MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH
INPUT/OUTPUT SIGNAL CHART
| Item | Input signal to main power window and door lock/unlock switch | Main power window and door lock/unlock switch function | Actuator |
|---|---|---|---|
| Main power window and door lock/unlock switch | All power window motor UP/DOWN signal | Power window control | Power window motors |
| Power window and door lock/unlock switch RH | Front power window motor RH UP/DOWN signal | Front power window motor RH | |
| Rear power window switch (crew cab) | Rear power window motor UP/DOWN signal | Rear power window motor | |
| BCM | RAP signal |
INPUT/OUTPUT SIGNAL CHART
POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH
INPUT/OUTPUT SIGNAL CHART
| Item | Input signal to front power window switch | Front power window switch function | Actuator |
|---|---|---|---|
| Power window and door lock/unlock switch RH | Front power window motor RH UP/DOWN signal | Power window control | Front power window motor RH |
| BCM | RAP signal |
INPUT/OUTPUT SIGNAL CHART
POWER WINDOW LOCK
Ground circuit inside main power window and door lock/unlock switch shuts off when power window lock switch is ON. This inhibits power window switch operation except with the main power window and door lock/unlock switch.
FRONT WINDOW ANTI-PINCH SYSTEM
| Component | Function |
|---|---|
| BCM | Supplies power supply to power window switch. Controls retained power. |
| Main power window and door lock/unlock switch | Directly controls all power window motor of all doors. |
| Power window and door lock/unlock switch RH | Controls front power window motor RH. |
| Rear power window switch (crew cab) | Controls rear power window motors LH and RH. |
| Front power window motor LH | Starts operating with signals from main power window and door lock/unlock switch. |
| Front power window motor RH | Starts operating with signals from main power window and door lock/unlock switch & power window and door lock/unlock switch RH. |
| Rear power window motor (crew cab) | Starts operating with signals from main power window and door lock/unlock switch & rear power window switch. |
| Front door switch LH or RH | Detects door open/close condition and transmits to BCM. |
COMPONENT FUNCTION CHART
Timer function
- BCM turns rear window defogger relay and heated mirror relay (if equipped) ON for approximately 15 minutes when rear window defogger switch is turned ON while ignition switch is ON. It makes rear window defogger and door mirror defogger (if equipped) operate.
- Timer is canceled after pressing rear window defogger switch again during timer operation. Then BCM turns rear window defogger relay and heated mirror relay (if equipped) OFF. The same reaction also occurs during timer operation, if the ignition switch is turned OFF.
INPUT/OUTPUT SIGNAL CHART
| Switch | Input signal to BCM | BCM function | Actuator |
|---|---|---|---|
| Rear window defogger switch | Defogger switch signal | Rear window defogger & door mirror defogger (if equipped) control | Rear window defogger Door mirror defogger (if equipped) |
| Ignition switch | Ignition signal |
INPUT/OUTPUT SIGNAL CHART
CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diagnostic Worksheet during the interview to document the facts and conditions when the noise occurs and any customer's comments; refer to [ SQUEAK AND RATTLE TROUBLE DIAGNOSIS: DIAGNOSTIC WORKSHEET ]. This information is necessary to duplicate the conditions that exist when the noise occurs.
- The customer may not be able to provide a detailed description or the location of the noise. Attempt to obtain all the facts and conditions that exist when the noise occurs (or does not occur).
- If there is more than one noise in the vehicle, be sure to diagnose and repair the noise that the customer is concerned about. This can be accomplished by test driving the vehicle with the customer.
- After identifying the type of noise, isolate the noise in terms of its characteristics. The noise characteristics are provided so the customer, service adviser and technician are all speaking the same language when defining the noise.
- Squeak - (Like tennis shoes on a clean floor) Squeak characteristics include the light contact/fast movement/brought on by road conditions/hard surfaces = higher pitch noise/softer surfaces = lower pitch noises/edge to surface = chirping.
- Creak-(Like walking on an old wooden floor) Creak characteristics include firm contact/slow movement/twisting with a rotational movement/pitch dependent on materials/often brought on by activity.
- Rattle-(Like shaking a baby rattle) Rattle characteristics include the fast repeated contact/vibration or similar movement/loose parts/missing clip or fastener/incorrect clearance.
- Knock -(Like a knock on a door) Knock characteristics include hollow sounding/sometimes repeating/often brought on by driver action.
- Tick-(Like a clock second hand) Tick characteristics include gentle contacting of light materials/loose components/can be caused by driver action or road conditions.
- Thump-(Heavy, muffled knock noise) Thump characteristics include softer knock/dead sound often brought on by activity.
