AUTOMATIC TRANSMISSION

When the DTC about automatic transmission is shown on display, carry out the following basic check. After that, carry out the replacement or repair work.

1. ATF level check < Refer to «AUTOMATIC TRANSMISSION FLUID»(ref-208395-S35776238372005120700000) .
2. Differential gear oil level check < Refer to «DIFFERENTIAL GEAR OIL»(ref-208395-S12578962472005120700000) .
3. ATF leak check < Refer to «AUTOMATIC TRANSMISSION FLUID»(ref-208395-S35776238372005120700000) .
4. Differential gear oil leak check < Refer to «DIFFERENTIAL GEAR OIL»(ref-208395-S12578962472005120700000) .
5. Stall test < Refer to «STALL TEST»(ref-208395-S11949561822005120700000) .
6. Line pressure test < Refer to «LINE PRESSURE TEST»(ref-208395-S40911946302005120700000) .
7. Transfer clutch pressure test < Refer to «TRANSFER CLUTCH PRESSURE TEST»(ref-208395-S31220221542005120700000) .
8. Time lag test < Refer to «TIME LAG TEST»(ref-208395-S14924596762005120700000) .
9. Road test < Refer to «ROAD TEST»(ref-208395-S41651055592005120700000) .
10. Shift characteristics < Refer to «TRANSFER CLUTCH PRESSURE TEST»(ref-208395-S31220221542005120700000) .

CHECK LIST NO. 1

Check the following items when problem has occurred.

Note. Use copies of this page for interviewing customers.

Scheme 1141

CHECK LIST NO.2

Check the following items about the vehicle's state when malfunction indicator light turns on.

Note. Use copies of this page for interviewing customers.

Scheme 1142

Scheme 1143

Scheme 1144

Scheme 1145

Scheme 1146

1. Airbag system wiring harness is routed near the ECM, main relay and fuel pump relay. CAUTION: All airbag system wiring harness and connectors are colored yellow. Do not use electrical test equipment on these circuit. Be careful not to damage the airbag system wiring harness when servicing the ECM, TCM, main relay and fuel pump relay.
2. Never connect the battery in reverse polarity. The ECM will be destroyed instantly. The fuel injector and other part will be damaged in just a few minutes more.
3. Do not disconnect the battery terminals while the engine is running. A large counter electromotive force will be generated in the generator, and this voltage may damage electronic parts such as ECM, etc.
4. Before disconnecting the connectors of each sensor and the ECM, be sure to turn OFF the ignition switch.
5. Poor contact has been identified as a primary cause of this problem. To measure the voltage and/or resistance of individual sensors or all electrical control modules at the harness side connector, use a tapered pin with a diameter of less than 0.64 mm (0.0.25 in). Do not insert the pin more than 5 mm (0.20 in) into the part.
6. Before removing the ECM from the located position, disconnect two cables on battery. Otherwise, the ECM may be damaged. CAUTION: When replacing the ECM, be careful not to use the wrong spec. ECM to avoid any damage on fuel injection system.
7. The connectors to each sensor in the engine compartment and the harness connectors on the engine side and body side are all designed to be waterproof. However, it is still necessary to take care not to allow water to get into the connectors when washing the vehicle, or when servicing the vehicle on a rainy day.
8. Use ECM mounting stud bolts at the body side grounding point when measuring voltage and resistance inside the passenger compartment.
9. Use engine grounding terminal or engine proper as the grounding point to the body when measuring voltage and resistance in the engine compartment. LH side RH side
10. Use TCM mounting stud bolts at the body side grounding point when measuring voltage and resistance inside the passenger compartment.
11. Every MFI-related part is a precision part. Do not drop them.
12. Observe the following cautions when installing a radio in MFI equipped models. CAUTION: The antenna must be kept as far apart as possible from the control unit. (The ECM is located under the steering column, inside of the instrument panel lower trim panel.) The antenna feeder must be placed as far apart as possible from the ECM and MFI harness. Carefully adjust the antenna for correct matching. When mounting a large power type radio, pay special attention to the three items above mentioned. Incorrect installation of the radio may affect the operation of the ECM.
13. Before disconnecting the fuel hose, disconnect the fuel pump connector and crank the engine for more than five seconds to release pressure in the fuel system. If engine starts during this operation, run it until it stops.
14. Problems in the electronic-controlled automatic transmission may be cause by failure of the engine, the electronic control system, the transmission proper, or by a combination of these. These three causes must be distinguished clearly when performing diagnostics.
15. Diagnostics should be conducted by rotating with simple, easy operations and proceeding to complicated, difficult operations. The most important thing in diagnostics is to understand the customer's complaint, and distinguish between the three causes.
16. In AT models, do not continue the stall for more than five seconds at a time (from closed throttle, fully open throttle to stall engine speed).
17. On models with ABS, when performing driving test in jacked-up or lifted-up or lifted-up position, sometimes the warning light may be lit, but this is not a malfunction of the system. The reason for this is the speed difference between the front and rear wheels. After diagnosis of engine control system, perform the ABS memory clearance procedure of self-diagnosis system.

