Sunroof: Other Subaru Outback BR рестайлинг

CAUTION

1. Before disassembling or reassembling parts, always disconnect the battery ground cable from battery. When replacing the audio, control module and other parts provided with memory functions, record the memory contents before disconnecting the battery ground cable. Otherwise, the memory is cleared.
2. Reassemble the parts in the reverse order of disassembly unless otherwise indicated.
3. Adjust parts to the given specifications.
4. Connect the connectors securely during reassembly.
5. After reassembly, make sure that the functional parts operate normally.

GENERAL TOOL

Scheme 18

Note. For other related fuses, < Refer to appropriate SYSTEM WIRING DIAGRAM. >

CHECK FUSE

1. Remove the fuse and check visually.
2. If the fuse is blown out, replace the fuse.

NOTE

For operation procedures of each component of the sunroof control system, refer to the respective information.

1. Glass lid: < Refer to «GLASS LID»(ref-565218-S25928834602013071000000) . >
2. Sunroof assembly: < Refer to «SUNROOF ASSEMBLY»(ref-565218-S12931191832013071000000) . >
3. Sunroof motor: < Refer to «SUNROOF MOTOR»(ref-565218-S41432870192013071000000) . >
4. Sunroof switch: < Refer to «SUNROOF SWITCH»(ref-565218-S34999989032013071000000) . >
5. Sunshade: < Refer to «SUNSHADE»(ref-565218-S36746597072013071000000) . >

Scheme 19

Scheme 20

1. Completely close the glass lid, and then open the sunshade.
2. Disconnect the claws and then remove the lid cover.
3. Remove the bolts, then remove the glass lid. CAUTION: Be careful not to damage the glass lid.

FORCED DRIVE

If the glass lid does not operate or the sunroof motor is not supplied with power, move the glass lid using the hexagon wrench.

Width across flat 5 mm (0.20 in)

Scheme 21

1. Remove the spot map light. (Models without EyeSight) < Refer to «REMOVAL»(ref-565206-S00072003182013071000000) , Spot Map Light. >
2. Remove the stereo camera cover. (Models with EyeSight) < Refer to «REMOVAL»(ref-565211-S16660257832013071000000) , Stereo Camera. >
3. Insert the hexagon wrench securely until it touches the motor shaft end.
4. Turn the hexagon wrench, and move the glass lid. Turning right, the glass lid open. Turning left, the glass lid close. CAUTION: Be careful not to damage the adjacent parts with the rod end when moving the glass lid with the hexagon wrench.
