After dismounting
| WARNING | Be sure to keep transmission (and transfer if equipped) assembly horizontal throughout the work. Should they be tilted, torque converter may fall of and cause personal injury and A/T fluid may flow out. |
- Remove breather hoses.
- Remove transfer by removing its bolts, if equipped.
Remounting
| WARNING | When moving transmission assembly with torque converter equipped in it, be sure to keep it horizontal. tilting it with its front facing down may allow converter to fall off, whereby an injury may result. |
For remounting, reverse dismounting procedure noting the following points.
Scheme 184
- When remounting drive plate, use specified bolts.
- Use specified torque as given below. "A": Sealant 99000-31110 Tightening torque Transmission case right stiffener bolt (a): 50 N.m (5.0 kg-m, 36.5 lb-ft) Torque converter mounting bolt (b): 65 N.m (6.5 kg-m, 47.0 lb-ft) Transmission to engine bolt and nut (c): 85 N.m (8.5 kg-m, 61.5 lb-ft) Drive plate bolt (d): 78 N.m (7.8 kg-m, 56.5 lb-ft) Engine rear mounting bolt (e): 50 N.m (5.0 kg-m, 36.5 lb-ft) Engine rear mounting member bolt (e): 50 N.m (5.0 kg-m, 36.35 lb-ft) Exhaust No. 1 pipe to manifold bolt and nut: 50 N.m (5.0 kg-m, 36.5 lb-ft) Muffler to exhaust No. 2 pipe nut: 60 N.m (6.0 kg-m, 43.5 lb-ft) Universal joint flange bolt and nut: 50 N.m (5.0 kg-m, 36.5 lb-ft) Oil filler tube bolt: 23 N.m (2.3 kg-m, 17.0 lb-ft) Select cable bracket bolt: 23 N.m (2.3 kg-m, 17.0 lb-ft)
- Clamp wiring harness and hoses securely. See «SELECT CABLE»(ref-151958-S15932298712004050300000) .
- Tuning of A/T throttle cable. See «SOHC, DOHC»(ref-151958-S27610347262004043000000) .
- Follow fluid level check procedure for refilling automatic transmission fluid and its level adjusting.
- Connect battery, and confirm that engine and transmission function acceptably.
