Diagnostic Trouble Code (DTC) Detecting Criteria (H6DO): Other Subaru Outback BP рестайлинг

Testing & Diagnostics 1 illustration ~5923 words

LIST

DTCItemIndex
P0011Intake Camshaft Position - Timing Over-Advanced or System Performance (Bank 1)< Ref. to DTC P0011 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0016Crankshaft Position - Camshaft Position Correlation (Bank 1)< Ref. to DTC P0016 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0018Crankshaft Position - Camshaft Position Correlation (Bank 2)< Ref. to DTC P0018 CRANKSHAFT POSITION - CAMSHAFT POSITION CORRELATION (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0021Intake Camshaft Position - Timing Over-Advanced or System Performance (Bank 2)< Ref. to DTC P0021 INTAKE CAMSHAFT POSITION - TIMING OVER-ADVANCED OR SYSTEM PERFORMANCE (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0026Intake Valve Control Solenoid Circuit Range/Performance (Bank 1)< Ref. to DTC P0026 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE / PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0028Intake Valve Control Solenoid Circuit Range/Performance (Bank 2)< Ref. to DTC P0028 INTAKE VALVE CONTROL SOLENOID CIRCUIT RANGE / PERFORMANCE (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0030HO2S Heater Control Circuit (Bank 1 Sensor 1)< Ref. to DTC P0030 HO2S HEATER CONTROL CIRCUIT (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0031HO2S Heater Control Circuit Low (Bank 1 Sensor 1)< Ref. to DTC P0031 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0032HO2S Heater Control Circuit High (Bank 1 Sensor 1)< Ref. to DTC P0032 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0037HO2S Heater Control Circuit Low (Bank 1 Sensor 2)< Ref. to DTC P0037 HO2S HEATER CONTROL CIRCUIT LOW (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0038HO2S Heater Control Circuit High (Bank 1 Sensor 2)< Ref. to DTC P0038 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0050HO2S Heater Control Circuit (Bank 2 Sensor 1)< Ref. to DTC P0050 HO2S HEATER CONTROL CIRCUIT (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0051HO2S Heater Control Circuit Low (Bank 2 Sensor 1)< Ref. to DTC P0051 HO2S HEATER CONTROL CIRCUIT LOW (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0052HO2S Heater Control Circuit High (Bank 2 Sensor 1)< Ref. to DTC P0052 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0057HO2S Heater Control Circuit Low (Bank 2 Sensor 2)< Ref. to DTC P0057 HO2S HEATER CONTROL CIRCUIT LOW (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0058HO2S Heater Control Circuit High (Bank 2 Sensor 2)< Ref. to DTC P0058 HO2S HEATER CONTROL CIRCUIT HIGH (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0068MAP/MAF - Throttle Position Correlation< Ref. to DTC P0068 MAP/MAF - THROTTLE POSITION CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0076Intake Valve Control Solenoid Circuit Low (Bank 1)< Ref. to DTC P0076 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0077Intake Valve Control Solenoid Circuit High (Bank 1)< Ref. to DTC P0077 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0082Intake Valve Control Solenoid Circuit Low (Bank 2)< Ref. to DTC P0082 INTAKE VALVE CONTROL SOLENOID CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0083Intake Valve Control Solenoid Circuit High (Bank 2)< Ref. to DTC P0083 INTAKE VALVE CONTROL SOLENOID CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0101Mass or Volume Air Flow Circuit Range/Performance< Ref. to DTC P0101 MASS OR VOLUME AIR FLOW CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0102Mass or Volume Air Flow Circuit Low Input< Ref. to DTC P0102 MASS OR VOLUME AIR FLOW CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0103Mass or Volume Air Flow Circuit High Input< Ref. to DTC P0103 MASS OR VOLUME AIR FLOW CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0107Manifold Absolute Pressure/Barometric Pressure Circuit Low Input< Ref. to DTC P0107 MANIFOLD ABSOLUTE PRESSURE / BAROMETRIC PRESSURE CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0108Manifold Absolute Pressure/Barometric Pressure Circuit High Input< Ref. to DTC P0108 MANIFOLD ABSOLUTE PRESSURE / BAROMETRIC PRESSURE CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0111Intake Air Temperature Sensor 1 Circuit Range/Performance< Ref. to DTC P0111 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0112Intake Air Temperature Sensor 1 Circuit Low< Ref. to DTC P0112 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0113Intake Air Temperature Sensor 1 Circuit High< Ref. to DTC P0113 INTAKE AIR TEMPERATURE SENSOR 1 CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0117Engine Coolant Temperature Circuit Low< Ref. to DTC P0117 ENGINE COOLANT TEMPERATURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0118Engine Coolant Temperature Circuit High< Ref. to DTC P0118 ENGINE COOLANT TEMPERATURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0122Throttle/Pedal Position Sensor / Switch "A" Circuit Low< Ref. to DTC P0122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0123Throttle/Pedal Position Sensor / Switch "A" Circuit High< Ref. to DTC P0123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0125Insufficient Coolant Temperature for Closed Loop Fuel Control< Ref. to DTC P0125 INSUFFICIENT COOLANT TEMPERATURE FOR CLOSED LOOP FUEL CONTROL , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0126Insufficient Engine Coolant Temperature for Stable Operation< Ref. to DTC P0126 INSUFFICIENT ENGINE COOLANT TEMPERATURE FOR STABLE OPERATION , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0128Coolant Thermostat (Engine Coolant Temperature Below Thermostat Regulating Temperature)< Ref. to DTC P0128 COOLANT THERMOSTAT (ENGINE COOLANT TEMPERATURE BELOW THERMOSTAT REGULATING TEMPERATURE) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0131O2 Sensor Circuit Low Voltage (Bank 1 Sensor 1)< Ref. to DTC P0131 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0132O2 Sensor Circuit High Voltage (Bank 1 Sensor 1)< Ref. to DTC P0132 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0133O2 Sensor Circuit Slow Response (Bank 1 Sensor 1)< Ref. to DTC P0133 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0134O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 1)< Ref. to DTC P0134 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0137O2 Sensor Circuit Low Voltage (Bank 1 Sensor 2)< Ref. to DTC P0137 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0138O2 Sensor Circuit High Voltage (Bank 1 Sensor 2)< Ref. to DTC P0138 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0139O2 Sensor Circuit Slow Response (Bank 1 Sensor 2)< Ref. to DTC P0139 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0140O2 Sensor Circuit No Activity Detected (Bank 1 Sensor 2)< Ref. to DTC P0140 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 1 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0151O2 Sensor Circuit Low Voltage (Bank 2 Sensor 1)< Ref. to DTC P0151 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0152O2 Sensor Circuit High Voltage (Bank 2 Sensor 1)< Ref. to DTC P0152 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0153O2 Sensor Circuit Slow Response (Bank 2 Sensor 1)< Ref. to DTC P0153 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0154O2 Sensor Circuit No Activity Detected (Bank 2 Sensor 1)< Ref. to DTC P0154 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0157O2 Sensor Circuit Low Voltage (Bank 2 Sensor 2)< Ref. to DTC P0157 O2 SENSOR CIRCUIT LOW VOLTAGE (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0158O2 Sensor Circuit High Voltage (Bank 2 Sensor 2)< Ref. to DTC P0158 O2 SENSOR CIRCUIT HIGH VOLTAGE (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0159O2 Sensor Circuit Slow Response (Bank 2 Sensor 2)< Ref. to DTC P0159 O2 SENSOR