Air Bag System (Diagnostics) (Except Wrx): Other Subaru XV GP

Airbag 6 illustrations ~246 words

PROCEDURE

StepCheckYesNo
1 CHECK WARNING LIGHT. Check whether the airbag warning light in the combination meter is lit.Does the airbag warning light illuminate?Go to step 2 .Perform the diagnosis according to phenomenon of the problem.
2 READ DTC. Turn the ignition switch to OFF. Connect the Subaru Select Monitor to data link connector. Turn the ignition switch to ON and run the Subaru Select Monitor. Read the DTC. (Current malfunction) < Refer to OPERATION , Read Diagnostic Trouble Code (DTC). > NOTE: If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. > Record all DTCs and freeze frame data.Is DTC displayed?Go to step 3 .Go to "Airbag Warning Light Failure" < Refer to AIRBAG WARNING LIGHT FAILURE . >.
3 PERFORM DIAGNOSIS. Determine the possible cause from "List of Diagnostic Trouble Code (DTC)" < Refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) . >. Inspect the DTC using "List of Diagnostic Trouble Code (DTC)". Repair the trouble cause. Perform the Clear Memory Mode. < Refer to CLEAR MEMORY MODE . > Perform the Inspection Mode. < Refer to INSPECTION MODE . > Read any other DTCs displayed.Is DTC displayed?Perform the procedure 1 ) to 5 ) in step 3.Finish the diagnosis.
NOTE
If the communication function of the Subaru Select Monitor cannot be executed properly, check the communication circuit. < Refer to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. >

Scheme 226

Scheme 226: CHECK
Scheme 226: CHECK

CAUTION

Refer to "CAUTION" in "General Description" in Airbag System. < Refer to CAUTION , General Description. >

PREPARATION TOOL

CAUTIONTo measure the voltage and resistance of airbag system component, be sure to use the specified test harness.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance, voltage and current.
OscilloscopeUsed for measuring the sensor.
ProbeUsed when measuring voltage and resistance of passenger's airbag module.

HOW TO USE PROBE

Insert the probe into the harness hole, and contact it with the terminal.

Scheme 227

Scheme 227: HOW TO USE PROBE
Scheme 227: HOW TO USE PROBE
CAUTIONDo not insert the probe forcibly. Be careful not to contact it to the connection (5) between the terminal and harness. (Harness will come off easily from connector if doing so.)

Scheme 228

Scheme 228: LOCATION
Scheme 228: LOCATION
  1. XV model

Scheme 229

Scheme 229
Scheme 229
  1. Except for XV model
Connector No.(AB1)(AB2)(AB6)(AB7)(AB9)(AB13)(AB16)(AB17)(AB18)(AB19)(AB21)(AB23)
Pin10430442215 or 2415 or 24424
ColorGrayYellowYellowYellowYellowYellowYellowYellowYellowYellowBlackYellow
Male/FemaleFemaleFemaleFemaleMaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemale
Connector No.(AB24)(AB26)(AB28)(AB30)(AB31)(AB32)(AB33)(AB34)(AB37)(AB38)(AB41)(AB53)
Pin424224242223
ColorYellowBlackYellowYellowBlackYellowBlackYellowOrangeBlackYellowBrown
Male/FemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemaleFemale
Connector No.(AB58)(AB59)(AB60)(AB61)(AB62)(AB63)(AB64)(AB66)
Pin232102222
ColorYellowBrownYellowBlackYellowYellowYellowBlack
Male/FemaleFemaleMaleMaleFemaleFemaleFemaleFemaleFemale

For operation procedures, refer to "Airbag Connector" of Airbag System. < Refer to AIRBAG CONNECTOR . >

