Lan Communication System (Diagnostics) (Except Wrx): Diagnosis

INSPECTION WITHOUT USING CAN DIAGNOSTIC

Before performing diagnostics, check the following item which might affect body integrated unit malfunctions.

Measure the battery voltage and check electrolyte. Standard voltage: 12 V or more Specific gravity: 1.260 or more
Check the fuse condition. Make sure that ampere of the fuse is setting value, and it is not blown out.
Check the connecting condition of harness and harness connector.
Confirm key illumination does not blink with ignition switch turned to ON.

INSPECTION USING CAN DIAGNOSTIC

Before performing diagnostics, check the following item which might affect body integrated unit malfunctions.

Confirm settings of body integrated unit are corresponded to vehicle equipment. < Refer to «OPERATION»(ref-560388-S01901385432013061300000) , Registration Body Integrated Unit. >
Make sure that the User Customizing of the body integrated unit matches the vehicle equipment. < Refer to «OPERATION»(ref-560388-S00094405942013061300000) , User Customizing. >
Confirm "Factory initial setting" of body integrated unit registrations is set to "Market".

DIAGNOSIS

Subaru Select Monitor communication line is open or shorted.

TROUBLE SYMPTOM

Not communicable with Subaru Select Monitor.

EXAMPLE OF DTC DATA NOT RECEIVED

When(4) (main wiring harness between combination meter and steering angle sensor) is open

Scheme 9

When (5) (main wiring harness between steering angle sensor and airbag CM) is open

Scheme 10

When (6) (main wiring harness between airbag CM and power steering CM) is open

Scheme 11

When (7) (ECM vicinity) is open

Note. If bus off occurs, ECM displays only the DTC that indicates bus off. However, other no-receive errors may occur depending on the judgment timing.

Scheme 12

When (12) (remote engine start CM vicinity) is open

Note. No DTC remains, and the remote engine starter does not function.

Scheme 13

When (13) (steering angle sensor vicinity) is open

Scheme 14

When (14) (TCM vicinity) is open

Scheme 15

When (15) (airbag CM vicinity) is open

Scheme 16

When (16) (power steering CM vicinity) is open

Note. Power steering CM may display U1120 (AUTO START STOP COMMUNICATION LOST).

Scheme 17

DTC MATRIX

Note. Perform the following procedure when using this chart in which the detailed trouble mode corresponds to the trouble status.

Search the trouble mode that corresponds to the vehicle status from the chart.
Perform the repair that corresponds to the trouble mode. Control module (which module vicinity) Trouble mode 1 Trouble mode 2 Trouble mode 3 Trouble mode 4 Trouble mode 5 ... ... Trouble mode n Detailed location (which location) Detailed trouble mode (What kind) Trouble status (trouble exists/trouble existed) DTC reading result from each module using Subaru Select Monitor VDC CM Vehicle status 1 Vehicle status 2 Vehicle status 3 Vehicle status 4 Vehicle status 5 ... ... Vehicle status n Body integrated unit Combination meter MFD A/C control panel TCM ... ... ECM Indicators illuminate/blink.