CIRCUIT SLOW RESPONSE (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0160O2 Sensor Circuit No Activity Detected (Bank 2 Sensor 2)< Ref. to DTC P0160 O2 SENSOR CIRCUIT NO ACTIVITY DETECTED (BANK 2 SENSOR 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0171System Too Lean (Bank 1)< Ref. to DTC P0171 SYSTEM TOO LEAN (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0172System Too Rich (Bank 1)< Ref. to DTC P0172 SYSTEM TOO RICH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0174System Too Lean (Bank 2)< Ref. to DTC P0174 SYSTEM TOO LEAN (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0175System Too Rich (Bank 2)< Ref. to DTC P0175 SYSTEM TOO RICH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0181Fuel Temperature Sensor "A" Circuit Range/Performance< Ref. to DTC P0181 FUEL TEMPERATURE SENSOR "A" CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0182Fuel Temperature Sensor "A" Circuit Low Input< Ref. to DTC P0182 FUEL TEMPERATURE SENSOR "A" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0183Fuel Temperature Sensor "A" Circuit High Input< Ref. to DTC P0183 FUEL TEMPERATURE SENSOR "A" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0196Engine Oil Temperature Sensor Circuit Range/Performance< Ref. to DTC P0196 ENGINE OIL TEMPERATURE SENSOR CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0197Engine Oil Temperature Sensor Low< Ref. to DTC P0197 ENGINE OIL TEMPERATURE SENSOR LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0198Engine Oil Temperature Sensor High< Ref. to DTC P0198 ENGINE OIL TEMPERATURE SENSOR HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0222Throttle/Pedal Position Sensor / Switch "B" Circuit Low< Ref. to DTC P0222 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0223Throttle/Pedal Position Sensor / Switch "B" Circuit High< Ref. to DTC P0223 THROTTLE/PEDAL POSITION SENSOR/SWITCH "B" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0230Fuel Pump Primary Circuit< Ref. to DTC P0230 FUEL PUMP PRIMARY CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0301Cylinder 1 Misfire Detected< Ref. to DTC P0301 CYLINDER 1 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0302Cylinder 2 Misfire Detected< Ref. to DTC P0302 CYLINDER 2 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0303Cylinder 3 Misfire Detected< Ref. to DTC P0303 CYLINDER 3 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0304Cylinder 4 Misfire Detected< Ref. to DTC P0304 CYLINDER 4 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0305Cylinder 5 Misfire Detected< Ref. to DTC P0305 CYLINDER 5 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0306Cylinder 6 Misfire Detected< Ref. to DTC P0306 CYLINDER 6 MISFIRE DETECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0327Knock Sensor 1 Circuit Low (Bank 1 or Single Sensor)< Ref. to DTC P0327 KNOCK SENSOR 1 CIRCUIT LOW (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0328Knock Sensor 1 Circuit High (Bank 1 or Single Sensor)< Ref. to DTC P0328 KNOCK SENSOR 1 CIRCUIT HIGH (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0332Knock Sensor 2 Circuit Low (Bank 2)< Ref. to DTC P0332 KNOCK SENSOR 2 CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0333Knock Sensor 2 Circuit High (Bank 2)< Ref. to DTC P0333 KNOCK SENSOR 2 CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0335Crankshaft Position Sensor "A" Circuit< Ref. to DTC P0335 CRANKSHAFT POSITION SENSOR "A" CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0336Crankshaft Position Sensor "A" Circuit Range/Performance< Ref. to DTC P0336 CRANKSHAFT POSITION SENSOR "A" CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0340Camshaft Position Sensor "A" Circuit (Bank 1 or Single Sensor)< Ref. to DTC P0340 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 1 OR SINGLE SENSOR) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0345Camshaft Position Sensor "A" Circuit (Bank 2)< Ref. to DTC P0345 CAMSHAFT POSITION SENSOR "A" CIRCUIT (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0400Exhaust Gas Recirculation Flow< Ref. to DTC P0400 EXHAUST GAS RECIRCULATION FLOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0420Catalyst System Efficiency Below Threshold (Bank 1)< Ref. to DTC P0420 CATALYST SYSTEM EFFICIENCY BELOW THRESHOLD (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0442Evaporative Emission Control System Leak Detected (Small Leak)< Ref. to DTC P0442 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0447Evaporative Emission Control System Vent Control Circuit Open< Ref. to DTC P0447 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT OPEN , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0448Evaporative Emission Control System Vent Control Circuit Shorted< Ref. to DTC P0448 EVAPORATIVE EMISSION CONTROL SYSTEM VENT CONTROL CIRCUIT SHORTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0451Evaporative Emission Control System Pressure Sensor< Ref. to DTC P0451 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0452Evaporative Emission Control System Pressure Sensor Low Input< Ref. to DTC P0452 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0453Evaporative Emission Control System Pressure Sensor High Input< Ref. to DTC P0453 EVAPORATIVE EMISSION CONTROL SYSTEM PRESSURE SENSOR HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0456Evaporative Emission Control System Leak Detected (Very Small Leak)< Ref. to DTC P0456 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (VERY SMALL LEAK) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0457Evaporative Emission Control System Leak Detected (Fuel Cap Loose/Off)< Ref. to DTC P0457 EVAPORATIVE EMISSION CONTROL SYSTEM LEAK DETECTED (FUEL CAP LOOSE/OFF) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0458Evaporative Emission System Purge Control Valve Circuit Low< Ref. to DTC P0458 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0459Evaporative Emission System Purge Control Valve Circuit High< Ref. to DTC P0459 EVAPORATIVE EMISSION SYSTEM PURGE CONTROL VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0461Fuel Level Sensor "A" Circuit Range / Performance< Ref. to DTC P0461 FUEL LEVEL SENSOR "A" CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0462Fuel Level Sensor "A" Circuit Low< Ref. to DTC P0462 FUEL LEVEL SENSOR "A" CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0463Fuel Level Sensor "A" Circuit High< Ref. to DTC P0463 FUEL LEVEL SENSOR "A" CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0464Fuel Level Sensor Circuit Intermittent< Ref. to DTC P0464 FUEL LEVEL SENSOR CIRCUIT INTERMITTENT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0500Vehicle Speed Sensor "A"< Ref. to DTC P0500 VEHICLE SPEED SENSOR "A" , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0506Idle Air Control System RPM Lower Than Expected< Ref. to DTC P0506 IDLE AIR CONTROL SYSTEM RPM LOWER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0507Idle Air Control System RPM Higher Than Expected< Ref. to DTC P0507 IDLE AIR CONTROL SYSTEM RPM HIGHER THAN EXPECTED , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0512Starter Request Circuit< Ref. to DTC P0512 STARTER REQUEST CIRCUIT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0513Incorrect Immobilizer Key< Ref. to DTC P0513 INCORRECT IMMOBILIZER KEY , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0600Serial Communication Link< Ref. to DTC P0600 SERIAL COMMUNICATION LINK , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0604Internal Control Module Random Access Memory (RAM) Error< Ref. to DTC P0604 INTERNAL CONTROL MODULE RANDOM ACCESS MEMORY (RAM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0605Internal Control Module Read Only Memory (ROM) Error< Ref. to DTC P0605 INTERNAL CONTROL MODULE READ ONLY MEMORY (ROM) ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0607Control