Scheme 230

Scheme 230: ELECTRICAL SPECIFICATION
Scheme 230: ELECTRICAL SPECIFICATION
  1. XV model
  2. Terminal numbers in airbag control module connector are shown in the figure.
  3. The airbag warning light illuminates when the connector is removed from the airbag control module.
ItemControl module terminal No.
Ignition power supplyDedicated fuse(1) - 21
Passenger's airbag module level one+(1) - 4
(1) - 3
Passenger's airbag module level two+(1) - 1
(1) - 2
Driver's airbag module level one+(1) - 5
(1) - 6
Driver's airbag module level two+(1) - 8
(1) - 7
Driver's knee airbag module+(1) - 9
(1) - 10
CAN-H(1) - 13
CAN-L(1) - 22
Front sub sensor LH+(1) - 30
(1) - 28
Front sub sensor RH+(1) - 29
(1) - 27
Ground line (GND)(1) - 25
(1) - 26
Passenger's airbag ON indicator(1) - 23
Passenger's airbag OFF indicator(1) - 17
Passenger's seat belt warning(1) - 15
Side airbag sensor LH Curtain airbag sensor LH Front door impact sensor LH+(2) - 24
(2) - 23
Seat belt pretensioner LH+(2) - 5
(2) - 6
Side airbag module LH+(2) - 1
(2) - 2
Curtain airbag module LH+(2) - 4
(2) - 3
Occupant detection control module+(3) - 16
(3) - 24
Side airbag sensor RH Curtain airbag sensor RH Front door impact sensor RH+(3) - 17
(3) - 18
Side airbag module RH+(3) - 8
(3) - 7
Curtain airbag module RH+(3) - 5
(3) - 6
Seat belt pretensioner RH+(3) - 4
(3) - 3
Lap seat belt pretensioner RH+(3) - 1
(3) - 2
Satellite safing sensor+(3) - 21
(3) - 22

Scheme 231

Scheme 231
Scheme 231
  1. Except for XV model
  2. Terminal numbers in airbag control module connector are shown in the figure.
  3. The airbag warning light illuminates when the connector is removed from the airbag control module.
ItemControl module terminal No.
Ignition power supplyDedicated fuse(1) - 21
Passenger's airbag module level one+(1) - 4
(1) - 3
Passenger's airbag module level two+(1) - 1
(1) - 2
Driver's airbag module level one+(1) - 5
(1) - 6
Driver's airbag module level two+(1) - 8
(1) - 7
Driver's knee airbag module+(1) - 9
(1) - 10
CAN-H(1) - 13
CAN-L(1) - 22
Front sub sensor LH+(1) - 30
(1) - 28
Front sub sensor RH+(1) - 29
(1) - 27
Ground line (GND)(1) - 25
(1) - 26
Passenger's airbag OFF indicator(1) - 17
Passenger's airbag ON indicator(1) - 23
Passenger's seat belt warning(1) - 15
Side airbag sensor LH Curtain airbag sensor LH Front door impact sensor LH+(2) - 8
(2) - 15
Side airbag module LH+(2) - 9
(2) - 10
Curtain airbag module LH+(2) - 7
(2) - 6
Seat belt pretensioner LH+(2) - 2
(2) - 1
Satellite safing sensor+(3) - 15
(3) - 14
Seat belt pretensioner RH+(3) - 4
(3) - 5
Side airbag sensor RH Curtain airbag sensor RH Front door impact sensor RH+(3) - 8
(3) - 11
Side airbag module RH+(3) - 7
(3) - 6
Curtain airbag module RH+(3) - 9
(3) - 10
Occupant detection control module+(3) - 12
(3) - 13

Recreate the circumstance by referring to the conditions described in the checklist.

DETECTING CONDITION

  1. Airbag warning light is faulty.
  2. Airbag control module to combination meter circuit is shorted or open.
  3. Grounding circuit is faulty.
  4. Airbag control module is faulty.
  5. Connector connection is improper.
  6. Connections of (AB6, AB17, AB18) to airbag control module are improper. CAUTION: Before performing diagnosis, refer to "CAUTION" in "General Description". < Refer to «CAUTION»(ref-560395-S17771233042013061300000) , General Description. >
StepCheckYesNo
1 CHECK CAN COMMUNICATION. Inspect LAN system. < Refer to PROCEDURE , Basic Diagnostic Procedure. >Is there any fault?Repair it according to diagnosis of LAN system.Go to step 2 .
2 CHECK DTC. Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 60 seconds or more. Check the connection status of airbag CM connector.Is there poor contact of connector?Reconnect the connector. Or repair the connector.Go to step 3 .
3 CHECK FOR POOR CONTACT. Check the combination meter. < Refer to PROCEDURE , Basic Diagnostic Procedure. >Is there any fault?Repair it according to INSTRUMENTATION/DRIVER INFO (DIAGNOSTICS).Replace the airbag CM. < Refer to REMOVAL , Airbag Control Module. >

