EXTERIOR LAMP BATTERY SAVER CONTROL

With the lighting switch (combination switch) in the 2nd position and the ignition switch is turned from ON or ACC to OFF, the battery saver feature is activated.

Under this condition, the headlamps remain illuminated for 5 minutes unless the lighting switch position is changed. If the lighting switch position is changed, then the headlamps are turned OFF.

This setting can be changed by SDT. Refer to [ SDT FUNCTION (BCM - BATTERY SAVER) ].

OUTLINE

1. BCM reads the status of the combination switch (light, turn signal, wiper and washer) and recognizes the status of each switch.
2. BCM is a combination of 5 output terminals (OUTPUT 1 - 5) and 5 input terminals (INPUT 1 - 5). It reads a maximum of 20 switch status.

Scheme 128

Combination switch INPUT-OUTPUT system list

COMBINATION SWITCH SPECIFICATION

Note. Headlamp has a dual system switch.

Scheme 129

Scheme 130

1. BCM reads the status of the combination switch at 10ms interval normally. NOTE: BCM reads the status of the combination switch at 20ms interval when BCM is controlled at low power consumption control mode.
2. BCM operates as follows and judges the status of the combination switch. INPUT 1 - 5 outputs the voltage waveforms of 5 systems simultaneously. It operates the transistor on OUTPUT side in the following order: OUTPUT 5 --> 4 --> 3 --> 2 --> 1. The voltage waveform of INPUT corresponding to the formed circuit changes according to the operation of the transistor on OUTPUT side if any (1 or more) switches are ON. It reads this change of the voltage as the status signal of the combination switch.

1. Front room/map lamp and room lamp 2nd row are controlled by the interior room lamp timer control function of the BCM.
2. Cargo lamp is controlled by the cargo lamp control function of the BCM.

The timer control functions of the BCM activate based on inputs from the remote keyless entry receiver, the key cylinder lock/unlock switch, the door switches, the key switch and the power window and door lock/unlock switches.

INTERIOR LAMP BATTERY SAVER CONTROL

If an interior lamp is left ON and does not turn OFF even when the doors are closed, the BCM turns off power to the interior lamps automatically to save the battery 30 minutes after the ignition switch is turned OFF.

The BCM controls power and ground to all interior lamps.

After the battery saver system turns the lamps OFF, the lamps will illuminate again when

1. a signal is received from a main power window and door lock/unlock switch, or when the front door LH lock assembly (key cylinder switch) is locked or unlocked
2. a door is opened or closed

The interior lamp battery saver control time period can be changed with the function setting of SDT.

1. Front room/map lamp (if equipped) and room lamp 2nd row are powered by fuse block (J/B) fuse number 18 (10A). When the lamps are set to the DOOR position, ground is provided through the door switches.
2. Cargo lamp is controlled by the cargo lamp control function of the BCM.

BATTERY SAVER CONTROL

When the lighting switch (combination switch) is in the 1ST or 2ND position and the ignition switch is turned from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination lamps remain illuminated for 30 minutes unless the lighting switch position is changed. If the lighting switch position is changed, then the illumination lamps are turned off after a 30 second delay. When the lighting switch is turned from OFF to 1ST or 2ND position after illumination lamps have been turned off by the battery saver control, the illumination lamps illuminate again.

When the lighting switch (combination switch) is in the 1ST or 2ND position and the ignition switch is turned from ON or ACC to OFF, the battery saver control feature is activated. Under this condition, the illumination lamps remain illuminated for 30 minutes unless the lighting switch position is changed. If the lighting switch position is changed, then the illumination lamps are turned off after a 30 second delay. When the lighting switch is turned from OFF to 1ST or 2ND position after illumination lamps have been turned off by the battery saver control, the illumination lamps illuminate again.

