P0122, P0123, P0220, P0222, P0223, P2135) | Not detected |
| VTA1 voltage | 0.2 V or less, or 4.535 V or higher |
| Either of the following conditions is met | |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Higher than 1.6 V |
| Difference of throttle position sensor voltage between VTA1 and VTA2 x 0.8 | Lower than 0.8 V |
| VTA1 voltage | 0.2 V or less |
| VTA1 voltage | 4.535 V or higher |
| Either of the following conditions A or B is met | |
| A. VTA2 voltage | 1.75 V or less |
| B. VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| VTA2 voltage | 1.75 V or less |
| VTA2 voltage when VTA1 0.2 V or higher, and 2.02 V or less | 4.8 V or higher |
| Difference between VTA1 and VTA2 voltages | 0.02 V or less |
| VTA1 voltage | 0.2 V or less |
| VTA2 voltage | 1.75 V or less |
| VTA1 voltage | More than 0.2 V, and less than 4.535 V |
| VTA2 voltage | More than 1.75 V, and less than 4.8 V |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the Clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for at least 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- With the vehicle stationary, fully depress and release the accelerator pedal [B].
- Idle the engine for 2 seconds or more [C].
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0120, P0121, P0122, P0123, P0220, P0222, P0223 or P2135.
- Check the DTC judgment result [D]. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows INCOMPLETE or UNKNOWN, perform steps [B] and [D] again.
- If the test result is UNKNOWN, enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the Pending DTCs. HINT: If a pending DTC is output, the system is malfunctioning.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
When any of these DTCs, as well as other DTCs relating to electronic throttle control system malfunctions are set, the ECM enters fail-safe mode. During fail-safe mode, the ECM cuts the current to the throttle actuator, and the throttle valve is returned to a 6° throttle angle by the return spring. The ECM then adjusts the engine output by controlling the fuel injection (intermittent fuel-cut) and ignition timing, in accordance with the accelerator pedal opening angle, to allow the vehicle to continue at a minimal speed. If the accelerator pedal is depressed firmly and gently, the vehicle can be driven slowly.
Fail-safe mode continues until a pass condition is detected, and the ignition switch is then turned off.
- READ VALUE USING TECHSTREAM (THROTTLE POSITION SENSOR) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Data List / All Data / Throttle Position No. 1 and Throttle Position No. 2. Read the values displayed on the Techstream. RESULT When Accelerator Pedal Released When Accelerator Pedal Depressed Trouble Area Proceed to Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) Throttle Position No. 1 (VTA1) Throttle Position No. 2 (VTA2) 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V 0 to 0.2 V VC circuit open A 4.5 to 5.0 V 4.5 to 5.0 V 4.5 to 5.0 V 4.5 to 5.0 V E2 circuit open 0 to 0.2 V, or 4.5 to 5.0 V 2.1 V to 3.1 V (Fail-safe) 0 to 0.2 V, or 4.5 to 5.0 V 2.1 V to 3.1 V (Fail-safe) VTA1 circuit open or ground short 0.6 V to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 5.0 V 0.6 V to 1.4 V (Fail-safe) 0 to 0.2 V, or 4.5 to 5.0 V VTA2 circuit open or ground short 0.5 to 1.1 V 2.1 to 3.1 V 3.2 to 4.8 V (Not fail-safe) 4.6 to 5.0 V (Not fail-safe) Throttle position sensor circuit normal B HINT: DTC P0121 is stored when the voltages output from VTA1 and VTA2 are not consistent with the characteristics of the sensors. Therefore, check the Freeze Frame Data when this DTC is output. Use the following formula to confirm relative fluctuations in voltage. Features of sensor output VTA2 x 0.8 is approximately equal to VTA1 + 1.11 V VTA1: Throttle Position No. 1 VTA2: Throttle position No. 2 If DTC P0121 is output, proceed to 2 "CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM)". B --> See step 5 A: Go to next step
- CHECK HARNESS AND CONNECTOR (THROTTLE POSITION SENSOR - ECM) Disconnect the throttle body connector. Disconnect the ECM connector. Measure the resistance according to the value(s) in the table below. Standard Resistance (Check for Open) Tester Connection Condition Specified Condition B30-5 (VC) - B50-96 (VCTA) Always Below 1 ohms B30-6 (VTA) - B50-98 (VTA1) Always Below 1 ohms B30-4 (VTA2) - B50-99 (VTA2) Always Below 1 ohms B30-3 (E2) - B50-97 (ETA) Always Below 1 ohms Standard Resistance (Check for Short) Tester Connection Condition Specified Condition B30-5 (VC) or B50-96 (VCTA) - Body ground Always 10 kohms or higher B30-6 (VTA) or B50-98 (VTA1) - Body ground Always 10 kohms or higher B30-4 (VTA2) or B50-99 (VTA2) - Body ground Always 10 kohms or higher Reconnect the ECM connector. Reconnect the throttle body connector. NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR (THROTTLE POSITION SENSOR - ECM) OK: Go to next step
