Engine Ignition System - Ignition (H6DO): Removal & Installation Subaru Outback BP рестайлинг

REMOVAL

Spark plug

Refer to "SPECIFICATION" for the spark plug. < Ref. to SPECIFICATION , General Description . >

Scheme 39

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. RH SIDE Remove the collector cover. Disconnect the ground cable from the battery. Remove the air cleaner case. < Ref. to «REMOVAL»(ref-306919-S29381940832008122600000) , Air Cleaner Case . > Remove the bracket (A). Disconnect the connector (B) from ignition coil. Remove the ignition coil. NOTE: Turn the #5 ignition coil to remove it. Remove the spark plug with a spark plug socket.
2. LH SIDE Remove the collector cover. Remove the battery and battery carrier. Remove the bracket (A). Disconnect the connector (B) from ignition coil. Remove the ignition coil. NOTE: Turn the #6 ignition coil to remove it. Remove the spark plug with a spark plug socket.

INSTALLATION

1. RH SIDE Install in the reverse order of removal. Tightening torque (Spark plug): 21 N.m (2.1 kgf-m, 15.5 ft-lb) Tightening torque (Ignition coil): 16 N.m (1.6 kgf-m, 11.8 ft-lb)
2. LH SIDE Install in the reverse order of removal. Tightening torque (Sparkplug): 21 N.m (2.1 kgf-m, 15.5 ft-lb) Tightening torque (Ignition coil): 16 N.m (1.6 kgf-m, 11.8 ft-lb)

Direct ignition type has been adopted. Refer to "Spark Plug" for removal procedure. < Ref. to REMOVAL , Spark Plug . >

Install in the reverse order of removal.

Tightening torque

16 N.m (1.6 kgf-m, 11.8 ft-lb)
