Lighting System: Other Subaru Outback BR рестайлинг

CAUTION

1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
2. Reassemble the parts in the reverse order of disassembly procedure unless otherwise indicated.
3. Connect the connectors securely during reassembly.
4. After reassembly, make sure that the functional parts operate normally.
5. Yellow connectors and harnesses with yellow tapes around them are the connectors and harnesses for the airbag system. Using a tester above such circuits may cause malfunction of airbag system. Follow the cautions for the airbag system in this case. Refer to «CAUTION»(ref-565203-S06105343772013071000000) .
6. Be careful not to damage the airbag system wiring harness when servicing electrical parts and switches.
7. If the steering wheel and steering angle sensor (steering roll connector) are removed, adjust the steering angle sensor. Refer to «ADJUSTMENT»(ref-565186-S16232332342013071000000) .

GENERAL TOOL

Scheme 62

Note. For other related fuses, refer to the wiring diagram. See appropriate SYSTEM WIRING DIAGRAM article.

CHECK FUSE

1. Remove the fuse and inspect visually.
2. If the fuse is blown out, replace the fuse. NOTE: If the fuse is blown again, check the system wiring harness.

Scheme 63

Scheme 64

1. Check the resistance between relay terminals. Terminal No. Inspection conditions Specification Circuit 1 - 2 Always 1 Mohms or more 1 - 2 Apply battery voltage between 4 - 3 terminals. Less than 1 ohms Terminal No. Inspection conditions Specification Circuit 1 - 2 Always 1 Mohms or more 1 - 4 Always Less than 1 ohms 1 - 2 Apply battery voltage between 3 - 5 terminals. Less than 1 ohms
2. Replace the relay if the inspection result is not within the standard value.

AUTO HEADLIGHT SYSTEM CHECK

Preparation tool

Subaru Select Monitor III kit

Circuit tester

Step Check Yes No 1 CHECK HEADLIGHT ILLUMINATION. Set the lighting switch to the switch 1 (TAIL) and switch 2 (HEAD). Do the tail and headlight illuminate? Go to step 2 . Check the combination switch (light) and headlight bulb. 2 CHECK INPUT SIGNAL. Prepare the Subaru Select Monitor kit. Turn the ignition switch to ON (engine OFF) and run the "PC application for Subaru Select Monitor". On «System Selection Menu» display, select {Integ. unit mode}. Select the {Lighting AUTO input} from {Current Data Display & Save}. Does the display switch between OFF <--> ON when the lighting switch is moved to AUTO position? Go to step 3 . Go to step 8 . 3 CHECK INPUT SIGNAL. From {Current Data Display & Save}, select {Illumination Sensor Output}. Light up the darkness around light control sensor. Is the value depending on the brightness output? (darkness: 47 - 53 Hz) Check and replace the body integrated unit. Inspection: Refer to BASIC DIAGNOSTIC PROCEDURE . Replacement: Refer to BODY INTEGRATED UNIT . Go to step 4 . 4 CHECK HARNESS. Disconnect the body integrated unit connector and light control sensor connector. Check the harness between body integrated unit connector and light control sensor connector. Connector & terminal (B280) No. 19 - (i194) No. 4: (B280) No. 29 - (i194) No. 6: Is harness normal? Go to step 5 . Repair or replace the harness. 5 CHECK HARNESS. Turn the ignition switch to ON. Measure the voltage between light control sensor connector and chassis ground. Connector & terminal (i194) No. 3 (+) - Chassis ground (-): Is the voltage 10 V or more? Go to step 6 . Repair or replace the harness. 6 CHECK BODY INTEGRATED UNIT. Connect the body integrated unit connector. Measure the resistance between body integrated unit connector and chassis ground. Connector & terminal (B280) No. 29 - Chassis ground: Is the resistance less than 10 ohms? Go to step 7 . Replace the body integrated unit. Refer to BODY INTEGRATED UNIT . 7 CHECK LIGHT CONTROL SENSOR. Connect the light control sensor connector. Turn the ignition switch to ON. Set the lighting switch to AUTO position. Connect the Subaru Select Monitor, and read the waveform data between light control sensor connector. Connector & terminal (i194) No. 4 - No. 6: Is waveform normal? (Interval of A becomes shorter as the surrounding becomes brighter.) Go to step 8 . Replace the light control sensor. 8 CHECK COMBINATION SWITCH (LIGHT). Check the combination switch (light). Refer to INSPECTION . Is the combination switch (light) normal? Go to step 9 . Replace the combination switch (light). 9 CHECK HARNESS. Disconnect the body integrated unit connector. Check the harness between body integrated unit connector and combination switch (light) connector. Connector & terminal (B71) No. 19 - (B281) No. 16: Is harness normal? Check and replace the body integrated unit. Inspection: Refer to BASIC DIAGNOSTIC PROCEDURE . Replacement: Refer to BODY INTEGRATED UNIT . Repair or replace the harness

