Engine Mechanical: Overview Suzuki Aerio I

Engine Construction Description

The engine is water-cooled, in line 4 cylinders, 4 stroke cycle gasoline unit with its DOHC (Double overhead camshaft) valve mechanism arranged for "V" type valve configuration consisting of 16 valves (4 valves/one cylinder). The double overhead camshaft is mounted over the cylinder head; it is driven from crankshaft through timing chains, and no push rods are provided in the valve train system.

Scheme 1

Air Cleaner Element Introduction

This air cleaner element is dry type. Remember that it needs cleaning according to Air Cleaner Element Inspection and Cleaning .

Main bearings general information

1. Service main bearings are available in standard size and 0.25 mm (0.0098 in.) undersize, and standard size has 5 kinds of bearings differing in tolerance.
2. Upper half of bearing (1) has oil groove (2) as shown in figure. Install this half with oil groove to cylinder block.
3. Lower half of bearing does not have oil groove.

Scheme 2