- Buzz-(Like a bumble bee) Buzz characteristics include high frequency rattle/firm contact.
- Often the degree of acceptable noise level will vary depending upon the person. A noise that you may judge as acceptable may be very irritating to the customer.
- Weather conditions, especially humidity and temperature, may have a great effect on noise level.
After verifying the customer concern or symptom, check ASIST for Technical Service Bulletins (TSBs) related to that concern or symptom.
If a TSB relates to the symptom, follow the procedure to repair the noise.
REPAIR THE CAUSE
- If the cause is a loose component, tighten the component securely.
- If the cause is insufficient clearance between components: separate components by repositioning or loosening and retightening the component, if possible. insulate components with a suitable insulator such as urethane pads, foam blocks, felt cloth tape or urethane tape. A Squeak and Rattle Kit (J-43980) is available.
| CAUTION | Do not use excessive force as many components are constructed of plastic and may be damaged. Always check with the Parts Department for the latest parts information. The following materials are contained in the Squeak and Rattle Kit (J-43980). Each item can be ordered separately as needed. URETHANE PADS [1.5 mm (0.059 in) thick] Insulates connectors, harness, etc. 100x135 mm (3.94x5.31 in)/60x85 mm (2.36x3.35 in)/15x25 mm (0.59x0.98 in) INSULATOR (Foam blocks) Insulates components from contact. Can be used to fill space behind a panel. 45 mm (1.77 in) thick, 50x50 mm (1.97x1.97 in)/10 mm (0.39 in) thick, 50x50 mm (1.97x1.97 in) INSULATOR (Light foam block) 30 mm (1.18 in) thick, 30x50 mm (1.18x1.97 in) FELT CLOTH TAPE Used to insulate where movement does not occur. Ideal for instrument panel applications. 15x25 mm (0.59x0.98 in) pad/5 mm (0.20 in) wide tape roll. The following materials not found in the kit can also be used to repair squeaks and rattles. UHMW (TEFLON) TAPE Insulates where slight movement is present. Ideal for instrument panel applications. SILICONE GREASE Used instead of UHMW tape that will be visible or not fit. |
Note. Will only last a few months. SILICONE SPRAY Use when grease cannot be applied. DUCT TAPE Use to eliminate movement.
CONFIRM THE REPAIR
Confirm that the cause of a noise is repaired by test driving the vehicle. Operate the vehicle under the same conditions as when the noise originally occurred. Refer to the notes on the Diagnostic Worksheet.
INSTRUMENT PANEL
Most incidents are caused by contact and movement between
- The cluster lid A and instrument panel
- Acrylic lens and combination meter housing
- Instrument panel to front pillar garnish
- Instrument panel to windshield
- Instrument panel mounting pins
- Wiring harnesses behind the combination meter
- A/C defroster duct and duct joint
These incidents can usually be located by tapping or moving the components to duplicate the noise or by pressing on the components while driving to stop the noise. Most of these incidents can be repaired by applying felt cloth tape or silicone spray (in hard to reach areas). Urethane pads can be used to insulate wiring harness.
| CAUTION | Do not use silicone spray to isolate a squeak or rattle. If you saturate the area with silicone, you will not be able to recheck the repair. |
CENTER CONSOLE
Components to pay attention to include
- Shifter assembly cover to finisher
- A/C control unit and cluster lid C
- Wiring harnesses behind audio and A/C control unit
The instrument panel repair and isolation procedures also apply to the center console.
DOORS
Pay attention to the
- Finisher and inner panel making a slapping noise
- Inside handle escutcheon to door finisher
- Wiring harnesses tapping
- Door striker out of alignment causing a popping noise on starts and stops
Tapping or moving the components or pressing on them while driving to duplicate the conditions can isolate many of these incidents. You can usually insulate the areas with felt cloth tape or insulator foam blocks from the Squeak and Rattle Kit (J-43980) to repair the noise.
TRUNK
Trunk noises are often caused by a loose jack or loose items put into the trunk by the owner.
In addition look for
- Trunk lid bumpers out of adjustment
- Trunk lid striker out of adjustment
- The trunk lid torsion bars knocking together
- A loose license plate or bracket
Most of these incidents can be repaired by adjusting, securing or insulating the item(s) or component(s) causing the noise.
SUNROOF/HEADLINING
Noises in the sunroof/headlining area can often be traced to one of the following
- Sunroof lid, rail, linkage or seals making a rattle or light knocking noise
- Sun visor shaft shaking in the holder
- Front or rear windshield touching headliner and squeaking
Again, pressing on the components to stop the noise while duplicating the conditions can isolate most of these incidents. Repairs usually consist of insulating with felt cloth tape.