DETAILED FLOW

DIAGNOSIS PROCEDURE CHART

Scheme 131

DIAGNOSIS PROCEDURE CHART

Scheme 132

DIAGNOSIS PROCEDURE CHART

SDT Function: (BCM - COMMON ITEM) [With Power Door Locks]

Refer to [ SDT FUNCTION (BCM - COMMON ITEM) ]

SDT Function: (BCM - COMMON ITEM) [Without Power Door Locks]

SDT can display each diagnostic item using the following diagnostic test modes.

PART DESCRIPTION

Utility

ITEM SETTING CHART

Data List

MONITOR ITEM DESCRIPTION

MONITOR ITEM DESCRIPTION

MONITOR ITEM DESCRIPTION

ITEM SETTING CHART

MONITOR ITEM DESCRIPTION

MONITOR ITEM DESCRIPTION

MONITOR ITEM DESCRIPTION

Monitor item

MONITOR ITEM DESCRIPTION

Power Supply and Ground Circuit Check [BCM]

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK FUSES AND FUSIBLE LINK Check that the following fuses and fusible link are not blown. Is the fuse blown? Replace the blown fuse or fusible link after repairing the affected circuit. GO TO 2 2 CHECK POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect BCM. 3. Check voltage between BCM harness connector and ground. Is the measurement value normal? GO TO 3 Repair or replace harness. 3 CHECK GROUND CIRCUIT Check continuity between BCM harness connector and ground. Does continuity exist? Inspection End. Repair or replace harness

Scheme 133

Scheme 134

Power Supply and Ground Circuit Check [IPDM E/R]

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK FUSIBLE LINKS Check that the following IPDM E/R fusible links are not blown. Is the fusible link blown? Replace the blown fusible link after repairing the affected circuit. GO TO 2 2 CHECK BATTERY POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect IPDM E/R. 3. Check voltage between IPDM E/R harness connectors and ground. Is there voltage on all pins? GO TO 3 Repair or replace harness. 3 CHECK GROUND CIRCUIT Turn ignition switch OFF. Check continuity between IPDM E/R harness connectors and ground. Does continuity exist? Inspection End. Repair or replace harness

