AIRBAG CONTROL MODULE

CAUTIONDo not reuse mounting bolts and nuts.

Scheme 99

Scheme 99

Tightening torque

25 N.m (2.55 kgf-m, 18.4 ft-lb)

FRONT SUB SENSOR

CAUTIONDo not reuse mounting bolts and nuts.

Scheme 100

Scheme 100

Tightening torque

13 N.m (1.33 kgf-m, 9.6 ft-lb)

SIDE AIRBAG SENSOR

CAUTIONDo not reuse mounting bolts and nuts.

Scheme 101

Scheme 101

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

CURTAIN AIRBAG SENSOR

CAUTIONDo not reuse mounting bolts and nuts.

Scheme 102

Scheme 102

Tightening torque

7.5 N.m (0.76 kgf-m, 5.5 ft-lb)

Scheme 103

Scheme 103: STEERING ROLL CONNECTOR

Scheme 104

Scheme 104: BEFORE STARTING ALL WORKS

Scheme 105

Scheme 105

Scheme 106

Scheme 106

Scheme 107

Scheme 107
  1. The airbag system is fitted with a backup power supply. After disconnecting the battery ground cable, the airbag may operate if you do not wait for 60 seconds or more before starting the service of airbag system.
  2. When servicing a vehicle, be sure to turn the ignition switch to OFF, disconnect the ground cable from battery, and wait for 60 seconds or more before starting work.
  3. Once the airbag warning light lights up, immediately inspect or repair the vehicle. Otherwise, the airbag system may malfunction.
  4. Do not allow water or oil to come in contact with the connector terminals. Also, do not touch the connector terminals directly.
  5. If damage, open circuit or rust is found on airbag system wiring harness, do not repair the harness. Always replace the faulty harness with a new genuine part.
  6. When painting or performing sheet metal work on the front part of the vehicle, including the front wheel apron, front fender and radiator panel side, remove the front sub sensors and wiring harness of airbag system.
  7. When painting or performing sheet metal work on the side of the vehicle, including the side sill, center pillar and front and rear doors, remove the side airbag sensors, curtain airbag sensor, and wiring harness of the airbag system.
  8. When installing steering wheel and steering roll connector, be sure to adjust the steering roll connector.

Scheme 108

Scheme 108: BEFORE STARTING PARTS REPLACEMENT

Scheme 109

Scheme 109

Scheme 110

Scheme 110

Scheme 111

Scheme 111

Scheme 112

Scheme 112

Scheme 113

Scheme 113

Scheme 114

Scheme 114

Scheme 115

Scheme 115
  1. If airbag sensors, airbag module, airbag control module, pretensioners, or harnesses are deformed or damaged, replace with new parts.
  2. Install the wiring harness securely with the specified clips to avoid interference or tangled with other parts.
  3. Do not use the airbag or pretensioner parts from other vehicles. Always replace the defective parts with new parts.
  4. Never reuse any activated airbag module and pretensioner.
  5. Do not discard undeployed airbag or pretensioner.
  6. When airbag control module, front sub sensor, side airbag sensor and curtain airbag sensor are removed, do not reuse the bolts and nuts of them. Always use new bolts and nuts for them.
  7. When installing steering wheel and steering roll connector, be sure to adjust the steering roll connector.
  8. After removal of each parts for airbag system, keep them with the pad facing upward on a dry, clean and flat surface without heat, light sources, moisture and dust.
  9. Do not drop any airbag component, store them under high temperature of 85°C (185°F) or more, or let water, oil or grease get on them; the internal parts may be damaged or the reliability may be greatly lowered.
  10. When storing a removed airbag module, do not place it with the pad side of airbag facing downward. Do not place any objects on the airbag module. Do not pile up the airbag module. If the pad of the airbag module is in contact with other objects, it may cause a serious accident if the airbag accidentally operates.
  11. Driver's airbag module
  12. Passenger's airbag module & side airbag module
  13. Do not disassemble driver's airbag module, passenger's airbag module, side or curtain airbag modules, or pretensioner.
  14. The removed front seat with airbag module must be kept at least 200 mm (8 in) away from walls and other objects.