OVERHEAD CONSOLE (FRONT AND REAR)
Overhead console noises are often caused by the console panel clips not being engaged correctly. Most of these incidents are repaired by pushing up on the console at the clip locations until the clips engage.
In addition look for
- Loose harness or harness connectors.
- Front console map/reading lamp lens loose.
- Loose screws at console attachment points.
SEATS
When isolating seat noise it's important to note the position the seat is in and the load placed on the seat when the noise is present. These conditions should be duplicated when verifying and isolating the cause of the noise.
Cause of seat noise include
- Headrest rods and holder
- A squeak between the seat pad cushion and frame
- The rear seatback lock and bracket
These noises can be isolated by moving or pressing on the suspected components while duplicating the conditions under which the noise occurs. Most of these incidents can be repaired by repositioning the component or applying urethane tape to the contact area.
UNDERHOOD
Some interior noise may be caused by components under the hood or on the engine wall. The noise is then transmitted into the passenger compartment.
Causes of transmitted underhood noise include
- Any component mounted to the engine wall
- Components that pass through the engine wall
- Engine wall mounts and connectors
- Loose radiator mounting pins
- Hood bumpers out of adjustment
- Hood striker out of adjustment
These noises can be difficult to isolate since they cannot be reached from the interior of the vehicle. The best method is to secure, move or insulate one component at a time and test drive the vehicle. Also, engine RPM or load can be changed to isolate the noise. Repairs can usually be made by moving, adjusting, securing, or insulating the component causing the noise.
Scheme 60
Scheme 61
DETAILED FLOW
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | OBTAIN INFORMATION ABOUT SYMPTOM Interview the customer to obtain the malfunction information (conditions and environment when the malfunction occurred) as much as possible when the customer brings the vehicle in. | GO TO 2 | |
| 2 | REPRODUCE THE MALFUNCTION INFORMATION Check the malfunction on the vehicle that the customer describes. Inspect the relation of the symptoms and the condition when the symptoms occur. | GO TO 3 | |
| 3 | IDENTIFY THE MALFUNCTIONING SYSTEM WITH "SYMPTOM DIAGNOSIS" Use "Symptom diagnosis" from the symptom inspection result in step 2 and then identify where to start performing the diagnosis based on possible causes and symptoms. | GO TO 4 | |
| 4 | IDENTIFY THE MALFUNCTIONING PARTS WITH "COMPONENT DIAGNOSIS" Perform the diagnosis with "Component diagnosis" of the applicable system. | GO TO 5 | |
| 5 | REPAIR OR REPLACE THE MALFUNCTIONING PARTS Repair or replace the specified malfunctioning parts. | GO TO 6 | |
| 6 | FINAL CHECK Check that malfunctions are not reproduced when obtaining the malfunction information from the customer, referring to the symptom inspection result in step 2. Are the malfunctions corrected? | Inspection End. | GO TO 3 |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | LISTEN TO CUSTOMER COMPLAINT Listen to customer complaint. Get detailed information about the conditions and environment when the symptom occurs. | GO TO 2 | |
| 2 | VERIFY THE SYMPTOM WITH OPERATIONAL CHECK Verify the symptom with operational check. | GO TO 3 | |
| 3 | GO TO APPROPRIATE TROUBLE DIAGNOSIS Go to appropriate trouble diagnosis. | GO TO 4 | |
| 4 | REPAIR OR REPLACE Repair or replace the specific parts. | GO TO 5 | |
| 5 | FINAL CHECK Final check. Is inspection result normal? | Inspection End | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
SDT Function (BCM - COMMON ITEM)
Refer to [ SDT FUNCTION (BCM - COMMON ITEM) ].
Data list
| Monitor Item [Unit] | Description |
|---|---|
| IGN ON SW [ON/OFF] | Indicates condition of ignition switch. |
| DOOR SW-DR [ON/OFF] | Indicates condition of front door switch LH. |
| DOOR SW-AS [ON/OFF] | Indicates condition of front door switch RH. |
MONITOR ITEM DESCRIPTION CHART
Utility
| Work item | Description |
|---|---|
| RETAINED PWR SET | RAP signal's power supply period can be changed by mode setting. Selects RAP signal's power supply period between three steps MODE1 (45 sec.)/MODE2 (OFF)/MODE 3 (2 min.). |
WORK ITEM DESCRIPTION CHART
| Monitor Item | Description |
|---|---|
| REAR DEF SW | Indicates [ON/OFF] condition of rear defogger switch. |
| IGN SW | Indicates [ON/OFF] condition of ignition switch. |
MONITOR ITEM DESCRIPTION CHART
Reference Value
Refer to "Reference Value" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Terminal Layout
Refer to "Terminal Layout" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Physical Values
Refer to "Physical Values" in ECU DIAGNOSIS: BCM (BODY CONTROL MODULE)
Fail Safe: BCM
Refer to FAIL SAFE: BCM ].
