Power Window Control System (Diagnostic Codes & Symptom Tests): Diagnosis

INSPECTION PROCEDURE

Note. When a power window regulator motor is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch or power window regulator switch and holding it in the auto up position. Open the power window by fully pushing down the switch.

Note. When a power window regulator motor is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch or back door power window regulator switch and holding it in the auto up position. Open the power window by fully pushing down the switch.

HINT

Since the power window control system has functions that use LIN communication, first confirm that there is no malfunction in the communication system by inspecting the LIN communication functions in accordance with the "How to Proceed with Troubleshooting" procedures. Then, conduct the following inspection procedure.

Scheme 136

Scheme 136: PROCEDURE

CHECK FOR DTC Clear the DTC. Refer to «DTC CHECK / CLEAR»(ref-421963-S28431784692011092600000) . Check for DTCs. Refer to «DTC CHECK / CLEAR»(ref-421963-S28431784692011092600000) . RESULT Result Proceed to No DTCs output A LIN communication DTCs are output B DTC B2312 is output C B --> See step 22 C --> See step 2 A --> END (DTC WAS STORED DUE TO SWITCH BEING OPERATED FOR 20 SECONDS OR MORE)
CHECK DTC OUTPUT Check the parts which the DTCs have been output from. RESULT Result Proceed to DTC output from multiplex network master switch A DTC output from front power window regulator motor LH B DTC output from front power window regulator motor RH C DTC output from rear power window regulator motor LH D DTC output from rear power window regulator motor RH E B --> See step 3 C --> See step 5 D --> See step 8 E --> See step 11 A --> See step 14
READ VALUE USING TECHSTREAM (MULTIPLEX NETWORK MASTER SWITCH) Use the Data List to check if the power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . D-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Up SW Driver side power window manual up signal / ON or OFF ON: Driver side power window manual up switch operated OFF: Driver side power window switch not operated - D Door P/W Down SW Driver side power window manual down signal / ON or OFF ON: Driver side power window manual down switch operated OFF: Driver side power window switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 4 OK --> See step 18
CHECK HARNESS AND CONNECTOR (MULTIPLEX NETWORK MASTER SWITCH - FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH) Disconnect the h1 multiplex network master switch connector. Disconnect the I2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition h1-20 (UP) - I2-10 (UP) Always Below 1 ohms h1-15 (DOWN) - I2-7 (DOWN) Always Below 1 ohms h1-20 (UP) - Body ground Always 10 kohms or higher h1-15 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 18
READ VALUE USING TECHSTREAM (POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . P-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto up/down signal / ON or OFF ON: Front passenger side power window auto up/down switch operated OFF: Front passenger side power window regulator switch not operated - P Door P/W Up SW Front passenger side power window manual up signal / ON or OFF ON: Front passenger side power window manual up switch operated OFF: Front passenger side power window regulator switch not operated - P Door P/W Down SW Front passenger side power window manual down signal / ON or OFF ON: Front passenger side power window manual down switch operated OFF: Front passenger side power window regulator switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 6 OK --> See step 19
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch. Refer to «INSPECTION»(ref-422232-S26604393732011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 8 (AUTO) - 1 (GND) Auto up/down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher 8 (AUTO) - 1 (GND) Not operated 10 kohms or higher NG --> See step 15 OK: Go to next step
CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH ASSEMBLY - FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH) Disconnect the g1 power window regulator switch connector. Disconnect the H2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition g1-6 (UP) - H2-10 (UP) Always Below 1 ohms g1-7 (DOWN) - H2-7 (DOWN) Always Below 1 ohms g1-8 (AUTO) - H2-4 (AUTO) Always Below 1 ohms g1-6 (UP) - Body ground Always 10 kohms or higher g1-7 (DOWN) - Body ground Always 10 kohms or higher g1-8 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 19
READ VALUE USING TECHSTREAM (REAR POWER WINDOW REGULATOR SWITCH LH) Use the Data List to check if the power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RL-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Auto SW Rear power window LH auto up/down signal / ON or OFF ON: Rear power window LH auto up/down switch operated OFF: Rear power window LH switch not operated - RL Door P/W Up SW Rear power window LH manual up signal / ON or OFF ON: Rear power window LH manual up switch operated OFF: Rear power window LH switch not operated - RL Door P/W Down SW Rear power window LH manual down signal / ON or OFF ON: Rear power window LH manual down switch operated OFF: Rear power window LH switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 9 OK --> See step 20
INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH Remove the rear power window regulator switch. Refer to «REMOVAL»(ref-422232-S21345065772011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 8 (AUTO) - 1 (GND) Auto up/down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher 8 (AUTO) - 1 (GND) Not operated 10 kohms or higher NG --> See step 16 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH - REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH) Disconnect the j1 rear power window regulator switch connector. Disconnect the K2 rear power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition j1-6 (UP) - K2-10 (UP) Always Below 1 ohms j1-7 (DOWN) - K2-7 (DOWN) Always Below 1 ohms j1-8 (AUTO) - K2-4 (AUTO) Always Below 1 ohms j1-6 (UP) - Body ground Always 10 kohms or higher j1-7 (DOWN) - Body ground Always 10 kohms or higher j1-8 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 20
READ VALUE USING TECHSTREAM (REAR POWER WINDOW REGULATOR SWITCH RH) Use the Data List to check if the power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RR-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Auto SW Rear power window RH auto up/down signal / ON or OFF ON: Rear power window RH auto up/down switch operated OFF: Rear power window RH switch not operated - RR Door P/W Up SW Rear power window RH manual up signal / ON or OFF ON: Rear power window RH manual up switch operated OFF: Rear power window RH switch not operated - RR Door P/W Down SW Rear power window RH manual down signal / ON or OFF ON: Rear power window RH manual down switch operated OFF: Rear power window RH switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 12 OK --> See step 21
INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH Remove the rear power window regulator switch. Refer to «REMOVAL»(ref-422232-S21345065772011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 8 (AUTO) - 1 (GND) Auto up/down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher 8 (AUTO) - 1 (GND) Not operated 10 kohms or higher NG --> See step 17 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH - REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH) Disconnect the i1 rear power window regulator switch connector. Disconnect the J2 rear power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition i1-6 (UP) - J2-10 (UP) Always Below 1 ohms i1-7 (DOWN) - J2-7 (DOWN) Always Below 1 ohms i1-8 (AUTO) - J2-4 (AUTO) Always Below 1 ohms i1-6 (UP) - Body ground Always 10 kohms or higher i1-7 (DOWN) - Body ground Always 10 kohms or higher i1-8 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 21
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S30883843772011092600000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S06724911672011092600000)
REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S15747782842011092600000)
REPLACE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S15747782842011092600000)
REPLACE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-422210-S16666442022011092600000)

