SPECIFICATION
| Cooling system | Electric fan + Forced engine coolant circulation system | ||||
|---|---|---|---|---|---|
| Total engine coolant capacity | L (US qt, Imp qt) | CVT model | Approx. 7.5 (7.9, 6.6) | ||
| MT model | Approx. 7.6 (8.0, 6.7) | ||||
| Water pump | Type | Centrifugal impeller type | |||
| Discharge performance | Discharge rate | L (US gal, Imp gal)/min. | 230 (60.8, 50.6) | ||
| Pump speed - Discharge pressure | 6, 600 rpm - 211.0 kPa (22 mAq) | ||||
| Engine coolant temperature | 80°C (176°F) | ||||
| Impeller diameter | Mm (in) | 60 (2.36) | |||
| Number of impeller vanes | 7 | ||||
| Pump pulley diameter | Mm (in) | 130 (5.12) | |||
| Thermostat | Type | Wax pellet type | |||
| Starting temperature to open | 87 - 91°C (189 - 196°F) | ||||
| Fully opens | 98°C (208°F) | ||||
| Valve lift | Mm (in) | 8.0 (0.315) or more | |||
| Valve bore | Mm (in) | 32 (1.26) | |||
| Radiator fan | Motor input | Main fan | W | 90 | |
| Sub fan | W | 90 | |||
| Fan diameter/Blade | Main fan | 300 mm (11.81 in)/4 | |||
| Sub fan | 300 mm (11.81 in)/5 | ||||
| Radiator | Type | Down flow, pressure type | |||
| Core dimensions | Width x Height x Thickness | Mm (in) | 687.4 x 340 x 16 (27.06 x 13.39 x 0.63) | ||
| Pressure range in which cap valve is open | KPa (kg/cm 2 , psi) | Positive pressure side | Standard | 93 - 123 (0.95 - 1.25, 14 - 18) | |
| Limit | 83 (0.85, 12) | ||||
| Negative pressure side | Standard | 1.0 to -4.9 or less (-0.01 - -0.05, -0.1 - -0.7) | |||
| Fins | Corrugated fin type | ||||
| Reservoir tank | Capacity | L (US qt, Imp qt) | 0.45 (0.48, 0.40) | ||
| Recommended materials | Item number | Alternative | |
|---|---|---|---|
| Coolant | SUBARU SUPER COOLANT (Concentrated type) | ||
| SUBARU SUPER COOLANT (Diluted type) | K0670Y0001 | ||
| Water for dilution | Distilled water | Soft water or tap water | |
| Cooling system protective agent | Cooling system conditioner | SOA345001 |
Scheme 8
Tightening torque: N.m (kgf-m, ft-lb)
T1: 6.4 (0.7, 4.7)
T2: 14 (1.4, 10.3)
Scheme 9
Tightening torque: N.m (kgf-m, ft-lb)
T1: 5 (0.5, 3.7)
T2: 7.5 (0.8, 5.5)
T3: 12 (1.2, 8.9)
