Glass/windows/mirrors: Overview Suzuki Equator I

POWER WINDOW OPERATION

1. Power window system is operable during the retained power operation timer after turning ignition switch ON and OFF.
2. Main power window and door lock/unlock switch can open/close all windows.
3. Power window and door lock unlock switch RH & rear power window switches LH and RH (crew cab) can open/close the corresponding windows.

POWER WINDOW AUTO DOWN OPERATION (FRONT LH)

1. AUTO DOWN operation can be performed when main power window turns to AUTO.

RETAINED POWER OPERATION

1. Retained power operation is an additional power supply function that enables power window system to operate during the 45 seconds even when ignition switch is turned OFF

Retained power function cancel conditions

1. Front door CLOSE (door switch OFF)-->OPEN (door switch ON).
2. When ignition switch is ON.
3. When timer time passes. (45 seconds)

Operation Description

1. Turn rear window defogger switch ON when the ignition switch is turned ON. Then front air control transmits rear window defogger switch signal to BCM.
2. BCM transmits rear window defogger control signal to IPDM E/R via CAN communication when rear window defogger operates.
3. IPDM E/R turns rear window defogger relay and heated mirror relay (if equipped) ON when rear window defogger switch signal is received.
4. Rear window defogger and door mirror defogger (if equipped) are supplied with power and operate when rear window defogger relay and heated mirror relay (if equipped) turn ON.
5. Rear window defogger ON is displayed when signal is received.

Rear Window Defogger System: Component Description

REAR WINDOW DEFOGGER SYSTEM REFERENCE CHART

Scheme 1

Scheme 2

Scheme 3

Scheme 4

Scheme 5

Description

1. BCM supplies power.
2. It operates each power window motor via corresponding power window switch and makes window move up/down when main power window and door lock/unlock switch is operated.

1. BCM supplies power.
2. It operates each power window motor via corresponding power window switch and makes window move up/down when main power window and door lock/unlock switch is operated.

1. BCM supplies power.
2. Front power window motor RH will be operated if power window and door lock/unlock switch RH is operated.

1. BCM supplies power.
2. Rear power window motor will be operated if rear power window switch is operated.

Door glass moves UP/DOWN by receiving the signal from power window main switch.

Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or power window and door lock/unlock switch RH.

Door glass moves UP/DOWN by receiving the signal from power window main switch or rear power window switch LH.

Door glass moves UP/DOWN by receiving the signal from main power window and door lock/unlock switch or rear power window switch RH.

Detects door open/close condition.

Detects door open/close condition.

Ground circuit of main power window and door lock/unlock switch shuts off if power window lock switch of main power window and door lock/unlock switch is operated. This inhibits all operation, except for the main switch.

1. The rear window defogger is operated by turning the rear window defogger switch ON.
2. Turns the indicator lamp in the rear window defogger switch ON when operating the rear window defogger.

Power is supplied to the rear window defogger with BCM control.

Heats the heating wire with the power supply from the rear window defogger relay to prevent the rear window from fogging up.

Heats the heating wire with the power supply from the rear window defogger relay to prevent the door mirror from fogging up.

Heats the heating wire with the power supply from the rear window defogger relay to prevent the door mirror from fogging up.

Auto Operation Does Not Operate But Manual Operate Normally (Driver Side)

DIAGNOSIS PROCEDURE

Power Window Retained Power Operation Does Not Operate Properly

DIAGNOSIS PROCEDURE
