Engine Cooling System: Maintenance Suzuki SX4 I рестайлинг

Cooling System (Mechanical) 5 illustrations ~399 words

Cooling System Draining

WARNINGIf the radiator cap is removed when the engine and radiator are still hot, extremely hot fluid and steam may spew out under pressure. This can cause severe burns. Wait until the engine coolant temperature has lowered before removing the radiator cap.

Scheme 19

Scheme 19
Scheme 19
  1. Remove radiator cap, see «Radiator Cap Removal and Installation»(ref-514579-S32418569342012112100000) .
  2. Drain coolant from radiator drain plug (1).
  3. After draining coolant, be sure to tighten drain plug (1) securely.

Cooling System Flushing

Reference: COOLING SYSTEM DRAINING

Reference: COOLING SYSTEM REFILLING

WARNINGIf the radiator cap is removed when the engine and radiator are still hot, extremely hot fluid and steam may spew out under pressure. This can cause severe burns. Wait until the engine coolant temperature has lowered before removing the radiator cap.

Note. The cooling system filled with SUZUKI super long life coolant needs no flushing. For detail of coolant specification, refer to COOLANT DESCRIPTION .

Scheme 20

Scheme 20
Scheme 20

Scheme 21

Scheme 21
Scheme 21
  1. Remove radiator cap, see «Radiator Cap Removal and Installation»(ref-514579-S32418569342012112100000) .
  2. With radiator cap removed, run engine until upper radiator hose is hot. NOTE: Determine that thermostat is open and coolant is circulating in the cooling system.
  3. Stop engine and drain coolant from radiator drain plug (1).
  4. Tighten radiator drain plug. Fill system with water and run engine until upper radiator hose becomes hot again.
  5. Repeat Steps 3 ) and 4 ) several times until drained liquid is nearly colorless.
  6. Tighten radiator drain plug (1) tightly.
  7. Remove reservoir cap (2) and reservoir (1).
  8. Empty reservoir of fluid and scrub its inside using soap and water. Flush it well with clean water and drain, Reinstall reservoir.

Cooling System Refilling

Reference: COOLING SYSTEM FLUSHING

WARNINGIf the radiator cap is removed when the engine and radiator are still hot, extremely hot fluid and steam may spew out under pressure. This can cause severe burns. Wait until the engine coolant temperature has lowered before removing the radiator cap.

Note. SUZUKI super long life coolant as supply part is diluted to the 50 percentage with deionized water. Use it as it is without diluting.

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Fill reservoir (1) with coolant up to FULL mark (3).
  2. Install reservoir cap (2) on reservoir (1).
  3. Fill radiator with coolant up to bottom of radiator filler neck (1) and install radiator cap. Coolant specification Freezing temperature: -36 °C (-33 °F) Antifreeze/anti-corrosion coolant concentration: 50% Coolant capacity Engine, radiator and heater (M/T model): 6.4 liters (13.53/11.26 US/Imp pt.) Engine, radiator and heater (CVT model): 6.3 liters (13.31/11.09 US/Imp pt.) Reservoir: 0.7 liters (1.48/1.23 US/Imp pt.) Total (M/T model): 7.1 liters (15.00/12.49 US/Imp pt.) Total (CVT model): 7.0 liters (14.79/12.32 US/Imp pt.)
  4. Run engine at idle speed.
  5. Run engine until radiator fan motor is operated.
  6. Stop engine and wait until engine comes cooled down to avoid getting burned.
  7. Add coolant to radiator up to bottom of radiator filler neck, and install radiator cap. See «Radiator Cap Removal and Installation»(ref-514579-S32418569342012112100000) .
  8. Repeat Step 4 ) through 7 ).
  9. Confirm that coolant level in reservoir is at "FULL" level mark. If coolant is insufficient, add coolant.
  10. Check for coolant leaks, see «Engine Cooling System Inspection»(ref-514579-S25640199602012112100000) .