HINT

Scheme 137

Scheme 137: PROCEDURE

Scheme 138

CHECK FOR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421963-S28431784692011092600000). Check for DTCs. Refer to «DTC CHECK / CLEAR»(ref-421963-S28431784692011092600000). RESULT Result Proceed to DTC is not output A DTC B2311 is output B DTC B2312 is output C DTC B2313 is output D LIN communication system DTCs are output E B --> See step 8 C --> See step 9 D --> See step 10 E --> See step 11 A: Go to next step
CHECK MANUAL UP/DOWN FUNCTION (BACK DOOR POWER WINDOW REGULATOR SWITCH ASSEMBLY) Check that the manual up/down function using the back door power window regulator switch can operate the multiplex network door ECU. Refer to «OPERATION CHECK»(ref-421963-S03630375062011092600000). OK Manual up/down function operates. NG --> See step 12 OK: Go to next step
READ VALUE USING TECHSTREAM (BACK DOOR POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the back door power window regulator switch is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000). BACK DOOR P/W Tester Display Measurement Item/Range Normal Condition Diagnostic Note Inside Back Door P/W Auto SW Back door power window regulator switch auto up/down signal / ON or OFF ON: Back door power window regulator auto up/down switch operated OFF: Back door power window regulator switch not operated - OK On tester screen, item changes between ON and OFF according to above chart. NG --> See step 6 OK: Go to next step
CHECK HARNESS AND CONNECTOR (MULTIPLEX NETWORK DOOR ECU - BACK DOOR POWER WINDOW REGULATOR MOTOR ASSEMBLY) Disconnect the W9 back door power window regulator motor connector. Disconnect the W10 multiplex network door ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition W9-4 (AUTO) - W10-12 (AUT2) Always Below 1 ohms W9-1 (GND) - W10-1 (E4) Always Below 1 ohms W9-4 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK MULTIPLEX NETWORK DOOR ECU (BACK DOOR P/W) Reconnect the multiplex network door ECU. Measure the voltage according to the value(s) in the table below. Standard Voltage Tester Connection Tool Setting Switch Condition Specified Condition W10-12 (AUT2) - W10-1 (E4) 2 V/DIV., 100 ms/DIV. Ignition switch ON, back door power window auto up or auto down function operating Pulse generation (Scheme 137) NG --> See step 13 OK --> See step 15
INSPECT BACK DOOR POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the back door power window regulator switch. Refer to «REMOVAL»(ref-422232-S24355276292011092600000). Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 8 (AUTO) - 1 (E) Auto up/down operation Below 1 ohms 8 (AUTO) - 1 (E) Not operated 10 kohms or higher NG --> See step 14 OK: Go to next step
CHECK HARNESS AND CONNECTOR (BACK DOOR POWER WINDOW REGULATOR SWITCH ASSEMBLY - MULTIPLEX NETWORK DOOR ECU AND BODY GROUND) Disconnect the f1 back door power window regulator switch connector. Disconnect the V2 multiplex network door ECU connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition f1-8 (AUTO) - V2-21 (AUTO) Always Below 1 ohms f1-1 (E) - Body ground Always Below 1 ohms f1-8 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 13
GO TO DTC B2311. Refer to «DTC B2311: Power Window Motor Malfunction»(ref-422264-S27131173762011092600000)
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
GO TO DTC B2313. Refer to «DTC B2313: Glass Position Initialization Incomplete»(ref-422264-S24359371612011092600000)
GO TO LIN COMMUNICATION SYSTEM. Refer to «HOW TO PROCEED WITH TROUBLESHOOTING»(ref-422210-S16666442022011092600000)
GO TO "Manual Up / Down Function does not Operate on Back Door Only". Refer to «Manual Up / Down Function does not Operate on Back Door Only»(ref-422264-S13801005872011092600000)
REPLACE MULTIPLEX NETWORK DOOR ECU (BACK DOOR P/W). Refer to «REMOVAL»(ref-422232-S30883843772011092600000)
REPLACE BACK DOOR POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S24355276292011092600000)
REPLACE BACK DOOR POWER WINDOW REGULATOR MOTOR ASSEMBLY. Refer to «REMOVAL»(ref-422232-S00413652142011092600000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Scheme 139