| Terminal | Wire Color | Item | Condition | Voltage (V) (Approx.) |
|---|---|---|---|---|
| 2 | G/Y | Front power window motor RH DOWN signal | When power window motor is operated DOWN | Battery voltage |
| 3 | L/W | Front power window motor RH UP signal | When power window motor is operated UP | Battery voltage |
| 5 | W/R | RAP signal | When ignition switch ON | Battery voltage |
| Within 45 seconds after ignition switch is turned to OFF | Battery voltage | |||
| More than 45 seconds after ignition switch is turned to OFF | 0 | |||
| When front door LH or RH open or power window timer operates | 0 | |||
| 6 | G/R | Front power window motor LH UP signal | When power window motor is operated UP | Battery voltage |
| 7 | G/W | Front power window motor LH DOWN signal | When power window motor is operated DOWN | Battery voltage |
| 8 (1) | G/B | Rear power window RH UP signal | When rear RH switch in main power window and door lock/unlock switch is operated UP | Battery voltage |
| 9 (1) | R | Rear power window RH DOWN signal | When rear RH switch in main power window and door lock/unlock switch is operated DOWN | Battery voltage |
| 14 | B | Ground | 0 | |
| 15 (1) | R/B | Rear power window LH UP signal | When rear LH switch in main power window and door lock/unlock switch is operated UP | Battery voltage |
| 16 (1) | R/Y | Rear power window LH DOWN signal | When rear LH switch in main power window and door lock/unlock switch is operated DOWN | Battery voltage |
| (1) Crew cab | ||||
| (1) | Crew cab |
TERMINAL VOLTAGE REFERENCE CHART
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Does power window motor operate with main power window and door lock/unlock switch operation? Is the inspection result normal? | Main power window and door lock/unlock switch power supply and ground circuit are OK. | Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (KING CAB)] ]. |
DIAGNOSIS PROCEDURE
Main Power Window And Door Lock/Unlock Switch Power Supply Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between main power window and door lock/unlock switch connector D7 terminal 5 and ground. 5 - Ground: Battery voltage Is the measurement value within the specification? GO TO 2 GO TO 3 2 CHECK GROUND CIRCUIT Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch. 3. Check continuity between main power window and door lock/unlock switch connector D7 terminal 14 and ground. Is the inspection result normal? GO TO 4 Repair or replace harness. 3 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect BCM and main power window and door lock/unlock switch. 3. Check continuity between BCM and main power window and door lock/unlock switch. 4. Check continuity between BCM and ground. Is the inspection result normal? Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. Repair or replace harness. 4 CHECK BCM OUTPUT SIGNAL Connect BCM. 2. Turn ignition switch ON. 3. Check voltage between BCM connector M20 terminal 68 and ground. 68 - Ground: Battery voltage Is the measurement value within the specification? GO TO 5 Replace BCM. Refer to [ BCM (BODY CONTROL MODULE): REMOVAL AND INSTALLATION ] 5 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (KING CAB)] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]
Scheme 62
Scheme 63
Scheme 64
Scheme 65
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH FUNCTION Does power window motor operate with main power window and door lock/unlock switch operation? Is the inspection result normal? | Main power window and door lock/unlock switch power supply and ground circuit are OK. | Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ]. |
DIAGNOSIS PROCEDURE
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between main power window and door lock/unlock switch connector D7 terminal 5 and ground. 5 - Ground: Battery voltage Is the measurement value within the specification? GO TO 2 GO TO 3 2 CHECK GROUND CIRCUIT Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch. 3. Check continuity between main power window and door lock/unlock switch connector D7 terminal 14 and ground. Is the inspection result normal? GO TO 4 Repair or replace harness. 3 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect BCM and main power window and door lock/unlock switch. 3. Check continuity between BCM and main power window and door lock/unlock switch. 4. Check continuity between BCM and ground. Is the inspection result normal? Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. Repair or replace harness. 4 CHECK BCM OUTPUT SIGNAL Connect BCM. 2. Turn ignition switch ON. 3. Check voltage between BCM connector M20 terminal 68 and ground. 68 Ground -: Battery voltage Is the measurement value within the specification? Check main power window and door lock/unlock switch output signal (rear power window switch LH) GO TO 5 Check main power window and door lock/unlock switch output signal (rear power window switch RH) GO TO 6 5 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL (REAR POWER WINDOW SWITCH LH) Turn ignition switch ON. 2. Check voltage between main power window and door lock/unlock switch connector and ground. Is the measurement value within the specification? GO TO 7 Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. 6 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL (REAR POWER WINDOW SWITCH RH) Turn ignition switch ON. 2. Check voltage between main power window and door lock/unlock switch connector and ground. Is the measurement value within the specification? GO TO 8 Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. 