Module Performance< Ref. to DTC P0607 CONTROL MODULE PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0638Throttle Actuator Control Range / Performance (Bank 1)< Ref. to DTC P0638 THROTTLE ACTUATOR CONTROL RANGE / PERFORMANCE (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P0700Transmission Control System (MIL Request)< Ref. to DTC P0700 TRANSMISSION CONTROL SYSTEM (MIL REQUEST) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1152O2 Sensor Circuit Range/Performance (Low) (Bank 1 Sensor 1)< Ref. to DTC P1152 O2 SENSOR CIRCUIT RANGE / PERFORMANCE (LOW) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1153O2 Sensor Circuit Range/Performance (High) (Bank 1 Sensor 1)< Ref. to DTC P1153 O2 SENSOR CIRCUIT RANGE / PERFORMANCE (HIGH) (BANK 1 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1154O2 Sensor Circuit Range/Performance (Low) (Bank 2 Sensor 1)< Ref. to DTC P1154 O2 SENSOR CIRCUIT RANGE / PERFORMANCE (LOW) (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1155O2 Sensor Circuit Range/Performance (High) (Bank 2 Sensor 1)< Ref. to DTC P1155 O2 SENSOR CIRCUIT RANGE / PERFORMANCE (HIGH) (BANK 2 SENSOR 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1160Return Spring Failure< Ref. to DTC P1160 RETURN SPRING FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1400Fuel Tank Pressure Control Solenoid Valve Circuit Low< Ref. to DTC P1400 FUEL TANK PRESSURE CONTROL SOLENOID VALVE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1420Fuel Tank Pressure Control Sol. Valve Circuit High< Ref. to DTC P1420 FUEL TANK PRESSURE CONTROL SOL. VALVE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1443Vent Control Solenoid Valve Function Problem< Ref. to DTC P1443 VENT CONTROL SOLENOID VALVE FUNCTION PROBLEM , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1492EGR Solenoid Valve Signal #1 Circuit Malfunction (Low Input)< Ref. to DTC P1492 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1493EGR Solenoid Valve Signal #1 Circuit Malfunction (High Input)< Ref. to DTC P1493 EGR SOLENOID VALVE SIGNAL #1 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1494EGR Solenoid Valve Signal #2 Circuit Malfunction (Low Input)< Ref. to DTC P1494 EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1495EGR Solenoid Valve Signal #2 Circuit Malfunction (High Input)< Ref. to DTC P1495 EGR SOLENOID VALVE SIGNAL #2 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1496EGR Solenoid Valve Signal #3 Circuit Malfunction (Low Input)< Ref. to DTC P1496 EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1497EGR Solenoid Valve Signal #3 Circuit Malfunction (High Input)< Ref. to DTC P1497 EGR SOLENOID VALVE SIGNAL #3 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1498EGR Solenoid Valve Signal #4 Circuit Malfunction (Low Input)< Ref. to DTC P1498 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (LOW INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1499EGR Solenoid Valve Signal #4 Circuit Malfunction (High Input)< Ref. to DTC P1499 EGR SOLENOID VALVE SIGNAL #4 CIRCUIT MALFUNCTION (HIGH INPUT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1560Back-up voltage circuit malfunction< Ref. to DTC P1560 BACK-UP VOLTAGE CIRCUIT MALFUNCTION , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1570Antenna< Ref. to DTC P1570 ANTENNA , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1571Reference Code Incompatibility< Ref. to DTC P1571 REFERENCE CODE INCOMPATIBILITY , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1572IMM Circuit Failure (Except Antenna Circuit)< Ref. to DTC P1572 IMM CIRCUIT FAILURE (EXCEPT ANTENNA CIRCUIT) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1574Key Communication Failure< Ref. to DTC P1574 KEY COMMUNICATION FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1576EGI Control Module EEPROM< Ref. to DTC P1576 EGI CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1577IMM Control Module EEPROM< Ref. to DTC P1577 IMM CONTROL MODULE EEPROM , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1578Meter Failure< Ref. to DTC P1578 METER FAILURE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P1602Control Module Programming Error< Ref. to DTC P1602 CONTROL MODULE PROGRAMMING ERROR , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2088Intake Camshaft Position Actuator Control Circuit Low (Bank 1)< Ref. to DTC P2088 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2089Intake Camshaft Position Actuator Control Circuit High (Bank 1)< Ref. to DTC P2089 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 1) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2092Intake Camshaft Position Actuator Control Circuit Low (Bank 2)< Ref. to DTC P2092 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT LOW (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2093Intake Camshaft Position Actuator Control Circuit High (Bank 2)< Ref. to DTC P2093 INTAKE CAMSHAFT POSITION ACTUATOR CONTROL CIRCUIT HIGH (BANK 2) , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2096Post Catalyst Fuel Trim System Too Lean Bank 1< Ref. to DTC P2096 POST CATALYST FUEL TRIM SYSTEM TOO LEAN BANK 1 , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2097Post Catalyst Fuel Trim System Too Rich Bank 1< Ref. to DTC P2097 POST CATALYST FUEL TRIM SYSTEM TOO RICH BANK 1 , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2098Post Catalyst Fuel Trim System Too Lean Bank 2< Ref. to DTC P2098 POST CATALYST FUEL TRIM SYSTEM TOO LEAN BANK 2 , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2099Post Catalyst Fuel Trim System Too Rich Bank 2< Ref. to DTC P2099 POST CATALYST FUEL TRIM SYSTEM TOO RICH BANK 2 , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2101Throttle Actuator Control Motor Circuit Range/Performance< Ref. to DTC P2101 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2102Throttle Actuator Control Motor Circuit Low< Ref. to DTC P2102 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2103Throttle Actuator Control Motor Circuit High< Ref. to DTC P2103 THROTTLE ACTUATOR CONTROL MOTOR CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2109Throttle/Pedal Position Sensor "A" Minimum Stop Performance< Ref. to DTC P2109 THROTTLE/PEDAL POSITION SENSOR "A" MINIMUM STOP PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2122Throttle/Pedal Position Sensor / Switch "D" Circuit Low Input< Ref. to DTC P2122 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2123Throttle/Pedal Position Sensor / Switch "D" Circuit High Input< Ref. to DTC P2123 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2127Throttle/Pedal Position Sensor / Switch "E" Circuit Low Input< Ref. to DTC P2127 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT LOW INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2128Throttle/Pedal Position Sensor / Switch "E" Circuit High Input< Ref. to DTC P2128 THROTTLE/PEDAL POSITION SENSOR/SWITCH "E" CIRCUIT HIGH INPUT , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2135Throttle/Pedal Position Sensor / Switch "A"/"B" Voltage Correlation< Ref. to DTC P2135 THROTTLE/PEDAL POSITION SENSOR/SWITCH "A"/"B" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2138Throttle/Pedal Position Sensor / Switch "D"/"E" Voltage Correlation< Ref. to DTC P2138 THROTTLE/PEDAL POSITION SENSOR/SWITCH "D"/"E" VOLTAGE CORRELATION , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2227Barometric Pressure Circuit Range / Performance< Ref. to DTC P2227 BAROMETRIC PRESSURE CIRCUIT RANGE / PERFORMANCE , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2228Barometric Pressure Circuit Low< Ref. to DTC P2228 BAROMETRIC PRESSURE CIRCUIT LOW , Diagnostic Trouble Code (DTC) Detecting Criteria . >
P2229Barometric Pressure Circuit High< Ref. to DTC P2229 BAROMETRIC PRESSURE CIRCUIT HIGH , Diagnostic Trouble Code (DTC) Detecting Criteria . >