Scheme 139: PROCEDURE

Scheme 140

Scheme 141

CHECK FOR DTC (B2312) Check if DTC B2312 is output. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000) . OK DTC B2312 is not output. NG --> See step 8 OK: Go to next step
READ VALUE USING TECHSTREAM (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY) Use the Data List to check if the multiplex network master switch is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . D-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note D Door P/W Up SW Driver side power window manual up signal / ON or OFF ON: Driver side power window manual up switch operated OFF: Driver side power window switch not operated - D Door P/W Down SW Driver side power window manual down signal / ON or OFF ON: Driver side power window manual down switch operated OFF: Driver side power window switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 4 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (POWER WINDOW) Select the Active Test, use the Techstream to generate a control command, and then check that power window regulator motor operates. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . D-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Driver side power window OFF/UP/DOWN - OK The power window regulator motor operates normally. NG --> See step 9 OK --> See step 11
CHECK HARNESS AND CONNECTOR (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY - BATTERY AND BODY GROUND) Disconnect the h1 multiplex network master switch connector. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition h1-11 (B) - Body ground Always 11 to 14 V Standard Resistance Tester Connection Condition Specified Condition h1-12 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Multiplex Network Master Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH - BATTERY AND BODY GROUND) Disconnect the I2 power window regulator motor connector. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition I2-2 (B) - Body ground Always 11 to 14 V Standard Resistance Tester Connection Condition Specified Condition I2-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Front Power Window Regulator Motor Assembly LH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY - FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH) Disconnect the h1 multiplex network master switch connector. Disconnect the I2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition h1-20 (UP) - I2-10 (UP) Always Below 1 ohms h1-15 (DOWN) - I2-7 (DOWN) Always Below 1 ohms h1-20 (UP) - Body ground Always 10 kohms or higher h1-15 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
INSPECT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH Remove the front power window regulator motor LH. Refer to «REMOVAL»(ref-422232-S15747782842011092600000) . Check that the window regulator motor moves smoothly as follows. NOTE: Do not apply positive (+) battery voltage to any terminal other than terminal 2 (B) to avoid damaging the pulse sensor inside the motor. Reset the power window regulator motor (initialize the pulse sensor) after installing the power window regulator motor to the door. OK Measurement Condition Specified Condition Connect the positive (+) battery terminal to terminal 2 (B), and connect the negative (-) battery terminal to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected to the battery, connect the negative (-) battery terminal to terminal 10 (UP). Disconnect and reconnect the negative (-) battery terminal to terminal 10 (UP) within 1 second. Motor gear rotates clockwise (Up) Connect the positive (+) battery terminal to terminal 2 (B), and connect the negative (-) battery terminal to terminal 1 (GND), and keep them connected for 3 seconds or more. With terminals 2 (B) and 1 (GND) connected to the battery, connect the negative (-) battery terminal to terminal 7 (DOWN). Disconnect and reconnect the negative (-) battery terminal to terminal 7 (DOWN) within 1 second. Motor gear rotates counterclockwise (Down) TEXT IN ILLUSTRATION *1 Motor Gear Clockwise Counterclockwise NG --> See step 9 OK --> See step 10
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
REPLACE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S15747782842011092600000)
REPLACE MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S30883843772011092600000)
REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-422214-S08215784352011092600000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Scheme 142

Scheme 142: PROCEDURE

Scheme 143

Scheme 144

CHECK FOR DTC (B2312) Check if DTC B2312 is output. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000) . OK DTC B2312 is not output. NG --> See step 8 OK: Go to next step
READ VALUE USING TECHSTREAM (POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the front power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . P-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Up SW Front passenger side power window manual up signal / ON or OFF ON: Front passenger side power window manual up switch operated OFF: Front passenger side power window regulator switch not operated - P Door P/W Down SW Front passenger side power window manual down signal / ON or OFF ON: Front passenger side power window manual down switch operated OFF: Front passenger side power window regulator switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 4 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (POWER WINDOW) Select the Active Test, use the Techstream to generate a control command, and then check that power window regulator motor operates. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . P-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Passenger side power window OFF/UP/DOWN - OK The power window regulator motor operates normally. NG --> See step 10 OK --> See step 11
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch. Refer to «INSPECTION»(ref-422232-S26604393732011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH ASSEMBLY - BODY GROUND) Disconnect the g1 power window regulator switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition g1-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Power Window Regulator Switch Assembly) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH ASSEMBLY - FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH) Disconnect the g1 power window regulator switch connector. Disconnect the H2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition g1-6 (UP) - H2-10 (UP) Always Below 1 ohms g1-7 (DOWN) - H2-7 (DOWN) Always Below 1 ohms g1-6 (UP) - Body ground Always 10 kohms or higher g1-7 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH - BATTERY AND BODY GROUND) Disconnect the H2 power window regulator motor connector. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition H2-2 (B) - Body ground Always 11 to 14 V Standard Resistance Tester Connection Condition Specified Condition H2-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Front Power Window Regulator Motor Assembly RH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S06724911672011092600000)
REPLACE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S06724911672011092600000)
REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-422214-S08215784352011092600000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Scheme 145

