Glass/windows/mirrors: Diagnosis Suzuki Equator I

DUPLICATE THE NOISE AND TEST DRIVE

If possible, drive the vehicle with the customer until the noise is duplicated. Note any additional information on the Diagnostic Worksheet regarding the conditions or location of the noise. This information can be used to duplicate the same conditions when you confirm the repair.

If the noise can be duplicated easily during the test drive, to help identify the source of the noise, try to duplicate the noise with the vehicle stopped by doing one or all of the following

1. Close a door.
2. Tap or push/pull around the area where the noise appears to be coming from.
3. Rev the engine.
4. Use a floor jack to recreate vehicle "twist".
5. At idle, apply engine load (electrical load, half-clutch on M/T model, drive position on A/T model).
6. Raise the vehicle on a hoist and hit a tire with a rubber hammer.

1. Drive the vehicle and attempt to duplicate the conditions the customer states exist when the noise occurs.
2. If it is difficult to duplicate the noise, drive the vehicle slowly on an undulating or rough road to stress the vehicle body.

Generic Squeak and Rattle Troubleshooting

Refer to Table of Contents for specific component removal and installation information.

Active Test

TEST ITEM DESCRIPTION CHART

TEST ITEM DESCRIPTION CHART

DTC Inspection Priority Chart: BCM

Refer to [ DTC INSPECTION PRIORITY CHART: BCM ].

DTC Index: BCM

Refer to [ DTC INDEX: BCM ].

Scheme 6

Component Inspection

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Turn ignition switch OFF. 2. Disconnect main power window and door lock/unlock switch. 3. Check continuity between main power window and door lock/unlock switch terminals for front window RH. Is the inspection result normal? Main power window and door lock/unlock switch is OK. Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]

Scheme 7

Scheme 8

Diagnosis Procedure

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK MAIN POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH Check continuity between main power window and door lock/unlock switch terminals for front window RH. 2. Check continuity between main power window and door lock/unlock switch terminals for rear window LH. 3. Check continuity between main power window and door lock/unlock switch terminals for rear window RH. Is the inspection result normal? Main power window and door lock/unlock switch is OK. Replace main power window and door lock/unlock switch. Refer to [ POWER WINDOW MAIN SWITCH: REMOVAL AND INSTALLATION ]

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK DOOR SWITCHES INPUT SIGNAL With SDT Check door switches ("DOOR SW-DR", "DOOR SW-AS") in Data list mode with SDT. Refer to [ SDT FUNCTION (BCM - DOOR LOCK) ] When any doors are open: DOOR SW-DR: ON DOOR SW-AS: ON When any doors are closed: DOOR SW-DR: OFF DOOR SW-AS: OFF Without SDT Check voltage between BCM connector M18 or M19 terminals 12, 47 and ground. Is the inspection result normal? Door switch circuit is OK. GO TO 2 2 CHECK BCM OUTPUT VOLTAGE Turn ignition switch OFF. Disconnect door switches. Check voltage between BCM connector M18, M19 terminals 12, 47 and ground. 12 - Ground: Battery voltage 47 - Ground: Battery voltage Is the inspection result normal? GO TO 3 Replace BCM. Refer to [ BCM (BODY CONTROL MODULE): REMOVAL AND INSTALLATION ] 3 CHECK DOOR SWITCH CIRCUIT Disconnect BCM. Check continuity between door switch connector D213 (Front LH), D314 (Front RH) terminal 2, D211 (Rear upper LH), D312 (Rear upper RH), D212 (Rear lower LH), D313 (Rear lower RH) terminal 1 and BCM connector M18, M19 terminals 12, and 47. 2 - 47: Continuity should exist 2 - 12: Continuity should exist 1 - 47: Continuity should exist 1 - 12: Continuity should exist 3. Check continuity between door switch connector D213 (Front LH), D314 (Front RH) terminal 2, D211 (Rear upper LH), D312 (Rear upper RH), D212 (Rear lower LH), D313 (Rear lower RH) terminal 1 and ground. 2 - Ground: Continuity should not exist 1 - Ground: Continuity should not exist Is the inspection result normal? GO TO 4 Repair or replace harness. 4 CHECK DOOR SWITCHES GROUND CIRCUIT Check continuity between door switch connector D213 (Front LH), D314 (Front RH) terminal 3, D211 (Rear upper LH), D312 (Rear upper RH), D212 (Rear lower LH), D313 (Rear lower RH) terminal 2 and ground. 3 - Ground: Continuity should not exist 2 - Ground: Continuity should not exist Is the inspection result normal? GO TO 5 Repair or replace harness. 5 CHECK DOOR SWITCHES Check continuity between door switch terminals. Is the inspection result normal? Check condition of harness and connector. Replace door switch

