Engine Cooling System: Overhaul Suzuki SX4 I рестайлинг

Radiator Cooling Fan Disassembly and Reassembly

Reference: RADIATOR COOLING FAN ASSEMBLY REMOVAL AND INSTALLATION

Scheme 17

1. Remove fan (1) from cooling fan motor (2).
2. Remove fan motor (2) from cooling fan guide (3).

Reassembly

Reverse disassembly procedures for reassembly.

Tightening torque

Fan nut (a): 6 N.m (0.61 kg-m, 4.5 lbf-ft)

Radiator cooling fan motor screw (b): 4 N.m (0.41 kg-m, 3.0 lbf-ft)

Scheme 18