7 CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH) Turn ignition switch OFF. 2. Disconnect rear power window switch LH. 3. Check continuity between main power window and door lock/unlock switch connector and rear power window switch LH connector. 4. Check continuity between main power window and door lock/unlock switch connector and ground. Is the inspection result normal? GO TO 9 Repair or replace harness. 8 CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH RH) Turn ignition switch OFF. 2. Disconnect rear power window switch RH. 3. Check continuity between main power window and door lock/unlock switch connector and rear power window switch RH connector. 4. Check continuity between main power window and door lock/unlock switch connector and ground. Is the inspection result normal? GO TO 9 Repair or replace harness. 9 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]
Scheme 66
Scheme 67
Scheme 68
Scheme 69
Scheme 70
Scheme 71
Scheme 72
Scheme 73
Scheme 74
Scheme 75
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FRONT POWER WINDOW MOTOR RH FUNCTION Does front power window motor RH operate with power window and door lock/unlock switch RH operation? Is the inspection result normal? | Power window and door lock/unlock switch RH power supply and ground circuit are OK. | Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [FRONT POWER WINDOW SWITCH] ]. |
DIAGNOSIS PROCEDURE
Power Window And Door Lock/Unlock Switch RH Power Supply Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between power window and door lock/unlock switch RH connector and ground. Is the measurement value within the specification? GO TO 3 GO TO 2 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect BCM and power window and door lock/unlock switch RH. 3. Check continuity between BCM connector (A) and power window and door lock/unlock switch RH connector (B). 4. Check continuity between BCM connector (A) and ground. Is the inspection result normal? GO TO 4 Repair or replace harness. 3 CHECK GROUND CIRCUIT Turn ignition switch OFF. 2. Disconnect power window and door lock/unlock switch RH. 3. Check continuity between power window and door lock/unlock switch RH connector and ground. Is the inspection result normal? Replace power window and door lock/unlock switch RH. Refer to [ FRONT POWER WINDOW SWITCH: REMOVAL AND INSTALLATION ]. Repair or replace harness. 4 CHECK BCM OUTPUT SIGNAL Connect BCM. 2. Turn ignition switch ON. 3. Check voltage between BCM connector and ground. Is the measurement value within the specification? Replace power window and door lock/unlock switch RH. Refer to [ FRONT POWER WINDOW SWITCH: REMOVAL AND INSTALLATION ]. Replace BCM. Refer to [ BCM (BODY CONTROL MODULE): REMOVAL AND INSTALLATION ]
Scheme 76
Scheme 77
Scheme 78
Scheme 79
Scheme 80
Rear Power Window Switch
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR POWER WINDOW MOTOR FUNCTION Does rear power window motor operate with rear power window switch operation? Is the inspection result normal? | Rear power window switch power supply and ground circuit are OK. | Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. |
DIAGNOSIS PROCEDURE
Rear Power Window Switch Power Supply Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between rear power window switch connector and ground. Is the measurement value within the specification? GO TO 2 (Rear power window switch LH) GO TO 3 (Rear power window switch RH) 2 CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH LH) Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch and rear power window switch LH. 3. Check continuity between main power window and door lock/unlock switch connector (A) and rear power window switch LH connector (B). 4. Check continuity between main power window and door lock/unlock switch connector (A) and ground. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Repair or replace harness. 3 CHECK HARNESS CONTINUITY (REAR POWER WINDOW SWITCH RH) Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch and rear power window switch RH. 3. Check continuity between main power window and door lock/unlock switch connector (A) and rear power window switch RH connector (B). 4. Check continuity between main power window and door lock/unlock switch connector (A) and ground. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Repair or replace harness. 4 CHECK HARNESS CONTINUITY Disconnect BCM and rear power window switch. 2. Check continuity between BCM connector (A) and rear power window switch connector (B). 3. Check continuity between BCM connector (A) and ground. Is the inspection result normal? GO TO 5 Repair or replace harness. 5 CHECK REAR POWER WINDOW SWITCH Check rear power window switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace rear power window switch. Refer to [ REAR POWER WINDOW SWITCH: REMOVAL AND INSTALLATION - REAR DOOR SWITCH (IF EQUIPPED) ]
Scheme 81
Scheme 82
Scheme 83
Scheme 84
Scheme 85
Scheme 86
Scheme 87
Scheme 88
Component Function Check
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK POWER WINDOW MOTOR CIRCUIT Does front power window motor LH operate when operating main power window and door lock/unlock switch? Is the inspection result normal? | Front power window motor LH is OK. | Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [DRIVER SIDE] ]. |
DIAGNOSIS PROCEDURE