DIAGNOSTIC TROUBLE CODE REFERENCE

ENABLE CONDITION

Secondary ParametersEnable Conditions
Time of establishing all secondary parameter conditions> or = 3000 ms
Battery voltage> or = 10.9 V
Engine speed> or = 1500 RPM
Engine coolant temperature> or = 50°C (122°F)
AVCS controlOperation
Target advance angle> or = 0°CA
Target timing advance change amount (per 64 ms)< 1.07°CA

ENABLE CONDITION

GENERAL DRIVING CYCLE

Perform the diagnosis continuously after warming up when the engine speed increases and AVCS operates.

MALFUNCTION INDICATOR LIGHT CLEAR CONDITIONS

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

FAIL SAFE

Fix valve lift amount to High

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Engine speed> or = 500 RPM
Engine coolant temperature> or = 50°C (122°F)
AVCS controlNot in operation
Target timing advance0°CA

ENABLE CONDITION

Perform the diagnosis continuously after starting engine and while AVCS is not operating.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Fix valve lift amount to High

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
After engine starting> or = 6000 ms
Engine oil temperature> or = 0°C (32°F)
Variable valve lift controlOperation

ENABLE CONDITION

Perform the diagnosis continuously 6 seconds after engine start while variable valve lift is being controlled

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Condition established time> or = 30000 ms
Battery voltage> or = 10.9 V
Heater currentPermitted
Control duty > or = 35 %Experienced
After fuel cut> or = 20000 ms

ENABLE CONDITION

Perform the diagnosis continuously after 30000 ms or more have passed since the engine started.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Rear oxygen sensor sub learning compensation: Not allowed to calculate.
  3. Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
  2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
  3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor activation judgment: Front oxygen (A/F) sensor full activation is not complete, or front oxygen (A/F) sensor half activation is not complete.
  2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
  3. Compensation when starting the engine at high temperature: Make the MIN value to be 0.3 --> 0, normally.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 1 second
Engine speed< 4500 RPM

ENABLE CONDITION

After starting the engine, perform the diagnosis continuously when engine is low speed.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 1 second
Engine speed< 4500 RPM

ENABLE CONDITION

After starting the engine, perform the diagnosis continuously when engine is low speed.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis continuously after idling.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Intake manifold pressure sensor process: Estimate the pressure from the engine speed and size of the throttle opening. When the throttle opening is also NG, fix at 66.7 kPa (500 mmHg, 19.69 inHg).
  2. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
  3. Fuel cut control: Fuel cut will operate at engine high speed.
  4. EVAP cone, learning (fuel): Not allowed to learn.
  5. Knocking compensation

When normal: Learning ignition advance angle value = knock F/B advance angle + entire learning advance angle value + portional learning advance angle value

Failure: learned ignition advance value = -6°CA. (6°CA retard)

Knock F/B advance angle value = 0°CA

Whole learning prohibited

Portional learning prohibited

  1. ISC control: ISC feedback amount calculation prohibited Amount of ISC open-loop compensation = Fixed at 6.82%
  2. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis continuously after idling.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
  2. EVAP cone, learning (fuel): Not allowed to learn.
  3. Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value When normal: Knock compensation value = Fixed at 0°CA Failure: Knock compensation value * Fixed at 0° CA (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed Portional learning zone compensation value calculation not allowed
  4. ISC control: Open loop compensation is set to (1 g (0.04 oz)/s). Stop calculation of throttle sensor temperature compensation (hold previous value)
  5. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Air flow meter: Engine load is normally calculated by manifold pressure and engine speed; however, calculated only by manifold pressure.
  2. EVAP cone, learning (fuel): Not allowed to learn.
  3. Knock compensation: Knock compensation final advance/delay angle value = knock compensation value + whole learning compensation value + portional learning compensation value When normal: Knock compensation value = Fixed at 0°CA Failure: Knock compensation value * Fixed at 0° CA (When knock: Max. 12°CA retard) Whole learning compensation coefficient update not allowed Portional learning zone compensation value calculation not allowed
  4. ISC control: Open loop compensation is set to (1 g (0.04 oz)/s). Stop calculation of throttle sensor temperature compensation (hold previous value)
  5. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Intake manifold pressure sensor process: Estimate the pressure from the engine speed and size of the throttle opening. When the throttle opening is also NG, fix at 66.7 kPa (500 mmHg, 19.69 inHg).
  2. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
  3. Fuel cut control: Fuel cut will operate at engine high speed.
  4. EVAP cone, learning (fuel): Not allowed to learn.
  5. Knocking compensation

When normal: Learning ignition advance angle value = knock F/B advance angle + entire learning advance angle value + portional learning advance angle value

Failure: learned ignition advance value = -6°CA. (6°CA retard)

Knock F/B advance angle value = 0°CA

Whole learning prohibited

Portional learning prohibited

  1. ISC control: ISC feedback amount calculation prohibited Amount of ISC open-loop compensation = Fixed at 6.82 %
  2. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Intake manifold pressure sensor process: Estimate the pressure from the engine speed and size of the throttle opening. When the throttle opening is also NG, fix at 66.7 kPa (500 mmHg, 19.69 inHg).
  2. Heavy fuel judgment: Not allowed to carry out the heavy judgment.
  3. Fuel cut control: Fuel cut will operate at engine high speed.
  4. EVAP cone, learning (fuel): Not allowed to learn.
  5. Knocking compensation

When normal: Learning ignition advance angle value = knock F/B advance angle + entire learning advance angle value + portions! learning advance angle value

Failure: learned ignition advance value = -6°CA. (6°CA retard)

Knock F/B advance angle value = 0°CA

Whole learning prohibited

Portional learning prohibited

  1. ISC control: ISC feedback amount calculation prohibited Amount of ISC open-loop compensation = Fixed at 6.82%
  2. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Engine coolant temperature at engine starting< 30°C (86°F)
Engine coolant temperature> or = 95°C (203°F)
Battery voltage> or = 10.9 V
Continuous time when the vehicle speed is less than 60 km/h (37.3 MPH)> or = 600 sec

ENABLE CONDITION

Perform the diagnosis when the vehicle speed condition is met after warming up from a cold condition.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Intake air temperature sensor process: Intake air temperature is fixed at 20°C (68°F).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
  2. ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
  3. ISC learning: Not allowed to learn.
  4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
  5. Air conditioner control: Not allowed to turn the air conditioner to ON.
  6. Radiator fan control: Both main and sub fan are in High driving.
  7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
  2. ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
  3. ISC learning: Not allowed to learn.
  4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
  5. Air conditioner control: Not allowed to turn the air conditioner to ON.
  6. Radiator fan control: Both main and sub fan are in High driving.
  7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Engine speed> or = Value from Map
Battery voltage> or = 10.9 V

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)110 (230)
Engine speed RPM500500