Hi-side circuit of CAN communication circuit is open. NOTE: If the module has a limit of DTC memory and the number of DTC occurrence exceeds the limit, older DTCs are preferentially stored. When there is no description in Current, it is referred to as "None". When DTC is in parentheses, it is referred to as "Not always occur". "Trouble exists" is referred to as the status before performing inspection and repair. "Trouble existed" is referred to as the status before performing DTC clear after repair. Control module VDC CM vicinity VDC CM vicinity Body integrated unit (VDC side) vicinity Body integrated unit (VDC side) vicinity Body integrated unit (EGI side) vicinity Body integrated unit (EGI side) vicinity Combination meter vicinity Combination meter vicinity Detailed location Hi side Hi side Hi side Hi side Hi side Hi side Hi side Hi side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Communication failure Current Current Current Current Current Current Current C1431 U0073 C1431 U0100 C1431 None None U0100 U0101 Past U0101 Past U0126 Past Past Past C1431 U0126 C1431 C1431 None None U0073 U0140 U0073 Past U0100 U0100 U0100 Same as above U0101 U0101 Past U0101 U0126 U0126 Same as above U0126 U0140 U0140 Body integrated unit (2) Current Past Communication failure Past Current Past Current Past U0122 U0122 U0122 U0100 U0100 U0155 U0155 U0101 U0101 Past U0155 U0155 Past Same as above U0164 U0164 Same as above U1201 U1201 Past Same as above Combination meter (3) Current Past Communication failure Past Communication failure Past Communication failure Past U0122 U0122 U0122 U0122 U0073 U0140 U0100 Past U0101 Same as above U0122 U0131 U0140 U0151 U0164 Any 5 item from above MFD (4) Current Current Communication failure Current Communication failure Past Current Current None None None U1650 None None Past Past Past Past Past None None None None None A/C control panel (5) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0155 U0155 Past Past Same as above Same as above TCM (1) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0155 U0155 Past Past Same as above Same as above A/B CM (6) Current Current Communication failure Current Communication failure Current Current Current None None None None None None Past Past Past Past Past Past None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current U0122 None U0122 U0122 U0122 U0122 None None Latest Latest Latest Latest Latest Latest Same as above U0122 Same as above Same as above None None ECM (1) Current Past Current Past Current Past Current Past P0700 P0700 P0700 P0700 U0122 U0122 U0155 U0155 U0122 U0122 U0122 U0122 Past Past Past Past Same as above Same as above Same as above Same as above Auto headlight beam leveler CM (6) Current Past Current Past Current Current Current Current U0122 U0122 U0140 U0140 None None None None Past Past Past Past Past Past Same as above Same as above None None None None Indicators illuminate/blink. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS, VDC off, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, A/B illuminate. CHECK ENGINE, VDC illuminate. CRUISE blink CRUISE blink CRUISE blink Below are the items that illuminate intermittently. (Cycles are erratic.) VDC Off, ABS, EMPTY, BRAKE CRUISE blink AT OIL TEMP, CRUISE blink. AT OIL TEMP, CRUISE blink. SPORTS illuminates. Headlight beam leveler indicator illuminates. Headlight beam leveler indicator illuminates. TPMS blinks --> illuminates. AT OIL TEMP, CRUISE blink. Below are the items that blink intermittently. Engine coolant temperature gauge (blue/red) blinks, AT OIL TEMP, CRUISE, Fuel gauge (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module MFD vicinity MFD vicinity A/C control panel vicinity A/C control panel vicinity Steering angle sensor vicinity Steering angle sensor vicinity AT CM vicinity AT CM vicinity Detailed location Hi side Hi side Hi side Hi side Hi side Hi side Hi side Hi side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Past Current Current None None None None U0126 U0126 U0101 C1431 Past Past Past Past Past Past Past None None None None Same as above Same as above C1431 U0101 Body integrated unit (2) Current None Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None Same as above None None Same as above Combination meter (3) Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None None None None Same as above MFD (4) Communication failure Past Current Current Current Current Current Current U1201 U0073 None None None None None None Past Past Past Past Past Past None None None None None None A/C control panel (5) Current Current Communication failure Past Current Current Current Past None None U0100 U0155 None None U0101 U0101 Past Past Past Past Past None None None None Same as above TCM (1) Current Current Current Current Current Current Communication failure Past None None None None None None U0100 U0122 Past Past Past Past Past Past U0140 None None None None None None U0155 A/B CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Electric power steering CM (7) Current Current Current Current Current Current Current Current None None None None None None None None Latest Latest Latest Latest Latest Latest Latest Latest None None None None None None None None ECM (1) Current Current Current Current Current Current Current Past None None None None None None U0101 U0101 Past Past Past Past Past Past Past None None None None None None Same as above Auto headlight beam leveler CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Indicators illuminate/blink. No change No change No change No change VDC, ABS illuminate. No change CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS illuminate. No change in MFD No change in MFD CRUISE blink Shift indicator goes off. CRUISE blink (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module A/B CM vicinity A/B CM vicinity Electric power steering CM vicinity Electric power steering CM vicinity ECM vicinity ECM vicinity Auto headlight beam leveler CM vicinity Auto headlight beam leveler CM vicinity Detailed location Hi side Hi side Hi side Hi side Hi side Hi side Hi side Hi side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Current Current Current None None None None C1431 U0100 C1431 None None Past Past Past Past Past Past Past None None None None Past C1431 None None Same as above U0100 Body integrated unit (2) Current Current Current Current Current Past Current Current None None None None U0100 (U1201) U0100 (U1201) Past Past Past Past Past Past None None None None Past Same as above None None Combination meter (3) Current Past Current Past Current Past Current Current U0151 U0151 U0131 U0131 U0100 (U0073) U0100 (U0073) None None Past Past Past Past Same as above Same as above Past Same as above MFD (4) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None A/C control panel (5) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None TCM (1) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None A/B CM (6) Communication failure Current Current Current Current Current Current Current None None None None None None None Past Past Past Past Past Past Past None None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current None None U1120 (9) U0122 C2543 C2543 None None U0122 C2543 U0073 U0073 Latest Latest C2543 (U1120 (9) ) None or any 1 item from above Past Past None None Any 1 item from above None None Latest Latest U0122 C2543 C2543 (U1120 (9) ) U0073 ECM (1) Current Current Current Current Current Past Current Current None None None None U0073 U0073 None None Past Past Past Past Past Past Past None None None None Same as above None None Auto headlight beam leveler CM (6) Current Current Current Current Current Current Communication failure Past None None None None None None U0122 U0140 Past Past Past Past Past Past None None None None None None Indicators illuminate/blink. A/B illuminates. No change No change No change VDC, ABS, CHECK ENGINE, EMPTY illuminate. CHECK ENGINE, VDC, ABS illuminate. Headlight beam leveler indicator illuminates. No change AT OIL TEMP blinks. Engine coolant temperature gauge (blue/red) blinks. Fuel gauge goes off. Tachometer: 0 rpm CRUISE blink (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) (9) When this code is displayed, perform the diagnosis as COMMUNICATION MALFUNCTION (METER ECU) (U0155). DTC that occurs in "Current" is displayed in top of the "Latest" list.