Scheme 13

Scheme 14

Regarding Wiring Diagram information, refer to POWER WINDOW SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK DOOR SWITCHES INPUT SIGNAL With SDT Check door switches ("DOOR SW-DR", "DOOR SW-AS") in Data list mode with SDT. Refer to [ SDT FUNCTION (BCM - DOOR LOCK) ] When any doors are open: DOOR SW-DR: ON DOOR SW-AS: ON When any doors are closed: DOOR SW-DR: OFF DOOR SW-AS: OFF Without SDT Check voltage between BCM connector M18 or M19 terminals 12, 47 and ground. Is the inspection result normal? Door switch circuit is OK. GO TO 2 2 CHECK BCM OUTPUT VOLTAGE Turn ignition switch OFF. 2. Disconnect door switches. 3. Check voltage between BCM connector M18, M19 terminals 12, 47 and ground. 12 - Ground: Battery voltage 47 - Ground: Battery voltage Is the inspection result normal? GO TO 3 Replace BCM. Refer to [ BCM (BODY CONTROL MODULE): REMOVAL AND INSTALLATION ] 3 CHECK DOOR SWITCH CIRCUIT Disconnect door switch and BCM. 2. Check continuity between door switch connector B8 (Front LH), B108 (Front RH) terminal 2 and BCM connector M18, M19 terminals 12, and 47. 2 - 47: Continuity should exist. 2 - 12: Continuity should exist. 3. Check continuity between door switch connector B8 (Front LH), B108 (Front RH) terminal 2 and ground. 2 - Ground: Continuity should not exist. Is the inspection result normal? GO TO 4 Repair or replace harness. 4 CHECK DOOR SWITCHES Disconnect door switch. 2. Check continuity between door switch terminals. Is the inspection result normal? Check switch case ground condition. Replace door switch

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Diagnosis Procedure Front Air Control

Regarding Wiring Diagram information, refer to DEFOGGER CONTROL SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK FRONT AIR CONTROL (REAR WINDOW DEFOGGER SWITCH) CIRCUIT Does rear window defogger switch operate normally? Is the inspection result normal? Inspection End. GO TO 2 2 CHECK HARNESS CONTINUITY Turn ignition switch OFF. 2. Disconnect BCM and front air control. 3. Check continuity between BCM harness connector M18 (A) terminal 9 and front air control harness connector M50 (B) terminal 16. 4. Check continuity between BCM harnesses connector M18 (A) terminal 9 and ground. Is the inspection result normal? Replace front air control. Refer to [ CONTROL UNIT: REMOVAL AND INSTALLATION ] Repair or replace harness as necessary

Scheme 19

Regarding Wiring Diagram information, refer to DEFOGGER CONTROL SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK FUSES Check if any of the following fuses in the IPDM E/R are blown. Is the inspection result normal? GO TO 2 If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. 2 CHECK REAR WINDOW DEFOGGER RELAY POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between IPDM E/R harness connector E124 terminal 60 and ground. Is the inspection result normal? Replace IPDM E/R. Refer to [ IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM): REMOVAL AND INSTALLATION ] GO TO 3 3 CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Is the inspection result normal? Check the following. Battery power supply circuit IPDM E/R Repair or replace the malfunctioning parts