Front Power Window Motor LH Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH OUTPUT SIGNAL Disconnect front power window motor LH. 2. Turn ignition switch ON. 3. Check voltage between front power window motor LH connector and ground. Is the measurement value within the specification? GO TO 2 Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch. 3. Check continuity between main power window and door lock/unlock switch connector and front power window motor connector LH. 4. Check continuity between main power window and door lock/unlock switch connector (A) and ground. Is the inspection result normal? GO TO 3 Repair or replace harness. 3 CHECK POWER WINDOW MOTOR Check front power window motor LH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [DRIVER SIDE] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace power window motor LH. Refer to [ FRONT DOOR GLASS REGULATOR: ON-VEHICLE REPAIR ]
Scheme 89
Scheme 90
Scheme 91
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK POWER WINDOW MOTOR CIRCIUT Does power window motor operate when operating main power window and door lock/unlock switch or power window and door lock/unlock switch RH? Is the inspection result normal? | Front power window motor RH is OK. | Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [PASSENGER SIDE] ]. |
DIAGNOSIS PROCEDURE
Front Power Window Motor RH Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK FRONT POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect front power window motor RH. 2. Turn ignition switch ON. 3. Check voltage between front power window motor RH connector and ground. Is the measurement value within the specification? GO TO 2 Replace power window and door lock/unlock switch RH. Refer to [ FRONT POWER WINDOW SWITCH: REMOVAL AND INSTALLATION ]. 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect power window and door lock/unlock switch RH. 3. Check continuity between power window and door lock/unlock switch RH connector and front power window motor RH connector. 4. Check continuity between power window and door lock/unlock switch RH connector and ground. Is the inspection result normal? GO TO 3 Repair or replace harness. 3 CHECK FRONT POWER WINDOW MOTOR RH Check front power window motor RH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [PASSENGER SIDE] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace front power window motor RH. Refer to [ FRONT DOOR GLASS REGULATOR: ON-VEHICLE REPAIR ]
Scheme 92
Scheme 93
Scheme 94
Scheme 95
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR POWER WINDOW MOTOR LH CIRCUIT Does rear power window motor LH operate with main power window and door lock/unlock switch or rear power window switch LH? Is the inspection result normal? | Rear power window motor LH is OK. | Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR LH] ]. |
DIAGNOSIS PROCEDURE
Power Window Motor Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK REAR POWER WINDOW SWITCH OUTPUT SIGNAL Disconnect rear power window motor LH. 2. Turn ignition switch ON. 3. Check voltage between rear power window motor LH connector and ground. Is the measurement value within the specification? GO TO 2 Check rear power window switch LH. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect rear power window switch LH. 3. Check continuity between rear power window switch LH connector (A) and rear power window motor LH connector (B). 4. Check continuity between rear power window switch LH connector (A) and ground. Is the inspection result normal? GO TO 3 Repair or replace harness. 3 CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR LH] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace rear power window motor LH. Refer to [ REAR DOOR GLASS REGULATOR: ON-VEHICLE REPAIR ]
Scheme 96
Scheme 97
Scheme 98
Scheme 99
Scheme 100
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR POWER WINDOW MOTOR RH CIRCUIT Does rear power window motor RH operate with operating main power window and door lock/unlock switch or rear power window switch RH? Is the inspection result normal? | Rear power window motor RH is OK. | Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR RH] ]. |
DIAGNOSIS PROCEDURE
Rear Power Window Motor RH Circuit Check
DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK REAR POWER WINDOW SWITCH RH OUTPUT SIGNAL Disconnect rear power window motor RH. 2. Turn ignition switch ON. 3. Check voltage between rear power window motor RH connector and ground. Is the measurement value within the specification? GO TO 2 Check rear power window switch RH. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect rear power window switch RH. 3. Check continuity between rear power window switch RH connector (A) and rear power window motor RH connector (B). 4. Check continuity between rear power window switch RH connector (A) and ground. Is the inspection result normal? GO TO 3 Repair or replace harness. 3 CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR RH] ]. Is the inspection result normal? Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Replace rear power window motor RH. Refer to [ REAR DOOR GLASS REGULATOR: ON-VEHICLE REPAIR ]
Scheme 101
Scheme 102