Scheme 116

Scheme 116: BEFORE STARTING TROUBLESHOOTING

Scheme 117

Scheme 117

Scheme 118

Scheme 118

Scheme 119

Scheme 119
  1. Even if any part is to be replaced as the result of diagnosis, do not use airbag parts or pretensioner parts from other vehicles. Always replace the defective parts with new parts.
  2. When checking the airbag system, be sure to use a digital circuit tester. Use of an analog circuit tester may cause the airbag to activate erroneously due to a minimal current inside tester.
  3. Do not allow water or oil to come in contact with the connector terminals. Also, do not touch the connector terminals directly.
  4. When checking, use a test harness (1). Damage to connector terminal cause malfunction. Do not directly apply the tester probe to connector terminal of airbag.
  5. Do not check continuity of the airbag modules for driver's side, passenger's side and curtain, or the pre-tensioner.
  6. If damage, open circuit or rust is found on airbag system wiring harness, do not repair the harness. Always replace the faulty harness with a new genuine part.

GENERAL TOOL

TOOL NAMEREMARKS
TORX® T30Used for removing/installing driver's airbag module.
STEERING WHEEL PULLERUsed for removing the steering wheel.

GENERAL TOOL SPECIFICATION

Scheme 120

Scheme 120: POWER SUPPLY

Scheme 121

Scheme 121
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the lock (A). While holding down the lock (A), disconnect the connector.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 122

Scheme 122: AIRBAG CONTROL MODULE
  1. How to disconnect: Push the lock lever plate. While holding down the lock lever plate, pull the lever toward you.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Insert the connector and push the lock lever in securely.

Scheme 123

Scheme 123: DRIVER'S AIRBAG MODULE (ROLL CONNECTOR)

Scheme 124

Scheme 124
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the slide lock (A) in the direction of arrow. With the slide lock pushed, disconnect the connector.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 125

Scheme 125: PASSENGER'S AIRBAG MODULE

Scheme 126

Scheme 126
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Push the slide lock (A) in the direction of arrow. With the slide lock pushed, disconnect the connector.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 127

Scheme 127: DRIVER'S AIRBAG MODULE, CURTAIN AIRBAG MODULE & PRETENSIONER

Scheme 128

Scheme 128
  1. How to disconnect: Using a flat tip screwdriver, pry the push lock upward to unlock. Pull the connector to disconnect from the driver's airbag module assembly or the retractor assembly.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Be sure to push the push lock in securely. Then pull it gently to make sure that it is locked. Connect the connector in the reverse order of disconnecting. At this time, be sure to insert it until a clicking sound is heard.

Scheme 129

Scheme 129: FRONT SUB SENSOR, SIDE AIRBAG SENSOR, CURTAIN AIRBAG SENSOR

Scheme 130

Scheme 130
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Holding outer part (A), pull it in the direction of arrow.
  2. How to connect: CAUTION: Do not touch the outer side section or else the outer side (A) will move back. Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 131

Scheme 131: SIDE AIRBAG MODULE

Scheme 132

Scheme 132
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A) in place, pull the connector (B) to the direction of arrow.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

Scheme 133

Scheme 133: BUCKLE SWITCH RH

Scheme 134

Scheme 134
  1. How to disconnect: CAUTION: When pulling the slide lock or disconnecting connector, be sure to hold the connector, not the harness. Move the slide lock (A) in the direction of arrow and hold it. While holding the slide lock (A) in place, pull the connector (B) to the direction of arrow.
  2. How to connect: CAUTION: Be sure to insert the connector in until it is locked. Then pull it gently to make sure that it is locked. Holding the connector, push it in securely until a clicking sound is heard.