Scheme 65

CHECK LIGHTING SWITCH

Measure the resistance between lighting switch terminals. Refer to INSPECTION .

CHECK DIMMER & PASSING SWITCH

Measure the resistance between dimmer & passing switch terminals. Refer to INSPECTION .

NOTE

For operation procedures of each component of the headlight system, refer to the respective section.

1. Headlight Assembly: Refer to «HEADLIGHT ASSEMBLY»(ref-565206-S35966596072013071000000) .
2. Headlight bulb: Refer to «HEADLIGHT BULB»(ref-565206-S07257378092013071000000) .
3. Combination switch (light): Refer to «COMBINATION SWITCH (LIGHT)»(ref-565206-S30584058882013071000000) .
4. Light control sensor: Refer to «LIGHT CONTROL SENSOR»(ref-565206-S22090864462013071000000) .

DAYTIME RUNNING LIGHT SYSTEM CHECK

For operation procedures of each component of the daytime running light system, refer to the respective section.

1. Headlight Assembly: Refer to «DAY TIME RUNNING RESISTOR»(ref-565206-S31009250142013071000000) .
2. Headlight bulb: Refer to «HEADLIGHT BULB»(ref-565206-S07257378092013071000000) .
3. Combination switch (light): Refer to «COMBINATION SWITCH (LIGHT)»(ref-565206-S30584058882013071000000) .
4. Daytime running resistor: Refer to «DAY TIME RUNNING RESISTOR»(ref-565206-S31009250142013071000000) .

Measure the resistance between lighting switch terminals. Refer to INSPECTION .

For operation procedures of each component of the clearance light & illumination light system, refer to the respective sections.

1. Combination switch (light): Refer to «COMBINATION SWITCH (LIGHT)»(ref-565206-S30584058882013071000000) .
2. Clearance light/parking light bulb: Refer to «CLEARANCE/PARKING LIGHT BULB»(ref-565206-S34757122712013071000000) .
3. License plate light: Refer to «LICENSE PLATE LIGHT»(ref-565206-S05607754552013071000000) .
4. Ignition switch illumination: Refer to «IGNITION SWITCH ILLUMINATION»(ref-565206-S23493636932013071000000) .

CHECK FRONT FOG LIGHT SWITCH

Measure the resistance between front fog light switch terminals. Refer to INSPECTION .

For operation procedures of each component of the front fog light system, refer to the respective section.

1. Combination switch (light): Refer to «COMBINATION SWITCH (LIGHT)»(ref-565206-S30584058882013071000000) .
2. Front fog light assembly: Refer to «FRONT FOG LIGHT ASSEMBLY»(ref-565206-S08409552452013071000000) .
3. Front fog light bulb: Refer to «FRONT FOG LIGHT BULB»(ref-565206-S24545118432013071000000) .

CHECK TURN SIGNAL SWITCH

Measure the resistance between turn signal switch terminals. Refer to INSPECTION .

