SPECIFICATIONS
| Washer tank | Capacity | 4.0 (4.2 US qt, 3.5 lmp qt) | ||
|---|---|---|---|---|
| Wiper motor | Rated voltage | 12 V | ||
| No-load current | 4 A or less | |||
| Speed [at 2.0 N.m (20 kg-cm, 17 in-lb)] | HIGH | 56 - 68 rpm | ||
| LOW | 35 - 45 rpm | |||
| Motor characteristics when bound | HIGH | Torque | 25.5 N.m (260 kg-cm, 1.88 ft-lb) or more | |
| Current | 33 A or less | |||
| LOW | Torque | 31.4 N.m (320 kg-cm, 2.31 ft-lb) or more | ||
| Current | 29.0 A or less | |||
| Wiper blade | Length | Driver side | 600 mm (23.62 in) | |
| Passenger side | 450 mm (17.72 in) | |||
Scheme 1
- The rear wiper operates over an angle of 168°. (Scheme 1): Identifying Rear Wiper Operating Angle
- The rear wiper operates intermittently as shown in the following table only when the wiper switch is in the INT position on AT models.
| Selector lever position (AT models only) | Vehicle speed km/h (MPH) | Interval (sec) |
|---|---|---|
| Wagon | ||
| Reverse (R) | Continuous operation | |
| Other than reverse (R) | 0 - 20 (0 - 12.4) | 12 |
| 20 - 50 (12.4 - 31.1) | 9 | |
| 50 - 80 (31.1 - 49.7) | 6 | |
| Over 80 (49.7) | 3 |
| Wiper motor | Rated voltage | 12 V | |
|---|---|---|---|
| No-load current | 2 A or less | ||
| Speed [at 0.5 N.m (5 kg-cm, 4.3 in-lb)] | 25 rpm or more | ||
| Motor characteristics when bound | Torque | 8.8 N.m (0.90 kgf-m, 6 ft-lb)or more | |
| Current | 13 A or more | ||
| Wiper blade | Length | 350 mm (13.78 in) | |