FRONT COLLISION

  1. Driver's airbag module
  2. Passenger's airbag module
  3. Driver's seat belt (pretensioner)
  4. Passenger's seat belt (pretensioner)
  5. Airbag control module
  6. Front sub sensor (right and left)
  7. Roll connector
  8. Passenger's side seat cushion pad and frame assembly
  9. Instrument panel (for integrating with passenger's airbag module)

SIDE COLLISION

  1. Airbag control module
  2. Side airbag module (operating side)
  3. Side airbag sensor (operating side)
  4. Curtain airbag module (operating side)
  5. Curtain airbag sensor (operating side)

DRIVER'S AIRBAG MODULE

  1. Frontal collision (driver's airbag module activated) Replace the following parts with new ones. Airbag control module Driver's airbag module ASSY Passenger's airbag module assembly Seat belt pretensioner assembly (left and right) Front sub sensor (right and left) Sensor cover plate (left and right) Steering shaft assembly Visually inspect the following items and replace any damaged part with a new one. Steering wheel assembly Steering support beam assembly Instrument panel harness and connector on body side
  2. Frontal collision (driver's airbag module not activated) Visually inspect the following items and replace any damaged or cracked part with a new one. Specially inspect the damage of airbag module body, mounting bracket and harness connector. Driver's airbag module assembly Passenger's airbag module assembly Seat belt pretensioner assembly (left and right) Front sub sensor (right and left) Sensor cover plate (left and right) Instrument panel assembly (because it is integrated with passenger's airbag module)
  3. No frontal collision Visually inspect the airbag modules for damage or contamination and replace any faulty part with a new one.

PASSENGER'S AIRBAG MODULE

  1. Frontal collision (passenger's airbag module activated) Replace the following parts with new ones. Airbag control module Driver's airbag module assembly Passenger's airbag module assembly Seat belt pretensioner assembly (left and right) Front sub sensor (right and left) Sensor cover plate (left and right) Instrument panel assembly (because it is integrated with passenger's airbag module) Visually inspect the following items and replace any damaged part with a new one. Steering support beam assembly Instrument panel harness and connector on body side
  2. Frontal collision (passenger's airbag module not activated) Visually inspect the following items and replace any damaged or cracked part with a new one. Specially inspect the damage of airbag module body, mounting bracket and harness connector. Driver's airbag module assembly Passenger's airbag module assembly Seat belt pretensioner assembly (left and right) Front sub sensor (right and left) Sensor cover plate (left and right) Instrument panel assembly (because it is integrated with passenger's airbag module)
  3. No frontal collision Visually inspect the airbag modules for damage or contamination and replace any faulty part with a new one.

SIDE AIRBAG MODULE

  1. Side impact (side airbag activated) Replace the following parts with new ones. Airbag control module Side airbag module assembly Side airbag sensor Curtain airbag module assembly Curtain airbag sensor Backrest pad assembly Backrest frame assembly Backrest cover assembly Visually inspect the following items and replace any damaged part with a new one. Headrest assembly Headrest lock bushing Outer slide rail Inner slide rail Seat hinge cover Seat lifter lever Reclining lever Side airbag harness and connector on body side
  2. Side impact (side airbag not activated) Visually inspect the following items and replace any damaged or cracked part with a new one. Specially inspect the damage of airbag module body, mounting bracket and harness connector. Backrest pad assembly Backrest frame assembly Backrest cover assembly Side airbag module assembly Side airbag sensor Curtain airbag module assembly Curtain airbag sensor
  3. No side impact Visually inspect the airbag modules for contamination and replace any faulty part with a new one.

CURTAIN AIRBAG MODULE

  1. Side impact (curtain airbag activated) Replace the following parts with new ones. Airbag control module Curtain airbag module assembly Side airbag sensor Curtain airbag sensor Roof trim Each pillar trim Airbag bracket (models with sunroof) Visually inspect the following items and replace any damaged part with a new one. Assist grip Assist grip bracket Curtain airbag harness and connector on body side.
  2. Side impact (side airbag not activated) Visually inspect the following items and replace any damaged or cracked part with a new one. Specially inspect the damage of airbag module body, mounting bracket and harness connector. Roof trim Each pillar trim Curtain airbag module assembly Side airbag sensor Curtain airbag sensor
  3. No side impact Visually inspect the airbag covers for damage or contamination and replace any faulty part with a new one.

Check for the following, and replace the damaged parts with new parts.

  1. Control module is cracked or deformed.
  2. Mounting bracket is cracked or deformed.
  3. Connector is scratched, cracked or deformed.
  4. Driver's airbag has been activated.
  5. Passenger's airbag has been activated.
  6. Side airbag has been activated.
  7. Curtain airbag has been activated.
  8. Seat belt pretensioner has been activated.