BATTERY

1. Measure battery voltage and specific gravity of electrolyte. Standard voltage: 12 V Specific gravity: Above 1.260
2. Check the condition of the main and other fuses, and harnesses and connectors. Also check for proper grounding.

ENGINE GROUNDING

Make sure the engine grounding terminal is properly connected to the engine.

Scheme 1147

Scheme 1148

1. LH side
2. RH side

ENGINE AND EMISSION CONTROL SYSTEM

1. The Multipoint Fuel Injection (MFI) system is a system that supplies the optimum air-fuel mixture to the engine for all the various operating conditions through the use of the latest electronic technology. With this system fuel, which is pressurized at a constant pressure, is injected into the intake air passage of the cylinder head. The injection quantity of fuel is controlled by an intermittent injection system where the electro-magnetic injection valve (fuel injector) opens only for a short period of time, depending on the quantity of air required for one cycle of operation. In actual operation, the injection quantity is determined by the duration of an electric pulse applied to the fuel injector and this permit simple, yet highly precise metering of the fuel.
2. Further, all the operating conditions of the engine are converted into electric signals, and this results in additional features of the system, such as large improved adaptability, easier addition of compensating element, etc. The MFI system also has the following features: Reduced emission of harmful exhaust gases. Reduction in fuel consumption. Increased engine output. Superior acceleration and deceleration. Superior startability and warm-up performance in cold weather since compensation is made for coolant and intake air temperature.

AUTOMATIC TRANSMISSION AND ELECTRONIC-HYDRAULIC CONTROL SYSTEM

The electronic-hydraulic control system consists of various sensors and switches, the TCM and the hydraulic controller including solenoid valves. The system controls the transmission proper including shift control, lock-up control, overrunning clutch control, line pressure control and shift timing control. It also controls the AWD transfer clutch. In other words, the system detects various operating conditions from various input signals and sends output signals to shift solenoids 1, 2 and low clutch timing solenoid and 2-4 brake timing solenoid, line pressure duty solenoid, lock-up brake duty solenoid, transfer duty solenoid and 2-4 brake duty solenoid (a total of eight solenoids).

Scheme 1149

Scheme 1150

Scheme 1151

Scheme 1152

Scheme 1153

Scheme 1154

Scheme 1155

Scheme 1156

Scheme 1157

Scheme 1158

Scheme 1159

Scheme 1160

Scheme 1161

Scheme 1162

Scheme 1163

Scheme 1164

Scheme 1165

Scheme 1166

Scheme 1167

Scheme 1168

Scheme 1169

Scheme 1170

Measuring condition

1. After the engine is warmed-up.
2. Gear position is in "N" or "P" range.
3. A/C is turned OFF.
4. All accessory switches are turned OFF.

NOTE

This connector is used both for OBD-II general scan tools and the Subaru Select Monitor.

