Airbag System (Diagnostics): Other Subaru Outback BR

Airbag 21 illustrations ~1221 words

PROCEDURE

StepCheckYesNo
1 CHECK WARNING LIGHT. Check whether the airbag warning light in the combination meter is lit.Does the airbag warning light illuminate?Go to step 2 .Perform the diagnosis according to phenomenon of the problem.
2 READ DTC. Turn the ignition switch to OFF. Connect the Subaru Select Monitor to data link connector. Turn the ignition switch to ON and run the Subaru Select Monitor. Read the DTC. Ref. to OPERATION , Read Diagnostic Trouble Code (DTC). NOTE: If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor. Record all DTCs and freeze frame data.Is DTC displayed?Go to step 3 .Go to "Airbag warning light failure" Ref. to AIRBAG WARNING LIGHT FAILURE ..
3 PERFORM DIAGNOSIS. Determine the possible cause "List of Diagnostic Trouble Code (DTC)" Ref. to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .. Inspect the DTC using "List of Diagnostic Trouble Code (DTC)". Repair the trouble cause. Perform the Clear Memory Mode. Ref. to CLEAR MEMORY MODE . Perform the Inspection Mode. Ref. to INSPECTION MODE . Read any other DTCs displayed.Is DTC displayed?Perform the procedure 1) to 5) in step 3.Finish the diagnosis.
NOTE
If the communication function of the Subaru Select Monitor cannot be executed normally, check the communication circuit. Ref. to COMMUNICATION FOR INITIALIZING IMPOSSIBLE , INSPECTION, Subaru Select Monitor.

DIAGNOSTIC PROCEDURE

Scheme 171

Scheme 171: CHECK
Scheme 171: CHECK

CAUTION

Refer to "CAUTION" in "General Description" in Airbag System. Ref. to CAUTION , General Description.

PREPARATION TOOL

CAUTIONTo measure the voltage and resistance of airbag system component, be sure to use the specified test harness.

Scheme 172

Scheme 172: SPECIAL TOOL
Scheme 172: SPECIAL TOOL

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176

Scheme 177

Scheme 177
Scheme 177

Scheme 178

Scheme 178
Scheme 178

Scheme 179

Scheme 179
Scheme 179

Scheme 180

Scheme 180
Scheme 180

Scheme 181

Scheme 181
Scheme 181

Scheme 182

Scheme 182
Scheme 182

Scheme 183

Scheme 183
Scheme 183

Scheme 184

Scheme 184
Scheme 184

Scheme 185

Scheme 185
Scheme 185

Scheme 186

Scheme 186
Scheme 186
  1. Subaru Select Monitor SPECIAL TOOL DESCRIPTION ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 1B022XU0 SUBARU SELECT MONITOR III KIT Used for troubleshooting the electrical system.
  2. TEST HARNESS H TEST HARNESS H REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FA030 TEST HARNESS H Used when measuring voltage and resistance of the front sub sensor.
  3. TEST HARNESS N TEST HARNESS N REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA000 TEST HARNESS N Used when measuring voltage and resistance of driver's airbag module, seat belt pretensioner and curtain airbag module.
  4. TEST HARNESS P TEST HARNESS P REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA020 TEST HARNESS P Used when measuring voltage and resistance of passenger's airbag module harness.
  5. TEST HARNESS Q TEST HARNESS Q REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299SA040 TEST HARNESS Q Used when measuring voltage and resistance of driver's airbag module.
  6. TEST HARNESS AG TEST HARNESS AG REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG070 TEST HARNESS AG Used when measuring voltage and resistance of airbag control module.
  7. TEST HARNESS AH TEST HARNESS AH REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG080 (Newly adopted tool) TEST HARNESS AH Used together with test harness AG when measuring voltage and resistance of the airbag control module.
  8. TEST HARNESS V TEST HARNESS V REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG010 TEST HARNESS V Used when measuring voltage and resistance of side airbag sensor and curtain airbag sensor.
  9. AIRBAG RESISTOR AIRBAG RESISTOR REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299PA040 AIRBAG RESISTOR Used in replacement of airbag module for which resistance value is same as airbag module. Two ST are required for diagnosis of two-stage inflator type airbag module.
  10. TEST HARNESS AJ TEST HARNESS AJ REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299FG000 TEST HARNESS AJ Used when measuring power supply and resistance of side airbag harness.
  11. TEST HARNESS AI TEST HARNESS AI REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299AG090 TEST HARNESS AI Used when diagnosing the side airbag sensor and curtain airbag sensor. Used together with test harness V.
  12. TEST HARNESS AD TEST HARNESS AD REFERENCE ILLUSTRATION TOOL NUMBER DESCRIPTION REMARKS 98299XA020 TEST HARNESS AD Used when measuring voltage and resistance of the occupant detection system.

