Contents Section: Cooling System (Mechanical) All sections

Engine Cooling System (H4DO): Other Subaru Outback BR рестайлинг

Cooling System (Mechanical) 2 illustrations ~413 words

CAUTION

  1. Prior to starting work, pay special attention to the following: Always wear work clothes, a safety cap, protective shoes. Additionally, wear a helmet, protective goggles, etc. if necessary. Protect the vehicle using a seat cover, fender cover, etc. Prepare the service tools, clean cloth, containers to catch grease and oil, etc.
  2. Prepare a container and cloth to prevent scattering of engine coolant when performing work where engine coolant can be spilled. If the oil spills, wipe it off immediately to prevent from penetrating into floor or flowing out for environmental protection.
  3. Vehicle components are extremely hot immediately after driving. Be wary of receiving burns from heated parts.
  4. When performing a repair, identify the cause of trouble and avoid unnecessary removal, disassembly and replacement.
  5. Before disconnecting connectors of sensors or units, be sure to disconnect the ground cable from battery.
  6. Always use the jack-up point when the shop jacks or rigid racks are used to support the vehicle.
  7. Remove contamination including dirt and corrosion before removal, installation, disassembly or assembly.
  8. Keep the removed parts in order and protect them from dust and dirt.
  9. All removed parts, if to be reused, should be reinstalled in the original positions with attention to the correct directions, etc.
  10. Bolts, nuts and washers should be replaced with new parts as required.
  11. Be sure to tighten the fasteners including bolts and nuts to the specified torque.
  12. Follow all government and local regulations concerning disposal of refuse when disposing engine coolant.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance and voltage.
Radiator cap testerUsed for checking radiator and radiator cap.

OPERATING CONDITION

Radiator fan operates depending on the radiator fan operation mode related to engine coolant temperature or the radiator fan operation mode related to A/C compressor load, whichever is higher as an operation mode.

Scheme 38

Scheme 38: OPERATING CONDITION
Scheme 38: OPERATING CONDITION

Scheme 39

Scheme 39
Scheme 39
  1. Radiator fan operation mode related to engine coolant temperature
  2. Radiator fan operation mode related to A/C compressor load

WATER PUMP PULLEY

  1. Using the ST, install the water pump pulley. ST1 18355AA000 PULLEY WRENCH ST2 18334AA030 PULLEY WRENCH PIN SET Tightening torque: 14 N.m (1.4 kgf-m, 10.3 ft-lb)
  2. Install the under cover. Refer to «INSTALLATION»(ref-565181-S36610771312013071000000) .
  3. Lower the vehicle.
  4. Install the V-belts. Refer to «INSTALLATION»(ref-565160-S15419969042013071000000) .
  5. Connect the battery ground terminal.

WATER PUMP

  1. Install the water pump to oil pan upper. NOTE: Use a new gasket. Tightening torque: 6.4 N.m (0.7 kgf-m, 4.7 ft-lb)
  2. Install the front exhaust pipe. Refer to «INSTALLATION»(ref-565184-S21488111002013071000000) .
  3. Install the water pump pulley. Refer to «WATER PUMP PULLEY»(ref-565166-S06173599442013071000000) .
  4. Fill engine coolant. Refer to «FILLING OF ENGINE COOLANT»(ref-565166-S19560019672013071000000) .