If the section of vehicle as shown in the figure is damaged, check the following items and replace the damaged parts with new parts.

Scheme 135

Scheme 135: FRONT SUB SENSOR
  1. Front sub sensor is cracked or deformed.
  2. Connector is scratched, cracked or deformed.
  3. Airbag has been activated.

SIDE AIRBAG SENSOR AND CURTAIN AIRBAG SENSOR

If the section of vehicle as shown in the figure is damaged, check the following items and replace the damaged parts with new parts.

Scheme 136

Scheme 136: SIDE AIRBAG SENSOR AND CURTAIN AIRBAG SENSOR
  1. Side airbag sensor and curtain airbag sensor are cracked or deformed.
  2. Mounting bracket is cracked or deformed.
  3. Connector is scratched, cracked or deformed.
  4. Side airbag or curtain airbag has been activated, (operating side)

ROLL CONNECTOR

Check the following items and replace any damaged, cracked, or deformed parts with new parts.

  1. Combination switch
  2. Steering roll connector

STEERING SHAFT

Measure the overall length of steering column.

If the length is not within the specification, the steering column may be damaged. Replace it with a new part.

Standard: Overall length L

Tilt and telescopic column (measure while minimized)

816.9 +1.5 -1.5 mm (32.16 +0.059 -1.59 in)

Scheme 137

Scheme 137: STEERING SHAFT

PASSENGERS SEAT

  1. Check for the following, and replace the damaged parts with new parts. Seat belt buckle body or bracket is scratched, cracked or deformed. Backrest frame for crack or deformation Headrest for deformation or play If the seat cushion cover and seat backrest cover is scratched or coming loose, replace with a new cover and readjust the system. Ref. to «OPERATION»(ref-371948-S11982603402010091900000) , System Calibration (Rezeroing). CAUTION: If any of the following applies, replace the seat cushion pad and frame assembly. Do not disassemble. Cracks or deformation found in the seat cushion frame or seat cushion pad. Scratches, cracks, or deformation found on the occupant detection system sensor mat or occupant detection control module, or attachment brackets of the control module. Harness and/or connector is cracked, deformed or open. Harness wire is exposed.
  2. After checking the installing condition of passenger's seat, perform the system adjustment of occupant detection system. Ref. to «OPERATION»(ref-371948-S11982603402010091900000) , System Calibration (Rezeroing).

SEDAN MODEL

CAUTIONRefer to "CAUTION" of "General Description" before handling the airbag module. Ref. to CAUTION , General Description.

Scheme 138

Scheme 138

Scheme 139

Scheme 139
  1. Turn the ignition switch to OFF.
  2. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
  3. Remove the roof trim. Ref. to «SEDAN MODEL»(ref-371913-S27585111042010091900000) , REMOVAL, Roof Trim.
  4. Remove the curtain airbag module assembly. CAUTION: Be careful not to damage the curtain airbag module during removal. Never open the curtain airbag module before activation. Never reuse the deployed curtain airbag module. Remove the modules in order starting from the vehicle front. Remove all bolts and clips, and remove the curtain airbag module assembly. Disconnect the curtain airbag module connector.

OUTBACK MODEL

CAUTIONRefer to "CAUTION" of "General Description" before handling the airbag module. Ref. to CAUTION , General Description.

Scheme 140

Scheme 140

Scheme 141

Scheme 141
  1. Turn the ignition switch to OFF.
  2. Disconnect the ground cable from battery and wait for at least 60 seconds before starting work.
  3. Remove the roof trim. Ref. to «OUTBACK MODEL»(ref-371913-S15822493882010091900000) , REMOVAL, Roof Trim.
  4. Remove the curtain airbag module assembly. CAUTION: Be careful not to damage the curtain airbag module during removal. Never open the curtain airbag module before activation. Never reuse the deployed curtain airbag module. Remove the modules in order starting from the vehicle front. Remove all bolts and clips, and remove the curtain airbag module assembly. Disconnect the curtain airbag module connector.