MAP REFERENCE

Perform the diagnosis only once after engine start.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Engine coolant temperature sensor process: Engine coolant temperature is fixed at 70°C (158°F).
  2. ISC Feedback: Calculate target engine speed as engine coolant temperature 70°C (158°F).
  3. ISC learning: Not allowed to learn.
  4. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.
  5. Air conditioner control: Not allowed to turn the air conditioner to ON.
  6. Radiator fan control: Both main and sub fan are in High driving.
  7. High water temperature expansion compensation coefficient: Normally, mass expands with high water temperature and other conditions, but this ignores water temperature conditions and expands when other conditions are established.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Refueling from the last engine stop till the current engine startNone
Fuel level> or = 15 L (3.963 US gal, 3.3 lmp gal)
Engine coolant temperature at the last engine stop> or = 75°C (167°F)

ENABLE CONDITION

Perform the diagnosis only once after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor heater control: Not allowed to turn on heater.
  2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
  3. A/F sub learning: Not allowed to calculate the A/F sub learning compensation factor.
  4. Compensation when starting the engine at high temperature: Make the MIN value to be 0.06 --> 0, normally.
  5. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor heater control: Not allowed to turn on heater
  2. A/F main learning: Not allowed to calculate the A/F main learning compensation factor.
  3. A/F sub learning: Not allowed to calculate the A/F sub learning compensation factor.
  4. Compensation when starting the engine at high temperature: Make the MIN value to be 0.06 --> 0, normally.
  5. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 1024 ms
Battery voltage> or = 10.9 V
Barometric pressure> 75.05 kPa (563 mmHg, 22.165 inHg)
Closed loop control with main feedbackOperation
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Elapsed time after starting the engine> or = 120000 ms
Engine coolant temperature> or = 75°C (167°F)
Engine speed1000 RPM - 2500 RPM
Vehicle speed10 km/h - 120 km/h (6.2 MPH - 74.6 MPH)
Amount of intake air10 g/s - 40 g/s (0.353 oz/s - 1.411 oz/s)
Engine load< 0.02 g/rev (0.001 oz/rev)
Learning value of EVAP cone, during purge< 0.2
Total time of operating canister purge> or = 19.9 sec

ENABLE CONDITION

Perform diagnosis only once at a constant speed of 10 km/h - 120 km/h (6.2 MPH - 74.6 MPH) 120000 ms or more after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Rear oxygen sensor sub learning compensation: Not allowed to calculate.
  3. Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor IC communication: Not allowed to communicate.
  2. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  3. Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
  4. Purge control: Not allowed to purge.

Used for abnormality judgment

Secondary ParametersEnable Conditions
High
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Low (1)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air> or = 10 g/s (0.353 oz/s)
Low (2)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air< 10 g/s (0.353 oz/s)
Current continuation time of the rear oxygen sensor heater> or = 25000 ms
Low (3)
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)
Amount of intake air< 10 g/s (0.353 oz/s)
Current continuation time of the rear oxygen sensor heater> or = 25000 ms
Fuel cutExperienced

ENABLE CONDITION

Used for normality judgment

Secondary ParametersEnable Conditions
Secondary air systemNot in operation
Closed loop control at the oxygen sensorIn operation
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Engine coolant temperature> or = 75°C (167°F)

ENABLE CONDITION

After starting the engine, continuously perform the diagnosis with the same engine condition.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

Rich --> lean diagnosis response

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
A/F main feedback control conditionCompleted
Deceleration fuel cut time is 5000 ms or more.Experienced
After fuel cut> or = 2000 ms
Current calculation time of the rear oxygen sensor heater> or = 40000 ms
Current continuation time of the rear oxygen sensor heater> or = 20000 ms
Estimated catalyst temperature> or = 400°C (752°F)
Number of deceleration fuel cut> or = 1 time

ENABLE CONDITION

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

Lean --> rich response diagnosis

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
A/F main feedback control conditionCompleted
Deceleration fuel cut time is 5000 ms or more.Experienced
After fuel cut> or = 2000 ms
Current calculation time of the rear oxygen sensor heater> or = 0 ms
Current continuation time of the rear oxygen sensor heater> or = 0 ms
Estimated catalyst temperature> or = 0°C (32°F)
Number of deceleration fuel cut> or = 1 time

ENABLE CONDITION

Perform the diagnosis only once when deceleration fuel cut occurs after rapid acceleration. (Pay attention to the oxygen sensor voltage for the timing of the deceleration.)

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

ENABLE CONDITION (USED ONLY FOR MALFUNCTION JUDGMENT)

Secondary ParametersEnable Conditions
Closed loop control at the rear oxygen sensorIn operation
Target output voltage of rear oxygen sensor> or = 0.55 V + 0.05 V
Amount of intake air> or = 10 g/s (0.353 oz/s)
Engine coolant temperature> or = 75°C (167°F)
Misfire detection every 200 rotations< 7 time
Front oxygen (A/F) sensor compensation coefficientNot in limit value
Battery voltage> or = 10.9 V
Deceleration fuel cut of 5000 ms or more.Experienced

ENABLE CONDITION

Perform the diagnosis once after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Sub feedback control: Not allowed

Secondary ParametersEnable Conditions
A/F main learning systemIn operation
Engine coolant temperature> or = 75°C (167°F)
Engine load change< 0.02 g/rev (0.001 oz/rev)
Engine load> or = Value of Map 1

ENABLE CONDITION

Map 1

Engine speed (RPM)Idling700100015002000250030003500400045005000
Measured value (g(oz)/rev)Non-turbo0.357 (0.013)0.25 (0.009)0.25 (0.009)0.317 (0.011)0.326 (0.011)0.337 (0.012)0.397 (0.014)0.439 (0.015)0.454 (0.016)0.454 (0.016)

MAP 1 REFERENCE

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

  1. When similar driving conditions are repeated 3 times and the result is OK.
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
A/F main learning systemIn operation
Engine coolant temperature> or = 75°C (167°F)
Engine load change< or = 0.02 g/rev (0.001 oz/rev)
Learning value of EVAP cone.< 0.1
Cumulative time of canister purge after engine start> or = 20 sec
Continuous period after canister purge starting< or = 29884 ms
Engine load> or = Value of Map 1

ENABLE CONDITION

Map 1

Engine speed (RPM)Idling700100015002000250030003500400045005000
Measured value (g(oz)/rev)Non-turbo0.357 (0.013)0.25 (0.009)0.25 (0.009)0.317 (0.011)0.326 (0.011)0.337 (0.012)0.397 (0.014)0.439 (0.015)0.454 (0.016)0.454 (0.016)

MAP 1 REFERENCE

Perform the diagnosis continuously at idling or at a constant speed after warming up the engine.

  1. When similar driving conditions are repeated 3 times and the result is OK.
  2. When "Clear Memory" is performed
  1. Purge control solenoid valve control: Not allowed to purge.
  2. Heavy fuel judgment control: Not allowed to carry out the heavy judgment.

DRIFT DIAGNOSIS

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Stuck Diagnosis

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 20000 ms
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform diagnosis after 20 seconds have passed since the engine started.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Engine speed> or = Value from Map

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)110 (230)
Engine speed RPM500500

MAP REFERENCE

Perform the diagnosis continuously after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Oil temperature sensor process: Engine oil temperature is fixed at 70°C (158°F).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Oil temperature sensor process: Engine oil temperature is fixed at 70°C (158°F).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Oil temperature sensor process: Engine oil temperature is fixed at 70°C (158°F).