AIRBAG WARNING LIGHT REMAINS OFF

Note. For the diagnostic procedure, refer to "AIRBAG WARNING LIGHT REMAINS ON". < Refer to AIRBAG WARNING LIGHT REMAINS ON , Airbag Warning Light Failure. >

LIST

DTCItemContent of diagnosisReference
U0073Control Module Communication Bus "A" OffCAN communication error occurred.< Refer to DTC U0073 CONTROL MODULE COMMUNICATION BUS "A" OFF , Diagnostic Chart with Trouble Code. >
B1000Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1000 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1003Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1003 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1105Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1105 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1106Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1106 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1115Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1115 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1116Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1116 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1120Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1120 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1121Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1121 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1125Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1125 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1126Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1126 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1135Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1135 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1136Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1136 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1145Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1145 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1146Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1146 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1170Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1170 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1185Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1185 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1195Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1195 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1196Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1196 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1199Airbag ECU MalfunctionAirbag control module is faulty.< Refer to DTC B1199 AIRBAG ECU MALFUNCTION , Diagnostic Chart with Trouble Code. >
B11E0Rollover IgnitionCurtain airbag module (LH/RH) and seat belt pretensioner (LH/RH) are deployed.< Refer to DTC B11E0 ROLLOVER IGNITION , Diagnostic Chart with Trouble Code. >
B11F2Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Refer to DTC B11F2 FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F3Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Refer to DTC B11F3 FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F4Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Refer to DTC B11F4 FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F5Front Impact IgnitionFront airbag module and seat belt pretensioner (LH/RH) are inflated.< Refer to DTC B11F5 FRONT IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F7Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11F7 SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F8Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11F8 SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11F9Side Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11F9 SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FASide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11FA SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FBSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11FB SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B11FCSide Impact IgnitionSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.< Refer to DTC B11FC SIDE IMPACT IGNITION , Diagnostic Chart with Trouble Code. >
B1610Front Sub Sensor RH FailureFront sub sensor (RH) is faulty< Refer to DTC B1610 FRONT SUB SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1612Front Sub Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and front sub sensor. Front sub sensor (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1612 FRONT SUB SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1613Front Sub Sensor RH Initialization Error< Refer to DTC B1613 FRONT SUB SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1615Front Sub Sensor LH FailureFront sub sensor (LH) is faulty.