- INSPECT ECM (VC VOLTAGE) Disconnect the throttle body connector. Turn the ignition switch to ON. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Switch Condition Specified Condition B30-5 (VC) - B30-3 (E2) Ignition switch ON 4.5 to 5.5 V Reconnect the throttle body connector. NG --> See step 6 OK: Go to next step
- REPLACE THROTTLE BODY Replace the throttle body. Refer to «REMOVAL»(ref-428889-S26076023702011101200000) . NEXT: Go to next step
- CHECK WHETHER DTC OUTPUT RECURS (THROTTLE POSITION SENSOR DTCS) Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . Start the engine. Allow the engine to idle for 15 seconds or more. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0120, P0121, P0122, P0123, P0220, P0222, P0223, and/or P2135 are output A DTC is not output B B --> END A --> See step 6
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Thermostat, cooling system |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Once per driving cycle |
| Duration | 64 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 8.33°C [47°F]) or more 111 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 19.44°C [67°F]) to (Closed-loop engine coolant temperature - 8.33°C [47°F]) 1200 seconds: Engine coolant temperature at engine start is less than (Closed-loop engine coolant temperature - 19.44°C [67°F]) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| MAF sensor circuit fail (P0102, P0103) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature | 64 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 8.33°C [47°F]) or more 111 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 19.44°C [67°F]) to (Closed-loop engine coolant temperature - 8.33°C [47°F]) 1200 seconds: Engine coolant temperature at engine start is less than (Closed-loop engine coolant temperature - 19.44°C [67°F]) |
Scheme 232
Scheme 232: CONFIRMATION DRIVING PATTERN
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 5°C (41°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- After starting the engine, wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
| Related DTCs | P0125: Insufficient engine coolant temperature for closed-loop fuel control |
| Required Sensors/Components (Main) | Thermostat, cooling system |
| Required Sensors/Components (Related) | Engine coolant temperature sensor and mass air flow meter |
| Frequency of Operation | Once per driving cycle |
| Duration | 64 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 8.33°C [47°F]) or more 111 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 19.44°C [67°F]) to (Closed-loop engine coolant temperature - 8.33°C [47°F]) 1200 seconds: Engine coolant temperature at engine start is less than (Closed-loop engine coolant temperature - 19.44°C [67°F]) |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | None |
| MAF sensor circuit fail (P0102, P0103) | Not detected |
| IAT sensor circuit fail (P0112, P0113) | Not detected |
| ECT sensor circuit fail (P0115, P0117, P0118) | Not detected |
| Thermostat fail (P0128) | Not detected |
| Time until actual engine coolant temperature reaches closed-loop fuel control enabling temperature | 64 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 8.33°C [47°F]) or more 111 seconds: Engine coolant temperature at engine start is (Closed-loop engine coolant temperature - 19.44°C [67°F]) to (Closed-loop engine coolant temperature - 8.33°C [47°F]) 1200 seconds: Engine coolant temperature at engine start is less than (Closed-loop engine coolant temperature - 19.44°C [67°F]) |
- Leave the vehicle outside overnight.
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp.
- Check that the engine coolant temperature is 5°C (41°F) or less.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off and wait for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Start the engine.
- After starting the engine, wait 21 minutes or more [B].
- Enter the following menus: Powertrain / Engine / Trouble Codes / Pending.
- Read the pending DTCs [C].
- If a pending DTC is output, the system is malfunctioning. HINT: If a pending DTC is not output, perform the following procedure.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Input the DTC: P0125.