GENERAL TOOL

TOOL NAMEREMARKS
Circuit testerUsed for measuring resistance, voltage and current.
OscilloscopeUsed for measuring the sensor.

GENERAL TOOL DESCRIPTION

Scheme 187

Scheme 187: LOCATION
Scheme 187: LOCATION

Scheme 188

Scheme 188
Scheme 188
  1. OUTBACK model
  2. Sedan model CONNECTOR TERMINAL DESCRIPTION Connector No. (AB1) (AB2) (AB6) (AB7) (AB9) (AB13) (AB16) (AB17) (AB18) (AB19) (AB21) (AB23) Pin 10 4 30 4 4 2 2 15 or 24 15 or 24 4 2 4 Color Gray Yellow Yellow Yellow Yellow Yellow Yellow Yellow Yellow Yellow Black Yellow Male/Female Female Female Female Male Female Female Female Female Female Female Female Female Connector No. (AB24) (AB26) (AB28) (AB31) (AB32) (AB33) (AB34) (AB35) (AB37) (AB38) (AB53) (AB59) Pin 4 2 4 2 4 2 4 2 2 2 3 3 Color Yellow Black Yellow Black Yellow Black Yellow (1) Orange Black Brown Brown Male/Female Female Female Female Female Female Female Female Female Female Female Female Male Connector No. (AB60) (AB61) Pin 2 10 Color Yellow Black Male/Female Male Female (1) White or natural

For operation procedures, refer to "Airbag Connector". Ref. to AIRBAG CONNECTOR .