< Refer to DTC B1615 FRONT SUB SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1617Front Sub Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and front sub sensor. Front sub sensor (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1617 FRONT SUB SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1618Front Sub Sensor LH Initialization Error< Refer to DTC B1618 FRONT SUB SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B16F2Front Sub Sensor RH Recognition ErrorFront sensor (RH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F2 FRONT SUB SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F3Front Sub Sensor LH Recognition ErrorFront sensor (LH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F3 FRONT SUB SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1620Side Airbag Sensor RH FailureSide airbag sensor (RH) is faulty.< Refer to DTC B1620 SIDE AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1622Side Airbag Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and side airbag sensor. Side airbag sensor (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1622 SIDE AIRBAG SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1623Side Airbag Sensor RH Initialization Error< Refer to DTC B1623 SIDE AIRBAG SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1625Side Airbag Sensor LH FailureSide airbag sensor (LH) is faulty.< Refer to DTC B1625 SIDE AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1627Side Airbag Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and side airbag sensor. Side airbag sensor (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1627 SIDE AIRBAG SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1628Side Airbag Sensor LH Initialization Error< Refer to DTC B1628 SIDE AIRBAG SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1630Curtain Airbag Sensor RH FailureCurtain airbag sensor (RH) is faulty.< Refer to DTC B1630 CURTAIN AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1632Curtain Airbag Sensor RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and curtain airbag sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1632 CURTAIN AIRBAG SENSOR RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1633Curtain Airbag Sensor RH Initialization Error< Refer to DTC B1633 CURTAIN AIRBAG SENSOR RH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B1635Curtain Airbag Sensor LH FailureCurtain airbag sensor (LH) is faulty.< Refer to DTC B1635 CURTAIN AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1637Curtain Airbag Sensor LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and curtain airbag sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1637 CURTAIN AIRBAG SENSOR LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1638Curtain Airbag Sensor LH Initialization Error< Refer to DTC B1638 CURTAIN AIRBAG SENSOR LH INITIALIZATION ERROR , Diagnostic Chart with Trouble Code. >
B16F4Side Airbag Sensor RH Recognition ErrorSide airbag sensor (RH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F4 SIDE AIRBAG SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F5Side Airbag Sensor LH Recognition ErrorSide airbag sensor (LH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F5 SIDE AIRBAG SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F6Curtain Airbag Sensor RH Recognition ErrorCurtain airbag sensor (RH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F6 CURTAIN AIRBAG SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F7Curtain Airbag Sensor LH Recognition ErrorCurtain airbag sensor (LH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F7 CURTAIN AIRBAG SENSOR LH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1642Side Satellite Sensor Bus RH Lost CommunicationOpen or short circuit in harness (RH) between airbag control module and front door impact sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Front door impact sensor (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1642 SIDE SATELLITE SENSOR BUS RH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1647Side Satellite Sensor Bus LH Lost CommunicationOpen or short circuit in harness (LH) between airbag control module and front door impact sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Front door impact sensor (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1647 SIDE SATELLITE SENSOR BUS LH LOST COMMUNICATION , Diagnostic Chart with Trouble Code. >
B1650Occupant Classification System MalfunctionOccupant detection sensor is faulty. Occupant detection control module is faulty. Occupant detection harness is faulty. Rear airbag harness (RH) is faulty. Fuse No. 25 is blown.< Refer to DTC B1650 OCCUPANT CLASSIFICATION SYSTEM MALFUNCTION , Diagnostic Chart with Trouble Code. >
B1655Front Buckle Switch RH FailureBuckle switch (RH) circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.< Refer to DTC B1655 FRONT BUCKLE SWITCH RH FAILURE , Diagnostic Chart with Trouble Code. >
B1660Passenger's Airbag On Indicator FailurePassenger's airbag indicator is faulty. Airbag control module is faulty. Airbag main harness circuit is open, shorted or shorted to ground. Body harness circuit is open.< Refer to DTC B1660 PASSENGER'S AIRBAG ON INDICATOR FAILURE , Diagnostic Chart with Trouble Code. >