Scheme 146

CHECK FOR DTC (B2312) Check if DTC B2312 is output. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000) . OK DTC B2312 is not output. NG --> See step 8 OK: Go to next step
READ VALUE USING TECHSTREAM (REAR POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the rear power window regulator is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RL-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RL Door P/W Up SW Rear power window LH manual up signal / ON or OFF ON: Rear power window LH manual up switch operated OFF: Rear power window LH switch not operated - RL Door P/W Down SW Rear power window LH manual down signal / ON or OFF ON: Rear power window LH manual down switch operated OFF: Rear power window LH switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 4 OK: Go to next step
PERFORM ACTIVE TEST USING TECHSTREAM (POWER WINDOW) Select the Active Test, use the Techstream to generate a control command, and then check that power window regulator motor operates. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RL-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Rear LH side power window OFF/UP/DOWN - OK The power window regulator motor operates normally. NG --> See step 10 OK --> See step 11
INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH Remove the rear power window regulator switch. Refer to «REMOVAL»(ref-422232-S21345065772011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH - BODY GROUND) Disconnect the j1 rear power window regulator switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition j1-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Rear Power Window Regulator Switch Assembly LH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH - REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH) Disconnect the j1 rear power window regulator switch connector. Disconnect the K2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition j1-6 (UP) - K2-10 (UP) Always Below 1 ohms j1-7 (DOWN) - K2-7 (DOWN) Always Below 1 ohms j1-6 (UP) - Body ground Always 10 kohms or higher j1-7 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH - BATTERY AND BODY GROUND) Disconnect the K2 power window regulator motor connector. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition K2-2 (B) - Body ground Always 11 to 14 V Standard Resistance Tester Connection Condition Specified Condition K2-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Rear Power Window Regulator Motor Assembly LH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-422214-S08215784352011092600000)

Note. Inspect the fuses for circuits related to this system before performing the following inspection procedure.

HINT

Scheme 147

Scheme 148

CHECK FOR DTC (B2312) Check if DTC B2312 is output. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000) . OK DTC B2312 is not output. NG --> See step 8 OK: Go to next step
READ VALUE USING TECHSTREAM (REAR POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the rear power window regulator motor is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RR-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note RR Door P/W Up SW Rear power window RH manual up signal / ON or OFF ON: Rear power window RH manual up switch operated OFF: Rear power window RH switch not operated - RR Door P/W Down SW Rear power window RH manual down signal / ON or OFF ON: Rear power window RH manual down switch operated OFF: Rear power window RH switch not operated - OK On tester screen, each item changes between ON and OFF according to above chart. NG --> See step 4 OK --> See step 10
PERFORM ACTIVE TEST USING TECHSTREAM (POWER WINDOW) Select the Active Test, use the Techstream to generate a control command, and then check that power window regulator motor operates. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RR-DOOR MOTOR Tester Display Test Part Control Range Diagnostic Note Power Window Rear RH side power window OFF/UP/DOWN - OK The power window regulator motor operates normally. NG --> See step 10 OK --> See step 11
INSPECT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH Remove the rear power window regulator switch. Refer to «REMOVAL»(ref-422232-S21345065772011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 6 (UP) - 1 (GND) Manual up operation Below 1 ohms 7 (DOWN) - 1 (GND) Manual down operation Below 1 ohms 6 (UP) - 1 (GND) Not operated 10 kohms or higher 7 (DOWN) - 1 (GND) Not operated 10 kohms or higher NG --> See step 9 OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH - BODY GROUND) Disconnect the i1 rear power window regulator switch connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition i1-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Rear Power Window Regulator Switch Assembly RH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH - REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH) Disconnect the i1 rear power window regulator switch connector. Disconnect the J2 rear power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition i1-6 (UP) - J2-10 (UP) Always Below 1 ohms i1-7 (DOWN) - J2-7 (DOWN) Always Below 1 ohms i1-6 (UP) - Body ground Always 10 kohms or higher i1-7 (DOWN) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK: Go to next step
CHECK HARNESS AND CONNECTOR (REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH - BATTERY AND BODY GROUND) Disconnect the J2 rear power window regulator motor connector. Measure the voltage and resistance according to the value(s) in the table below. Standard Voltage Tester Connection Condition Specified Condition J2-2 (B) - Body ground Always 11 to 14 V Standard Resistance Tester Connection Condition Specified Condition J2-1 (GND) - Body ground Always Below 1 ohms TEXT IN ILLUSTRATION *a Front view of wire harness connector (to Rear Power Window Regulator Motor Assembly RH) NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 10
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
REPLACE REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S21345065772011092600000)
REPLACE MAIN BODY ECU (MULTIPLEX NETWORK BODY ECU). Refer to «REMOVAL»(ref-422214-S08215784352011092600000)

