Glass - Window - Mirrors: Other Subaru Outback BP

Windows 3 illustrations ~336 words

CAUTION

  1. When electrical connectors are disconnected, always conduct an operational check after connecting them again. Avoid impact and damage to the glass.

PREPARATION TOOL

TOOL NAMEREMARKS
Circuit TesterUsed for checking voltage and continuity.
Piano WireUsed for window glass removal.
Windshield KnifeUsed for window glass removal.

TOOL NAME

SEDAN

Remove glass in the same procedure as for windshield glass. Refer to REMOVAL , Windshield Glass.

Scheme 54

Scheme 54: SEDAN

WAGON

Remove glass in the same procedure as for windshield glass. Refer to REMOVAL , Windshield Glass.

Scheme 55

Scheme 55: INSTALLATION
  1. Cut off nozzle tip as shown in the figure.
  2. Install glass in the same procedure as for windshield glass. Refer to «INSTALLATION»(ref-216279-S36657178622006011800000) , Windshield Glass. CAUTION: When door is opened/closed after glass is bonded, always lower door glass and then open/close it carefully. Move vehicle slowly.
  3. After completion of all work, allow vehicle to stand for about 24 hours. NOTE: For minimum drying time and time the vehicle must be left standing before driving after bonding, follow instructions or instruction manual from the adhesive manufacturer.
  4. After curing of adhesive, pour water on external surface of vehicle to check that there are no water leaks. CAUTION: When a vehicle is returned to the user, tell him or her that the vehicle should not be subjected to heavy impact for at least three days.

SUB-SWITCH

Remove two hooks (A) of switch panel to remove power window sub-switch and disconnect electrical connector.

Scheme 56

Scheme 56: SUB-SWITCH

MAIN SWITCH

Install in the reverse order of removal.

Install in the reverse order of removal.

Measure switch resistance.

Driver's switch

Switch positionTerminal No.Standard
UP3 and 9, 7 and 1Less than 1 ohm
OFF3 and 7 and 1Less than 1 ohm
DOWN7 and 9, 3 and 1Less than 1 ohm
AUTO DOWN7 and 9, 3 and 1Less than 1 ohm

RESISTANCE REFERENCE CHART

Front passenger's switch

Switch positionTerminal No.Standard
UP9 and 5, 1 and 4Less than 1 ohm
OFF1 and 5 and 4Less than 1 ohm
DOWN9 and 4, 1 and 5Less than 1 ohm

RESISTANCE REFERENCE CHART

Rear left switch

Switch positionTerminal No.Standard
UP9 and 13, 1 and 8Less than 1 ohm
OFF1 and 13 and 8Less than 1 ohm
DOWN9 and 8, 1 and 13Less than 1 ohm

RESISTANCE REFERENCE CHART

Rear right switch

Switch positionTerminal No.Standard
UP9 and 16, 1 and 14Less than 1 ohm
OFF1 and 16 and 14Less than 1 ohm
DOWN9 and 14, 1 and 16Less than 1 ohm

RESISTANCE REFERENCE CHART

If defective, replace the main switch.

Measure switch resistance.

Front passenger's door switch and rear door switch

Switch positionTerminal No.Standard
UP5 and 1, 6 and 2Less than 1 ohm
OFF4 and 1, 6 and 2Less than 1 ohm
DOWN5 and 2, 4 and 1Less than 1 ohm

RESISTANCE REFERENCE CHART

If defective, replace the sub-switch.

AUTO A/C

Switch positionTerminal No.Standard
OFFMore than 1 Mohm
ON(i48) 13 and (i49) 12Less than 1 ohm

TERMINAL SPECIFICATION CHART

MANUAL A/C

Switch positionTerminal No.Standard
OFFMore than 1 Mohm
OFF(i17) 14 and (i17) 10Less than 1 ohm

TERMINAL SPECIFICATION CHART

Change over switch left position

Switch positionTerminal No.Standard
OFFMore than 1 Mohm
UP7 and 4, 2 and 1Less than 1 ohm
DOWN7 and 2, 4 and 1Less than 1 ohm
LEFT9 and 4, 2 and 1Less than 1 ohm
RIGHT9 and 2, 4 and 1Less than 1 ohm

TERMINAL NUMBER SPECIFICATION CHART

Change over switch right position

Switch positionTerminal No.Standard
OFFMore than 1 Mohm
UP6 and 4, 2 and 1Less than 1 ohm
DOWN6 and 2, 4 and 1Less than 1 ohm
LEFT8 and 4, 2 and 1Less than 1 ohm
RIGHT8 and 2, 4 and 1Less than 1 ohm

TERMINAL NUMBER SPECIFICATION CHART

If defective, replace the switch.

REPAIR

Refer to REPAIR under Rear Window Defogger. Refer to REPAIR , Rear Window Defogger.
