SPECIAL TOOL
- Subaru Select Monitor
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system
- TEST HARNESS H
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of front sub sensor and front door impact sensor
Scheme 216
- TEST HARNESS N
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module, seat belt pretensioner and curtain airbag module
Scheme 217
- TEST HARNESS Q
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module
Scheme 218
- TEST HARNESS AG
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module
Scheme 219
Scheme 220
- TEST HARNESS AH
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG080 TEST HARNESS AH Used together with test harness AG when measuring voltage and resistance of the airbag control module
Scheme 221
- TEST HARNESS V
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor
Scheme 222
- AIRBAG RESISTOR
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two ST are required for diagnosis of two-stage inflator type airbag module
Scheme 223
- TEST HARNESS AJ
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness
Scheme 224
- TEST HARNESS AI
ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used for diagnoses of side airbag sensor and curtain airbag sensor. Used together with test harness V