Scheme 66

Scheme 67

1. Remove the A/C control panel. Manual A/C model: Refer to «MANUAL A/C MODEL»(ref-565180-S37378891552013071000000) . Auto A/C model: Refer to «AUTO A/C MODEL»(ref-565180-S14523345252013071000000) .
2. Measure the resistance between hazard switch terminals. Preparation tool: Circuit tester Auto A/C model Terminal No. Inspection conditions Standard 1 - 2 Switch OFF 1 Mohms or more Switch ON Less than 1 ohms Manual A/C model Terminal No. Inspection conditions Standard 4 - 5 Switch OFF 1 Mohms or more Switch ON Less than 1 ohms
3. Replace the A/C control panel if the inspection result is not within the standard value.

CHECK TURN SIGNAL AND HAZARD MODULE

1. Measure the voltage between turn signal & hazard module connector and chassis ground. Preparation tool: Circuit tester Connector Terminal No. Input/Output Inspection conditions Standard 6 <--> Chassis ground Input Turn signal switch (Right) OFF --> ON 9 V or more --> less than 1 V 5 <--> Chassis ground Input Turn signal switch (Left) OFF --> ON 9 V or more --> less than 1 V 8 <--> Chassis ground Input Hazard switch OFF --> ON 9 V or more --> less than 1 V 2 <--> Chassis ground Output Turn signal switch (Right) OFF --> ON Repeat less than 1 V --> less than 1 V <--> more than 9 V at 60 to 120 times per minute. 3 <--> Chassis ground Output Turn signal switch (Left) OFF --> ON Repeat less than 1 V --> less than 1 V <--> more than 9 V at 60 to 120 times per minute. 2 <--> Chassis ground Output Hazard switch OFF --> ON Repeat less than 1 V --> less than 1 V <--> more than 9 V at 60 to 120 times per minute. 3 <--> Chassis ground Output Hazard switch OFF --> ON Repeat less than 1 V --> less than 1 V <--> more than 9 V at 60 to 120 times per minute.
2. Replace the turn signal and hazard module if the inspection result is not within the standard value.

For operation procedures of each component of the turn signal and hazard light system, refer to the respective sections.

1. Combination switch (light): Refer to «COMBINATION SWITCH (LIGHT)»(ref-565206-S30584058882013071000000) .
2. Front turn signal light bulb: Refer to «FRONT TURN SIGNAL LIGHT BULB»(ref-565206-S15530867972013071000000) .
3. Side turn signal light assembly: Refer to «SIDE TURN SIGNAL LIGHT ASSEMBLY»(ref-565206-S15790246042013071000000) .
4. Rear combination light assembly: Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-565206-S30851756422013071000000) .
5. Rear turn signal light bulb: Refer to «REAR TURN SIGNAL LIGHT BULB»(ref-565206-S09348805962013071000000) .

For operation procedures of each component of the back-up light system, refer to the respective section.

1. Rear combination light assembly: Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-565206-S30851756422013071000000) .
2. Rear finisher light assembly: Refer to «REAR FINISHER LIGHT ASSEMBLY»(ref-565206-S27711138292013071000000) .
3. Back-up light bulb: Refer to «BACK-UP LIGHT BULB»(ref-565206-S05797538802013071000000) .

For operation procedures of each component of the stop light system, refer to the respective section.

1. Rear combination light assembly: Refer to «REAR COMBINATION LIGHT ASSEMBLY»(ref-565206-S30851756422013071000000) .
2. Rear finisher light assembly: Refer to «REAR FINISHER LIGHT ASSEMBLY»(ref-565206-S27711138292013071000000) .
3. Tail light/stop light bulb: Refer to «TAIL/STOP LIGHT BULB»(ref-565206-S28153202382013071000000) .
4. High-mounted stop light: Refer to «HIGH-MOUNTED STOP LIGHT»(ref-565206-S14938639582013071000000) .

