Lighting System: Wiring Subaru Outback BR рестайлинг

Exterior Lights 6 illustrations ~421 words

WIRING DIAGRAM

See appropriate SYSTEM WIRING DIAGRAM article.

See appropriate SYSTEM WIRING DIAGRAM article.

See appropriate SYSTEM WIRING DIAGRAM article.

See appropriate SYSTEM WIRING DIAGRAM article.

See appropriate SYSTEM WIRING DIAGRAM article.

See appropriate SYSTEM WIRING DIAGRAM article.

Scheme 56

Scheme 56: CHECK BACK-UP LIGHT SWITCH (MT MODEL)
Scheme 56: CHECK BACK-UP LIGHT SWITCH (MT MODEL)
  1. Disconnect the back-up light switch connector.
  2. Measure the resistance between back-up light switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 1 - 2 When shift lever is set in reverse position Less than 1 ohms Other positions 1 Mohms or more
  3. Replace the back-up light switch if the inspection result is not within the standard value.

Scheme 57

Scheme 57: CHECK INHIBITOR SWITCH (AT/CVT MODEL)
Scheme 57: CHECK INHIBITOR SWITCH (AT/CVT MODEL)
  1. Disconnect the inhibitor switch connector.
  2. Measure the resistance between inhibitor switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 7 - 8 When the selector lever is in the "R" range Less than 1 ohms Other positions 1 Mohms or more
  3. Replace the inhibitor switch if the inspection result is not within the standard value.

See appropriate SYSTEM WIRING DIAGRAM article.

Scheme 58

Scheme 58: CHECK STOP LIGHT SWITCH
Scheme 58: CHECK STOP LIGHT SWITCH
  1. Disconnect the stop light switch connector.
  2. Measure the resistance between stop light switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 2 - 3 When brake pedal is depressed Less than 1 ohms When brake pedal is released 1 Mohms or more
  3. Replace the stop light switch if the inspection result is not within the standard value.

See appropriate SYSTEM WIRING DIAGRAM article.

Scheme 59

Scheme 59: CHECK DOOR SWITCH
Scheme 59: CHECK DOOR SWITCH
  1. Remove the door switch.
  2. Measure the resistance between door switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 2 - 3 When door is opened Less than 1 ohms When door is closed 1 Mohms or more
  3. Replace the door switch if the inspection result is not within the standard value.

Scheme 60

Scheme 60: CHECK REAR GATE LATCH SWITCH
Scheme 60: CHECK REAR GATE LATCH SWITCH
  1. Disconnect the rear gate latch switch connector.
  2. Measure the resistance between rear gate latch switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 3 - 4 When rear gate is opened Less than 1 ohms When rear gate is closed 1 Mohms or more
  3. If the inspection result is not within the standard value, replace the rear gate latch and actuator assembly.

Scheme 61

Scheme 61: CHECK TRUNK LID LATCH SWITCH
Scheme 61: CHECK TRUNK LID LATCH SWITCH
  1. Disconnect the trunk lid latch switch connector.
  2. Measure the resistance between trunk lid latch switch terminals. Preparation tool: Circuit tester Terminal No. Inspection conditions Standard 2 - 3 When trunk lid is opened Less than 1 ohms When trunk lid is closed 1 Mohms or more
  3. If the inspection result is not within the standard value, replace the trunk lid latch and actuator assembly.
