PRECAUTION

1. IGNITION SWITCH EXPRESSION HINT: The type of ignition switch used on this model differs according to the specifications of the vehicle. The expressions listed in the table below are used in this information. Expression Ignition Switch (position) Engine Switch (condition) Ignition Switch off Off Off Ignition Switch ON ON On (IG) Ignition Switch ACC ACC On (ACC) Engine Start START Start
2. POWER WINDOW CONTROL SYSTEM PRECAUTIONS WARNING: The power window control system prohibits the auto up/down function when the jam protection function malfunctions. Therefore, troubleshoot the power window control system after confirming that no trouble codes are output. When a door window regulator is replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be resumed by repeating the following operation at least 5 times: Close the power window by fully pulling up the power window switch and holding it at the auto up position. Open the power window by fully pushing down the power window switch. The jam protection function may operate unexpectedly even when the power window control system is normal, due to detection of a value different from the operation learned value when the door glass moving speed changes sharply under any of the following conditions: A power window is being opened or closed while the vehicle is driving on a rough road. A power window is being opened or closed while the door is being opened or closed. A sharp voltage change. NOTE: Do not disconnect the cable from the negative (-) battery terminal while the ignition switch is ON. Otherwise, DTC B2313 will be stored.

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

COMMUNICATION TABLE

1. *: w/ Smart Key System

CUSTOMIZE PARAMETERS

1. CUSTOMIZING FUNCTION WITH TECHSTREAM (REFERENCE) HINT: The following items can be customized. NOTE: When the customer requests a change in a function, first make sure that the function can be customized. Record the current settings before customizing. Connect the Techstream to the DLC3. Turn the ignition switch to ON. Turn the Techstream on. Enter the following menus: Customize. Select the setting by referring to the table below. POWER WINDOW Tester Display Default Content Setting Door Key P/W Up OFF This function is used to close the windows by operating the mechanical key. ON or OFF Door Key P/W Down OFF This function is used to open the windows by operating the mechanical key. ON or OFF P/W Up W/ Transmitter OFF This function is used to close the windows using the wireless key transmitter. ON or OFF P/W Down W/ Transmitter OFF This function is used to open the windows using the wireless key transmitter. ON or OFF P Window Auto Up Avail This function is used to enable or disable the auto up function for the front passenger door window using the power window regulator switch assembly (for front passenger side). Avail or Not Avl P Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the front passenger door window using the master switch. Avail or Not Avl RR Window Auto Up Avail This function is used to enable or disable the auto up function using the rear power window regulator switch assembly RH. Avail or Not Avl RR Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear RH door window using the master switch. Avail or Not Avl RL Window Auto Up Avail This function is used to enable or disable the auto up function using the rear power window regulator switch assembly LH. Avail or Not Avl RL Window Auto Up From Driver Avail This function is used to enable or disable the remote auto up function for the rear LH door window using the master switch. Avail or Not Avl Door Key Linked Back P/W UP AVAIL This function is used to close the back door window by operating the mechanical key. NOT AVL or AVAIL Door Key Linked Back P/W DOWN AVAIL This function is used to open the back door window by operating the mechanical key. NOT AVL or AVAIL PSD & PBD OPERATION (W/ SMART KEY SYSTEM) Tester Display Default Content Setting Smart Back Door P/W Up SW AVAIL This function is used to permit or disable back door power window up operation via the back door control switch. NOT AVL or AVAIL Smart Back Door P/W Down AVAIL This function is used to permit or disable back door power window down operation via the back door control switch. NOT AVL or AVAIL Smart Back Door P/W Press ON 0.8 sec. This function is used to change the time that the back door control switch. must be pressed to operate the back door power window. 0.8 sec., 1 sec., 1.2 sec., 1.4 sec. Back Door P/W UP when half-shut NOT AVL This function is used to permit or disable back door power window up operation when the back door is ajar. NOT AVL or AVAIL

INITIALIZATION

1. INITIALIZE POWER WINDOW CONTROL SYSTEM (POWER WINDOW REGULATOR MOTOR ASSEMBLY (ALL DOORS)) WARNING: When a power window regulator motor assembly is reinstalled or replaced, the power window control system must be initialized. Functions such as auto up/down, jam protection, remote control and key-off operation do not operate if the initialization is not performed. HINT: When the battery is replaced, it is not necessary to initialize the power window control system. NOTE: When a power window regulator motor assembly is replaced, DTC B2313 is output. Clear the DTC after the initialization. When performing initialization, do not perform any other procedures. When performing initialization, use the power window switch of each door to initialize each power window regulator motor. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used, due to detection of a value different from the operation learned value of the door glass movement speed. In such cases, the auto up function can be reinitialized by repeating the following operation at least 5 times: Open the power window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly. Close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and holding it at the auto up position. If the initialization is not completed properly, the LIN communication system may have a malfunction. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-422210-S16666442022011092600000) . Initialization procedure when replacing a power window regulator motor assembly with a new one: Connect the battery and turn the ignition switch to ON (at this time, the LED on the multiplex network master switch assembly or power window regulator switch assembly blinks to indicate that it is ready for initialization). Fully open the window by fully pushing down the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully opened. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully closed to reset the glass position. The LED on the multiplex network master switch assembly or power window regulator switch assembly stops blinking and illuminates to indicate that the initialization is complete. Initialization procedure when removing/installing a power window regulator motor assembly: Connect the battery and turn the ignition switch to ON. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization. Initialization procedure when the power window does not fully open: Connect the battery and turn the ignition switch to ON. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 6 seconds or more after the window is fully closed (if the power window does not move or stops halfway even when the switch is fully pulled, release the switch and fully pull it again). Fully open the window by pushing down the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully opened. Release the multiplex network master switch assembly or power window regulator switch assembly. Then fully push down and hold the switch for 4 seconds or more. Fully close the power window by fully pulling up the multiplex network master switch assembly or power window regulator switch assembly and hold the switch for 1 second or more after the window is fully closed to reset the glass position and complete the initialization.