Scheme 20

Regarding Wiring Diagram information, refer to DEFOGGER CONTROL SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY CIRCUIT Turn ignition switch ON. 2. Check voltage between rear window defogger harness connector B165 terminal 1 and ground. Is the inspection result normal? GO TO 2 GO TO 3 2 CHECK GROUND CIRCUIT Turn ignition switch OFF. 2. Disconnect rear window defogger. 3. Check continuity between rear window defogger harness connector B210 terminal 2 and ground. Is the inspection result normal? GO TO 4 Repair or replace harness as necessary. 3 CHECK HARNESS CONTINUITY Disconnect IPDM E/R. 2. Check continuity between rear window defogger harness connector B165 (A) terminal 1 and IPDM E/R harness connector E124 (B) terminal 60. 3. Check continuity between rear window defogger harness connector B165 (A) terminal 1 and ground. Is the inspection result normal? GO TO 5 Replace or repair harness. 4 CHECK FILAMENT Check filament. Refer to [ REAR WINDOW DEFOGGER POWER SUPPLY AND GROUND CIRCUIT CHECK ]. Is the inspection result normal? Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Repair filament. Refer to [ FILAMENT REPAIR ]. 5 CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Is the inspection result normal? Check the following. Battery power supply circuit IPDM E/R Repair or replace the malfunctioning parts

Scheme 21

Scheme 22

Scheme 23

Scheme 24

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to DEFOGGER CONTROL SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY Check if the following fuse in the IPDM E/R is blown. Is the inspection result normal? GO TO 2 If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. 2 CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT Check voltage between IPDM E/R harness connector E120 terminal 23 and ground. Is the inspection result normal? GO TO 3 Replace IPDM E/R. Refer to [ IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM): REMOVAL AND INSTALLATION ] 3 CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect door mirror LH. 3. Turn ignition switch ON. 4. Check voltage between door mirror LH harness connector D4 terminal 1 and ground. Is the inspection result normal? GO TO 4 Repair or replace harness. 4 CHECK DOOR MIRROR DEFOGGER CIRCUIT Turn ignition switch OFF. 2. Disconnect IPDM E/R. 3. Check continuity between IPDM E/R harness connector E120 (A) terminal 23 and door mirror D4 (B) LH or D107 (B) RH terminal 1. 4. Check continuity between IPDM E/R harness connector E120 E120 terminal 23 and ground. Is the inspection result normal? GO TO 5. Repair or replace harness. 5 CHECK DOOR MIRROR DEFOGGER GROUND CIRCUIT Check continuity between door mirror LH harness connector D4 terminal 6 and ground. 6 - Ground: Continuity should exist. Is the inspection result normal? GO TO 6 Repair or replace harness. 6 CHECK DOOR MIRROR DEFOGGER LH Check door mirror defogger LH. Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [LH] ]. Is the inspection result normal? GO TO 7 Replace door mirror. Refer to [ DOOR MIRROR ASSEMBLY: REMOVAL AND INSTALLATION ]. 7 CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Is the inspection result normal? Check the following. Battery power supply circuit IPDM E/R Repair or replace the malfunctioning parts

Scheme 25

Scheme 26

Scheme 27

DIAGNOSIS PROCEDURE

Regarding Wiring Diagram information, refer to DEFOGGER CONTROL SYSTEM: WIRING DIAGRAM .

