Wiper System & Washer System: Adjustments Subaru Outback BR рестайлинг

ADJUSTMENT

1. Operate the rear wiper once.
2. Align the blade with the marking on the glass.

Scheme 10

Scheme 11

Scheme 12

Scheme 13

Scheme 14

1. Disconnect the ground cable from battery.
2. Remove the rear wiper arm assembly. Remove the wiper arm cover. Remove the nut and remove the wiper arm.
3. Remove the rear gate trim. Remove the rear gate upper trim. Remove the claws on the trim edge. Disconnect the claws in the center of trim, and remove the rear gate upper trim. Remove the rear gate pillar trim. Release the claws. Remove the claws on the bottom of trim, and remove the rear gate pillar trim. Remove the hand grip of rear gate. CAUTION: Be careful not to scratch the trim. To protect the trim from damage, attach a protective tape to the tool in use. Insert a precision screwdriver (a). With the screwdriver inserted, move the precision screwdriver toward the claw and open the cap. Remove the screws and detach the hand grip. Remove the rear gate lower trim. Remove the clips on both ends. Release the clips and remove the rear gate lower trim.
4. Remove the rear wiper motor assembly. Remove the harness clamp, and disconnect the harness connector of the wiper motor assembly. Remove the bolts, and then remove the wiper motor assembly.

Scheme 15

1. Install each part in the reverse order of removal.
2. Make sure that the o mark on the pivot cap faces up, as shown in the figure. Tightening torque: < Refer to «REAR WIPER»(ref-565214-S37942586002013071000000) , COMPONENT, General Description. >

Scheme 16

1. Connect the battery to the wiper motor connector and confirm that wiper motor operates.
2. Connect the battery to the terminals of connector, then run the motor and disconnect the terminal in mid motion.
3. Connect the battery and confirm that the motor stops at the automatic stop position after the motor operates at low speed again.

Scheme 17

Scheme 18

Scheme 19

1. Disconnect the ground cable from battery.
2. Remove the rear gate upper trim. Remove the claws on the trim edge. Disconnect the claws in the center of trim, and remove the rear gate upper trim.
3. Remove the high-mounted stop light. Remove the nut. Disconnect the connector and remove the high-mounted stop light.
4. Remove the rear washer nozzle. CAUTION: Before removing, apply protective tape to the body panel and used tools not to damage the rear gate panel. Push the claw using a flat tip screwdriver, etc. When the washer nozzle lifts up, pull out the nozzle using a clip remover, etc. Disconnect the washer hose and remove the washer nozzle.