Scheme 1171

Scheme 1172

Scheme 1173

1. Prepare a general scan tool (OBD-II general scan tool) required by SAE J1978.
2. Open the cover and connect the OBD-II general scan tool to data link connector located in the lower portion of instrument panel (on the driver's side).
3. Using the OBD-II general scan tool, call up DTC and freeze frame data. OBD-II general scan tool functions consist of: MODE $01: Current powertrain diagnostic data MODE $02: Powertrain freeze frame data MODE $03: Emission-related powertrain DTC MODE $04: Clear/Reset emission-related diagnostic information MODE $06: Request on-board monitoring test results for non-continuously monitored systems MODE $07: Request on-board monitoring test results for continuously monitored systems MODE $09: Request vehicle information

Read out the data according to repair procedures. (For detailed operation procedures, refer to the OBD-II General Scan Tool Operation Manual.)

Note. For details concerning DTC, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

MODE $02 (POWERTRAIN FREEZE FRAME DATA)

Refers to data denoting the operating condition when trouble is sensed by the on-board diagnosis system. list of the support data and PID (Parameter Identification) codes are shown in the following table.

Scheme 1174

Note. Refer to OBD-II general scan tool manufacturer's instruction manual to access freeze frame data (MODE $02).

MODE $06

Refer to test value of troubleshooting and data of test limit on support data bit sequence table. List of support data is shown in the following table.

Scheme 1175

MODE $07

Refer to data of DTC (pending code) for troubleshooting result about emission in first time.

MODE $09

Refer to data of vehicle specification (VIN, calibration ID, etc.).

Scheme 1176

Scheme 1177

Scheme 1178

Scheme 1179

1. Prepare the Subaru Select Monitor kit. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
2. Connect the diagnosis cable to Subaru Select Monitor.
3. Insert the cartridge into Subaru Select Monitor. Refer to «PREPARATION TOOL»(ref-208370-S05181239172005120700000) , General Description.
4. Connect the Subaru Select Monitor to data link connector. Data link connector located in the lower portion of instrument panel (on driver's side). Connect the diagnosis cable to data link connector. CAUTION: Do not connect scan tools except for Subaru Select Monitor and OBD-II general scan tool.
5. Turn the ignition switch to ON (engine OFF) and Subaru Select Monitor switch to ON.
6. Using the Subaru Select Monitor, call up DTC and various data, then record them.

READ CURRENT DATA FOR ENGINE (NORMAL MODE)

1. On << Main Menu>> display screen, select the {Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {Current Data Display & Save} and press the [YES] key.
5. On << Data Display Menu>> display screen, select the {Data Display} and press the [YES] key.
6. Using the scroll key, move the display screen up or down until the desired data is shown. A list of support data is shown in the following table.

Scheme 1180

Scheme 1181

Note. For detailed operation procedure, refer to the Subaru Select Monitor Operation Manual.

READ CURRENT DATA FOR ENGINE (OBD MODE)

1. On << Main Menu>> display screen, select the {Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {OBD System} and press the [YES] key.
5. On << OBD Menu>> display screen, select the {Current Data Display & Save} and press the [YES] key.
6. On << Data Display Menu>> display screen, select the {Data Display} and press the [YES] key.
7. Using the scroll key, move the display screen up or down until the desired data is shown. A list of support data is shown in the following table.

Scheme 1182

Scheme 1183

Note. For detailed operation procedure, refer to the Subaru Select Monitor Operation Manual.

READ FREEZE FRAME DATA FOR ENGINE (OBD MODE)

1. On << Main Menu>> display screen, select the {Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {OBD System} and press the [YES] key.
5. On << OBD Menu>> display screen, select the {Freeze Frame Data} and press the [YES] key. A list of support data is shown in the following table.

Scheme 1184

Note. For detailed operation procedure, refer to the Subaru Select Monitor Operation Manual.

READ CURRENT DATA FOR AT

1. On << Main Menu>> display screen, select the {Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Transmission Control System} and press the [YES] key.
3. Press the [YES] key after the information of transmission type is displayed.
4. On << Transmission Diagnosis>> display screen, select the {Current Data Display & Save} and press the [YES] key.
5. On << Data Display Menu>> display screen, select the {Data Display} and press the [YES] key.
6. Using the scroll key, move the display screen up or down until the desired data is shown. A list of support data is shown in the following table.