Scheme 189

Scheme 189: ELECTRICAL SPECIFICATION
Scheme 189: ELECTRICAL SPECIFICATION

Scheme 190

Scheme 190
Scheme 190
  1. OUTBACK model
  2. Terminal numbers in airbag control module connector are shown in the figure.
  3. Airbag warning light illuminates when the connector is removed from airbag control module. CONTROL MODULE TERMINAL REFERENCE Item Control module terminal No. Data link connector (1) - 16 Combination meter (1) - 11 Ignition power supply Dedicated fuse (1) - 21 Passenger's airbag module level one + (1) - 4 - (1) - 3 Passenger's airbag module level two + (1) - 1 - (1) - 2 Driver's airbag module level one + (1) - 5 - (1) - 6 Driver's airbag module level two + (1) - 8 - (1) - 7 Front sub sensor LH + (1) - 30 - (1) - 28 Front sub sensor RH + (1) - 29 - (1) - 27 Ground line (GND) (1) - 25 (1) - 26 Passenger's airbag ON indicator (1) - 23 Passenger's airbag OFF indicator (1) - 17 Passenger's seat belt warning (1) - 15 Side airbag sensor LH Curtain airbag sensor LH + (3) - 17 - (3) - 18 Side airbag module LH + (3) - 8 - (3) - 7 Curtain airbag module LH + (3) - 5 - (3) - 6 Seat belt pretensioner LH + (3) - 4 - (3) - 3 Side airbag sensor RH Curtain airbag sensor RH + (2) - 24 - (2) - 23 Seat belt pretensioner RH + (2) - 5 - (2) - 6 Side airbag module RH + (2) - 1 - (2) - 2 Curtain airbag module RH + (2) - 4 - (2) - 3 Occupant detection control module + (2) - 9 - (2) - 17
  4. Sedan model
  5. Terminal numbers in airbag control module connector are shown in the figure.
  6. Airbag warning light illuminates when the connector is removed from airbag control module. CONTROL MODULE TERMINAL REFERENCE Item Control module terminal No. Data link connector (1) - 16 Combination meter (1) - 11 Ignition power supply Dedicated fuse (1) - 21 Passenger's airbag module level one + (1) - 4 - (1) - 3 Passenger's airbag module level two + (1) - 1 - (1) - 2 Driver's airbag module level one + (1) - 5 - (1) - 6 Driver's airbag module level two + (1) - 8 - (1) - 7 Front sub sensor LH + (1) - 30 - (1) - 28 Front sub sensor RH + (1) - 29 - (1) - 27 Ground line (GND) (1) - 25 (1) - 26 Passenger's airbag ON indicator (1) - 23 Passenger's airbag OFF indicator (1) - 17 Passenger's seat belt warning (1) - 15 Seat belt pretensioner LH + (3) - 4 - (3) - 5 Side airbag sensor LH Curtain airbag sensor LH + (3) - 8 - (3) - 11 Side airbag module LH + (3) - 7 - (3) - 6 Curtain airbag module LH + (3) - 9 - (3) - 10 Seat belt pretensioner RH + (2) - 2 - (2) - 1 Side airbag sensor RH Curtain airbag sensor RH + (2) - 8 - (2) - 15 Side airbag module RH + (2) - 9 - (2) - 10 Curtain airbag module RH + (2) - 7 - (2) - 6 Occupant detection control module + (2) - 14 - (2) - 13

Recreate the circumstance by referring to the conditions described in the checklist.

DETECTING CONDITION

  1. Airbag warning light is faulty.
  2. Airbag control module to airbag warning light circuit is shorted or open.
  3. Grounding circuit is faulty.
  4. Airbag control module is faulty.
  5. Connector connection is improper.