For operation procedures of each component of the interior light system, refer to the respective section.

1. Spot map light: Refer to «SPOT MAP LIGHT»(ref-565206-S20371355002013071000000) .
2. Room light: Refer to «ROOM LIGHT»(ref-565206-S00708833462013071000000) .
3. Luggage room light: Refer to «LUGGAGE ROOM LIGHT»(ref-565206-S28821806622013071000000) .
4. Trunk room light: Refer to «TRUNK ROOM LIGHT»(ref-565206-S12107641802013071000000) .
5. Glove box light: Refer to «GLOVE BOX LIGHT»(ref-565206-S00711057782013071000000) .
6. Door step light: Refer to «DOOR STEP LIGHT»(ref-565206-S38270856552013071000000) .
7. Door switch: Refer to «DOOR SWITCH»(ref-565206-S08285453402013071000000) .

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

1. Position the front wheels straight ahead. (After moving a vehicle 5 m (16 ft) or more with front wheels positioned straight ahead, make sure that the vehicle moves straight ahead.)
2. Turn the ignition switch to OFF.
3. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
4. Remove the driver's airbag module assembly. CAUTION: Before handling the airbag module, refer to «CAUTION»(ref-565203-S06105343772013071000000) . Using a hexagon wrench etc. wrapped by protective tape, insert the snap pins and release the locks (3 locations). Disconnect the horn harness and airbag connector and remove the airbag module assembly. Refer to «PROCEDURE»(ref-565203-S20438257392013071000000) .
5. Remove the steering wheel. CAUTION: Always use the steering wheel puller for removal to avoid deforming the steering wheel. If the steering wheel has been removed, make sure that the roll connector is not turned from the original position. Disconnect the connector and remove the nut. Put alignment marks and remove the steering wheel using a steering wheel puller. Preparation tool: Steering wheel puller
6. Remove the steering column cover. Lower the lever of the steering column. Release the claws and remove the screws, then detach the steering column lower cover. Separate the steering column upper cover and steering upper cover, and remove the steering column upper cover.
7. Remove the roll connector. CAUTION: Make sure that the roll connector is not turned from the original position. Disconnect the connector under the roll connector. Release the claws and remove the roll connector.
8. Remove the wiper switch assembly. Disconnect the connector from wiper switch. Release the claws, and pull out the wiper switch assembly. CAUTION: Do not press the claws with excessive force. They may be damaged.
9. Remove the combination switch (light). Disconnect the connector of combination switch. Remove the screws and detach the combination switch (light).

LIGHTING SWITCH

DIMMER & PASSING SWITCH

TURN SIGNAL SWITCH

FRONT FOG LIGHT SWITCH

HIGH BEAM

Scheme 76

1. Disconnect the ground cable from battery.
2. Remove the clips and remove the air intake duct. (When removing the headlight high beam bulb RH)
3. Disconnect the connector and remove the headlight high beam bulb.

LOW BEAM

Scheme 77

Scheme 78

Scheme 79

1. Disconnect the ground cable from battery.
2. Remove the clips and remove the air intake duct. (When removing the headlight low beam bulb RH)
3. Turn the steering wheel in the opposite direction from the parts to be removed. Then remove the clips and turn over the mud guard.
4. Remove the headlight low beam bulb. Remove the back cover. Unlock the bulb socket and bulb spring, and remove the headlight low beam bulb.

SEDAN MODEL

1. Rear combination light side

Scheme 80

Scheme 81

1. Disconnect the ground cable from battery.
2. Release the lock and remove the bulb inspection cover of trunk room trim.
3. Remove the bulb socket and tail light/stop light bulb.

1. Rear finisher light side

Scheme 82

1. Disconnect the ground cable from battery.
2. Remove the trunk lid trim. Refer to «TRUNK LID TRIM»(ref-565181-S39560907552013071000000) .
3. Remove the bulb socket and tail light bulb.