Scheme 135

Scheme 136

Physical Values

WIRE COLOR REFERENCE Terminal Wire color Item Signal input/output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR Ignition keyhole illumination Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 P Combination switch input 5 Input ON Lighting, turn, wiper OFF Wiper dial position 4 3 SB Combination switch input 4 Input ON Lighting, turn, wiper OFF Wiper dial position 4 4 V Combination switch input 3 Input ON Lighting, turn, wiper OFF Wiper dial position 4 5 L Combination switch input 2 Input ON Lighting, turn, wiper OFF Wiper dial position 4 6 R Combination switch input 1 7 GR Front door lock assembly LH (key cylinder switch) unlock Input OFF ON (open, 2nd turn) Momentary 1.5V OFF (closed) 0V 8 SB Front door lock assembly LH (key cylinder switch) lock Input On (open) Momentary 1.5V OFF (closed) 0V 9 Y Rear window defogger switch Input ON Rear window defogger switch ON 0V Rear window defogger switch OFF 5V 11 G/B Ignition switch (ACC or ON) Input ACC or ON Ignition switch ACC or ON Battery voltage 12 LG Front door switch RH (All) Input OFF ON (open) 0V Rear door switch upper RH (King Cab) OFF (closed) Battery voltage Rear door switch lower RH (King Cab) 13 L Rear door switch RH (Crew Cab) Input OFF ON (open) 0V OFF (closed) Battery voltage 15 W Tire pressure warning check connector Input OFF - 5V 18 BR Remote keyless entry receiver (Ground) Output OFF - 0V 19 V Remote keyless entry receiver (power supply) Output OFF Ignition switch OFF 20 G Remote keyless entry receiver signal (Signal) Input OFF Stand-by (keyfob buttons released) When remote keyless entry receiver receives signal from keyfob (keyfob buttons pressed) 21 GR Immobilizer system antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move. 23 G Security indicator lamp Output OFF Goes OFF --> illuminates (Every 2.4 seconds) Battery voltage --> 0V 25 BR Immobilizer system antenna amp. Input OFF --> ON Ignition switch (OFF --> ON) Just after turning ignition switch ON: Pointer of tester should move. 27 W Compressor ON signal Input ON A/C switch OFF 5V A/C switch ON 0V 28 R Front blower monitor Input ON Front blower motor OFF Battery voltage Front blower motor ON 0V 29 G Hazard switch Input OFF ON 0V OFF 5V 31 GR Cargo lamp switch Input OFF ON 0V OFF Battery voltage 32 O Combination switch output 5 Output ON Lighting, turn, wiper OFF Wiper dial position 4 33 GR Combination switch output 4 Output ON Lighting, turn, wiper OFF Wiper dial position 4 34 G Combination switch output 3 Output ON Lighting, turn, wiper OFF Wiper dial position 4 35 BR Combination switch output 2 Output ON Lighting, turn, wiper OFF Wiper dial position 4 36 LG Combination switch output 1 37 B Key switch Input OFF Key inserted Battery voltage Key removed 0V 38 W/R Ignition switch (ON) Input ON - Battery voltage 39 L CAN-H - - - - 40 P CAN-L - - - - 45 V Lock switch Input OFF ON (lock) 0V OFF Battery voltage 46 LG Unlock switch Input OFF ON (unlock) 0V OFF Battery voltage 47 GR Front door switch LH (All) Input OFF ON (open) 0V Rear door switch upper LH (King Cab) OFF (closed) Battery voltage Rear door switch lower LH (King Cab) 48 P Rear door switch LH (Crew Cab) Input OFF ON (open) 0V OFF (closed) Battery voltage 50 P Cargo lamp Output OFF Any door open (ON) 0V All doors closed (OFF) Battery voltage 51 G Trailer turn signal (right) Output ON Turn right ON 52 V Trailer turn signal (left) Output ON Turn left ON 56 V Battery saver output Output OFF 30 minutes after ignition switch is turned OFF 0V ON - Battery voltage 57 R/Y Battery power supply Input - - Battery voltage 58 W Optical sensor Input ON When optical sensor is illuminated 3.1V or more When optical sensor is not illuminated 0.6V or less 59 GR Front door lock assembly LH (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 60 LG Turn signal (left) Output ON Turn left ON 61 G Turn signal (right) Output ON Turn right ON 63 BR Interior room/map lamp Output OFF Any door switch ON (open) 0V OFF (closed) Battery voltage 65 V All door lock actuators (lock) Output OFF OFF (neutral) 0V ON (lock) Battery voltage 66 L Front door lock actuator RH, rear door lock actuators LH/RH (unlock) Output OFF OFF (neutral) 0V ON (unlock) Battery voltage 67 B Ground Input ON - 0V 68 O Power window power supply (RAP) Output - Ignition switch ON Battery voltage Within 45 seconds after ignition switch OFF Battery voltage More than 45 seconds after ignition switch OFF 0V When front door LH or RH is open or power window timer operates 0V 69 P Power window power supply (BAT) Output OFF - Battery voltage 70 W Battery power supply Input OFF - Battery voltage

Scheme 137

Scheme 138

Scheme 139

Scheme 140

Scheme 141

Scheme 142

Scheme 143

Scheme 144

Scheme 145

Scheme 146

Scheme 147

Scheme 148

Scheme 149

Scheme 150

Fail-safe index

BCM performs fail-safe control when any DTC listed below is detected.