B1675Satellite Safing Sensor FailureSatellite safing sensor is faulty.< Refer to DTC B1675 SATELLITE SAFING SENSOR FAILURE , Diagnostic Chart with Trouble Code. >
B1676Lost Communication With Satellite Safing SensorOpen or short circuit in harness between airbag control module and satellite safing sensor. Satellite safing sensor is faulty. Airbag control module is faulty.< Refer to DTC B1676 LOST COMMUNICATION WITH SATELLITE SAFING SENSOR , Diagnostic Chart with Trouble Code. >
B1677Satellite Safing Sensor Initialization Incomplete< Refer to DTC B1677 SATELLITE SAFING SENSOR INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B16F8Satellite Safing Sensor Recognition ErrorSatellite safing sensor is misinstalled. Airbag control module is faulty.< Refer to DTC B16F8 SATELLITE SAFING SENSOR RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B16F9Door Sensor RH Recognition ErrorFront door impact sensor (RH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16F9 DOOR SENSOR RH RECOGNITION ERROR , Diagnostic Chart with Trouble Code. >
B1690Door Sensor RH FailureFront door impact sensor (RH) is faulty.< Refer to DTC B1690 DOOR SENSOR RH FAILURE , Diagnostic Chart with Trouble Code. >
B1692Lost Communication With Door Sensor RHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1692 LOST COMMUNICATION WITH DOOR SENSOR RH , Diagnostic Chart with Trouble Code. >
B1693Door Sensor RH Initialization Incomplete< Refer to DTC B1693 DOOR SENSOR RH INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B16FALost Communication With Door Sensor LHFront door impact sensor (LH) is misinstalled. Airbag control module is faulty.< Refer to DTC B16FA LOST COMMUNICATION WITH DOOR SENSOR LH , Diagnostic Chart with Trouble Code. >
B1695Door Sensor LH FailureFront door impact sensor (LH) is faulty.< Refer to DTC B1695 DOOR SENSOR LH FAILURE , Diagnostic Chart with Trouble Code. >
B1697Lost Communication With Door Sensor LHOpen or short circuit in harness between curtain airbag sensor and front door impact sensor. Front door impact sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1697 LOST COMMUNICATION WITH DOOR SENSOR LH , Diagnostic Chart with Trouble Code. >
B1698Door Sensor LH Initialization Incomplete< Refer to DTC B1698 DOOR SENSOR LH INITIALIZATION INCOMPLETE , Diagnostic Chart with Trouble Code. >
B161ALost Communication With Front Satellite Sensor BusOpen or short circuit in harness between airbag control module and front sub sensor. Front sub sensor is faulty. Airbag control module is faulty.< Refer to DTC B161A LOST COMMUNICATION WITH FRONT SATELLITE SENSOR BUS , Diagnostic Chart with Trouble Code. >
B16F1Passenger's Seat Belt Warning FailureAirbag control module is faulty. Body integrated unit is faulty. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.< Refer to DTC B16F1 PASSENGER'S SEAT BELT WARNING FAILURE , Diagnostic Chart with Trouble Code. >
B16F0Passenger's Airbag Off Indicator FailureAirbag warning light is faulty. Open or short circuit in harness between airbag control module and airbag warning light. Poor contact of airbag main harness and instrument panel harness. Ground circuit is faulty. Airbag control module is faulty.< Refer to DTC B16F0 PASSENGER'S AIRBAG OFF INDICATOR FAILURE , Diagnostic Chart with Trouble Code. >
B1760Sensor Mat AbnormalOccupant detection sensor is open, shorted between terminals, shorted to power supply or shorted to ground. Seat heater is open. Occupant detection control module is faulty.< Refer to DTC B1760 SENSOR MAT ABNORMAL , Diagnostic Chart with Trouble Code. >
B1761Sensor Mat Liquid Coating AbnormalDetected that the occupant detection sensor is spattered with fluid. Occupant detection sensor is faulty. Occupant detection control module is faulty.< Refer to DTC B1761 SENSOR MAT LIQUID COATING ABNORMAL , Diagnostic Chart with Trouble Code. >
B1771Buckle Switch AbnormalPassenger's buckle switch circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.< Refer to DTC B1771 BUCKLE SWITCH ABNORMAL , Diagnostic Chart with Trouble Code. >
B1795ECU Internal CircuitFault Occupant detection control module is faulty.< Refer to DTC B1795 ECU INTERNAL CIRCUIT FAULT , Diagnostic Chart with Trouble Code. >
B1800Short in Driver's AirbagAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1800 SHORT IN DRIVER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1801Open in Driver's AirbagAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1801 OPEN IN DRIVER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1802Short in Driver's Airbag (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1802 SHORT IN DRIVER'S AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1803Short in Driver's Airbag (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1803 SHORT IN DRIVER'S AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1805Short in Passenger's AirbagAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1805 SHORT IN PASSENGER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1806Open in Passenger's AirbagAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1806 OPEN IN PASSENGER'S AIRBAG , Diagnostic Chart with Trouble Code. >
