General Information (Except Wrx): Removal & Installation Subaru XV GP

FUSE INSTALLATION

Fuses for the back-up circuit on initially delivered vehicles are removed to prevent battery discharge. Attach the 20 A fuse as shown in the figure.

Scheme 27

Scheme 28

Scheme 29

Scheme 30

Scheme 31

1. Using the key, lock and unlock the door several times to check for normal operation. Open and close the door several times for smooth movement.
2. Completely close the driver's door, and then check the smooth movement with operating door lock knob from lock to unlock several times. Set the door lock knob (A) to lock position. Then pull the inner remote (B) to ensure that doors will not open. For other doors, place the door lock knob (A) to lock position and then pull the inner remote (B) to ensure that doors will not open.
3. Close all the doors, and then press the lock on power door lock switch at driver's side. Check that all doors (including the rear gate) lock.
4. Press the driver's side power door lock switch to unlock side. Check that all doors including rear gate are unlocked.
5. Check that the passenger's power door lock switch locks and unlocks normally in the same manner.
6. Insert the key to ignition switch, and open the driver's side door. Press lock on power door lock. Check that the door is not locked.

Scheme 32

1. Set the child safety lock lever on both rear doors to the lock position.
2. Close the rear doors completely.
3. Check that the lock levers of the rear doors are in the unlock position. Then, pull inner remote of rear doors to ensure that doors will not open.
4. Pull the outer handles to ensure that doors will open.

GROMMET INSTALLATION

Install the grommet provided on the rear seat to the tie-down hole. (When equipped)

Scheme 33

Scheme 34

1. Turn the ignition switch to ON and check that the malfunction indicator light starts blinking.
2. If the light blinks, return the ignition key to LOCK.
3. Remove the D check fuse.
4. Then, turn the ignition key to ON again.
5. Make sure that the malfunction indicator light is off. If the malfunction indicator light blinks, carry out an engine diagnosis.

REPLACEMENT

Refer to replacement section for engine oil replacement. < Refer to REPLACEMENT , Engine Oil. >

Refer to replacement section for engine oil filter replacement. < Refer to ENGINE OIL FILTER . >

Refer to replacement section for spark plug replacement. < Refer to SPARK PLUG . >

Refer to replacement section for V-belt replacement. < Refer to V-BELT . >

For fuel filter replacement procedure, refer to replacement section. < Refer to FUEL FILTER . >

Refer to replacement section for air cleaner element replacement. < Refer to AIR CLEANER ELEMENT . >

Refer to replacement section for engine coolant replacement. < Refer to REPLACEMENT , Engine Coolant. >

Refer to replacement section for transmission gear oil replacement. < Refer to REPLACEMENT , Transmission Gear Oil. >

Refer to replacement section for CVTF replacement. < Refer to REPLACEMENT , CVTF. >

Refer to replacement section for brake fluid replacement. < Refer to REPLACEMENT , Brake Fluid. >

Refer to "AC" section for A/C filter replacement. < Refer to REPLACEMENT , A/C Filter. >