FAIL SAFE CHART

WIRE COLOR REFERENCE Terminal Wire color Signal name Signal input/output Measuring condition Reference value (Approx.) Ignition switch Operation or condition 1 W Battery power supply Input OFF - Battery voltage 2 R Battery power supply Input OFF - Battery voltage 3 G ECM relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 4 P ECM relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 6 V Throttle control motor relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 7 BR ECM relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 8 W/R Fuse 54 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 10 R/B Fuse 45 Output ON Daytime light system active 0V Daytime light system inactive Battery voltage 11 Y A/C compressor Output ON or START A/C switch ON or defrost A/C switch Battery voltage A/C switch OFF or defrost A/C switch 0V 12 W/G Ignition switch supplied power Input - OFF or ACC 0V ON or START Battery voltage 13 R Fuel pump relay Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 14 W/G Fuse 49 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 15 W/R Fuse 50 (ABS) Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 16 W/G Fuse 51 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 17 W/G Fuse 55 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 19 W Starter motor Output START - Battery voltage 20 BR Cooling fan motor (low) Output ON or START - Battery voltage 21 GR Ignition switch supplied power Input - OFF or ACC 0V START Battery voltage 22 G Battery power supply Output OFF - Battery voltage 23 LG Door mirror defogger output signal Output - When rear defogger switch is ON Battery voltage When raker defogger switch is OFF 0V 24 P Cooling fan motor (high) Output - Conditions correct for cooling fan operation Battery voltage Conditions not correct for cooling fan operation 0V 27 W Fuse 38 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 28 R LH front parking and front side marker lamp Output OFF Lighting switch 1st position OFF 0V ON Battery voltage 29 G Trailer tow relay Output ON Lighting switch 1st position OFF 0V ON Battery voltage 30 R/B Fuse 53 Output - Ignition switch ON or START Battery voltage Ignition switch OFF or ACC 0V 32 GR Wiper low speed signal Output ON or START Wiper switch OFF Battery voltage LO or INT 0V 35 L Wiper high speed signal Output ON or START Wiper switch OFF, LO, INT Battery voltage HI 0V 37 Y Power generation command signal Output - Ignition switch ON 40% is set on "Active test," "ALTERNATOR DUTY" of "Engine / Powertrain" 40% is set on "Active test," "ALTERNATOR DUTY" of "Engine / Powertrain" 38 B Ground Input - - 0V 39 L CAN-H - ON - - 40 P CAN-L - ON - - 42 GR Oil pressure switch Input - Engine running Battery voltage Engine stopped 0V 43 G Wiper auto stop signal Input ON or START Wiper switch OFF, LO, INT Battery voltage 44 R Daytime light relay control (Canada only) Input ON Daytime light system active 0V Daytime light system inactive Battery voltage 45 LG Horn relay control Input ON When door locks are operated using keyfob (OFF --> ON) (1) Battery voltage --> 0V 46 V Fuel pump relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 47 O Throttle control motor relay control Input - Ignition switch ON or START 0V Ignition switch OFF or ACC Battery voltage 48 R Starter relay (inhibit switch) Input ON or START Selector lever in "P" or "N" 0V Selector lever any other position Battery voltage 49 GR Front RH parking and front side marker lamp Output OFF Lighting switch 1st position OFF 0V ON Battery voltage 50 W Front fog lamp (LH) Output ON or START Lighting switch must be in the 2nd position (LOW beam is ON) and the front fog lamp switch OFF 0V ON Battery voltage 51 V Front fog lamp (RH) Output ON or START Lighting switch must be in the 2nd position (LOW beam is ON) and the front fog lamp switch OFF 0V ON Battery voltage 52 P LH low beam headlamp Output - Lighting switch in 2nd position Battery voltage 54 R RH low beam headlamp Output - Lighting switch in 2nd position Battery voltage 55 G LH high beam headlamp Output - Lighting switch in 2nd position and placed in HIGH or PASS position Battery voltage 56 L RH high beam headlamp Output - Lighting switch in 2nd position and placed in HIGH or PASS position Battery voltage 57 GR Parking, license, and tail lamp Output ON Lighting switch 1st position OFF 0V ON Battery voltage 59 B Ground Input - - 0V 60 GR Rear window defogger relay Output ON or START Rear defogger switch ON Battery voltage Rear defogger switch OFF 0V 61 R/B Fuse 32 Output OFF - Battery voltage (1) When horn reminder is ON

Scheme 151

Scheme 152

Scheme 153

CAN COMMUNICATION CONTROL

When CAN communication with ECM and BCM is impossible, IPDM E/R performs fail-safe control. After CAN communication recovers normally, it also returns to normal control.