Lo-side circuit of CAN communication circuit is open. NOTE: If the module has a limit of DTC memory and the number of DTC occurrence exceeds the limit, older DTCs are preferentially stored. When there is no description in Current, it is referred to as "None". When DTC is in parentheses, it is referred to as "Not always occur". "Trouble exists" is referred to as the status before performing inspection and repair. "Trouble existed" is referred to as the status before performing DTC clear after repair. Control module VDC CM vicinity VDC CM vicinity Body integrated unit (VDC side) vicinity Body integrated unit (VDC side) vicinity Body integrated unit (EGI side) vicinity Body integrated unit (EGI side) vicinity Combination meter vicinity Combination meter vicinity Detailed location Lo side Lo side Lo side Lo side Lo side Lo side Lo side Lo side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Communication failure Current Current Current Current Current Current Current C1431 U0073 C1431 U0100 C1431 None None U0100 U0100 Past U0101 Past U0126 Past Past Past C1431 U0126 C1431 C1431 None None U0073 U0140 U0073 Past U0100 U0100 U0100 Same as above U0101 U0101 Past U0101 U0126 U0126 Same as above U0126 U0140 U0140 Body integrated unit (2) Current Past Communication failure Past Current Past Current Past U0122 U0122 U0122 U0100 U0100 U0155 U0155 U0101 U0101 Past U0155 U0155 Past Same as above U0164 (U1201) Past Same as above U0164 (U1201) Same as above Combination meter (3) Current Past Communication failure Past Communication failure Past Communication failure Past U0122 U0122 U0122 U0122 U0073 U0140 U0100 Past U0101 Same as above U0122 U0131 U0140 U0151 U0164 Any 5 item from above MFD (4) Current Current Communication failure Current Communication failure Past Current Past None None None U1650 (U1650) (U1201) (U1650) (U1201) Past Past Past Past None None None Same as above A/C control panel (5) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0140 U0155 U0155 Past Past Same as above Same as above TCM (1) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0140 U0155 U0155 Past Past Same as above Same as above A/B CM (6) Current Current Communication failure Current Communication failure Current Current Current None None None None None None Past Past Past Past Past Past None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current U0122 None U0122 U0122 U0122 U0122 (C2543) (C2544) Latest Latest Latest Latest Latest Latest Same as above U0122 Same as above Same as above Same as above (C2543) (C2544) ECM (1) Current Past Current Past Current Past Current Past P0700 P0700 P0700 P0700 U0122 U0122 U0155 U0155 U0122 U0122 U0122 U0122 Past Past Past Past Same as above Same as above Same as above Same as above Auto headlight beam leveler CM (6) Current Past Current Past Current Current Current Current U0122 U0122 U0140 U0140 None None None None Past Past Past Past Past Past Same as above Same as above None None None None Indicators illuminate/blink. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS, VDC off, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, A/B, BRAKE, VDC, EMPTY, VDC OFF, ABS illuminate. CHECK ENGINE, VDC illuminate. CRUISE blink CRUISE blink CRUISE blink CRUISE blink AT OIL TEMP, CRUISE blink. AT OIL TEMP, CRUISE blink. SPORTS illuminates. Engine coolant temperature gauge (blue/red) blinks. Headlight beam leveler indicator illuminates. Headlight beam leveler indicator illuminates. TPMS blinks --> illuminates. TPMS blinks --> illuminates. AT OIL TEMP, CRUISE blink. Shift indicator goes off. Fuel level warning indicator goes off. Tachometer: 0 rpm (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module MFD vicinity MFD vicinity A/C control panel vicinity A/C control panel vicinity Steering angle sensor vicinity Steering angle sensor vicinity AT CM vicinity AT CM vicinity Detailed location Lo side Lo side Lo side Lo side Lo side Lo side Lo side Lo side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Past Current Current None None None None U0126 U0126 U0101 C1431 Past Past Past Past Past Past Past None None None None Same as above Same as above C1431 U0101 Body integrated unit (2) Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None Same as above None None Same as above Combination meter (3) Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None None None None Same as above MFD (4) Communication failure Past Current Current Current Current Current Current U1201 U0073 None None None None None None Past Past Past Past Past Past None None None None None None A/C control panel (5) Current Current Communication failure Past Current Current Current Past None None U0100 U0155 None None U0101 U0101 Past Past Past Past Past None None None None Same as above TCM (1) Current Current Current Current Current Current Communication failure Past None None None None None None U0100 U0122 Past Past Past Past Past Past U0140 None None None None None None U0155 A/B CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Electric power steering CM (7) Current Current Current Current Current Current Current Current None None None None None None None None Latest Latest Latest Latest Latest Latest Latest Latest None None None None None None None None ECM (1) Current Current Current Current Current Current Current Past None None None None None None U0101 U0101 Past Past Past Past Past Past Past None None None None None None Same as above Auto headlight beam leveler CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Indicators illuminate/blink. No change No change No change No change VDC, ABS illuminate. No change CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS illuminate. No change in MFD No change in MFD CRUISE blink Shift indicator goes off. CRUISE blink (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module A/B CM vicinity A/B CM vicinity Electric power steering CM vicinity Electric power steering CM vicinity ECM vicinity ECM vicinity Auto headlight beam leveler CM vicinity Auto headlight beam leveler CM vicinity Detailed location Lo side Lo side Lo side Lo side Lo side Lo side Lo side Lo side Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Current Current Current None None None None C1431 U0100 C1431 None None Past Past Past Past Past Past Past None None None None Past C1431 U0100 None None Same as above Body integrated unit (2) Current Current Current Current Current Past Current Current None None None None U0100 (U1201) U0100 (U1201) None None Past Past Past Past Past Past None None None None Past None None Same as above Combination meter (3) Current Past Current Past Current Past Current Current U0151 U0151 U0131 U0131 U0100 (U0073) U0100 (U0073) None None Past Past Past Past Same as above Same as above Past None None Same as above MFD (4) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None A/C control panel (5) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None TCM (1) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None A/B CM (6) Communication failure Current Current Current Current Current Current Current None None None None None None None Past Past Past Past Past Past Past None None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current None None U1120 (9) U0122 C2543 C2543 None None U0122 C2543 U0073 U0073 Latest Latest C2543 (U1120 (9) ) None or any 1 item from above Past Past None None Any 1 item from above None None Latest Latest C2543 U0122 C2543 (U1120 (9) ) U0073 ECM (1) Current Current Current Current Current Past Current Current None None None None U0073 U0073 None None Past Past Past Past Past Past Past None None None None Same as above None None Auto headlight beam leveler CM (6) Current Current Current Current Current Current Communication failure Past None None None None None None U0122 U0140 Past Past Past Past Past Past None None None None None None Indicators illuminate/blink. A/B illuminates. No change No change No change VDC, ABS, CHECK ENGINE, EMPTY illuminate. CHECK ENGINE, VDC, ABS illuminate. Headlight beam leveler indicator illuminates. No change AT OIL TEMP blinks. CRUISE blink Engine coolant temperature gauge (blue/red) blinks. Fuel gauge goes off. Tachometer: 0 rpm (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) (9) When this code is displayed, perform the diagnosis as COMMUNICATION MALFUNCTION (METER ECU) (U0155). DTC that occurs in "Current" is displayed in top of the "Latest" list.
Hi/Lo-side circuit of CAN communication circuit is open. NOTE: If the module has a limit of DTC memory and the number of DTC occurrence exceeds the limit, older DTCs are preferentially stored. When there is no description in Current, it is referred to as "None". When DTC is in parentheses, it is referred to as "Not always occur". "Trouble exists" is referred to as the status before performing inspection and repair. "Trouble existed" is referred to as the status before performing DTC clear after repair. Control module VDC CM vicinity VDC CM vicinity Body integrated unit (VDC side) vicinity Body integrated unit (VDC side) vicinity Body integrated unit (EGI side) vicinity Body integrated unit (EGI side) vicinity Combination meter vicinity Combination meter vicinity Detailed location Both sides Both sides Both sides Both sides Both sides Both sides Both sides Both sides Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Communication failure Current Current Current Current Current Current Current C1431 U0073 C1431 U0100 C1431 None None U0100 U0101 Past U0101 Past U0126 Past Past Past C1431 U0126 C1431 C1431 None None U0073 U0140 U0073 Past U0100 U0100 U0100 Same as above U0101 U0101 Past U0101 U0126 U0126 Same as above U0126 U0140 U0140 Body integrated unit (2) Current Past Communication failure Past Current Past Current Past U0122 U0122 U0122 U0100 U0100 U0155 U0155 U0101 U0101 Past U0155 U0155 Past Same as above U0164 U0164 Same as above Past Same as above Combination meter (3) Current Past Communication failure Past Communication failure Past Communication failure Past U0122 U0122 U0122 U0122 U0073 U0140 U0100 Past U0101 Same as above U0122 U0131 U0140 U0151 U0164 Any 5 item from above MFD (4) Current Current Communication failure Current Communication failure Past Current Past None None None U1650 U1650 U1650 Past Past Past Past None None None Same as above A/C control panel (5) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0140 U0155 U0155 Past Past Same as above Same as above TCM (1) Current Past Communication failure Past Communication failure Past Current Past U0122 U0122 U0122 U0122 U0140 U0155 U0155 Past Past Same as above Same as above A/B CM (6) Current Current Communication failure Current Communication failure Current Current Current None None None None None None Past Past Past Past Past Past None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current U0122 None U0122 U0122 U0122 U0122 None None Latest Latest Latest Latest Latest Latest Same as above U0122 Same as above Same as above None None ECM (1) Current Past Current Past Current Past Current Past P0700 P0700 P0700 P0700 U0122 U0122 U0155 U0155 U0122 U0122 U0122 U0122 Past Past Past Past Same as above Same as above Same as above Same as above Auto headlight beam leveler CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Indicators illuminate/blink. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS, VDC off, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, VDC off, ABS, BRAKE illuminate. CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, A/B, BRAKE, VDC, EMPTY, VDC OFF, ABS illuminate. CHECK ENGINE, VDC illuminate. CRUISE blink CRUISE blink CRUISE blink CRUISE blink AT OIL TEMP, CRUISE blink. AT OIL TEMP, CRUISE blink. SPORTS illuminates. Engine coolant temperature gauge (blue/red) alternately blinks. Headlight beam leveler indicator illuminates. Headlight beam leveler indicator illuminates. TPMS blinks --> illuminates. AT OIL TEMP, CRUISE blink. TPMS blinks --> illuminates. Shift indicator goes off. Fuel level warning indicator goes off. Tachometer: 0 rpm (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module MFD vicinity MFD vicinity A/C control panel vicinity A/C control panel vicinity Steering angle sensor vicinity Steering angle sensor vicinity AT CM vicinity AT CM vicinity Detailed location Both sides Both sides Both sides Both sides Both sides Both sides Both sides Both sides Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Past Current Current None None None None U0126 U0126 U0101 U1431 Past Past Past Past Past Past Past None None None None Same as above Same as above C1431 U0101 Body integrated unit (2) Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None Same as above None None Same as above Combination meter (3) Current Current Current Past Current Current Current Past None None U0164 U0164 None None U0101 U0101 Past Past Past Past Past Past None None None None None Same as above MFD (4) Communication failure Past Current Current Current Current Current Current U1201 (U0073) None None None None None None Past Past Past Past Past Past None None None None None None A/C control panel (5) Current Current Communication failure Past Current Current Current Past None None U0100 U0155 None None U0100 U0100 Past Past Past Past Past None None None None Same as above TCM (1) Current Current Current Current Current Current Communication failure Past None None None None None None U0100 U0122 Past Past Past Past Past Past U0140 None None None None None None Same as above U0155 A/B CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Electric power steering CM (7) Current Current Current Current Current Current Current Current None None None None None None None None Latest Latest Latest Latest Latest Latest Latest Latest