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

OFF setting may be needed depending on the NG portion.

Secondary ParametersEnable Conditions
All secondary parameters enable conditions> or = 1024 ms
Intake manifold pressure change at 120°CA< Value of Map 1
Throttle position change during 16 milliseconds< 20 deg
Fuel shut-off functionNot in operation
Fuel level> or = 9.6 L (2.536 US gal, 2.112 lmp gal)
Vehicle dynamic control or AT torque controlNot in operation
Evaporative system leak checkNot in operation
Engine speed400 RPM - 8000 RPM
Intake manifold pressure> or = Value of Map 2
Battery voltage> or = 8 V
Fuel parameter determinationNot extremely low volatility
Elapsed time after starting the engine> or = 0 ms
Engine speed change during 32 milliseconds< 500 RPM

ENABLE CONDITION

Map 1

RPM7001000150020002500300035004000450050005500600065007000
KPa (mmHg, inHg)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)20 (150, 5.906)

MAP 1 REFERENCE

Map 2

RPM7001000150020002500300035004000450050005500600065007000
KPa (mmHg, inHg)26.66 (200.0, 7.874)23.33 (175.0, 6.89)23.33 (175.0, 6.89)23.33 (175.0, 6.89)23.59 (177.0, 6.968)24.39 (183.0, 7.205)28.33 (212.5, 8.366)32.29 (242.2, 9.535)36.26 (272.0, 10.709)36.26 (272.0, 10.709)37.19 (279.0, 10.984)38.12 (286.0, 11.26)41.86 (314.0, 12.362)48.92 (367.0, 14.449)

MAP 2 REFERENCE

  1. If conditions are met, it is possible to detect the misfires from idling to high engine speed. However, to avoid excessive load or harm to the engine, perform diagnosis at idle.
  2. Perform the diagnosis continuously.
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Knocking compensation

When normal: Learning ignition advance angle value = knock F/B advance angle + entire learning advance angle value + portional learning advance angle value

Failure: learned ignition advance value = -6°CA. (6°CA retard)

Knock F/B advance angle value = 0°CA

Whole learning prohibited

Portional learning prohibited

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Knocking compensation

When normal: Learning ignition advance angle value = knock F/B advance angle + entire learning advance angle value + portional learning advance angle value

Failure: learned ignition advance value = -6°CA. (6°CA retard)

Knock F/B advance angle value = 0°CA

Whole learning prohibited

Portional learning prohibited

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 8 V
Engine speed< 3000 RPM

ENABLE CONDITION

Perform the diagnosis continuously under 3000 RPM engine speed.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 8 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment from abnormality judgment, and then make the whole learning incomplete.
  2. Ignition timing partial learning compensation: Enter the initial value (0° CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0° CA) to the compensation value of the partial learning zone when making a normality judgment --> abnormality judgment.
  3. AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced.
  4. ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the OCV driving Duty to be the given value (9.36%).
Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 40 sec
Engine coolant temperature> or = 75°C(167°F)
Engine speed1200 RPM - 3250 RPM
Intake manifold pressure (absolute pressure)< 36.66 kPa (275 mmHg, 10.827 inHg)
Ambient air temperature> or = 5°C(41°F)
Throttle position< 0.25 deg
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Vehicle speed> or = 53 km/h (32.9 MPH)
Fuel shut-off functionIn operation
Neutral switchOFF
After neutral switch ON/OFF change> or = Value from Map
No load change (A/C, power steering, lighting, rear defogger, heater fan and radiator fan)> or = 5000 ms

ENABLE CONDITION

Map

Engine coolant temperature °C (°F)40 (-40)30 (-22)20 (-4)10 (14)0 (32)10 (50)20 (68)30 (86)
After neutral switch change msec00000000

MAP REFERENCE

Engine coolant temperature °C (°F)40 (104)50 (122)60 (140)70 (158)80 (176)90 (194)100 (212)110 (230)
After neutral switch change msec00000000

MAP REFERENCE

During deceleration fuel cut from 53 km/h (approx. 33 MPH) or more, perform diagnosis once.

Be careful of vehicle speed and engine speed. (Diagnosis will not be completed if the vehicle speed and engine speed conditions become out of specification due to deceleration.)

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

A/F main learning = Not allowed.

Knock learning = Not allowed.

EGR control: Operation prohibited.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Engine coolant temperature> or = 75°C (167°F)
Estimated catalyst temperature> or = 560°C (1040°F)
Misfire detection every 200 rotations< 7 time
Learning value of evaporation gas density< 0.2
Sub feedbackIn operation
Evaporative system diagnosisNot in operation
Time of difference (< 0.10) between actual lambda and target lambda> or = 1000 ms
Vehicle speed> 60 km/h (37.3 MPH)
Amount of intake air> or = 10 g/s (0.353 oz/s) and < 40 g/s (1.411 oz/s)
Engine load change every 0.5 engine speed.< 0.02 g/rev (0.001 oz/rev)
Rear oxygen output change from 660 mV or less to 660 mV or moreExperienced after fuel cut
Elapsed time after starting the engine> or = 205 sec
Purge execution calculated time> or = 5 sec

ENABLE CONDITION

Perform the diagnosis only once at a constant 60 km/h (37.3 MPH) or higher.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Pressure control solenoid valve

PCV controls the fuel tank pressure to be equal to the atmospheric air pressure. Normally, the solenoid is set to OFF. The valve opens and closes mechanically in accordance with the pressure difference between tank and atmospheric air, or tank and canister.

The valve is forcibly opened by setting the solenoid to ON at the time of diagnosis.

Scheme 306

Scheme 306: Pressure control solenoid valve

0.04-inch Diagnosis

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Total time of canister purge operation> or = 120000 ms
Elapsed time after starting the engine> or = 856 sec
Learning value of evaporation gas density< 0.08
Engine speed1050 RPM - 6500 RPM
Fuel tank pressure> or = -4 kPa (-30 mmHg, -1.181 inHg)
Intake manifold relative vacuum (relative pressure)> or = - 26.66 kPa (- 200 mmHg, - 7.874 inHg)
Vehicle speed> or = 32 km/h (19.9 MPH)
Fuel level9.6 L (2.536 US gal, 2.112 lmp gal) - 54.4 L (14.372 US gal, 11.968 lmp gal)
Closed air/fuel ratio controlIn operation
Fuel temperature10°C (14°F) - 45°C (113°F)
Intake air temperature> or = -10°C (14°F)
Pressure change every one second< 1.7 mmHg (Mode A) < 1.7 mmHg (Mode D)
Minimum pressure change value every one second - Maximum pressure change value every one second< 1.7 mmHg (Mode A)
< 1.7 mmHg (Mode D)
Change of fuel level per 128 milliseconds< 2 L (0.528 US gal, 0.44 lmp gal)
Air fuel ratio0.76 - 1.25