  6. Connection of (AB6, AB17, and AB18) to airbag control module is improper.
CAUTIONBefore performing diagnosis, refer to "CAUTION" in "General Description". Ref. to CAUTION , General Description.

Scheme 191

Scheme 191: WIRING DIAGRAM
Scheme 191: WIRING DIAGRAM
StepCheckYesNo
1 READ DTC. Read the DTC. Ref. to READ DIAGNOSTIC TROUBLE CODE (DTC) .Is DTC displayed?Go to step 2 .Go to step 3 .
2 CHECK DTC.Is the displayed DTC 2D?Go to step 3 .Perform the diagnosis according to DTC.
3 CHECK FOR POOR CONTACT. Turn the ignition switch to OFF, disconnect the battery ground cable, and wait for 60 seconds or more. Confirm that the connectors of airbag control module (AB6, AB17, and AB18) are securely connected.Is there poor contact of connectors (AB6, AB17, and AB18)?If the poor contact of the connector is not fixed, replace the airbag main harness along with body harness or replace the airbag control module. Ref. to AIRBAG CONTROL MODULE .Go to step 4 .
4 CHECK AIRBAG MAIN HARNESS. Remove the instrument panel lower cover and column cover, and disconnect the connectors (AB7) and (AB2). Remove the console front panel and disconnect the connector (AB9). Disconnect the connectors (AB6, AB17, and AB18) from the airbag control module, and connect the connector (1 AG) in the test harness AG. NOTE: For sedan models, connect test harness AH between the connectors (AB6, AB17, AB18) and (1AG). Connect the battery ground terminal and turn the ignition switch to ON. Connect the connectors (7AG) and (8AG) in the test harness AG. NOTE: After the fault has been cleared, disconnect the connectors (7 AG) and (8AG).Does the airbag warning light go off?Go to step 5 .Go to step 6 .
5 CHECK GROUND CIRCUIT. Measure the resistance between connector (2AG) in the test harness AG and chassis ground. Connector & terminal (2AG) No. 4 - Chassis ground: (2AG) No. 3 - Chassis groundIs the resistance less than 10 ohms?Replace the airbag control module. Ref. to AIRBAG CONTROL MODULE .Repair the chassis ground circuit.
6 CHECK AIRBAG MAIN HARNESS AND BULKHEAD HARNESS. Disconnect the connectors (7AG) and (8AG). Remove the combination meter. Measure the resistance between the combination meter connector and test harness AG connector (2AG). Connector & terminal (2AG) No. 5 - (i10) No. 12Is the resistance less than 10 ohms?Check the combination meter.Go to step 7 .
7 CHECK POOR CONTACT OF CONNECTOR. Turn the ignition switch to OFF, disconnect the battery ground terminal, and wait 60 seconds or more. Confirm that there is a firm contact between connectors (AB1) and (B495).Is there poor contact of connector?Repair the bulkhead harness or replace the airbag main harness along with bulkhead harness.Go to step 8 .
8 CHECK AIRBAG MAIN HARNESS. Check the airbag main harness for defect.Is there any defect in the airbag main harness?Replace the airbag main harness along with bulkhead harness.Repair the bulkhead harness.
NOTE
For sedan models, connect test harness AH between the connectors (AB6, AB17, AB18) and (1AG).
NOTE
After the fault has been cleared, disconnect the connectors (7 AG) and (8AG).

