- Manual seat LH (Scheme 16): Identifying Front Seat Components With Torque Specifications (Manual Seat LH) Tightening torque: N.m (kgf-m, ft-lb) T1: 6 (0.61, 4.4) T2: 18 (1.84, 13.3) T3: 38 (3.87, 28.0) T4: 52 (5.30, 38.4) T5: 53 (5.40, 39.1)
- Power seat LH (Scheme 17): Identifying Front Seat Components With Torque Specifications (Power Seat LH) Tightening torque: N.m (kgf-m, ft-lb) T1: 6 (0.61, 4.4) T2: 18 (1.84, 13.3) T3: 38 (3.87, 28.0) T4: 52 (5.30, 38.4) T5: 53 (5.40, 39.1)
- Manual seat RH (Scheme 18): Identifying Front Seat Components With Torque Specifications (Manual Seat Rh) Tightening torque: N.m (kgf-m, ft-lb) T1: 5.9 (0.6, 4.4) T2: 6 (0.61, 4.4) T3: 18 (1.84, 13.3) T4: 38 (3.87, 28.0) T5: 52 (5.30, 38.4) T6: 53 (5.40, 39.1)
- Power seat RH (Scheme 19): Identifying Front Seat Components With Torque Specifications (Power Seat RH) Tightening torque: N.m (kgf-m, ft-lb) T1: 5.9 (0.6, 4.4) T2: 6 (0.61, 4.4) T3: 18 (1.84, 13.3) T4: 38 (3.87, 28.0) T5: 52 (5.30, 38.4) T6: 53 (5.40, 39.1)
Identifying Rear Seat Components With Torque Specifications (Sedan Model). Scheme 20
Tightening torque: N.m (kgf-m, ft-lb)
T1: 9.8 (1.0, 7.2)
T2: 24.5 (2.5, 18.1)
T3: 53 (5.40, 39.1)
Identifying Rear Seat Components With Torque Specifications (Outback Model). Scheme 21
Tightening torque: N.m (kgf-m, ft-lb)
T1: 24.5 (2.5, 18.1)
T2: 53 (5.40, 39.1)
IT DOES NOT FUNCTION WITH MANUAL OPERATION (WITH MEMORY)
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK SEAT FUNCTIONS. Operate each power seat switch and check that each power seat function operates normally. | Does all function fail to operate? | Go to step 2 . | Check the motor which does not operate. < Ref. to SOME MOTORS DO NOT OPERATE (WITH MEMORY) , INSPECTION, Power Seat System. > |
| 2 CHECK FUSE. Check the power seat fuse inside the fuse box. | Is the fuse blown out? | Replace the appropriate fuse. | Go to step 3 . |
| 3 CHECK POWER SUPPLY CIRCUIT. Disconnect the power seat control module connector. Measure the voltage between harness connector and chassis ground. Connector & terminal (R388) No. 10 (+) - Chassis ground (-): (R389) No. 8 (+) - Chassis ground (-): (R389) No. 3 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 4 . | Check body harness. |
| 4 CHECK POWER SUPPLY CIRCUIT. Measure the resistance between power seat control module harness connector and chassis ground. Connector & terminal (R389) No. 14 - Chassis ground: (R389) No. 12 - Chassis ground | Is the resistance less than 10 ohms? | Go to step 5 . | Check body harness. |
| 5 CHECK IGNITION CIRCUIT. Measure the voltage between harness connector and chassis ground while turning the ignition switch to ON. Connector & terminal (R388) No. 11 (+) - Chassis ground (-) | Is the voltage 10 V or more? | Go to step 6 . | Check body harness. |
| 6 CHECK TRANSMISSION CIRCUITS. Measure the resistance between harness connector and chassis ground under the following condition. AT/CVT model: Shift the select lever to "P" position. MT model: Pull parking brake lever. Connector & terminal (R388) No. 12 - Chassis ground | Is the resistance less than 10 ohms? | Go to step 7 . | Check body harness. |
| 7 CHECK SWITCH. Disconnect the connector of power seat switch assembly. Measure the resistance between connector terminals when moving the switch to reclining forward and reclining backward. < Ref. to CHECK POWER SEAT SWITCH , INSPECTION, Power Seat System. > | Is there any problem on the inspection result? | Replace the power seat control module. | Replace the power seat switch assembly. |
UNABLE TO PERFORM THE RELOADING OPERATION (DRIVER'S SEAT WITH MEMORY)
| Step | Check | Yes | No |
|---|---|---|---|
| 1 CHECK MEMORY FUNCTIONS. Perform the memory operation of the seat position, and check the memory replay operation. | Does the seat position memory replay correctly? | Memory function is normal. It is considered that the memory was cleared because the voltage falls below the operation-ensured voltage temporarily during memory restoration or manual operation. It operates normally by registering a memory. | Go to step 2 . |
| 2 CHECK MEMORY FUNCTIONS. At the memory operation of step 1, check the beep sound (once). | Was it possible to confirm the beep sound? | Go to step 3 . | < Ref. to UNABLE TO SET POSITIONS INTO MEMORY (WITH MEMORY) , INSPECTION, Power Seat System. > |
| 3 CHECK SWITCH. Disconnect the harness connector of memory switch assembly. Check memory switch. < Ref. to CHECK MEMORY SWITCH (WITH MEMORY FUNCTION) , INSPECTION, Power Seat System. > | Is there any problem on the inspection result? | Go to step 4 . | Replace the memory switch assembly. |
| 4 CHECK HARNESS. Measure the resistance between the memory switch connector and power seat control module connector. Connector & terminal (R388) No. 13 - (D143) No. 2: (R388) No. 14 - (D143) No. 3: (R388) No. 15 - (D143) No. 8 | Is the resistance less than 10 ohms? | Go to step 5 . | Check power seat harness. |
| 5 CHECK COMBINATION METER. Turn the ignition switch to ON and check the indicator light inside the meter. AT/CVT model: Select lever shifted to "P" position. | Does the indicator display "P"? | Go to step 6 . | Check the combination meter. < Ref. to INSPECTION , Combination Meter System. > |
| 6 CHECK OPERATION. Operate all power seat switches to check operation of each motor. | Does each motor rotate for one second or more when operating each switch? | Replace the power seat control module. | Encoder defection. Replace the appropriate motor as a frame assembly. |