If No CAN Communication Is Available With ECM

FAIL-SAFE OPERATION CHART

If No CAN Communication Is Available With BCM

FAIL-SAFE OPERATION CHART

IGNITION RELAY MALFUNCTION DETECTION FUNCTION

1. IPDM E/R monitors the voltage at the contact circuit and excitation coil circuit of the ignition relay inside it.
2. IPDM E/R judges the ignition relay error if the voltage differs between the contact circuit and the excitation coil circuit.
3. If the ignition relay cannot turn OFF due to contact seizure, it activates the tail lamp relay for 10 minutes to alert the user to the ignition relay malfunction when the ignition switch is turned OFF.

IGNITION SWITCH SPECIFICATION

Note. The tail lamp turns OFF when the ignition switch is turned ON.

FRONT WIPER CONTROL

IPDM E/R detects front wiper stop position by a front wiper auto stop signal.

When a front wiper auto stop signal is in the conditions listed below, IPDM E/R stops power supply to wiper after repeating a front wiper 10 second activation and 20 second stop five times.

IGNITION SWITCH SPECIFICATION

Note. This operation status can be confirmed on the IPDM E/R "Data list" that displays "Block" for the item "WIP PROT" while the wiper is stopped.

STARTER MOTOR PROTECTION FUNCTION

IPDM E/R turns OFF the starter control relay to protect the starter motor when the starter control relay remains active for 90 seconds.

Component Function Check

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

DIAGNOSIS PROCEDURE CHART

CREW CAB

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK DOOR SWITCHES Disconnect door switch. 2. Check continuity between door switch terminals. Is the inspection result normal? Inspection End Replace door switch

Scheme 154

Scheme 155

KING CAB

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK DOOR SWITCHES Disconnect door switch. 2. Check continuity between door switch terminals. Is the inspection result normal? Inspection End Replace door switch

Scheme 156

CARGO LAMP SWITCH

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK CARGO LAMP SWITCH Turn ignition switch OFF. 2. Disconnect cargo lamp switch connector. 3. Check continuity between cargo lamp switch terminals. Is the inspection result normal? Inspection End Replace cargo lamp switch

Scheme 157

Scheme 158

CARGO LAMP RELAY

DIAGNOSIS PROCEDURE CHART Step Action YES NO 1 CHECK CARGO LAMP RELAY Turn ignition switch OFF. 2. Disconnect cargo lamp relay connector. 3. Supply power to terminal 2 and ground to terminal 1 of the cargo lamp relay. 4. Check continuity between cargo lamp relay terminals 3 and 5. Is the inspection result normal? Inspection End Replace cargo lamp relay

Scheme 159

Scheme 160

DIAGNOSIS PROCEDURE CHART

AUTO LIGHT SYSTEM

The auto light system may not turn the headlamp ON/OFF immediately after passing a dark area or a bright area (short tunnel, sky bridge, shadowed area etc.). This is normal.

LOW BEAM AND HIGH BEAM

Note. By regulation, no means for horizontal aim adjustment is provided from the factory; only vertical aim is adjustable.

1. Turn headlamp low beam on.
2. Use adjustment screw to perform aiming adjustment.
3. Adjust beam pattern until cut-off line (top edge of illumination area) is positioned at same height off ground as bulb center (on H-line). Measure cut-off line within distance A on H-line. See «AIMING CHART»(ref-375715-S39302098952010102800000) below. Basic illuminating area for adjustment should be within the range shown on the aiming chart. Adjust headlamps accordingly.

Scheme 161

Aiming Chart

AIMING CHART

Headlamp

HEADLAMP SPECIFICATIONS

Exterior Lamp

EXTERIOR LAMP SPECIFICATION

Special Service Tool

Refer to [ SPECIAL SERVICE TOOL ].

Commercial Service Tool

Refer to [ COMMERCIAL SERVICE TOOL ].