DIAGNOSTIC PROCEDURE

  1. Fuse No. 5 (in fuse & relay box) is blown out.
  2. Body harness circuit is open.
  3. Airbag warning light is faulty.
  4. Airbag main harness is faulty.
  5. Airbag control module is faulty.
CAUTIONBefore performing diagnosis, refer to "CAUTION" in "General Description". Ref. to CAUTION , General Description.

LIST

DTCDisplayContent of diagnosisReference
11Driver's Airbag failureAirbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 11 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
12Passenger's Airbag failureAirbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 12 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
15Driver's Airbag failureAirbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 15 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
16Passenger's Airbag failureAirbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 16 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
1ADriver's Airbag failureAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 1A DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
1BPassenger's Airbag failureAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 1B PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
1DDriver's Airbag failureAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 1D DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
1EPassenger's Airbag failureAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 1E PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
21Airbag ECU failureAirbag control module is faulty.Ref. to DTC 21 AIRBAG ECM FAILURE , Diagnostic Chart with Trouble Code.
22Front Airbag: Firing outputFront airbag module and seat belt pretensioner (LH/RH) are inflated.Ref. to DTC 22 FRONT AIRBAG FIRING OUTPUT , Diagnostic Chart with Trouble Code.
26Passenger's Airbag Indicator FailurePassenger's airbag indicator is faulty. Airbag control module is faulty. Airbag main harness circuit is open, shorted or shorted to ground. Body harness circuit is open.Ref. to DTC 26 PASSENGER'S AIRBAG INDICATOR FAILURE , Diagnostic Chart with Trouble Code.
27ODS Communication ErrorOccupant detection control module communication is faulty. Airbag rear harness circuit is open, shorted, shorted to ground or shorted to power supply. Occupant detection harness is faulty. Airbag control module is faulty. Occupant detection system is faulty.Ref. to DTC 27 ODS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
29ODS FailureOccupant detection sensor is faulty. Occupant detection control module is faulty. Occupant detection harness is faulty. Fuse is blown.Ref. to DTC 29 ODS FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
2AODS Calibration ErrorOccupant detection control module is faulty. Calibration of occupant detection control module is initial setting or faulty.Ref. to DTC 2A ODS CALIBRATION ERROR , Diagnostic Chart with Trouble Code.
2BODS System Wrong PartsSpecification of occupant detection control module is improper. Occupant detection control module is faulty.Ref. to DTC 2B ODS SYSTEM WRONG PARTS , Diagnostic Chart with Trouble Code.
2DAirbag Warning Indicator FailureAirbag warning light is faulty. Open or short circuit in harness between airbag control module and airbag warning light. Poor contact of airbag main harness and instrument panel harness. Ground circuit is faulty. Airbag control module is faulty.Ref. to DTC 2D AIRBAG WARNING INDICATOR FAILURE , Diagnostic Chart with Trouble Code.
33Front Sub Sensor RH failureFront sub sensor (RH) is faulty.Ref. to DTC 33 FRONT SUB SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
34Front Sub Sensor LH failureFront sub sensor (LH) is faulty.Ref. to DTC 34 FRONT SUB SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
37Buckle Switch RH FailurePassenger's buckle switch circuit is open, shorted or shorted to ground. Occupant detection system is faulty. Occupant detection harness is faulty.Ref. to DTC 37 BUCKLE SWITCH RH FAILURE , Diagnostic Procedure with Diagnostic Trouble Code (DTC).
39Seat Belt Warning FailureAirbag control module is faulty. Body integrated unit is faulty. Harness circuits between body integrated unit and airbag control module are open, shorted or shorted to ground.Ref. to DTC 39 SEAT BELT WARNING FAILURE , Diagnostic Chart with Trouble Code.
3AFront Sub Sensor RH false installationFront sensor (RH) is misinstalled. Airbag control module is faulty.Ref. to DTC 3A FRONT SUB SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
3BFront Sub Sensor LH false installationFront sensor (LH) is misinstalled. Airbag control module is faulty.Ref. to DTC 3B FRONT SUB SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
41Side Airbag RH failureSide airbag harness (RH) circuit is shorted to ground. Side airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 41 SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
42Side Airbag LH failureSide airbag harness (LH) circuit is shorted to ground. Side airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 42 SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
45Side Airbag RH failureSide airbag harness (RH) circuit is shorted to power supply. Side airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 45 SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
46Side Airbag LH failureSide airbag harness (LH) circuit is shorted to power supply. Side airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 46 SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
4ASide Airbag RH failureSide airbag harness (RH) circuit is shorted. Side airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 4A SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
