DTC P1530: IGNITION TIMING ADJUSTMENT SWITCH CIRCUIT MALFUNCTION Suzuki Esteem I

Testing & Diagnostics 1 illustration ~126 words

Note. Ignition timing is not adjustable on Esteem or Swift.

Scheme 21

Scheme 21: DTC P1530: IGNITION TIMING ADJUSTMENT SWITCH CIRCUIT MALFUNCTION
Scheme 21: DTC P1530: IGNITION TIMING ADJUSTMENT SWITCH CIRCUIT MALFUNCTION
  1. Ensure test switch terminal of test connector (located in underhood relay/fuse block) is not grounded. (Scheme 21) If test switch terminal is grounded, remove jumper wire and retest system. If test switch terminal is not grounded, go to next step.
  2. Turn ignition on. Measure voltage between test connector terminals No. 4 (ground) and No. 5 (test switch terminal). If reading is 10-14 volts, problem is intermittent or due to a faulty PCM. Go to INTERMITTENTS in «TROUBLE SHOOTING - NO CODES»(ref-91186) article. If reading is not 10-14 volts, check Purple/White wire (Esteem) or Purple/Green wire (Swift) for short to ground. If wire is okay, replace PCM.