None None None None None None None None ECM (1) Current Current Current Current Current Current Current Past None None None None None None U0101 U0101 Past Past Past Past Past Past Past None None None None None None Same as above Auto headlight beam leveler CM (6) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None Indicators illuminate/blink. No change No change No change No change VDC, ABS illuminate. No change CHECK ENGINE, VDC, ABS illuminate. CHECK ENGINE, VDC, ABS illuminate. No change in MFD No change in MFD CRUISE blink Shift indicator goes off. CRUISE blink (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) Control module A/B CM vicinity A/B CM vicinity Electric power steering CM vicinity Electric power steering CM vicinity ECM vicinity ECM vicinity Auto headlight beam leveler CM vicinity Auto headlight beam leveler CM vicinity Detailed location Both sides Both sides Both sides Both sides Both sides Both sides Both sides Both sides Detailed trouble mode Open Open Open Open Open Open Open Open Trouble status Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed Trouble exists Trouble existed DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Current Current Current Current Current Current Current Current None None None None C1431 U0100 C1431 None None Past Past Past Past Past Past Past None None None None Past C1431 None None Same as above U0100 Body integrated unit (2) Current Current Current Current Current Past Current Current None None None None U0100 (U1201) U0100 (U1201) Past Past Past Past Past Past None None None None Past Same as above None None Combination meter (3) Current Past Current Past Current Past Current Current U0151 U0151 U0131 U0131 U0100 U0100 None None Past Past Past Past Past Same as above Same as above Same as above None None MFD (4) Current Current Current Current Current Current Current Current None None None None None None None None Past Past Past Past Past Past Past Past None None None None None None None None A/C control panel (5) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None TCM (1) Current Current Current Current Current Past Current Current None None None None U0100 U0100 None None Past Past Past Past Past Past Past None None None None Same as above None None A/B CM (6) Communication failure Current Current Current Current Current Current Current None None None None None None None Past Past Past Past Past Past Past None None None None None None None Electric power steering CM (7) Current Current Current Latest Current Latest Current Current None None U1120 (9) U0122 C2543 C2543 None None U0122 C2543 U0073 U0073 Latest Latest C2543 (U1120 (9) ) None or any 1 item from above Past Past None None Any 1 item from above None None Latest Latest U0122 C2543 C2543 (U1120 (9) ) U0073 ECM (1) Current Current Current Current Current Past Current Current None None None None U0073 U0073 None None Past Past Past Past Past Past Past None None None None Same as above None None Auto headlight beam leveler CM (6) Current Current Current Current Current Current Communication failure Past None None None None None None U0122 U0140 Past Past Past Past Past Past None None None None None None Indicators illuminate/blink. A/B illuminates. No change No change No change VDC, ABS, CHECK ENGINE, EMPTY illuminate. CHECK ENGINE, VDC, ABS illuminate. Headlight beam leveler indicator illuminates. No change AT OIL TEMP blinks. Engine coolant temperature gauge (blue/red) blinks. Fuel gauge goes off. Tachometer: 0 rpm CRUISE blink (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) (9) When this code is displayed, perform the diagnosis as COMMUNICATION MALFUNCTION (METER ECU) (U0155). DTC that occurs in "Current" is displayed in top of the "Latest" list.
Power supply-output short, GND-output short and short circuit in CAN communication circuit NOTE: If the module has a limit of DTC memory and the number of DTC occurrence exceeds the limit, older DTCs are preferentially stored. When there is no description in Current, it is referred to as "None". When DTC is in parentheses, it is referred to as "Not always occur". "Trouble exists" is referred to as the status before performing inspection and repair. "Trouble existed" is referred to as the status before performing DTC clear after repair. Control module (10) Option Option Option Option Option Option Option Option Detailed location Hi side Lo side Hi to Low Hi side Lo side Hi to Low Lo side Hi side Detailed trouble mode GND-output short Power supply-output short Short circuit GND-out-put short Power supply-output short Short circuit GND-out-put short (9) Power supply-output short (9) Trouble status Trouble exists <-- <-- Trouble existed <-- <-- Trouble exists/Trouble existed <-- DTC reading result from each module using Subaru Select Monitor VDC CM (1) (8) Communication failure <-- <-- Current <-- <-- Current <-- C1431 None None or 1 item from above Past U0073 C1431 (U0126) Body integrated unit (2) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None U0100 U0101 Past U0122 U0155 U0164 U1201 None Combination meter (3) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None U0100 U0101 Past U0122 None U0131 U0140 U0151 U0164 Any 5 item from above MFD (4) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None U1201 U1650 Past Any 1 to 2 items from above None A/C control panel (5) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None Past None TCM (1) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None U0100 U0122 Past U0140 None U0155 A/B CM (6) Communication failure <-- <-- Past <-- <-- Current <-- U0073 None Past None Electric power steering CM (7) Current <-- <-- Latest <-- <-- Current <-- U0073 U0073 None U0122 U0122 C2543 C2543 Latest Any 1 item from above None Latest All items above ECM (1) Current <-- <-- Past <-- <-- Current <-- U0073 U0073 None U0122 U0101 U0155 U0122 Past None or any 1 to 4 items from above U0155 None or any 1 to 4 items from above None Past Same as above Auto headlight beam leveler CM (6) Communication failure <-- <-- Past <-- <-- Current <-- U0140 None U0122 Past None Indicators illuminate/blink. CHECK ENGINE, A/B, BRAKE, VDC, EMPTY, VDC OFF, ABS illuminate. <-- <-- CHECK ENGINE, VDC, ABS illuminate. <-- <-- No change <-- CRUISE blink Headlight beam leveler indicator illuminates. Engine coolant temperature gauge (blue/red) alternately blinks. TPMS blinks --> illuminates. Shift indicator goes off. Fuel level warning indicator goes off. Tachometer: 0 rpm (1) When U0073 occurs, other U-codes are not stored. (Judge timing affects the storing order.) (2) The number of DTC memory is limited to 8 items. (Older items are preferentially stored.) (3) The number of DTC memory is limited to 5 items. (Older items are preferentially stored.) (4) The number of DTC memory is limited to 2 items. (Older items are preferentially stored.) (5) All types of DTCs can be simultaneously stored. When U0073 occurs, other U-codes are not displayed. (6) All types of DTCs can be simultaneously stored. (7) The number of DTC memory is limited to 1 item for Current and 3 items for Latest. (8) If C1431 contains a current malfunction after repair, perform IGN OFF --> ON. (It remains immediately after repair.) (9) This can only be detected by inspection using a tester. (10) In this trouble mode, a faulty portion can only be identified by inspection using a tester.