- Check the DTC judgment result. Techstream Display Description NORMAL DTC judgment completed System normal ABNORMAL DTC judgment completed System abnormal INCOMPLETE DTC judgment not completed Perform driving pattern after confirming DTC enabling conditions UNKNOWN Unable to perform DTC judgment Number of DTCs which do not fulfill DTC preconditions has reached ECU's memory limit HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal. If the judgment result shows INCOMPLETE or UNKNOWN, perform step [B] again.
- Enter the following menus: Powertrain / Engine / Utility / All Readiness.
- Check the judgment result. HINT: If the judgment result shows ABNORMAL, the system has a malfunction. If the judgment result shows NORMAL, the system is normal.
- If the test result is INCOMPLETE or UNKNOWN and no pending DTC is output, perform a universal trip and check for permanent DTCs. Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) . HINT: If a permanent DTC is output, the system is malfunctioning. If no permanent DTC is output, the system is normal.
- CHECK ANY OTHER DTCS OUTPUT (IN ADDITION TO DTC P0125) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0125 is output A DTC P0125 and other DTCs are output B HINT: If any DTCs other than P0125 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 5 OK: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK --> REPLACE ENGINE COOLANT TEMPERATURE SENSOR
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat |
| Required Sensors/Components (Sub) | Engine Coolant Temperature (ECT) sensor, Intake Air Temperature (IAT) sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 540 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance) |
| Battery voltage | 11 V or more |
| One of the following conditions 1 or 2 is met | |
| 1. All of following conditions are met | |
| ECT at engine start - IAT at engine start | 15 to 7°C (-27 to 12.6°F) |
| ECT at engine start | 10 to 56°C (14 to 133°F) |
| IAT at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions are met | |
| ECT at engine start - IAT at engine start | More than 7°C (12..6°F) |
| ECT at engine start | 56°C (133°F) or less |
| IAT at engine start | 10°C (14°F) or more |
| Accumulated time that vehicle speed is 80 mph (128 km/h) or more speed | Less than 20 seconds |
| Duration that all of the following conditions 1 and 2 are met | 5 seconds or more |
| 1. Estimated ECT | 75°C (167°F) or more |
| 2. ECT sensor output | Less than 75°C (167°F) |
Scheme 233
Scheme 233: CONFIRMATION DRIVING PATTERN
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S23178403412011101200000) .
- Turn the ignition switch off for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F). [A]
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle for 15 minutes at 50 mph (80 km/h). [B] WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After driving the vehicle at 50 mph (80 km/h) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher. [C] HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
- CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTC other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S09869597972011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S20017543742011101200000)
| Related DTCs | P0128: Coolant Thermostat |
| Required Sensors/Components (Main) | Thermostat |
| Required Sensors/Components (Sub) | Engine Coolant Temperature (ECT) sensor, Intake Air Temperature (IAT) sensor, Vehicle speed sensor |
| Frequency of Operation | Once per driving cycle |
| Duration | 540 seconds |
| MIL Operation | 2 driving cycles |
| Sequence of Operation | None |
| Monitor runs whenever following DTCs are not present | P0010, P0020 (OCV bank 1, 2) P0011, P0021 (VVT system bank 1, 2 - advance) P0012, P0022 (VVT system bank 1, 2 - retard) P0013, P0023 (Exhaust OCV bank 1, 2) P0014, P0024 (Exhaust VVT system bank 1, 2 - advance) P0015, P0025 (Exhaust VVT system bank 1, 2 - retard) P0016, P0018 (VVT system bank 1, 2 - misalignment) P0017, P0019 (Exhaust VVT system bank 1, 2 - misalignment) P0031, P0032, P0051, P0052 (A/F sensor heater) P0102, P0103 (MAF meter) P0112, P0113 (IAT sensor) P0115, P0117, P0118 (ECT sensor) P0120, P0121, P0122, P0123, P0220, P0222, P0223, P2135 (TP sensor) P014C, P014D, P014E, P014F (Air fuel ratio sensor - slow response) P015A, P015B, P015C, P015D (Air fuel ratio sensor - delayed response) P0171, P0172, P0174, P0175 (Fuel system) P0301, P0302, P0303, P0304, P0305, P0306 (Misfire) P0335 (CKP sensor) P0340, P0342, P0343, P0345, P0347, P0348 (VVT sensor) P0351, P0352, P0353, P0354, P0355, P0356 (Igniter) P0365, P0367, P0368, P0390, P0392, P0393 (Exhaust VVT sensor) P0500 (Vehicle speed sensor) P2195, P2196, P2197, P2198 (A/F sensor - rationality) P2237, P2240 (A/F sensor - open) P2238, P2241, P2252, P2255 (A/F sensor - low impedance) P2239, P2242, P2253, P2256 (A/F sensor - high impedance) |
| Battery voltage | 11 V or more |
| One of the following conditions 1 or 2 is met | |
| 1. All of following conditions are met | |
| ECT at engine start - IAT at engine start | 15 to 7°C (-27 to 12.6°F) |
| ECT at engine start | 10 to 56°C (14 to 133°F) |
| IAT at engine start | 10 to 56°C (14 to 133°F) |
| 2. All of following conditions are met | |
| ECT at engine start - IAT at engine start | More than 7°C (12..6°F) |
| ECT at engine start | 56°C (133°F) or less |
| IAT at engine start | 10°C (14°F) or more |
| Accumulated time that vehicle speed is 80 mph (128 km/h) or more speed | Less than 20 seconds |
| Duration that all of the following conditions 1 and 2 are met | 5 seconds or more |
| 1. Estimated ECT | 75°C (167°F) or more |
| 2. ECT sensor output | Less than 75°C (167°F) |
- Connect the Techstream to the DLC3.