B1807Short in Passenger's Airbag (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1807 SHORT IN PASSENGER'S AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1808Short in Passenger's Airbag (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1808 SHORT IN PASSENGER'S AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1810Short in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1810 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1811Open in Driver's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1811 OPEN IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1812Short in Driver's Airbag Dual Stage - 2nd Step (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1812 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1813Short in Driver's Airbag Dual Stage - 2nd Step Circuit (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1813 SHORT IN DRIVER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1815Open in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1815 OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1816Open in Passenger's Airbag Dual Stage - 2nd StepAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1816 OPEN IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP , Diagnostic Chart with Trouble Code. >
B1817Short in Passenger's Airbag Dual Stage - 2nd Step (To Ground)Airbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1817 SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1818Short in Passenger's Airbag Dual Stage - 2nd Step Circuit (To +B)Airbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1818 SHORT IN PASSENGER'S AIRBAG DUAL STAGE - 2ND STEP CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1820Short in Side Airbag RHSide airbag harness (RH) circuit is shorted. Side airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1820 SHORT IN SIDE AIRBAG RH , Diagnostic Chart with Trouble Code. >
B1821Open in Side Airbag RHSide airbag harness (RH) circuit is open. Side airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1821 OPEN IN SIDE AIRBAG RH , Diagnostic Chart with Trouble Code. >
B1822Short in Side Airbag RH (To Ground)Side airbag harness (RH) circuit is shorted to ground. Side airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1822 SHORT IN SIDE AIRBAG RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1823Short in Side Airbag RH (To +B)Side airbag harness (RH) circuit is shorted to power supply. Side airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1823 SHORT IN SIDE AIRBAG RH (TO +B) , Diagnostic Chart with Trouble Code. >
B1825Short in Side Airbag LHSide airbag harness (LH) circuit is shorted. Side airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1825 SHORT IN SIDE AIRBAG LH , Diagnostic Chart with Trouble Code. >
B1826Open in Side Airbag LHSide airbag harness (LH) circuit is open. Side airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1826 OPEN IN SIDE AIRBAG LH , Diagnostic Chart with Trouble Code. >
B1827Short in Side Airbag LH (To Ground)Side airbag harness (LH) circuit is shorted to ground. Side airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1827 SHORT IN SIDE AIRBAG LH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1828Short in Side Airbag LH (To +B)Side airbag harness (LH) circuit is shorted to power supply. Side airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1828 SHORT IN SIDE AIRBAG LH (TO +B) , Diagnostic Chart with Trouble Code. >
B1830Short in Curtain Airbag RH Squib CircuitCurtain airbag harness (RH) circuit is shorted. Curtain airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1830 SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1831Open in Curtain Airbag RH Squib CircuitCurtain airbag harness (RH) circuit is open. Curtain airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1831 OPEN IN CURTAIN AIRBAG RH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1832Short in Curtain Airbag RH Squib Circuit (To Ground)Curtain airbag harness (RH) circuit is shorted to ground. Curtain airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1832 SHORT IN CURTAIN AIRBAG RH SQUIB CIRCUIT (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1833Short in Curtain Shield Airbag RH Squib Circuit (To +B)Curtain airbag harness (RH) is shorted to power supply. Curtain airbag module (RH) is faulty. Airbag control module is faulty.< Refer to DTC B1833 SHORT IN CURTAIN SHIELD AIRBAG RH SQUIB CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1835Short in Curtain Airbag LH Squib CircuitCurtain airbag harness (LH) circuit is shorted. Curtain airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1835 SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1836Open in Curtain Airbag LH Squib CircuitCurtain airbag harness (LH) circuit is open. Curtain airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1836 OPEN IN CURTAIN AIRBAG LH SQUIB CIRCUIT , Diagnostic Chart with Trouble Code. >