4BSide Airbag LH failureSide airbag harness (LH) circuit is shorted. Side airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 4B SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
4DSide Airbag RH failureSide airbag harness (RH) circuit is open. Side airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 4D SIDE AIRBAG RH FAILURE , Diagnostic Chart with Trouble Code.
4ESide Airbag LH failureSide airbag harness (LH) circuit is open. Side airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 4E SIDE AIRBAG LH FAILURE , Diagnostic Chart with Trouble Code.
53Side Airbag Sensor RH failureSide airbag sensor (RH) is faulty.Ref. to DTC 53 SIDE AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
54Side Airbag Sensor LH failureSide airbag sensor (LH) is faulty.Ref. to DTC 54 SIDE AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
55Side/Curtain Airbag: Firing outputSide airbag module and curtain airbag module are deployed. Curtain airbag module is deployed.Ref. to DTC 55 SIDE CURTAIN AIRBAG FIRING OUTPUT , Diagnostic Chart with Trouble Code.
58Curtain Airbag Sensor RH failureCurtain airbag sensor (RH) is faulty.Ref. to DTC 58 CURTAIN AIRBAG SENSOR RH FAILURE , Diagnostic Chart with Trouble Code.
59Curtain Airbag Sensor LH failureCurtain airbag sensor (LH) is faulty.Ref. to DTC 59 CURTAIN AIRBAG SENSOR LH FAILURE , Diagnostic Chart with Trouble Code.
5ASide Airbag Sensor RH false installationSide airbag sensor (RH) is misinstalled. Airbag control module is faulty.Ref. to DTC 5A SIDE AIRBAG SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5BSide Airbag Sensor LH false installationSide airbag sensor (LH) is misinstalled. Airbag control module is faulty.Ref. to DTC 5B SIDE AIRBAG SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5CCurtain Airbag Sensor RH false installationCurtain airbag sensor (RH) is misinstalled. Airbag control module is faulty.Ref. to DTC 5C CURTAIN AIRBAG SENSOR RH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
5DCurtain Airbag Sensor LH false installationCurtain airbag sensor (LH) is misinstalled. Airbag control module is faulty.Ref. to DTC 5D CURTAIN AIRBAG SENSOR LH FALSE INSTALLATION , Diagnostic Chart with Trouble Code.
61Belt Pretensioner RH failureSeat belt pretensioner (RH) circuit is shorted to ground. Pretensioner (RH) is faulty. Pretensioner harness is shorted to ground. Airbag control module is faulty.Ref. to DTC 61 BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
62Belt Pretensioner LH failureSeat belt pretensioner (LH) circuit is shorted to ground. Pretensioner (LH) is faulty. Pretensioner harness is shorted to ground. Airbag control module is faulty.Ref. to DTC 62 BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
65Belt Pretensioner RH failureSeat belt pretensioner (RH) circuit is shorted to power supply. Pretensioner (RH) is faulty. Pretensioner harness is shorted to power supply. Airbag control module is faulty.Ref. to DTC 65 BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
66Belt Pretensioner LH failureSeat belt pretensioner (LH) circuit is shorted to power supply. Pretensioner (LH) is faulty. Pretensioner harness is shorted to power supply. Airbag control module is faulty.Ref. to DTC 66 BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
6ABelt Pretensioner RH failureSeat belt pretensioner (RH) circuit is shorted. Pretensioner (RH) is faulty. Pretensioner harness is shorted. Airbag control module is faulty.Ref. to DTC 6A BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
6BBelt Pretensioner LH failureSeat belt pretensioner (LH) circuit is shorted. Pretensioner (LH) is faulty. Pretensioner harness is shorted. Airbag control module is faulty.Ref. to DTC 6B BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
6DBelt Pretensioner RH failureSeat belt pretensioner (RH) circuit is open. Pretensioner (RH) is faulty. Pretensioner harness is open. Airbag control module is faulty.Ref. to DTC 6D BELT PRETENSIONER RH FAILURE , Diagnostic Chart with Trouble Code.
6EBelt Pretensioner LH failureSeat belt pretensioner (LH) circuit is open. Pretensioner (LH) is faulty. Pretensioner harness is open. Airbag control module is faulty.Ref. to DTC 6E BELT PRETENSIONER LH FAILURE , Diagnostic Chart with Trouble Code.
71Driver's Airbag failureAirbag main harness circuit is shorted to ground. Airbag module harness (driver's side) circuit is shorted to ground. Roll connector circuit is shorted to ground. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 71 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
72Passenger's Airbag failureAirbag main harness circuit is shorted to ground. Airbag module harness (passenger's side) circuit is shorted to ground. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 72 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
75Driver's Airbag failureAirbag main harness circuit is shorted to power supply. Airbag module harness circuit (driver's side) is shorted to power supply. Roll connector circuit is shorted to power supply. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 75 DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
76Passenger's Airbag failureAirbag main harness circuit is shorted to power supply. Airbag module harness (passenger's side) circuit is shorted to power supply. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 76 PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
7ADriver's Airbag failureAirbag main harness circuit is shorted. Airbag module harness (driver's side) circuit is shorted. Roll connector circuit is shorted to power supply. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 7A DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