- Turn the ignition switch to ON and turn the Techstream on.
- Clear the DTCs (even if no DTCs are stored, perform the clear DTC procedure). Refer to «DTC CHECK / CLEAR»(ref-428881-S06483383612011101200000) .
- Turn the ignition switch off for 30 seconds.
- Turn the ignition switch to ON and turn the Techstream on [A].
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Stop the engine and allow it to soak.
- Connect the Techstream to the DLC3.
- Turn the ignition switch ON and turn the Techstream on.
- Enter the following menus: Powertrain / Engine / Data List / All Data / Coolant Temp and Intake Air.
- Check if "Coolant Temp" is 56°C (133°F) or less and "Intake Air" is between 0 and 35°C (32 and 95°F). [A]
- Set the heater to MAX HOT with fresh air mode selected and turn the A/C off.
- Start the engine and drive the vehicle for 15 minutes at 50 mph (80 km/h). [B] WARNING: When performing the confirmation driving pattern, obey all speed limits and traffic laws. HINT: Data can be captured relatively easily by using the snapshot function in the Data List. Enter the following menus: Data List / Function / Snap-shot configuration / Record time / 5 min. Data capture can be started by using the target point. For example, setting the target point to an engine speed of 4000 RPM and then racing the engine, etc. to raise the engine speed to a speed of 4000 RPM or more will cause data capture to start.
- After driving the vehicle at 50 mph (80 km/h) and "Coolant Temp" stabilizes, check that "Coolant Temp" is 75°C (167°F) or higher. [C] HINT: If "Coolant Temp" is below 75°C (167°F) while driving the vehicle at 50 mph (80 km/h), inspect the cooling system and thermostat.
- CHECK OTHER DTC OUTPUT (IN ADDITION TO DTC P0128) Connect Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Powertrain / Engine / Trouble Codes. Read the DTCs. Result Result Proceed to DTC P0128 is output A DTC P0128 and other DTCs are output B HINT: If any DTC other than P0128 are output, troubleshoot those DTCs first. B --> See step 4 A: Go to next step
- CHECK COOLING SYSTEM Check for defects in the cooling system that might cause the system to be too cold, such as abnormal radiator fan operation or any modifications. NG --> REPAIR OR REPLACE COOLING SYSTEM OK: Go to next step
- INSPECT THERMOSTAT Remove the thermostat. Refer to «REMOVAL»(ref-428876-S29306666792011101200000) . Check the valve opening temperature of the thermostat. Standard 80 to 84°C (176 to 183°F) HINT: In addition to the above check, confirm that the valve is completely closed when the temperature is below the standard. Reinstall the thermostat. Refer to «INSTALLATION»(ref-428876-S28236509722011101200000) . NG --> See step 5 OK --> See step 6
- GO TO DTC CHART. Refer to «DIAGNOSTIC TROUBLE CODE CHART»(ref-428881-S08160572302011101200000)
- REPLACE THERMOSTAT. Refer to «REMOVAL»(ref-428876-S29306666792011101200000)
- REPLACE ECM. Refer to «REMOVAL»(ref-428889-S30962419642011101200000)