Scheme 1185

Note. For detailed operation procedure, refer to the Subaru Select Monitor Operation Manual.

SUBARU SELECT MONITOR (NORMAL MODE)

1. On << Main Menu>> display screen, select the {Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {Diagnostic Code(s) Display} and press the [YES] key.
5. On << Diagnostic Code(s) Display>> display screen, select the {Current Diagnostic Code(s)} or {History Diagnostic Code(s)} and press the [YES] key.

Note. For detailed operation procedure, refer to SUBARU SELECT MONITOR OPERATION MANUAL . For details concerning DTC, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

SUBARU SELECT MONITOR (OBD MODE)

1. On << Main Menu>> display screen, select the {2. Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {OBD System} and press the [YES] key.
5. On << OBD Menu>> display screen, select the {Diagnosis Code(s) Display} and press the [YES] key.
6. Make sure that a DTC is shown on display screen.

Note. For detailed operation procedure, refer to SUBARU SELECT MONITOR OPERATION MANUAL . For details concerning DTC, refer to LIST OF DIAGNOSTIC TROUBLE CODE (DTC) .

PREPARATION FOR DRIVE CYCLE

1. Make sure that the fuel remains approx. half amount [20 - 40l (5.3 - 10.6 US gal, 4.4 - 8.8 lmp gal)], and battery voltage is 12 V or more.
2. After performing the diagnostics and cleaning memory, check for any remaining unresolved trouble data. Refer to «CLEAR MEMORY MODE»(ref-208370-S08712199312005120700000) .
3. Separate the test mode connector.

Note. Except for the water temperature specified items at starting, the diagnosis is carried out after engine warm up. Carry out the diagnosis which is marked * on DTC twice, then, after finishing first diagnosis, stop the engine and do second time at the same condition.

Scheme 1186

Scheme 1187

Scheme 1188

TEN MINUTES IDLING

Note. Give the vehicle at 10 km/h (6 MPH) or more before diagnosis.

Scheme 1189

1. On << Main Menu>> display screen, select the {2. Each System Check} and press the [YES] key.
2. On << System Selection Menu>> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {Clear Memory} and press the [YES] key.
5. When the `Done' and `Turn Ignition Switch OFF' are shown on display screen, turn the ignition switch to OFF, and then turn the Subaru Select Monitor to OFF.

Note. After the memory has been cleared, the idle air control solenoid valve must be initialized. To do this, turn the ignition switch to ON position. Wait 3 seconds before starting the engine. For detailed operation procedure, refer to SUBARU SELECT MONITOR OPERATION MANUAL .

1. On << Main Menu >> display screen, select the {2. Each System Check} and press the [YES] key.
2. On << System Selection Menu >> display screen, select the {Engine Control System} and press the [YES] key.
3. Press the [YES] key after the information of engine type is displayed.
4. On << Engine Diagnosis>> display screen, select the {OBD System} and press the [YES] key.
5. On << OBD Menu>> display screen, select the {4. Diagnosis Code(s) Cleared} and press the [YES] key.
6. When the `Clear Diagnostic Code?' is shown on the display screen, press the [YES] key.
7. Turn the Subaru Select Monitor and ignition switch to OFF.

Note. After the memory has been cleared, the idle air control solenoid valve must be initialized. To do this, turn the ignition switch to ON position. Wait 3 seconds before starting the engine. For detailed operation procedure, refer to SUBARU SELECT MONITOR OPERATION MANUAL .

STARTER MOTOR CIRCUIT

CONTROL MODULE POWER SUPPLY AND GROUND LINE

Scheme 1190

Scheme 1191

IGNITION CONTROL SYSTEM

Scheme 1192

Scheme 1193

Scheme 1194

FUEL PUMP CIRCUIT

Scheme 1195

Scheme 1196

Scheme 1197

FUEL INJECTOR CIRCUIT

Scheme 1198

Scheme 1199

LIST

DIAGNOSTIC TROUBLE CODE (DTC) INDEX

Note. Check general diagnostics table with non-conformity symptom for automatic transmission. Refer to BASIC DIAGNOSTIC PROCEDURE .