DTC DETECTING CONDITION

Communication is unstable because of high speed CAN communication error.

Display of combination meter indicates faulty.
Control faulty may occur due to CAN communication error.

DIAGNOSTIC PROCEDURE

Step	Check	Yes	No
1 CHECK CAN COMMUNICATION CIRCUIT. Check CAN communication circuit. < Refer to PROCEDURE , CAN Communication Circuit Check. >	Is CAN communication circuit faulty?	Repair the faulty portion, following the diagnosis procedure.	Go to step 2 .
2 CHECK DTC. Start the engine. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0073 a current malfunction?	Perform the diagnosis of U0073. < Refer to DTC U0073 CONTROL MODULE COMMUNICATION BUS "A" OFF , Diagnostic Procedure with Diagnostic Trouble Code (DTC). >	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U1201 a current malfunction?	Go to step 4 .	It is possible that temporary poor communication occurs. Perform the clear memory.
4 CHECK DTC. Turn the ignition switch to ON. Using the Subaru Select Monitor, read DTC of CAN system.	Is U1201 a current malfunction?	Go to step 5 .	It is possible that temporary poor communication occurs. Perform the clear memory.
5 CHECK CONTROL MODULE. Turn the ignition switch to OFF. Disconnect the control modules other than body integrated unit in order. NOTE: When disconnecting ECM or VDC CM, connect resistance of 120 ohms between CAN Hi and CAN Lo as an alternative of end resistance. Turn the ignition switch to ON. Using the Subaru Select Monitor, read DTC of CAN system.	Is there any control module that U1201 is not detected as current malfunction?	Replace the control module.	Repeat 1 ) to 4 ) in step 5 until U1201 is not detected.

NOTE
When disconnecting ECM or VDC CM, connect resistance of 120 ohms between CAN Hi and CAN Lo as an alternative of end resistance.

DIAGNOSTIC PROCEDURE

Integrated unit communication is shut down because of high speed CAN error.

CAN communication is not normal.

Step	Check	Yes	No
1 CHECK DTC. Start the engine. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0073 a current malfunction?	Go to step 2 .	It may be a temporary poor contact. Perform the clear memory.
2 CHECK CAN COMMUNICATION CIRCUIT. Check CAN communication circuit. < Refer to PROCEDURE , CAN Communication Circuit Check. >	Is CAN communication circuit faulty?	Repair the faulty portion, following the diagnosis procedure.	Go to step 3 .
3 CHECK DTC. Perform the inspection using the DTC check sheet. < Refer to CHECK USING THE DTC CHECK SHEET , LIST, List of Diagnostic Trouble Code (DTC). > Using the Subaru Select Monitor, read DTC of CAN system.	Is U0073 a current malfunction?	Go to step 4 .	System is normal.
4 CHECK CONTROL MODULE. Turn the ignition switch to OFF. Disconnect the control modules other than body integrated unit in order. NOTE: When disconnecting ECM or VDC CM, connect resistance of 120 ohms between CAN Hi and CAN Lo as an alternative of end resistance. Turn the ignition switch to ON. Using the Subaru Select Monitor, read DTC of CAN system.	Is there any control module that U0073 is not detected as current malfunction?	Replace the control module.	Repeat 1) to 4) in step 3 until U0073 is not detected.

NOTE
When disconnecting ECM or VDC CM, connect resistance of 120 ohms between CAN Hi and CAN Lo as an alternative of end resistance.

DIAGNOSTIC PROCEDURE

Defective data from ECM.

Defective data on CAN communication occurs.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0401 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the ECM connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0401 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the engine data abnormal detected in several modules?	Replace the ECM. < Refer to ENGINE CONTROL MODULE (ECM) . >	Go to step 6 .
6 REPLACE MODULE. Replace the ECM. Read the DTC using Subaru Select Monitor.	Is U0401 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the ECM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0401 a current malfunction?	Replace the ECM. < Refer to ENGINE CONTROL MODULE (ECM) . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0401 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Received error data from TCM.

SPORT indicator light blinks.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0402 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the TCM connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0402 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the transmission data abnormal detected in several modules?	Replace the TCM. < Refer to TRANSMISSION CONTROL MODULE (TCM) . >	Go to step 6 .
6 REPLACE MODULE. Replace the TCM. Read the DTC using Subaru Select Monitor.	Is U0402 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the TCM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0402 a current malfunction?	Replace the TCM. < Refer to TRANSMISSION CONTROL MODULE (TCM) . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0402 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Data from VDCCM is faulty.

ABS warning light and VDC warning light illuminate.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0416 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the VDC CM connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0416 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the VDC data abnormal detected in several modules?	Replace the VDC CM. < Refer to VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U) . >	Go to step 6 .
6 REPLACE MODULE. Replace the VDC CM. Read the DTC using Subaru Select Monitor.	Is U0416 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the VDC CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0416 a current malfunction?	Replace the VDC CM. < Refer to VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U) . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0416 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from EPS CM.

Cooperation control with EPS CM does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0420 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the power steering CM connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0420 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the electric power steering data abnormal detected in several modules?	Replace the power steering CM. < Refer to POWER STEERING CONTROL MODULE . >	Go to step 6 .
6 REPLACE MODULE. Replace the power steering CM. Read the DTC using Subaru Select Monitor.	Is U0420 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the power steering CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0420 a current malfunction?	Replace the power steering CM. < Refer to POWER STEERING CONTROL MODULE . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0420 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from body integrated unit.