HINT

Scheme 149

Scheme 149: PROCEDURE

CHECK FOR DTC Clear the DTCs. Refer to «DTC CHECK / CLEAR»(ref-421963-S28431784692011092600000) . Check for DTCs. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . RESULT Result Proceed to DTC is not output A DTC B2311 is output B DTC B2312 is output C DTC B2313 is output D B --> See step 6 C --> See step 7 D --> See step 8 A: Go to next step
CHECK MANUAL UP/DOWN FUNCTION (POWER WINDOW REGULATOR SWITCH) Check that the manual up/down function using the front power window regulator switch can operate the front power window. Refer to «OPERATION CHECK»(ref-421963-S03630375062011092600000) . OK Front passenger side door power window moves. NG --> See step 9 OK: Go to next step
READ VALUE USING TECHSTREAM (POWER WINDOW REGULATOR SWITCH) Use the Data List to check if the front power window regulator is functioning properly. Refer to «DATA LIST / ACTIVE TEST»(ref-421963-S15539009672011092600000) . P-DOOR MOTOR Tester Display Measurement Item/Range Normal Condition Diagnostic Note P Door P/W Auto SW Front passenger side power window auto up/down signal / ON or OFF ON: Front passenger side power window auto up/down switch operated OFF: Front passenger side power window regulator switch not operated - OK On tester screen, item changes between ON and OFF according to above chart. NG --> See step 4 OK --> See step 11
INSPECT POWER WINDOW REGULATOR SWITCH ASSEMBLY Remove the power window regulator switch. Refer to «INSPECTION»(ref-422232-S26604393732011092600000) . Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Switch Condition Specified Condition 8 (AUTO) - 1 (GND) Auto up/down operation Below 1 ohms 8 (AUTO) - 1 (GND) Not operated 10 kohms or higher NG --> See step 10 OK: Go to next step
CHECK HARNESS AND CONNECTOR (POWER WINDOW REGULATOR SWITCH - FRONT POWER WINDOW REGULATOR MOTOR RH AND BODY GROUND) Disconnect the g1 power window regulator switch connector. Disconnect the H2 power window regulator motor connector. Measure the resistance according to the value(s) in the table below. Standard Resistance Tester Connection Condition Specified Condition g1-8 (AUTO) - H2-4 (AUTO) Always Below 1 ohms g1-1 (GND) - Body ground Always Below 1 ohms g1-8 (AUTO) - Body ground Always 10 kohms or higher NG --> REPAIR OR REPLACE HARNESS OR CONNECTOR OK --> See step 11
GO TO DTC B2311. Refer to «DTC B2311: Power Window Motor Malfunction»(ref-422264-S27131173762011092600000)
GO TO DTC B2312. Refer to «DTC B2312: Power Window Switch Malfunction»(ref-422264-S40206031852011092600000)
GO TO DTC B2313. Refer to «DTC B2313: Glass Position Initialization Incomplete»(ref-422264-S24359371612011092600000)
GO TO "Front Passenger Side Power Window does not Operate with Front Passenger Side Power Window Switch". Refer to «Front Passenger Side Power Window does not Operate with Front Passenger Side Power Window Switch»(ref-422264-S09890055682011092600000)
REPLACE POWER WINDOW REGULATOR SWITCH ASSEMBLY. Refer to «REMOVAL»(ref-422232-S30883843772011092600000)
REPLACE FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RH. Refer to «REMOVAL»(ref-422232-S15747782842011092600000)

HINT

Note. When a power window regulator motor is reinstalled or replaced, the power window control system must be initialized. After any door glass or a door glass run has been replaced, the jam protection function may operate unexpectedly when the auto up function is used. In such cases, the auto up function can be reinitialized by repeating the following operations at least 5 times: Close the power window by fully pulling up the multiplex network master switch or power window regulator switch and holding it at the auto up position. Open the power window by fully pushing down the multiplex network master switch or power window regulator switch.