DIAGNOSIS PROCEDURE Step Action YES NO 1 CHECK POWER SUPPLY Check if the following fuse in the IPDM E/R is blown. Is the inspection result normal? GO TO 2 If fuse is blown, be sure to eliminate cause of malfunction before installing new fuse. 2 CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT Check voltage between IPDM E/R harness connector E120 terminal 23 and ground. Is the inspection result normal? GO TO 3 Replace IPDM E/R. Refer to [ IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM): REMOVAL AND INSTALLATION ] 3 CHECK DOOR MIRROR DEFOGGER POWER SUPPLY CIRCUIT Turn ignition switch OFF. 2. Disconnect door mirror RH. 3. Turn ignition switch ON. 4. Check voltage between door mirror RH harness connector D107 terminal 1 and ground. Is the inspection result normal? GO TO 4 Repair or replace harness as necessary. 4 CHECK DOOR MIRROR DEFOGGER CIRCUIT Turn ignition switch OFF. 2. Disconnect IPDM E/R. 3. Check continuity between IPDM E/R harness connector E120 (A) terminal 23 and door mirror harness connector D107 RH, or D4 LH (B) terminal 1. 4. Check continuity between IPDM E/R and ground. Is the inspection result normal? GO TO 5. Repair or replace harness as necessary. 5 CHECK DOOR MIRROR DEFOGGER GROUND CIRCUIT Check continuity between door mirror RH harness connector D107 terminal 6 and ground. 6 - Ground: Continuity should exist. Is the inspection result normal? GO TO 6 Repair or replace harness. 6 CHECK DOOR MIRROR DEFOGGER RH Check door mirror defogger RH. Refer to [ DOOR MIRROR DEFOGGER CIRCUIT CHECK [RH] ]. Is the inspection result normal? GO TO 7 Replace door mirror. Refer to [ DOOR MIRROR ASSEMBLY: REMOVAL AND INSTALLATION ]. 7 CHECK INTERMITTENT INCIDENT Check intermittent incident. Refer to [ SERVICE INFORMATION FOR ELECTRICAL INCIDENT: INTERMITTENT INCIDENT ] Is the inspection result normal? Check the following. Battery power supply circuit IPDM E/R Repair or replace the malfunctioning parts

Scheme 28

Scheme 29

Scheme 30

Scheme 31

DIAGNOSIS PROCEDURE

FITTING INSPECTION

1. Check that the glass fits securely into the glass run groove.
2. Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)] and check that the clearance to the sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts, guide rail bolts, and glass and guide rail bolts to adjust the glass position. Regulator and motor or manual crank assembly bolts: 5.7 N.m (0.58 kg-m, 50 in-lb) Glass bolts: 6.1 N.m (0.62 kg-m, 54 in-lb)

Scheme 32

Scheme 33

1. Remove the front door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
2. Position the vapor barrier aside.
3. If equipped, temporarily reconnect the power window switch.
4. For power windows, operate the power window switch to raise/lower the door window until the glass bolts can be seen.
5. For manual windows, temporarily reinstall the window crank handle and lower the window until the glass bolts can be seen.
6. Remove the glass bolts.
7. Raise the front door glass and hold it in place with suitable tool.
8. If equipped, disconnect the harness connector from the regulator assembly.
9. Remove the bolts and the regulator assembly. SEC.803

INSPECTION AFTER REMOVAL

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

1. Wire wear
2. Regulator deformation
3. Grease condition for each sliding part

1. Check that the glass fits securely into the glass run groove.
2. Lower the glass slightly [approximately 10 to 20 mm (0.39 to 0.79 in)], and check that the clearance to the sash is parallel. If the clearance between the glass and sash is not parallel, loosen the regulator bolts, guide rail bolts, and glass carrier plate bolts to adjust the glass position. Regulator and motor or manual crank assembly bolts: 7.5 N.m (0.77 kg-m, 66 in-lb) Glass bolts: 5.7 N.m (0.58 kg-m, 50 in-lb)

Scheme 34

1. Remove the rear door finisher. Refer to [ «DOOR FINISHER: REMOVAL AND INSTALLATION»(ref-375698-S35870222642010102800000) ]
2. Position aside the vapor barrier.
3. Remove the inside seal.
4. If equipped, temporarily reconnect the power window switch.
5. For power windows, operate the power window switch to raise/lower the door window until the glass bolts can be seen.
6. For manual windows, temporarily reinstall the window crank handle and lower the window until the glass bolts can be seen.
7. Raise the rear door glass and hold it in place with suitable tool.
8. Remove the bolts and the regulator assembly. If equipped, disconnect the connector from the regulator assembly.

SEC.823

Scheme 35

Check the regulator assembly for the following items. If a malfunction is detected, replace or grease it.

1. Gear wear
2. Regulator deformation
3. Spring damage
4. Grease condition for each sliding part