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FUNCTION With SDT Check door switches in Data list mode with SDT. Is the inspection result normal? | Door switch is OK. | Refer to [ DOOR SWITCH CIRCUIT CHECK [KING CAB] ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FUNCTION With SDT Check door switches in Data list mode with SDT. Is the inspection result normal? | Door switch is OK. | Refer to [ DOOR SWITCH CIRCUIT CHECK [CREW CAB] ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK POWER WINDOW LOCK SIGNAL Exchanges for a normal main power window and door lock/unlock switch, and operation is checked. Does power window lock operate? | Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. | Check condition of harness and connector. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER SWITCH FUNCTION Check that the indicator lamp of rear window defogger illuminates with rear window defogger switch ON. Is the inspection result normal? | Rear window defogger switch function is OK. | Refer to [ REAR WINDOW DEFOGGER SWITCH CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER RELAY POWER SUPPLY CIRCUIT Check that an operation noise of rear window defogger relay (located in IPDM E/R) can be heard when turning the rear window defogger switch ON. Is the inspection result normal? | Rear window defogger relay power supply circuit is OK. | Refer to [ REAR WINDOW DEFOGGER RELAY CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER Check that the heating wire of rear window defogger is heated when turning the rear window defogger switch ON. Is the inspection result normal? | Rear window defogger is OK. | Refer to [ REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK DOOR MIRROR DEFOGGER LH Check that heating wire of door mirror defogger LH is heated when turning the rear window defogger switch ON. Is the inspection result normal? | Door mirror defogger is OK. | Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [LH] ]. |
DIAGNOSIS PROCEDURE
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK DOOR MIRROR DEFOGGER RH Check that the heating wire of door mirror defogger RH is heated when turning the rear window defogger switch ON. Is the inspection result normal? | Door mirror defogger RH is OK. | Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [RH] ]. |
DIAGNOSIS PROCEDURE
None of the Power Windows CAN Be Operated Using Any Switch
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK BCM POWER SUPPLY AND GROUND CIRCUIT Check BCM power supply and ground circuit. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK ]. Is the inspection result normal? | GO TO 2 | Repair or replace the malfunctioning parts. |
| 2 | CHECK MAIN POWER WINDOW AND DOORLOCK/UNLOCK SWITCH Check main power window switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ] or [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (KING CAB)] ]. Is the inspection result normal? | GO TO 3 | Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. |
| 3 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH POWER SUPPLY AND GROUND CIRCUIT Check power window switch main power supply and ground circuit. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ] or [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (KING CAB)] ]. Is the inspection result normal? | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Driver Side Power Window Alone Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK FRONT POWER WINDOW MOTOR LH Check front power window motor LH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [DRIVER SIDE] ]. Is the inspection result normal? | Inspection End. | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
Front Passenger Side Power Window Alone Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH Check power window and door lock/unlock switch RH. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [FRONT POWER WINDOW SWITCH] ]. Is the inspection result normal? | GO TO 2 | Repair or replace the malfunctioning parts. |
| 2 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ] or [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (KING CAB)] ]. Is the inspection result normal? | GO TO 3 | Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. |
| 3 | CHECK FRONT POWER WINDOW MOTOR RH CIRCUIT Check front power window motor RH circuit. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [PASSENGER SIDE] ]. Is the inspection result normal? | Inspection End. | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
Rear LH Side Power Window Alone Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR POWER WINDOW SWITCH LH Check rear power window switch LH. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. Is the inspection result normal? | GO TO 2 | Repair or replace the malfunctioning parts. |
| 2 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ]. Is the inspection result normal? | GO TO 3 | Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. |
| 3 | CHECK REAR POWER WINDOW MOTOR LH Check rear power window motor LH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR LH] ]. Is the inspection result normal? | Inspection End. | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
Rear RH Side Power Window Alone Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR POWER WINDOW SWITCH RH Check rear power window switch RH. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [REAR POWER WINDOW SWITCH] ]. Is the inspection result normal? | GO TO 2 | Repair or replace the malfunctioning parts. |
| 2 | CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check main power window and door lock/unlock switch. Refer to [ POWER SUPPLY AND GROUND CIRCUIT CHECK [POWER WINDOW MAIN SWITCH (CREW CAB)] ]. Is the inspection result normal? | GO TO 3 | Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. |
| 3 | CHECK REAR POWER WINDOW MOTOR RH Check rear power window motor RH. Refer to [ POWER WINDOW MOTOR CIRCUIT CHECK [REAR RH] ]. Is the inspection result normal? | Inspection End. | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
Power Window Lock Switch Does Not Function
