Wiper System and Washer System - Mechanism & Function: Other Subaru Outback BR рестайлинг

Wiper/washer Systems 2 illustrations ~342 words

FRONT WASHER SYSTEM

  1. The front washer system consists of a washer tank, motor and pump unit, and a pair of nozzles.
  2. The washer tank is installed behind the front bumper under the left headlight.
  3. The washer motor and pump unit is installed at the bottom of the washer tank.
  4. The washer nozzles are installed to the front hood at its rear end and from the under side. Each nozzle has a spray hole.
  5. Each washer nozzle has a check valve at a location approximately 100 mm (3.94 in) from the nozzle.
  6. The washer tank is filled to its specified capacity when the fluid level is at the "FULL" mark on the filling pipe. Do not fill washer fluid until its level exceeds the "FULL" mark. The fluid may spill during driving or when replacing the head light bulb.

REAR WASHER SYSTEM

  1. The front and rear washers share the same washer tank.
  2. The washer motor and pump unit is installed at the bottom of the washer tank.
  3. The washer nozzle is installed to the lower part of the roof spoiler. The nozzle has two spray holes.
  4. The washer nozzle is provided with a check valve, which is located just below it.

GENERAL

When the intermittent wiper is selected, the intermittent stop time is adjusted according to the vehicle speed to effectively secure visibility.

The control module built into the wiper switch assembly controls the intermittent stop time according to the vehicle speed signal provided from the body integrated unit.

Vehicle Speed Sensitive Intermittent Wipers Circuit Diagram (With And Without Wiper Relay Unit). Scheme 5

Scheme 5: Vehicle Speed Sensitive Intermittent Wipers Circuit Diagram (With And Without Wiper Relay Unit)

The intermittent stop time will change according to the selected position of the intermittent volume switch.

Intermittent Time Versus Vehicle Speed Graph. Scheme 6

Scheme 6: Intermittent Time Versus Vehicle Speed Graph

Note. The intermittent stop time in relation to vehicle speed is as shown in the figure, but this may differ from the actual speed. Only 5 levels are shown here, but in actual use, it will operate at all positions of the intermittent volume switch.