OUTBACK MODEL

1. Rear combination light side

Scheme 83

1. Disconnect the ground cable from battery.
2. Remove the clips and detach the rear combination light covers.
3. Remove the rear combination light assembly. CAUTION: Be careful not to damage the clips. Release the bolts and clips, then pull out the rear combination light assembly to the vehicle rear. Disconnect the connector and remove the rear combination light assembly.
4. Remove the bulb sockets and bulbs.

1. Rear finisher light side

Scheme 84

Scheme 85

1. Release the claws and remove the bulb inspection cover of rear gate trim
2. Remove the bulb socket and tail light bulb.

SPOT MAP LIGHT BULB

1. Visually check the bulb for blow out.
2. Check the bulb specification. Refer to «SPECIFICATION»(ref-565206-S40110358542013071000000) .
3. Replace the bulb if it is found defective.

SPOT MAP LIGHT SWITCH

1. Remove the overhead console assembly.
2. Measure the resistance between spot map light switch terminals. Preparation tool: Circuit tester Models without EyeSight Terminal No. Inspection conditions Standard Connection diagram - Switch OFF 1 Mohms or more - 6 - 5 Switch ON Less than 1 ohms 6 - 7 Switch door Less than 1 ohms Models with EyeSight Terminal No. Inspection conditions Standard Connection diagram - Switch OFF 1 Mohms or more - 13 - 12 Switch ON Less than 1 ohms 13 - 14 Switch door Less than 1 ohms
3. Replace the overhead console assembly or stereo camera cover assembly if the inspection result is not within the standard value.

OVERHEAD CONSOLE ILLUMINATION LIGHT BULB

Note. Since LEDs (Light Emitting Diode) are used for the overhead console illumination light bulb, replace the overhead console assembly if an LED burns out.

Scheme 86

Scheme 87

1. Disconnect the ground cable from battery.
2. Remove the room light. Release the claws and remove the cover. Remove the screws. Disconnect the connector and remove the room light and bulb.

ROOM LIGHT BULB

1. Visually check the bulb for blow out.
2. Check the bulb specification. Refer to «SPECIFICATION»(ref-565206-S40110358542013071000000) .
3. Replace the bulb if it is found defective.

Scheme 88

1. Remove the room light.
2. Measure the resistance between room light switch terminals. Preparation tool: Circuit tester Terminal No. Inspection Conditions Standard - Switch OFF 1 Mohms or more 1 - 3 Switch ON Less than 1 ohms 2 - 3 Switch door Less than 1 ohms
3. Apply battery voltage to check the lighting condition of room light. Terminal No. Inspection Conditions Specification 3 (+) - 1, 2 (-) Switch OFF Light OFF Switch ON Light ON Switch door Light ON
4. Replace the room light if the inspection result is not within the standard value.

Scheme 89

Scheme 90

1. Disconnect the ground cable from battery.
2. Remove the luggage room light. Release the claws and remove the luggage room light main body. Disconnect the connector and remove the luggage room light.
3. Release the claws, and detach the luggage room light cover and bulb.

LUGGAGE ROOM LIGHT BULB

1. Visually check the bulb for blow out.
2. Check the bulb specification. Refer to «SPECIFICATION»(ref-565206-S40110358542013071000000) .
3. Replace the bulb if it is found defective.

Scheme 91

1. Remove the luggage room light.
2. Measure the resistance between luggage room light switch terminals. Preparation tool: Circuit tester Terminal No. Inspection Conditions Standard - Switch OFF 1 Mohms or more 1 - 2 Switch ON Less than 1 ohms 2 - 3 Switch door Less than 1 ohms
3. Replace the luggage room light if the inspection result is not within the standard value.

Scheme 92

Scheme 93

1. Disconnect the ground cable from battery.
2. Remove the trunk room light Disconnect the connector. Turn the trunk room light counterclockwise to 60° and remove the light.
3. Release the claws, and detach the trunk room light cover and bulb.
