Starting System: Overhaul Suzuki SX4 I рестайлинг

Disassembly

Reference: STARTING MOTOR REMOVAL AND INSTALLATION

Reference: STARTING MOTOR COMPONENTS

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Before disassembly, draw alignment mark (1) and (2) for easy correct positioning on reassembly.
2. Remove nut (1) and disconnect lead wire (2) from magnetic switch (3).
3. Remove screws (4) and take out magnetic switch (1), and then disassemble spring (2) and plunger (3). NOTE: Do not disassemble magnetic switch. Replace it as assembly, if necessary.
4. Remove bolts (1), then separate yoke from starter housing (2).
5. Remove packing (2) and planetary gears (1).
6. Remove seal rubber (1) and plate (2).
7. Remove shaft assembly (1) with drive lever (2).
8. Draw pinion stop ring (3) toward over-running clutch side and remove snap ring (2) by using snap ring pliers (5), then pull out pinion stop ring (3), over-running clutch (4) and internal gear (1) from gear shaft.
9. Remove starter end frame (1), and then remove brush assembly (2) from yoke (3).
10. Remove armature (1) from yoke (2).
11. Remove brush springs (2) and brushes (1).

Scheme 22

Scheme 23

Scheme 24

Scheme 25

Scheme 26

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Install brush springs (2) and brushes (1) to brush holder (3).
2. Install armature to yoke.
3. Install brush assembly (1) to armature (2) while pushing 4 brushes (3) outward.
4. Install starter end frame (1) to brush holder. Tighten brush holder screws (2) to specified torque. Tightening torque Brush holder screw (a): 3.5 N.m (0.36 kg-m, 3.0 lbf-ft)
5. Before installing over-running clutch (2) and internal gear (3) to gear shaft (1), apply grease to shaft spline. "A": Grease 99000-25011 (SUZUKI Super Grease A)
6. Install internal gear and over-running clutch (1) to gear shaft (4) with new snap ring (3) noting the direction of pinion stop ring (2).
7. Apply grease to drive lever (2), insert shaft assembly (1) into starter housing with drive lever positioned as shown in the figure. "A": Grease 99000-25011 (SUZUKI Super Grease A)
8. Install packing (1) so that cuts in packing align with holes (3) for through bolts in starter housing.
9. Install plate (5) and seal rubber (4) to starter housing.
10. Apply grease to planetary gears (2), then Install planetary gears to gear shaft. "A": Grease 99000-25011 (SUZUKI Super Grease A)
11. Install yoke, armature, brush assembly and starter end frame (4) to starter housing (2) by aligning with alignment mark (3) provided before disassembly.
12. Tighten starter end frame bolts (1) to specified torque. Tightening torque End frame bolt (a): 6.0 N.m (0.61 kg-m, 4.5 lbf-ft)
13. Apply grease to plunger. "A": Grease 99000-25011 (SUZUKI Super Grease A)
14. Install magnetic switch (1), spring (2) and plunger (3) to starter housing (5) by aligning match marks provided before removal, and then tighten screws (4) to specified torque. Tightening torque Magnetic switch screw (a): 6.0 N.m (0.61 kg-m, 4.5 lbf-ft)
15. Connect lead wire (1) to terminal "M" (2), and then tighten lead wire nut to specified torque. Tightening torque Lead wire nut (a): 10 N.m (1.0 kg-m, 7.5 lbf-ft)
16. After completing assembly, check magnetic switch for operation.
