Engine Ignition System - Ignition (H4DOTC): Removal & Installation Subaru Outback BP рестайлинг

Ignition System 3 illustrations ~154 words

REMOVAL

CAUTIONAll spark plugs installed on an engine must be of the same heat range.

Spark plug

< Refer to SPECIFICATION , General Description . >

Scheme 29

Scheme 29: RH SIDE
Scheme 29: RH SIDE

Scheme 30

Scheme 30
Scheme 30
  1. Remove the collector cover.
  2. Disconnect the ground cable from battery.
  3. Remove the air cleaner case. < Refer to «REMOVAL»(ref-303068-S16847708932008102300000) , Air Cleaner Case . >
  4. Disconnect the connector from ignition coil.
  5. Remove the ignition coil. NOTE: Turn #3 ignition coil by 180 degrees to remove it.
  6. Remove the spark plug with a spark plug socket.

Scheme 31

Scheme 31: LH SIDE
Scheme 31: LH SIDE
  1. Remove the collector cover.
  2. Remove the battery and battery carrier.
  3. Disconnect the connector from ignition coil.
  4. Remove the ignition coil. NOTE: Turn #4 ignition coil by 180 degrees to remove it.
  5. Remove the spark plug with a spark plug socket.

Direct ignition type has been adopted. Refer to " REMOVAL , Spark Plug" for removal procedure.

INSTALLATION

Install in the reverse order of removal.

Tightening torque

16 N.m (1.6 kgf-m, 11.7 ft-lb)