ENABLE CONDITION

0.02-inch Diagnosis

Secondary ParametersEnable Conditions
At starting a diagnosis
Evap. diagnosisIncomplete
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Time since last incomplete 0.02-inch leakage diagnosis
When cancelling in mode A> 120000 ms
When cancelling in other than mode A> 600000 ms
Total time of canister purge operation> or = 120000 ms
Elapsed time after starting the engine> or = 120 sec
Fuel temperature10°C (14°F) - 55°C (131°F)
Fuel level9.6 L (2.536 US gal, 2.112 lmp gal) - 54.4 L (14.372 US gal, 11.968 lmp gal)
Intake manifold relative vacuum (relative pressure)> or = - 8 kPa (- 60 mmHg, - 2.362 inHg)
Fuel tank pressure0.67 kPa (-5 mmHg, -0.197 inHg) - 1.43 kPa (10.7 mmHg, 0.421 inHg)
Vehicle speed50 km/h (31.1 MPH) - 510 km/h (316.9 MPH) continues for 125000 ms
Closed air/fuel ratio controlIn operation
Engine speed1050 RPM - 7000 RPM
During diagnosis
Change of fuel level< or = Value of Map 4
Pressure change every one second< 0.06 kPa (0.44 mmHg, 0.017 inHg)
Minimum pressure change value every one second - Maximum pressure change value every one second< 0.07 kPa (0.51 mmHg, 0.02 inHg) (Mode D)
Pressure change in tank every second< or = 0.1 kPa (0.75 mmHg, 0.03 inHg)
Barometric pressure change0.48 kPa (-3.6 mmhg, -0.142 inHg) - 0.32 kPa (2.4 mmhg, 0.094 inHg) (Mode D) -0.32 kPa (-2.4 mmhg, -0.094 inHg) - 0.32 kPa (2.4 mmhg, 0.094 inHg) (Mode E)

ENABLE CONDITION

Map4

Fuel level ( l , US gal, lmp gal)010, 2.642, 2.220, 5.284, 4.430, 7.926, 6.640, 10.568, 8.850, 13.21, 1160, 15.852, 13.2
Change ( l , US gal, lmp gal)5, 1.321, 1.15, 1.321, 1.15, 1.321, 1.15, 1.321, 1.15, 1.321, 1.15, 1.321, 1.15, 1.321, 1.1

MAP 4 REFERENCE

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 60 sec
Fuel level> or = 9.6 L (2.536 US gal, 2.112 lmp gal)
Fuel temperature< 35°C (95°F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)

ENABLE CONDITION

  1. Perform the diagnosis continuously after 60 sec have passed since the engine started.
  2. Pay attention to the fuel level and temperature.
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Purge control solenoid valve control: Purge fixed mode is prohibited.

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Purge control solenoid valve control: Purge fixed mode is prohibited.

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 5000 ms
Vehicle speed> or = 2 km/h (1.2 MPH)
All conditions of EVAP canister purgeCompleted
Learning value of evaporation gas concentration (left and right)< 0.08
Main feedback compensation coefficient (left and right)> or = 0.9
Battery voltage> or = 10.9 V

ENABLE CONDITION

Perform the diagnosis when purging enable conditions are met without idling.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Purge control solenoid valve control: Purge fixed mode is prohibited.

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 1 second

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after starting the engine> or = 1 second

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Malfunction CriteriaThreshold Value
Engine speed> or = 500 RPM
Elapsed time after starting the engine> or = 1 second
Battery voltage> or = 10.9 V
Idle switchON
Fuel level> or = 9.6 L (2.536 US gal, 2.112 lmp gal) and < 54.4 L (14.372 US gal, 11.968 lmp gal)
Vehicle speed = 0 km/h (0 MPH)> or = 10000 ms

ENABLE CONDITION

  1. Always perform the diagnosis continuously at idle speed.
  2. Pay attention to the fuel level.
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Battery voltage> or = 10.9 V
Elapsed time after engine starting> or = 2000 ms

ENABLE CONDITION

Always perform diagnosis more than 2000 ms after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Accelerator sensor signal process: Not allowed full closed point learning (hold the previous value)
  2. ABS wheel speed sensor signal process: Vehicle speed = 10 km/h (6 MPH)
  3. Fuel cut control: Not allowed vehicle speed 0 km/h (0 MPH) fuel cut. Normally the high vehicle speed fuel cut performs on vehicle speed condition and engine speed, but perform the fuel cut only on engine speed condition (4400 RPM or more).
  4. ISC control: Open loop compensation is set to (1 g (0.04 oz) oz/s) Not allowed ISC feedback volume calculation.
  5. Air conditioner control: Not allowed air conditioner cut at accelerating.
  6. Radiator fan control: Both main and sub fan ON drive
  7. Gear ratio judgment: Gear = Control as fixed in sixth gear
Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Fuel level> or = 9.6 L (2.536 US gal, 2.112 lmp gal)
Elapsed time after starting the engine> or = 10.49 sec
Feedback of ISCIn operation
Lambda value (left and right)> or = 0.9
And
< 1.1
After switching air conditioner to ON/OFF> or = 5.1 sec
After intake manifold pressure changes by 4 kPa (30 mmHg, 1.181 inHg) or more.> 5.1 sec
Elapsed time after switching neutral position switch to ON/OFF> 5.1 sec
Vehicle speed0 km/h (0 MPH)

ENABLE CONDITION

Perform the diagnosis continuously at idling after warming up engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Judgment of heavy fuel: Not allowed to make the judgment of heavy fuel

Secondary ParametersEnable Conditions
Engine coolant temperature> or = 75°C (167°F)
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Fuel level> or = 9.6 L (2.536 US gal, 2.112 lmp gal)
Elapsed time after starting the engine> or = 10.49 sec
Feedback of ISCIn operation
Lambda value (left and right)> or = 0.9
And
< 1.1
After switching air conditioner to ON/OFF> or = 5.1 sec
After intake manifold pressure changes by 4 kPa (30 mmHg, 1.181 inHg) or more.> 5.1 sec
Elapsed time after switching neutral position switch to ON/OFF> 5.1 sec
Vehicle speed0 km/h (0 MPH)

ENABLE CONDITION

Perform the diagnosis continuously at idling after warming up engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Judgment of heavy fuel: Not allowed to make the judgment of heavy fuel

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

When starting the engine.

Perform the diagnosis only after starting the engine.

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Perform the diagnosis continuously after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Diagnosis with the initial routine.

Perform the diagnosis as soon as the ignition switch is turned to ON.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Ignition switchON

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
(1) Ignition switchON
(1) Battery voltage> or = 6 V
(2) Ignition switchON
(2) Battery voltage> or = 6 V
(3) Ignition switchON
(3) Battery voltage> or = 6 V
(4) Ignition switchON
(4) Battery voltage> or = 6 V
(5) Throttle opening angle
(5) Ignition switchON
(5) Battery voltage> or = 6 V
(6) Brake switch (only with cruise control)ON
(6) Ignition switchON
(6) Battery voltage> or = 6 V
(7) Ignition switchON
(7) Battery voltage> or = 6 V

ENABLE CONDITION

  1. (1) - (4): Always perform the diagnosis continuously.
  2. (5): Always perform the diagnosis continuously when idling.
  3. (6): Perform the diagnosis when the brake pedal is depressed.
  4. (7): Always perform the diagnosis continuously.
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Normal operation of electric throttle controlON