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | REPLACE MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Replace main power window and door lock/unlock switch and check operation. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]. Is the inspection result normal? | Inspection End. | Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] |
DIAGNOSIS PROCEDURE
Rear Window Defogger and Door Mirror Defogger Do Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER SWITCH Check rear window defogger switch. Refer to [ REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT CHECK ]. Is the inspection result normal? | GO TO 2 | Repair or replace the malfunctioning parts. |
| 2 | CHECK REAR WINDOW DEFOGGER RELAY Check rear window defogger relay. Refer to [ REAR WINDOW DEFOGGER RELAY CIRCUIT CHECK ]. Is the inspection result normal? | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Rear Window Defogger Does Not Operate But Both of Door Mirror Defogger Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT Check rear window defogger power supply and ground circuit. Refer to [ REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT CHECK ]. Is the inspection result normal? | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Both Doors Mirror Defogger Don't Operate But Rear Window Defogger Operates
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Is the inspection result normal? | Check the following. Battery power supply circuit IPDM E/R | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Driver Side Door Mirror Defogger Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK DOOR MIRROR DEFOGGER LH Check door mirror defogger LH. Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [LH] ]. Is the inspection result normal? | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Passenger Side Door Mirror Defogger Does Not Operate
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK DOOR MIRROR DEFOGGER RH Check door mirror defogger RH. Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [RH] ]. Is the inspection result normal? | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Repair or replace the malfunctioning parts. |
DIAGNOSIS PROCEDURE
Rear Window Defogger Switch Does Not Light, But Rear Window Defogger Operates
| Step | Action | YES | NO |
|---|---|---|---|
| 1 | CHECK REAR WINDOW DEFOGGER SWITCH Check that the rear window defogger switch is operating normally. Is the inspection result normal? | Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] | Refer to [ REAR WINDOW DEFOGGER SWITCH CIRCUIT CHECK ]. |
DIAGNOSIS PROCEDURE
Repairing Water Leaks for Windshield
Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the windshield area while pushing glass outward. To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.
Repairing Water Leaks for Rear Window Glass
Leaks can be repaired without removing or reinstalling glass.
If water is leaking between urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the rear window area while pushing glass outward.
To stop leak, apply primer (if necessary) and then urethane adhesive to the leak point.
Scheme 103
Scheme 104
- Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
- Position the vapor barrier aside.
- Remove the window inside seal.
- If equipped, temporarily reconnect the power window switch.
- For power windows, operate the power window switch to raise/lower the door window until the glass bolts can be seen.
- For manual windows, temporarily reinstall the window crank handle and lower the window until the glass bolts can be seen.
- Remove the glass bolts.
- While holding the door window, raise it at the rear and pull the glass out of the sash toward the outside of the door.
Setting of Limit Switch
If any of the following work has been done, set the limit switch (integrated in the motor).
- Removal and installation of the regulator.
- Removal and installation of the motor from the regulator.
- Removal and installation of the glass.
- Removal and installation of the glass run.
Manual Mirror
- Remove the front door sash cover.
- Remove the nuts and the door mirror assembly.
Power Mirror
Note. Be careful not to damage the mirror bodies.
- Remove the front door sash cover.
- Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
- Disconnect the door mirror harness connector.
- Remove the nuts and the door mirror assembly.
REPAIR EQUIPMENT
- Conductive silver composition (DuPont No. 4817 or equivalent)
- Ruler 30 cm (11.8 in) long
- Drawing pen
- Heat gun
- Alcohol
- Cloth
Scheme 105
Scheme 106
Scheme 107
- Wipe broken heat wire and its surrounding area clean with a cloth dampened in alcohol.
- Apply a small amount of conductive silver composition to tip of drawing pen. Shake silver composition container before use.
- Place ruler on glass along broken line. Deposit conductive silver composition on break with drawing pen. Slightly overlap existing heat wire on both sides [preferably 5 mm (0.20 in)] of the break.
- After repair has been completed, check repaired wire for continuity. This check should be conducted 10 minutes after silver composition is deposited. Do not touch repaired area while test is being conducted.
- Apply a constant stream of hot air directly to the repaired area for approximately 20 minutes with a heat gun. A minimum distance of 3 cm (1.2 in) should be kept between repaired area and hot air outlet. If a heat gun is not available, let the repaired area dry for 24 hours.
Special Service Tool
Refer to [ SPECIAL SERVICE TOOL ].
Commercial Service Tool
Refer to [ COMMERCIAL SERVICE TOOL ].