B1837Short in Curtain Airbag LH Squib Circuit (To Ground)Curtain airbag harness (LH) circuit is shorted to ground. Curtain airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1837 SHORT IN CURTAIN AIRBAG LH SQUIB CIRCUIT (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1838Short in Curtain Shield Airbag LH Squib Circuit (To +B)Curtain airbag harness (LH) is shorted to power supply. Curtain airbag module (LH) is faulty. Airbag control module is faulty.< Refer to DTC B1838 SHORT IN CURTAIN SHIELD AIRBAG LH SQUIB CIRCUIT (TO +B) , Diagnostic Chart with Trouble Code. >
B1860Short in Driver's Knee AirbagAirbag main harness circuit is shorted. Knee airbag module harness circuit is shorted. Knee airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1860 SHORT IN DRIVER'S KNEE AIRBAG , Diagnostic Chart with Trouble Code. >
B1861Open in Driver's Knee AirbagAirbag main harness circuit is open. Knee airbag module harness circuit is open. Knee airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1861 OPEN IN DRIVER'S KNEE AIRBAG , Diagnostic Chart with Trouble Code. >
B1862Short in Driver's Knee Airbag (To Ground)Airbag main harness circuit is shorted to ground. Knee airbag module harness circuit is shorted to ground. Knee airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1862 SHORT IN DRIVER'S KNEE AIRBAG (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1863Short in Driver's Knee Airbag (To +B)Airbag main harness circuit is shorted to power supply. Knee airbag module harness circuit is shorted to power supply. Knee airbag module is faulty. Airbag control module is faulty.< Refer to DTC B1863 SHORT IN DRIVER'S KNEE AIRBAG (TO +B) , Diagnostic Chart with Trouble Code. >
B1900Short in Front P/T RHSeat belt pretensioner (RH) circuit is shorted. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.< Refer to DTC B1900 SHORT IN FRONT P/T RH , Diagnostic Chart with Trouble Code. >
B1901Open in Front P/T RHSeat belt pretensioner (RH) circuit is open. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.< Refer to DTC B1901 OPEN IN FRONT P/T RH , Diagnostic Chart with Trouble Code. >
B1902Short in Front P/T RH (To Ground)Seat belt pretensioner (RH) circuit is shorted to ground. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.< Refer to DTC B1902 SHORT IN FRONT P/T RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1903Short in Front P/T RH (To +B)Seat belt pretensioner (RH) circuit is shorted to power supply. Pretensioner (RH) is faulty. Pretensioner harness (RH) is shorted. Airbag control module is faulty.< Refer to DTC B1903 SHORT IN FRONT P/T RH (TO +B) , Diagnostic Chart with Trouble Code. >
B1905Short in Front P/T LHSeat belt pretensioner (LH) circuit is shorted. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.< Refer to DTC B1905 SHORT IN FRONT P/T LH , Diagnostic Chart with Trouble Code. >
B1906Open in Front P/T LHSeat belt pretensioner (LH) circuit is open. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.< Refer to DTC B1906 OPEN IN FRONT P/T LH , Diagnostic Chart with Trouble Code. >
B1907Short in Front P/T LH (To Ground)Seat belt pretensioner (LH) circuit is shorted to ground. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.< Refer to DTC B1907 SHORT IN FRONT P/T LH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B1908Short in Front P/T LH (To +B)Seat belt pretensioner (LH) circuit is shorted to power supply. Pretensioner (LH) is faulty. Pretensioner harness (LH) is shorted. Airbag control module is faulty.< Refer to DTC B1908 SHORT IN FRONT P/T LH (TO +B) , Diagnostic Chart with Trouble Code. >
B19F0Short in Front P/T 2 RHLap seat belt pretensioner (RH) circuit is shorted. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted. Airbag control module is faulty.< Refer to DTC B19F0 SHORT IN FRONT P/T 2 RH , Diagnostic Chart with Trouble Code. >
B19F1Open in Front P/T 2 RHLap seat belt pretensioner (RH) circuit is open. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is open. Airbag control module is faulty.< Refer to DTC B19F1 OPEN IN FRONT P/T 2 RH , Diagnostic Chart with Trouble Code. >
B19F2Short in Front P/T 2 RH (To Ground)Lap seat belt pretensioner (RH) circuit is shorted to ground. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted to ground. Airbag control module is faulty.< Refer to DTC B19F2 SHORT IN FRONT P/T 2 RH (TO GROUND) , Diagnostic Chart with Trouble Code. >
B19F3Short in Front P/T 2 RH (To +B)Lap seat belt pretensioner (RH) circuit is shorted to power supply. Lap seat belt pretensioner (RH) is faulty. Lap seat belt pretensioner harness (RH) is shorted to power supply. Airbag control module is faulty.< Refer to DTC B19F3 SHORT IN FRONT P/T 2 RH (TO +B) , Diagnostic Chart with Trouble Code. >

More articles — Air Bag System (Diagnostics) (Except Wrx)