7BPassenger's Airbag failureAirbag main harness circuit is shorted. Airbag module harness circuit (passenger's side) is shorted. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 7B PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
7DDriver's Airbag failureAirbag main harness circuit is open. Airbag module harness circuit (driver's side) is open. Roll connector circuit is open. Driver's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 7D DRIVER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
7EPassenger's Airbag failureAirbag main harness circuit is open. Airbag module harness circuit (passenger's side) is open. Passenger's airbag module is faulty. Airbag control module is faulty.Ref. to DTC 7E PASSENGER'S AIRBAG FAILURE , Diagnostic Chart with Trouble Code.
91Curtain Airbag Module RH FailureCurtain airbag harness (RH) circuit is shorted to ground. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 91 CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
92Curtain Airbag Module LH FailureCurtain airbag harness (LH) circuit is shorted to ground. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 92 CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
95Curtain Airbag Module RH FailureCurtain airbag harness (RH) is shorted to power supply. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 95 CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
96Curtain Airbag Module LH FailureCurtain airbag harness (LH) is shorted to power supply. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 96 CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
9ACurtain Airbag Module RH FailureCurtain airbag harness (RH) circuit is shorted. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 9A CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
9BCurtain Airbag Module LH FailureCurtain airbag harness (LH) circuit is shorted. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 9B CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
9DCurtain Airbag Module RH FailureCurtain airbag harness (RH) circuit is open. Curtain airbag module (RH) is faulty. Airbag control module is faulty.Ref. to DTC 9D CURTAIN AIRBAG MODULE RH FAILURE , Diagnostic Chart with Trouble Code.
9ECurtain Airbag Module LH FailureCurtain airbag harness (LH) circuit is open. Curtain airbag module (LH) is faulty. Airbag control module is faulty.Ref. to DTC 9E CURTAIN AIRBAG MODULE LH FAILURE , Diagnostic Chart with Trouble Code.
A1Front Sensor Bus Communication errorOpen or short circuit in harness between airbag control module and front sub sensor. Front sub sensor is faulty. Airbag control module is faulty.Ref. to DTC A1 FRONT SENSOR BUS COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
BBRoll Over: Firing OutputCurtain airbag module (LH/RH) and seat belt pretensioner (LH/RH) are deployed.Ref. to DTC BB ROLL OVER: FIRING OUTPUT , Diagnostic Chart with Trouble Code.
E3 E4Front Sensor Bus RH Communication errorOpen or short circuit in harness (RH) between airbag control module and front sub sensor. Front sub sensor (RH) is faulty. Airbag control module is faulty.Ref. to DTC E3 FRONT SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC E4 FRONT SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
E7 E8Front Sensor Bus LH Communication errorOpen or short circuit in harness (LH) between airbag control module and front sub sensor. Front sub sensor (LH) is faulty. Airbag control module is faulty.Ref. to DTC E7 FRONT SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC E8 FRONT SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
E9Side Sensor Bus RH Communication errorOpen or short circuit in harness (RH) between airbag control module and curtain airbag sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.Ref. to DTC E9 SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
EB ECSide Sensor Bus RH Communication errorOpen or short circuit in harness (RH) between airbag control module and side airbag sensor. Side airbag sensor (RH) is faulty. Airbag control module is faulty.Ref. to DTC EB SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC EC SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
ED EESide Sensor Bus RH Communication errorOpen or short circuit in harness (RH) between airbag control module and curtain airbag sensor. Side airbag sensor (RH) is faulty. Curtain airbag sensor (RH) is faulty. Airbag control module is faulty.Ref. to DTC ED SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC EE SIDE SENSOR BUS RH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F1Side Sensor Bus LH Communication errorOpen or short circuit in harness (LH) between airbag control module and curtain airbag sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.Ref. to DTC F1 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F3 F4Side Sensor Bus LH Communication errorOpen or short circuit in harness (LH) between airbag control module and side airbag sensor. Side airbag sensor (LH) is faulty. Airbag control module is faulty.Ref. to DTC F3 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC F4 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
F5 F6Side Sensor Bus LH Communication errorOpen or short circuit in harness (LH) between airbag control module and curtain airbag sensor. Side airbag sensor (LH) is faulty. Curtain airbag sensor (LH) is faulty. Airbag control module is faulty.Ref. to DTC F5 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code. Ref. to DTC F6 SIDE SENSOR BUS LH COMMUNICATION ERROR , Diagnostic Chart with Trouble Code.