Cooperation control with body integrated unit does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0422 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the body integrated unit connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0422 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the body integrated data abnormal detected in several modules?	Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >	Go to step 6 .
6 REPLACE MODULE. Replace the body integrated unit. Read the DTC using Subaru Select Monitor.	Is U0422 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the body integrated unit. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0422 a current malfunction?	Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0422 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from combination meter.

Display of combination meter does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0423 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the combination meter connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0423 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the meter data abnormal detected in several modules?	Replace the combination meter. < Refer to COMBINATION METER . >	Go to step 6 .
6 REPLACE MODULE. Replace the combination meter. Read the DTC using Subaru Select Monitor.	Is U0423 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Replace the current combination meter with the original combination meter. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0423 a current malfunction?	Replace the combination meter. < Refer to COMBINATION METER . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0423 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from A/C control panel.

Cooperation control of air conditioner does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0424 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the A/C control panel connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0424 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the air conditioner data abnormal detected in several modules?	Replace the A/C control panel.	Go to step 6 .
6 REPLACE MODULE. Replace the A/C control panel. Read the DTC using Subaru Select Monitor.	Is U0424 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Restore the A/C control panel. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0424 a current malfunction?	Replace the A/C control panel.	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0424 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from steering angle sensor.

VDC CM does not operate normally.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0428 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the steering angle sensor connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0428 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the steering angle sensor data abnormal detected in several modules?	Replace the steering angle sensor. < Refer to STEERING ANGLE SENSOR . >	Go to step 6 .
6 REPLACE MODULE. Replace the steering angle sensor. Read the DTC using Subaru Select Monitor.	Is U0428 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the steering angle sensor. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0428 a current malfunction?	Replace the steering angle sensor. < Refer to STEERING ANGLE SENSOR . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0428 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Defective data was transmitted from A/B CM.

Cooperation control with airbag does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is DTC for the buss off or the data no-receive displayed?	Perform the diagnosis according to DTC.	Go to step 3 .
3 CHECK DTC. Check the displayed DTC.	Is U0452 a current malfunction?	Go to step 4 .	Go to step 8 .
4 CHECK DTC. Turn the ignition switch to OFF. Disconnect the A/B CM connector. Connect the disconnected connectors. Read the DTC using Subaru Select Monitor.	Is U0452 a current malfunction?	Go to step 5 .	Go to step 8 .
5 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the airbag data abnormal detected in several modules?	Replace the A/B CM. < Refer to AIRBAG CONTROL MODULE . >	Go to step 6 .
6 REPLACE MODULE. Replace the A/B CM. Read the DTC using Subaru Select Monitor.	Is U0452 a current malfunction?	Go to step 7 .	System is normal.
7 CHECK MODULE. Reinstall the A/B CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0452 a current malfunction?	Replace the A/B CM. < Refer to AIRBAG CONTROL MODULE . >	System is normal.
8 CHECK HARNESS. Shake the harness, and check for poor contact. Using the Subaru Select Monitor, read DTC of CAN system.	Is U0452 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 9 .
9 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Not received data from ECM.

Cooperation control of transmission may not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0100 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0100 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the engine data no-receive detected in several modules?	Replace the ECM. < Refer to ENGINE CONTROL MODULE (ECM) . >	Go to step 5 .
5 REPLACE MODULE. Replace the ECM. Read the DTC using Subaru Select Monitor.	Is U0100 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the ECM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0100 a current malfunction?	Replace the ECM. < Refer to ENGINE CONTROL MODULE (ECM) . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0100 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

Not received data from TCM.

Cooperation control with transmission is not performed.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0101 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0101 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the transmission data no-receive detected in several modules?	Replace the TCM. < Refer to TRANSMISSION CONTROL MODULE (TCM) . >	Go to step 5 .
5 REPLACE MODULE. Replace the TCM. Read the DTC using Subaru Select Monitor.	Is U0101 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the TCM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0101 a current malfunction?	Replace the TCM. < Refer to TRANSMISSION CONTROL MODULE (TCM) . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0101 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data from VDCCM is received.

ABS warning light and VDC warning light illuminate.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0122 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit in the wiring diagram. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0122 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the VDC data no-receive detected in several modules?	Replace the VDC CM. < Refer to VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U) . >	Go to step 5 .
5 REPLACE MODULE. Replace the VDC CM. Read the DTC using Subaru Select Monitor.	Is U0122 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the VDC CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0122 a current malfunction?	Replace the VDC CM. < Refer to VDC CONTROL MODULE AND HYDRAULIC CONTROL UNIT (VDCCM&H/U) . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0122 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data is received from steering angle sensor.

VDC CM does not operate normally.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0126 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0126 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the steering angle sensor data no-receive detected in several modules?	Replace the steering angle sensor. < Refer to STEERING ANGLE SENSOR . >	Go to step 5 .
5 REPLACE MODULE. Replace the steering angle sensor. Read the DTC using Subaru Select Monitor.	Is U0126 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the steering angle sensor. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0126 a current malfunction?	Replace the steering angle sensor. < Refer to STEERING ANGLE SENSOR . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0126 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data is received from power steering CM.

Cooperation control with power steering CM does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0131 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0131 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the electric power steering data no-receive detected in several modules?	Replace the power steering CM. < Refer to POWER STEERING CONTROL MODULE . >	Go to step 5 .
5 REPLACE MODULE. Replace the power steering CM. Read the DTC using Subaru Select Monitor.	Is U0131 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the power steering CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0131 a current malfunction?	Replace the power steering CM. < Refer to POWER STEERING CONTROL MODULE . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0131 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data is received from body integrated unit.

Cooperation control with body integrated unit does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0140 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0140 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the body integrated data no-receive detected in several modules?	Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >	Go to step 5 .
5 REPLACE MODULE. Replace the body integrated unit. Read the DTC using Subaru Select Monitor.	Is U0140 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the body integrated unit. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0140 a current malfunction?	Replace the body integrated unit. < Refer to BODY INTEGRATED UNIT . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0140 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data is received from A/B CM.

