Engine Mechanical: Adjustments Suzuki Aerio I

Mechanical 2 illustrations

Accelerator Cable Adjustment

With accelerator pedal depressed fully, check clearance between throttle lever (2) and lever stopper (1) (throttle body) which should be within the following specification.

Clearance between throttle lever and lever stopper (with pedal depressed fully) "b"

0.5 - 2.0 mm (0.02 - 0.07 in.)

If measured value is out of specification, adjust it to specification with cable adjusting nut (4).

Scheme 3

Scheme 3: Accelerator Cable Adjustment
Scheme 3: Accelerator Cable Adjustment

Scheme 4

Scheme 4: Throttle Body and Intake Manifold Components
Scheme 4: Throttle Body and Intake Manifold Components
