INSTALLATION

1. Before installing steering wheel, be sure to adjust the direction of roll connector with steering. Refer to «ADJUSTMENT»(ref-565203-S35151865132013071000000) .
2. Install each part in the reverse order of removal. NOTE: Align the alignment marks on the steering wheel and steering column. Tightening torque: Steering wheel: 39 N.m (3.98 kgf-m, 28.8 ft-lb) Clearance: Between column cover and steering wheel: 4 - 6 mm (0.16 - 0.24 in)

Scheme 35

1. Disconnect the combination switch (light) connector.
2. Measure the resistance between combination switch (light) connector terminals. Preparation tool: Circuit tester
3. Replace the combination switch (light) if the inspection result is not within the standard value.

REMOVAL

Note. The light control sensor is integrated with the sunload sensor.

Scheme 36

Scheme 37

1. Disconnect the ground cable from battery.
2. Remove the light control sensor. CAUTION: Be careful not to damage the sensors and interior trims when removing. Release the claws and clips, then detach the side speaker cover (RH). Push out the light control sensor by pressing the left and right claws. Disconnect the connector, and remove the light control sensor.

Install each part in the reverse order of removal.

Scheme 38

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

1. Disconnect the ground cable from battery.
2. Remove the clips and remove the air intake duct. (When removing the headlight RH)
3. Remove the clips and remove the grille bracket. NOTE: To prevent damage to the grille bracket, make sure to remove all clips.
4. Remove the front bumper face assembly. Refer to «REMOVAL»(ref-565181-S15689469752013071000000) .
5. Remove the fender cover assembly UPR. Remove the clip. Release the claws of the fender cover assembly UPR by pulling it forward and remove the fender cover.
6. Remove the headlight assembly. Remove the bolts and clips, and pull out the headlight assembly to the front of the vehicle. Disconnect the connector and remove the headlight assembly. Headlight connector RH Headlight connector LH

1. Install each part in the reverse order of removal. Tightening torque: Headlight assembly: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
2. Adjust the headlight beam and fog light beam. Adjust the headlight beam. Refer to «HEADLIGHT BEAM ADJUSTMENT»(ref-565206-S42245164422013071000000) . Adjust the fog light beam. (Model with fog light) Refer to «FOG LIGHT AIMING»(ref-565206-S26614077792013071000000) .

Note. When installing the back cover, turn it to the position shown in the figure to lock while pressing the entire periphery of the cover.

Scheme 44

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

1. Install each part in the reverse order of removal. Tightening torque: Front fog light assembly: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
2. Adjust the fog light beam. Refer to «FOG LIGHT AIMING»(ref-565206-S26614077792013071000000) .

Scheme 45

Scheme 46

Scheme 47

1. Before checking the fog light beam level, be sure of the following: The area around the fog light has not sustained any accident, damage or other type of deformation. Vehicle is parked on a level surface. The inflation pressure of tires is correct. Vehicle's fuel tank is fully filled.
2. Bounce the vehicle several times to normalize the suspension.
3. Make certain that someone is seated in the driver's seat.
4. Place the vehicle with the front end facing to the measurement panel. h mm (in) at 3 m (10 ft) 40 (1.58)
5. Adjust the fog light beam. Remove the clips and turn over the front end of front mud guard. Adjust the beam direction by turning the aiming screw from the bottom of front bumper face. Sedan model OUTBACK model

Scheme 48

1. Disconnect the ground cable from battery.
2. Remove the clips and turn over the front end of front mud guard.
3. From the bottom of bumper face, remove the front fog light bulb. Disconnect the connector. Remove the bulb.

Scheme 49

1. Disconnect the ground cable from battery.
2. Remove the clips and turn over the front end of front mud guard.
3. From the bottom of bumper face, remove the front fog light bulb. Disconnect the connector. Remove the bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

Sedan model: 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)

OUTBACK model: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear combination light ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear combination light ASSY: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Install each part in the reverse order of removal.

Tightening torque

Rear finisher light assembly: 4.5 N.m (0.45 kgf-m, 3.3 ft-lb)

Scheme 50

1. Disconnect the ground cable from battery.
2. Release the lock and remove the bulb inspection cover of trunk room trim.
3. Remove the bulb socket and back-up light bulb.

Scheme 51

1. Disconnect the ground cable from battery.
2. Release the claws and remove the bulb inspection cover of rear gate trim
3. Remove the bulb socket and back-up light bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Tightening torque

High-mounted stop light: 4.5 N.m (0.46 kgf-m, 3.3 ft-lb)

Note. The spot map light is a single unit with the overhead console or stereo camera cover.

Scheme 52

Scheme 53

1. Disconnect the ground cable from battery.
2. Remove the overhead console assembly. (Models without EyeSight) Push and open the rear end of the overhead console lid, and remove the screws. Remove the clips and pull out the overhead console to disconnect the connectors.
3. Remove the stereo camera cover assembly. (Models with EyeSight) Refer to «REMOVAL»(ref-565211-S16660257832013071000000) .
4. Release the claws, then detach the spot map light cover and bulb.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

Install each part in the reverse order of removal.

1. Install each part in the reverse order of removal. Tightening torque: Daytime running resistor: 7.5 N.m (0.76 kgf-m, 5.5 ft-lb)
2. Adjust the fog light beam. (Model with fog light) Refer to «FOG LIGHT AIMING»(ref-565206-S26614077792013071000000) .

From behind the bumper, release the claws and remove the reflex reflector.

Scheme 54

Install each part in the reverse order of removal.

Scheme 55

1. Disconnect the ground cable from battery.
2. Remove the door switch. Remove the screws, and pull out the door switch. Disconnect the connector and remove the door switch.

Install each part in the reverse order of removal.