Cooperation control with A/B CM does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0151 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0151 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the airbag data no-receive detected in several modules?	Replace the A/B CM. < Refer to AIRBAG CONTROL MODULE . >	Go to step 5 .
5 REPLACE MODULE. Replace the A/B CM. Read the DTC using Subaru Select Monitor.	Is U0151 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Reinstall the A/B CM. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0151 a current malfunction?	Replace the A/B CM. < Refer to AIRBAG CONTROL MODULE . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0151 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data received from combination meter.

Display of combination meter does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0155 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0155 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the meter data no-receive detected in several modules?	Replace the meter. < Refer to COMBINATION METER . >	Go to step 5 .
5 REPLACE MODULE. Replace the combination meter. Read the DTC using Subaru Select Monitor.	Is U0155 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Replace the current combination meter with the original combination meter. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0155 a current malfunction?	Replace the combination meter. < Refer to COMBINATION METER . >	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0155 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

No data is received from A/C control panel.

Cooperation control of air conditioner does not operate properly.

Step	Check	Yes	No
1 CHECK DTC. Check the displayed DTC.	Are DTCs other than U*** displayed?	Perform the diagnosis according to DTC.	Go to step 2 .
2 CHECK DTC. Check the displayed DTC.	Is U0164 a current malfunction?	Go to step 3 .	Go to step 7 .
3 CHECK DTC. Check CAN communication circuit. < Refer to CAN COMMUNICATION CIRCUIT CHECK . > Read the DTC using Subaru Select Monitor.	Is U0164 a current malfunction?	Go to step 4 .	Go to step 7 .
4 CHECK DTC. Using the Subaru Select Monitor, read DTC of all the systems.	Is the air conditioner data no-receive detected in several modules?	Replace the A/C control panel.	Go to step 5 .
5 REPLACE MODULE. Replace the A/C control panel. Read the DTC using Subaru Select Monitor.	Is U0164 a current malfunction?	Go to step 6 .	System is normal.
6 CHECK MODULE. Restore the A/C control panel. Replace the module that the DTC has been detected. Read the DTC using Subaru Select Monitor.	Is U0164 a current malfunction?	Replace the A/C control panel.	System is normal.
7 CHECK HARNESS. Shake the harness, and check for poor contact. Read the DTC using Subaru Select Monitor.	Is U0164 a current malfunction?	Repair the poor contact of harness, or replace the harness.	Go to step 8 .
8 CHECK CONNECTOR. Check the connector used for high speed CAN for poor contact.	Is there poor contact of connector?	Repair the connector that has poor contact, or replace harness.	It is possible that temporary poor communication occurs. Delete the DTC.

DIAGNOSTIC PROCEDURE

INSPECTION

Item	Operation	Specifications		Note
Item	Operation	YES	NO	Note
Diagnostic code	DTC is displayed when inspecting all DTCs.	Perform the diagnosis according to DTC.	System is normal.
Speedometer	Faster vehicle speed than the actual speed is displayed.	VDC CM data may not be received.	System is normal.	Also, check vehicle speed pulse circuit.
Fuel gauge	Fuel is present, but displayed less than actual amount.	Communication error may be present.	System is normal.	Also, check the fuel gauge.
Fuel level warning light	Fuel is present, but the light illuminates.	Communication error may be present.	System is normal.	Also, check the fuel gauge.
Engine coolant temperature light	Engine coolant temperature light blinks in red and blue alternately.	Communication error may be present.	System is normal.	Check the engine coolant light related items.
[S], [I] or [S#] indicator	Blinking.	Communication error may be present.	System is normal.	Check the intelligent switch.
VDC indicator	Illuminating.	Communication error may be present.	System is normal.	Check that VDC is not operating.
VDC OFF indicator	Illuminating.	Communication error may be present.	System is normal.	Check that VDC is not OFF.
Brake warning, etc.	Illuminating.	Brake fluid may be low in amount, or communication error may be present.	System is normal.	Check brake related items.
Shift position	Not displayed.	Communication error may be present.	System is normal.	Also, check AT system.
AT temperature light	Blinking.	Communication error may be present.	System is normal.	Also, check AT system.
Door indicator	Not displayed.	Communication error may be present.	System is normal.	Check the door switch.
Clearance indicator	Not illuminating.	Communication error may be present.	System is normal.	Check the combination switch.
Hi beam indicator	Not illuminating.	Communication error may be present.	System is normal.	Check the combination switch.
Front fog indicator	Not illuminating.	Communication error may be present.	System is normal.	Check the combination switch.
Illumination	Illuminating at the maximum brightness.	Communication error may be present.	System is normal.	Also, check the illumination switch.
Cruise control indicator	Not illuminating.	Communication error may be present.	System is normal.	Check the cruise control system.
AWD indicator	Not illuminating.	Communication error may be present.	System is normal.	Check TCM.
Hill hold indicator	Not illuminating.	Communication error may be present.	System is normal.	Also, check VDC CM.

INSPECTION

Lan Communication System (Diagnostics) (Except Wrx): Diagnosis Subaru XV GP

INSPECTION WITHOUT USING CAN DIAGNOSTIC

INSPECTION USING CAN DIAGNOSTIC

DIAGNOSIS

TROUBLE SYMPTOM

EXAMPLE OF DTC DATA NOT RECEIVED

Scheme 9

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

Scheme 15

Scheme 16

Scheme 17

DTC MATRIX

DTC DETECTING CONDITION

DIAGNOSTIC PROCEDURE

INSPECTION

More articles — Lan Communication System (Diagnostics) (Except Wrx)

Login / Signup

Enter the code

You have successfully logged in!