ENABLE CONDITION

Always perform the diagnosis continuously when the electric throttle control is operating.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 4096 ms
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Rear oxygen sensor sub feedbackExecution
Rear oxygen sensor output voltage - Feedback target voltage0.2 V - 0.1 V
Or rear oxygen sensor sub feedback compensation coefficientOn Min.
Or rear oxygen sensor sub feedback compensation coefficientOn Max.
Elapsed time after starting the engine> or = 60000 ms
Engine coolant temperature> or = 75°C (167°F)
Vehicle speed> or = 20 km/h (12.4 MPH)
Amount of intake air> or = 8 g/s (0.282 oz/s)
Load change at 120°CA< 0.02 g/rev (0.001 oz/rev)
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Learning value of evaporation gas density< 0.2
Total time of operating canister purge> or = 19.9 sec
Targeted lambda value load compensation coefficient0.050 - 0.050

ENABLE CONDITION

Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Rear oxygen sensor sub learning compensation: Not allowed to calculate.
  3. Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Time needed for all secondary parameters to be in enable conditions> or = 4096 ms
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Rear oxygen sensor sub feedbackExecution
Rear oxygen sensor output voltage - Feedback target voltage0.2 V - 0.1 V
Or rear oxygen sensor sub feedback compensation coefficientOn Min.
Or rear oxygen sensor sub feedback compensation coefficientOn Max.
Elapsed time after starting the engine> or = 60000 ms
Engine coolant temperature> or = 75°C (167°F)
Vehicle speed> or = 20 km/h (12.4 MPH)
Amount of intake air> or = 8 g/s (0.282 oz/s)
Load change at 120°CA< 0.02 g/rev (0.001 oz/rev)
Front oxygen (A/F) sensor impedance0 ohms - 50 ohms
Learning value of evaporation gas density< 0.2
Total time of operating canister purge> or = 19.9 sec
Targeted lambda value load compensation coefficient0.050 - 0.050

ENABLE CONDITION

Perform diagnosis continuously at a constant speed of 20 km/h (12.4 MPH) or more after 60000 ms have passed since the engine started.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Rear oxygen sensor sub learning compensation: Not allowed to calculate.
  3. Correction when re-starting at high temperature: Normally minimum value 0.06 --> 0.
  4. Purge control: Not allowed to purge.
Secondary ParametersEnable Conditions
Battery voltage> or = 6 V
Throttle position sensorNormal

ENABLE CONDITION

  1. Ignition switch ON --> OFF
  2. Ignition switch OFF --> ON (Only after clearing memory)
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Throttle opening is fixed to 6°.

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis after starting the engine.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Drain valveOpen
Battery voltage> or = 10.9 V
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Tank pressure when starter is OFF --> ON0.43 kPa (-3.2 mmHg, -0.126 inHg)
And
1.43 kPa (10.7 mmHg, 0.421 inHg)

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Pressure control solenoid valve control: Open the pressure control solenoid valve.

Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 1 second
EGR valve target position> 0 step
Battery voltage> or = 10.9 V

ENABLE CONDITION

Perform diagnosis continuously during EGR operation.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Knock sensor learning compensation: Calculation prohibited.
  3. EGR control: Operation prohibited.
Secondary ParametersEnable Conditions
Elapsed time after starting the engine> or = 1 second
EGR valve target position> 0 step
Battery voltage> or = 10.9 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Front oxygen (A/F) sensor main learning compensation: Not allowed to calculate.
  2. Knock sensor learning compensation: Calculation prohibited.
  3. EGR control: Operation prohibited.
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Barometric pressure> or = 75.05 kPa (563 mmHg, 22.165 inHg)
Battery voltage> or = 10.9 V
Cold start diagnosisIncomplete
Vehicle speed< 2 km/h (1.2 MPH)
Misfire within 200 engine revs.< 7
Time after starting= 14 seconds

ENABLE CONDITION

Perform the diagnosis at cold start.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
  2. Ignition timing partial learning compensation: Enter the initial value (0° CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
  3. AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced. => ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the oil flow control solenoid valve driving duty a predetermined value (9.36%).
Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed
  1. Ignition timing whole learning compensation: Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when IG OFF, and then make the whole learning incomplete. Enter the initial value (whole learning compensation factor = 0.5, Variable amount of whole learning compensation factor = 0.25) to the whole learning compensation factor and variable amount of whole learning compensation factor when making a normality judgment --> abnormality judgment, and then make the whole learning incomplete.
  2. Ignition timing partial learning compensation: Enter the initial value (0° CA) to the compensation value of partial learning zone with IG OFF. Enter the initial value (0°CA) to the compensation value of partial learning zone when making a normality judgment --> abnormality judgment.
  3. AVCS control: Maximum timing retard learning is not complete or maximum timing retard learning completion is not experienced. => ISC feedback compensation: Do not perform the AVCS actual timing advance compensation. Make the oil flow control solenoid valve driving duty a predetermined value (9.36%).
Secondary ParametersEnable Conditions
Conditions for carrying out the sub feedback learningCompleted
Continuous time when all conditions are established.> or = 1 sec

ENABLE CONDITION

Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.

  1. When similar driving conditions are repeated 3 times and the result is OK.
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Conditions for carrying out the sub feedback learningCompleted
Continuous time when all conditions are established.> or = 1 sec

ENABLE CONDITION

Perform the diagnosis continuously when the vehicle is idling or running at a constant speed of 80 km/h (50 MPH) or more.

  1. When similar driving conditions are repeated 3 times and the result is OK.
  2. When "Clear Memory" is performed

None

Secondary ParametersEnable Conditions
Under control of electronic throttle controlON
CPU communication line sub --> main normal judgmentNormal

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Battery voltage> or = 11 V
Electronic throttle control relay outputON

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Battery voltage> or = 6 V
Electronic throttle control relay outputOFF

ENABLE CONDITION

  1. When ignition switch ON --> OFF
  2. Ignition switch OFF --> ON (Only after clearing memory)
  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Ignition switchON --> OFF
Ignition switch (only after clear memory)OFF --> ON

ENABLE CONDITION

Perform the diagnosis at full closed point learning.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)
  1. Single malfunction: Control with normal sensor
  2. Simultaneous failure: Throttle opening is fixed to 6°.
Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)
  1. Single malfunction: Control with normal sensor
  2. Simultaneous failure: Throttle opening is fixed to 6°.
Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)
  1. Single malfunction: Control with normal sensor
  2. Simultaneous failure: Throttle opening is fixed to 6°.
Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)
  1. Single malfunction: Control with normal sensor
  2. Simultaneous failure: Throttle opening is fixed to 6°.
Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed (Only with engine stopped)

Stop the continuity to the electronic throttle control motor. (Throttle opening is fixed to 6°.)

Secondary ParametersEnable Conditions
Ignition switchON
Battery voltage> or = 6 V

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Throttle opening is fixed to 6°.

Secondary ParametersEnable Conditions
Engine speed< 300 RPM
Vehicle speed< 1 km/h (0.6 MPH)

ENABLE CONDITION

Perform the diagnosis once at ignition switch ON.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Barometric pressure sensor process: Fix the barometric pressure to 101 kPa (760 mmHg, 29.8 inHg).

Secondary ParametersEnable Conditions
None_

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Barometric pressure sensor process: Fix the barometric pressure to 101.3 kPa (760 mmHg, 29.9 inHg).

Secondary ParametersEnable Conditions
None

ENABLE CONDITION

Always perform the diagnosis continuously.

  1. When the OK driving cycle is completed 3 times in a row
  2. When "Clear Memory" is performed

Barometric pressure sensor process: Fix the barometric pressure to 101.3 kPa (760 mmHg, 29.9 inHg).
